Machining Center - Horizontal

MORI SEIKI NHX 4000 -206

x-travel 560 mm
y-travel 560 mm
z-travel 660 mm
Control M 730 BM MAPPS IV
distance spindle center to table 80 - 640 mm
distance Spindlenose and center of table 70 - 730 mm
max. spindle speed 12.000 min/-1
power capacity - main spindel 15 / 11 kW
tool taper SK 40
spindle diameter in front bearing 80 mm
numbers of pallets 2 pos.
work height max. 1.050 mm
size of pallet 400 x 400 mm
max. workpiece weight 400 kg
max. workpiecediameter 630 mm
Max. workpiece - hight 900 mm
B-Axis 0,001 °
Indexing-time 90° 1,3 sec
change time of pallets 8,0 sec
number of toolpositions 60 pos.
tool taper SK 40
max. tool diameter 70 mm
Gsdpfx Ahjx Hpyme Deca
max. tool-dia with free toolbox 170 mm
max. tool length 450 mm
max. tool weight 8 kg
change-time tool to tool 0,9 sec
change-time chip to chip 2,8 - max. 9,9 sec
feed speeds max. 60.000 mm/min
rapid traverse ( X / Y / Z ) 60 m/min
total power requirement 35 kVA
weight of the machine ca. 7,9 t
dimensions of the machine ca. 5,5 x 3,5 x 2,6 m
CNC - MachiningCenter Horizontal
MORI SEIKI - NHX 4000

- pallet-changer
- WITHOUT clamping towers
