Used Directional Drilling for sale (8,787)

Condition: new, Year of construction: 2026, functionality: fully functional, Alignment press system Push and pull force 24/30 t Njdjuy N H Ejpfx Airown Hydraulic station 50 m rod Expander 80/132/160/200 mm Without locator device Price: €27,000.00 net Dry drilling: no bentonite use, no bentonite disposal

Condition: used, Year of construction: 2023, functionality: fully functional, machine/vehicle number: AB00029039, feed length X-axis: 3,050 mm, feed length Y-axis: 900 mm, feed length Z-axis: 60 mm, input frequency: 50 Hz, input current: 31 A, feed rate X-axis: 40 m/min, feed rate Y-axis: 40 m/min, feed rate Z-axis: 10 m/min, working width: 900 mm, total width: 2,159 mm, total length: 3,459 mm, total height: 1,500 mm, SCM Startech CN Plus R F23L CNC drilling, grooving and routing centre, manufactured in Italy in 2023. The machine is currently installed in Pejë, Kosovo, and can be inspected under power by prior appointment. Machine identification: - Manufacturer: SCM - Model: Startech CN Plus R F23L - Year of manufacture: 2023 - Serial number: AB00029039 - CE version Nwodpfj Afnhhsx Airjn - Machine weight: 1,383 kg Main equipment: - F23L drilling head - 13 independent vertical drilling spindles: 7 in X and 6 in Y - 10 horizontal drilling spindles: 6 in X and 4 in Y - Drilling motor power: 2.2 kW - Drilling spindle speed: 4,200 rpm - 5.5 kW vertical electrospindle for routing operations - Electrospindle speed: 1,000–18,000 rpm - ER32 collet with manual tool change - Maximum routing tool diameter: 20 mm - Integrated grooving saw in the X direction - Maximum saw blade diameter: 125 mm - Saw blade speed: 5,500 rpm - Automatic workpiece positioning and side alignment - Centralised lubrication system - SCM Maestro CNC software with Hicam machine interface - PC control with 19-inch display - Barcode program support - Uninterruptible power supply unit (UPS) - Additional Maestro CNC hardware key Working capacity: - Maximum panel dimensions: 3,050 × 900 × 60 mm - Minimum panel dimensions: 200 × 80 × 10 mm - Maximum axis speed X/Y/Z: 40/40/10 m/min - Maximum vertical drilling depth: 30 mm Installation data: - Electrical supply: 400 V, 3+N, 50 Hz - Input current: 31 A - Installed power: 20.7 kVA - Compressed-air consumption: 50 Nl/min The machine is used, fully functional and available for demonstration under power. Availability: by arrangement. Sale basis: EXW Pejë, Kosovo. Dismantling, loading and transport can be arranged separately. Further technical information, documentation and an operating video are available on request.

Condition: used, Year of construction: 1997, Second-hand machine Year of manufacture: 1997 Features and technical specifications: - Number of drilling spindles: 21, spaced at 32 mm intervals - Drilling direction: Bottom & end face - Swivel range: 0–90 degrees via handwheel - Pneumatic workpiece clamps: 3 pcs. Nedpfx Aiezn Ah Rsrswn - Opening: Max. 100 mm in height and max. 640 mm in width - Motor: 1.5 kW - Extraction diameter: 120 mm - Includes a wide range of stops (see pictures) Availability: at short notice Storage location: 63934 Röllbach

