Used High Speed Milling Machine for sale (99,736)

Condition: new, The UWF 1.1, a top-tier Conventional Vertical Milling Machine in the Universal Milling Machines group, showcases the precision and robustness that KNUTH is known for. Equipped with a large clamping table and a swiveling universal milling head that pivots in two planes, it effectively meets the diverse needs of a universal milling machine, making it ideal for individual production, repair, and training workshops. The heavy machine frame is complemented by wide, adjustable dovetail guides across all axes, ensuring stability and accuracy. An automatic feed system operates through a gearbox, driving the X- and Y-axes, while rapid traverse is available for the Z-axis. With features such as a motorized height adjustment in the Z direction and an outer arbor support for horizontal milling, the UWF 1.1 stands out with its extensive standard equipment. Request a quote today to enhance your machining capabilities with this exceptional Conventional Vertical Milling Machine and Universal Milling Machine from KNUTH. Gjdpowub Acjfx Ah Heil

Condition: used, Year of construction: 1995, pressure 100 t stroke 20 - 120 mm no. of strokes 40 - 240 /min distance between columns 1300 mm dayligth (stroke and adjustment up) 670 mm column travel -side 400 mm table surface area 1200 x 800 mm hole in the table 900 x 200 mm table height over floor 1150 mm ram surface 1130 x 650 mm ram adjustment 80 mm material width 250 mm material thickness 0,3 - 3,0 mm material cross-cut 750 mm² feed length 1 - 9999,9 mm power requirement 22,0 kW Weight 16,0 t dimensions (WxDxH) 3,7 x 2,5 x 3,7 m Gjdpfswc U Nlox Ah Hsil height over floor 3,7 m permitted for automatic mode according to the CE-Norm with infinitely variable PIV-drive, pneumatic clutch/brake combination (make Ortlinghaus), electronic press force monitoring (two channel), automatic stroke adjustment, motoric ram adjustment, pneumatic counterbalance in ram, motorised circular oil lubrication electronic roll feed (make Kaiser, type KWV 250)

Condition: good (used), Year of construction: 1972, functionality: fully functional, overall weight: 1,200 kg, x-travel: 290 mm y-travel: 170 mm z-travel: 310 mm Millung spindle number of milling spindle turning speeds: 16 milling spindle turning speeds: 40 - 2000 U/min inner taper of milling spindle: ISO 40 max. diameter of the vice bore: 25 Vertical milling head Gedpfxox Tdkgo Ah Heil inner taper of milling spindle: ISO 40 spindle turning speed range: 50 - 2.500 U/min max. diameter of the vice bore: 25 dimensions: 1.100 x 1.100 x 1.660 mm

Condition: as good as new (ex-display), Year of construction: 2024, Machine is in the exhibition and was only used for demonstration purposes. Optimill F 150 E CNC milling machine direct from the manufacturer. F 150 E - The OPTIMUM CNC milling machine with Siemens control SINUMERIK 808D Advanced is characterized by performance, speed, precision and long service life. Carousel tool changer with 16 tool positions Gjdpfx Ahow Ea Dge Hoil All linear guides with stainless steel covers Automatic central lubrication Siemens main spindle motor Servo drive from SIEMENS in all axes (closed control loop) Chip conveyor in belt design ensures efficient chip removal Chip trolley Max. Spindle speed 10,000 min-1 Machine light in the work area Portable, electronic handwheel with enabling switch and emergency stop switch. Makes running in programs considerably easier Coolant system with 190 liter coolant tank Tools are changed automatically or at the touch of a button Solid, exact milling table, large dimensions and precise surface finish Access doors very generously designed to reduce cleaning and maintenance time to a minimum Software package "SINUMERIK 808D on PC" included. (Practical training software so that workpieces can be programmed and simulated offline on the PC. Software can be downloaded free of charge at). SINUMERIK 808 ADVANCED - CNC technology from the technology leader, paired with a revolutionary operating concept The SINUMERIK 808D ADVANCED control is a panel-based CNC control. The compact and user-friendly entry-level solution is used for simple milling applications. Features such as simple operation, commissioning and maintenance are the perfect basis for equipping CNC machines. Thanks to its technology-specific features, the SINUMERIK 808D ADVANCED control is perfectly preconfigured for milling. Thanks to the hardware and software extensions, the SINUMERIK 808D ADVANCED also offers sufficient performance for simple milling functions in mold and tool making. Compact and robust Thanks to a panel-based CNC design with few interfaces and a control panel in protection class IP65, the SINUMERIK 808D ADVANCED is perfectly prepared for use in harsh environments. The small dimensions allow it to be used in compact machines INCLUDED RJ45 Ethernet port 8.4" LCD color display with 800 x 600 resolution Prepared for remote maintenance AST function; enables simple optimization for higher dynamic and accuracy requirements Absolute encoder / no reference run required Higher accuracy Travel distance: X=750mm Y=500mm Z=500mm Dimensions and weights Length approx. 3420 mm Width/depth approx. 2050 mm Height approx. 2400 mm Weight approx. 4500 kg Drilling/milling capacity Cutter head size max. 80 mm End mill size max. 38 mm Electrical data Supply voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 15 kW Horizontal milling table Length 900 mm Width 500 mm Distance vertical spindle - milling table min. 100 mm Distance vertical spindle - milling table max. 600 mm T-slots size 18 mm Number of T-slots 5 T-slot spacing 80 mm Load capacity max. 350 kg Accuracy Repeat accuracy ±0.005 mm Positioning accuracy ±0.01 mm

