Used Shaft Grinding Machine for sale (86,406)

Condition: excellent (used), Center height 127 mm Distance between centers 1000 mm Grinding wheel 350 x 50 x 127 mm + 300 x 25 x 127 mm Grinding wheel speeds 1'775-2'400 rpm Grinding head rotating 190 / 45 ° With internal grinding attachement Misc. accessories MARCELS MASCHINEN AG Godpfex R R Ndsx Ah Hobg

Condition: good (used), Year of construction: 1992, Tool cutter grinder Max. Radius 45 Gr Side X Travel 40 mm Length Y Travel 10 mm Head spindle Z Travel 15 mm Indexing raster 12 x Machine incl. collet device 0,5 to 17,5 mm Milling cutting attachment for Mk1, Mk2, Mk3 incl. HERKT Traunreut Projector for secure grinding incl. HSS Grinding attachment from 3 to 18 mm Gedsw S T R Espfx Ah Hsbg Grinding wheel Ø:100 x 50 x 20 mm Grinding speeds: 4500Rpm Length: 660mm Width: 570mm Height: 900mm Weight: 190kg

Condition: excellent (used), Control : Siemens Sinumerik 840D SL Accessories available: - various grinding wheel holders - Lifting pump for cooling lubricant - Various spare parts for machine, machine documents - Magnetic table 2000 x 250 mm incl. clamping hydraulics Godpfx Ahoulgh Aj Hjbg - Machine hours: 24,000 h (since 2014) - Table dresser: Dittel brand - Sanding head: manually swiveling Machine length 6.6 m Width 2.8 m Height 2.5 m Weight 14'000 kg Drives Siemens

Condition: good (used), Year of construction: 2008, functionality: fully functional, Technical details grinding length 2000 mm grinding width 850 mm distance spindle center to table 900 mm control Siemens 840 D total power requirement 155 kVA weight of the machine ca. 15 t dimensions of the machine ca. 8815 x 4185 x 2963 mm Additional information CNC Precision Surface and Profile Grinding Machine Technical Specifications: Grinding length 2000 mm Grinding width 850 mm Travel, transverse 750 mm Distance from table to spindle center 900 mm (or 800 mm with intermediate plate) Magnetic plate size 2000 x 700 mm Table load without magnet 3500 kg Table speed 60 m/min. Spindle drive 26 kW Grinding wheel dimensions 500 x 150 x 203.2 mm Grinding wheel peripheral speed 35 m/s Equipment: Godpox Sqf Usfx Ah Hebg 3-axis contouring control Siemens 840 D Grinding programs: Full-cut grinding Face grinding Plunge grinding Path grinding X/Y-axis and Y-Z-axis Profile grinding Automatic program sequence with roughing, finishing, fine finishing and spark-out grinding. Multiple plunge grinding for economical production Surface grinding with continuous, continuously programmable cross feed Grinding wheel calibration Plunge/step grinding Face grinding Dressing in the grinding cycle with lift-off amount Fully automatic compensation of dressing amounts Tool management AC servo drives with ball screw and absolute measuring system in the X, Y, and Z axes Preloaded precision roller guides in the X, Y, and Z axes with linear guides Portable electronic handwheel Automatic belt filter system Coolant heating Electro-permanent magnetic chuck Fully enclosed Direct measuring system in the vertical axis Temperature-controlled machine bed for consistent accuracy Linear motor in the X-axis, table speed max. 60 m/min. Swiveling control panel Continuous speed control of the grinding spindle Electrical linear measuring device for cross-travel adjustment with zero point setting in any position, resolution 0.001 mm Electro-mechanical locking via position control of the headstock in the cross direction for profile and plunge grinding Mechanical extraction of coolant mist TAG table dresser Pre-profiling dresser VPG 190 Diamond grinding wheel, 190 mm diameter Software program for pre-profiling dresser VPG Rough profiling (roughing) CNC table profile dresser TAD 190 Profile depth max. 45 mm Contour accuracy +/- 0.0025 mm Swivel angle +/- 65 degrees Max. dressing speed 210 mm/min. Diamond wheel for table dressing machine TAD 190 Regrinding package for diamond wheel Intermediate plate for raising the magnet WinWop profiling software Import of CAD profile data SP 60 JOB Listing expansion package Additional holes for the magnet clamping plate to facilitate removal of workpieces using compressed air Ghost shift circuit for shutting down the machine after the end of the program

