STITCH WELDER MACHINE SWM Metformer

METFORMER SWM

Condition: excellent (used), High-performance spot welding tongs with a double-acting cylinder Manufacturer: DALEX, Type 3528 - 4 Rated power at 50% duty cycle: 63 kVA Secondary short-circuit current: 31 kA Electrode force: 60-730 daN Double-acting cylinder, long stroke 62 mm, pre-stroke 40 mm Working stroke with stroke adjustment 0-22 mm with 5/2-way solenoid valve Nwedpfski Tkpox Airon Cardan suspension and mounting bracket 10 m connection cable with control cable Arm extension: 170 mm Arm distance: 170 mm Complete with 1 pair of electrode arms, straight on the top and bottom, 170 mm Synchronous welding control MPS 1036 Example photo

Condition: as good as new (ex-display), Year of construction: 2024, pressure 60.0 t chamfer lenght 1270 mm distance between columns 1000 mm column arm 410 mm ram stroke speed 160 mm/sec work speed 10.0 mm/sec return speed 165 mm/sec work stroke 275 mm dayligth 530 mm table height 900 mm table width 90.0 mm back stop - adjustable max. 800 mm oil volume 150 ltr. voltage 400 V engine output 7.5 kW Weight 4320 kg range L-W-H 2250 x 1960 x 2750 mm Demonstration/demo machine (!!) From our showroom (like new) With very few operating hours ----- CNC press brake with special equipment * Version "ERGO" - knee room for the operator * flexible articulated arm mount for the controller * increased installation height * increased cylinder stroke * as well as increased bending beam speeds ----- Nsdpfxexabt Aj Airown Furnishing: - DELEM CNC control model DA-66T graphic/touch screen * 2D graphical programming * 17" TFT color screen with high resolution * Bending sequence calculation * Product programming and real size display * USB interface * intuitive, graphical entry of profiles * Automatic calculation of features: tool safety zones, Press force, bending tolerance, crown setting, stretched Length, embossing force, flattening, automatic rounding calculation * Radius programming * Graphic tool and product library * Collision monitoring * 3D visualization * 1GB memory - Motorized backgauge with R-axis, on ball screws - X = 800 mm R = 250 mm with 2 stop fingers - controlled axes : Y1 - Y2 - X - R - Deer foot upper tool with PS 135.85-R08, system "A" with quick-change clamp - additional crowning device in the tool holder of the upper tool - 4V universal die block M 460 R with die shoe 60 mm mount - BOSCH/HOERBIGER hydr. components - SIEMENS electrical system - LEUZE light barrier behind the machine - FIESSLER AKAS laser with FPSC protection device v.d. machine - Swiveling control panel, mounted on the left - Front, foldable sheet metal support - Double foot control - CE mark / declaration of conformity - Operating manual: Machine and control in German - Safety manual : press brakes

Condition: excellent (used), throat depth: 1,100 mm, nominal power at 50% duty cycle: 96 kVA, short-circuit current: 31,500 A, input voltage: 400 V, type of cooling: water, overall weight: 830 kg, Equipment: type plate available, Spot welding machine, type PMS 11-4 G3, 3-phase DC version - specifically designed for welding aluminum sheets - rarely used, completely inspected and cleaned - fully functional, ready for demonstration - rated voltage 400V/50Hz - rated power 96 kVA - welding current 23 kA - connection cable cross-section 10 sq mm/phase - fuse rating 63A - arm reach 1050 mm (!!) - electrode arm diameter 60 mm - electrode holder diameter 30 mm - electrode force 600 daN - stroke 65+25 mm - electrode cone MK2 - control unit MPS 8043/1 from Harms & Wende with current ramp-up and pulse function - with operating manual - 2-stage foot switch according to UVV standards - main machine switch - pneumatic maintenance unit - weight approx. 830 kg Njdoh N Sc Eepfx Airswn - complete documentation with wiring diagram, compressed air circuit diagram, and cooling water circuit - VAT can be shown separately - delivery from warehouse in Dresden approx. 4 days within Germany - export may take longer! On-site commissioning is subject to a charge and will be billed according to the actual effort involved. The machine is located in Dresden, near the A17 highway, and can be inspected and demonstrated by appointment.

