Used Arburg 3D Printer for sale (349)

Condition: excellent (used), Year of construction: 2004, Arburg 320C 500-100 / Excellent technical condition Year of construction: 10.2004 Injection unit: Screw diameter: 25 mm Injection weight: 45 g Injection pressure: 2000 bar Metering volume: 49 ccm Clamping unit: Clamping force: 50 t Distance between tie bars: 320x320 mm Size of the clamping platens: 446x446 mm Ejector: hydraulic Clamping unit: hydraulic Control system: SELOGICA Additional equipment: The machine is in excellent technical condition and was used for testing injection molds Operating hours: 25,739 h in automatic mode Total number of operating hours: 30,661 h Hydraulic core pull x 1 Reinforced injection units - bimetal Proportional valve on the injection unit - precise injection Built-in pressure quality control system from the Sensor Kistler brand - mold pressure measurement It is possible to change the screw diameter to smaller or larger: 20 mm or 30 mm Ppjdpfxjycr Dxj Afhol Dimensions Weight: 2300 kg Length/width/height: 3.18x1.47x1.99 m Drive: Pump/motor: 15 kW Heating output: 4.9 kW Total output: 19.9 kW All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2011, Arburg 320C 500-170 Year of construction: 2011 Injection unit: Screw diameter: 35 mm Injection weight: 105 g Injection pressure: 1470 bar Metering volume: 115 ccm Clamping unit: Clamping force: 50 t Distance between tie bars: 320x320 mm Size of the clamping platens: 446x446 mm Ejector: hydraulic Clamping unit: hydraulic Control system: SELOGICA touchscreen Ppodpfx Asycr Dlefhol Additional equipment: Operating hours: approx. 35,000 h in automatic mode Control system with air valve Core pull control Hardened injection unit - bimetal Proportional valve on the injection unit - precise injection Original Demag mold crane: chain, electrically controlled, 2 lifting speeds Dimensions: Weight: 2310 kg Length/width/height: 3.41x1.47x1.99 m Drive: Pumps/motor: 11 kW Heating output: 9.4 kW Total output: 20.4 kW All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2006, Arburg 320C 500-170 with the Wittmann W811 robot Year of construction: 12/2006 Injection unit: Screw diameter: 30 mm Injection weight: 77 g Injection pressure: 2000 bar Dosing volume: 85 ccm Clamping unit: Ppsdpfjycr A Isx Afhol Clamping force: 50 t Distance between tie bars: 320x320 mm Size of the clamping platens: 446x446 mm Ejector: hydraulic Clamping unit: hydraulic Control system: SELOGICA touchscreen Additional equipment: Euromap 67 Robot interface Air valve x 1 Hydraulic core pull x 1 Hardened injection unit - bimetal Proportional valve on the injection unit - precise injection Built-in sorting flap Robot Wittmann W811 Year of construction: 2010 4-axis robot: 3 axes are driven by servomotors (electric); axis C - pneumatic Travel in axes: X-420, Y-1200, Z-1500 Touch control panel The safety package for robots Robot with adapter, protective housing Purchase of the robot for an additional charge Dimensions Weight: 2400 kg Length/width/height: 3.41x1.47x1.99 m Drive: Pumps/motor: 11 kW Heating output: 9.4 kW Total output: 20.4 kW All offered machines are started by our service technicians before sale. It is possible to obtain a video of the technical tests of the selected machine or participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2007, Arburg 270C 400-70 Year of manufacture: 2007 Injection Unit: Screw diameter: 22 mm Shot weight: 31 g Injection pressure: 2000 bar Dosage volume: 34 ccm Clamping Unit: Clamping force: 40 t Tie bar spacing: 270x270 mm Platen size: 446x446 mm Ejector: hydraulic Clamping unit: hydraulic Control system: SELOGICA - Touchscreen Additional equipment: Euromap 67 Robot interface 2x air valves 1x hydraulic core pull Hot runner control Injection unit hardened - bimetallic Proportional valve on the injection unit – precise injection Screw diameter change possible Dimensions: Weight: 2370 kg Length/Width/Height: 2.99x1.43x1.98 m Pedpsycr Abjfx Afhspl All offered machines are started and tested by our service technicians prior to sale. It is possible to receive a video of the technical tests of the selected machine or participate in live technical tests at our facility in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2005, Arburg 320A 500-170 with the sprue picker / electric machine Year of manufacture: 2005 Injection unit: Screw diameter: 35 mm injection weight: 105 g Injection pressure: 1470 bar Metering volume: 115 ccm Clamping unit : clamping force: 50 t tie bar distance: 320x320 mm size of clamping platens: 446x446 mm ejector: electric clamping unit: toggle lever Control system: SELOGICA Ppodpoycry Tsfx Afhel Additional equipment: Electric machine: high speed, energy saving and very quiet. Euromap 67 Robot interface injection unit hardened - bimetal Central lubrication Machine with the built-in conveyor belt Arburg and original sorting flap Dimensions: Weight: 3500 kg Length/width/height: 3.41x1.43x1.99 m Drive: Pumps/motor: 10.2 kW Heating power: 5,5 kW All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request

