Used Gildemeister Nef Ct 40 for sale (237)

Condition: used, Year of construction: 1999, turning diameter 500 mm Dkjdpfoub Amljx Agfek turning length 1500 mm control Manual Plus spindle bore diameter 70 mm turning speed range 8 - 2800 U/min transmission ratio 3 swing diameter over face slide 290 mm spindle head DIN 55027 Gr 8 tool holder Typ C quill stroke 180 mm weight of the machine ca. 3,2 t dimensions 3,0 x 1,8 x 1,8 m Description of the machine: This machine is suitable for turning chucked and shaft workpieces. The commercially available steel grades, casting, copper, aluminium, brass, gunmetal and cuttable plastic can be turned on this machine. --> Concept of the N.E.F. plus The machine si supplied as standard with the following described equipment - Cycle control - AC-Main drive - Compund slide rest with AC drive and operating panel - Tailstock traversable using slavingunit, manualy clamped, including following centre point - Coolant unti - Chip protection hoods, manually actuated - Protection hood for chuck - Fast change tool holder Hahn & Kolb Multifix C - Reduction collar for turning spindel accessories according to pictures: - 2 STK steady rests - various clamping jaws - Hahn & Kolb Multifix type C - Various torsion bar holders Technical data: Working area: - Circulation diameter over bed: 500 mm - Circumferential diameter above the radial slide: 285 mm - Chuck Ø: 250(315) mm - Face slide: 260 mm - Distance between centres: 1000/1500 mm Turning spindle: - Spindle head DIN 55027: Size 8 - Hole diameter of the spindle: 70 mm - Hollow taper of the spindle nose: 80 metric - Spindle diameter in front bearing

Condition: ready for operation (used), Year of construction: 1992, Immediately available ex location: CNC Lathe Gildemeister Type CT 60 Year of manufacture: 1992 CNC control: EPL 2 Turning diameter: 360 mm Turning length: 1000 mm Swing diameter over bed: 600 mm Swing diameter over cross slide: 360 mm Djdpfx Agjyzmgmsfokk Travel X-axis: 1100 mm Travel Z-axis: 380 mm Chuck: 250 mm Spindle bore: 108 mm Spindle speeds: 16 – 3150 rpm Drive: 30 kW Turret: 12 positions Driven tools Rapid traverse: 10 m/min Tailstock MK 5 Quill stroke: 180 mm Accessories: Jaws Chip conveyor Weight: 6.5 t Offered at a price of EUR 4,000.-- plus VAT, ex location

Condition: excellent (used), Year of construction: 2010, operating hours: 3,624 h, functionality: fully functional, travel distance X-axis: 398 mm, travel distance Z-axis: 1,250 mm, rotational speed (max.): 3,000 rpm, We offer in good condition Gildemeister NEF 600 with Heidenhain control, please note customer removes 3-jaw chuck. Machine will be sold without 3-jaw chuck. Technical Data: Turning diameter: 600mm Turning length: 1190mm Main spindle: Speed range – main spindle: 0 – 3,000 rpm Drive power – main spindle: 39.4 / 27.5 kW Max. torque: 430 Nm Spindle diameter at front bearing: 100 mm Spindle bore: 90mm Max. bar diameter: 75mm Turret: Number of tool stations: 12 pos - VDI 40 Travel: X-axis: 398mm Z-axis: 1250mm Dksdsxrg S Iopfx Agfsk Tailstock: Tailstock travel: 1150mm

