Used Grinding for sale (4,013)

Condition: excellent (used), Sanding belt width: 200 mm Sanding belt length: 1800 mm Table surface area: 230 x 600 mm 5 sanding speeds via stepped pulley drive Credozi A Slopfx Acged Electrical connection: 400 V, 0.55 kW

Condition: ready for operation (used), Sanding belt width: 200 mm Sanding belt length: 1500 mm Table surface area: 240 x 460 mm 1 belt speed Electrical connection: 380 V Cjdpfszi A Rzex Acgerd Space requirement: 880 x 550 x 1080 mm

Condition: used, Year of construction: 2003, functionality: fully functional, Control system: Siemens Sinumerik 840D Includes: Grinding media preparation, hydraulic unit, and portal loading system for loading and unloading the machine. Technical data: Center distance: 600 mm, Center height: 180 mm Maximum grinding diameter: 355 mm Maximum workpiece weight: 150 kg Maximum Z-axis speed: 11 m/min Minimum Z-axis speed: 0.01 m/min Maximum X-axis speed: 7.5 m/min Minimum X-axis speed: 0.01 m/min External cylindrical grinding spindle: Grinding wheel standard (outer diameter x width x inner diameter): 600 x 80 x 304.8 mm Grinding wheel peripheral speed: 5 - 50 m/s Power consumption of grinding spindle motor: 11 kW Workpiece spindle: Taper bore of workpiece spindle: MK 5 Power consumption: 2.7 kW Tailstock: Taper bore of center: MK 4 Coolant tank: 2000 liters, Lubricating oil: 30 liters, Hydraulic oil: 60 liters Operating voltage: 400 volts, 3 phases Mains frequency: 50 Hz Total machine weight: approx. 5800 kg Operating sound pressure level: 70 dB (A) Cjdezh Ux Ispfx Acgjrd

Condition: used, Year of construction: 2003, functionality: fully functional, Siemens Sinumerik 840D control system includes: grinding media preparation, hydraulic unit, and portal loading system for loading and unloading the machine Technical data: Center distance: 600 mm, center height: 180 mm maximum grinding diameter: 355 mm maximum workpiece weight: 150 kg maximum Z-axis speed: 11 m/min minimum Z-axis speed: 0.01 m/min maximum X-axis speed: 7.5 m/min minimum X-axis speed: 0.01 m/min External cylindrical grinding spindle: Grinding wheel standard (outer diameter x width x inner diameter): 600 x 80 x 304.8 mm Grinding wheel peripheral speed: 5 - 50 m/s Power consumption of grinding spindle motor: 11 kW Workpiece spindle: Codezh Uwqjpfx Acgsrd Taper bore of workpiece spindle stock: MK 5 Power consumption: 2.7 kW Tailstock: Taper bore of center: MK 4 Coolant tank: 2000 liters, lubricating oil: 30 liters, hydraulic oil: 60 liters Operating voltage: 400 volts, 3 phases Mains frequency: 50 Hz Total machine weight: approx. 5800 kg Operating sound pressure level: 70 dB (A)

Condition: used, Year of construction: 2001, functionality: fully functional, Control system: Siemens Sinumerik 840D Includes: Grinding media preparation, hydraulic unit, and portal loading system for loading and unloading the machine. Technical data: Center distance: 600 mm, Center height: 180 mm Maximum grinding diameter: 355 mm Maximum workpiece weight: 150 kg Maximum Z-axis speed: 11 m/min Minimum Z-axis speed: 0.01 m/min Maximum X-axis speed: 7.5 m/min Minimum X-axis speed: 0.01 m/min External cylindrical grinding spindle: Grinding wheel standard (outer diameter x width x inner diameter): 600 x 80 x 304.8 mm Grinding wheel peripheral speed: 5 - 50 m/s Power consumption of grinding spindle motor: 11 kW Workpiece spindle: Taper bore of workpiece spindle: MK 5 Power consumption: 2.7 kW Tailstock: Taper bore of center: MK 4 Cedpfxjzh Uvtj Acgord Coolant tank: 2000 liters, Lubricating oil: 30 liters, Hydraulic oil: 60 liters Operating voltage: 400 volts, 3 phases Mains frequency: 50 Hz Total machine weight: approx. 5800 kg Operating sound pressure level: 70 dB (A)

