Used Cnc Horizontal Lathe for sale (16,140)

Condition: new, The Basic 170 Super PRO is a high-performance Conventional Horizontal Lathe from the renowned brand KNUTH, designed specifically for metalworking applications. Over the years, the Basic series has established itself as a reliable choice for mechanics, featuring a modern ergonomic design and extensive standard equipment to meet the demands of contemporary users in workshops and training centers. This lathe boasts a turning diameter over bed of 354 mm and a center width of 1,000 mm, providing robust construction from high-quality cast iron for maximum stability. With hardened and ground gears for quiet operation, adjustable spindle bearings for precision, and an effective coolant system, the Basic 170 Super PRO ensures long tool life and minimal maintenance. It also features ample storage for accessories and an easy-to-use position indicator for auxiliary functions. For universal applications in repairs, training, and production, you can request a quote for this exceptional Conventional Horizontal Lathe today. Kodpfx Aeuyhvxeanonf

Condition: good (used), Year of construction: 1990, functionality: fully functional, CNC Lathe YCM TC-2 Item number: 04-02-090 Manufacturer: YCM Good overall condition Workshop-tested machine Delivery time: Immediately – subject to prior sale Year of manufacture: approx. 1990 Dimensions (L x W x H): approx. 2400 x 1400 x 2100 mm Weight: approx. 3600 kg Control: Fanuc O-T Technical specifications: Swing over bed: approx. 480 mm Swing over cross slide: approx. 310 mm Spindle bore: approx. 52 mm Max. machining diameter: approx. 250 mm Distance between centers: approx. 550 mm Spindle speed range: approx. 110–3500 rpm Feed rate X-axis: approx. 10 m/min Feed rate Z-axis: approx. 15 m/min Turret: 8 stations Accessories: 3-jaw chuck Various tool holders Chip conveyor Knodpfx Aswfw Sujanjf Machine leveling feet Documentation Live center Various chuck jaws Further accessories available on request. Price and additional technical details available upon request.

Condition: good (used), Year of construction: 1996, Chuck size: 203 mm or 8 inch Maximum turning diameter: 435 mm Maximum turning length: 254mm journey X-axis rapid traverse speed: 16 m/min Z-axis rapid traverse speed: 20 m/min X-axis stroke: 230mm Z-axis stroke: 330 mm Spindle Maximum spindle speed: 4000rpm Maximum spindle power: 18,5kW Maximum spindle torque: 156 Nm Kjdpfx Aeqctr Heansnf Dimensions LxWxH: 22006x1750x1800mm weight: 4300kg

Condition: ready for operation (used), Max. swing over bed: 528 mm Max. swing over cross slide: 370 mm Max. turning length: 785 mm Spindle bore: 77 mm Main spindle speed range: 20 - 3,500 rpm Tool turret: 12 positions Control: FANUC O-T Knodpfsx Hx A Dox Aanof Year of manufacture: 2000 Machine weight approx.: 6,200 kg

Condition: like new (used), Year of construction: 2021, functionality: fully functional, machine/vehicle number: LU3000EX, Power kVA: 34.2 Kodex Hg Eyopfx Aanjnf

Condition: excellent (used), Year of construction: 2005, machine/vehicle number: P15143, Manufacturing origin JP Voltage 400 V Netweight 2400 kg Dimensions 2450x1320x1700 mm mm with bar-feeder LNS Express 200 TECHNICAL DATA Main spindle Max machining diameter Ø 16 mm Max turning length, without re-chucking 200 mm Through-hole diameter Ø 20 mm Speed 10'000 min-1 Indexing 0,001° Drive 2,2 kW Sub-spindle Max machining diameter Ø 16 mm Knodpfxegfqu So Aanof Speed 10'000 min-1 Indexing 0,001° Drive 0,75 kW No. of rotary tools at vertical tool holder 4 Speed of rotary tools 8'000 min-1 Drive power 0,75 kW No. of tools at turret 10 Speed of rotary tools 6’500 min-1 Drive power 0,75 kW Tools 5 Drill holder for back machining 3/2 rotary (option) Collet sleeve diameter Ø 19,05 mm Tool holders, rotary tools (shank section) 10 mm Collet type (spindle and sub-spindle) F20 (138E) Drill collets ER11 Guide bush(Neukomm) F605 (61.002) Rapid feed rates, all axes 20m/min errors and omissions excepted-data given without obligation