Condition: excellent (used), Year of construction: 2013, functionality: fully functional, travel distance X-axis: 6,500 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 650 mm, table length: 6,300 mm, table width: 2,500 mm, spindle speed (min.): 30 rpm, spindle speed (max.): 4,000 rpm, rapid traverse X-axis: 20,000 m/min, rapid traverse Y-axis: 3,500 m/min, rapid traverse Z-axis: 10,000 m/min, distance between stands: 3,050 mm, table load: 30,000 kg, overall weight: 59,000 kg, spindle nose: NT No.50, feed length W-axis: 1,300 mm, Okuma MCR-A5C gantry machining center (2013) with BT50 spindle, 6,500 mm X-travel and 30 t table load. Machine has approx. 5,700 cutting hours and 6,900 spindle hours, suitable for heavy and precise machining of large workpieces. Gisdpfxox Tzyxo Ah Hel

Condition: refurbished (used), Deckel FP1 Activ CNC Milling Machine – Completely Refurbished The Deckel FP1 Activ has stood for highest precision, durability, and universal application in toolmaking, training, and manufacturing for decades. In the variant offered here, completely refurbished, you receive a machine that is both technically and visually overhauled, coming very close to new condition while offering a cost-effective alternative to a new purchase. Condition: Completely Refurbished The machine has been fully overhauled and subjected to a comprehensive technical inspection. All relevant assemblies have been checked, repaired, or replaced as necessary. The goal is a permanently reliable machine with high accuracy and repeatable performance. Scope of Refurbishment - Full technical inspection of all functions - Repair or replacement of defective components - Thorough cleaning of the entire machine - Readjustment of all existing settings - Replacement of all lubricants - Replacement of various standard parts - Replacement of worn components - New painting in desired color - Overhaul of guideways Delivery Time Approx. 12 weeks from receipt of order Your Advantages at a Glance - High precision and stability - Proven Deckel quality - Significantly more economical compared to a new machine - Ideal for one-off production, training, and workshop use - Future-proof investment with long service life - Alternative options available Giedpfxjx Tdy Ij Ah Hjl Upon request, we can also offer you a partially refurbished or workshop-inspected alternative. Delivery time for these options is shorter and available upon request. Please refer to the table for details on the respective scope of refurbishment or contact us directly. We are happy to advise you personally on specifications, control options, and suitable accessories. We will find the right solution for your application.

Condition: new, The UWF 3.2, a robust Universal Milling Machine in the category of Conventional Vertical Milling Machines, enhances the acclaimed UWF 3 with its advanced specifications. This versatile machine features a high-strength HT-200 cast-iron bed for exceptional rigidity and stability under heavy loads. It offers a generous setup area of 1,370 x 320 mm, while its precision-ground guideways ensure long-term accuracy and minimal wear. Operators can enjoy the flexibility of an infinitely variable servomotor feed across all three axes. Additionally, the universal cutter head swivels on two planes, enabling a swift transition from horizontal to vertical machining. Included are essential tools and features like a powerful coolant system and a chip tray to streamline your workflow. Whether in a repair workshop or for training applications, the UWF 3.2 stands out for its performance and reliability. To discover how this Universal Milling Machine can meet your production needs, request a quote today. Gedpfeuyh Aljx Ah Hoil

Condition: used, Year of construction: 1990, pressure 32 t distance between columns 680 / 550 mm stroke 8 - 50 mm no. of strokes 85 - 500 Hub/min dayligth (stroke and adjustment up) 300 mm column travel -side 250 mm table surface area 620 x 450 mm hole in the table 450 x 110 mm table height over floor 915 mm ram surface 560 x 350 mm power requirement 7,5 kW weight of the machine ca. 5,60 t required space 3,6 x 1,65 x 2,8 m Giedpfxjvuuf So Ah Hsl ram adjustment 50 mm permitted for automatic mode according to the German Safety Regulations (UVV) with infinitely variable drive, pneumatic clutch, pneumatic counterbalance in ram, pincer feed (ZR 18 D) can be offered without or with putting into operation in given condition

Condition: good (used), Year of construction: 1972, functionality: fully functional, travel distance X-axis: 290 mm, travel distance Y-axis: 170 mm, travel distance Z-axis: 310 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, overall weight: 1,200 kg, x- travel: 290 mm y-travel: 170 mm z-travel: 310 mm Milling spindle number of milling spindle turning speeds: 16 milling spindle turning speeds: 40-2000 U/min inner taper of milling spindle: ISO 40 max. diameter of the vice bore: 25 mm dimensions: 1066 x 1048 x 1330 mm Gisdsx Tdipopfx Ah Hjl

