TRUMPF TruLaser Tube 7000 KT02

TRUMPF TruLaser Tube 7000 KT02

Condition: new, Year of construction: 2025, Effective Tube Cutting Length: 6500mm/9200mm Laser Output Power: 6000w/3000w/2000w/1500w Effective Round Tube Cutting Diameter: Φ20-230mm Effective Square Tube Cutting Diameter: □20*20-□160*160mm Edge Length: 20-170mm Fedpfx Agog Dgbhj Aoph Outer Circle Diameter: ≤230mm Certification: CCC, CE, GS, ISO, Sgs Laser Source Brand: IPG/MAX Warranty: 3 years Power supply: 110V/220V/380V 50Hz/60Hz 1.Bigger than Bigger The maximum cutting diameter of T series is 30%longer than the mainstream products in the market ; The maximum cutting weight is 100% heavier than the mainstream products in the market. 2.Chuck position control, torque control function The position control CNC self-centering chuck with independent intellectual property rights can automatically clamp material according to the input tube size; Position monitoring in torque mode to ensure that the thick tube is not loosened and the small tube is not deformed;Brand new dust-proof structure, long-lasting use without lagging. 3.Edge-seeking, center-finding Brand new function of edge-seeking, center-finding. Optimized edge-finding method and algorithm, higher cutting precision and stability

Year of construction: 2013, operating hours: 84,545 h, condition: ready for operation (used), General Data Machine weight 17500 kg Fpsdpfxjx D Nwwo Ag Ajh Main Drive Punching force 220 kN This TRUMPF TRUPUNCH 5000 S10 was manufactured in 2013. It features a Siemens Sinumerik 840D control system, a working area of 3050x1550 mm, and a punching press of 220 kN. Capable of handling sheet weights up to 280 kg and thicknesses up to 8 mm, it includes a Linear ATC for 21 tools and additional options like MULTITOOL and ENGRAVING. Regularly maintained and in good condition. Contact us for more information about this machine. Application Types Punching

Condition: as good as new (ex-display), functionality: fully functional, Year of construction: 2022, operating hours: 60 h, +++ Demo machine, approx. 60 operating hours +++ +++ Descending Die +++ Basic machine: TruPunch 3000 large format (S20) Machine: - Box frame - Hybrid axis system - Linear tool magazine with 24 stations for clamps and tools - Hydraulic clamps (3x) - Drives with maintenance-free three-phase motors - Repositioning with programmable presser foot - Foot switch to close clamps - Part chute, right - Part removal flap, left - Sensor for part removal flap - SortMaster Compact retrofit-prepared Punching head: - Delta Drive - Rotating single-station tool adapter - Programmable presser foot position - Tool length compensation - Punch spray lubrication - Punching slug vacuum - Forming function - Punch stroke counter Control: - TRUMPF control based on Rexroth IndraMotion MTX - Touch panel with 19" TFT color display - Touchpoint - Auto-shutdown - Remote support interface - Program manager - Production plan Data transmission: - Central Link - Online Update Manager Safety: - CE marking and EC Machinery Directive - Double-beam safety light barrier Advanced standard configuration: - First index pin (inside right) - Ball tables - Part chute for finished part container - Chip container to rear for removal Advanced machine and punching features: - MultiTool function - MultiShear function - MultiBend function - Tapping function with thread counter - Forming tap breakage control - Lubricant level monitoring - Unlimited time license - Marking/Quick beading function (option) - Engraving function - Deburring and roller technology function - Adaptive stroke calibration - StripLine - Die spray lubrication with fill level monitoring - Descending Die - Integrated flattening function - Smart punch monitoring - Additional clamp - Height-adjustable clamp - Vibration damping - Chip container removed to front - Brush tables with loading and unloading assistance - Warped sheet detection Technical data TruPunch 3000 large format (S20) Dimensions / Weight: Width: 7644 mm Depth: 7666 mm Height: 2200 mm Fedpfx Aexmfc Ueg Asph Weight (fully equipped): 13,800 kg Control / Hardware / Electrics: Hard disk type: SSD Number and size of hard disks: 2 x 120 GB Customer program memory: 10 GB Display: Touchscreen Display size: 21.5 in Interfaces: USB Network: RJ45 Control type: Bosch CML75 Operating system: Windows 10 IoT Axis data: X/Y/C axis drive: NC-controlled, maintenance-free three-phase servo motors Punching head drive: Electric Max. X axis speed: 90 m/min Max. Y axis speed: 60 m/min Max. simultaneous axis speed: 108 m/min Max. C axis speed (punching): 350 rpm Max. C axis speed (tapping): 350 rpm Max. punching stroke rate (E=1mm): 690 1/min Max. marking stroke rate: 1000 1/min Accuracy — positioning deviation Pa: +/- 0.1 mm Accuracy — position range Ps: +/- 0.03 mm Smallest programmable increment: 0.001 mm Working range / Workpiece size: Max. sheet thickness: 6.4 mm Max. workpiece weight: 230 kg X axis working range: 3000 mm Y axis working range: 1550 mm Punch-specific data: Max. punching force: 180 kN Max. presser foot force: 20 kN Max. tool size, punching (outer diameter): 76.2 mm Max. tool size, forming (outer diameter): 101.6 mm