Condition: new, The V-Turn 410/1000, part of the Conventional Horizontal Lathes category and under the Engine Lathes group, is a precision lathe that excels in both precision and production applications. This bestselling machine features a robust inverter and a high-performance 5.5 kW motor that enables spindle speeds of up to 3,000 RPM, ensuring efficient processing of workpieces with small diameters. The constant cutting speed function automatically adapts to the turning diameter during face turning, delivering superior quality akin to that of CNC machines. Built on a heavy ribbed machine bed and a solid one-piece cast-iron frame, the V-Turn provides exceptional stability for heavier machining tasks. With its wide, hardened guideways and large spindle bearings, it guarantees excellent concentricity and longevity. The extensive standard equipment includes a 3-axis position indicator, coolant system, and a quick change tool holder, among others. Experience the precision of KNUTH's V-Turn 410/1000—request a quote today and enhance your machining capabilities in the Conventional Horizontal Lathe category and Engine Lathes group. Knjdpfx Asp Aua Usanjf

Condition: used, functionality: fully functional, turning diameter over cross slide: 280 mm, turning length: 600 mm, turning diameter: 230 mm, spindle speed (max.): 4,500 rpm, overall weight: 3,500 kg, CNC LATHE GOODWAY GCL-2L (1997) For sale Goodway GCL-2L CNC lathe, year 1997. A robust and reliable turning center well suited for general machining, subcontracting, and small to medium batch production. Equipped with FANUC OT control, this machine offers proven performance and easy operation. Technical specifications: Turning length: 600 mm Max. turning diameter: Ø230 mm Swing over bed: Ø400 mm Swing over cross slide: Ø280 mm Distance between centers: 462 mm CNC control: FANUC OT X-axis travel: 125 mm Kjdpfx Aex Hr T Asanonf Z-axis travel: 340 mm Spindle bore: 52 mm Max. spindle speed: 4500 rpm Spindle motor power: 15 kW Number of turrets: 1 Tools on turret: 8 Rotating tools: 6 Tailstock: No Bar feeder: No Machine dimensions (L × W × H): 2100 × 1300 × 1700 mm Machine weight: approx. 3500 kg General: Heavy-duty and stable construction Proven Goodway build quality Reliable FANUC control system Suitable for subcontracting and workshop use Ideal for both single-piece and small series production The deal includes a bar feeder. Ask quote including transportation. Verify all specifications with the seller.