Condition: used, Year of construction: 2020, grinding diameter 390 mm grinding length 650 mm centre height 200 mm workpiece weight max. 250 kg x-axis 380 mm z-axis 1150 mm sanding disc diameter 400 mm peripheral speed 20-50 m/sec workpiece spindle stepless 1 - 650 U/min tailstock quill taper MT 4 quill stroke 45 mm dia. of quill 50 mm total power requirement 22 kW Gedjx Rn Uqjpfx Ah Hobg

Condition: used, Year of construction: 1991, working area 225 mm table-size L:550 mm table-size B:200 mm sanding disc diameter 200mm mm magnetic plate size 500 mm weight of the machine ca. 1,8 t dimensions of the machine ca. 2000x1600x2100 m Gjdpfxoud Algj Ah Hobg

Condition: used, Year of construction: 1970, Technical details: grinding length: 1000 mm grinding width: 400 mm workpiece height: 500 mm Table dimensions: 2230 x 670 mm table surface area: 1340 x 400 mm magnetic plate size: 1000 x 410 mm table load: 450 kg throat of the spindle nose: max 330 mm grinding spindle speed: 1440 U/min total power requirement: 18,2 kW weight of the machine ca.: 3,5 nur Maschine t dimension machine xH: 1,9 x 3,3 x 2,25 m dimensions electric cabinet LxWxH: 1,0 x 0,4 x 1,4 m Precision surface grinding machine Possible surface grinding operations: -cross grinding; plunge grinding; face grinding and grinding with a straight grinding track Further specifications: -hydraulic table speed, infinitely variable 1...30 or 2...30 m/min. -Largest table stroke 1150 mm Godpfsx Afpasx Ah Hjbg -Manual cross feed 0.01 mm -Manual vertical infeed of the grinding wheel 0.002mm and minimum infeed 0.001mm -Automatic infeed 0.001...0.1mm -Largest selectable total infeed amount 5.0mm -Coolant system (tank with pump) -hydr. aggregate -control cabinet *

Condition: good (used), Year of construction: 2001, grinding length: 650 mm, grinding width: 525 mm, total height: 350 mm, table length: 600 mm, table width: 350 mm, Manufacturer: Geibel & Hotz Type: FS 635-Z SA Control: Digital read out Year of construction: 2001 Magnetic table 600 x 350 mm Closed housing for CE Automatic vertical lubrication SA Automatic lubrication Coolant tank Specifications Metric US Standard X - axis 650 mm Y - axis 525 mm Z - axis 350 mm Table length 600 mm Table width 350 mm Table load 400 Feed X - axis 35000 mm/min. Feed Z-axis 1000 mm/min. Grinding stone dimensions 300 x 50 x 76.2 mm Power output 3.7 kW Speed 2800 ? rpm Gbodpfevdal Ajx Ah Hog Dimensions (estimate) length 3200 mm width 2000 mm height 2870 mm weight 2300 kg Please note: The information on this page has been obtained from the manufacturer to the best of our knowledge and belief, and where possible, the information is given in good faith but accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend that you check all relevant details.

Condition: excellent (used), Control : Siemens Sinumerik 840D SL Accessories available: - various grinding wheel holders - Lifting pump for cooling lubricant - Various spare parts for machine, machine documents - Magnetic table 2000 x 250 mm incl. clamping hydraulics - Machine hours: 8,000 h (since 2018) - Table dresser: Dittel brand Gedpfx Ahjulghcs Hjbg - Grinding head: manually swiveling Machine length 6.6 m Width 2.8 m Height 2.5 m Weight 14'000 kg Drives Siemens

Condition: good (used), Year of construction: 1995, functionality: fully functional, Technical details internal diameter 800 mm grinding depth 500 mm swing diameter 850 mm weight of the machine ca. 6,4 t Additional information Used internal cylindrical grinding machine with face grinding device in special design with enlarged swing diameter and extended, hydraulic transverse movement Reconstructed and modernized 1995 in the Glauchau manufacturer’s plant, put into operation 1996 1. TECHNICAL DATA 1.1 Working area Grinding diameter in the workpiece guard internal grinding, min./max. mm 30/630(800) External grinding, max. mm 800 Grinding depth, up to approx. mm 500 Table stroke mm 800 Workpiece diameter, max. mm 800 Swing diameter in workpiece protection, max. mm 800 Without workpiece protection, approx. mm 850 Distance from workpiece spindle head to grinding spindle carrier, max. mm 1225 Adjustment of the internal grinding device on the table, max. mm 545 1.2 Workpiece headstock Cross shift, max. mm 650 Cross adjustment via gear motor and positioning device with HEIDENHAIN digital position display Swivel, max. degrees 15 Workpiece spindle Speeds rpm 16/22/32/ 45/63/90/ Gbedox Sp Tkspfx Ah Hsg 125/18/250 Load capacity, max 1000 Spindle head (with bayonet flange) DIN 55021 size 11 Machine accessories: 2-axis digital displays made by HEIDENHAIN Coolant system with magnetic separator Fixators (machine shoes) Various grinding wheels Diamond dresser Large face plate Internal and face grinding device Halogen machine lamp Machine documentation

