Koch Technology GmbH & Co. KG

Condition: reconditioned (used), Year of construction: 1995, machine/vehicle number: 9511/5376, workpiece height (max.): 40 mm, working width: 1,200 mm, number of spindles: 1, table width: 1,300 mm, table height: 900 mm, working height: 900 mm, pressure: 6 bar, workpiece width (max.): 1,200 mm, KOCH drilling and dowel insertion machine Type SPRINT PTP Workpiece dimensions Workpiece length (Y) 100 - 800 mm Workpiece width (X) 20 - 1200 mm Workpiece thickness (Z) 10 - 40 mm Iolhccqorc A Nwjqotf Machine equipment - Horizontal drilling station with one drilling spindle -Drill holder Ø 10 mm - Dowel hole blow-out and extraction system - Glue application and dowel insertion station with a DW34 dowel tool for dowels Ø 8 mm - ELC electronic glue monitoring system - Vibratory conveyor - Glue pump 1:1 - Workpiece support table 1300 mm wide - 1 stop each left and right - Mechanical digital displays for height adjustment (workpiece thickness) -PC positioning control

Year of construction: 1991, Condition: used, machine/vehicle number: 9105/4452, Double end automatic operation, for straight, right-angled workpieces Stock dimensions Stock length 220 - 2500 mm Stock width 15 - 200 mm Stock thickness 15 - 50 mm Double-sided trim saw: The saws are cutting downwards through the clamped workpiece.Each side 1 sawing unit. Horizontal drilling station: each side 1 drilling unit with 1 drilling motor 2 kW Distribution of vertical drilling units: 3 units at the front of the overhead beam Itjlhceit T H Socqqjf 2 units at the back of the overhead beam Workpiece centre support: With stop and back stop Edge drilling unit: Each Side 1 support with height adjustment Distance from edge max 250 mm.

Condition: new, machine/vehicle number: 22069, total height: 23,000 mm, total length: 36,600 mm, total width: 9,400 mm, working height: 420 mm, input frequency: 50 Hz, input voltage: 400 V, overall weight: 2,100 kg, The electro-mechanic case clamp VK011 allows a fast assembly of cabinets without having to make pre-adjustments on the clamp. The strong clamping plates of the VK011 enable all-over clamping of the cases to achieve the highest quality results. A clamping power of up to 2.300 kg can be generated in the press. - Vertical press plate (150 x 50 mm) Ijlhsgqfpfjccqqetf - Horizontal press plate (150 x 50 mm) - Preselection of pressing time - Max. pressing pressure 1,800 kg (horizontal), 2,300 kg (vertical) - Machine operation via joystick - 2-hand operation Advantages: - High flexibility:Pressing pressure is variably adjustable. Great variety of different cabinet dimensions possible - Maximum output due to positioning speed of up to 54 mm/sec (ECO up to 29 mm/sec) - Intuitive operation via joystick - High safety standards due to CE-conformity e.g. 2-hand-operation, security fence etc. - Sturdy design, linear guides and ball screws lead to the highest precision - Plug & Play

Condition: new, Year of construction: 2023, machine/vehicle number: A2306/9210, The pneumatically working drawer clamp type Box V3.0 ensures a simple and fast assembly of drawers and frames. Thanks to its functional design, it is possible to press single parts as well as complete drawers with different connections. This way, a perfect connection as well as shape of the drawer can be guaranteed. Because of the special clamping process, folding connections and drawer fronts with glass insets cannot be deformed. Maximum clamping power: vertical: 800 kg / horizontal: 800 kg Adjustable depth stops allow clamping of drawers with longer fronts Lateral press units slowly approach the workpiece Machine operation via joystick. Special equipment: - Digital positioning readout - Kit Door (for frontal clamping of drawer corners) Advantages: - High flexibility: Variably adjustable clamping unit for drawers and frames of different dimensions - Minimum set-up times allow high output - Intuitive operation Itelhcjgqfnzecqqjf - High safety standards due to CE-conformity e.g. 2-hand-operation - Plug & Play

Year of construction: 1998, Condition: used, machine/vehicle number: 9803/5823, The second-hand drilling and dowel insertion machine is equipped with 2 separate working fields. One workpiece can be processed while the next piece is loaded. The boring and dowel driving pattern is processed on point-to-point-basis. Dowel diameter: 8 x 30 mm Stock length: min. 90 mm Stock width: up to 2x 1,100 mm Stock thickness: 14-40 mm EQUIPEMNT 1 x horizontal drilling station 1 x glue injecting and dowel insertion station type 34 Electronic Glue Control ELC 1 x vibrator hopper convejor 1 x glue pump 1:1 Central lubrication Workpiece support table 1,250 mm 4 x stock clamping system for horizontal and vertical drilling Vertical drilling: Workpiece in upright positiont Stock length: min. 320 mm Stock width: max. 600 mm Stock thickness: 10-36 mm 1 center stop with 2 sensors removeable for both workpieces Ijlhccqegkwqqsqetf 2 x workpiece support 550 mm deep (Y) retractable right and left NC-positioning of height adjustment of the drilling and dowel insertion station (Z-axis) Electric supply 400 V, 50 Hzs, 3 phases KOCH Numeric with 1 NC-axis (X)
