Plasma cutting system 3000 mm x 8000 mm

DURMA PL-C 3080

Condition: used, Year of construction: 2000, functionality: fully functional, machine/vehicle number: D08L/8034, Offer Number: D08L/8034 Machinetype: straightening and cutting machine Make: WAFIOS Type: R31 Constr. year: 2000 wire diameter range: 1,5-7,0mm Bdsdpswi Th Tsfx Ak Heb cutting length: 3000 mm speed - meters/min: 5-120 Location: In our warehouse

Condition: good (used), functionality: fully functional, Year of construction: 1990, machine/vehicle number: 4ROLL, roller (bottom) diameter: 470 mm, roller (top) diameter: 470 mm, side roll diameter: 420 mm, roller diameter: 470 mm, roller length: 3,050 mm, working width: 3,050 mm, working height: 1,800 mm, sheet thickness (max.): 50 mm, sheet thickness steel (max.): 45 mm, sheet thickness aluminum (max.): 45 mm, sheet thickness copper (max.): 45 mm, overall weight: 43,000 kg, total length: 7,700 mm, total width: 2,410 mm, total height: 2,470 mm, power: 37 kW (50.31 HP), input voltage: 380 V, type of input current: three-phase, working length: 3,050 mm, Equipment: documentation/manual, emergency stop, PLATE BENDING MACHINE FACCIN - 4 ROLL HYDRAULIC 3000 X 40 MM MODEL 4HCI3-35/30 YEAR 1990 PLATE BENDING ROLL LINEAR GUIDEWAYS DOUBLE PINCH PRE-BENDING Machine in good working condition Bending capacity -Plate width : 3000 mm -Rolling plate thickness 40 mm - Prebend thickness 35 mm Rolls dimensions: -Useful length 3050 mm -central rolls upper/lower 470 mm -side rolls left/right 420 mm • Hardening of the 4 rolls high strength surface • 3 rolls driven powered with gear unit with hydraulic motor • Conical bending attachment side rolls tiltable to form cones, contrast pad roller type. • Opening front hydraulic drop-end to unload the closed shell. • Variable speed working roll bending rotation hydraulic speed fast/slow. • Console electric on wheels with centralized commands joysticks and 3 digital readout. • Digital readouts of the rolls position bending and pre-bending repeatability. Bdsdpswb Scmsfx Ak Heb • Hydraulic tank capacity oil 350 liters – power electric 37 Kw voltage 380 /50 • Dimension 7700 x2410 x H 2470 mm - weight 43000kgs

Condition: good (used), Year of construction: 2000, table width: 1,000 mm, table length: 1,800 mm, ram plate width: 600 mm, total length: 25,000 mm, total width: 27,000 mm, total height: 47,000 mm, overall weight: 43,000 kg, die cushion stroke: 200 mm, Siemens Simatic OP 27 control system Bdodotiwgiopfx Ak Hjb Light barrier Sick Separate control cabinet Ritta Side passages Ground level installation

Condition: good (used), Year of construction: 2012, CNC portal plasma cutting machine Manufacturer: Microstep Model: SPL PAA 9001.25 Year of manufacture: 2012 CNC control system Working area: 2,500 x 9,000 mm Bsdpfsu U Hm Aex Ak Hedb 1 plasma torch with Kjellberg HiFocus 280i power source 2 autogenous torches for propane Oscillating conveyor table by Beuting Donaldson DFPRO12 filter unit for outdoor installation

Condition: new, Year of construction: 2023, arm reach: 1,400 mm, load capacity: 6 kg, New welding robot TIG OKIO AB6-C1400 -Country of origin: China -Type: AB6-C1400 -Number of axes: 6 -Reach: 1400 mm -Maximum payload: 6 kg -Control cabinet -Remote control Bedpfx Akoqnt N Dj Hsdb -Wire feeder -Welding source: TIG WSM400R -Cooler

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, measuring range X-axis: 1,200 mm, measuring range Y-axis: 2,000 mm, measuring range Z-axis: 1,000 mm, Measuring Range X – axis 1200 mm Y – axis 2000 mm Z – axis 1000 mm Accuracy acc. ISO 10360 E = [2,6 + 4L/1000]µm Bdododv I Abspfx Ak Hob DCC controller Renishaw UCC S5 JS box Renishaw MCU-5 (wireless on demand) Temperature sensor Renishaw Probe system Renishaw REVO 5-axis scanning probe Probe changer Renishaw (price REVO system new appx. € 80.000,--) Application software Inspect3D Inca V6 avzula version built 2014, retrofit 2017 with Revo

