Used Vibratory Finishing Machine for sale (65,112)

Condition: new, Year of construction: 2025, * 250 lt Net Volume * Dosing pump included. * Highly wear resistant P.U.Lining (90 Shore) * High performance three phase current drive motor. Iodsh I N Udjpfx Adwstb * Changeable valf for the wastewater decharging * Main swicth and emergency stop switch. * Timer and working hours timer * Special construction of control panel(EU Standarts) included

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: ZCVS125, total width: 870 mm, total height: 950 mm, overall weight: 185 kg, input voltage: 380 V, warranty duration: 24 months, nominal power: 1.13 kW (1.54 HP), power: 1.13 kW (1.54 HP), workpiece width (max.): 150 mm, workpiece length (max.): 150 mm, ZCVS 125 CIRCULAR TYPE OF VIBRATORY MACHINE * Net 125 liter volume * Highly wear resistant P.U.Lining (90 Shore) * Dosing pump included. * Changeable valf for the wastewater decharging *According to requested diameter size for seperator MOTOR: * High performance three phase current drive motor. * 1,1 kW 1500 rpm (Italian OLI) * The motor is lubrication free. You don’t need motor lubrication. CONTROL PANEL: * Main switch and emergency stop switch. * Timer and working hours timer * Control box with switch for engine right/left running * CE safety standard PAINTING: *Colour in RAL 5011 & RAL 7036 *Epoxy paint is used to ensure long life of the paint Iedpoh Agr Hsfx Adwotb

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, Used (only test-run) vibratory finishing machine from PERS (image similar) Gentle deburring of small parts, laser-cut and stamped parts, formed, turned, and milled components. Suitable for all materials! Fully manually operated stand-alone unit. Low investment required! Technical Data: Year of manufacture: 12/2020 The machine is powered and can be inspected by appointment! Capacity: 120 l Iedpfehr Rkiox Adwotb Bowl diameter: 640 mm Dimensions (LxWxH): 1,740 x 900 x 1,470 mm Power: 4 kW Voltage: 400 V AC / 3 phase Frequency: 50 Hz Weight: approx. 500 kg Speed: 50–160 RPM PU coating: 26 mm

Condition: excellent (used), Robust industrial machine made in Germany: Walther Trowal, model DLT 4, year 1980. The device is intended for surface finishing of metal, aluminum, or plastic parts – trowalizing process (deburring, edge rounding, polishing, cleaning). Classic drum-type construction – reliable, heavy-duty, and durable, typical for “West Germany” manufacture. Technical data: • Model: DLT 4 • Manufacturer: Carl Kurt Walther GmbH & Co. KG, Wuppertal-Vohwinkel (West Germany) • Year of manufacture: 1980 • Drive type: ZOD71N 10 • Motor power: 0.38 kW • Power supply: 380 V / 50 Hz • Drum speed: 31 / 61 rpm • Range: 3.5 – 7 rpm • Drum diameter: Ø 70 cm • Working length: approx. 80 cm • Net weight: 825 kg Condition description: • Complete machine, drum rotates smoothly and evenly. • Perforation and internal lining in good condition. • No visible cracks or structural damage. • Requires electrical connection and possibly a basic inspection. • Ideal for tool shops, machining plants, or production lines. Application: • Deburring and cleaning parts after machining. • Polishing metal or aluminum components. • Finishing screws, bushings, stamped parts, castings, and precision components. Condition: used, robust, classic Walther Trowal construction – ready for light refurbishment or immediate operation. Itsdsxmlinjpfx Adwjb

Condition: used, Vibratory finishing machines Pre-filter system, filter system, pre-filter container, water filter for cylindrical vibrator, vibratory finishing machine, vibratory finishing system, vibratory finishing cylindrical vibrator, Trowal system, continuous vibrator -Pre-filter system: for vibratory finishing machines or others -Transport frame: mobile, with 2 filter inserts Ijdeigamujpfx Adwjtb -Collection tank: volume approx. 350 litres -Total dimensions: 1400/620/H920 mm -Weight: 106 kg

Condition: excellent (used), Year of construction: 1988, For sale: Industrial vibratory finishing machine from the renowned brand SPALECK (Max Spaleck GmbH & Co. KG, Bocholt, West Germany) – model VAT-240. Robust unit manufactured in 1988, designed for professional finishing of components. Ideal applications include: • Surface polishing • Deburring after machining • Edge rounding • Cleaning and surface preparation prior to painting or electroplating Works with different types of media – ceramic, plastic, or steel – depending on the workpieces to be processed. Technical data: Itedpfx Adew Ixw Asweb • Model: VAT-240 • Year of manufacture: 1988 • Maximum batch load: 500 kg • Power supply: 3-phase, 380 V, 50 Hz • Control voltage: 220 V • Rated current: 20 A • Protection: 25 A • Total power: 18.1 kW • Serial number: 63712 • Included: control cabinet with START/STOP buttons, emergency stop switch, and ammeter The machine is complete, in good technical condition, and ready for operation upon connection. Heavy-duty construction, discharge chute with rubber cover, and convenient media change system. SPALECK is a German brand known for manufacturing reliable vibratory finishing machines, highly regarded by industrial plants worldwide.