Condition: excellent (used), Year of construction: 2004, - Fagor digital display - Accessories available Working area Djdsyvy Rnepfx Agfjkk Max. turning diameter over bed: 350 mm Max. turning diameter over cross slide: 200 mm Centre height: 180 mm Centre distance: 1000 mm Bed width at guideway level: 255 mm Top slide travel towards headstock: 60 mm Top slide travel away from headstock: 55 mm Spindle nose with flange according to ISO 702-3 (DIN 55027) C6 (DIN 6) Spindle taper: Morse taper 6 Spindle bore: 54 mm Tailstock quill taper: Morse taper 4 Tailstock quill travel: 100 mm Tailstock lateral adjustment: ± 10 mm Spindle speed range, stepless: 40 – 2500 rpm Feed levels: Longitudinal feed: 9 Cross feed: 9 Feed rates: Longitudinal feed: 0.04 - 0.4 mm/rev Cross feed: 0.02 - 0.2 mm/rev Metric threads: Number: 28 Pitch: 0.2 – 4.5 mm Inch threads: Number: 21 Pitch: 76-8 TPI Module threads: Number: 28 Pitch: 0.2-4.5 mm Diametral pitch threads: Number: 21 Pitch: 76-8 DP Leadscrew thread pitch: 6 mm Tool holder section: 20x20 mm Max. spindle torque: 200 Nm Main drive power: 4 kW (5.5 HP) Electric pump power: 0.12 kW (0.16 HP) Synchronous speed of main motor at 50 Hz: 1500 rpm / at 60 Hz: 1800 rpm Synchronous speed of coolant pump motor at 50 Hz: 3000 rpm / at 60 Hz: 3600 rpm Machine dimensions Length x width x height: 2300 x 940 x 1400 mm Weight: 1500 kg

Condition: good (used), Year of construction: 2002, turning diameter over cross slide: 150 mm, spindle bore: 52 mm, turning length: 750 mm, turning diameter: 320 mm, center width: 750 mm, quill stroke: 120 mm, quill diameter: 70 mm, center height: 160 mm, spindle speed (min.): 20 rpm, spindle speed (max.): 4,000 rpm, total length: 2,800 mm, total width: 1,820 mm, total height: 1,750 mm, spindle motor power: 9,000 W, overall weight: 2,000 kg, NC lathe, control Heidenhain Manualplus 4110, capacity Ø 320 mm, between centers 750 mm, motor 9 kw, spindle speed 20 - 4000 rpm, bore Ø 52 mm, 3- and 4-jaws chucks (6), soft chucks, tool post Multifix + Capto C3 with holders, turning pins, drilling chuck, coolant system, several accessoires in cabinet, manual, YOP 2002, 13'600h, in TOP condition Dkjdpfx Ageyymx Tsfsk

Condition: used, Year of construction: 2000, functionality: fully functional, machine/vehicle number: 13100000701, turning diameter over cross slide: 415 mm, turning length: 2,000 mm, turning diameter: 710 mm, spindle bore: 92 mm, spindle speed (max.): 1,800 rpm, spindle speed (min.): 16 rpm, travel distance X-axis: 385 mm, spindle motor power: 22,000 W, rapid traverse X-axis: 6 m/min, rapid traverse Z-axis: 8 m/min, total height: 1,865 mm, total length: 4,530 mm, total width: 2,005 mm, quill diameter: 110 mm, quill stroke: 210 mm, feed rate X-axis: 5 m/min, feed rate Z-axis: 5 m/min, type of input current: three-phase, torque: 2,750 Nm, overall weight: 5,600 kg, Equipment: documentation/manual, We are offering this used GILDEMEISTER NEF plus 710 CNC lathe, year of manufacture 2000. Type: NEF plus 710 Year of manufacture: 2000 Rated voltage: 400 V Number of phases: 3 ~ Frequency: 50 Hz Power: 49 kVA Rated current: 70 A Djdpeyylfljfx Agfokk Fuse: 80 A Control voltage (AC): 230 V Control voltage (DC): 24 V If you have any questions or require further information, please feel free to send us a message or call us.