Condition: used, Year of construction: 2006, Empty weight: 4.000 kg Price: On request What are Presale Items at Second Owner? Presale items are machines that we sell in their current condition ("as-is"). We have purchased these machines based solely on photos and sell them with the information provided in the advertisement. Unfortunately, we do not have additional details, such as exact dimensions or machine specifications. Additionally, these machines are often not yet in stock and have not been inspected by us. These machines are offered at competitive prices, which means the prices are lower than usual, but the risk lies entirely with the buyer. Please carefully review the information in the advertisement before making a purchase. If you have any questions, feel free to contact us! - Machine available from: 2026-05-25 - Year: 2006 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 5 - - Min. spindle speed [rpm]: 600 - - Max. spindle speed [rpm]: 20000 - - Main motor power [kW]: 11 - - C-axis present: Yes - Type milling table: Beam table - Tool clamping system: HSK-F63 Knjdpex Hfiksfx Aanof - Drilling unit present: Yes - └ Horizontal drill spindles [pcs.]: 6 - └ Vertical drilling spindles [pcs.]: 12 - Saw unit present: Yes - Tool changer positions [pcs.]: 16 - System/software: Xilog plus - Safety feature: Safety mat - Vacuum pump present: Yes - └ Main motor power [kW]: 5.5 - └ Capacity [m³/h]: 250 - CNC options: Offcut conveyor, Manual control - Table length [mm]: 3050 - Table width [mm]: 1240 - Z-axis working range [mm]: 200 - X-axis maximum stroke [mm]: 3500 - Y-axis maximum stroke [mm]: 1815 - Z-axis maximum stroke [mm]: 440 - Transport weight [kg]: 4000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: ready for operation (used), Max. swing over bed: 460 mm Max. swing over cross slide: 230 mm Max. turning length: 810 mm Spindle bore: 56 mm Main spindle speed range: 20 – 3,100 rpm Tool turret: 8-position VDI30 Knedpfx Aajx Hx Aqjnsf Control: FANUC Oi-TC Year of construction: 2007 Machine weight approx.: 6,200 kg

Condition: used, Year of construction: 1998, turning length: 800 mm, turning diameter: 600 mm, spindle bore: 127 mm, spindle speed (max.): 2,500 rpm, travel distance X-axis: 345 mm, travel distance Z-axis: 995 mm, Mori Seiki SL-400B CNC Lathe (1998) Machine Type: CNC Turning Center (2-Axis) Knjdsx Hpw Sopfx Aansf Year of Manufacture: 1998 Control System: Mori Seiki MSC-501 Machining Capacity Maximum Turning Diameter: approx. 600 mm Maximum Turning Length: approx. 800 mm Distance Between Centers: approx. 940 mm X-Axis Travel: approx. 343 mm Z-Axis Travel: approx. 993 mm Spindle Nose: A2-11 Spindle Bore: approx. 127 mm (5") Spindle Speed: up to 2,400 rpm Spindle Motor Power: approx. 30 kW Tool Turret: 12 Stations Machine Weight: approx. 9,500 Machine Dimensions (L × W × H): approx. 4,300 × 2,000 × 2,100 mm

Year of construction: 2010, condition: excellent (used), machine/vehicle number: 9589 (232-0001), Manufacturing origin CH Netweight 1600 kg Custom position 8458.9120 Dimensions 167x87x165 cm With bar-feeder LNS Tryton 112 TECHNICAL DATA Control Fanuc série 32i-B 5 linear axes : Longitudinal travel of main spindle Z1 Longitudinal travel of backwork counter spindel Z4 Cross travel of tools X1 (turning operations and cross milling) Cross travel of tools Y1 (tools selection and milling operations) Radial plunge of 2 tools (T21 et T22) X2 Spindel (mounted on Z1-axis) : Max bar capacity 10 mm Work travel 20 mm Type of drawed collet W15 Max speed 15'000 min-1 Linear tools system mounted on 2 axes X1 and Y1 Kodpfx Ajf Nqzqoanonf Tools system for turning comprising 2 slides controlled by X2-axis Backwork counter-spindle with motor (on axis Z4) : Max clamping 10 mm Work travel 120 mm Type of pushed collet F13 (76-00357) Max speed 15'000 min-1 Spindles denomination S1 et S4 Least increment for axes programming 0.1 µ Coolant pump max flow 50 L/min Pump motor 1,1 kW Oil tank 130 L errors and omissions excepted-data given without obligation