Condition: used, Year of construction: 2003, functionality: fully functional, Siemens Sinumerik 840D control system includes: grinding media preparation, hydraulic unit, and portal loading system for loading and unloading the machine Technical data: Center distance: 600 mm, center height: 180 mm Credjzh Uvajpfx Acgsd maximum grinding diameter: 355 mm maximum workpiece weight: 150 kg maximum Z-axis speed: 11 m/min minimum Z-axis speed: 0.01 m/min maximum X-axis speed: 7.5 m/min minimum X-axis speed: 0.01 m/min External cylindrical grinding spindle: Grinding wheel standard (outer diameter x width x inner diameter): 600 x 80 x 304.8 mm Grinding wheel peripheral speed: 5 - 50 m/s Power consumption of grinding spindle motor: 11 kW Workpiece spindle: Taper bore of workpiece spindle stock: MK 5 Power consumption: 2.7 kW Tailstock: Taper bore of center: MK 4 Coolant tank: 2000 liters, lubricating oil: 30 liters, hydraulic oil: 60 liters Operating voltage: 400 volts, 3 phases Mains frequency: 50 Hz Total machine weight: approx. 5800 kg Operating sound pressure level: 70 dB (A)

Condition: used, Year of construction: 2022, width of the strips 150 mm band length 2000 mm turning speeds 1500x3000 U/min Crodpjzip Ndefx Acgsd total power requirement 2,6/3,1 kW weight of the machine ca. 200 kg

Condition: used, Year of construction: 2012, workpiece . workpiece diameter 15 -70 mm swing diameter max. 150 mm clamping length max. 500 mm Swing over bezel area 70 mm dimension 150 x 300 mm max. turning speeds 250 min/-1 longitudinal adjustment manuell über Kettenrad Fixed tip MK 4 (Junker D75 mm) clamping capacity ü. Hydraulik einstellbar travel -z axis max. 1000 mm feed z - Achse (CNC gesteuert) dimension D 205 x 450 mm flange diameter D 190 mm standards association D 127 mm drive 30 kW speed control mit Frequenz- Umformer max. turning speeds 4400 min/-1 type Borazon (CBN) o. Diamant mm diameter 450 mm bore D 127 mm peripheral speed max. 90 m/sec type GR-3520-NR mm diameter range D 20 - D 35 mm dimension D 80 x 250 mm flange D 100 standards association D 75 drive 1,8 kW max. turning speeds 24000 min/-1 weight of the machine ca. 7,0 t In our opinion, the machine is in good condition and can be inspected under power by appointment. There are 2 identical machines available. Csdpfx Asx H Andocgsrd Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well as Subject to prior sale!

Condition: used, Year of construction: 2004, grinding wheel diameter 660 mm Control Siemens 840D work piece width min. 5 / max. 180 mm max. workpiece diameter 200 mm Cedpoxq R Hajfx Acgsrd weight of the machine ca. 15,0 t dimensions of the machine ca. L 3,1 x B 4,0 x 2,7 m In our opinion, the machine is in good used condition. The machines were used for the production of connecting rods. Two machines are available. One machine is suitable for pre-grinding and one for regrinding. Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: used, Year of construction: 2021, max. travel distances (transverse x longitudinal) 280 x 600 mm distance spindle /table 500 mm Grinding surface of table 250 x 500 mm Grinding Wheel Dimension 355 x 25 x 127 mm grinding wheel turning speeds 1.500 / 1.800 mm Crodpfx Acjxp R D Njgjd power requirement 2,2 kW In our opinion, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if noted in the additional information. Subject to changes and errors in the technical data and information, as well as subject to prior sale!

