Used Hermle for sale (151)

Condition: good (used), Year of construction: 1996, CNC Milling Machine Hermle UWF 902H + Renishaw probe + 34-position tool changer The horizontal spindle was defective and has been removed! Year of manufacture: 1996 Control: Heidenhain TNC 426 Spindle hours: approx. 9,000 Operating hours: approx. 60,000 Spindle: SK40 Speed: 20 - 6,300 rpm Travel: X 600 / Y 450 / Z 500 mm Dsdpfjw U Dvqjx Addswf Table: 600 x 450 mm Total power requirement: 16 KVA Dimensions (approx.) LxWxH: 300 x 220 x 230 cm Weight: approx. 5 t

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, The machine is in good technical condition and can be tested by prior arrangement. The current condition corresponds to its age, and we currently have no issues with the machine. On 16.03.2022, the tool magazine door was replaced. On 28.08.2023, the SIMODRIVE 611/18A servo converter was replaced. SK 40. Spindle hours: 18,396, machine hours: 56,040. Number of axes: 3. Machine video available upon request. Heidenhain 530. Dwsdpjxyip Sjfx Addof

Condition: excellent (used), Year of construction: 1998, operating hours: 1,48,086 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, rapid traverse X-axis: 35,000 m/min, rapid traverse Y-axis: 35,000 m/min, rapid traverse Z-axis: 35,000 m/min, rotational speed (max.): 12,000 rpm, overall weight: 6,500 kg, coolant supply: 20 bar, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Control: Heidenhain TNC 430 (handles modern trochoidal paths without issues) Year of manufacture: 1998 Basic dimensions (L/W/H): 2.5 x 2.1 x 2.7 m X-axis travel: 600 mm Y-axis travel: 450 mm Z-axis travel: 450 mm A-axis rotation range: +20° / -90° C-axis rotation range: 360° Rotary table diameter: 280 mm Highlights: Tool measurement / workpiece probe / LED machine lighting / HSK63 / V2A stainless steel interior cladding / ICS (internal coolant supply) / chip conveyor / external air with cold air nozzle via M-function / status LED signal lamp Spindle Data Spindle mount: HSK A 63 (12,000 rpm) Tool magazine: 30 positions Feeds and Speeds Feed rate range: 1 - 30,000 mm/min Rapid traverse speed: 35 m/min MACHINE DETAILS Machine weight: approx. 6,500 kg Control on-time: 154,435 h Machine on-time: 148,086 h Program runtime: 49,428 h Spindle hours: 46,014 h Drive hours: 77,927 h Dwedpfx Adoxz A Nnjdof 5-axis postprocessor for Fusion 360 included Inspection and demonstration by appointment. Price is net, plus VAT.

Condition: reconditioned (used), Year of construction: 2016, CNC Vertical Machining Center HERMLE C 400 U With Heidenhain TNC 640 CNC Control Year of manufacture: 09/2016 Travel distances: X 850 Y 700 Z 500 mm Spindle speed range: 20 – 18,000 rpm, stepless Including the following accessories: - NC rotary swivel table Ø 650 mm x 540 mm (T-slots for SRT) - Vertical tool changer with 38 magazine slots (HSK 63) - Additional magazine with 50 magazine positions (ZM 50) - Through-spindle coolant supply 40 bar with paper band filter - Scale air purging - Fine filter for through-spindle coolant supply 40 bar - Scraper belt conveyor Dwodpfxjw Ewmfs Addjf - Chip cart 450 liters - Coolant unit - Air blow-off unit - Spindle center compressed air - Manual cabin door, manual cabin roof - Polycarbonate safety windows - Electronic thermal compensation - Electronic handwheel - BLUM tool breakage/control & measurement A2 - Heidenhain 3D touch probe - Chip rinsing pistol - Oil mist extraction unit - Control cabinet cooling device (RITTAL) - 4 adjustable machine feet - Operating manuals

Condition: good (used), Year of construction: 1999, HERMLE C600 U 5 AXIS MACHINING CENTRE WITH HEIDENHAIN ITNC430 CONTROL Dwodpox A Hgtsfx Addef UKUK Table Dimension Ø280mm (4 'T' Slots). Maximum Table Load 300kg. Axis Travel 'X'=600mm, 'Y'=450mm, 'Z'=450mm, 'B'=220° (±110° ), 'C'=360° . Rapid Traverse 30m/min. Maximum Spindle Speed 12,000rpm. Spindle Taper ISO 40. 30 Position ATC. S/No. 12859 (1999).