Condition: as good as new (ex-display), The Numturn 500/1500 FA is a precision CNC Flat Bed Lathe designed for a wide range of applications, making it an excellent choice for the CNC Flat Bed Lathes category. With a robust construction featuring heavy ribbing of the machine frame and wide hardened V-guides, this lathe is engineered for heavy-duty machining. The Fagor 8055i control enhances your workshop programming experience, while the automatic 8-station servo-driven tool turret significantly increases productivity and flexibility for both single part and small batch production of larger workpieces. Its hydraulic power chuck offers adjustable holding force, and the heavy-duty tailstock provides high clamping force for secure machining. The completely lockable enclosure and smart central lubrication system contribute to a low-maintenance operation, allowing for more efficient workflows. KNUTH leads the way in reliability and performance, so if you're looking for a CNC Flat Bed Lathe that delivers robust construction and precise functionalities, you can request a quote today. Ksdpfxem E Ty Ne Aansnf

Condition: used, Year of construction: 2001, functionality: fully functional, turning diameter over cross slide: 180 mm, turning length: 180 mm, turning diameter: 180 mm, spindle bore: 42 mm, spindle speed (max.): 6,000 rpm, spindle speed (min.): 60 rpm, overall weight: 6,000 kg, CNC LATHE GTS-150 For sale GTS-150 CNC lathe, a compact yet powerful machine suitable for precise and efficient turning operations. Thanks to its rigid construction, high spindle speed, and reliable FANUC control, this machine is an excellent choice for versatile workshop and subcontracting use. Technical specifications: Max. turning diameter: Ø180 mm Max. turning length: 180 mm Max. swing over cover: 180 mm Chuck size: 6″ Bar capacity: Ø42 mm Spindle bore: Ø51 mm Spindle speed range: 60–6000 rpm Spindle motor: 5.5 / 7.5 kW Kjdpfjx Hr Sljx Aanjnf Spindle bearing diameter: Ø80 mm Spindle nose: A2-5 X1 / X2 travel: 155 mm Z1 travel: 180 mm Z2 travel: 500 mm Controller: FANUC 18i-TB Hydraulic / coolant tank capacity: 50 / 140 L Machine dimensions (L × W × H): 2.4 × 1.7 × 1.8 m Machine weight: approx. 6000 kg General: Rigid and stable construction High-speed spindle with precise motion control Suitable for both single-piece and series production Excellent choice for subcontracting and precision machining Machine comes with IEMCA bar feeder Ask quote including transporation. Verify all specifications with the seller.

Condition: used, Year of construction: 1998, turning length: 800 mm, turning diameter: 600 mm, spindle bore: 127 mm, spindle speed (max.): 2,500 rpm, travel distance X-axis: 345 mm, travel distance Z-axis: 995 mm, Mori Seiki SL-400B CNC Lathe (1998) Machine Type: CNC Turning Center (2-Axis) Year of Manufacture: 1998 Control System: Mori Seiki MSC-501 Machining Capacity Maximum Turning Diameter: approx. 600 mm Maximum Turning Length: approx. 800 mm Ksdpfxsx Hpvuo Aanonf Distance Between Centers: approx. 940 mm X-Axis Travel: approx. 343 mm Z-Axis Travel: approx. 993 mm Spindle Nose: A2-11 Spindle Bore: approx. 127 mm (5") Spindle Speed: up to 2,400 rpm Spindle Motor Power: approx. 30 kW Tool Turret: 12 Stations Machine Weight: approx. 9,500 Machine Dimensions (L × W × H): approx. 4,300 × 2,000 × 2,100 mm

Condition: excellent (used), Year of construction: 2014, operating hours: 5,650 h, functionality: fully functional, machine/vehicle number: 243-0011, CNC AUTOMATIC LATHE TORNOS EVODECO 16/10 with bar-feeder LNS Fanuc 31iB - 5646 hours Manufacturing origin CH Voltage 400 V Netweight 2700 kg Dimensions 2135x1250x2114 mm TECHNICAL DATA Number of axes 10 Number of spindles 2 Main spindle Maximum bar diameter 16 mm Maximum machining length 180 mm Spindle speed 12'000 min-1 Spindle power 15.8 kW Indexing accuracy C-axis 0.001 Counter spindle Maximum bar diameter 16 mm Spindle speeds 12'000 min-1 Spindle power 15.8 kW Indexing accuracy C-axis 0.001 Tool gang 1 Number of positions 5 Kedpfekhnqgjx Aanenf Number of motorized positions 3 Rotating tool speed 8'000 min-1 Tool gang 2 Number of positions 5 Number of motorised positions 3 Speed of rotating tools 8'000 min-1 End attachment Number of positions 4 Number of motorised positions 3 Speed of rotating tools 8'000 min-1 back operation Number of positions 6 Number of motorised positions 6 Rotating tool speed 8'000 min-1 Power supply Supply voltage 400V Errors and omissions excepted-data given without obligation