Condition: used, Year of construction: 2009, CNC grinding machine Type/Model: Ri 8-4 Year of manufacture: 2009 Operating hours: 25,726 h Technical data Round table diameter: 800 mm Grinding diameter max.: 1100 mm Workpiece diameter max.: 1120 mm Crjdpfx Acozh Hrtjgod Workpiece height max.: 550 (700) mm Plunge depth max.: 300 mm Table load max.: 1500 kg Round table (C-axis) & guide Bearing: Hydrostatic guides in the X and C axes for maximum damping and wear-free operation Table drive: Direct drive Speed range: 0.01 to 200 rpm Positional accuracy: ± 1.5 arc seconds (smallest increment: 0.0001°) Tool holder & spindle (turret head) Number of spindle positions: up to 4 grinding spindles/tool positions in the automatically swiveling turret head CNC control & axis drives Standard control: Siemens Sinumerik 840D with extended Kehren application software X-axis: Linear drive Travel ranges (approximate values) X-axis (horizontal): approx. 1,200 mm Z-axis (vertical): approx. 700 mm Dimensions & weight Machine weight: approx. 20,000 kg + peripherals Equipment: - Coolant lifting unit Knoll FHA/300 - Emulsion mist separator Handte EM-DS - Platform with motor-adjustable platform for tool changes

Condition: good (used), I am selling a Rema DS 12/ST in good condition. Cjdpsu Uvv Tefx Acgsrd

Condition: good (used), Year of construction: 2021, operating hours: 5,500 h, grinding length: 600 mm, grinding diameter: 440 mm, feed length X-axis: 325 mm, feed length Z-axis: 750 mm, Control system, serial number and main data o Control system: SIEMENS, Type 840 D SL o Operating hours recorded: 5,475 Travel ranges o X-axis travel: 325 mm o Z-axis travel: 750 mm Axis speeds o X and Z axes max.: 15,000 mm/min o X and Z axes min.: 0.01 mm/min Working area o Max. grinding length: 600 mm o Max. grinding diameter: 440 mm o Min. grinding diameter: 10 mm Performance data o Grinding spindle: 1 tool for external cylindrical grinding o Tool dimensions: Ø 610 x 160 x 304.8 mm o Cutting speed: 60 m/s o Power: 15 kW Workpiece spindle o Speed range: 30 - 5,000 min⁻¹ o Taper: 5 Morse Tailstock o Design: pneumatic o Max. quill stroke: 80 mm o Taper: 5 Morse Connection values Cjdpfxjzgdtle Acgjrd o 400 V / 50 Hz / 71 A / 43 kW Automation / Peripherals • Handling robot, YASKAWA, Type YR-1-06VXH12-A00, year of manufacture 2022, serial number 6V2272528290001 • Automation system / workpiece storage, EGS AUTOMATION DANOBAT, Type CG600-BL1, year of manufacture 2023, serial number 190605-6, 2-position • Filter, 3FS, Type M1600, No. 565209, year of manufacture 2021, weight 85 kg • Oil band filter, MICROFILTER, Type EASYBAND 150, serial number 0202, year of manufacture 2021 • Pump, REXROTH, Type HM-46