Condition: excellent (used), Year of construction: 2016, Arburg 270C 400-70 e² with Arburg Multilift Robot / Hybrid Machine Year of manufacture: 2016 Injection Unit: Screw diameter: 22 mm Shot weight: 31 g Injection pressure: 2000 bar Dosage volume: 34 ccm Pedoycq Ipopfx Afhopl Clamping Unit: Clamping force: 40 t Tie bar spacing: 270x270 mm Platen size: 446x446 mm Ejector: hydraulic Clamping unit: hydraulic Control system: SELOGICA - Touchscreen Additional Equipment: Hybrid machine: energy efficient and extremely quiet Euromap 67 Robot interface Air valve x 2 Hydraulic core pull x 1 Injection unit hardened - bimetallic Main machine motor - servo motor with inverter drive - energy saving Proportional valve on injection unit – precise injection Self-sealing nozzle Arburg Multilift Select 6 kg traverse robot Year of manufacture: 05.2016 5-axis robot: 3 axes driven by servo motors (electric); axes B and C Travel paths in axes: X-600, Y-800, Z-1000 Robot with adapter, conveyor belt, and safety enclosure Purchase of robot and conveyor belt available at extra cost Dimensions: Weight: 2210 kg Length/Width/Height: 3.18x1.43x1.98 m All machines offered are started up by our service engineers before sale. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 2012, Arburg 680CB 400-170 / Vertical injection molding machine, tie-bar-less / Very good technical condition. Year of manufacture: 2012 Injection unit: Screw diameter: 25 mm injection weight: 54 g Injection pressure: 2500 bar Metering volume: 59 ccm Clamping unit : clamping force: 40 t Ppsdpfx Afoycq Hljhsl tie bar distance: 0x0 mm Ejector: hydraulic Clamping unit: hydraulic Control system: SELOGICA - touch screen Additional equipment: Very good technical condition Vertical injection molding machine, tie-bar-less Euromap 67 Robot interface Air valve x 3 Hydraulic core puller x 3 Hot runner control x 12 Injection unit hardened - bimetal Proportional valve on the injection unit - precise injection It is possible to change the screw diameter The machine has been regularly serviced by the authorized service Arburg Original Arburg mold crane Dimensions: Weight: 6500 kg Length/width/height: 1.97x1.69x3.40 m All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request

Condition: excellent (used), Year of construction: 2008, Arburg OK-C S350-60 / Vertical injection molding machine with sliding table / Very good technical condition Year of manufacture: 2008 injection unit: screw diameter: 18 mm injection weight: 18 g injection pressure: 2500 bar Dosing volume: 20 ccm Clamping unit: Clamping force: 35 t tie bar distance: 0x0 mm size of clamping platens: 295x395 mm ejector: hydraulic clamping unit: hydraulic Control system: SELOGICA - touch screen Additional equipment: Vertical injection molding machine with sliding table 3 stations on the sliding table Air valve x 4 Hydraulic core pull x 1 Control system with hot runners Injection unit hardened - bimetal Parallel movements Infrared protection curtains It is possible to change the screw diameter Dimensions: Weight: 2500 kg Length/width/height: 2.55x1.85x3.52 m Ppjdeycq E Ijpfx Afhsl All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request