Condition: new, The Servoturn 500/1000, a remarkable addition to the Conventional Horizontal Lathes category, exemplifies the innovative approach of KNUTH in the Servo-conventional Lathes group. This machine integrates cutting-edge feed technology with the reliability of traditional engineering. Its electronic hand wheels and ball screw drives enhance precision, enabling high-torque servo motors to execute feed movements with unrivaled dynamics, surpassing standard lathe capabilities. The user-friendly interface allows operators to select feed and thread pitches effortlessly, while the rapid traverses minimize downtime, ensuring high productivity. A robust machine frame and heavy-duty tailstock guarantee stability and performance, making it suitable for heavier materials. The Servoturn 500's standard equipment includes a quick-change tool holder, a 3-axis position indicator, and a reliable coolant system. Experience unparalleled turning with this advanced machine. To learn more, request a quote today and elevate your machining capabilities with the Servoturn 500/1000, a stellar choice in the Servo-conventional Lathe market. Knsdpsl Iy Sisfx Aanjf

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 16380, CNC automatic lathe CITIZEN CINCOM L-20 VIII with Fedek STM-326 bar feeder, year 2008. Machine is fully controlled by Citizen. Supplied with geometric protocol. Knsdpfow T Stzox Aanof

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 14891, Year 2012 with Fanuc 18i-TB Fully inspected by Citizen and ready for production Country of manufacture: JP Voltage: 200V/50-60Hz/3ph. Dimensions: 1400x900x1300 mm Net machine weight: 950 kg TECHNICAL SPECIFICATIONS Controller: Fanuc Series 18i-TB 6 axes: (X1/Y1/Z1/X2/Y2/Z3) Maximum bar diameter: Ø 4 mm Maximum turning length: 40 mm Main spindle, max. speed: 16,000 rpm (12,000 rpm) Indexing: 1° Maximum speed of driven tools: 8,000 rpm Sub-spindle, max. speed: 10,000 rpm, 1° indexing Tool posts: total of 8 tools Guide bushing unit: standard Knedpfx Aew T S Ilsanef Technical data provided subject to errors and omissions.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: NT315HF0043, Control MSX-711 (Fanuc 3Li) for 5axes simult. Spindel A2-5 40 pos. ATC type Capto C5 Bar-feeder LNS MoveS2 INVENTORY NR.2180207, MACHINE EQUIPPED WITH : Control MSX-711 (FANUC 3Li) for 5 axes simultaneous machining, color screen 15’’ and dialog system MAPPS III Memory capacity up to 1000 programs Kjdpjd Hkucsfx Aanjnf Options : tools correctors (milling spindle), B tools life gestion, input of tools correctors G10, 3 interpolations, variable thread step (G34), circular threading, personalised macro, high precision contouring control (control II contour AI), card ATA 1 GB, offset tool for 5 axes machining Chips conveyor (with chain) model/500 B-axis with direct motor (DDS) ATC type CAPTO C5/ 40 positions Tools to zero setting system with automatic arm for milling spindle High-pressure cooling system type KNOLL with 500L tank, pump and paper filtration, for cooling through spindle centre Cutting fluid coolant unit Type KNOLL Linear measuring system for Axes X1 / Y / Z1 Tool monitoring system through control of main spindle motor and feed motors Automatic workpiece measuring system with touch-test RENISHAW and macro B for use in Milling spindle Light signal Automatic machine stop Workpieces receptor vat Ø52mm, L120mm 10 additional M functions Flange for cylinder, threaded ring, traction tube, bore Ø 52 Clamping chuck HAINBUCH Spanntop Axzug Nova, with stop type 100 for pieces in chuck and for jobs in bars with passage, clamping head type 32, A2-5 direct mounting, adapter Hydraulic chuck KITAGAWA, type BB206A5, Ø170mm, A2-5 direct mounting, passage Ø52mm Bar-feeder LNS, Type Move S2 Diameter of roung bars : Ø8 – 80 mm, bars length : 700 mm – 1600 mm ; loading from the front ; longitudinal shift : 470 mm ; set of guidings Ø18-20 Ø24-26 and Ø28-30 ; pushers : 1x Ø 8 – 1x Ø 15 mm ; guiding devices for main spindle Ø 21 – 26 and 31 mm Fire extinctor through carbonic gas type Tyco KLA III with 10kg CO2 Aspiration system ELBARON RON/A 3000 D-2H with full rest

