Used Cnc Flatbed Lathe for sale (14,249)

Condition: good (used), Year of construction: 2013, Fanuc Oi-TD CNC control 12-fold turret head (VDI 30 taper) collet chuck device C-axis driven tools tailstock coolant device chip conveyor With the machine are 6 driven tools, some fixed tool holders, 3-jaw chuck and collets Technische Daten / technical details: Nkedep T Uxxopfx Adwot max. Umlaufdurchmesser über Bett / max rotary diameter over bed 460 mm max. Umlaufdurchmesser über Schlitten / max rotary diameter over sledge 328 mm max. Drehdurchmesser / max. turning diameter 303 mm max. Drehlänge / max. turning lenght 334 mm Planweg (x) / cross way (x) 181 mm Längsweg (z) / longitudinal way (z) 390 mm max. Stangendurchmesser / max bar diameter 52 mm Drehzahlbereich / spindle speed 4500 UpM /rpm Werkzeugrevolver / turret head 12 fach /holes Eilgang x,z / rapid feed x,z 30,30 m/min Antriebsleistung Spindel / drive capacity spindle 9/11 kW Gewicht der Maschine ca. / weight 3000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: good (used), Year of construction: 2017, operating hours: 900 h, functionality: fully functional, turning length: 520 mm, turning diameter: 372 mm, TECHNICAL DETAILS Turning diameter over bed: 570 mm Max. turning diameter: 372 mm Max. Turning length: 520 mm Chuck: 152 mm (203 mm) Spindle speed: 6000 (45000) rpm Bore diameter: 60 mm (68 mm) Travel (x/z): 215 mm / 562 mm MACHINE DETAILS Year of construction: 2017 Weight: 4000 kg Operating hours: 849 h (as of November/December) EQUIPMENT - Control system: Siemens Sinumerik 820 D incl. Operate - 3 jaw power chuck Nodpfsrpiuysx Adwekt - 12-fold tool changer with driven tools - Automatic tool measurement - parts catcher - programmable tailstock - oil skimmer - Work area lighting - 2x WTO drilling and milling unit, straight BMT 55 - 2x WTO drilling and milling device, angled BMT 55 - 1x facing holder 25x25 mm - 3x facing and longitudinal turning holder - 4x universal combination holder - Chip conveyor

Year of construction: 2012, condition: good (used), Mazatrol Smart CNC control 3-jaw chuck C-axis driven tools 12-fold revolver Tool Eye tail stock coolant device chip conveyor Nkjdeiyx Diepfx Adwet Technische Daten / technical details: max. Umlaufdurchmesser / max. swing diameter 660 mm max. Drehdurchmesser/ max. turning diameter 350 mm max. Drehlänge / max. turning length 532 mm Planweg (x) / cross way (x) 225 mm Längsweg (z) / longitudinal way (z) 560 mm Drehzahlbereich / spindle speed 5000 UpM /rpm Drehzahl angetriebene Werkzeuge / speed of driven tools 4500 UpM / rpm Werkzeugrevolver / turret head 12 fach /holes Eilgang X/Z / rapid feed X/Z 30/33 m/min Antriebsleistung Spindel / drive capacity spindle 15 kW Gewicht der Maschine ca. / weight 4500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, Year of construction: 2017, Doosan Puma GT3100LM Year of manufacture: 2017 Control: Fanuc 0i-TF Turning diameter: [mm] 376 Turning length [mm] 1245 Main spindle: Nodpfxexggkts Adwekt Belt-driven spindle Max. spindle speed 2800 rpm Max. power 22 kW Max. torque 1124 Nm Bar capacity 102 mm 3-jaw chuck, Schunk ROTA THW plus 315-104 12-position turret BMT65 turret head Travel in X/Z axes 260/1350 mm

Condition: excellent (used), Year of construction: 2013, Control Siemens Sinumerik 840D Max. turning diameter: 280 mm Max. bar capacity main spindle: 61 mm Turning length: 490 mm Spindle speed main/sub spindle: 4700 / 6000 rpm 12-position turret with driven tools C-axis Y-axis Parts catcher Workpiece ejector Chip conveyor Various tool holders Nedpfx Adjyc Hzrjwskt

Condition: used, Year of construction: 2010, turning diameter over bed 316 mm turning length 340 mm control ultimax Hurco turning diameter over bed slide 240 mm swing dia. 402,5 mm spindle turning speed - stepless 0- 6000 U/min- rpm spindle bore 45 mm feeds 0- 30 m/min voltage 400 V connected load 14 KW face slide travel 185 mm longitudinal travel 340 mm dimensions of the machine ca. 3,76 x 2,92 x 2,15 m taper diameter VDI 20 mm main drive motor 11,5 kW weight of the machine ca. 3,2 t Machine has 12 position turret and a bar loader. Njdpoydqpiofx Adwokt