Year of construction: 1993, operating hours: 13,924 h, condition: excellent (used), x-400,y-330,z-350,Winkeltisch 630x335,SK 40, 40-6.000 U/min,Meßtaster , Djdpfx Aofgz Rkjddewf Steuerung Heidenhain TNC 425

Condition: used, Year of construction: 2006, x-travel 850 mm y-travel 700 mm z-travel 500 mm Control HEIDENHAIN iTNC 530 rotary table 800 mm c-axis 0.001º ( ±360º) 0 B-axis (table) º mm Dsdpoxrvldsfx Addswf number of spindle speeds 18.000 U/min/rpm tool taper SK 40 DIN 69871 spindle drive 15 kW max. torque on the spindle 130 Nm Tools changer 38 fach/tools Internal cooling system 80 bar handwheel HR- 410 total power requirement 41 kVA weight of the machine ca. 10,5 t Equipment- Paper belt filter – 200 l tank- Active control cabinet cooling- Infrared probe M&H (Heidenhain)- Laser tool measuring system Blum- Chip conveyor- Cleaning pistol with pump 2 bar / 40 l min- 3D Quick Set- Electronic handwheel

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, Machine parameters: Travels in X, Y, Z axes: 650X450X450 mm Description: The machine is in good technical condition; test runs are possible by prior arrangement. HSK 63. Heidenhain 426/430. - The current condition corresponds to the machine's age, and there are currently no issues. X-axis ball screw was replaced on 5.1.2022. Hydraulics were overhauled on 25.4.2024. - Spindle hours: 41,273, machine hours: 89,892 - Number of axes: 5. Video of the machine available on request. Dodpoxyipfofx Addewf

Condition: ready for operation (used), Year of construction: 2008, operating hours: 27,167 h, functionality: fully functional, Technical Data – HERMLE C 40 UP Control System: - Heidenhain iTNC 530 - Travel X/Y/Z: 850/700/500 mm Options: - Heidenhain DNC - DXF Import - Kinematic Opt iTNC Main Spindle: - Speed: 18,000 rpm - Tool Holder: HSK-A63 Tool Magazine: - Additional Magazine ZM43 Feed / Axes: - Linear guideways – Dynamic Version Dwjdpoxx Rxrsfx Addjf - Table variant: NC-SRT Ø 420 mm, worm gear drive - Table axis: A-axis offset from center - Table specification: Pallet clamping system Coolant System: - Internal coolant supply 80 bar - Coolant filter type: Paper band filter for internal coolant system Chip Disposal: - Scraper belt conveyor Cab / Safety: - Base structure - Automatic cabin door - Manual roof cover - Laminated safety glass window Electrics: - Frequency: 50 Hz - Country key: DE Pallet Automation: - Pallet changer: PW160, 400 × 400 mm - Pallet storage MMS / Measuring Systems: - External MQL (Minimum Quantity Lubrication) - Tool breakage monitoring A2 Blum - Heidenhain touch probe - Prepared for additional touch probe Software / Options: - Event Messenger - Tool identification HSK - Machine license: TCS-Soflex - System monitoring Free Accessories: - Electronic thermal compensation - Electronic hand-held control module - Oil mist extraction (prepared & with post filter) - Flange for oil mist extraction - Sealing air for scales - Chip washdown gun - Bed flushing - Internal & external air blast - Signal light - Test documentation - Test protocol: C 40 iTNC 530 PW160

Condition: good (used), Year of construction: 1995, Travel: X = 600, Y = 400, Z = 420 mm Speed range: 20 – 4000 rpm Gear stages: 3 Dedpfxow Uin Se Addjwf Taper: SK 40 Quill stroke: 75 mm Spindle motor: 5.9 kW Feed range: 1 – 5000/6000 mm/min (manual/programmed) Rapid traverse x, y: 7 m/min Rapid traverse z: 6 m/min Clamping surface: 900 x 458 mm Weight: approx. 2300 kg With coolant system, electronic handwheel, various tools (without cabinet)