Condition: excellent (used), Year of construction: 2013, operating hours: 15,159 h, machine/vehicle number: 61600, A trough vibrator (vibratory finishing machine) including centrifuge from the manufacturer Rösler is for sale. The machine is in very good condition and can be inspected on site by telephone appointment. Isdoqrr A Rjpfx Adwotb

Condition: ready for operation (used), Vibratory finishing system, Slide Grinding Machine,Circular trough vibratory finishing machine, Used Machine Manufacturer: Gránit-Ex Kft Type: FM-10, 1500 x 1500 Iodpfjxdfabex Adwjtb Year: 2020 Weight: 600 kg d: 550 mm, Circumference: 1670 mm D: 1350 mm, Circumference: 3650 mm Torus: 350 mm

Condition: used, Year of construction: 2017, operating hours: 26,780 h, functionality: fully functional, machine/vehicle number: 80065, High-performance vibratory finishing system by Rösler – Complete solution for efficient surface processing For sale is a fully equipped Rösler continuous flow system R 550/6600 DA including extensive peripheral equipment – ideal for industrial series processing of aluminum die-cast and metal parts. System highlights: - Continuous flow system R 550/6600 DA - Processing bowl: 6,600 mm length, 550 mm width, 1,450 liter capacity - Vibratory principle with multi-mass imbalance system for uniform processing - PLC control (Siemens S7-1500) with plain text display and network interface - Integrated central lubrication and process water collection system Complete peripherals for maximum efficiency: - Conveyor belts (R 600/4500 FB/T and R 360/3000 FB/T) - Belt dryer R 2000.1 BT with heating capacity up to 50 kW and blow-off station - Centrifugal separator system Z 1000 ASS-II Turbo for process water recirculation - Lifting station, buffer and circulation tanks, wastewater tank - Control cabinet with PLC control and frequency inverters - Media storage hopper, dosing units, and sludge cart Technical advantages: - High throughput for serial production (up to 400,000 workpieces/year) Iedpex I Numsfx Adwstb - Water-saving recirculation system with automatic sludge discharge - Robust and durable design – vibration and noise dampening - Simple operation thanks to user-friendly controls and automated processes Ideal for: Automotive suppliers, metal processing, die-casting companies and anyone seeking a reliable solution for deburring, edge rounding and surface finishing. Condition: Very well maintained, ready for operation Scope of delivery: Complete system incl. documentation and accessories

Condition: used, Manufacturer: Carl Kurt Drum diameter: 700 mm Motor: 1 kW Itsdeu Abr Ejpfx Adwsb

Condition: good (used), WALTHER TROWAL - Type CA 340 - Speed range: 800 - 1500 rpm Itedpfsxtbidox Adweb - Drive power: 7.5 kW - Separation unit - Acoustic enclosure cover - Controls / Start / Stop / Timer / Separation Dimensions: LxWxH: 1.8 x 1.6 x 1.8 meters / Weight: 1300 kg Errors and input mistakes excepted

Condition: used, Round-tub vibratory finishing machine WALTHER TROWAL Type CLS-230 Order No. 05.833/00 Year of construction 1969 Tub diameter 1100 mm Total tub height approx. 650 mm Working container / Gross volume max. 230 liters Usable volume approx. 115 liters Speed 1100 to 1800 rpm, stepless Motor power 7.5 kW Power connection 400 Volt, 50 Hz - Operating cycle manual and via timer - Stepless motor speed adjustment via variator gearbox Iodsfqpxiopfx Adwjtb - Manually adjustable eccentric imbalance weights - Container with polyurethane lining – lining partially damaged or worn - Sound-insulated lid - Manual separation flap - Built-in screening device after the separation flap - Liquid connection - Material discharge opening 180 x 150 mm - Control cabinet for wall mounting - Baffle lid with perforated screen Space requirement with base L x W x H 1800 x 1750 x 1700 mm Net weight approx. 1800 kg In good condition Function description: Workpieces and abrasive media are set in motion by the generated vibration and are recirculated extremely gently. The constant relative movement between workpieces and abrasive media results in deburring and surface finishing of the workpieces.

