Welding machine

OKIO

Condition: not inspected (used), Face plate diameter: 3000 mm Turning diameter without side support: 3500 mm Turning diameter with side support: 3300 mm Turning height under tool: 2560 mm Max. workpiece height: 2750 mm Ram stroke vertical: 1500 mm Ram stroke horizontal: 1800 mm Travel distance of side support: 2320 mm Traverse travel: 2100 mm Max. workpiece weight: 20 tons Ksdpfx Asvyy Txjadsdw Total weight: approx. 75 tons

Condition: excellent (used), functionality: fully functional, turning length: 530 mm, turning diameter over cross slide: 620 mm, turning diameter: 260 mm, spindle motor power: 15,000 W, spindle speed (min.): 35 rpm, spindle speed (max.): 3,500 rpm, spindle bore: 80 mm, travel distance X-axis: 195 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 590 mm, rapid traverse X-axis: 12 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 15 m/min, Mori Seiki SL-25Y/500 CNC LATHE With 1.5m LNS bar feeder Control: Mori Seiki MF-T6 Tool holders: (2) Radial live tolls (2) Axial live tools (4) inside tool holders (4) outside tool holders Kdodpfxew Ett Io Aadew Swing over bed: 815 mm (32.1″) Swing over cross slide: 620 mm (24.4″) Distance between centers: 620 mm (24.4″) Max. turning diameter: 260 mm (10.2″) Max. turning length: 530 mm (20.9″) X-axis travel: 195 mm +130 +65 (7.7″ + 5.1″ + 2.6″) Z-axis travel: 590 mm (23.2″) Y-axis travel: 100 mm ±50 (3.9″ ± 2.0″) Spindle speed range: 35 – 3,500 RPM Spindle nose: JIS A-8 Through spindle hole diameter: 80 mm (3.1″) Spindle bearing inner diameter: 130 mm (5.1″) Number of tool stations: 12 Shank height for square tool: 25 mm (1.0″) Shank diameter for boring bar: 50 mm (2.0″) Turret indexing time: 0.25 sec Rotary tool spindle speed: 100 – 2,000 RPM Rotary tool cutting capability: End mill max Ø20 mm, Face mill max Ø50 mm, Tap max M12 Rapid traverse rate:   X-axis: 12,000 mm/min (472.4 IPM)   Z-axis: 15,000 mm/min (590.6 IPM)   Y-axis: 10,000 mm/min (393.7 IPM) Feed per revolution:   X-axis: 0.001 – 342 mm/rev   Z-axis: 0.001 – 342 mm/rev   Y-axis: 0.001 – 500 mm/rev Jog feedrate: 6,000 mm/min (236.2 IPM) Tailstock travel: 403 mm (15.9″) Tailstock spindle diameter: 110 mm (4.3″) Tailstock spindle travel: 100 mm (3.9″) Tailstock taper: MT-5 (Live center) Spindle motor power (30 min/cont): 15/11 kW (20/15 HP) Rotary tool spindle motor: 3.7/2.2 kW (5/3 HP) Electrical power supply: 44 kVA Coolant tank capacity: 100 liters (26.4 gal) Machine height: 2,060 mm (81.1″) Floor space: 3,183 × 1,799 mm (125.3″ × 70.8″) Machine weight: 5,400 kg (11,900 lbs)

Year of construction: 2004, condition: used, machine/vehicle number: 0201-220031, FICEP DZ 603 drilling machine for sectional steel The Ficep DZ 603 is a drilling machine with 3 drilling axes for profile processing. This 3-axis drilling machine is designed for profile beam processing in steel construction. Steel profiles can be drilled and center-punched automatically on 3 axes (flange and web). The CNC control from Mitrol with Arianna software takes care of programming the drilling system. CAD data in DSTV or DXF format is converted into NC data in the CNC control and the machine starts the machine program in which the axes are moved to the specified position. A gripper measuring carriage positions the profile at the appropriate drilling position in the drilling unit. A 5-fold tool changer ensures fast drill bit changes on the individual drilling axes. A stable roller conveyor transports the steel profiles in the infeed and outfeed areas. Technical description Ficep DZ 603 drilling unit: Beam height: max. 610 mm Flange width: max. 450 mm Machining length: max. 11,300 mm CNC control Mitrol ARIANNA 3 drilling spindles suitable for HSS cooling channel drills Spindle speed: from 180 to 1000 RPM Drill diameter: min ø 8 mm - max ø 40 mm Power of the drilling spindles 7.5 kW each Kdjdpfx Ajrr Tausadew The DZ603 drilling machine is sold without marking unit.

