Used Drilling Work Table for sale (77,059)

Condition: excellent (used), Year of construction: 1965, table load: 60,000 kg, table width: 3,250 mm, total width: 3,250 mm, Indexing dividing setting: 1e stage full rotation setting 5 Gr 2e stage full rotation (fine) 30 " Turning rotation setting: 1e stage 1 - 48 Rpm 2e stage 0,27 - 11 Rpm   V-Axis movement setting: 1e stage 10 mm 2e stage (fine) 0,02 mm Scraped guide way 1 size: 300 x 85 mm  Scraped guide way 2 size: 225 x 85 mm Scraped guideway 3 size: 250 x 85 mm Table Ø: 3250mm Dusdpfx Agex S Ihaj Rel Table load: 60 T Movement V-axis: 1800mm Rotation B-Axis: 360000° Rotation speed B-Axis:48Omw/min. Movement speed V-axis:1600mm/min. Length: 6900mm Width: 3500mm Height: 1400mm Weight: 25000kg

Condition: used, Year of construction: 2006, Technical details: table load: 2,2 t table diameter: 2500 mm Total power requirement: 9,6 kW max. table load: 22.000 daN / 2200kg table rotating: links/rechts Grad table - inclinable: 0 - 120 Grad table height: 1700 mm machine weight approx.: 12000 kg connected load: ca. 5,0 kVA dimensions LxWxH: ca. 4,5 x 2,5 x 2,3 m Welding positioning turn-tilt table developed and manufactured by Müller Opladen ARC KON EWeding GmbH. Machine frame solid, welded steel construction with ball-bearing tilting device Table with centering grooves and T-slots for M24 according to DIN 650. Infinitely variable rotary drive from 0.05 - 1.0 rpm. Height to center of swivel axis 1700 mm Dedpfx Aeu Nkx Isg Rsul hydr. tilt adjustment, infinitely variable from 0 - 120° Drive is designed for a torque of approx. 40,000 Nm at the turntable Accessories: 1x 2-row foot switch 1x remote control 1x working platform *

Condition: used, Technical details: bore capacity in steel (diameter): 40 mm throat: 360 mm bore stroke: 280 mm spindle taper MT: MK 5 spindle speed:: 32 - 1400 U/min feed: 0,11-1,73 mm/U connected load: 6 kW Distance spindle/table max.: 750 mm table clamping surface:: 780+650 mm drill table adjustment: verical 800 mm Dodpfowid Uwsx Ag Rjul column diameter: Größe: 230 x 950 mm dimension machine xH: 1,1 x 0,8 x 2,8 m weight of the machine ca.: 1,5 kg for thread cutting clockwise and counter clockwise operation *

Condition: used, Year of construction: 1971, Technical details: Duedsu Idtpjpfx Ag Rel max. diameter of face turning: ca. Ø 900 mm revolution per minute: Spindel: 12,5 - 00 / 24 step U/min revolution per minute: Planscheibe: 8 - 190 / 12 step U/min feed steps: Planscheibe: 0,03 - 3 / step rapid traverse: alle Bewegungen: 2000 / 4000 m/min tool taper: der Arbeitsspindel: ISO 50 / SK50 table clamping surface:: 700 x 800 table rotating: 360° Grad drill table adjustment: quer: 800 mm max. table load: 1500 kg total power requirement: ca. 11,0 kW weight of the machine ca.: 7800 kg dimension machine xH: 3,0 x 2,0 x 2,6 m dimensions electric cabinet: 1800 x 400 x 1950 mm Ø of the face plate 420mm Movement of the face slide 180mm largest Ø during facing approx. 900mm Longitudinal movement of the column 700mm Vertical movement of the headstock 700mm Feed drive of column, headstock and clamping table: -for spindle operation=0,20 - 10 mm/rev with 34 speeds -for operation with faceplate= 0,16 - 16 mm/rev with speeds Equipment: optical fine measuring device/measuring system Heidenhain for axes X/Y/Z/C-table hydraulics machine feet/footplates control panel with boom *

Condition: used, Year of construction: 1987, Technical details: table diameter: 500 mm table height: 70 mm rotatability of the table - manual/mechanic: ja ° weight of the machine approx.: 300 kg space requirements of the machine approx.: 0,92x0,650x0,19 m T-slots are 3 pcs longtitudinal and 1x transverse in the middle existing a=18mm h=30mm b=30mm c=13mm * Dusdou Nkm Ejpfx Ag Rsl