Condition: used, Year of construction: 2021, Drilling capacity in St 60 55 mm threading in St 60 M 30 M 36 Short spindle MK 4 spindle stroke 140 mm throat 300 mm column diameter 145 mm Machine table - usable table surface 615x430 mm T-Slots Amount - Width - Distance 2x14x224 mm distance spindle - column min./max. 150/735 mm feed 0,1 + 0,3 mm/U 0 stufenlos Spindle Speed 70-2.400 U/min. engine 3,0 kW machine weight ab. 380 kg Standard equipment: - 7" TFT LCD display with touch function: * Manual input of spindle speed set value * Actual speed display * Integrated drilling depth display with touch zero point transfer * Virtual drilling depth scale in the display * Machine status indicators and warnings on the display * Service information * Selectable operating language: DE/EN/FR/ES/IT/NL/RU Nwsdpsz I Ub Hsfx Airjn - Thread cutting device, for thread cutting with stop, max. 6 threads/min (thread cutting capacity depending on spindle speed), thread depth adjustable via depth stop and on the TFT LCD display (4 tools) - Infinitely variable speed adjustment via adjustment lever - Spindle protection with electrical fuse - Three separate buttons for clockwise rotation - anticlockwise rotation - stop - Mushroom pushbutton (latching) for EMERGENCY STOP - Main switch, lockable - Clockwise and counter-clockwise rotation via contactor control - Control voltage 24 V, protection class IP 54 - Paint finish: DD textured paint signal white RAL 9003, PANTONE 4545c, black Item 20.5 Foot switch in addition to the thread cutting device, for switching the direction of spindle rotation in the process. direction of rotation during the process Item 25. Coolant unit B, consisting of: separate container (33 l), pump with motor protection switch, complete armature motor protection switch, complete fitting Item 37.5 Technology calculator in the display The technology calculator guides you through the cutting task Determination of the cutting data using the following parameters: - Manufacturing process - Tool diameter - Cutting speed - Material table - Transfer function of the spindle speed as set value

Condition: good (used), Nagel Citoborma 280B Paper Drill The unit is in 100% working order. It is one of the latest models. The drilling table is adjustable in all directions (laterally and front-to-back). It features stops for setting the drilling spacing. Nwjdpfx Asz S Upmsirsn The installed table is an enlarged version. Additionally, the paper drill is equipped with an automatic table lock that releases after every cycle. Excellent condition. Robust construction – weight: 76 kg. Power supply: 380V. Two drilling heads with an adjustable spacing range of 45–120 mm. Drill bit diameter: 2–20 mm. Stack height: 60 mm. The machine has undergone a full inspection. Includes drill bits, tools, a new cutting stick, and an instruction manual.

Condition: good (used), Uchida Durselen UD-04 four-head paper drill The unit is in perfect, like-new condition! This is the latest, currently manufactured model. Made in Japan. The machine features a range of functions designed for ease of operation, including: – infinitely variable drill rotation speed, controlled via an inverter (VFD) – four drilling heads with independently adjustable positions – a sliding table equipped with a programming bar – spacers for simple setup when drilling holes at standard intervals for A4 and A5 formats – casters for easy mobility Technical specifications: Nwedpfsz S Ulujx Airen Drill diameter: 2–10 mm Stack height: 50 mm Distance between heads: 45 mm – 380 mm Weight: 200 kg Power supply: 230V Automatic drilling cycle, operated via a foot pedal. Robust, pedestal-mounted construction. Waste directed into an external collection bin. Drill table adjustable in all planes, with front and side margin settings. Includes maintenance tools, a new drill block (cutting stick), and drill bits.

Condition: good (used), Hang 114-30/4 Paper Drill Machine The unit is in perfect condition and 100% functional. A top-tier machine in the category of paper drills. This is a currently manufactured model, featuring the most comprehensive equipment configuration available. Equipped with two integrated frequency converters (inverters) for stepless spindle speed adjustment (260 – 1,800 rpm) and smooth table elevation. Rapid drill zeroing/alignment system. The drilling table is adjustable in all planes; the margin (backgauge) setting is controlled via dial indicators. Waste material is directed into an external container. Operated via an electric foot switch. Energy-saving standby mode. Automatic drive belt tensioning. Each drilling head features independent adjustment, allowing for the use of drills of varying lengths. Includes a cooling and lubrication system for the drills. Technical specifications: Number of drilling heads: 4 Nsdpfxoz S Un Ae Airswn Drill diameter: 3–10 mm Stack height: 65 mm Drill spacing: min. 36 mm / max. 260 mm Table dimensions: 600 x 480 mm Power supply: 400 V Weight: 400 kg The machine comes with documentation, maintenance tools, and drill bits.