Condition: good (used), Year of construction: 1996, Description: For sale is a Gildemeister NEF Plus 710 lathe, year of manufacture 1996, in operational condition and ready for immediate use. The machine has been regularly maintained and is in good condition. Ideally suited for precision turning of metal and plastic components. General technical specifications of the Gildemeister NEF Plus 710 (Year: 1996) Technical Data: Machine type: CNC lathe Model: NEF Plus 710 Dksdsygdgaepfx Agfek Year of manufacture: 1996 Control: Siemens 810T (or comparable) Workpiece diameter: max. 710 mm Turning diameter: max. 710 mm Turning length (range): up to approx. 1000 mm Spindle speed: 30 – 2,500 rpm Drive power: 15–22 kW (depending on version) Spindle mount: A2-6 Cooling: Integrated coolant system Included: Tool holder (VDI), standard equipment Special Features: Operational condition: The machine is fully functional and ready for use. Location: Collection in Langenfeld (NRW), Germany. Price: €13,500 plus VAT. The lathe is perfectly suited for all types of CNC turning applications and offers excellent cost-effectiveness for workshops and manufacturing companies. Contact: Please send a message for further information or to arrange a viewing appointment. Important information: All information is subject to change, prior sale, errors, and availability. Technical data and all provided information are non-binding and for guidance only. Contact: If interested or to arrange a viewing, please send a message or schedule an appointment. Disclaimer: The item is sold as described. Returns, guarantee, and warranty are excluded. The buyer agrees that the item is purchased "as seen" and without any right of return. No liability is accepted for the accuracy of the information provided in the text or photos. By purchasing this item, you agree to the above terms and conditions.

Condition: used, Year of construction: 2003, Lathe DMG Type NEF 320 K Condition: Used Year of Manufacture: 2003 Control: SINUMERIK 810DE-L CCUO Cycles for taper turning and thread cutting Technical Data Swing over bed: 320 mm Swing over cross slide: 150 mm Chuck: 200 mm Cross travel: 150 mm Feed drive AC: 4 m/min Main spindle: Size 6 Spindle bore: 52 mm Spindle mounting: MK 6 Spindle front bearing diameter: 85 mm Drive power: 7 kW Max. torque: 320 Nm Speed range: 14 - 3550 rpm Gear stages: 2 Dsdjyrggmepfx Agfskk Tool post: Multifix size B Quill: 70 mm Quill stroke: 120 mm Quill mounting: MK5 Dimensions Length / Width: 2600 mm / 1440 mm Weight: approx. 1440 kg

Condition: reconditioned (used), Year of construction: 2003, Universal Lathe GILDEMEISTER NEF 320 K With Siemens SINUMERIK 810 DE control (SIMATIC PANEL TOUCH SCREEN) Year of manufacture: 2003 Spindle bore: 52 mm Distance between centers: 750 mm Swing diameter over bed: 320 mm Swing diameter over cross slide: 150 mm Cross slide travel: 185 mm Infinitely variable speed range: 14 – 3550 rpm Djdpfxoxn Ar Ae Agfekk Including the following accessories: Sliding guard with internal lighting Multifix tool holder with 2 inserts 3-jaw chuck SCHUNK ROTA plus Ø 200 mm 2 sets of soft top jaws Coolant system Chip blow gun 6 machine feet Operating manual The machine is in very good condition!

Condition: used, Year of construction: 2001, functionality: fully functional, center width: 1,000 mm, turning diameter over bed slide: 500 mm, For sale is a cycle-controlled lathe of the Gildemeister brand and type NEF 520 K The machine is fully functional, the guides are somewhat worn but still functional Technical data: Gildemeister universal lathe NEF 520K Year of manufacture: 2001 Control: Siemens Touch Panel Rotation Ø over bed: 500mm Rotation Ø over facing slide: 290mm Face travel: 260mm Center distance: 1000mm Drive power 12 KW 1st gear stage 8 - 750 rpm 2nd gear stage 32 - 3000 rpm Quill Ø: 80mm Quill holder: MK5 Quill stroke: 180mm Dkjdpfxjtrmrxs Agfsk Three-jaw manual chuck: Ø250mm Four-jaw manual chuck: Ø250mm Tool holder: Multifix size C Fixed vice with jaws and rollers, guide Ø10 - 115 On request, loading and transport can be organized for an additional charge All prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours?