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in the exhibition. Optimill F 110 HSC Premium CNC milling machine direct from the manufacturer. F 110 HSC - The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control is characterized by performance, speed, precision and a long service life. - Heavy-duty design - High productivity - High reliability Gedpew Ea Rgefx Ah Hsil - Heavily ribbed, torsion-free machine base - Profiled rail with recirculating ball bearing for high rapid traverse speeds in all axes - High-torque servo drives in all three axes - Telescopic guideway cover on all three axes - Automatic lubrication - Massive, exact milling table with three T-slots, large dimensions and precision-ground - The portable, electronic handwheel with enabling switch and emergency stop switch makes it much easier to the run-in of programs considerably - Coolant device with chip flushing system and cleaning gun - Chip conveyor in belt design ensures efficient chip removal - Chip trolley - RJ45 plug connection and 230 V power connection - Closed switch cabinet with integrated heat exchanger ensures optimum temperature and prevents the ingress of dirt particles - Machine light in the work area - Additional package SIEMENS material liability for defects and free online/on-site service OSS Plus - 1-year Basic maintenance contract included in D/A/CH Milling spindle Inline spindle Machine data Electrical connection 400 V / ~50 Hz Total connected load 15 kVA Milling spindle Drive motor S1 operation 9 kW Torque drive motor S1 operation 57 Nm Drive motor S6-30% operation 21.2 kw Torque drive motor S6-30% operation 135 Nm Spindle holder SK 40 / DIN 69871 Internal spindle cooling option Drive motor S1 operation 10.5 kW Torque drive motor S1 operation 50 Nm Drive motor S6-30% operation 26.4 kW Torque drive motor S6-30% operation 125 Nm Cooling lubricant system Power of the coolant pumps, 2 pieces 900 W Delivery rate max. 35 l/min. Tank capacity 116 liters Cleaning pump Power of the cleaning pump 530 W Milling accuracy Repeat accuracy ± 0.005 mm Positioning accuracy ± 0.005 mm Tool changer Double arm gripper type Number of tool positions 20 Tool diameter max. 78 mm Tool diameter (secondary positions free) max. 120 mm Tool length 300 mm Tool weight max. 8 kg Time tool change: tool to tool 2.5 seconds Travel distance X-axis 650 mm Y-axis 400 mm Z-axis 500 mm Feed drive Rapid traverse X-, Y-, Z-axis 48 / 48 / 32 m/min. Motor torque X- / Y- / Z-axis 11 Nm / 11 Nm / 20 Nm Feed forces X- / Y- / Z-axis 3.67 kN / 3.67 kN / 6.68 kN Speed range Speeds* 12,000 min-1 Pneumatics Air pressure 6 bar Air consumption per hour 6 - 8 kg/m³ Milling table Distance spindle - table 100 - 600 mm Table length x width 850 x 400 mm T-slot size / number / distance 18 mm / 3 / 100 mm Max. load 400 kg Dimensions Length x width x height 2,100 x 2,300 x 2,750 mm Total weight 4,300 kg

Condition: new, Year of construction: 2024, Universal milling and drilling machine Kunzmann WF 610 M with Heidenhain TNC 128 control system Paths X/Y/Z = 610/400/450 mm Speed 1-4500 rpm Power 8.5 kW at 100 % ED Spindle SK40 DIN 69871 (form AD) with tightening bolt DIN 69872 Fixed angle table 800x 425 mm 6 x 14 H7 T-slots coolant device 66 liters electric handwheel HEIDENHAIN HR 510 FS Gijdjuf Sv Dspfx Ah Hol Further technical data is available on request. The machine is located at our premises in 71334 Waiblingen-Beinstein, is immediately available and can also be inspected. Please register in advance.

Condition: used, Year of construction: 1994, pressure 250 t distance between columns 1650 / 1400 mm stroke fix 150 mm no. of strokes 30 - 75 Hub/min Giedpfovuucwjx Ah Hel dayligth (stroke and adjustment up) 665 mm column travel -side 550 mm table surface area 1600 x 900 mm hole in the table 1000 x 300 mm table height over floor 980 mm ram surface 1400 x 900 mm power requirement 42,0 kW weight of the machine ca. 33,00 t required space 2,8 x 2,5 x 4,4 m permitted for automatic mode according to the German Safety Regulations (UVV) with infinitely variable drive, pneumatic clutch/brake combination (Ortlinghaus), hydraulic overload protection in ram, pneumatic counterbalance in ram, FIX stroke, motoric ram adjustment, motoric centralized lubrication Werkzeugwechselsystem elektronischem Walzenvorschub (Normatic, AESL 500-2,8) electronic roll feed (Normatic, AESL 500-2,8) with motor (Indramat), motorised adjustable material guide, motorised height adjustment tool changing system distance table - ram without tool changing system approx. 765 mm can be offered without putting into operation or alternatively with new control Siemens S 7-1500 F