Condition: excellent (used), Year of construction: 1997, Arburg 220M 350-90 Year of manufacture: 1997 Injection Unit: Screw diameter: 25 mm Shot weight: 41 g Injection pressure: 1860 bar Dosage volume: 49 ccm Clamping Unit: Clamping force: 35 t Tie bar distance: 221x221 mm Platen size: 346x346 mm Ejector: hydraulic Clamping unit: hydraulic Control system: MULTRONICA Additional equipment: Perfect technical condition Ppodoycq Enepfx Afhel Operating hours: 19,000 h The machine was used in a company producing packaging for the food industry Dimensions: Weight: 1620 kg Length/Width/Height: 3.30x1.70x1.94 m Drive: Pump/motor: 11 kW Heating capacity: 4.6 kW Total power: 15.6 kW All machines offered are started up by our service technicians prior to sale. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in Łódź. Price: On request

Condition: excellent (used), Year of construction: 1999, Arburg 221KS 250-75 / Universal machine Year of manufacture: 1999 injection unit: Screw diameter: 20 mm injection weight: 26 g Injection pressure: 2350 bar Metering volume: 31 ccm Clamping unit: Clamping force: 25 t tie bar distance: 221 mm size of clamping platens: 342x250 mm ejector: hydraulic clamping unit: toggle lever Control system: SELOGICA Additional equipment: Ppsdpfx Afsycq D Dehel Universal machine - injection unit can run both vertically and horizontally Control with air valve Core pull control injection unit hardened - bimetal Clamp for fixing the injection unit vertical Dimensions: Weight: 1150 kg Length/width/height: 2.63x1.34x1.93 m Drive: Pump/motor: 5.5 kW Heating power: 4,6 kW Total power: 10,1 kW All offered machines are started by our service technicians before sale. It is possible to get a video of technical tests of the selected machine or participate in live technical tests in our company in Łódź. Price: Upon request

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, clamping force: 1,000 kN, Equipment: documentation/manual, Clamping force: 100 t Screw diameter: 35 mm Distance between tie bars V: 420 mm Distance between tie bars H: 420 mm Shot volume: 144 cm3 Type: Horizontal Drive: Hydraulic Podpfjycvw Asx Afhspl Hours: 46000

Condition: excellent (used), Year of construction: 2011, Screw diameter: 15 mm Podexzzw Djpfx Afhjpl Clamping force: 700 kN Opening stroke: 400 mm Tool plates: 510 x 510 mm Incl. handling robot Incl. complete manual Incl. WITTMANN temperature control unit

Condition: like new (used), Year of construction: 2014, Arburg 320 C 500-170 (2014) Working hours : 44.124 h Clamping force: 50 t Screw diameter : 25 mm Shot weight : 75 g Clamping force: 500 kN Distance between tie bars: 320 × 320 mm Platen size (H × V): 446 × 446 mm Minimum mould height: 200 mm Maximum daylight opening: 550 mm Ejector stroke: 125 mm Screw diameter: 30 mm Maximum shot volume: 85 cm³ Maximum shot weight (PS): 77 g Injection pressure: 2000 bar Screw speed max: 400 r/min Nozzle stroke: 250 mm Nozzle contact pressure: 40.6 kN Heating capacity: 9.4 kW Pump drive power: 11 kW Total installed power: approx. 20.5 kW L 3.4 m x W 1.4 m x H 2.0 m Weight :2 400 kg Injection Unit Thermoplastics injection unit, 25 mm screw, high wear-resistant design Standard screw coupling with flat-ended geometry Open nozzle, 25 mm Nozzle tip for open nozzle Heater band for open nozzle Clamping Unit Psdpfx Afsxqdtajhjpl Mounting platen set, central diameter 125 mm Core pull 1, serial movement, holding pressure via check valve Hydraulic ejector Ejector quick-coupling Connector for ejector platen protection

