Used Hydraulic Part for sale (15,075)

Condition: new, sheet length: 2100upper roll diameter: 140sheet thickness: 4Bottom Roll Diameter: 140length: 4000heigth: 1040width: 1140weight approx.: 2240 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle Kjdpfxswhtdfo Adbsnd - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Options: Central Support:  – ¤5,479 Side Supports:  – ¤3,055 CNC: – ¤7,670 Material Feeding Table:  – ¤2,258 Variable Speed of Rotation:  – ¤3,109 Automatic material extractor PLC control CNC control Automatic material loading system Changeable top roll Adjustable bottom roll support system (customizable upon request) We have many references!

Condition: new, pressure: 100motor: 11daylight: 500stroke lenght (max.): 400Tappet adjustment: 790 x 600table height: Fußboden zu Tischplatte Oberkannte - 850messurements (LxWxH): 1.300 x 2.000 x 2.750weight approx.: 5.500oil filling: 200Demonstration machine, year of manufacture 2023 Type: Hydraulic C-Frame PressCapacity: 100 tons at 230 barControl / Key Switch Modes:Setup Mode – Manual operation without light sensor Automatic Mode – Full speed with integrated light sensor Hydraulic System:Main Cylinder: Ø 230 mm Auxiliary Cylinders: 2 pcs, Ø 50 x 30 mm Auxiliary Guides: 2 pcs, Ø 50 mm Motor: 11 kW / 15 HP Pump: 16 cc, 23 L/min – Helical gear pump Speed:Approach: 110 mm/sec Return: 200 mm/sec Pressure phase: 9 mm/sec Machine Dimensions:Daylight Opening: 500 mm Stroke Length: 400 mm Ram Plate: 790 x 600 mm (with T-slots) Table Plate: 790 x 600 mm (with T-slots) Table Height: 850 mm (from floor to top of table) Hydraulic Equipment:REXROTH hydraulic control block & components Pressure adjustable via PLC (20 – 100 tons) Speed adjustable via PLC Air oil cooler Pre-fill valve Pressure hold valve Control System:Siemens S7-1200 PLC Main control cabinet Safety PLC (SICK) Light curtains (SICK – 700 mm) Linear encoder for stroke adjustment 10” PLC touchscreen – BEIJER (German & English) Movable two-hand control unit Ethernet connection for remote support Visual and acoustic fault alarms Dual work area lighting In full compliance with EN 693 machine safety regulations Side safety doors (outward opening) Hydraulic proportional valves Dual-channel safety control Ksdpfxowrkctj Adbond User manual & parts list (German) Oil Volume: 220 L (Tank capacity: 250 L)Total Weight: approx. 5,500 kgOverall Dimensions: 1300 x 2000 x 2750 mmColor: RAL 7035 Light Grey & RAL 7016 Anthracite Grey Besichtigung unter Strom bei uns in Böheimkirchen 3071 (Neustiftgasse 34) möglich.

Condition: new, sheet thickness: 30bending length: 4100upper roll diameter: 510 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device Knodpfx Ajd Ab N Tjdbjd - In accordance for CE norms Options: - variable speed of rotation EURO 5.858,-- - metarial feeding table EURO 5.100,-- - oil coiler STD. - center support EURO 18.750,-- - side supports EURO 16.800,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, sheet thickness: 60bending length: 2100upper roll diameter: 510 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel Knedpfx Adsd Ab Rbebod - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Options: - variable speed of rotation EURO 5.858,-- - metarial feeding table EURO 5.100,-- - oil coiler STD. - center support EURO 18.750,-- - side supports EURO 10.400,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, sheet thickness: 25bending length: 2600upper roll diameter: 360 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Kjdpfx Aed Ab Rwodbond Options: - variable speed of rotation EURO 4.681,-- - metarial feeding table EURO 3.400,-- - oil coiler EURO 1.040,-- - center support EURO 13.600,-- - side supports EURO 9.200,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, sheet thickness: 45bending length: 3100upper roll diameter: 510 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting Knedpfed Ab N Usx Adbod - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Options: - variable speed of rotation EURO 7.000,-- - metarial feeding table EURO 3.700,-- - oil coiler EURO 800,-- - center support EURO 9.500,-- - side supports EURO 10.200,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, sheet thickness: 25bending length: 4100upper roll diameter: 460 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Options: - variable speed of rotation EURO 5.858,-- - metarial feeding table EURO 5.100,-- - oil coiler STD. - center support EURO 18.750,-- - side supports EURO 15.400,-- Knsdpsd Ab Rdefx Adbed - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, sheet thickness: 50bending length: 2100upper roll diameter: 460 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Ksdpfx Adjd Ab Risbjnd Options: - variable speed of rotation EURO 5.858,-- - metarial feeding table EURO 5.100,-- - oil coiler   STD. - center support EURO 18.750,-- - side supports EURO 9.700,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, sheet thickness: 30bending length: 2600upper roll diameter: 390 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Options: - variable speed of rotation EURO 4.681,-- - metarial feeding table EURO 3.400,-- - oil coiler EURO 1.040,-- - center support EURO 13.600,-- - side supports EURO 9.450,-- - Automatic material extractor Knedped Ab Rrjfx Adbjd - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, bending length: 3100sheet thickness: 16upper roll diameter: 330 Technical specifications: - Hardened and polished rolls - Conic bending device - Digital readout for side rolls - Complete body made of ST-52 Steel - Portable control panel separated form machine - Rolls are mounted with bearings - Top roll cover, openable and closeable by hydraulic, controlled from control panel. - All rolls are driven by hydraulic motor and planetary gearbox - Side rolls upwards downwards movements are hydraulic powered Knoded Ab S Iopfx Adbed Options: - variable rotation speed EURO 4.682.00 Material feed table on request Oil cooler EURO 1,040.00 Center support EURO 13.600,00 Side supports EURO 9.400.00 We have many references!