Condition: used, Year of construction: 1998, Technical details: bore capacity in steel (diameter): 15 mm bore stroke: 100 mm threading: M16 number of drilling stations: 3 drill spindle - Morse Taper: 3x MK2 spindle throat: 220 mm spindle distance: 335 mm headstock adjustment: (vertikal) 290 manuell mm feed:: mauell mm/U spindle speed:: 220-1600 / 400-3200 / 800-6400 U/min distance between table/spindle: min./max.: 235/525 mm table surface area: 1270 x 315 mm table adjustment: fest / fix mm total power requirement: nicht bekannt kW weight of the machine ca.: 0,72 t dimension machine xH: 1,4 x 0,8 x 2,25 m Duodpfxou Idute Ag Rjl incl. cooling water system operation by hand and foot The drilling spindles are equipped as follows: 1x drill chuck 13mm 2x quick chuck 10mm *

Condition: used, Technical details: table diameter: 450 mm rotatability of the table - manual/mechanic: 360 ° clamping table - swivable: 90° mechanisch Grad weight of the machine approx.: 100 kg dimensions: L: 800 x B: 700 x H: 400 mm Dujdpeu N D Ayefx Ag Rol The surface of the round table is scraped. Very good condition! micrometer precise locking Positioning in the 0.01 mm range T-slots according to DIN 650 radial Foot clamping 16mm (6 holes) *

Condition: used, Year of construction: 1968, Technical details: bore capacity in steel (diameter): 40 mm throat: 380 mm bore stroke: 240 mm spindle taper MT: MK 5 spindle speed:: n.b. U/min feed: 01 / 0,14 / 0,2 / 0,28 / 0,4 (manuell+automatisch) mm/U Distance spindle/table max.: 200 - 800 mm table clamping surface:: 540 x 730 mm table rotating: 360 ° drill table adjustment: 600 (manuell) mm column diameter: Ø 220 mm base plate surface area: B: 510 x L: 510 mm total power requirement: 4,0 kW weight of the machine ca.: 1300 kg Dedpsvpfzyefx Ag Rjul dimension machine xH: 1,2 x 0,95 x 2,35 m Operation via control panel and/or foot switch Mechanical thread cutting incl. vice *

Condition: used, Technical details: Duodpfx Agsva Higo Rjl bore capacity in steel (diameter): 30 mm throat: 260 mm bore stroke: 160 mm spindle taper MT: MK3 feed steps: 0,1; 0,2; 0,3 mm/U und manuell spindle speed:: max. 1800 stufenlos U/min Distance spindle/table max.: 750 mm table clamping surface:: L: 280 x B: 355 mm table rotating: nein ° clamping table - swivable: 360 Grad drill table adjustment: vertikal: 600 mm column diameter: 130 mm threading: Nein / no total power requirement: 1,1 kW weight of the machine ca.: 570 kg dimension machine xH: 0,9 x 0,9 x 1,9 m This machine has 2 tables. Drilling table LxW: 370 x 500 mm Attachment table: LxW: 420 x 750 mm Clamping surface = 320 x 600 mm, transverse displacement (X-axis) 250 mm possible Ejection of tool via ejector wedge accessories: vice machine base *

Condition: used, Technical details: Dsdpfxju Id Dzj Ag Reul bore capacity in steel (diameter): 16 mm throat: 190 mm bore stroke: 60 mm Distance spindle/table max.: 250 mm range of revolution per miute: 410 / 725 / 1100 / 1700 bei 4step U/min spindle taper MT: MK 2 table surface area: 155 x 155 mm vertical adjustment: Tisch/table = 180 mm table rotating: 360 ° base plate surface area: 175 x 175 mm distance spindle center to floor plate:: max. 360 mm column diameter: 70 mm machine weight ab.: 65 kg dimensions L x W x H: 0,6 x 0,3 x 0,85 m Drill sleeve equipped with drill chuck 1 - 16 mm table rotatable *