Condition: like new (used), Year of construction: 2015, Arburg 320 C 500-170 (2015) Golden edition Working hours : 40.167 h Clamping force: 50 t Screw diameter : 30 mm Clamping force: 500 kN Distance between tie bars: 320 × 320 mm Platen size (H × V): 446 × 446 mm Minimum mould height: 200 mm Maximum daylight opening: 550 mm Ejector stroke: 125 mm Screw diameter: 30 mm Maximum shot volume: 85 cm³ Maximum shot weight (PS): 77 g Injection pressure: 2000 bar Screw speed max: 400 r/min Nozzle stroke: 250 mm Nozzle contact pressure: 40.6 kN Heating capacity: 9.4 kW Pump drive power: 11 kW Total installed power: approx. 20.5 kW Machine length: approx. 3.4 m Machine width: approx. 1.4 m Machine height: approx. 2.0 m Machine weight: approx. 2 400 kg 2 pumps machine Machine Equipment / Configuration Control system: Selogica Direct controller Hydraulic system: Dual-pump hydraulic system Injection Unit Thermoplastics injection unit, 30 mm screw, high wear resistant design Standard screw coupling with flat-ended geometry Open nozzle, 30 mm Nozzle tip for open nozzle Heater band for open nozzle Clamping Unit Mounting platen set, central diameter 125 mm Ppjdpfoxqdxiox Afhel Core pull 1, for serial movement, holding pressure via check valve Interfaces & Connectivity Robot interface EUROMAP 67 (50-pin) Interface for electrical safety interlock on safety door EUROMAP 73

Condition: like new (used), Year of construction: 2020, Clamping force: 25 ton Version: Shuttle table Ppjdpfx Asvl Skasfhsl Opening force/stroke min.- max. : 100/225 mm Mould height variable min.- max. : 122-222 mm Shuttle table stroke: 500 mm Wight on shuttle table. max. :120 kg Ejector force/stroke max. : 16/40 kN/mm Screw: 22 mm Effective screw length L/D : 20 Screw stroke max. : 90 mm Stroke volume: 34 cm3 Shot weight: 31 g Injection pressure: 2000 bar Working hours: 7397 h

Condition: like new (used), Year of construction: 2017, Clamping force: 25 ton Version: Shuttle table Opening force/stroke min.- max. : 100/225 mm Mould height variable min.- max. : 122-222 mm Shuttle table stroke: 500 mm Wight on shuttle table. max. :120 kg Ejector force/stroke max. : 16/40 kN/mm Screw: 22 mm Ppjdju Epy Nopfx Afhol Effective screw length L/D : 20 Screw stroke max. : 90 mm Stroke volume: 34 cm3 Shot weight: 31 g Injection pressure: 2.000 bar Working hours: 12.500 h

Condition: like new (used), Year of construction: 2019, Arburg 1200 T 2000-800 Clamping unit 2000T Table diameter: 1200mm Angle rotation: 180 degrees Clamping force: 200 tons Opening force max. kN/mm: 115/500 Injection unit Screw diameter: 45 mm Shot volume: 318 cm3 Shot weight: 291 g Injection pressure: 2470 bar Psdpfx Aswugczefhepl 1. Model: T model 2. Machine type: 1200 T 2000 - 800 3. Plasticizing unit: Thermoplastics cylinder 45 mm, highly wear-resistant 4. Screw: Reinforced screw coupling for splined coupling geometry 5. Control system: SELOGICA ‘direct’ controller 6. Technology stage: Stage 2 servo-regulated with 2 control pumps 7. Rotary table: Advanced ergonomics special model, 2-station 180° forward/backward alternating 8. Nozzle: Open nozzle 45 mm with nozzle tip 9. In-mould needle nozzles: Electric & hydraulic control for needle nozzle 1, electric & pneumatic control for needle nozzle 2 10. Heating: Heater band for open nozzle, 9 electric heating control circuits for mould heating 11. Clamping platen: Mould mounting platen set, central diameter 125 mm 12. Blow unit: Mould blow unit with pressure reducer at station 1 13. Safety: Optical barrier at loading station, continuous oil cooling and filtration 14. Hopper: Adapter (extension) for feed hopper, machine delivered without 50 L hopper 15. Robot interface: Interface for robot system for station 2 & 3 (based on EM67/1) 16. Electric axes: Basic equipment for electric axes control 17. I/O: 4 programmable inputs/outputs on terminal rail 18. Sockets: Additional socket combination (1 CEE, 1 Schuko) 19. Interfaces: Temperature control device interface (REGLOPLAS), printer USB interface, Compact Flash, EUROMAP 65 chip card user authorisation 20. Acoustic alarm: Error alarm acoustic signal 21. Safety interlock: Interface for safety interlock of door (EUROMAP 73) 22. Cooling circuits: 3 regulated machine-related cooling circuits with flow indicator, 3 manually adjustable cooling circuits for second water manifold 23. Anti-corrosion: Anti-corrosion treatment for rotary table, sealing lip on outer diameter 24. Manual & labels: CD operating manual & spare parts list, Slovak language labels 25. Machine feet: Anti-vibration footplates 26. Other: Hydraulic ejector, external cycle start key, standard equipment packages, new ARBURG colour scheme 27. Display languages: IT/EN/SK