Condition: new, bending length: 3100sheet thickness: 10upper roll diameter: 270 Technical specifications: - Hardened and polished rolls - Conic bending device - Digital readout for side rolls Kedpjd Ab Tcofx Adbsnd - Complete body made of ST-52 Steel - Portable control panel separated form machine - Rolls are mounted with bearings - Top roll cover, openable and closeable by hydraulic, controlled from control panel. - All rolls are driven by hydraulic motor and planetary gearbox - Side rolls upwards downwards movements are hydraulic powered Options: - variable rotation speed EURO 4.682.00 Material feed table on request Oil cooler EURO 1,040.00 Center support EURO 8.250.00 Side supports EURO 7.070.00 We have many references!

Condition: new, sheet length: 3100sheet thickness: 10,0prebending: 8,0total power requirements: 11,0weight approx.: 9.7messurements (LxWxH): 4,88x1,16x1,18 Illustration Similar Bending Capacity: 10.0 mm » at 3x upper roll diameter Initial Bending: 8.0 mm » at 1.5x upper roll diameter Upper Roll Diameter: 270 mm Knodpfx Adod Ab H Eebod Lower Roll Diameter: 250 mm Side Roll Diameter: 220 mm Max. Opening: 50 mm Working Height: 825 mm • Fully hydraulic drive of upper and lower rolls via planetary gears • Digital display for side roll positions • Hydraulic folding support • Conical bending device • Hardened rolls • Hydraulic side roll adjustment synchronized via PLC • Hydraulic lower roll adjustment via torsion shaft • Pressure-adjustable lower roll • Electrical and hydraulic overload protection • Movable control panel • Operating manual in GERMAN and ENGLISH • Machine and equipment in accordance with CE regulations Important Points for Conical Rolling: • The maximum sheet thickness is 50% of the nominal capacity. • The cone length must be a maximum of 30% or more than 60% of the roll length. • Hardened rolls are recommended.

Condition: new, sheet length: 3120sheet thickness: 10,0total power requirements: 22weight approx.: 12250messurements (LxWxH): 3850x3060x1850 Knodpfxsd Eqrle Adbod

Condition: new, sheet length: 4120sheet thickness: 13,0total power requirements: 30weight approx.: 16750messurements (LxWxH): 4930x3160x2100 Ksdpfxsd Eqrdo Adbond

Condition: new, sheet thickness: 45bending length: 2600upper roll diameter: 460 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Kjdpfx Asd Ab Rhsdbond Options: - variable speed of rotation EURO 5.858,-- - metarial feeding table EURO 5.100,-- - oil coiler STD. - center support EURO 18.750,-- - side supports EURO 12.500,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, sheet thickness: 33sheet length: 3100upper roll diameter: 430 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Options: - variable speed of rotation EURO 5.858,-- - metarial feeding table EURO 3.400,-- - oil coiler    STD. - center support EURO 13.600,-- Knedpfod Ab Rlsx Adbsd - side supports EURO 12.000,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, sheet thickness: 16bending length: 4100upper roll diameter: 390 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Options: - variable speed of rotation EURO 4.681,-- - metarial feeding table EURO 3.400,-- - oil coiler EURO 1.040,-- - center support EURO 13.600,-- - side supports EURO 12.516,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) Knodped Ab Rpofx Adbsd We have many references!