Condition: used, Technical details: number of spindles: 4 bore capacity in steel (diameter): 30 mm bore stroke: 200 mm drill spindle - Morse Taper: MK3 spindle throat: 350 mm spindle distance: Mittenstand: 490 mm headstock adjustment: 500 mm feed:: 0,07; 0,15; 0,25; 0,33 / 4step mm/U feed:: manuell und automatisch spindle speed:: 70 ... 1.600 / 8step U/min distance between table/spindle: max. 430 mm distance between table/spindle: min. 180 mm table surface area: 1820 x 400 mm table adjustment: 250mm mit Handkurbel mm total power requirement: 10,8 kW dimension machine xH: ca. 1,0 x 2,1 x 2,8 m All spindle heads with clockwise and counter-clockwise rotation Drill head 1 to 3 clockwise and counter-clockwise rotation without tapping function Drill head 4 with automatic thread-cutting function, rawhide chuck up to Ø 33mm All drill heads and the table are height-adjustable. Equipment: Coolant supply i.D. Dsdpfx Agsu Idt Nj Rjul *

Condition: used, Technical details: bore capacity in steel (diameter): 30 mm bore stroke: 180 mm drill spindle - Morse Taper: 4 x MK 3 spindle throat: 310 mm spindle distance: 490 mm number of drilling stations: 4 headstock adjustment: 300 (manuell) mm feed:: 0,08 - 0,64 / 6 step mm/U spindle speed:: 50 - 1.215 / 19 step U/min distance between table/spindle: max./min.: 500 / 200 mm table surface area: 1820 x 395 mm table adjustment: Höhe: 300 (manuell) mm total power requirement: 4x 1,5 (6,0 kW) kW weight of the machine ca.: 2,8 t dimension machine xH: 2,1 x 1,1 x 2,75 m Further technical data: -Center distance of the drilling spindle 490mm -thread cutting on drilling columns 3 and 4 with automatic switchover -All drilling spindles run with clockwise and counter-clockwise rotation -spindle countershaft and variator -with coolant system Djdpfx Aou Idu Hsg Rsul *

Condition: used, Year of construction: 1972, Technical details: bore capacity in steel (diameter): 25 mm distance drilling head - clamping area: min./ max.: 200 / 600 mm drill head horizontal traverse: 400 mm drilling head vertical adjustable: 200 mm bore spindle stroke: 150 mm spindle taper MT: 3 Djdpfewtcttex Ag Rsul grinding spindle speed: 102 - 2000 / 12 step U/min Arm length: min. / max. 200 / 600 mm Table dimensions: horizontal 930 x 390 mm Table dimensions: vertical 600 x 630 mm dimension machine xH: 1,4 x 1,1 x 2,1 m The machine is currently in the technical department. Boom: Length: 1250mm; vertical adjustment 200mm; horizontal adjustment 400mm, swivel 360°. i.D. *

Condition: used, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 1000 workpiece height max.: - mm Dedpfx Aev S Ay Seg Rjul column diameter: 300 mm horizontal adjustment of the boring slide: 400 mm distance table - lower edge spindle: 200 mm spindle taper MT: MK 4 bore spindle stroke: 200 mm range of revolutions per minute - continous: 18steps 14-710 U/min swivel range of the arm: 360 Grad feed: 0,09/0,12/0,25/0,5 mm/U weight of the machine ca.: 2,0 t dimension machine xH: 2,4 x 0,9 x 2,4 m Transportable! Operation via pressure switch Support feet 4x D=16x30mm Height-adjustable 60 mm with ratchet wrench *

Condition: used, Year of construction: 1992, Technical details: spindle diameter: 100 mm x-travel: 1500 mm y-travel: 1450 mm z-axis: 930 mm w-axis: 506 mm B-axis (table): 360 ° control for program: HdH TNC 407 tool taper: SK50 number of spindle speeds: 5 - 1.600 / stufenlos table load: 4,0 t table-size: 1100 x 1400 mm table rotating: 360 ° feed steps: X/Y/W/Z-Achse: 2 - 2000 mm/min Dujdpfxeu Idqbs Ag Rjl Rapid feed X axis: X/Y/W/Z-Achse 5000 mm/min. total power requirement: 40 kW dimensions electric cabinet: 2000 x 600 x 2000 mm machine dimensions LxWxH: 4,9 x 3,7 x 3,8 m weight of the machine ca.: 14 t CNC drilling-milling machine with hydraulic power unit. Working paths from the table: X-axis table transverse 1500mm W-axis table longitudinal 1000mm 9x T-slots according to DIN 650 Equipment: measuring probe electronic handwheel hydr. weight compensation Y-axis universal milling head And some accessories, ask for them! i.D. *