Condition: used, Year of construction: 2003, turning diameter 320 mm turning length 750 mm control Siemens type 810DL CCUO turning diameter over slide rest 150 mm cross movement 185 mm spindle passage 52 mm turning speeds 14-3550 U/min transmission ratio 2 quill stroke 120 mm rapid traverse 6 m/min main drive motor 7 kW 3-jaw-chuck diameter 200 mm total power requirement 10 kW weight of the machine ca. 2 t dimensions of the machine ca. 2,6x1,44x1,44 m 8950 turning hours Dkjdpfx Aoyutucsgfjk The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2006, Technical details: turning diameter over bed: 500 mm turning dia. over face-slide: 290 mm turning length: 850 mm centre distance: 850 mm longitudinal traverse (z-axis): 900 mm facing movement (x-axis): 260 mm control: Manuaplus 4110 revolution per minute: 10 - 3000 / 2x seples U/min max. torque on the spindle: 920 Nm spindle bore: 70 mm facing movement (x-axis): 8 m/min. longitudinal traverse (z-axis): 10 m/min. operating hours - idle run: ca. 34.600 h tailstock taper ISO: MK 5 tailstock quill stroke: 180 mm total power requirement: 24 kVA Weight approx.: 5,2 t dimension machine xH: 2,2 x 3,2 x 1,9 m Multifix steel holder size C 3-jaw chuck Ø 250mm Dksdpfx Agswtct Hjfsk chip tray manual hour counter live center in tailstock Operation control panel and monitor Accessories: 4-jaw chuck Ø 250mm with internal jaws various chuck keys Machine lighting 8x foot plates 4x wedge lifters various pairs of jaws 1x bezel Ø 100mm closed *

Condition: used, Year of construction: 2001, turning diameter . mm turning length . mm control . type . CCUO turning diameter over slide rest . mm cross movement . mm spindle passage . mm turning speeds . U/min transmission ratio . quill stroke . mm rapid traverse . m/min main drive motor . kW 3-jaw-chuck diameter . mm total power requirement . kW weight of the machine ca. . t dimensions of the machine ca. . m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity Djdpoyqwb Ejfx Agfskk More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2001, turning diameter 320 mm turning length . mm control Siemens type . CCUO turning diameter over slide rest . mm cross movement . mm spindle passage . mm turning speeds . U/min transmission ratio . quill stroke . mm rapid traverse . m/min main drive motor . kW 3-jaw-chuck diameter . mm total power requirement . kW weight of the machine ca. . t dimensions of the machine ca. . m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity Djdpfxjyqtdio Agfjkk More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 1995, Make: GILDEMEISTER Type of machine: NEF Plus 500 Year of manufacture: 1995 Dkodpfx Aotpn S Isgfjk Control system: Gründig Machine's weight: 2650 kg Speed range: 8 - 2800 1/ min Cutting diameter: 500 mm Turning length: 1000 mm Overall dimensions: 2500 x 1750 x 1850 mm Spindle opening: 70 mm

Condition: repair required (used), Year of construction: 2002, functionality: not functional, turning length: 750 mm, swing diameter over bed slide: 320 mm, type of input current: three-phase, We offer this used Gildemeister NEF 320 cycle-controlled lathe, year of manufacture 2002. Control system: Heidenhain 4110 Control does not boot up, see error message in the photo. A floppy disk with the machine data is available. Other condition unknown, as it comes from the closure of a model making company. Dedpfxoypwhvj Agfokk Machine is still under power. Crane loading onto your truck is possible.