Condition: as good as new (ex-display), Year of construction: 2019, Machine is in the exhibition and was only used for demonstration purposes. Sale of last Optimill F 120X CNC milling machine directly from the manufacturer. F 120X - The OPTIMUM CNC milling machine with Siemens control SINUMERIK 828D is characterized by performance, speed, precision and long service life. Heavy-duty design High productivity Linear guides for high rapid traverse speeds in all axes 21-fold magazine tool changer High reliability Cast body made of quality Mehanite casting Cross table precision ground with 3 T-slots Heavily ribbed, torsion-free machine base Precision-ground, preloaded high-performance ball screws ball screws in all axes High-torque servo drives directly on the ball screws Giodpsw Ea Rmefx Ah Hel in all 3 axes Electronic handwheel Chip conveyor Cleaning gun RJ45 plug connection, USB connection and power connection (230V) Coolant unit with 210 liter coolant tank Heat exchanger Options included: PPU 290 touch panel 16000rpm inline spindle with oil cooler Belt conveyor with chip cart Machine leasing possible via Siemens Finance. Liquidity prerequisite. Dimensions and weights Length approx. 2315 mm Width/depth approx. 2194 mm Height approx. 2325 mm Weight approx. 3800 kg Drilling/milling capacity Cutter head size max. 80 mm Feed/rapid traverse speed X-axis 40000 mm/min Y-axis 40000 mm/min Z-axis 40000 mm/min Electrical data Supply voltage 400 V Phase(s) 3 Ph Current type AC Mains frequency 50 Hz Electrical connection Total connected load 45 kVA Distance vertical spindle - milling table min. 150 mm Distance vertical spindle - milling table max. 450 mm T-slots size 14 mm Number of T-slots 3 T-slot spacing 125 mm Max. load 250 kg Accuracy Repeat accuracy ± 0.006 mm Positioning accuracy ± 0.005 mm Cooling lubricant system Coolant pumps Coolant pump(s) Drive power 370W each Tank capacity 120 l Control system Type Sinumerik 828D PPU 290 System software SW 28x CNC memory 8 MB Block change time 2 ms Look Ahead 150 Number of tools 512 Travel distance X-axis automatic 500 mm Y-axis automatic 400 mm Z-axis automatic 300 mm Vertical spindle Spindle holder BT 30 Speed range 10 - 16000 min¯¹ Power drive motor continuous operation S1 12 kW Power drive motor S6-30 % operation 22.8 kW Torque drive motor continuous operation S1 38 Nm Torque drive motor 30% operation S6 116 Nm Feed motor torque X-axis continuous operation S1 6 Nm Y-axis continuous operation S1 6 Nm Z-axis continuous operation S1 11 Nm Servo tool changer Carousel type in front of the spindle Number of tool positions 21 tools

Condition: used, Year of construction: 1982, pressure 30 t stroke 8 - 40 mm no. of strokes 100 - 600 /min distance between columns 330 mm dayligth (stroke and adjustment up) 280 mm column travel -side 300 mm table surface area 540 x 470 mm hole in the table 315 x 110 mm table height over floor 1000 mm Giedpovuk Hrsfx Ah Hel ram surface 250 mm material width 120 mm material thickness - 3,0 mm feed length - 60 mm power requirement 5,5 kW Weight 2,6 t dimensions of the machine ca. 1,5 x 1,2 x 2,2 mxmxm permitted for automatic mode according to the German Safety Regulations (UVV) with infinitely variable drive, pneumatic clutch, manual stroke adjustment, manuel ram adjustment, fix table, mechanical roll feed (Bruderer BBV 120/60) table surface 540 x 300 mm or 330 x 390 mm as is where is, WITHOUT putting into operation

Condition: as good as new (ex-display), Year of construction: 2024, The machine is on display. Optimill F 300 HSC Premium CNC milling machine, direct from the manufacturer. F 300 HSC – The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control stands out for its power, speed, precision, and exceptional service life. • Heavy-duty construction • High productivity • High reliability • Strongly ribbed, torsion-resistant machine base • Linear guideways with recirculating rollers on all axes for high load capacities • High-torque servo drives directly connected to the ball screws on all three axes • Precision-ground, pre-tensioned high-performance ball screws for rapid traverse speeds on all axes • Telescopic guideway covers on all three axes Gedpfxsw Ea Ife Ah Heil • Main spindle SK40 with spindle speed up to 15,000 rpm with inline spindle • Massive, highly precise milling table with five T-slots—large dimensions and precision-ground • Portable electronic handwheel with enabling button and emergency-stop key significantly simplifies program setup • Tool changer with arm gripper, 30 tool positions • Coolant system with chip flushing and cleaning gun • 20-bar internal spindle coolant • Belt-type chip conveyor ensures efficient swarf removal • Chip trolley • Oil separator • LED machine light in the working area • SIEMENS extended warranty package and free online/on-site service (OSS Plus) • 1 year Basic maintenance contract included for Germany/Austria/Switzerland • Control System: • 15.6" color display • 16:9 format • Complete Package: • Safety Integrated • Residual material detection and processing • ShopMill step programming • Network drive management • 3D simulation • Path tracing • Additional Siemens OSS PLUS packages: • 12 months; Item No. 3589020 • 24 months; Item No. 3589021 • 36 months; Item No. 3589022 • Technical Features: • Inline spindle • Taper SK 40 / DIN 69871 • Spindle speed 15,000 rpm • Dimensions & Weight: • Length: approx. 2,856 mm • Width/Depth: approx. 2,300 mm • Height: approx. 2,850 mm • Weight: approx. 6,500 kg • Rapid Traverse Speeds: • X-axis: 36 m/min • Y-axis: 36 m/min • Z-axis: 32 m/min • Electrical Data: • Connection voltage: 400 V • Line frequency: 50 Hz • Power connection: Total connected load 30 kVA • Milling Table (horizontal): • Length: 1,200 mm • Width: 600 mm • T-slot size: 18 mm • Number of T-slots: 5 • T-slot spacing: 100 mm • Max. load capacity: 800 kg • Accuracy: • Repeatability: ± 0.005 mm • Positioning accuracy: ± 0.005 mm • Travel Path: • X-axis (auto): 1,000 mm • Y-axis (auto): 620 mm • Z-axis (auto): 630 mm • Vertical Spindle: • Spindle taper: SK 40 DIN 69871 • Speed range: 15,000 rpm • Main drive motor (S1 continuous): 20 kW • Main drive motor (S6-30% cyclical): 52.4 kW • Motor torque (S1 continuous): 96 Nm • Motor torque (S6-30% cyclical): 250 Nm • Feed Force: • X-axis: 6.68 kN • Y-axis: 6.68 kN • Z-axis: 12.01 kN • Feed Motor Torque (S1 continuous): • X-axis: 20 Nm • Y-axis: 20 Nm • Z-axis: 36 Nm • Tool Changer: • Double arm gripper • Tool positions: 30 • Max. tool length: 300 mm • Max. tool weight: 8 kg • Tool change time (tool-to-tool): 2.5 sec.