Condition: used, Technical details: bore capacity in steel (diameter): 28 mm throat: 345 mm bore stroke: 190 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 4 spindle speed:: 50 - 1280 / 4 steples U/min Duedpfx Aeu Idk Ueg Rol feed: 0,1; 0,2, 0,3 manuell/automastic mm/U Distance spindle/table max.: 200 - 800 mm table clamping surface:: 450 x 600 mm table rotating: 360 ° table adjustment: vertical 600 mm column diameter: Ø 160 mm weight of the machine ca.: 273 kg dimension machine xH: 1,0 x 0,71 x 2,0 m Thread cutting with right and left rotation via foot switch Table adjustment via hand crank Without coolant tank Machine vice Quick-action clamping chuck Röhm Supra 3 - 16mm i.D. *

Condition: used, Technical details: number of spindles: 4 bore capacity in steel (diameter): 2-16 mm bore stroke: 140 mm Dsdpfx Aju Idugsg Roul drill spindle - Morse Taper: MK 3 spindle throat: 280 mm spindle distance: 455 mm headstock adjustment: 250 via Hand - Kurbel mm feed:: 0,08 - 0,12 - 0,20 - 0,31 / 4 steps mm/U feed:: automatic + manuell spindle speed:: 180 - 2000 / 8 steps U/min distance between table/spindle: min. 3x 140mm und 1x 260mm mm distance between table/spindle: max. 3x 700mm und 1x 820mm mm table surface area: 1800 x 350 mm table adjustment: 300 via Hand mm total power requirement: 6,3 kW weight of the machine ca.: 2,4 t dimension machine xH: 2,1 x 0,9 x 2,2 m Application: Drilling, countersinking; reaming and thread cutting. Each drill spindle has its own drive motor Equipment: Foot pedal/operation Hand crank *

Condition: used, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 275-800 workpiece height max.: 1.040 mm horizontal adjustment of the boring slide: 180 mm vertical adjustment of arm: 800 mm distance table - lower edge spindle: 1.040 max -350 min mm spindle taper MT: MK 4 range of revolutions per minute - continous: 63 - 1.600 / 8 step U/min swivel range of the arm: 360 Grad feed: 0,125/0,200/0,315 mm/U Dsdpfxowa Rzle Ag Rsul column diameter: 180 mm base plate surface area: 730 x 500 mm weight of the machine ca.: 1,2 t dimension machine xH: 1,75x0,56x1,97 m Cooling water system with pump and supply to the spindle *

Condition: used, Year of construction: 1987, Technical details: spindle diameter: 120 mm x-travel: 2750 mm y-travel: 1500 mm z-travel: 1250 mm B-axis (table): 360 W-axis (spindle longitudinal): 900 mm control for program: TNC 155 Bahnsteuerung / contouring control tool taper: SK50 table load: 6,3 t table-size: 1600 x 1400 mm table rotating: 360 ° Dujdpfx Aou Idrfjg Rjl range drill spindle revolution per minute: 3 - 1000 U/min total power requirement: 100 kW dimensions electric cabinet: L: 650 x B: 2800 x H: 2100 mm machine dimensions LxWxH: siehe Liste m weight of the machine ca.: ca. 15,0 t Contouring control Facing slide feed 210mm (U-axis) hydraulic unit Boom with control panel Measuring system Heidenhain *

Condition: used, Year of construction: 1999, Technical details: bore capacity in steel (diameter): 32 mm throat: 293 mm bore stroke: 120 mm bore capacity in cast iron: Ø 38 mm spindle taper MT: MK 3 spindle throat: 293 mm spindle speed:: 160 - 2250 / seples U/min feed: 0,10 - 0,20 / manuell+automatisch mm/U Distance spindle/table max.: 55 - 642 mm Djdpjva Hmrofx Ag Reul table clamping surface:: 300 x 300 mm drill table adjustment: ja mm column diameter: 115 mm distance spindle center to floor plate:: 1207 mm total power requirement: 1,9 kW weight of the machine ca.: 280 kg dimension machine xH: 0,7 x 1,0 x 1,9 m Column drilling machine with infinitely variable speed adjustment and automatic feed. Tapping with changeover switchEquipment: RÖHM 3 - 16 mm chuck, operation by foot switch left/right *