Condition: refurbished (used), Our Leybold RUVAC WAU1001 Roots-blower pumps will: be good as new Fsdsfq D Hvopfx Ag Ajph be checked after the manufacturer's specifications, for example its tolerances be fitted with new wear parts be available at short notice included one-year warranty

Condition: new, DESCRIPTION DM100 Z2C - performs edge rounding and removes sharp burrs from both the inner and outer edges of steel, stainless steel or aluminium parts after laser, shear or punch cutting of metal parts from 50 x 50 mm up to 1100 x 100 mm in size. Ekdjtxp The 1st station processes the products through a contact roller (approx. 55° shore) with an abrasive belt and removes strong burrs in the first step. The 2nd station processes the products with 2 counter-rotating cross belts each from below and from above. The cross belts round off the parts to be machined on both the inner and outer edges. A big advantage is also the deburring of products with surface protection foil, because only the edges are processed without damaging the foil. Technical data - DM1100 Z2C: Working capacity (Ø mm) 1100x100 No. of belt stations (Z) 1 Fsdsd Ixadepfx Ag Ajph No. of cross belt stations 2 Abrasive belt, dimensions (mm) 1100x2200 Abrasive belt speed (m/s) 8-22 Cross belt speed (m/s) 2-8 Feed speed (m/s) 0.6-3.2 Sanding belt motor per head (kW) 18.5 Cross belt motor (kW) (2x) 3 Feed motor (kW) (3x) 0.18 Total power (kW) 33 Power consumption (A) 62 Rod suction connection per head (Ø mm) 150+185 Dimensions (mm) 3600x2330x2350 Weight (kg) 5000

Condition: used, System: used piston diaphragm pump / pump Type: HMD-G-50-500 Flow rate: 40.0 m3/h Pressure: 1,6 MPa Fpodpfjdkdi Tsx Ag Aeh

Condition: good (used), Year of construction: 1962, High speed radial drilling machine, radial drilling machine, drilling machine, boom drilling machine, high speed radial drilling machine -Clamping table: 400 x 1100 mm -Projection: 930 mm Fpjdpfx Aeirax Uog Aoh -Taper mount: MK4 -Engine power: 1.35/1.8 kW -Speed: 41-1700 rpm -Columns: Ø 200 mm -Spindle stroke: 125 mm -Thread cutting device: YES -Feed: 0.075 - 0.3 mm/rev -Dimensions: 1800/1235/H2240 mm -Weight: 1500kg

Condition: good (used), Year of construction: 1992, Indoor crane, crane, electric wire rope hoist, hoist, motor winch, motor winch, tackle, traction winch, block and tackle Fedpfx Ajl Tuvdsg Asph -Manufacturer: steel, crane chassis with electric cable pull -Crane chassis: Type GO 24 20 16 -Traveling speed: 20 m/min -Roller pitch: 800mm -Cable: Type AS 2010 -Traction: 1000 kg / load capacity 4000 kg -Drum speed: 16 m/min / stroke 4 m/min -Lifting height: mm -Transport dimension: 1250/1180/H400 mm -Own weight: 356 kg

Condition: excellent (used), functionality: fully functional, Year of construction: 2009, Options: ACB, BendGuard for manual bending, HQ version, interface to 2nd machine Fpsdpowykccjfx Ag Ajh

Year of construction: 2017, condition: ready for operation (used), - USED - FIBER LASER CUTTING MACHINE FOR TUBES WITH LOADING/UNLOADING SYSTEM MIN CIRCULAR SECTION: ø 25 mm MAX CIRCULAR SECTION: ø 355 mm Fjdpfx Aox E Eiheg Aoph MAX SQUARE SECTION: 260 X 260 mm MAX RECTANGULAR SECTION: 300 X 200 mm MAX ADMITTED LOAD: 100 Kg/m SOURCE: IPG YLS-4000 ; 4000 W CONTROL UNIT: SIEMENS 840D WEIGHT: 12500 Kg NOTE: AUTOMATIC LOADING 3-12.5 mt; AUTOMATIC UNLOADING 12.5 mt; 3D CUTTING HEAD; CAPACITIVE SENSOR; AUTOMATIC ADJUSTMENT