Condition: used, Year of construction: 1983, pressure 160 t stroke fix 160 mm no. of strokes 30 - 120 /min distance between columns 1190 mm dayligth (stroke and adjustment up) 735 mm column travel -side 600 mm table surface area 1200 x 1000 mm hole in the table 500 x 300 mm table height over floor 900 mm ram surface 1000 x 800 mm ram adjustment 125 mm material width 550 mm material thickness 0 - 6,0 mm material cross-cut 1100 mm² feed length 350 mm power requirement 45,0 kW Weight 25,0 t dimensions of the machine ca. 2,3 x 2,1 x 4,7 mxmxm permitted for automatic mode according to the German Safety Regulations (UVV) Gjdpfxjvuk E Us Ah Hjil with infinitely variable drive (PIV), hydraulic overload protection in ram, motoric ram adjustment, pneumatic counterbalance in ram, ram interlocking, centralized lubrication, mechanical pincer feed (Haulick, RS 350/550 SL 90) as is where is, WITHOUT putting into operation

Condition: as good as new (ex-display), Year of construction: 2025, The machine is currently on display. Optimill F 110 E CNC milling machine, direct from the manufacturer. F 110 E – The OPTIMUM CNC milling machine equipped with Siemens SINUMERIK 808D control, stands out for its performance, speed, precision, and long service life. • Heavy-duty construction • High productivity • High reliability • Strongly ribbed, torsion-resistant machine base • Linear guideways with ball circulation for high rapid traverse speeds on all axes • Powerful servo drives on all three axes • Telescopic covers on all guideways • Automatic lubrication • Spindle oil cooler • Solid, precision-ground milling table with three oversized T-slots Gjdpfx Aow Ebv Reh Hjil • The portable electronic handwheel with enabling button and emergency stop switch greatly facilitates program setup • Coolant system with chip flushing and cleaning gun • Chip conveyor with auger design • Chip cart • RJ45 interface and 230 V power connection • Enclosed electrical cabinet with integrated heat exchanger ensures optimal temperature and prevents ingress of dirt particles • Machine lamp providing over 500 Lux in the working area RJ45 Ethernet port 8.4” LCD color display with 800 x 600 resolution Prepared for remote maintenance AST function: enables easy optimization for higher requirements in dynamics and accuracy Absolute encoder / no reference run necessary Higher accuracy Travel distances: X = 650 mm Y = 400 mm Z = 500 mm Dimensions and weights Length approx. 2,100 mm Width/depth approx. 2,300 mm Height approx. 2,750 mm Weight approx. 4,100 kg Boring/milling performance Max. cutter head size: 90 mm Electrical data Connection voltage: 400 V Network frequency: 50 Hz Electrical connection Total connected load: 20 kW Horizontal milling table: Length: 850 mm Width: 400 mm Distance spindle nose to table min.: 100 mm Distance spindle nose to table max.: 600 mm T-slot size: 18 mm Number of T-slots: 3 T-slot spacing: 100 mm Maximum load capacity: 400 kg Accuracy Repeat accuracy: ±0.005 mm Positioning accuracy: ±0.005 mm

Condition: used, Year of construction: 1996, pressure 63 t distance between columns 965 mm stroke 4 - 60 mm no. of strokes 30 - 800 Hub/min dayligth (stroke and adjustment up) 380 mm column travel -side 355 mm table surface area 960 x 640 mm hole in the table 850 x 140 mm table height over floor 1150 mm ram surface 960 x 460 mm power requirement 32,5 kW weight of the machine ca. 13,00 t required space 3,3 x 1,7 x 2,9 m Gedovut Rgopfx Ah Heil ram adjustment 80 mm permitted for automatic mode according to the CE Regulations with infinitely variable drive, pneumatic clutch, semi-automatic stroke adjustment, motoric ram adjustment, mechanical pincer feed type GF 160 can be offered without or with putting into operation in given condition