Condition: not inspected (used), Year of construction: 2023, operating hours: 1,400 h, machine/vehicle number: 180073, grinding depth: 100 mm, grinding length: 100 mm, overall weight: 5,000 kg, grinding diameter: 100 mm, workpiece diameter (max.): 215 mm, feed length X-axis: 400 mm, feed length Z-axis: 200 mm, j.stumpf [at] ivg.auction Control system, monitoring, and key data o Control system: SIEMENS, type SINUMERIK 840 D SL o Year of manufacture: 2023 o Recorded operating hours: 1,376 Working area o Swinging diameter above the W-axis: 215 mm o Grindable bore length: 100 mm o Grindable bore diameter max.: 100 mm o Grindable external length: 100 mm o Length of the part with clamping devices: 200 mm Travel distances o X-axis: 400 mm o Z-axis: 200 mm Axis speeds o X-axis: 1 - 25,000 mm/min o Z-axis: 1 - 25,000 mm/min Spindle data o C0-axis, workpiece spindle 400 with direct drive o Motor spindle, infinitely adjustable: 0 - 2,000 rpm o Motor power: 5 kW o Workpiece weight incl. clamping devices max.: 80 kg o Internal taper: 5 MK o External centering: 80 g6 mm o Spindle bore: 30 mm o Water cooling: available Operating data o Machine weight: 4,500 kg o Machine connection values o 3 x AC / 400 V / 50 Hz o Rated power: approx. 34 kVA o Rated current: approx. 49 A Peripherals • Air filter unit, IFS, type IFMC 1800, year of manufacture 2021, serial no. 565760-02 • Cooling unit, HYFRA, type E-CHILLY 5-400V-S, year of manufacture 2022, serial no. 10129303PC01240522, cooling capacity approx. 5,480 m³ / 32° Celsius • Hydraulic unit, LEHMANN UMT, type KSS0119, year of manufacture 2022, own weight approx. 610 kg, consisting of: • Cooling unit, HYFRA, type TRK-CHILLY-45-EF-S, year of manufacture 2022, serial no. 10132616PC01290722 • Chip conveyor, LEHMANN UMT, type FB100, year of manufacture 2022, serial no. AUF007093-1, own weight approx. 80 kg • Magnet unit, LEHMANN UMT, type VMA 100S GM WA, year of manufacture 2022, serial no. AUF007093-1, own weight approx. 60 kg Codpszgcd Njfx Acgsrd The machine was loaded manually. In automatic loading operation, a collision occurred.

Condition: good (used), Year of construction: 2022, operating hours: 7,400 h, machine/vehicle number: 100644, grinding length: 600 mm, workpiece length between centers: 600 mm, feed length X-axis: 650 mm, feed length Z-axis: 1,000 mm, overall weight: 10,000 kg, j.stumpf [at] ivg.auction Control, monitoring, and operating data o NC control: SIEMENS, Type 840 D SL o Year of manufacture: 2022 o Serial number: 100644 o Recorded operating hours: 7,315 o Monitoring system: MARPOSS, Type P7 Travel distances o X-axis: 650 mm o Z-axis: 1,000 mm Axis speeds o X and Z axes max.: 15,000 mm/min o X and Z axes min.: 0.01 mm/min Working area o Max. grinding length: 600 mm o Center distance: 225 mm Performance data o Grinding spindle: 1 tool for external cylindrical grinding o Tool dimensions: Ø 760 x 250 x Ø 304.8 mm o Cutting speed: 60 m/s o Power: 30 kW o Max. grinding wheel speed according to text: approx. 80 m/s Workpiece spindle o Axis speed: 5 - 1,000 min⁻¹ o Taper: 5 Morse o Motor torque: 16 N.m Tailstock & tool post o Taper: 5 Morse o Max. tailstock quill travel: 80 mm o Diamond grinding wheel profiling tool Saddle drives o Torque motor X-axis: 28 N.m o Torque motor Z-axis: 16 N.m Operating data o Year of manufacture: 2022 o Recorded operating hours: 7,315 o Operating pressure: approx. 6 bar General data o 3 x 400 VAC / 50 Hz / 72 kW / 119 A o Weight: 10,000 kg Peripherals • Automated workpiece removal station, JOVI, Type 1113B, year of manufacture 2022, weight approx. 300 kg • Air filter unit, IFS, Type M 1600, year of manufacture 2022, serial no. 567663, weight approx. 85 kg, connection power 380 - 460 V, 50 / 60 Hz, 0.7 kW, 1.5 - 2.1 A • Hydraulic unit, REXROTH, Type Deposito HE-16120 Codozgbw Iopfx Acgerd • Coolant filter unit, MICRONFILTER, Type EASY 250 / KMT350, year of manufacture 2022, serial no. 0201, tank volume approx. 2,300 l, connection power 400 V / 50 Hz, 2.44 kW • Immersion cooler, HASCH, Type MCS-120ST-05AOP6R7S7UZ1-3405C, year of manufacture 2022, serial no. 1003220300954, weight approx. 206 kg • Magnetic separator, MICRONFILTER, Type KMT350, serial no. 0211 • Tool loading unit, DANOBAT, Type rotary table lift, year of manufacture 2022, serial no. 3130490901, weight approx. 350 kg, max. load capacity approx. 360 kg