Condition: good (used), Year of construction: 2002, HERMLE C800 U 5 AXIS MACHINING CENTRE WITH HEIDENHAIN ITNC 530 CONTROL Table Dimension Ø280mm (4 'T' Slots). Maximum Table Load 300kg. Axis Travel 'X'=800mm, 'Y'=600mm, 'Z'=500mm, 'B'=220° (±110° ), 'C'=360° . Rapid Traverse 30m/min. Spindle Taper ISO 40. Maximum Spindle Speed 12,000rpm. 87 Position ATC. S/No. 15650 (2002). Djdpex A Hf Aofx Addewf

Condition: used, Year of construction: 2000, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller manufacturer: HEIDENHAIN, controller model: 460, rotational speed (max.): 15,000 rpm, spindle nose: HSK 63A, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Used HERMLE C800U high-speed 5-axis continuous vertical machining center; this is a medium-sized CNC machine equipped with a gantry granite structure, weighing 8,200 kg. Axis travels: X 800 mm, Y 500 mm, Z 600 mm, with a 5-axis table featuring a 280 mm diameter platter. Year of manufacture: 2000, fitted with HEIDENHAIN TNC 430, HSK 63A spindle at 15,000 rpm (max 19 kW) cooled by a dedicated chiller, 30-position pick-up type tool changer, and remote electronic handwheel. Dwjdjxryfzspfx Addjf The equipment is completed by a KNOLL chip conveyor, high-pressure through-spindle coolant, and a RENISHAW MP10 wireless 3D workpiece probe.

Condition: used, Year of construction: 2013, x-travel 450 mm y-travel 600 mm Dwjdpst Syf Ujfx Addjf z-travel 330 mm control iTNC 530 HSCI Heidenhain turning speeds max. 18.000 min/-1 power capacity - main spindel 31 / 17 kW max. Torque 98 / 54 Nm tool taper HSK A63 rotary table dia. 320 mm Swivel range A: +/- 135 ° rotatable C: 360 ° max. table load 300 kg Number of revolutions A: 25 / C: 40 rpm T-slots 4x 14H7 number of toolpositions 55 pos. tool taper HSK A63 max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 250 mm max. tool weight 8,0 kg max. total weight 220 kg change-time chip to chip 4,5 sec Accelaration 8 m/sec² Feed force 4,5 kN rapid traverse ( X / Y / Z ) 30 m/min total power requirement 40 kVA weight of the machine ca. 9,0 t dimensions of the machine ca. 6,5 x 6,5 x 3,5 m 5 Axis - CNC Machining Center Universal HERMLE - C 22 U - Good condition! - Linear axes XYZ and drives renewed - new spindle Q1/2024 - Optional: Internal coolant supply retrofitting possible (by Hermle, for an additional charge) - Additional container with paper belt filter incl. level monitoring - Conversion of coolant lubricant tank (lifting pump incl. level monitoring)

Condition: good (used), Year of construction: 2005, functionality: fully functional, The machine is in good technical condition; inspection under power is possible by arrangement. Video available. Technical specifications: Working table length: 900 mm Dwedpfx Aexxmr Ieddjf Working table width: 500 mm Maximum table load: 500 kg Spindle drive power: 32 kW Number of tools in magazine: 28 pcs Maximum spindle speed: 12,000 rpm X-axis travel: 740 mm Y-axis travel: 500 mm Z-axis travel: 500 mm Machine height: 2,400 mm Machine width: 2,500 mm Weight: 7.3 t

Condition: excellent (used), functionality: fully functional, feed length X-axis: 700 mm, feed length Y-axis: 550 mm, feed length Z-axis: 550 mm, travel distance X-axis: 700 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 550 mm, HERMLE UWF 1001 CNC milling machine With CNC control, HEIDENHAIN / Type: TNC 155 Measuring probe / Coolant system / Chip conveyor Dwjdpfxoxxkkbs Addef Enclosure / Cabin / Control cabinet: 1260 x 500 x 1700 mm Travel paths: 700 x 550 x 550 mm / Clamping table area: 1000 x 490 mm