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in the exhibition and was only used for demonstration purposes. Optimill F 80 CNC milling machine direct from the manufacturer. - Machine in cast iron column design for high rigidity - Carousel tool changer with 12 tool positions - All linear guides with stainless steel covers - Automatic central lubrication - Siemens main spindle motor - Siemens servo drive in all axes (closed control loop) - Maximum spindle speed of 10,000 min-1 - The portable, electronic handwheel with enabling switch and emergency stop switch makes it much easier to run in programs SINUMERIK 808 ADVANCED CNC technology from the technology leader SINUMERIK 808D on PC - Control-identical software package that further simplifies the handling of the machine tool Compact and robust - Thanks to a panel-based CNC design with few interfaces and a control panel in protection class IP65, the SINUMERIK 808D ADVANCED is perfectly prepared for use in harsh environments Communicative - Front panel USB (IP65) - Serial interface RS232C - RJ45 Ethernet on the rear - Technology-specific keyboard layout - Hard keys with protective membrane Dimensions and weights Length approx. 1995 mm Width/depth approx. 1930 mm Height approx. 1640 mm Weight approx. 2300 kg Rapid traverse speed X-axis 20 m/min Y-axis 20 m/min Gisdpfx Aow Ea Rtsh Hol Z-axis 20 m/min Electrical data Supply voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 12 kVA Horizontal milling table Length 800 mm Width 260 mm Distance vertical spindle - milling table min. 100 mm Distance vertical spindle - milling table max. 550 mm T-slots size 16 mm Number of T-slots 5 T-slot spacing 50 mm Load capacity max. 200 kg Accuracy Repeat accuracy ± 0.01 mm Positioning accuracy ± 0.01 mm Coolant system Coolant pump(s) Drive power 450 W Tank capacity 80 l Pneumatic connection Operating pressure 7 bar Travel distance X-axis automatic 450 mm Y-axis automatic 260 mm Z-axis automatic 450 mm Distance spindle - column max. 370 mm Vertical spindle Spindle holder BT 40 Speed range 50 - 10000 min¯¹ Power drive motor continuous operation S1 3.7 kW Power drive motor S6-30 % operation 5.5 kW Torque drive motor continuous operation S1 24 Nm Torque drive motor 30% operation S6 36 Nm Feed motor Torque X-axis continuous operation S1 6 Nm Y-axis continuous operation S1 6 Nm Z-axis continuous operation S1 11 Nm Tool changer Carousel type Number of tool positions 12 tools Tool diameter max. 95 mm Tool length max. 300 mm Tool weight max. 8 kg Time tool change chip to chip (C to C) 7 s

Condition: used, Year of construction: 1993, pressure 63 t stroke 10 - 80 mm no. of strokes 75 - 400 /min distance between columns 1080 / 920 mm dayligth (stroke and adjustment up) 450 mm column travel -side 300 mm table surface area 1000 x 550 mm hole in the table 700 x 160 mm table height over floor 1080 mm ram surface 900 x 450 mm ram adjustment 80 mm material width 250 mm material thickness 0,3 - 3,0 mm Gjdpfevut Ixox Ah Heil material cross-cut 750 mm² feed length 1,0 – 9999,9 mm power requirement 11,0 kW Weight 9,5 t dimensions of the machine ca. 2,8 x 2,7 x 3,1 mxmxm permitted for automatic mode according to the German Safety Regulations (UVV) with infinitely variable drive (PIV), pneumatic clutch/brake combination (make Ortlinghaus), manual stroke adjustment, motoric ram adjustment, motoric circular oil lubrication, pneumatic counterbalance in ram electronic servo-roll feed Kaiser KWV 250

Condition: as good as new (ex-display), Year of construction: 2025, The machine is on display. Optimill F110 ECO Premium CNC milling machine, direct from the manufacturer. F110 ECO – The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control stands out for its performance, speed, precision, and long service life. Model: F110 ECO Control: SIEMENS SINUMERIK 828D PPU271.5 Milling spindle with belt drive Machine Specifications Electrical connection: 400 V / ~50 Hz Total connected load: 15 kVA Milling Spindle Drive motor S1 operation: 7.5 kW Torque of drive motor S1 operation: 45 Nm Drive motor S6 30% operation: 16.2 kW Torque of drive motor S6 30% operation: 103 Nm Spindle taper: BT40 Coolant System Coolant pump output: 900 W Max. flow rate: 35 l/min Tank capacity: 116 liters Cleaning pump Milling Precision Repeatability: 0.008 mm Positioning accuracy: 0.004 mm Tool Changer Type: Double-arm gripper Giodpfew Edbpsx Ah Hsl Number of tool stations: 20 Max. tool diameter: 78 mm Max. tool diameter (neighboring tool pockets empty): 120 mm Tool length: 300 mm Max. tool weight: 8 kg Tool change time, tool-to-tool: 2.5 seconds Travel (Axis Movement) X-axis: 650 mm Y-axis: 400 mm Z-axis: 500 mm Feed Drive Rapid traverse X, Y, Z-axis: 48 / 48 / 32 m/min Motor Torque X / Y / Z-axis: 11 Nm / 11 Nm / 20 Nm Feed Forces X / Y / Z-axis: 3.67 kN / 3.67 kN / 6.68 kN Spindle Speed Range Speeds*: 8,000 rpm Pneumatics Compressed air: 6 bar Air consumption per hour: 6–8 kg/m³ Milling Table Distance spindle to table: 100–600 mm Table length x width: 800 x 400 mm T-slot size / number / pitch: 18 mm / 3 / 100 mm Max. payload: 400 kg Dimensions Length x width x height: 2,100 x 2,300 x 2,750 mm Total weight: 4,300 kg Equipment Linear guides with ball screw drive for high rapid traverse speeds on all axes Telescopic guideway covers on all three axes Automatic lubrication system Portable electronic handwheel with enabling switch and emergency stop button RJ45 interface and 230 V power outlet Work area machine lamp Cleaning pistol Ball screws and linear guides from THK Chip flushing system Cooling at the spindle head (machining area) Control cabinet Arm-type tool changer SW24 CE *More options available

