Electric guillotine shears

S

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 164, travel distance X-axis: 250 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 300 mm, controller model: GE FANUC Series 16i-M, spindle speed (max.): 14,000 rpm, TECHNICAL DETAILS X-axis travel: 250 mm Y-axis travel: 200 mm Z-axis travel: 300 mm Number of axes: 3 Max. spindle speed: 14,000 rpm Table length: 400 mm Table width: 250 mm Number of T-slots: 3 Distance between T-slots: 80 mm T-slot width: 14 mm Tool magazine capacity: 48 Tool holder: HSK E40 Working feed rate: 20 m/min Rapid traverse: 30 m/min Max. feed force: 3,700 N MACHINE DETAILS Control: GE FANUC Series 16i-M Resolution: 1 µm Compressed air supply: 6 bar Electrical connection: 50 Hz 3x 400 Volt Spindle drive power: 10.4 kW Total power requirement: 18 kVA Dimensions & Weight Dimensions (L x W x H): 2,100 x 1,630 x 2,265 mm Machine weight: approx. 1,700 kg Required floor space: approx. 2 m² EQUIPMENT Vice: Jaw width 100 mm Set of tool holders Coolant system Lredpfx Afoyhnzkjaoh Lighting

Year of construction: 1981, condition: ready for operation (used), functionality: fully functional, saw blade length: 6,500 mm, saw blade width: 120 mm, machine/vehicle number: 7283, The machine can be used either as a standalone unit or as part of a complete production line: - Joulin vacuum lifter + stacking and feeding task (Reference ID: 21264612) - Costa planing machine (Reference ID: 21264937) TECHNICAL DETAILS Lredeyk Tqvepfx Afaeh Saw blade length min.: 6,350 mm Saw blade length max.: 6,500 mm Saw blade width min.: 90 mm Saw blade width max.: 120 mm MACHINE DETAILS Saw band tension: Pneumatic saw band tensioning Design: Double bandsaw (twin configuration) EQUIPMENT Cross and longitudinal conveyors for automatic wood infeed and outfeed Diagonal cutting possible

Condition: ready for operation (used), Year of construction: 2009, operating hours: 27,745 h, functionality: fully functional, machine/vehicle number: NT320110134, turning length: 1,045 mm, turning diameter: 600 mm, travel distance X-axis: 685 mm, travel distance Y-axis: 125 mm, travel distance Z-axis: 1,075 mm, The offer includes a comprehensive tool package (see attachment; an Excel table can be provided on request)! An inspection checklist for 2025 is also included. TECHNICAL DETAILS Maximum workpiece swing diameter: 600 mm Swing diameter over cross slide: 600 mm Maximum distance between centers: 1,255 mm Maximum machining diameter at tool spindle: 600 mm Maximum turning length: 1,045 mm Bar capacity: 65 mm Axes X-axis tool spindle: 685 mm Y-axis tool spindle: ±125 mm Z-axis tool spindle: 1,075 mm B-axis swivel range: ±120° X-axis turret 2: 130 mm Z-axis turret 2: 970 mm Main spindle Maximum speed: 5,000 rpm Gear stages: 2 Spindle nose: JIS A2-6 Spindle bore: 73 mm Indexing: min. 0.0001° Inner bearing diameter: 120 mm Counter spindle Maximum speed: 5,000 rpm Gear stages: 2 Spindle nose: JIS A2-6 Spindle bore: 73 mm Indexing: min. 0.0001° Lredpoyml Eqjfx Afash Inner bearing diameter: 120 mm Tool spindle (Turret 1) Maximum speed: 12,000 rpm Maximum tool length: 200 mm Maximum tool weight: 4 kg Tool change time: 1.25 s MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 3,765 x 2,966 x 2,765 mm Weight: 15,800 kg Operating Hours Power-on hours: 131,963 h Operating hours: 68,391 h Spindle hours: 27,745 h

