Machining center

MAHO DMU 70 VL - CNC Fräsmaschine 3 Achsen

Condition: like new (used), Niemann Butterfly VKDVB 332-20 Dissolver Vacuum version with Busch vacuum pump Power 15 kW with wall scraper Speed range 0-240 rpm, adjustable via frequency converter Control cabinet Lrodowmaxmepfx Adwsg 3 stainless steel mixing tanks, each 300 l Matching: Niemann/Gehalin H 500 squeezing device D = 700 mm for 300 l mixing tank Top condition, straight from production!

Condition: excellent (used), Year of construction: 2023, CNC Milling and Turning Center Machine type: DMG Mori CLX 450 TC Control: Siemens 840 D sl Operate Slimline Year of manufacture: 2023 TECHNICAL DATA: Max. turning length: 1,100 mm Turning diameter: 400 mm Main spindle: ISM 65 Speed range: 5,000 rpm Drive power: 14 / 17 kW Torque: 275 / 345 Nm Spindle nose: A2-8 Bar capacity: 67 mm C-axis Lrjdpex Ryw Rsfx Adweg CNC spindle swiveling for milling and turning operations Max. speed: 12,000 rpm Drive power: 8.8 / 10.5 kW Torque: 73 / 90 Nm Tool holder: HSK 63 Tool positions: 60 Counter spindle: ISM 65 Spindle nose: A2-8 Max. speed: 5,000 rpm Drive power: 14 / 17 kW Torque: 275 / 345 Nm C-axis X-axis: 750 mm Y-axis: +/- 100 mm Z-axis: 1,100 mm B-axis: +/- 120 mm Features: Chip conveyor Direct position measuring system Chip flushing gun 3-jaw chuck: SMW-Autoblok BBD 250/78 mm 3-jaw chuck: SMW BBD 250/78 mm Tailstock function on counter spindle High-pressure pumps: 8 bar / 20 bar Coolant tank: 600 l Oil mist extraction Probe: Renishaw RMP 40

Condition: used, Year of construction: 1988, Control Grundig x-travel 700 mm y-travel 500 mm z-travel 400 mm weight of the machine ca. 2,8 t +++++ Lsdsiqu S Eopfx Adwjrg Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: excellent (used), Year of construction: 1998, x-travel 800 mm y-travel 600 mm z-travel 500 mm Lodpfxox Dndco Adwjrg

Condition: used, Year of construction: 2007, reus 8000 min-1 U/min Weight 5500 kg Year 2007 Control Siemens 840D Dimensions (L/W/H) 3600 x 2800 x 2400 mm travel -x axis 1035 mm travel -y axis 560 mm travel -z axis 510 mm Ledpfx Ajwm Rqasdworg

Condition: used, max. wheel diameter 180 mm gear width 45 mm max. module 4 min. module 0,5 Ledpju Uu S Tjfx Adwjrg stroke length max. 0 - 52 mm spindle taper innen MK 4 table diameter 160 mm table bore diameter 75 mm no. of strokes 355 - 630 Hub/min feed range 0,008 - 0,4 mm/Hub dimensions of the machine ca. 2,30 x 1,50 x 2,36 m power capacity 6 kW weight of the machine ca. 2.500 kg Year of construction: Approx. 1970

Year of construction: 2010, condition: ready for operation (used), A twin-spindle turning and milling center Mazak is available. Travel X/Y/Z: 580mm/160mm/1545mm, B-axis: 225°, C-axis: 360°, center distance: 1500mm, max. turning diameter: 660mm, swing diameter over bed: 660mm, speed main spindle/counter spindle: 5000rpm, tool stations: 40+9, coolant pressure: 70bar. Machine dimensions X/Y/Z: approx. 5200mm/2550mm/2600mm, weight: approx. 14000kg, spindle hours: 24679h. Including high-pressure coolant, SMW steady rest, SMW chuck, steady rest integration, Renishaw probe, measuring probe, CAD/CAM software Topsolid 7.18, oil skimmer, postprocessor and Inspection-Plus package. The machine was mainly used for finishing. Documentation available. An on-site inspection is possible. Lodpex Ih Dgefx Adwerg

Condition: good (used), Year of construction: 1997, x-travel 600 mm y-travel 450 mm z-travel 400 mm Lsdpfxowbi A De Adwsrg Control Heidenhain 430 ITNC tool taper SK 40 voltage 400 V control voltage 24 V weight of the machine ca. 6 t - Operating hours: 48,690 - Max. table load: 1,000 kg - Machine weight: 6,000 kg - Includes tool holders – SK40 - Includes all descriptions - Includes programming manual – Heidenhain - Includes 1 machine vice - Includes clamping claws

Condition: like new (used), Year of construction: 2021, operating hours: 1,200 h, X 800 mm H 460 mm Z 510 mm Control FANUC Lredpev Th E Ajfx Adwsg Chip Conveyor Including 4-axis Rotary table.

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, Control: Mazatrol M Plus Travel paths: x-1660 y-760 z-660 mm Clamping surface to spindle head: 155 – 815 mm Distance from column to spindle center: 808 mm Ljdjvrxd Hopfx Adwjrg Spindle inner taper: SK 40 Tool changer: 24 – compartment Spindle speeds: 7000 rpm Usable table area: 2000 x 760 mm Table load: 1000 kg Rapid traverse x, y axis: 24000 mm/min Rapid traverse z axis: 20000 mm/min Feed: 1 – 5000 mm/min Machine weight: approx. 8700 kg including chip conveyor, coolant system The machine can be inspected under power.