Condition: used, Year of construction: 1991, Mazak SQT 10MS lathe for sale. The machine is fully functional and in good condition. Technical specifications: Max. turning diameter 230 mm Main spindle Speed range 35-6,000 rpm Main drive power 11 kW Secondary spindle Drive power 5.5 kW Nkjdpfx Adov Tbu Dowst Speed range 180 - 6,000 rpm Indexing 72 positions/5 ° Tool turret Number of tool positions 12 Driven tools Speed range 120-3,000 rpm Drive power 2.2 kW Travel paths X-axis 160 mm Z-axis 455 mm B-axis 460 mm Travel speed Feed range X/Z-axis 0 - 5,000 mm/min C-axis 1 - 2,000 °/min Machine data (with standard equipment) Total connected load 43 kVA Machine weight, . 3,500 kg Machine dimensions (L x W x H), approx. 2.70 x 1.70 x 1.85 m Accessories Tool presetter (MAZAK Tool Eye System) C-axis Dual foot switch for opening/closing the chuck Chuck status feedback (open/closed) Front door lock Complete coolant system Work area lighting Documentation

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, SMEC PL25 YEAR 2012 Max. Cutting Diameter : 380 Max. Cutting Length : 530 Chuck Size : 10'' Nsdex Rxydepfx Adwokt Max. Spindle Speed : 3500rpm Max. Bar Size : 75

Year of construction: 2001, condition: good (used), Data will follow... Nksdjydni Hepfx Adwjt

Condition: good (used), Year of construction: 1999, Ref. -No.: 10443 Manufacturer: VDF BOEHRINGER Type: 16 M - G Year of construction: 1999 Type of control: CNC Control: REXROTH INDRAMAT SYSTEM 200 BTV 30 Storage location: Halberstadt Country of origin: Germany Turning Diameter: 520 mm Turning Diameter Over Slide Rest: 150 mm Spindle Speeds: 25 - 4.500 RPM Spindle Bore: 78 mm Tool Taper: VDI 40 Rapid Traverse: 15.000 mm / min Distance Between Centres: 1110 mm Spindle motor drive: 18 kW Turret places: 12 Pcs Machine length: 5000 mm Machine width: 2800 mm Machine Height: 3200 mm Weight Of The Machine Ca.: 14,5 t Further information: 2x revolver (12 places) Njdoycpw Aopfx Adwskt Machine can be inspected under power by appointment.

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads Nkjdpfeydiqfox Adwst 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: used, turning diameter 256 mm turning length 483 mm greates pass round over bed 548 mm swing diameter over slide rest 320 mm length between centers 584 mm x-axis 203 mm z-axis 508 mm spindle tunring speed 4.800 U/min Nkodpfxjycxkle Adwjt number of tool places 10 Pos. In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: excellent (used), Year of construction: 2019, CNC Lathe TAKAMAZ XY120PLUS Japan Year of manufacture: 2019 - Control system: Fanuc Oi-TD - Machining hours: 3,600 hours - Functionality: fully operational Axes: Nedex Sxl Aepfx Adwskt - X1 axis (150 mm) - Z1 axis (330 mm) - Y1 axis (+/- 35 mm) - Main turret: 24-tool stations with driven tools - C1 axis Sub-spindle: - X2 axis (150 mm) - Z2 axis (440 mm) - C2 axis - Small turret with 12-tool stations Machining capacity: - Max. turning diameter: Main 170 mm / sub 135 mm - Max. turning length: 330 mm - Bar capacity: Main Ø52 mm / sub Ø20 mm - Spindle speed: up to 5,000 rpm - Sub-spindle speed: up to 5,000 rpm - Automatic parts catcher with parts conveyor belt - Chip conveyor (tube type) - Machine documentation - Driven tool holders: 6 pcs (3/3) - Interface for bar feeder - Dimensions (L x W x H): 2,630 x 1,950 x 1,730 mm - Machine weight: 4,500 kg