Condition: good (used), Stago PB 2015 Paper Drill The latest model from the manufacturer Stago; this machine comes from the office of a large company. The unit is 100% functional. The drilling table is adjustable in all directions (laterally and front-to-back). It features stops for setting the drilling spacing. The installed table is an enlarged version. Additionally, the drill is equipped with an automatic table-locking mechanism. Robust construction – weight approx. 70 kg. Power supply: 380V. Two drilling heads. Drill bit diameter: 2–10 mm. Stack height: 60 mm. Nodpjz S Uwqsfx Airewn Adjustable spacing between the heads. The drill has undergone a full inspection. Includes drill bits and tools.

Condition: good (used), Nagel Citoborma 111 paper drill The unit is 100% functional and in very good condition. The drilling table is adjustable in all directions (laterally and front-to-back). It features stops for setting the drilling spacing. Robust construction – weight: 35 kg. This is one of the latest Citoborma drill models, currently still in production. Power supply: 230V. Nwjdpfsz S Ui Hjx Airjn Drill bit diameter: 2–9 mm. Stack height: 50 mm. Includes drill bits, a new drilling stick (cutting strip), and an instruction manual. Made in Germany.

Condition: good (used), Nagel Citoborma 180 Paper Drill This machine is 100% functional. This is the latest model. The drill table is adjustable in all directions (sides, front/back). It has stops for setting the drilling spacing. The installed table is an enlarged version. Additionally, the drill has an automatic table lock that releases after each cycle. Very good condition. Solid construction – weight 65 kg. 230V power supply One drilling head. Nwodoz Rk Hxepfx Airon Drill diameter 2-20 mm. Stack height 60 mm. The machine has been serviced. Includes drills and tools, a new cutting stick, and an instruction manual.

Condition: good (used), HANG 114-00/4 paper drill The device is in very good condition. This is the latest product of the hang brand. The highest class of machines among drilling machines.. Waste directed to an external container. Controlled by an electric foot switch. Each head is independently adjustable, which allows the use of drills of different lengths. Technical data: number of drilling heads: 4 drill diameter: 3-10mm stack height: 65mm drill spacing max260mm Nodpez N R Uasfx Airewn drill speed: 1500 rpm two table lifting speeds table dimensions: 600x480mm Power supply: 400V Weight: 400kg The machine has documentation, operating tools and drills.

Condition: good (used), Durselen PB 16A four-head paper drill The device is in perfect condition, like new! This is the newest one. currently produced model. Production Germany. Four drilling heads with adjustable spacing. The machine has a pneumatic drill cooling system. Sliding work table. Automatic column system – a belt that is moved to the next position when worn out Technical data: Drill diameter: 2-16 mm, Stack height: 50 mm, weight: 300 kg Power supply 380V Nedpfjz N R Umsx Airown Automatic drilling cycle, controlled by a foot pedal. Smooth regulation of spindle speed and lowering speed of heads on inverters. Solid construction on a pedestal. Waste is directed to the built-in bin Drill table adjustable in every plane, front and side margins. The set includes operating tools and drills.