Condition: good (used), Year of construction: 2022, operating hours: 2,800 h, grinding length: 600 mm, grinding wheel diameter: 450 mm, total width: 3,300 mm, total length: 2,900 mm, total height: 1,900 mm, grinding diameter: 290 mm, quill stroke: 80 mm, distance between centers: 600 mm, grinding wheel width: 50 mm, feed length X-axis: 300 mm, feed length Z-axis: 800 mm, grinding spindle motor power: 25,000 W, grinding spindle speed: 4,500 rpm, j.stumpf [at] ivg.auction Technical Data Year of manufacture, serial number, and operating hours o Year of manufacture: 2022 o Operating hours recorded: 2,737 Control and monitoring o Control: SIEMENS, Type SINUMERIK o Monitoring system: MARPOSS, Type P7 Travel distances o X-axis: 300 mm o Z-axis: 800 mm Axis speeds o X and Z axes max.: 15,000 mm/min o X and Z axes min.: 0.010 mm/min Work area o Max. grinding length: 600 mm o Center height above the table: 150 mm o Max. diameter of oscillation above the table: 290 mm o Workpiece weight: approx. 50 kg Performance data o Grinding wheel speed: up to 120 m/s o Max. grinding wheel dimensions: Ø 450 x 50 mm o Workpiece spindle speed: 30 - 2,000 rpm o Grinding wheel drive: 25 kW / 70 Nm / max. 4,500 min⁻¹ Codpfx Aezgan Sscgjrd o Workpiece spindle: 15 kW / 24 Nm / max. 5,000 min⁻¹ Hydraulic steady rest and dresser o Arbor taper: MK4 o Max. quill stroke: 80 mm o Diamond dressing disc, outer Ø 100 mm Workpiece spindle o Arbor taper: MK5 Operating data & connection values o Operating hours recorded: 2,737 Machine connection values o 3 x 400 VAC / 50 Hz / 58 kW / 97 A Dimensions / footprint o Required footprint (L x W x H): 2,810 x 3,300 x 1,900 mm Peripherals • Automated workpiece removal station, JOVI, Type 1113A, year of manufacture 2022, weight approx. 300 kg • Air filter unit, IFS, Type VARIO M 2000, serial no. 568113, year of manufacture 2022, weight approx. 120 kg, connection power 400/460 V, 50/60 Hz, 0.7 kW, 1.7/1.6 A • Water cooling unit, HASCH, Type MCW-50CT-17AUZ1-3407C, serial no. 1001220302582, year of manufacture 2022, weight approx. 150 kg, tank volume approx. 15 l • Coolant filter system, MICRONFILTER, Type EASY 250 / KMT350, serial no. 0201, year of manufacture 2022, tank volume approx. 2,300 l, connection power 400 V / 50 Hz, 5.34 kW • Immersion cooler, HASCH, Type MCS-120ST-05AOP6R7S6UZ1-3407C, serial no. 1003220400836, year of manufacture 2022, weight approx. 206 kg • Coolant tank, MICRONFILTER, Type VR200L / MIN-150L, serial no. 0201, year of manufacture 2022, tank volume approx. 150 l, connection power 400 V / 50 Hz, 1.1 kW • Separating magnet, MICRONFILTER, Type KMT350, serial no. 0212 • Loading unit, DANOBAT, Type rotary table lift, serial no. 3810490908, year of manufacture 2022, weight approx. 170 kg, max. load capacity approx. 230 kg • Rotary table trolley, year of manufacture 2022, serial number 110000503

Condition: new, Year of construction: 2025, Working width: 380 mm Working height: 250 mm 1st unit, rotor group: Group of two oscillating rotor brushes, Ø 200 mm, one 1.5 kW motor per brush, variable speed drive 2nd unit, rotor group: Group of two oscillating rotor brushes, Ø 200 mm, one 1.5 kW motor per brush, variable speed drive Both units with oscillation: yes Credpfx Asv R U Ifecgjd Height adjustment: handwheel Height indicator: mechanical counter Feed speed: 1 - 6 m/min Feed motor power: 0.37 kW Vacuum carpet: yes Machine length: 1400 mm Machine width: 900 mm Weight: 500 kg