Condition: used, Year of construction: 2006, functionality: fully functional, Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 mm Swing diameter over face slide: 260 mm Face slide travel: 380 mm Main drive Drive power AC motor - 40/60/100% duty cycle: 33/27/22 kW Spindle box Spindle bore diameter: 106 mm Spindle diameter in front bearing: 140 mm Speed range (V constant): 1 - 2,000 rpm Cross slide Feed range, face: 0.001 - 1,000 mm/rev Feed range, face, optional up to: 5,000 mm/rev Feed range, longitudinal and thread pitch: 0.001 - 2,000 mm/rev Feed range longitudinal and thread pitch, optional up to: 13,000 mm/rev Feed force flat: 9,000 N Feed force longitudinal: 12,000 N Automatic tool turret Number of tool stations: 12 With tool drive for 6 stations Tool holder system (DIN69880) VDI40 Nkjdpfjycuflex Adwjt Equipment SIMENS SINUMERIK 840D sl (Shop Turn with manual functions) COMBI control station C-axis with drilling, milling, and engraving cycles Residual material detection and machining – during roughing and contour pockets MULTIFIX C forne setup Three-jaw chuck SMW AUTOBLOK: HI-GRIP HGF260-81-3 Oil emulsion mist filter for work area extraction: MAHLE LTA600 4 driven axial tool holders 2 driven radial tool holders

Condition: used, turning diameter 240 mm Nkjdpfoycxibex Adwot turning length 530 mm control Siemens 840D SL swing diameter 560 mm x-travel 207,5 mm z-travel 530 mm turning speeds 6000 U/min 12 Stk. total power requirement --- kW weight of the machine ca. 6,1 t

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, CNC Lathe - Horizontal / Brand: GEMINIS / Type: GEMINIS GT9 G2 (heavy series) / Year of construction: 2015 The machine can be inspected by appointment under power. TECHNICAL DATA: - Max swing over bed: 2.000 mm - Distance between centers: 8.000 mm - Height of centres: 1.050 mm - Swing over slide: 1.600 mm - Main spindle bore Ø: 150 mm - Main spindle nose: DIN 55026-15 - Speed range: 4 - Speed range I: 0-80 rpm - Speed range II: 0-175 rpm - Speed range III: 0-350 rpm - Speed range IV: 0-700 rpm - Cross slide travel: 1.060 mm - Quill Ø: 400 mm - Quill travel: 300 mm - Max. weight allowed between centers: 30 tons Nksdpfx Adjvuih Uowst Machine base: - Distance between the guideways: 1.350 mm - Height of the machine base: 650 mm EQUIPMENT / ACCESSORIES: - CNC-Control: FAGOR 8065 - Independent 4-jaw chuck: Ø 1.600 mm - Set of hard inner and outer claws - Square automatic turret: SAUTER 4 pos – Ø 320 x 320 mm - Tailstock and quill: Motorised - Quill placement: Built-in Rotating - Automatic Locking/Unlocking of the tailstock body - Air conditioner for electronic cabinet - Portable electronic handwheel - Chip conveyor - 4-support Closed steady rest: Ø 500-900 mm - Permissible weight allowed for steady rest: 10 tons - Prepared for C-axis with transmission from main engine - Preparation for subsequent adaptation of a milling head with Y axis on turret - Preparation for rectifier head assembly - Very well-equipped with tools Without guarantee of completeness and correctness of the technical information and the equipment. - Subject to prior sale -

Condition: excellent (used), Year of construction: 2013, operating hours: 4,300 h, functionality: fully functional, machine/vehicle number: NL 254131163, CNC controller M730BM with MAPS IV Capacity X-axis travel mm: 250 Y-axis travel mm: +/- 50 Z-axis travel: mm 795 Turning length mm: 705 Max. turning diameter mm: ø 366 Swing over bad mm: ø 920 Swing over cross-side mm: 742 Bar work capacity mm: 80 Upper turret Number of tool slots St: 12 Speed driven tools RPM: 10.000 Drive power driven tools kW: 5,5 / 3,7 (3 mm / cont) Main spindle Speed spindle rpm: 4,000 Drive power spindle kW: 18.5 / 15 (50% ed / cont) Chuck type: BB210 Manufacturer: KITAGAWA Spindle nose: JIS A2-8 Tailstock Tailstocktravel mm: 734 Holder: MT5 Nedot Akiropfx Adwokt equipment Chip conveyor Tool measuring arm Foot switch for chuck or collet system Interface for bar feeder