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in showroom condition. Optimill F 200 HSC Premium CNC milling machine direct from the manufacturer. F 200 HSC – The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control stands out for its performance, speed, precision, and long service life. Heavy-duty design · High productivity · High reliability · Heavily ribbed, torsion-free machine base · Linear guideway with roller circulation for high rapid traverse speeds on all axes · High-torque servo drives on all three axes · Telescopic guideway covers on all three axes · Automatic lubrication · Massive, precise milling table with five large, precision-ground T-slots · The portable electronic handwheel with enabling button and emergency stop rotary switch significantly simplifies program setup · Coolant system with chip flushing and cleaning gun · Through-spindle coolant supply with 20 bar pressure · Belt-type chip conveyor ensures efficient chip removal · Chip collection trolley · RJ45 interface and 230 V power connection · Enclosed electrical cabinet with integrated heat exchanger for optimal temperature control and prevention of dust ingress · Machine light in the work area · Additional SIEMENS material defect warranty package and free online/on-site OSS Plus service · 1-year Basic maintenance contract included in Germany/Austria/Switzerland Milling spindle: Inline spindle Machine specifications Electrical connection: 400 V / ~50 Hz Total connected load: 20 kVA Milling spindle Drive motor S1 operation: 10.5 kW Torque drive motor S1: 50 Nm Drive motor S6-30% operation: 26.4 kW Torque drive motor S6-30%: 125 Nm Spindle taper: SK 40 / DIN 69871 Coolant system Power of coolant pumps, 3 pcs: 1 kW Flow rate: 35 l/min Tank capacity: 200 liters Cleaning pump Cleaning pump power: 530 W Milling accuracy Repeat accuracy: ± 0.005 mm Positioning accuracy: ± 0.005 mm Tool changer Type: Double-arm gripper Number of tool stations: 24 Max. tool diameter: 78 mm Max. tool diameter (adjacent stations empty): 120 mm Tool length: 300 mm Max. tool weight: 8 kg Tool change time, tool to tool: 2.5 seconds Travel X-axis: 850 mm Y-axis: 500 mm Z-axis: 550 mm Feed drive Rapid traverse X-, Y-, Z-axis: 48 m/min Motor torque X-/ Y- / Z-axis: 16 Nm / 16 Nm / 20 Nm Feed forces X-/ Y- / Z-axis: 5.34 kN / 5.34 kN / 6.68 kN Speed range Spindle speed*: 12,000 rpm Pneumatics Air pressure: 6 – 8 bar Air consumption per hour: 6 – 8 kg/m³ Milling table Spindle – table distance: 100 – 650 mm Table size (L x W): 1,000 x 500 mm T-slot size / number / spacing: 18 mm / 5 / 100 mm Max. table load: 500 kg Dimensions Length x width x height: 2,400 x 2,355 x 2,860 mm Total weight: 5,500 kg Godpfx Ahew Ea Avj Hsil

Condition: as good as new (ex-display), Year of construction: 2025, The machine is on display and has only been used for demonstration purposes. Optimill F50 E CNC milling machine, direct from the manufacturer. F50 E – The OPTIMUM CNC milling machine with Siemens SINUMERIK 808D Advanced control system stands out for its performance, speed, precision, and long service life. • Column design made of cast iron for high rigidity • Carousel-type tool changer with eight tool stations • All linear guides with stainless steel covers • Automatic central lubrication • Siemens main spindle motor • Siemens servo drive on all axes (closed-loop system) • Maximum spindle speed of 10,000 rpm • The portable electronic handwheel with enabling button and emergency stop slam switch greatly facilitates program setup • Coolant system with 70-liter coolant tank • Tool change carried out automatically or at the push of a button (electropneumatic tool clamping system) • Heavy-duty, precision-milled table – generously sized and finely surface-machined • Large access doors to minimize cleaning and maintenance times • LED machine lamp for full illumination of the work area • Additional SIEMENS package: material defect warranty and free on-site service (OSS) SINUMERIK 808D • Software package identical to control version, ensuring process reliability • LED tool number display • MCP with rotary switch for feed and spindle override • Absolute encoders – no reference run required • Higher accuracy Control • 8.4” LCD color display with 800 x 600 resolution Additional SIEMENS OSS package • 12 months; Item No. 3589010 • 36 months; Item No. 3589012 Dimensions and weights Length approx. 2030 mm Width/depth approx. 1600 mm Height approx. 1980 mm Weight approx. 1900 kg Electrical data Connection voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 10 kVA Horizontal milling table Length 690 mm Width 225 mm Vertical spindle to table distance min. 90 mm Vertical spindle to table distance max. 410 mm T-slot size 14 mm Number of T-slots 3 T-slot pitch 63 mm Maximum load 150 kg Accuracy Giedpfx Aew Ea Swoh Hjl Repeatability ± 0.015 mm Positioning accuracy ± 0.015 mm Pneumatic connection Operating pressure 6 bar Travel X-axis automatic 330 mm Y-axis automatic 220 mm Z-axis automatic 320 mm Spindle to column distance min. 280 mm Spindle to column distance max. 280 mm Vertical spindle Spindle taper BT 30 Speed range 10,000 rpm Drive motor power S1 continuous operation 3.7 kW Drive motor power S6-30% duty cycle 5.5 kW Drive motor torque S1 continuous operation 24 Nm Drive motor torque S6-30% duty cycle 36 Nm Feed speed X-axis 15,000 mm/min Y-axis 15,000 mm/min Z-axis 15,000 mm/min Feed motor torque X-axis S1 continuous operation 3.5 Nm Y-axis S1 continuous operation 6 Nm Z-axis S1 continuous operation 6 Nm Tool changer Type: carousel Number of tool stations: 8 Max. tool diameter: 100 mm Max. tool length: 200 mm Max. tool weight: 6 kg Tool-to-tool change time: 7 s