Condition: new, Year of construction: 2024, Working width: 380 mm Working height: 150 mm 1. Unit, rotor group: Group of 5 oscillating rotary brushes, Ø 115 mm, each with a 3 kW motor Csdpfx Astnf Rrscgerd 2. Unit, brush: Scotch Brite Hard / diameter 210 mm, variable drive Height adjustment: handwheel Height display: mechanical counter Feed speed: 4 - 12 m/min Feed motor power: 0.37 kW Vacuum conveyor belt: yes Machine length: 1400 mm Machine width: 900 mm Weight: 500 kg

Condition: used, Year of construction: 1973, Additional flanges and a spindle for internal grinding are included with the machine. The Jones was completely disassembled and inspected; it works flawlessly. The price is for one machine. Credpsw Dvwasfx Acgsd

Condition: ready for operation (used), - USED - SURFACE GRINDING MACHINE MAX GRINDING LENGTH: 1015 mm MAX GRINDING WIDTH: 405 mm MAX GRINDING HEIGTH: 350 mm MAGNETIC CHUCK: 400 x 1000 mm GRINDING WHEEL SIZE: 50 x 127 x 350 mm MOTOR POWER: 3,7 kW WEIGHT: 3600 Kg OVERALL DIMENSIONS: 3500 x 1700 x 2000 mm Crjdpfx Acjh St Dqegsd ACCESSORIES: DRESSING TOOL

Condition: good (used), Year of construction: 2000, Grinding booth, soundproof booth for grinding operations, suitable for noisy environments. Dimensions: depth 4000 mm, length 9000 mm, height 4 meters, with 2 sliding gates. Cedpfjzh Nrcox Acgjrd

Condition: good (used), Year of construction: 1992, functionality: fully functional, Technical details workpiece diameter 1000 mm workpiece weight - kg workpiece height - mm grinding wheel motor 11 kW total power requirement 25 kW Cedpfx Aozimx Ajcgord weight of the machine ca. 6500 kg dimensions of the machine ca. 4100 x 3200 x 2600 mm Additional information Machine comes from a plant closure Equipment: Coolant system 500 liters with paper belt filter 4 grinding stones (3 of them unused) Technical data: Rotary table diameter 800 mm Max. distance from rotary table to grinding spindle center 850 mm Grinding wheel diameter 400 mm Grinding wheel width 80 mm

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, Technical details grinding length 800 mm grinding width 400 mm workpiece height 375 mm weight of the machine ca. 3,5 t Additional information CNC Precision Surface and Profile Grinding Machine This machine is ideally suited for precision applications in tool and mold making. Technical Details: Grinding surface: 800 x 450 mm Grinding area: 800 x 400 x 375 mm Table load (max.): 700 kg X-axis = Longitudinal movement of worktable Table longitudinal stroke: 20 - 850 mm Table drive: Electromechanical with toothed belt drive Table speed: 5 - 35,000 mm/min Table setup: Electric handwheel and direction push button Y-axis = Vertical movement Distance from table to spindle center: 140 - 525 mm Vertical drive: Electromechanical with ball screw Vertical speed: 50 - 2,000 mm/min Vertical adjustment via electric handwheel and direction pushbuttons Minimum infeed 0.001 mm Measuring system: glass scale Crsdpfx Aezimvnjcgsd Z-axis = Transverse movement Maximum transverse travel 400 mm Drive type: electromechanical with ball screw Transverse speed 50 - 2000 mm/min Transverse travel adjustment via electric handwheel and direction pushbuttons Measuring system: glass scale C-axis = Grinding spindle Grinding spindle motor 7 kW Grinding spindle speed 1400 rpm Grinding wheel standard 300 x 50 x 76.2 mm Spindle bearing: Precision roller bearing Lubrication: Lifetime lubrication Connected load: approx. 19 kVA Total weight: 3500 kg Equipment: - Electro-permanent magnetic chuck Clamping surface 800 x 400 mm, Pole spacing 18 mm, with 16-stage holding force control and automatic Magnetic pole reversal for demagnetization - Leveling blocks For setting up and leveling the machine - Grinding wheels and two flanges - Partial enclosure Open at the top for loading with a sliding door - Dressing system Consisting of a holder for a prism arm or fork dresser Practicle arm for single-point diamond (MK O) or shaped diamond - Grinding spindle speed control Peripheral speed 10-32 m/s The peripheral speed of the grinding wheel is kept constant (V-constant control) with a 7 kW grinding spindle motor - Universal paper belt filter unit UPF 100 Tank capacity approx. 280 liters, Pump capacity 20 liters/minute at 1.5 bar - Air purifier Flow rate approx. 1000 m³/h - Compressed air ports For easier removal of large workpieces with a manual compressed air valve in the machine's work area. - Mobile balancing unit With optical operator guidance for dynamic balancing of the grinding wheel directly in the machine. Imbalance size and position are calculated automatically. With transport case. - Cleaning set Hand-held impulse nozzle for cleaning the work area - Documentation/Manual For sale is our reliably operating grinding machine from mold making. The machine was purchased new in 2016 and is in good technical condition, having been used for a maximum of 20 hours per week. It runs perfectly and is being sold solely due to an investment in a larger model.