Condition: excellent (used), Year of construction: 2019, Clamping force 500 kN Opening force 40 kN Opening stroke 250 mm Screw diameter 15 mm Including 2 pcs. WITTMANN temperature control units Including spare screw 15 mm Psdpfx Afsxrymlshopl Including complete documentation Immediately available from stock

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, clamping force: 2,000 kN, Equipment: documentation/manual, Clamping force: 200 t Screw diameter: 55 mm Shot weight: 434 g Distance between tie bars V: 570 mm Distance between tie bars H: 570 mm Shot volume: 474 cm3 Platen dimensions : 795 x 795 mm Working hours: 25.969 h Type: Horizontal Drive: Hydraulic Ppedpex Ir Ngofx Afhol Equipment: 1x core puller Euromap 67

Condition: good (used), Year of construction: 2010, Clamping force: 200 t Screw diameter: 35 mm Shot weight: 141 g Distance between tie bars V: 570 mm Distance between tie bars H: 570 mm Shot volume: 154 cm3 Screw stroke: 160 mm Injection pressure: 2000 bar Type: Horizontal Drive: Hybrid Equipment: Thermoplastics cylinder cpl. 35 mm high-wear resistance Ppjdpfx Afswpkfcehsl Drive unit w. 11 kW motor and 21.4 l/min capacity SELOGICA 'direct' controller Air blast system 1 with pressure reducer Interface for robot system (EUROMAP 67), 50-pin AED - electrom. dosage drive 9 electr. heating control circuits for mould heating Interface for colouring device 8 free cooling circuits manually adjustable Position-regulated screw

Condition: excellent (used), Year of construction: 2015, clamping force: 1,300 kN, Arburg 520S 1300-400 (2015) Clamping force: 130 t Screw diameter: 40 mm (higly wear resistant) Shot weight: 184 g Distance between tie bars V: 520 mm Distance between tie bars H: 520 mm Min/Max mould height: 350mm Opening stroke: 925mm Shot volume: 201 cm3 Type: Horizontal Drive: Hydraulic (Arburg servohydraulics) Ppsdpfxewv Hrxs Afhol Hours: 28.000 hours only! \+ Apex Sprue picker robot 4 free cooling circuits Core puller: 1

Condition: used, Year of construction: 2006, (2006) Arburg 420 C 800-350 DUROPLAST Clamping force: 80 ton Screw dia: 40mm Weight 3400 kg Ppedpfx Afsuy Sdtshol Machine used for Bakelite production (DUROPLAST)

Condition: good (used), Year of construction: 1998, Arburg 270S 500-150 (1998) Clamping force: 50 t Screw diameter: 25 mm Distance between tie bars V: 270 mm Distance between tie bars H: 270 mm Type: Horizontal Drive: Hydraulic Ppsdpfjxl Hpgox Afhjl