Condition: used, Rotary vibratory finishing machine WALTHER TROWAL type CLS-980 SA Com. No. 15.207 Year of construction 1972 Trough diameter 1850 mm Total outer height of trough approx. 1150 mm Working hopper / gross volume max. 980 liters Useful volume approx. 490 liters Largest possible workpiece diameter approx. 300 mm (measured diagonally) Screen area 3400 cm2 Infinitely variable speed 1000 to 1700 rpm Motor power 22 kW Mains connection 400 Volt, 50 Hz - Switch-on time manually and via timer - Infinitely variable motor speed via DANFOSS drive controller type VLT 3032 (frequency converter) - Manually adjustable eccentric unbalance weights - Container with rubber lining - sound-insulated lid with pneumatic lid opening - Manual separating flap - built-in sieve separator after the separating flap - liquid inlet - Material outlet opening 470 x 300 mm - Control cabinet and drive controller for wall mounting - Bulkhead cover with perforated sieve - 1 box of pyramid grinding media Space requirement L x W x H 3000 x 3000 x 2550 mm Transport dimensions L x W x H 2300 x 3000 x 2550 mm dead weight 2500 kg good condition Itodpfx Asdzqn Dodwjb Functional description: Workpieces and grinding wheels are set in motion by the vibrations generated and circulated extremely gently. The constant relative movement between the workpieces and the grinding wheel causes deburring and surface finishing of the workpieces.

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 12551/94-12, Automated system for finishing operations with a centrifugal disc. Ijdpev U Em Tsfx Adwjtb

Condition: good (used), Year of construction: 2001, machine/vehicle number: 10248275, Offer 24438 Vibratory finishing machine with circular vibrator - vibration dryer + centrifuge Technical data: - Mass finishing machine - Circular vibrator WALTHER CD 200 Tank capacity approx. 200 L Useful volume 92 L Max. Workpiece size measured diagonally 180 mm Screen area 2,097 cm² Drive 400V / 1.5 Kw Weight 550 kg - Vibration dryer WALTHER G 100 C Max. Workpiece size measured diagonally 160 mm Heating capacity 3 Kw Weight 380 kg - Basket centrifuge WALTHER ZM 03 Capacity 1000 L/min. Drum capacity 14 L Aluminum drum with diameter 102.5 mm Wall thickness 9.5 mm Dirty water tank 300 L Drive 400V / 1.5 Kw Weight 650 kg Itodpeufimasfx Adweb - Separate control cabinets with operating elements - Total space requirement approx. W 5000 x D 1600 x H 2000 mm - Total weight of the system approx. 1600 kg

Condition: good (used), Vibratory Finishing Machine / WALTHER CC315 incl. control unit -Model CC315 -Speed range 945-1445 rpm -Separate control / On - Off / Timer etc. -Soundproof lid Isdpfx Adew R U U Ajwotb -Wastewater cover Dimensions: LxWxH 2x1.6x1.6 meters / Weight 850 kg Subject to errors and omissions.

Year of construction: 1998, condition: good (used), Hello Dear Interested Parties We are offering a well used Rösler vibratory finishing machine. This Rösler continuous grinding machine has been used since 2015 for own use and we are the 2nd owner. It is sold because of a reconstruction of the production hall and other project purposes. Manufacturer: Rösler Throughfeed Line Type: R 650 / 4600 DA Machine No.: 19289/98-06 Year of construction: June 1998 Control: SPS control Plant & Accessories: Dosing equipment Vibrating feeder buffer R 20/6/1,5 SR-P To conveyor 1, R470/4000 FB/S to spraying system Spraying system R 12/6 SM-E-So To conveyor belt 2, R470/2500 FB/S to continuous plant To conveyor belt 3, R470/1500 FB/S to circular dryer Granulate rotary dryer RT 850EUR Sludge tanks Central control cabinet with PLC control S5-95 Remark: Plant fuses perfectly, inspection on site is possible by appointment, this plant is still under power and can be tested if necessary. since here is a used trades, no warranty or no guarantees for. Ijdjihvr Rjpfx Adwotb MFG

Condition: new, Year of construction: 2025, ZGE60 - 60Lt Vibratory Sieving Machine * Changeable sieving system * 0.34 kW vibratory motor Itjdew Hpfvopfx Adweb * Start/Stop thermal switch It is used to automatically separate abrasive/polishing stones and material from each other after the deburring and/or polishing process in vibratory machines that do not have a sieving system.

Condition: new, Year of construction: 2025, machine/vehicle number: ZGS200, 200 l Capacity * 7.5 kW high-performance three-phase drive motor. Ijdpfx Asw Hb Tfjdwetb * Adjustable speed control up to 300 rpm. * Control panel and dosing pump included. - The dosing pump automatically adds the chemical to the tank * Working hours timer * PLC panel programmable on request * PU or INOX plate * Replaceable valve for wastewater drainage. * Inner tank features channels and cavities to ensure a non-stick wall.

