Used Mori Seiki Cnc for sale (199)

Condition: used, Swing Diameter Over Bed: 400 mm Swing Diameter Over Longitudinal Slide: 350 mm Distance Between Centers: 610 mm Travel Limit: 240 mm Hjdpfxexg Nd Ae Aftjfl Suggested Workpiece Diameter: 200 mm Max Longitudinal Travel: 560 mm Machining Length: 550 mm Max Cross Travel: 40 mm + 120 mm Height of Spindle Axis from Floor: 1135 mm Programmable Spindle Speed Range: 40 to 4000 rpm Spindle Bore Diameter: 52 mm Spindle Interior Cone: MK 6 Slide/Bed Slope: 45/45° Turret Positions: 12 Tools Main Motor: 15 kW Control: Fanuc 6T Equipped with: See photos

Condition: used, Year of construction: 2008, Technical details: standard turning dia.: 200 turning length: max. 810 mm control: MSX-701 MAPPS III greates pass round over bed: 800 mm Max. distance between centres: 1130 mm max. turning diameter: 320 mm max. workpiecediameter: 300 mm bar material dia.: 65 mm Traverse X-Axis 1: 210 Traverse X-Axis 2: 210 mm Traverse X-Axis 3: 210 mm Traverse Y-Axis 1: 110 (+65/-45) mm Traverse Y-Axis 2: 110 (+45,/-65) mm Traverse Z-Axis 1: 300 mm Traverse Z-Axis 3: 300 mm Traverse Z-Axis 2: 810 mm Traverse B-Axis: 870 mm turning speed range - spindle: 5.000 1/min Number of spindle speed ranges: 2 . spindle nose: JIS A2-6 spindle bore: 73 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° turning speed range - spindle: 5.000 1/min Hfsdezd Su Espfx Aftel spindle nose: JIS A2-6 spindle bore: 73 mm bar material dia. max: 65/52 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° Number of Turrets: 3 . Number of tool stations: 16 x 3=48 pos Schank height for square tool: 20 mm Diameter of boring bar: 32 mm turret changing time (4-stations): 0,18 sec Number of driven tools: 16 x 3=48 pos max. spindle speed driven tools: 6.000 U/min. Rotary tool machining ability: M16 / Ø16 . rapid traverse X-axis: 30 m/min rapid traverse Y-axis: 20 m/min rapid traverse Z-axis: 50 m/min drive capacity - spindle motor: 25 / 22 kW power capacity - driven tools: 7,5 / 5,5 kW total power requirement: 92,7 kVA weight of the machine ca.: 9,4 t dimensions of the machine ca.: 4,0 x 2,8 x 2,4 m Accerories Chip conveyor Coolantsystem C-axis in main and sub spindle Y-axis 2 x part counter total counter tool setting Spindle 1 Chuck SMW KNCS-N 210 / 52 mm Spindle 2 Collet Chuck Hainbuch Spanntop nova Kombi Axfix 65 Robot interface Barfeeder Interface CNC Turning- and Milling Center MORI SEIKI NZ 2000 T3Y2 The NZ2000 T3Y has 2 spindles and 3 turrets, and 2 turrets have the Y-axis function and built-in milling motors. This not only allows synchronized machining using 3 turrets, but also achieves heavy-duty cutting and high-speed machining using rotary tools thanks to the built-in motor turrets. *

Condition: good (used), Year of construction: 1987, Machine is in good working condition. Hfjdpfx Aez Arxzsftjl Parts shown by hand not come.