Condition: excellent (used), 3-phase DC spot welding machine DALEX, Type PMS 11-4 G 3 Rated power at 50% duty cycle: 96 kVA Secondary short-circuit current: 44.5 kA Secondary open-circuit voltage: 4.72 V Nodpfx Aiehmvaworewn Electrode force: 100-600 daN Arm reach: 550 mm with mounting control cabinet according to VDE 0100 Main switch Synchronous welding control 8033 Weight: 740 kg

Condition: new, Year of construction: 2024, 1050 mm 5.5 mm 5.0 mm roll diameter 130 / 195 mm 2.2 kW 1050 kg 2150 x 900 x 1200 mm - 2 central rollers driven by an electric motor - Swing-out upper beam - Conical bending device - separate control panel - self-braking main motor Nwsdpoq Sz Ahsfx Airen - CE mark/Declaration of Conformity Special equipment included in the price: - hardened rollers - Motorized rear roller adjustment

Condition: new, Fastech 3-Roll Round Bending Machine FRM 1050 x 90 Technical Specifications: Special equipment included in the price: hardened rolls motorized rear roll adjustment digital display Sheet metal width 1050 mm Sheet metal thickness 3.3 mm max. Sheet metal thickness for pre-bending 3.0 mm Roll length 1050 mm Roll diameter 90 mm Smallest bending diameter 130 mm Weight 475 kg Dimensions L-W-H 1750 x 800 x 1130 mm Motor: 1.1 KW Nsdpfxehzq Dbo Airjwn Equipment: Top and bottom rolls, electrically driven Top roll can be pivoted out Taper bending device asymmetrical roll arrangement self-braking main motor separate control and operating panel Safety cable Values apply to St-37 / 240 N/mm² CE marking

Year of construction: 2001, condition: good (used), Universal CNC Turning Lathe from Pinacho apply for toolmaker , mold maker, education and Locksmith Turning diameter : 360mm Control : Fagor 8055 Technical data Turning diameter 360mm Turning lenght 1000mm Control Siemens Fagor 8055 Tailstock MK 3 Tools Barufaldi 6 pice Nsdefglzgepfx Airewn Speeds 1-4000U/min Power supply 380V - 5,5 KW Contact person: AWM GmbH Herr Mario Wurm