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: 25-1361, total length: 775 mm, total width: 550 mm, total height: 775 mm, overall weight: 100 kg, input voltage: 380 V, warranty duration: 24 months, nominal power: 0.34 kW (0.46 HP), power: 0.35 kW (0.48 HP), workpiece length (max.): 525 mm, Equipment: CE marking, documentation/manual, emergency stop, ZTV 50 Trough type vibratory machine * Highly wear resistant P.U.Lining (90 Shore) * High performance three phase current drive motor. (Italian OLI Brand – 0,34 kW) * Changeable valve for the wastewater decharging * Control panel(EU Standarts) included * Main swicth and emergency stop switch. * Timer and working hours timer * CE safety standard * Dosing pump included. Itsdpfxewb Hhds Adwjb * The machine has noise isolation lid and metal machine cabinet - The cover is controlled by hand manually - The sound isolation cover provides significant noise reduction when the finishing process is in play. - It also curbs water or finishing compounds spillage from the vibratory finishing machine.

Condition: like new (used), Used (as new) vibratory finishing machine from PERS Semi-automatic vibratory finishing line with container for separating abrasive media and workpieces. No additional separation device needed. Itsdpfx Adjhr Rgfjwob Technical data: The machine is powered and can be inspected by appointment! Capacity: 140/65 l Bowl diameter: 660 mm Dimensions (LxWxH): 1,700 x 1,300 x 1,140 mm Power: 4 kW Speed: 0-160 RPM PU coating: 26 mm

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: ZCVS250, total width: 1,100 mm, total height: 950 mm, overall weight: 350 kg, input voltage: 380 V, warranty duration: 24 months, nominal power: 1.13 kW (1.54 HP), power: 1.13 kW (1.54 HP), workpiece width (max.): 190 mm, workpiece length (max.): 190 mm, Equipment: CE marking, ZCVS 250 CIRCULAR TYPE OF VIBRATORY MACHINE * Net 250 liter volume (Capacity between 125lt to 1250lt is available up to request) * Highly wear resistant P.U.Lining (90 Shore) * Dosing pump included. * Changeable valf for the wastewater decharging *According to requested diameter size for seperator MOTOR: * High performance three phase current drive motor. * 1,1 kW 1500 rpm (Italian OLI) * The motor is lubrication free. You don’t need motor lubrication. CONTROL PANEL: * Main switch and emergency stop switch. * Timer and working hours timer * Control box with switch for engine right/left running Iedpfsrkmv Sox Adwjtb * CE safety standard PAINTING: *Colour in RAL 5003 & RAL 7001 *Epoxy paint is used to ensure long life of the paint.

Condition: used, The RGM 3, a top-tier Tube End Finishing Machine from KNUTH, is designed for precision and efficiency in tube processing. Its rigid construction and small footprint make it an ideal choice for any workshop looking to optimize space without sacrificing performance. The machine features a jaw chuck at the front and a clamping chuck at the rear, allowing for versatile operations. Additionally, it comes equipped with a tube cutter and an inside deburrer, ensuring clean and accurate finishes on all types of tubing. With the inclusion of a mobile base, the RGM 3 offers easy maneuverability, enhancing its usability. Whether you need to perform intricate tube work or handle larger projects, this highly robust machine is built for the task. Don't miss out on the opportunity to enhance your tube and profile processing capabilities; order online today to bring the RGM 3 to your workshop. Ijdpfxouxc Rhe Adwstb

Condition: new, The EM 250, a robust Tube End Finishing Machine from KNUTH, is designed to provide precise deburring of tubes, profiles, and flat materials, making it an essential addition to any cold circular saw, shear, or profile processing setup. This powerful machine allows for effective deburring both inside and outside the workpieces utilizing a sturdy wire brush, ensuring that chips and burrs are thoroughly removed while maintaining the integrity of the cutting edge. With a motor rating of 2.2 kW and a speed of 3,000 1/min, the EM 250 is ready to enhance productivity in any workshop engaged in tube processing. It features a rigid machine foot and is equipped with a vacuum exhaust connection for cleaner operation. Moreover, it comes with a 5-year warranty for the drive motor, underscoring its reliability. For a well-rounded solution in Tube End Finishing Machines, consider the EM 250. Request a quote today to learn more about this powerful tool in Tube and Profile Processing. Isdpfx Aeu E H Tgsdwjtb

Condition: new, The RA 2 Tube End Finishing Machine is an essential tool for every workshop, designed to simplify the assembly and welding of tubes at a precise 90° angle. This robust device caters to various tube diameters while allowing for horizontal and vertical operation, making it versatile for both dual and corner unions. With its capability to handle tubes with wall thicknesses of up to 5 mm, from steel to non-ferrous metals, the RA 2 ensures quick and efficient machining. An eccentric shaft guarantees minimal effort during operation, enhancing productivity. The machine comes standard with an operator manual to facilitate setup and use. For your tube end finishing needs and additional inquiries, you can request a quote today and elevate your performance with KNUTH equipment. Ijdpfx Aswhkf Hedwstb