Condition: good (used), Hang 117-01 paper drill The device is in perfect condition, 100% functional. The highest class of machines among drilling machines. Each head is independently adjustable, which allows the use of drills of different lengths. Drill table adjustable in every plane, with a lock. Nwjdpfoz N R Uysx Airon The spacing of the heads is adjustable with a crank. Waste directed to an external container. Two operating speeds: 950 and 1900 rpm Technical data: number of drilling heads: 2 diameter of lights: 3-10mm stack height: 60mm drill spacing min: 45mm / max 160mm table dimensions: 780x430mm Weight: 100kg Power supply 380V The machine has documentation, maintenance tools, drills, and a new column

Condition: excellent (used), Year of construction: 2014, Axle: 920 mm X-axis: 3000 mm Material thickness: 12 mm - 30 mm Feed rate: 20 m/min A-axis: 360 degrees Minimum dimensions: Plate: x = 300 mm Y = 120 mm z = 12 mm The machine is equipped with a 4-position drill chuck and a saw blade. Nodpfefmdcqox Airewn Maximum and minimum hole diameters that can be drilled: 3 - 35 mm The saw blade runs in the X direction. Max. cutting depth with saw blade: 10 mm Motor: 0.75 HP, 400 volts Required extraction capacity: 2300 m3/h Location: available at warehouse 54634 Bitburg - immediately available -

Condition: good (used), Nagel Citoborma 290AB Paper Drill The machine is 100% functional and ready to use. Nodpfx Ajz Dtagoirswn Robust construction – weighs 200 kg. This is the current Citoborma drill model in production. 400V power supply. Two drilling heads with adjustable spacing ranging from 45-170 mm. Drill diameter: 2-20 mm. Stack height: 60 mm. Controlled by an electric foot pedal. Waste is directed to an external sleeve. The drill table is adjustable in every direction (sides, front/back) and has stops for setting the drill spacing (non-standard drilling). Additionally, a special module for standard spacings is installed in the table. Furthermore, the table has two movable margins. The drill has an automatically released table lock after each cycle, allowing the table to be moved to the next position. The set includes drills, tools and instructions.

Condition: used, functionality: fully functional, Year of construction: 2021, The Bauer BG 28 is a high-performance rotary drilling rig engineered by BAUER Maschinen GmbH for deep foundation construction, bridge building, and heavy civil engineering projects. Nwsdpfx Aio Adra Eoren

Condition: used, Year of construction: 1989, Technical details: bore capacity in steel (diameter): 28 mm throat: 285 mm bore stroke: 165 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 3 spindle speed:: 65 - 1.750 / 4x steples U/min feed: 0,1; 0,2; 0,3 manuell/automatisch mm/U Distance spindle/table max.: 80 - 680 mm table clamping surface:: 500 x 370 mm table rotating: 360 ° drill table adjustment: 600 vertical mm column diameter: Ø 130 mm total power requirement: 7,5 kW weight of the machine ca.: 273 kg Nwsdpeu Idkzsfx Airjn dimension machine xH: 0,9 x 0,6 x 1,9 m The machine can cut threads, change of direction left/right selectable via foot switch and/or depth stop Table can be swiveled and adjusted in height. *

Condition: good (used), Year of construction: 1987, travel distance X-axis: 11,500 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 2,000 mm, feed length W-axis: 1,600 mm, x-travel 11,500 mm y-travel 4,500 mm Nwsdpe Afwnqsfx Airjn w-axis 1,600 mm z-axis 2,000 mm Spindle diameter 200 mm Rotary table 3,000 x 4,000 mm Bed length of rotary table 4,600 mm Tool holder SK50 Workpiece weight on rotary table 80 t Total power requirement 83 kW Additional information incl. 15 plates

Condition: used, functionality: fully functional, Year of construction: 2010, machine/vehicle number: L2D, The Atlas Copco Boomer L2D (now under Epiroc) is a heavy-duty, twin-boom hydraulic face drilling rig designed for underground mining, tunneling, and large-scale civil engineering projects Nwsdsz D Alfspfx Airen

Condition: good (used), Year of construction: 1989, machine/vehicle number: 8906756, functionality: fully functional, actuation type: pneumatic, overall weight: 84 kg, GRASS BBM /ST with adapter for BLUM fittings Nwodpfxozvn N Ne Airsn Row drilling unit – hinge plate drilling – drilling for base plates – drilling for press-in dowels – adapter for pressing in the hinge plates and base plates.