Condition: good (used), Year of construction: 2001, functionality: fully functional, Technical details grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Control SIEMENS 840 D magnetic clamping plate 4200 x 1300 mm segment head diameter 1400 mm grinding motor turning speeds up to 320 U/min. grinding motor 306 kW weight of the machine ca. 50,0 t Additional information Segment dimensions: 120/106 x 41 x 250 mm Number of segments: 1 set = 26 pieces Grinding motor feed: 0.5 - 35 m/min, infinitely variable Grinding motor feed: - in steps: 0.002 - 1 mm continuous: up to 5 mm/min. infinitely variable Equipment: * CNC-control SIEMENS Sinumerik 840 D * Automatic hydr. swivelling of the grinding motor from hollow to cross grinding * NC-controlled adjustment of the Marposs measuring head by means of precision support. - new grinding dimensions can be entered into the control, whereby the the grinding head automatically adjusts to the corresponding height. * Dresser with adjustment axis in the machine bed * Coolant system * Electro-magnetic table Crjdjzill Uepfx Acgod * Switch cabinet * Oil mist extraction * Documentation Dimensions (length x width x height) Bed: 11800x2200x1400 mm, weight 27500 kg Grinding head: 3000 x 2500 x 3100 mm, estimated weight 14 t 2 x Oil mist extraction: 1200 x 800 x 2000 mm each Control panel: 1200 x 800 x 400 mm Small control cabinet: 1400 x 1400 x 800 mm 2 x gears each 1200 x 800 x 500 mm Control cabinet: 1600 x 800 x 2000 mm Control cabinet: 3400 x 600 x 2400 mm

Condition: good (used), Year of construction: 2007, functionality: fully functional, Technical details grinding length 600 mm grinding width 400 mm workpiece height 375 mm Additional information CNC Precision Surface and Profile Grinding Machine Crjdpeziligefx Acged Grinding area: 600 x 400 x 375 mm Grinding spindle motor: 3.7 kW Table drive: hydraulic Cross-axis drive: electromechanical Grinding wheel: 300 x 50 x 76.2 mm Peripheral speed: 10 - 32 m/s Electromagnetic plate: 600 x 400 mm with holding force control and automatic magnetic pole reversal for demagnetizing Features: Partially enclosed, open-topped loading compartment with a sliding door Cleaning kit for cleaning the work area with hand-held impulse nozzle Holder for prism arm with single-point diamond, MK 0 Grinding spindle speed control with V-constant controller Universal paper filter unit UPF 100, tank capacity approx. 280 liters Coolant pump: 20 liters/minute at 1.5 bar With mud box Machine light Grinding wheel flanges