Condition: as good as new (ex-display), Year of construction: 2025, The machine is currently on display. Optimill F200 ECO Premium CNC Milling Machine—direct from the manufacturer. F200 ECO – The OPTIMUM Premium CNC Milling Machine with Siemens SINUMERIK 828D Control stands out for its performance, speed, precision, and long service life. Model: F200 ECO Control: SIEMENS SINUMERIK 828D PPU271.5 Milling Spindle: Belt Drive Machine Specifications Electrical connection: 400 V / ~50 Hz Total connected load: 15 kVA Milling Spindle Drive motor S1 operation: 9 kW Drive motor torque S1 operation: 57 Nm Drive motor S6 30% operation: 17.1 kW Drive motor torque S6 30% operation: 118 Nm Spindle taper: BT40 Coolant System Coolant pump power: 900 W Max. delivery rate: 35 l/min Tank capacity: 116 liters Flushing pump Milling Precision Repeatability: 0.008 mm Positioning accuracy: 0.004 mm Tool Changer Type: Double-arm gripper Number of tool stations: 20 Max. tool diameter: 78 mm Max. tool diameter (adjacent stations empty): 120 mm Tool length: 300 mm Max. tool weight: 8 kg Tool change time, tool-to-tool: 2.5 seconds Travel X-axis: 850 mm Y-axis: 500 mm Gijdpfx Asxyh Dboh Hel Z-axis: 550 mm Feed Drive Rapid feed, X-/Y-/Z-axis: 48 / 48 / 48 m/min Motor Torque X / Y / Z-axis: 16 Nm / 16 Nm / 20 Nm Feed Forces X / Y / Z-axis: 5,34 kN / 5,34 kN / 6,68 kN Speed Range Spindle speed*: 10,000 rpm Pneumatics Compressed air: 6 bar Air consumption per hour: 6 – 8 kg/m³ Milling Table Spindle-to-table distance: 100 – 650 mm Table length × width: 1000 × 500 mm T-slot size / number / spacing: 18 mm / 5 / 100 mm Maximum load capacity: 500 kg Dimensions Length × width × height: 2,400 × 2,355 × 2,860 mm Total weight: 5,500 kg Equipment • Linear guides with ball screw for high rapid traverse speeds on all axes • Telescopic guideway covers on all three axes • Automatic lubrication • Portable electronic handwheel with enabling switch and emergency stop • RJ45 port and 230 V power outlet • Machine lamp in work area • Cleaning blow gun • Ball screws and linear guides from THK • Chip flushing system • Cooling at the spindle head (machining area) • Control cabinet • Arm-type tool changer • SW24 • CE compliant *More options available

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in the exhibition and was only used for demonstration purposes. Optimill F 3 Pro CNC milling machine (training machine) directly from the manufacturer. F 3 PRO - The OPTIMUM CNC milling machine with Siemens control SINUMERIK 808D Advanced is characterized by performance, speed, precision and long service life. All linear guides with stainless steel covers Automatic central lubrication Servo drive from SIEMENS in all axes (open control loop) Max. Spindle speed 4000 min-1 Machine light in the work area Portable, electronic handwheel with enabling switch and emergency stop switch. Makes running in programs considerably easier Tools can be changed at the touch of a button Access doors very generously designed to reduce cleaning and maintenance time to a minimum Software package "SINUMERIK 808D on PC" included. (Practical training software so that workpieces can be programmed and simulated offline on the PC. Software can be downloaded free of charge at). SINUMERIK 808 ADVANCED - CNC technology from the technology leader, paired with a revolutionary operating concept The SINUMERIK 808D ADVANCED control is a panel-based CNC control. The compact and user-friendly entry-level solution is used for simple milling applications. Features such as simple operation, commissioning and maintenance are the perfect basis for equipping CNC machines. Compact and robust Thanks to a panel-based CNC design with few interfaces and a control panel in protection class IP65, the SINUMERIK 808D ADVANCED is perfectly prepared for use in harsh environments. The small dimensions allow it to be used in compact machines INCLUDED RJ45 Ethernet port 8.4" LCD color display with 800 x 600 resolution Prepared for remote maintenance Dimensions and weights Length approx. 1410 mm Width/depth approx. 1372 mm Height approx. 2007 mm Weight approx. 1000 kg Drilling/milling capacity Cutter head size max. 50 mm End mill size max. 25 mm Electrical data Gedpfx Ajw Ea R Hsh Hsil Supply voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 5 kVA Horizontal milling table Length 620 mm Width 180 mm Distance vertical spindle - milling table min. 50 mm Distance vertical spindle - milling table max. 295 mm T-slots size 12 mm Number of T-slots 3 T-slot spacing 50 mm Load max. 30 kg Accuracy Repeat accuracy ± 0.02 mm Positioning accuracy ± 0.01 mm Coolant system Coolant pump(s) Drive power 95 W Tank capacity 30 l Travel distance X-axis automatic 355 mm Y-axis automatic 190 mm Z-axis automatic 245 mm Vertical spindle Spindle holder BT 30 Speed range 4000 min¯¹ Explanation Speed range Please note that the maximum spindle speed must be reduced by approx. 20 % in continuous operation Power drive motor continuous operation S1 1.5 kW Power drive motor S6-30 % operation 2.2 kW Torque drive motor continuous operation S1 9.5 Nm Torque drive motor 30% operation S6 14 Nm Feed rate Speed X-axis 10000 mm/min Y-axis 10000 mm/min Z-axis 10000 mm/min Feed motor torque X-axis continuous operation S1 1.9 Nm Y-axis continuous operation S1 3.5 Nm Z-axis continuous operation S1 3.5 Nm