Condition: used, turning diameter 710 mm turning length 2000 mm control Heidenhain type Manuel Plus turning diameter over slide 410 mm x-travel 385 mm turning speeds 9-1800 U/min transmission ratio 2 drive capacity - workpiece 22 kW Torque 2500 Nm Dkjdpfx Agsyqtnbsfsk spindle diameter 160 mm spindle passage 92 mm total power requirement 49 KVA weight of the machine ca. 5,6 t dimensions of the machine ca. 5x2x2,2 m Spindle nose DIN 55027/11 Toolholder: Type MultiFix C Tool holder Capto C4 Tailstock: Tailstock mount MK 6 Quill diameter 110 mm Quill stroke 210 mm Feed rates: Rapid traverse (X/Z) 8/10 m/min Maximum feed rate 5,000 mm/min Maximum feed force 2,000 daN The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), Swing over bed 212 mm Distance between centers 750 mm Spindle speeds 10-4'000 rpm Dkodpfx Agjud Nb Iofsk Control: HEIDENHAIN Manual Plus Misc. accessories MARCELS MASCHINEN CH

Condition: good (used), Year of construction: 1984, functionality: fully functional, Swing diameter over bed: 560 mm Dsdpfx Asvn Rlzogfekk Swing diameter over cross slide: 250 mm Spindle bore: 65.3 mm Max. power: 15 kW Speeds: 11.2 - 2,240 rpm Distance between centers: 1,000 mm Quill diameter: 80 mm Quill taper: MT 5 Including chip conveyor Including complete documentation Immediately available from stock

Condition: good (used), Year of construction: 2006, Control unit MANUAL PLUS 4110 Dkodpfsx Tg T Rsx Agfjk

Condition: ready for operation (used), Year of construction: 2006, operating hours: 32,503 h, functionality: fully functional, machine/vehicle number: 01510006441, controller model: MANUAL PLUS 4110, TECHNICAL DETAILS Control: MANUAL PLUS 4110 MACHINE DETAILS Electrical Supply Rated voltage: 400 V Phases: 3~ Frequency: 50 Hz Performance Data Power: 24 kVA Rated current: 35 A Fuse rating: 50 A Dsdpfxsx Uz Eds Agfskk Operating hours: 32,503 h

Condition: used, Year of construction: 2001, chucking diameter 250 mm greates pass round over bed 500 mm swing diameter over slide rest 290 mm Dsdpfsw Syc Iox Agfokk centre distance 850 / 1350 mm control Heidenhain weight of the machine ca. 2700 t dimensions of the machine ca. 2900 x 1953 x 1825 m

Condition: used, Year of construction: 1999, control Heidenhain centre distance 1400 mm Dkodpfx Ajw Syd Segfsk weight of the machine ca. 3,6 t Handwheel defective

Year of construction: 1996, condition: ready for operation (used), A cycle-controlled CNC lathe Gildemeister is available. Center distance: 1500mm, max. turning length: 1500mm, swing diameter over bed/cross slide: 500mm/290mm, speed: 2800rpm, spindle bore: 70mm, spindle torque: 1050Nm, travel X/Z: 260mm/1600mm, rapid traverse X/Z: 6m/8m/min, feed rate: 5m/min, feed force: 5kN, tailstock quill stroke: 180mm, tailstock quill diameter: 80mm. Machine dimensions X/Y/Z: approx. 3200mm/1800mm/1900mm, weight: approx. 3100kg, operating hours: 79727h. Documentation available. On-site inspection is possible. Dedpfx Aox Uq Uhogfjkk

Condition: good (used), Year of construction: 2000, operating hours: 21,594 h, functionality: fully functional, Gildemeister NEF 320 CNC teach-in lathe Heidenhain Manual Plus Year of manufacture: 2000 Machine operating hours: 21,594 Max. turning diameter over bed: 320 mm Max. turning diameter over cross-slide: 150 mm Max. turning length between centers: 750 mm Max. spindle bore: 50 mm Motor: 9 kW Spindle speed: 10–4,000 rpm Chuck: Rota-S Plus Multifix quick-change toolpost with tool holders Dksdpfx Agjyh Hg Njfek Documentation and accessories Machine is powered up and available for inspection