Condition: good (used), Year of construction: 2005, turning length: 450 mm, travel distance X-axis: 135 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 450 mm, C-Axis rapid traverve 400 Min Turret indecing time 0,2 sec for 1 station Nkodpfoydcvzex Adwjt Heavy duty cutting (depth cut 6mm) 162.7 mL/Min LNS Bar feeder new 2017 Large package tooling driven / live tools 8 axis controlled with 2 spindles and turrets Max. turning Ø: 250mm X-Axis: 135mm Y-Axis: 40+40 = 80mm Z-Axis: 450mm B Axis: 510° Spindle bore: 49mm Speedrange: 6000Rpm Spindle power: 30kW Subspindle speeds: 6000Rpm Subspindle bore: 49mm ATC / revolver: 12 Speed live tools: 6000Rpm Positions lower revolver:12 Speed live tools: 6000Rpm Length: 2800mm Width: 2000mm Height: 2000mm Weight: 5000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: good (used), In good technical condition and fully operational. Year of manufacture: 1974, with an overhaul including comprehensive modernization (retrofit) of the CNC control system, complete with automatic central lubrication for the axes and hydraulic systems, water cooling, conductive rollers with brushes for a system allowing the possible welding of the workpiece, and complete protection against flying chips. Heidenhain manual plus 4110 control system. Swing diameter over bed: 1,250 mm and over support: 900 mm. Nodpfx Adex Ttlaewjkt Max. workpiece weight: 14,000 kg. Max. workpiece length: 3,000 mm. Machine weight: 16,350 kg. Machine power: 80 kW. Machine dimensions: Width 3,000 mm, Height 2,100 mm, Length 8,000 mm. Accessories: faceplate including handles, steady rest, raised tool head, universal chuck. Complete technical documentation, service history, and maintenance and overhaul records are available.

Condition: excellent (used), Year of construction: 2014, CNC-swiss type automatic lathe brand: STAR type: SV-38R Nkodpfjvgulvox Adwst new in: 2014 equipped with: FANUC 31i control, turret with B, Y, X, and Z axis, driven tools, 2x C-axis, Y2 axis, subspindle, high pressure pump, oil mist, backworking, chip conveyor, parts conveyor, fire extinguishing system, useable for short and long parts automatic bar loader FMB TURBO 5-55

Condition: good (used), Year of construction: 2007, CNC Swiss Type Automatic Lathe Make: STAR Model: SR-32J Year of manufacture: 2007 Equipped with: FANUC 18i-TB control Nkjdpfx Ajycq Ddodwst Synchronous spindle Driven tools C-axis Backworking Parts conveyor belt Oil mist extraction system Bar feeder: FMB TURBO

Condition: good (used), Year of construction: 2011, CNC Swiss-type automatic lathe Make: STAR Model: SR-32 J Type N Year of manufacture: 2011 Equipped with: FANUC 32i Model B control Synchronous spindle Live tooling C-axis Subsequent machining (backworking) High-pressure pump Chip conveyor Parts conveyor Oil mist extraction unit Nsdpfxjycqx Io Adwekt Bar feeder: FMB TURBO 3-36

Condition: used, Year of construction: 1990, Numerous tool holders Power chuck 12-position turret Machine type: CNC lathe Year of manufacture: 1990 Control: Traub TX 8 F Turning diameter: 480 mm Turning length: 800 mm Spindle bore: 65 mm Spindle speed: 40 - 4000 rpm Nkodpjyc Hgbjfx Adwet Weight: approx. 5000 kg Dimensions (W x D x H): approx. 2950 x 1990 x 2000 mm Condition: used

Condition: used, Year of construction: 2022, controller manufacturer: Siemens, controller model: SINUMERIK 828D, _____ Description: Year of manuf. : 2022 Control : Siemens SINUMERIK 828D Turning diam. : 288 mm Turning length : 243 mm Work area max. turning diameter:288mm max. machining length:243mm Nodpsyavz Asfx Adwokt X-axis:175mm Z-axis:350mm Main spindle Chuck diameter:210mm Max. bar diameter:67mm Spindle bore diameter:76mm Drive power:10.5/20 kW max. torque:213 NM max. speed:4,500 rpm Tailstock Quill diameter:65mm Quill stroke:80mm Axial force:4,312 N Center point adapter:MT4 Tool turret Number of tool stations:12 Tool holder:BMT45 Powered tools:Yes Max. speed:5,000 rpm

Condition: used, Year of construction: 2007, swing dia. 430 mm Distance between the spindles 1450 mm Nksdoyb S Nrjpfx Adwjt control MAZATROL 640T x-axis 310 mm z-axis 605 mm spindle tunring speed 4.000 U/min In our opinion, the machine is in good used condition and can be inspected under power by appointment. Technical Features & Accessories: - Gantry Loader Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!