Condition: used, Year of construction: 1996, Technical details: x-travel: 600 mm y-travel: 450 mm z-travel: 400 mm control: Heidenhain TNC 425 spindle taper ISO: SK 40 DIN 69871 quill stroke vertical: 75 mm distance between column - table edge: 190 (fest) vertikal mm spindle head swivable left - right: 90° Vertikal-Spindel ° distance between table/spindle: min./max.: 165/565 Vertikal-Spindel mm distance between table/spindle: min./max.: 165/565 Horizontal-Spindel mm turning speed range: 20 ... 4500 U/min tool changer with: 32 tools (Typ HTC 32) feed:: 1 ... 5000 mm/min Table dimensions: 850x440 mm table swivelabel +/-: nein = starr ° table load: 500 kg total power requirement: 15 kW weight approx.: 3500 kg dimension machine xH: 2,5 x 3,0 x 2,1 m dimensions electric cabinet LxWxH: 1,6 x 0,6 x 1,7 m Dwjdpfx Aju Nc T Rjddsf Universal Milling and Drilling Machine Equipment: - cooling tank capacity 100 litres, flow rate 16 l/min - control panel with jib length arm - hand wheel control unit - 8 pieces machine base The machine can be demonstrated under power. i.D. *

Condition: used, Year of construction: 2016, operating hours: 80,000 h, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 330 mm, spindle speed (max.): 18,000 rpm, spindle speed (min.): 20 rpm, input voltage: 400 V, controller manufacturer: Siemens 840d sl Operate, number of spindles: 1, rotary table diameter: 320 mm, spindle nose: HSK-A 63, tool diameter: 125 mm, tool length: 250 mm, tool weight: 8,000 g, operating hours of spindle: 21,000 h, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Hermle C22U 5-axis machining center Siemens 840D sl Operate 55 tool stations HSK-A63 NC swiveling rotary table SRT320 mm Worm drive C-axis Single-sided drive A-axis Dwsdpfexxg Ezsx Addef Standard coolant system without through-spindle coolant (IKZ) Rear scraper-belt chip conveyor External air blow Air blow through spindle center Chip flushing pistol Oil mist extraction incl. post-filter Automatic cabin door Manual cabin roof Electric thermal compensation Siemens Heidenhain touch probe The machine is currently still being measured and overhauled, but can be inspected at any time. The listed machine hours are approximate and may vary slightly.

Condition: used, Year of construction: 1988, Tool CNC Milling Machine HERMLE type UWF 1000 CNC Year of construction: 1988 Travel X: 700 mm Travel Y: 550 mm Travel Z: 500 mm Numerical Command: HEIDENHAIN TNC 155 Spindle ISO 40 Spindle: Ø 70 mm Spindle speed: from 25 to 3150 RPM Table size: 1000 x 500 mm Vertical sleeve travel: 100 mm Swivel head Spindle motor: 6,9 kW Weight: 3,3 T Dedpfx Ajxxpw Tjddjwf

Condition: used, Year of construction: 2022, x-travel 450 mm y-travel 600 mm z-travel 330 mm Control Heidenhain TNC 640 spindle HSK A 63 turning speeds 18000 U/min swivable table: STP 320mm Tools changer 55 fach/tools Internal cooling system 80 bar Chip coveyor JA Spindle hours 7521 h Machine on 10.532 h weight of the machine ca. 8,7 t 5-axis CNC machining center -Equipment & accessories Dsdpfxswh Ukto Addjwf -Dynamic Efficiency (ACC, AFC, vortex milling), -Dynamic Precision (CTC,AVD,LAC), -Additional magazine ZM216, torque drive in the C axis, -Spur gear tandem drive -in the A-axis, car. Cabin roof including side panel, interior -Scratch belt conveyor, chip washing gun, electric. heat compensation, -Tool breakage monitoring, robot cell RS05-2

Condition: used, Year of construction: 2000, x-travel 800 mm y-travel 600 mm z-travel 500 mm table surface area 1000 x 560 mm spindle taper HSK 63 A spindle turning speed - stepless 20 - 16.000 U/min spindle power 15 kW max. torque on the spindle 9 Nm feeds x/y/z -stepless 1 - 30.000 mm/min rapid traverse 35 m/min feed power 8000 N ATC 30 Stationen control HEIDENHAIN, TNC 430 total power requirement 32 kVA Dodexq Hf Sjpfx Addewf weight of the machine ca. 7,2 t dimensions of machine L x W x H 2,75 x 2,30 x 2,95 m Accessories: HEIDENHAIN probe TS 632, various tool fixtures, chip conveyor, coolant