Condition: excellent (used), Year of construction: 2020, We don't get to use it in production, therefore the sale. Kdodpfx Aaorq A Sxsdjw

Year of construction: 1990, condition: excellent (used), Equipment The machine can be upgraded with new software and control system according to customer requirements. Measuring range X = 850 mm Y = 1200 mm Z = 600 mm Measurement accuracy 2,5µ + L/250 Price: on request! Kodpoff Eakjfx Aadjdw We would be happy to provide you with a detailed offer! Please note: Our offer is directed exclusively to professional customers. (Changes and errors in the technical data, information and prices as well as prior sale reserved)

Year of construction: 1994, condition: good (used), Ziersch & Baltrusch surface grinding machine - with Formmaster 6 / 30 - with belt filter unit - with coolant unit - width: 250 cm - depth: 200 cm Kodpfsk Ixl Asx Aadedw - height: 220 cm Good condition fully functional can be viewed and tried on site. Shipping also abroad. Viewing : Basically, I would like to point out that to avoid misunderstandings, the item is welcome to be inspected and tested under power before purchase. Please ask questions before buying to avoid ambiguity. For general questions or to make an appointment for a viewing, I am, at the phone number below or above, always available. Errors in the description and subject to prior sale. VAT is shown separately on my invoices. Shipping with forwarding agent.

Year of construction: 2019, condition: ready for operation (used), Connected load: 84kVA, length: 5065mm, width: 1100mm, height: 1530mm. Kjdpeg A Trgefx Aadsdw

Condition: refurbished (used), Year of construction: 2025, operating hours: 16 h, functionality: fully functional, measuring range X-axis: 400 mm, measuring range Y-axis: 400 mm, measuring range Z-axis: 200 mm, warranty duration: 12 months, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 200 mm, input voltage: 230 V, feed length X-axis: 400 mm, feed length Y-axis: 400 mm, feed length Z-axis: 200 mm, year of last overhaul: 2025, ambient temperature (min.): 16 °C, Equipment: documentation/manual, lighting, type plate available, Mahr Multiscope 442 multi-sensor measuring device equipped with camera, laser and Renishaw probe system. Factory overhauled premium multisensor measuring center with guarantee and warranty rebuilt 2025. Incl. latest SW update, 18 months free SW update service, free lifetime SW hotline and user support. Delivery with factory service or forwarding agency, worldwide. Online, optionally on-site demos with customer parts, application technology advice from accredited Profitech measurement laboratories during project planning. Complete service: – Delivery, construction, commissioning, accuracy acceptance according to standard, certification and extensive acceptance documentation. Individual education and training programs can also be booked as online courses. Rent-hire-purchase or financing possible directly via Profitech and without a financial institution. Measuring device individually configurable to customer needs Measuring range of all sensors: 400x400x200mm Kdodpfxedy Uvme Aadew Dimensions: 800x1000x2000mm Weight: about 800kg max. loading weight: glass plate 30kg Accuracy: U1=1.9 + L/200; U2=2.4 + L/150; U3=2.9 + L/100 (L= measuring length in mm) max. travel speed: 250mm/s including camera including lasers including LED ring light incl. new frame grabber (Eagle) including 2-monitor operation incl. CNC control and PC including new Optichek 3D 5.0 evaluation software

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, overall weight: 250 kg, load capacity: 16 kg, We at Binici MB GmbH also have other industrial robots in-house. Ksdpfxsv Diuye Aadedw All our robots are fully functional (with complete accessories). We are at your disposal for good advice

Condition: new, Year of construction: 2024, Protec welding rotary table 20000 Kg load capacity speed infinitely variable 0,05 - 0,35 rpm Hand remote control foot remote control extra charge 390.-€ height 700mm diameter 2000mm Kdedpfx Aajid Szkjdow