Condition: new, sheet thickness: 30bending length: 2100upper roll diameter: 360 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Options: - variable speed of rotation EURO 4.681,-- - metarial feeding table EURO 3.400,-- - oil coiler EURO 1.040,-- - center support EURO 13.600,-- - side supports EURO 9.060,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references! Kedpfx Asd Ab Rxedbond

Condition: new, sheet thickness: 13bending length: 3100upper roll diameter: 300 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Kodpfx Aded Ab R Hjbsnd Options: - variable speed of rotation EURO 4.681,-- - metarial feeding table EURO 3.400,-- - oil coiler EURO 1.040,-- - center support EURO 13.600,-- - side supports EURO 9.400,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references!

Condition: new, sheet thickness: 16bending length: 2100upper roll diameter: 270 Technical specifications: - Hardened and polished rolls - Complete body made of ST-52 Steel - Machine have 4 rolls and designed for symmetrical working principle - Hydraulic powered cover for easy material extracting - Digital readout for side rolls (2 digital readout) - Side rolls are free for rotation and upwards downwards movements are hydraulic powered - Top and bottom rolls are driven by hydraulic and gearbox. Bottom roll’s vertical movements are hydraulic powered - Separate control panel form machine - Conic bending device - In accordance for CE norms Options: - variable speed of rotation EURO 4.681,-- - metarial feeding table EURO 3.400,-- - oil coiler EURO 1.040,-- - center support EURO 8.250-- - side supports EURO 5.700,-- - Automatic material extractor - PLC control - CNC control - Automatic material loading system - Changeable top roll - Adjustable bottom roll support system (for customer’s special requests) We have many references! Kedpsd Ab R Ujfx Adbsnd

Condition: new, pressure: 60stroke: 250total power requirements: 7,5weight approx.: 4000messurements (LxWxH): 1.820 x 960 x 2.400table diamension: 750 x 500tappet area: 500 x 430drilling on table: 100daylight: 450working speed: 8,5retracting speed: 47rapid traverse: 26 Knjdpfjd Ab Ixjx Adbod

Condition: new, bending length: 3100sheet thickness: 25upper roll diameter: 390 Technical specifications: - Hardened and polished rolls - Conic bending device - Digital readout for side rolls - Complete body made of ST-52 Steel - Portable control panel separated form machine - Rolls are mounted with bearings Kjdpfxsd Ab Swe Adbjnd - Top roll cover, openable and closeable by hydraulic, controlled from control panel. - All rolls are driven by hydraulic motor and planetary gearbox - Side rolls upwards downwards movements are hydraulic powered Options: - variable rotation speed EURO 4.682.00 Material feed table on request Oil cooler EURO 1,040.00 Center support EURO 13.600,00 Side supports EURO 10.540,00 We have many references!

Condition: new, bending length: 2100sheet thickness: 40upper roll diameter: 390 Ksdpod Ab Syjfx Adbjnd Technical specifications: - Hardened and polished rolls - Conic bending device - Digital readout for side rolls - Complete body made of ST-52 Steel - Portable control panel separated form machine - Rolls are mounted with bearings - Top roll cover, openable and closeable by hydraulic, controlled from control panel. - All rolls are driven by hydraulic motor and planetary gearbox - Side rolls upwards downwards movements are hydraulic powered Options: - variable rotation speed EURO 4.682.00 Material feed table on request Oil cooler EURO 1,040.00 Center support EURO 13.600,00 Side supports EURO 9.250.00 We have many references!

Condition: new, bending length: 4100sheet thickness: 6upper roll diameter: 270 Technical specifications: - Hardened and polished rolls - Conic bending device Kjdpfxod Ab Tbj Adbond - Digital readout for side rolls - Complete body made of ST-52 Steel - Portable control panel separated form machine - Rolls are mounted with bearings - Top roll cover, openable and closeable by hydraulic, controlled from control panel. - All rolls are driven by hydraulic motor and planetary gearbox - Side rolls upwards downwards movements are hydraulic powered Options: - variable rotation speed EURO 4.682.00 Material feed table on request Oil cooler EURO 1,040.00 Center support EURO 8.250.00 Side supports EURO 9.660.00 We have many references!

Condition: new, sheet length: 4065sheet thickness: 10,0total power requirements: 22weight approx.: 14900messurements (LxWxH): 4860x3170x2430 Knsdpfx Adohp Dkbobjd