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, Fanuc 31i, turning bush, pcs catcher, pcs conveyor, pce ejector, coolant tank, Robobar SBF-532 bar3600mm Manufacturing origin Japan Voltage 400V Netweight 3000 kg Dimensions 240x138x205 cm Total power Custom position 8458.11 20 TECHNICAL DATA Number of axes 8 Number of spindles 2 Control Fanuc 31i Main spindle Max bar diameter 25.4 mm Travel 230 mm Speed 10'000 min-1 Power 5.5 kW C-axis indexing precision 0.1° Counter-spindle Max bar diameter 25.4 mm Spindle speed 10'000 min-1 Power 5.5 kW Ksdpjd Hihyefx Aansnf C-axis indexing precision 0.1° Number of guide bushes 2 Guide bush 1 Number of positions 10 Number of motorised positions 4 Live tools speed 10’000min-1 Guide bush 2 Number of positions 6 Number of motorised positions 2 Live tools speed 10’000min-1 End-attachment Number of positions 4 Secondary operations Number of positions 2 Voltage 400V Installed power 14kW errors and omissions excepted-data given without obligation Inventory nr.2180201, machine equipped with : Control Fanuc 31i Rotating guide bush Parts catcher Parts conveying band Parts ejector Coolant tank Bar-feeder Robobar SBF-532, longueur barre max 3600 mm

Condition: refurbished (used), Year of construction: 2004, machine/vehicle number: 350735, Manufacturing origin Swiss Voltage 380/50/3 Netweight 1570 kg Custom position 8458.1120 Dimensions 1830x1260x1700 mm TECHNICAL DATA Capacities Max. turning diameter Ø 270 mm Max. swing over carriage Ø 115 mm Centre height over carriage 60 mm Turning length B32 265 mm Headstock A2-4 Spindle for Schaublin collets W20 / W25 / F38 / B32 Spindle speed, continuous 50 - 5'000 min-1 Spindle inner diameter (without chuck key) 39 mm Max. bar passage in collet W20 14,5 mm Max. bar passage in automatic chuck 32 mm Max. recommended turning diameter 200 mm Pneumatic clamping Adjustable axial clamping force, force at 5 bar 1'150 daN Cross slide Cross travel, X axis 180 mm Resolution, X-axis (at radius) 0,0005 mm AC motor drive, continuous / intermittent torque 4 / 14 Nm Ball screw, diameter x pitch Ø 20 x 5 mm Longitudinal travel, Z axis 390 mm Resolution, Z axis 0.001 mm Knedpshr Rtnjfx Aanof AC motor drive, continuous / intermittent torque 4 / 14 Nm Ball screw, diameter x pitch Ø 32 x 5 mm Feed rates Working feeds, X and Z axis, stepless 0 - 5 m/min Rapid feeds, X and Z axis 8 m/min Feed forces, X / Z axis, continuous 503 / 503 daN Tooling system: Revolver Standardised tool holder attachment VDI 20 Number of tool stations 8 Number of live tool stations 4 AC motor drive, continuous / intermittent 0.55 / 1.1 kW Spindle speed, stepless 30 - 5'000 min-1 Max. tool cross-section 16 x 16 mm Integrated coolant and indexing in both directions yes Cooling Tank capacity 55 L Pump capacity 10 L/min Pressure 1.7 bar Pneumatic tailstock Taper of the spindle sleeve Morse 3 Spindle outer diameter 45 mm Spindle stroke 70 mm Adjustable contact force 25 - 260 daN Tip height from ground 1'162 mm errors and omissions excepted data gived without obligation