Condition: used, Year of construction: 1991, turning length: 530 mm, turning diameter: 340 mm, spindle bore: 78 mm, spindle speed (max.): 3,500 rpm, rotational speed (max.): 3,500 rpm, overall weight: 6,000 kg, CNC MF T4, 3-axis machine with C-axis 12-position motorized tool turret 250mm chuck 78mm spindle bore Maximum spindle speed: 3500 rpm, power: 15 kW Distance between centers: 625mm Hfsdpoznvizsfx Aftsl Maximum turning diameter: 625mm Chip conveyor Weight: 6000 kg

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, CNC Horizontal Lathe Mori Seiki NL2000Y/500 Year 2012 Controller : MAPPS III Hfsdpfx Aswvrfkjftol Max Swing Ø923mm Max over cross slide Ø755mm Max Turn Ø356mm Bar Capacity Ø65mm Travel X260mm / Z590mm Y +/-50mm Spindle Speed 5000rpm Turret 12 stations Max. milling speed 6,000rpm Chip conveyor Stock Clearance at 39.000EUR ONLY

Condition: good (used), Year of construction: 1998, functionality: fully functional, Maximum turning diameter: 650mm, Maximum Machining length: 863mm X345 Z900mm, live tooling, C-axis, spindelbore 130mm. MSC 501 (Fanuc) Hedpfxjz Api De Aftsfl

Condition: used, TURNING CENTER "MORI SEIKI" MOD. ZL 200SMC With twin powered turret and sub-spindle CNC MSC-501 Turning length: 452 mm Max. turning diameter: 388 mm Max. diameter over bed: 510 mm Distance between centers: 751 mm Spindle mount: A2-6 Spindle speed: 4,000 rpm Spindle motor power: 11 kW Number of tools: 12 Hodpfx Aoxwxwtoftjfl

Condition: good (used), Year of construction: 2001, functionality: fully functional, turning length: 1,020 mm, turning diameter over cross slide: 580 mm, spindle motor power: 22,000 W, travel distance X-axis: 565 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 1,080 mm, rotational speed (max.): 4,500 rpm, overall weight: 12,000 kg, For Sale: Mori Seiki MT2000SZ Multi-Axis Turn-Mill Center For sale: A highly versatile and efficient Mori Seiki MT2000SZ multi-axis CNC turn-mill center for demanding industrial production. This machine enables complete machining of complex components in a single setup using its main spindle, sub-spindle, B-axis milling spindle, and lower turret. General Information Manufacturer: Mori Seiki Model: MT2000SZ Control Unit: MAPPS / MSG-501 (Fanuc) Year of Manufacture: 2001 Technical Specifications Capacity & Travel: Max. Turning Diameter: 550 mm Max. Turning Length: 1,020 mm X-axis Travel: 565 mm Y-axis Travel: ±80 mm Z-axis Travel: 1,077 mm B-axis (Milling Spindle): ±120° (0.001° indexing) Main Spindle & Sub-Spindle: Main Spindle Speed / Power: 4,500–6,000 rpm / 22 kW / Bar Capacity Ø 65–73 mm Sub-Spindle Speed / Power: 4,500–6,000 rpm / 15 kW C-axis: Both main and sub-spindle (0.001°) Milling Spindle (Upper Head) & Tool Magazine: Milling Spindle Speed: 10,000 rpm Milling Spindle Power: 7.5 kW Tool Magazine (ATC): 60 positions Lower Turret: Tool Stations: 12-position turret (live tooling) Live Tooling Speed: 4,000–6,000 rpm Dimensions & Weight: Hjdpfjzy Ntkox Aftjfl Dimensions (L x W x H): approx. 3,830 mm x 2,881 mm x 2,650 mm Machine Weight: approx. 12,000 kg Features & Equipment Multi-Axis Configuration: Main spindle, sub-spindle, B-axis milling head, and lower turret Upper Head (Milling Spindle): Full B-axis for driven tools with Automatic Tool Changer (ATC) Lower Turret: Independent lower turret for flexible and high-efficiency simultaneous machining Included Accessories: Plenty of tools, chuck jaws, and user manuals, etc.