Condition: used, Year of construction: 1989, Technical details: bore capacity in steel (diameter): 28 mm throat: 285 mm bore stroke: 165 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 3 spindle speed:: 65 - 1.750 / 4x steples U/min feed: 0,1; 0,2; 0,3 manuell/automatisch mm/U Distance spindle/table max.: 80 - 680 mm table clamping surface:: 500 x 370 mm Duodpfx Agsu Idkze Rjl table rotating: 360 ° drill table adjustment: 600 vertical mm column diameter: Ø 130 mm total power requirement: 7,5 kW weight of the machine ca.: 273 kg dimension machine xH: 0,9 x 0,6 x 1,9 m The machine can cut threads, change of direction left/right selectable via foot switch and/or depth stop Table can be swiveled and adjusted in height. *

Condition: used, Year of construction: 1976, Technical details: bore capacity in steel (diameter): 32 mm throat: 320 mm bore stroke: 255 mm drill capacity in cast iron: Ø 40 mm spindle taper MT: 4 spindle speed:: bis 1500 / 6 step U/min feed: 0,1 - 0,16 - 0,25 - 0,4 mm/U feed:: automatisch / manual mm/U throat: 320 mm table clamping surface:: 400 x 400 mm Distance spindle/table max.: 50 - 700 mm drill table adjustment: 650 mm distance ground floor - spindle: 1185 mm base plate surface area: 560 x 435 mm column diameter: 160 mm total power requirement: ca. 2,2 kW Duodov Sb Inepfx Ag Rol weight of the machine ca.: 720 kg dimension machine xH: 1,0 x 0,6 x 2,5 m Spindle right/left rotation Work table can be rotated and tilted left/right Coolant tank/coolant device Machine illumination *

Condition: used, Year of construction: 1982, Technical details: Duodpfxou Idkbe Ag Rel bore capacity in steel (diameter): 28 mm throat: 300 mm bore stroke: 150 mm drill capacity in cast iron: 30 mm spindle taper MT: MK3 spindle speed:: 200; 300; 500; 800; 1250; 2000 / 6 step U/min feed: manuell mm/U Distance spindle/table max.: 50 - 600 mm table clamping surface:: 330 x 300 mm table rotating: nein ° drill table adjustment: 550 (Handkurbel) mm column diameter: Ø 125 mm total power requirement: 1,5 kW weight of the machine ca.: ca. 300 kg dimension machine xH: 0,7 x 0,45 x 1,87 m Equipped with RÖHM Supra 3 - 16mm quick-action chuck Machine vice *

Condition: used, Year of construction: 1997, Technical details: bore capacity in steel (diameter): 35 mm arm length: - mm workpiece height max.: 660 mm threading: GG 25 M36 threading: ST 60 M30 drill capacity in cast iron: 42 mm tool taper: MK4 quill stroke: 165 mm Table dimensions: 1200 x 600 mm column diameter: 170 mm work height max.: 900 mm current type: Drehstrom total power requirement: 25 A frequency: 50 Hz connection voltage: 400 V connected load: 6,5 kVA dimension machine xH: 2,3 x 1,7 x 2,4 m weight of the machine ca.: 2,5 t Accessories and Equipment – DONAU DANUFLEX 135 Accessories: ·1 × Drill chuck ·2 × Angle plates ·1 × Machine vice ·1 × Clamping cube Features / Equipment: ·Side drilling table, height-adjustable ·Drilling possible at up to 3 stations (front, left, rear) Duodpfjxu Dwgex Ag Rjl ·Two-stage spindle gearbox, automatic switching via push button ·Continously variable spindle speed control in each gear stage: 20 – 3,100 rpm ·Continuously adjustable feed rate ·Thread cutting device integrated ·Adjustable depth limit stop *

Condition: used, Year of construction: 2004, Technical details: table length: 4000 mm table width: 2000 mm Max. sheet thickness: 100 mm table height over floor: ca. 860 mm total wight: 5,6 + 0,5 t Dujdpfsu Nkxuex Ag Rel dimensions LxWxH: 4,0 x 2,2 x 0,1 m Welding table / Pricing 0.50 EUR/kg with substructure and 6 base stands *