Year of construction: 1998, condition: excellent (used), machine/vehicle number: 988e510044, Control Fanuc 18i - turret1 with 12 posts turret 2 with 10 posts - chips conveyor Knedpfjiy A Iuex Aanjf

Condition: like new (used), Year of construction: 2022, operating hours: 3,800 h, functionality: fully functional, Year 2022 - 3800 hours MultiSwiss 8x26, 6 Y-axes 8 motor spindles, 11 kW – 8000 rpm max Spindle capacity 26 mm, Z stroke 75 mm (max. workpiece 65 mm) Knedpfx Asxrfunsanef 2 X-slide units in positions 1-8, stroke 80 mm 6 X-Y slide units in positions 2-3-4-5-6-7, X stroke 55 mm, Y +/-16.5 mm Counter spindle 11 kW – 8000 rpm max Z stroke 150 mm, X 170 mm HP ejector adaptation for counter spindle (requires 3010 or 3020) Fanuc 30iB CNC control Integrated PC with Windows 10 operating system 21.5" color touchscreen Independent C axis on each spindle in main and counter operations (requires 0060 or 0065 or 0070 or 0075)

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 341966, Country of manufacture: Switzerland Voltage: 400/50/3 Net weight: 2640 kg Customs tariff number: 8458.1120 Dimensions: 2301 x 1438 x 1676 mm TECHNICAL SPECIFICATIONS Capacities: Maximum turning diameter: 330 mm Knodpfjw T Smhex Aanef Maximum diameter admitted over cross slide: 160 mm Center height over cross slide: 83 mm Maximum diameter admitted over bed: 430 mm Turning length (depending on equipment): 650 mm Headstock: Standardized spindle nose, suitable for use with various collets and chucks using adaptation accessories. Collet accessories (SCHAUBLIN): B45/F48 Maximum bar capacity, diameter: 36 mm / 42 mm Automatic chuck, standard diameter: 170 mm Direct drive via AC motor, power at 100% / 50% duty: 15 / 18.5 kW Maximum torque at 100% / 50% duty: 135 / 165 Nm Maximum spindle speed: 5000 rpm C axis: Pneumatic clamping cylinder: 2700 daN Cross slide: Transverse travel, X axis: 240 mm Radial resolution: 0.0005 mm AC motor drive, nominal torque: 3 Nm Ball screw, diameter x pitch: 32 x 5 mm Longitudinal travel, Z axis: 720 mm Resolution: 0.001 mm AC motor drive, nominal torque: 6 Nm Ball screw, diameter x pitch: 32 x 10 mm Feeds: Stepless working feeds, X/Z axes: 0–5000 mm/min Rapid traverse feeds, X/Z axes: 8 / 10 m/min Feed force, X/Z axes: 420 / 670 daN Turret tool system: Number of tool stations: 8 Standardized tool holder mounting: VDI 30 Max. tool shank size: 20 x 20 mm Integrated coolant Indexing in both rotation directions Coolant system: Tank capacity: 120 liters Pump flow rate: 10 l/min Pressure: 5 bar Unless otherwise specified, the above technical details are provided without commitment or liability.