Condition: used, 2,000 linear meters of structural profiles, U-shape Used, good condition, see pictures Galvanized Length per piece approx. 467 cm Profile 7.5/8 cm Material thickness approx. 3 mm Weight per piece approx. 43 kg Negotiable price: €4.90 net/linear meter ex warehouse Available individually or in packs One pack consists of 20 pieces – approx. 93.4 linear meters Goods are in stock. Transport possible upon request. Inspection possible at any time by appointment. Further information available upon request. We have over 5,000 linear meters of pallet racking from numerous manufacturers in stock at all times. (Subject to changes and errors in technical data, information and prices, as well as prior sale! See our terms and conditions, all prices excl. VAT ex warehouse.) Lenox Trading – Top warehouse technology & heavy-duty racking, used & new Description: Are you looking to buy high-quality warehouse racking? With approximately 100 employees, Lenox Trading is one of the largest dealers for new and used warehouse technology in the entire DACH region (Austria, Germany, Switzerland). ⚡ IMMEDIATELY AVAILABLE: • Over 10,000 linear meters of racking available for immediate delivery • 20,000 m² of storage platforms & steel construction platforms immediately available • 30–50 semi-trailer loads of goods turnover weekly for maximum selection 📦 OUR RANGE (BUY CHEAPLY ONLINE): Whether pallet racking, heavy-duty racking, high-bay racking, shelving systems, tire racks, or racking for IBC containers – we deliver and install throughout Europe with our OWN team! Including CAD planning, transport, dismantling and assembly. Njdpsulwiqofx Airown 🏭 TOP BRANDS USED & FROM INSOLVENCY/BANKRUPTCY LIQUIDATION: • SSI Schäfer (Schäfer Lagertechnik, R 3000, PR 600, PR 300) • Jungheinrich (Type MPB, Type E, heavy-duty racking Jungheinrich) • Wezsuisse Euronorm, Bito RK 4209, Schäfer EK 113, Schäfer RK 521, Schäfer LF 533, Familog SP 6428, R-KLT 4315, RL-KLT 6147, Schäfer KLT 3214, UTZ SILAFIX 3Z, EF 3120, EF 6420 • Cantilever racking (Elvedi cantilever racking, Schäfer, Ohra) • Stow, Meta, Bito, Galler, Nedcon, Voest, SLP, Palflex, Ramada, Bauer, Ohrner 🔨 OUR SECOND BUSINESS AREA: ONLINE AUCTIONS & LIQUIDATION For dismantling and clearance projects, we offer a complete, all-round service package: 1. Flat-rate purchase: Purchase of commercial goods, equipment & complete stock including thorough clearance. 2. Commission-based auction: Conducting auctions on behalf of clients. Our full service provided by our own employees: cataloging, office preparation, inspection, goods issue, logistics, dismantling and thorough handover. Whether you became aware of us through heavy-duty racking or are looking for galvanized heavy-duty racking / heavy-duty racking systems – we guarantee the best conditions. Contact us for a non-binding offer!

Condition: used, functionality: fully functional, total height: 1,900 mm, total width: 1,200 mm, overall weight: 1,200 kg, input voltage: 400 V, Equipment: documentation/manual, type plate available, Precision cross-honing machine Used Sunnen Eclipse EC-3500 CGM-27 Nodpfx Ajyx Dv Hsirewn Bore diameter – Honing range: 1.5 – 165 mm Stroke length – Honing length: 6 – 170 mm Spindle speeds: 200 – 3,000 rpm Stroke rates: 60 – 500 strokes Total power requirement – Spindle drive: 4.1 kW Stroke motor: 1.1 kW Machine weight: approx. 1200 kg Depth: 1.6 m Width: 1.2 m Height: 1.9 m SICK safety light curtain Oil filtration / filter system for the honing oil is integrated – spare filter cartridges available Horizontal cross-honing machine / honing machine, type EC 3500, and operating manual for the honing machine Documentation/manual, nameplate available An inspection while the machine is powered on is possible after prior appointment. Price upon request All technical specifications are subject to typographical errors and omissions. Sale exclusively to countries within the EU.

Condition: new, Year of construction: 2025, functionality: fully functional, total height: 760 mm, total width: 330 mm, total length: 540 mm, overall weight: 55 kg, product height (max.): 4 mm, laser power: 1,500 W, Intelligent welding process support Give your welding process additional drive with intelligent functions. The Bodor Welding Process Database incorporates welding parameters for steel from 1 to 4 mm in terms of flat welds and fillet welds. Working as a beginner’s guide, it allows users with different levels of expertise to weld effortlessly. Nwsdpfxjqx Hnys Airsn Smart control knob The control knob is easy to navigate. Users are able to manage their welding solutions in one setting. They can select welding process and adjust welding parameters (e.g. power, weld bead width, frequency, etc) , and the knob will automatically store customized parameters for their operations in the future. Portable design, integrated power structure Without built-in water tanks or cooling fans, BodorWelder 1500 takes up a covering area of 0.24㎡. This compact machine aims to help users with complex welding jobs in diverse working scenarios. It also comes with a set of Bodor welding nozzles, fulfilling all kinds of requirements.