Condition: ready for operation (used), Year of construction: 2008, operating hours: 29,709 h, functionality: fully functional, machine/vehicle number: NT320GE0052, turning length: 1,045 mm, turning diameter: 600 mm, travel distance X-axis: 685 mm, travel distance Y-axis: 125 mm, travel distance Z-axis: 1,075 mm, The machine's tool spindle was replaced in 2022! The offer includes a comprehensive tooling package (see attachment; an Excel tool list can be provided upon request)! TECHNICAL DETAILS Maximum workpiece swing diameter: 600 mm Swing diameter over cross slide: 600 mm Maximum distance between centers: 1,255 mm Maximum turning diameter with tool spindle: 600 mm Maximum turning length: 1,045 mm Bar capacity: 65 mm Travel paths X-axis (tool spindle): 685 mm Lredpfx Afeymlvvjash Y-axis (tool spindle): ±125 mm Z-axis (tool spindle): 1,075 mm B-axis (swivel range): ±120° X-axis (turret 2): 130 mm Z-axis (turret 2): 970 mm Main spindle Speed: max. 5,000 rpm Gear stages: 2 Spindle nose: JIS A2-6 Spindle bore: 73 mm Indexing: min. 0.0001° Bearing inner diameter: 120 mm Counter spindle Speed: max. 5,000 rpm Gear stages: 2 Spindle nose: JIS A2-6 Spindle bore: 73 mm Indexing: min. 0.0001° Bearing inner diameter: 120 mm Milling spindle (turret 1) Speed: max. 12,000 rpm Maximum tool length: 200 mm Maximum tool weight: 4 kg Tool change time: 1.25 s MACHINE DETAILS Dimensions (L x W x H): 3,765 x 2,966 x 2,765 mm Weight: 15,800 kg Operating hours Power-on hours: 138,593 h Operating hours: 66,865 h Spindle hours: 29,709 h

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, turning length: 2,000 mm, spindle speed (max.): 1,000 rpm, travel distance Z-axis: 2,000 mm, overall weight: 40,000 kg, turning diameter over bed slide: 1,270 mm, controller model: Fanuc Serie 18i-TB, TECHNICAL DETAILS Turning length: 2,000 mm Swing diameter over bed: 1,550 mm Swing diameter over cross slide: 1,270 mm Spindle speed: 1,000 rpm Spindle diameter at front bearing: 240 mm Spindle bore: 185 mm Spindle power: 37/30 kW Bar capacity: 165 mm Travel in longitudinal direction (Z-axis): 2,000 mm Cross travel: 685 mm Rapid traverse speed X-axis: 10 m/min Rapid traverse speed Z-axis: 12 m/min MACHINE DETAILS CNC control: Fanuc Series 18i-TB Dimensions & Weight Dimensions (L x W x H): 9,800 x 3,695 x 5,292 mm Machine weight: approx. 40 t Lredpfxoylwl Tj Afash EQUIPMENT 12-position turret

Condition: used, mileage: 6,93,518 km, power: 235 kW (319.51 HP), first registration: 12/2012, fuel type: diesel, number of seats: 49, gearing type: automatic, emission class: euro5, color: white, brakes: retarder, Equipment: ABS, air conditioning, parking heater, General Engine: MAN AdBlue particulate filter Emission standard: EURO 5 Total seats: 49 Seats: 44 + 4 + 1 elevated/fixed Standing places: 100 Transmission: Automatic Lrjdpfx Afoymu Eyeash Safety * Retarder * ABS, ASR, EBS * Fog lights Passenger compartment * Auxiliary heater * Air conditioning * Driver’s microphone * Stroller bay * Wheelchair ramp * Wheelchair space * Stop request button Audio, Communication, Electronics * Radio, CD Exterior * Matrix/destination display * Double-width doors, number: 3 * Lifting-/lowering system * Power steering * Tachograph disc * Sun visor * Electrically adjustable exterior mirrors * Roof hatches * Roof ventilators * Roof fans Miscellaneous * German registration documents * Twin tyres * Vehicle length: 17.98 m * Vehicle width: 2.50 m * Vehicle height: 2.98 m * Tyres, front axle approx. 50% * Tyres, middle axle approx. 50% * Tyres, rear axle approx. 50% Our internal vehicle number: 12214 Subject to errors and prior sale. Images and text may differ from the actual vehicle. Always over 300 vehicles available in our inventory.