Condition: not inspected (used), Year of construction: 1987, functionality: unexamined, machine/vehicle number: 2023, travel distance X-axis: 900 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 180 mm, spindle speed (max.): 1,60,000 rpm, table load: 800 kg, No minimum price – guaranteed sale to the highest bidder! The machine is being auctioned due to a business closure. Bidding obligates the successful bidder to collect the machine within the specified timeframe from 26.01.2026 to 29.01.2026! TECHNICAL DETAILS Travel X-axis travel: 900 mm Y-axis travel: 600 mm W-axis travel: 635 mm Z-axis travel: 180 mm U-axis travel: 6/20 mm Distance between columns: 950 mm Clearance table to spindle: 735 mm Main spindle diameter: 100 mm Tool holder: E 23 E 19 EF 6 Work Table Table dimensions: 1,020 x 860 mm T-slot width: 14 mm T-slot spacing: 100 mm Table load capacity: max. 800 kg Taper grinding: max. 16° Digital readout X/Y: 0.001 mm Godpfjx Rw E Sox Ah Hebg Basic deviation X/Y at 20°: 0.004 mm Spindle speed: from 4,500 to 160,000 rpm Planetary movement (Z-axis): 5 to 250 C-axis NC drive: 0 – 5 Feed X and Y-axis feed: 0 to 1,500/3,000 mm/min W-axis feed: 800 mm/min Z-axis feed: 0.5 – 12,000 mm/min MACHINE DETAILS Control: CNC 311 Electrical Data Operating voltage: 3 x 380 V Frequency: 50 Hz Control voltage: 110 V Connection rating: 8.5 kW Dimensions & Weight Dimensions (L x W x H): 5,000 x 2,000 x 3,300 mm Weight: 7,000 kg EQUIPMENT Matching workshop cabinet with contents Various grinding tools Clamping devices High-frequency grinding head BÜCHE ENF 4000 extraction unit

Condition: used, Year of construction: 1996, grinding length 1.000 mm grinding width 550 mm workpiece height 400 mm table surface area 1.580 x 550 mm table load capacity 950 kg magnetic clamping plate 1.000 x 550 mm x-Travel 1.200 mm table feed 1 - 30 m/min vertical feeds: 1 - 300 mm/min z-axis 470 mm cross feed 1 - 2.000 mm/min dimensions of grinding wheel 400 x 100 x 127 mm grinding wheel speeds 1.500 - 3.500 U/min grinding spindle drive 11,00 kW total power requirement 23,00 kW weight of the machine ca. 7,50 t dimensions of the machine ca. 4,50 x 3,20 x H2,90 m Gbjdpfxsxx A Dmo Ah Hog Coolant system with coolant pump integrated in the hydraulic tank, exhauster.

Condition: good (used), Magnetic plate, magnetic table, sine table, sine plate, relief grinding device, grinding machine accessories Gbjdpjb A Iqdjfx Ah Hsg -Design: Cutting tool mold making for conically ground cutting plates or mold inserts -Angle head for surface grinding machine or measuring machine -Magnetic plate -Angle: adjustable -Wooden box -Total weight with box: 35 kg

Condition: good (used), Year of construction: 2001, functionality: fully functional, Technical details grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Gjdex Sp Nxopfx Ah Hobg Control SIEMENS 840 D magnetic clamping plate 4200 x 1300 mm segment head diameter 1400 mm grinding motor turning speeds up to 320 U/min. grinding motor 306 kW weight of the machine ca. 50,0 t Additional information Segment dimensions: 120/106 x 41 x 250 mm Number of segments: 1 set = 26 pieces Grinding motor feed: 0.5 - 35 m/min, infinitely variable Grinding motor feed: - in steps: 0.002 - 1 mm continuous: up to 5 mm/min. infinitely variable Equipment: * CNC-control SIEMENS Sinumerik 840 D * Automatic hydr. swivelling of the grinding motor from hollow to cross grinding * NC-controlled adjustment of the Marposs measuring head by means of precision support. - new grinding dimensions can be entered into the control, whereby the the grinding head automatically adjusts to the corresponding height. * Dresser with adjustment axis in the machine bed * Coolant system * Electro-magnetic table * Switch cabinet * Oil mist extraction * Documentation Dimensions (length x width x height) Bed: 11800x2200x1400 mm, weight 27500 kg Grinding head: 3000 x 2500 x 3100 mm, estimated weight 14 t 2 x Oil mist extraction: 1200 x 800 x 2000 mm each Control panel: 1200 x 800 x 400 mm Small control cabinet: 1400 x 1400 x 800 mm 2 x gears each 1200 x 800 x 500 mm Control cabinet: 1600 x 800 x 2000 mm Control cabinet: 3400 x 600 x 2400 mm