Condition: excellent (used), Year of construction: 2009, operating hours: 7,700 h, functionality: fully functional, mileage: 7,700 km, overall weight: 5,050 kg, fuel type: diesel, color: yellow, axle configuration: 2 axles, empty load weight: 5,050 kg, gearing type: hydrostat, number of seats: 1, Equipment: additional headlights, adjustable chassis, all wheel drive, hydraulics, low noise, rubber tracks, MGC.pl – professional sales and service of VERMEER machines! We specialize in the sale and service of professional VERMEER horizontal directional drilling rigs. We provide expert technical advice, assistance in selecting the right equipment, and service support. We also offer other VERMEER drilling rig models. VERMEER NAVIGATOR D20x22 SERIES II – 2009 VERMEER NAVIGATOR D9X13 SERIES II - 2012 VERMEER D24x40A - 2003 We offer for sale a professional VERMEER D20x22 II NAVIGATOR horizontal directional drilling rig from 2009, manufactured in the United States. The machine comes from its first and only owner, who has used it continuously since it was new until the cessation of their business operations. We have a flushing system available for this DRILLING RIG, which is not included in the PRICE. Engine - Model: Kubota 3800 Turbo - Type: Turbocharged diesel engine - Power: 62 kW / 83 hp, approximately 84 hp - Maximum idle speed: 2400 rpm - Engine oil capacity with filter: 8.5 l - Fuel tank: 95 l Drilling parameters - Maximum spindle torque: 2983 Nm - Maximum spindle rotation speed: 205 rpm - Thrust force: approximately 89 kN / 9.07 t - Pull force: approximately 89 kN / 9.07 t - Minimum bore diameter: 9 cm - Carriage travel speed – fast range: 41 m/min - Carriage travel speed – slow range: 27 m/min - Automatic rod feeder: yes Drill rods - Type: Vermeer Firestick® I - Single rod length: 3 m - Rod diameter: 52 mm - Single rod weight: 27 kg - Minimum bending radius: 31 m - Rod magazine capacity: 107 m total length Flushing and hydraulic system - Maximum flushing pump capacity: 95 l/min - Maximum flushing pressure: 52 bar - Hydraulic oil tank capacity: 87 l Dimensions, weight, and travel Nwjdpfx As Ad I Hueirsn - Maximum length: 541 cm - Transport length: 508 cm - Width: 119 cm - Height: 193 cm - Catalog weight: 4808 kg - Maximum travel speed: approximately 4 km/h EQUIPMENT Hydraulic drilling system Track-type undercarriage Operator station with seat Drill rod magazine Hydraulic drilling mast Anchoring and stabilization system Control system for working functions Design adapted for professional trenchless operations APPLICATION The VERMEER D20x22 II drilling rig is used for: Construction of fiber optic and telecommunications networks Installation of water supply systems Construction of gas networks Laying of power cables Installation of pressure sewer systems Construction of culverts under roads and railway tracks Implementation of infrastructure projects using trenchless methods GREATEST ADVANTAGES OF THE OFFERED MACHINE 1 OWNER SINCE NEW – the machine remained in the hands of one company throughout its service life. SALE DUE TO CESSATION OF BUSINESS – the previous owner has ceased operating the business. INSPECTION REPORT: The machine has been tested for various functions and is fully operational. There are no leaks. The engine runs smoothly, both when warm and cold. The hydraulic system also has no significant play or leaks. The stated price is net and applies to export and for companies. A substantial discount is possible for private customers. We invite you to contact us directly by phone to obtain your best price.