Condition: ready for operation (used), Year of construction: 2016, operating hours: 37,049 h, clamping force: 4,000 kN, overall weight: 21,000 kg, This Arburg 820 S 4000 - 2100 was manufactured in 2016. It features a clamping force of 4000 kN, a screw diameter of 60-100 mm, and a shot weight up to 1860 g. The machine is equipped with a SEPRO SR AXESS 30 S3 robot and has a hydraulic pump drive power of 55 kW. Ideal for precision in plastic injection molding. Contact us for more information about this machine. Clamping unit • Locking force (max.): 150 kN • Opening force (max.): 100 kN / increased: 800 kN • Opening stroke (max.): 700 mm • Mold height (min.): 350 mm • Distance between platens (max.): 1050–1550 mm • Clear tie bar distance: 820 × 820 mm • Mold mounting platens (W × H): 1171 × 1171 mm • Mold half weight (max.): 4500 kg • Ejector force (max.): 100 kN • Ejector stroke (max.): 250 mmHydraulics / drive / miscellaneous • Hydraulic pump drive power: 55 kW • Installed total power: • 4000-2100: 88.9 kW • 4000-3200: 96.2 kW • Color: Plastic-coated structure (light gray / mint green / rapeseed yellow) • Control cabinets: Safety regulation DIN EN 60204 • Socket combination: 1 Schuko + 1 Cekon • Injection unit power supply: 1 × 16 AInjection unit • Effective screw length (L/D): 23/20/17.5 | 70/80/90 | 23/20/18 • Screw diameter (mm): 60/65/70 | 80/90/100 | 60/65/70 • Theoretical shot volume (max., cm³): 792/1078/1407 | 2513/3462/4240 | 1132/1608/2036 • Shot weight (max., g PS): 293/384/1826 | 1255/1469/1860 | 820/1167/1477 • Injection pressure (max., bar): 2500/2000/1530 | 2500/1500/1200 | 2500/2000/1530 • Injection flow rate (max., cm³/s): 294/362/400 | 812/1030/1250 | 312/396/440 • Injection flow rate with accumulator (max., cm³/s): 354/450/502 | 1188/1552/1964 | 375/475/528 • Back pressure positive/negative (max., bar): 350/50 | 350/50 | 350/50 • Screw circumferential speed (max., m/s): 0.38 | 0.28 | 0.28 • Screw torque (max., Nm): 2057/2247/2247 | 6757/80 | 2057/2247/2247 • Nozzle contact force (max.): 110 kN • Nozzle stroke (max.): 600 mm Pjdsydpvbopfx Afhjpl • Heating zones / heating capacity: 6 × 4500 + 3300 | 6 × 5500 + 4300 • Installed nozzle heating: 1000 W | 1250 WDimensions and weights (base machine) • Clearance length: 490 mm • Electrical connection (fuse protection) motor + heating: 250 A • Electrical connection (fuse protection) motor: 125 A • Electrical connection (fuse protection) heating: 50 / 63 A Additional equipment • SEPRO SR AXESS 30 S3 robot (2008)

Condition: ready for operation (used), Year of construction: 2007, clamping force: 5,000 kN, overall weight: 26,400 kg, This 3-axis Arburg Allrounder 920S 5000-3200 hydraulic injection moulding machine was manufactured in 2007. It features a maximum clamping force of 5,000 kN, a screw diameter range of 70 to 90 mm, and a maximum shot weight up to 1,860 g. Consider the opportunity to buy this Arburg Allrounder 920S hydraulic injection moulding machine. Contact us for more information about this machine. • Maximum mold opening force: 150 kN • Enhanced opening force: 100 / 1,000 kN • Opening stroke: up to 900 mm • Mold height: min. 400 – max. 1,050 mm • Distance between platens: 1,300 – 1,950 mm • Tie-bar spacing (H × V): 920 × 920 mm • Platen size (W × H): 1,280 × 1,280 mm • Movable platen weight (half): max. 8,000 kg • Ejector force: max. 800 kN • Ejector stroke: max. 250 mm Hydraulics / Drive • Hydraulic pump motor power: 75 kW • Dry cycle time (opening stroke 5): 4.5–6.44 s • Installed total power: 96 kW • Color: Structural light gray / mint green / red-yellow Psdpfxsydnigs Afhspl • Control cabinet safety standard: DIN EN 60204 • Socket combination: 1 × Schuko, 1 × CEE Injection Unit • Screw diameters: 70 / 80 / 90 mm • Effective screw length (L/D): 23 / 20 / 18 • Maximum shot volume: 1,232 / 1,608 / 2,036 cm³ • Maximum shot weight (PS): 1,125 / 1,469 / 1,860 g • Plasticizing capacity (PS): 185 / 215 / 250 kg/h • Maximum injection pressure: 2,500 / 2,000 / 1,580 bar • Injection rate: • Without accumulator: 290 / 380 / 482 cm³/s • With accumulator: 1,188 / 1,552 / 1,964 cm³/s • Holding pressure: max. 350 / 200 bar • Screw speed: 47 / 54 / 61 rpm • Screw torque: 3,500 Nm • Nozzle contact force: max. 110 kN • Nozzle stroke: max. 675 mm • Installed barrel heating power: 6 × 5,500 + 4,300 W • Installed nozzle heating power: 1,100 W • Oil fill volume: 590 liters • Motor + heating fuse rating: 200 A • Motor fuse: 125125 A • Heating fuse: 63 A