Condition: good (used), Tool grinding machine, grinding machine, angle grinding machine, turning steel grinding machine, steel grinding machine -3x grinding wheels: Ø 340 mm, speed 1500 rpm -1x grinding wheels: Ø 170 mm, speed 3000 rpm -max. steel cross section: 80 x 80 mm -Dimensions: 1300/900/H1450 mm Gsdpfx Ajfmm A Eeh Hobg -Weight: 500 kg

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder -Manufacturer: VEB, Double grinding wheel type SE 2x315/1 -Grinding wheel: max. Ø 315 mm -Peripheral speed: 45 m/s -Motor power: 1.0 kW Gbodpfx Ahegqvlme Heg -Operating voltage: 380 volts -Accessories: incl. grinding wheel dresser, see photos -Dimensions: 640/890/H1070 mm -Weight: 248 kg

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder -Manufacturer: Greif, double grinding wheel type D 20/4 Gbedpfx Aov Hawqjh Hjg -Grinding discs: max. Ø 250 mm -Motor power: 0.37 kW -Speed: 1400 rpm -Operating voltage: 220/380 volts -Dimensions: 500/310/H315 mm -Weight: 40 kg

Condition: good (used), Tool grinding machine, grinding machine, angle grinding machine, rotary steel grinding machine, steel grinding machine -Grinding places: 4 -Angle tables on swing tables: 3 -Angle table for chip breaker groove: 1 -Quantity: 1 piece available -Dimensions: 1210/1210/H1450 mm Gbsdpfjdv T Tbsx Ah Hsg -Weight: 536 kg

Condition: good (used), Dividing head, spiral milling device, dividing head, tool holder for grinding, drill grinding machine, milling cutter grinding machine, drill grinding holder Godpfx Aexfhchsh Hobg -Manufacturer: Stankoimport, dividing head/tool holder for tool grinding machine -Type: 36642.M1 -Parting head: rotatable/tiltable -Mounting/Dimensions: MK5 see photos -Dimensions: 300/270/H180 mm -Weight: 21.6 kg

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder Gjdpfx Aheb A H Dmj Hsbg -Motor power: 0.2 kW -Speed: 3000 rpm -Grinding discs: Ø 150x20x32 mm -Operating voltage: 220 volts

Condition: good (used), Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinding machine, center grinding machine -Max. shaft diameter: 320 mm -Max. grinding length: 345 mm -Chuck size: Ø 133 mm -Dimensions: 1925/1135/H1755 mm -Weight: 1592 kg Gbjdpsduiw Aefx Ah Hog -functionally tested

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder Godpfxjb A I R De Ah Hebg -Grinding discs: max. Ø 360 mm x 40 mm -Operating voltage: 380 volts -Dimensions: 760/450/H1080 mm -Weight: 200 kg

Condition: good (used), Year of construction: 1982, Grinding machine, angle grinder, rotary steel grinder, thread drill grinder, milling cutter grinder, surface grinder, drill grinder, bench grinder, double bench grinder Gsdpfx Ahjnymgdj Hjbg -Manufacturer: Gebr. Bayer, tool grinding machine with 2 stations -Motor power: 0.75 kW -Speed: 2800 rpm -Grinding discs: Ø max. 225/160 mm -Coolant device: -Dimensions: 1210/710/H1340 mm -Weight: 195 kg

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder -Motor power: 0.75 kW -Speed: 3000 rpm -Max. grinding wheels: Ø 200 x 32 mm Gsdpfedvlvljx Ah Hebg -Operating voltage: 380 volts -Dimensions: 540/280/H1230 mm -Weight: 116 kg

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, bench grinder, drill grinding machine -Grinding disc: max. Ø 200 x 30 mm Gbodpfx Ahjb A H Eyo Heg -Speed: 2800 rpm -Motor power: 0.74 kW -Operating voltage: 380 volts