Condition: used, Year of construction: 2012, operating hours: 4,579 h, Equipment: all wheel drive, Telescopic boom lift, JLG 680 S, 4x4 all-wheel drive, with 4m platform basket JLG, * 680 S, * Working height: 22.7 m, * Platform height: 20.7 m, * Lateral outreach: 18 m, * Year of manufacture: 2012, * Hour meter reading: 4,879 hours recorded, * 3-section telescopic steel construction, * Powered by a 4-cylinder Deutz diesel engine, * 2 driving speeds, * Tire size: 18-625 NHS, * Tread depth: 17-21 mm, * Wheelbase: 3,050 mm, * Drive configuration: 4x4, * Overall dimensions: 12,250 x 2,520 x 2,980 mm, * Weight: 15,953 kg, * Basket load capacity: 230 kg, * Rotatable platform basket, * Steel platform basket construction, * Basket dimensions (L x W x H): 4,000 x 1,020 x 1,100 mm, * Basket and ground controls, oscillating axle. Lredpfx Asymutkefash Further data and additional images are available on request. This description does not constitute a binding offer and may contain errors. No guarantee on all information provided. Please also visit our homepage.

Condition: used, Year of construction: 2006, operating hours: 5,688 h, Equipment: all wheel drive, Telescopic Boom Lift, JLG 680 S, 4x4 All-wheel Drive, with 4m Platform Basket - Manufacturer: JLG - Model: 680 S - Working height: 22.7 m - Platform height: 20.7 m - Lateral outreach: 18 m - Year of manufacture: 2006 - Hour meter reading: 5,688 hours (read off) - 3-section telescoping steel boom - Powered by 4-cylinder Deutz diesel engine - 2 drive speeds - Tire size: 18-625 NHS - Tread depth: 17-21 mm - Wheelbase: 3,050 mm - Drive configuration: 4x4 - Transport dimensions (L x W x H): 12,250 x 2,520 x 2,980 mm - Weight: 15,953 kg - Platform load capacity: 230 kg - Rotating platform basket - Platform basket in steel construction - Platform basket dimensions (L x W x H): 4,000 x 1,020 x 1,100 mm - Basket and ground controls, oscillating axle, generator Further data and additional images are available upon request. This description does not constitute a binding offer and may contain errors. No guarantee for the accuracy of all information. Lodjymur Tspfx Afasrh Also visit our homepage.

Condition: good (used), Manufacturer CLEARING Model S4-900-180 Condition Used Stock No.0274 Thrust: 900 ton. Thrust points No. 4 Plunger Slide stroke 940 mm. Slide adjustment 762 mm. Number of strokes/min No. 16 Mold clearance at PMI 1,412 mm. Slide size 4,572 mm. x 2,438 mm. Table size 4,572 mm. x 2,130 mm, Pull-out carriage Present Useful front passage 4,622 mm. Lodpfx Afetzy R Njaerh Side passage in the shoulder 1,400 mm. Hydraulic Safety Present Cushion in the Basement Present Bottom plate press stroke 280 mm.

Condition: excellent (used), Manufacturer: ROVETTA Model: S4-600 Year: 2002 Condition: Used Lredew Hci Ijpfx Afaoh Stock number: 0363-0364-0365-0366 Pressing force: 800 tons Number of connecting rods: 4 Drive mechanism: LINK DRIVE Ram stroke: 900 mm Ram adjustment: 500 mm Ram dimensions: 4,500 x 2,300 mm Table dimensions: 4,500 x 2,300 mm Lateral opening in frame: 2,450 mm Usable front passage: 4,500 mm Die space at BDC: max. 1,500 mm, min. 1,000 mm Hydraulic safety device: Present Side removable carriage: Present