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, High-precision drilling and milling machine Fehlmann Model Picomax 56TOP Heidenhain TNC 620, excellent condition, CE compliant!! Technical data: >> Year of manufacture: 2014, Machine No. 14214621 >> Travel ranges X/Y/Z: 500/400/400 mm >> Distance between table and spindle nose: 120-520 mm >> Clamping area (L x W): 908 x 480 mm >> Spindle speed range: 50-12000 rpm >> Drive power: 9.5 kW >> Tool magazine: Number of positions: 20 Nsdpe Agaruefx Airjwn >> Footprint (W x D x H): 1700 x 1900 x 2500 mm >> Weight approx. 3000 kg About the machine: The top-of-the-line machine for manual and CNC operation with an innovative Fehlmann operating concept: user-friendly, fast, and economical. The precision milling and drilling machine PICOMAX 56 TOP (Touch Or Program™) is available with a completely new operating concept that combines 3-axis CNC operation with manual operation via drilling lever and handwheels. Specifically designed to quickly, safely, and efficiently perform milling, drilling, and threading operations on individual parts without time-consuming programming. Even after a short training period, the PICOMAX 56 TOP milling machine can be used extremely economically by skilled personnel, even without programming knowledge. Even in its basic configuration, the FEHLMANN milling machine 'Made in Switzerland' offers various features of a modern, high-performance milling machine, such as: fully digital CNC Heidenhain control TNC 620, a Fehlmann-specific, liquid-cooled, and high-torque motor spindle for universal milling up to 12,000 rpm, as well as Z/S-interpolated threading, 3D milling, and turning. The tool holders and accessories (see pictures) are included. Absolutely excellent condition. Mechanically and electrically inspected. Take advantage of the opportunity to inspect and test this machine on-site while it is powered up.

Condition: good (used), Year of construction: 1983, travel distance X-axis: 6,000 mm, Spindle diameter: 200 mm Machining width: 6000 mm Machining height: 3150 mm Max. machining depth: 1985 mm Slide cross section: 530 x 550 mm Table load capacity: 20 t Plate field size: 11200 x 5550 mm Tool holder: SK 60 Nwedpfx Ais Afwrzjrjn Machine weight approx.: 173 t Additional information: - Additional equipment: large and small angular heads - Listing No.: 22979 - The table is model S20 MP, size: 2200 x 2500 mm - The machining width on the X-axis of the machine is 6000 mm - Including 6 plates measuring 5600 mm x 1850 mm

Condition: ready for operation (used), Year of construction: 1977, functionality: fully functional, serial number 2934 weight 709 kg Nwodpfx Aijztfytoron feed ja m/min taper MK 3

Condition: new, This is a new machine which is manufactured in Romania by the manufacturer Emsil. Customer wishes can be taken into account depending on technical implementability and are checked in advance by the manufacturer's engineering office. Narwhal features a drilling spindle that is made of hardened, tempered and rectified alloy steel. It is mounted with preloaded oblique precision ball bearings. Njdpfx Aieu Id H Aerjwn The machine is also equipped with a milling and boring bar which can handle exceptional power and torque. The bar is made of nitrided alloy steel and is also mounted with oblique preloaded precision ball bearings. It moves on bronze guide bushings. The clamps of both units, used for securing and releasing the tool holder cone with ISO 50 coupling, open and close automatically Rotary Turntable: The table is turned by means of a double pinion gearbox, a central rod wth bearings and hydrostatic sliding block of the centre bearing which is of a suitable size to guarantee maximum precision with large loads, even unbalanced ones. There is a recirculating ball screw slide guide system for the x-axes. Both axes are equipped with a direct measuring system. CNC Axes Control: The 9 axes of the machine are monitored at all times. The monitoring system is equipped with a 15'' TFT screen, a control panel, remote diagnostics that alert the user in case of faults, a user memory, network connectivity, remote control of the process, integrated PLC, etc. The machine is compatible with the multiple control systems such as Heidenhain, Fanuc, Siemens etc. You can choose the sizes of machining of X/Y and Z axes: from 1200 - 3500 / 1000 - 3500 / 400 - 1500mm *