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller manufacturer: Heidenhain, controller model: 530, rotary table diameter: 280 mm, spindle speed (max.): 16,000 rpm, 5-axis machining center Manufacturer: Hermle Model: C20U Year of manufacture: 2006 Control: Heidenhain iTNC-530 Dodswqnnkopfx Addswf Power-on hours: approx. 48,000 h Spindle hours: approx. 20,500 h Serial number: XXXXX Technical specifications: ----- • Travel (X-Y-Z): 600 x 450 x 450 mm • C-axis: 360° • A-axis: +/-115° • Swivelling rotary table Ø280 mm • Spindle: 16,000 rpm • Magazine: 30x SK-40 • Additional magazine with 43 stations • Standard coolant system • Air blast through spindle + blow-off device • Blum laser for tool breakage detection and measurement • Renishaw 3D probe • Electrical thermal compensation • Sealing air for glass scales • Chip conveyor Accessories: ----- • Documentation • Rinsing gun • Handwheel • Maintenance history

Condition: used, Year of construction: 1992, Technical details: x-travel: 600 mm y-travel: 400 mm z-travel: 420 mm spindle taper ISO: SK 40 control: Heidenhain TNC 360 quill stroke vertical: 75 mm turning speed range: 20 ... 4000 U/min spindle head swivable left - right: 90° links / rechts ° feed:: X/Y/Z: 1...6000 mm/min. feed:: X/Y: 7 m/min. + Z: 6 m/min. Table dimensions: 900 x 460 mm table load capacity: 400 kg weight approx.: 2300 kg dimension machine xH: 4,0 x 3,8 x 2,0 m Dedpsu Nc U Iefx Addjwf total power requirement: 13 kW Equipment: - separated production cell - coolant system - control panel with swivel-mounted boom - measuring probe SK 40 Heidenhain TS 120 - oil collecting basin *

Condition: used, Year of construction: 2014, operating hours: 87,419 h, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 330 mm, spindle speed (max.): 18,000 rpm, spindle speed (min.): 20 rpm, input voltage: 400 V, controller manufacturer: Siemens 840d sl Operate, number of spindles: 1, rotary table diameter: 320 mm, spindle nose: HSK-A 63, tool diameter: 125 mm, tool length: 250 mm, tool weight: 8,000 g, operating hours of spindle: 20,657 h, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Hermle C22U 5-axis machining centre Siemens 840D sl Operate 55 tool positions HSK-A63 NC tilting rotary table SRT320 mm C-axis worm gear drive Single-sided drive A-axis Standard coolant system without through-spindle coolant (IKZ) Rear-mounted scraper belt conveyor External air blast Spindle centre air blast Dwedpoxxg D Rjfx Addof Chip flushing gun Oil mist extraction incl. post filter Automatic cabin door Manual cabin roof Electric thermal compensation Siemens Heidenhain touch probe

Condition: used, Year of construction: 1996, x-travel 850 mm y-travel 630 mm z-travel 500 mm Dwedpeuxfz Asfx Addjf Control Heidenhain total power requirement 16 kW dimensions of the machine ca. 5 x 4,2 m

Condition: used, Year of construction: 1996, Technical details: x-travel: 600 mm y-travel: 450 mm z-travel: 400 mm tool taper: IBAG SKI 25 control: Heidenhain TNC 425 quill stroke vertical: nicht bekannt mm turning speed range: 2400 - 24.000 U/min feed:: 1 ... 5000 m/min m/min table surface area: 850 x 440 mm table swivelabel +/-: starr ° table load: 500 kg tool holder / places: 32 places für IBAC SKI 25 weight approx.: 3600 kg dimension machine xH: 2,5 x 3,0 x 2,1 m dimensions electric cabinet: L:1550 X B:550 x H:1700 mm Universal Milling and Drilling Machine - with IBAG high frequency spindle type HF 100A-30/24 - milling spindle taper Tool taper IBAG SKI with IBAG tightening bolt - cooling tank, capacity 16 l/min and 100 litre capacity Dwodpfxeu Nc Uhe Addjf Accessories: - 3-D push-button Heimer - Vertical head Hermle - Tool holders according to availability i.D. *