Condition: excellent (used), Year of construction: 2014, operating hours: 60 h, functionality: fully functional, machine/vehicle number: NL202140731, spindle motor power: 15,000 W, spindle speed (max.): 5,000 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 590 mm, type of input current: three-phase, total height: 2,145 mm, total length: 3,820 mm, total width: 2,081 mm, spindle nose: A2-6, overall weight: 5,100 kg, CNC Lathes with Milling NLX2000Y-500, Mori Seiki Year: 2014 Bar Capacity 65mm C axis 0.001 degree Control MORI M730B Machine Dimensions 3820 x 2081 x 2145mm Machine Weight 5100kg Maximum Cutting Diameter 366mm Maximum Cutting Length 510mm Milling Motor Power 5.5/3.7kW Milling RPM 10000rpm Rapid Feedrates 30m/minute Spindle Motor Power 15/11kW Spindle Nose A2-6 Spindle Speed 5000rpm Spindle Taper MT #4 Standard Cutting Diameter 271mm Swing 923.8mm Swing 755mm Tailstock Body Travel 564mm Tailstock Quill Diameter 80mm Tool Size 25 x 25mm Turret Positions 12 Station X axis Travel 260mm Hjdpfjzua Egsx Aftefl Y axis Travel +/-50mm Z axis Travel 590mm

Condition: used, Year of construction: 2011, Technical details: standard turning dia.: 200 turning length: max. 810 mm control: MSX-701 MAPPS IV greates pass round over bed: 800 mm Hfodpfx Afjzk U Rpjtol Max. distance between centres: 1130 mm max. turning diameter: 320 mm max. workpiecediameter: 300 mm bar material dia.: 65 mm Traverse X-Axis 1: 210 Traverse X-Axis 2: 210 mm Traverse X-Axis 3: 210 mm Traverse Y-Axis 1: 110 (+65/-45) mm Traverse Y-Axis 2: 110 (+45,/-65) mm Traverse Z-Axis 1: 300 mm Traverse Z-Axis 3: 300 mm Traverse Z-Axis 2: 810 mm Traverse B-Axis: 870 mm turning speed range - spindle: 5.000 1/min Number of spindle speed ranges: 2 . spindle nose: JIS A2-6 spindle bore: 73 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° turning speed range - spindle: 5.000 1/min spindle nose: JIS A2-6 spindle bore: 73 mm bar material dia. max: 65/52 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° Number of Turrets: 3 . Number of tool stations: 16 x 3=48 pos Schank height for square tool: 20 mm Diameter of boring bar: 32 mm turret changing time (4-stations): 0,18 sec Number of driven tools: 16 x 3=48 pos max. spindle speed driven tools: 6.000 U/min. Rotary tool machining ability: M16 / Ø16 . rapid traverse X-axis: 30 m/min rapid traverse Y-axis: 20 m/min rapid traverse Z-axis: 50 m/min drive capacity - spindle motor: 25 / 22 kW power capacity - driven tools: 7,5 / 5,5 kW total power requirement: 92,7 kVA weight of the machine ca.: 9,4 t dimensions of the machine ca.: 4,0 x 2,8 x 2,4 m Accerories Chip conveyor Coolantsystem C-axis in main and sub spindle part counter total counter tool setting Overhead partsgripper with conveyor belt. Spindle 1 Chuck SMW KNCS-N 210 / 52 mm Spindle 2 Collet Chuck Hainbuch Spanntop nova Kombi Axfix 65 Robot interface CNC Turning- and Milling Center MORI SEIKI NZ 2000 T3Y2 The NZ2000 T3Y has 2 spindles and 3 turrets, and 2 turrets have the Y-axis function and built-in milling motors. This not only allows synchronized machining using 3 turrets, but also achieves heavy-duty cutting and high-speed machining using rotary tools thanks to the built-in motor turrets. The robot cell has been diemanteled, it is now a stand alone machine. A bar feeder can be added. *