Condition: excellent (used), functionality: fully functional, Year of construction: 2003, machine/vehicle number: NOH366, ABUS ELV Crane Skyline Crane Runway Bridge Crane Hall Crane Crane There are 3 identical cranes available! Load capacity / Lifting capacity: 5t - 5000KG Bedpfoxtyvpex Ak Hedb Span: 14,260mm, external dimension approx. 14,500mm Year of manufacture: 2003, with radio remote control and pendant control as backup Lifting height: 6m Overall height (top of crane to hook): approx. 900mm End carriage length with buffer: approx. 280cm Further data to follow Crane is dismantled and immediately available Very good condition, inspection book is available Column-mounted slewing cranes and wall-mounted slewing cranes also available Demag KBK and Abus HB systems, as well as Errikla, Hadef, Stahl KT 2000, etc. Shipping via freight carrier possible, please enquire with postcode Collection preferred

Condition: used, Year of construction: 2020, functionality: fully functional, operating hours: 1,000 h, Kovo Staněk TZNZ 5-11/16-36 (2020) – High-Performance Hanger Shot Blaster Type: overhead rail / hook (CE) • Year: 2020 • Total weight: 12,000 kg • Condition: excellent, production-ready. Capacity & Power Max workpiece: Ø 1600 × 3600 mm (H) Max hook load: 1000 kg Throwing wheels: 5 × 11 kW, rotor Ø 350 mm (individually fed) Abrasive hopper: approx. 1800 kg Air demand: 20 m³/h at 6 bar Noise level: ≤ 85 dB(A) Machine size (W × D × H): 4730 × 5070 × 6520 mm Mains: 400/690 V, 50 Hz • Control voltage: 24 V DC Control & Automation PLC (NX platform) with touchscreen HMI and remote service access. Up to 99 programs with per-job settings: blast time, turbine speed, hook rotation and speed, swing angle of turbine block, servo abrasive flow per wheel, automatic conveyor start/stop. Diagnostics and full interlocking on doors and motions. Wear Protection & Build Bdodpfx Aexpiw Ujk Hjb Blasting chamber lined with XAR500 wear plates (5 mm) and manganese steel X120Mn12 in formed/high-wear zones; replaceable rubber in impact areas. Wheel internals (blades, cages, liners) made from tool steel 1.2379 / X153CrMoV12 (~62 HRC). Heavy welded turbine block housing. Service platform with safety gate and Total Stop. Abrasive Circuit Designed for steel shot S330 (initial charge about 1.5 t). Elevator → air separator → shared hopper loop; magnetic/air cleaning maintains media quality. Servo dosing to each wheel ensures uniform intensity and reduced consumption. Extraction & Filtration CIPRES CARM dust collector, 7.5 kW fan, automatic back-draft flap; ducting includes automatic valve for cabin purge at cycle end. Handling System Powered monorail with adjustable speeds; servo-driven hook rotation and lift; pneumatic diverter switch; two 1.1 kW hoists. Timed sequence allows loading the next batch while blasting. Applications Forgings, castings, welded structures and general steel fabrications—surface preparation before painting, galvanizing or coating with high throughput and repeatable Sa 2½–3 results. Key Advantages 5 wheels for high coverage and speed • PLC plus servo precision • XAR and manganese lining for long service life • 12-ton EU build • Low noise ≤ 85 dB(A). Available for inspection on request via the platform.

Condition: used, mileage: 9,62,877 km, lifting height: 20,000 mm, Year of construction: 2007, operating hours: 1 h, Drivetrain Drive: Wheel Weights Empty weight: 25.460 kg Functional Lifting capacity: 14.800 kg Identification Serial number: 970090 / 5127349 Other information Front tyres / undercarriage remaining: 80 Rear tyres remaining : 80 Tyre brand: Goodyear Bsdpsxwim Ejfx Ak Hodb Carrier engine: - Upper engine: - Counterweight: 0 Transport dimensions (LxWxH): 0x0x0 Additional information Please contact PFEIFER GROUP for more information

Condition: used, Technical details: spindle diameter: 130 mm drill depth: 1380 mm x-travel: 2500 mm y-travel: 1600 mm z-travel: 380 mm w-axis: 900 Bohrspindelvorschub mm U-axis: 320 Planschiebervorschub mm control: auf Wunsch tool taper: ISO SK50 revolution per minute: Planschieber:4,5-180 U/min rpm - drive spindle: 4,5-900 U/min feed:: x/y: 5-2000 total power requirement: ca. 40 kW weight of the machine ca.: ca.< 35 + AZusatzeinrichtungen t The machine can be offered in 4 different sales options. Please choose! 1. the machine is in mint mechanical condition. As is/is. 2. the machine as is/is incl. plate field 4000x2000x300mm = stock no. 1101081 3. the machine is newly wired, with new electrical cabinet, digital display, with 4-axis, AC drives from Siemens, axis motors from Siemens (50A/31Nm) with 12 months warranty on all new parts. 4. further additional equipment can be offered as an option. Such as coolant system, chip conveyor, enclosure etc. We should discuss this on the table with your technical staff. i.D. Bodpfxsvr S Uls Ak Hjdb *