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 34, spindle bore: 86 mm, overall weight: 16,000 kg, Turning and milling center acquired through business takeover Manufacturer: Mori Seiki / Model: MT 250S / 1500 / Year of manufacture: 2000 / Refurbishment for 200,000 euros Condition: good, Control: CNC Mori Seiki MSC 501 Technical data: See attached PDF Max. turning diameter: 570 mm Turning length: 1530 mm Max. swivel diameter: 800 mm Swivel diameter over cross slide: 420 - 860 mm Hfsdpfxezxg Sus Aftsl Spindle distance: 1,828 mm Main spindle: Speed range: 35 - 3500 min.-1 Main spindle power: 18.5 kW / 15 kW Number of curve speeds: 2 Spindle nose: JIS A2-8 Max. bar capacity: 73 mm Spindle bore: 86 mm Spindle bearing diameter: 130 mm C-axis: 0.001° Counter spindle: Counter spindle speeds: 50 - 3500 min.-1 Counter spindle power: 11 / 7.5 kW Number of curve speeds: 2 Spindle nose: JIS A2-6 Max. bar capacity: 60 mm Spindle bore: 73 mm Spindle bearing diameter: 110 mm C-axis: 0.001° Milling spindle: Spindle speeds: 8000 min.-1 Power: 7.5 kW / 5.5 kW Tool taper: KM 63 Spindle bearing diameter: 80 mm B-axis: 120° / 105° Resolution: B 0.001° Number of tools: 42 Tool taper: KM 63 Max. tool diameter: 80 / 125 mm Max. tool length: 400 mm Max. tool weight: 8 kg Tool change time: 1.6 sec. X-axis: 635 mm / Y-axis: + / - 110 mm / Z-axis: 1595 mm / B-axis: 120° / 105° + Chuck: Rapid traverse (X/Y/Z): 24 / 24 / 30 m/min. Max. feed rate: 30,000 mm/min. / Total power: 72.3 kW / Weight: 22 tons / Dimensions: 7.0 x 3.5 x 3.5 m, steady rest

Condition: used, Year of construction: 2005, turning diameter 170 mm Max. Turning length 120 mm bar capacity 52 mm control FANUC MSX-501 travel -x1 axis 140 mm travel -x2 axis 140 mm travel -z1 axis 450 mm travel -z2 axis 410 mm Hedpfxjzyvb Ij Aftofl travel -y axis +/- 40 mm travel - b axis (spindle 2) 525 mm speeds station 1 60 - 6000 U/min spindle bore 1 62 mm speeds station 2 60 - 6000 U/min spindle bore 2 62 mm driven tools turning speeds 6.000 U/min CNC Turning- and Milling Center | MORI SEIKI - ZT 1500 Y equipped with 2 turrets for driven tools, Y-axis and bar loader. The machine is in a well-maintained condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: ZT1500Y | ZT-1500 Y | ZT 1500Y | ZT-1500-Y

Condition: used, Year of construction: 1995, Fanuc MSC 516 2 pallets, 500x500mm BT40 spindle Spindle speed: 12,000 RPM Hfjdpszgrzkjfx Aftsl 20-tool changer Coolant pressure: 20 bar Renishaw

Condition: good (used), Year of construction: 2004, turning length: 1,345 mm, turning diameter: 420 mm, spindle speed (min.): 3,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 1,280 mm, Manufacturer: Mori Seiki Co., Ltd. (Nagoya, Japan) + chuck system Machine model: NL3000MC/1250 Serial number: NL301DJ0070 Year of manufacture: October 2004 Machine weight: 7600 kg Electrical data Voltage: AC 200 V Phases: 3 Frequency: 50 Hz Rated power: 44 kVA Full load current: 127 A Spindle motor current: 200 A Interrupting capacity: 5 kA Electrical diagram number: NL301DJ0070 The machine is a CNC turning center (Mori Seiki NL series) with a nominal electrical power of 44 kVA. CHUCK SYSTEM: Manufacturer: Kitagawa Chuck: B-212A821F Chuck cylinder: S2091 Technical data Permissible pressure (when using external chuck jaws on the standard package): 2.7 MPa Hfsdpfx Afjzm Tkajtjl Maximum speed: 3000 min⁻¹ CNC turning center of the NL series (Mill Center version) with milling capability (driven tools + C-axis). The data is compiled from original Mori Seiki / DMG MORI catalogs and matches your machine's nameplate (year 2004, weight 7600 kg, 44 kVA, 200 V). Capacity ValueMax. turning diameter420 mmMax. turning length1250–1345 mm Swing over bed995 mm Swing over carriage825 mm Bar capacity90 mm (3.5") Standard chuck12" (Kitagawa B-212A821F) Travels X-axis: 260–280 mm Z-axis: approximately 1280–1370 mm (depending on the exact configuration /1250) Y-axis: option (usually ±60 mm for Y/SY versions) Spindle Max. speed: up to 4000–6000 min⁻¹ (limited to 3000 min⁻¹ with your Kitagawa chuck) Spindle bore diameter: 105 mm (approximately 91 mm with chuck) Spindle mounting: A2-8 Spindle motor power: 22/18.5 kW (30/25 HP) or up to 30 kW (depending on the version) Minimum indexing angle: 0.001° Turret (MC version) Number of stations: 10 or 12 Rotary tools: yes (max. 6000 min⁻¹) Power of rotary tool drive: 5.5 / 5.5 / 3.7 kW Indexing time: approximately 0.2–0.3 s Rapid traverses and drives Rapid traverse X/Z: up to 30 m/min Rapid traverse Y: up to 10 m/min (if equipped) C-axis: up to 300–400 min⁻¹ Electrical and other data (from your nameplate) Rated power: 44 kVA Voltage: 200 V AC, 3-phase, 50 Hz Full load current: 127 A Machine weight: 7600 kg Controller: typically MSX-850 / MAPPS

Condition: used, Year of construction: 1988, turning diameter ca. 570 mm turning length ca. 530-610 mm control FANUC ohne Gewähr x-travel ca 160-200 mm y-travel ca. 560 mm weight of the machine ca. 4,5 - 5 t ca 10 oder 12 spindle bore 52-76 mm weight of the machine ca. 4 t Hjdpfxoyiu Tpj Aftsfl

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, Swing over bed 755mm, swing over crosslide 740mm, max turning diam 366mm, max turning lenght 785mm.Live tooling, C-axis. X 260mm, Y 100mm, Z 795mm Y , Control MXS 850 III. Hjdpfxoz Arxue Aftjfl

Condition: used, Year of construction: 1996, functionality: limited functionality, turning length: 330 mm, turning diameter: 248 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 370 mm, travel distance Z-axis: 190 mm, TECHNICAL DETAILS Turning diameter: 248 mm Hfsdjzul Umspfx Aftol Turning length: 330 mm Travel range, X-axis: 370 mm Travel range, Z-axis: 190 mm Spindle bore: 45 mm Spindle speed: 6,000 rpm Tailstock quill travel: 120 mm Note: A switch on the X-axis needs to be reset.

Condition: used, Year of construction: 2006, turning length: 1,298 mm, turning diameter: 356 mm, spindle speed (max.): 4,000 rpm, controller model: MORI SEIKI MSX 850III / MAPPS III, center width: 1,250 mm, TECHNICAL DETAILS Maximum turning diameter: 1,250 mm Maximum turning length: 1,298 mm Maximum turning diameter: 356 mm Standard turning diameter: 275 mm Swinging diameter over bed: 923 mm X-axis travel: 260 mm Z-axis travel: 1,345 mm Maximum spindle speed: 4,000 rpm Spindle bore: approx. 80 mm Number of turrets: 1 Number of tool positions: 12 MACHINE DETAILS Control system: MORI SEIKI MSX 850III / MAPPS III Dimensions & Weight Hfodpfx Afjzwgqustol Dimensions (L x W x H): 5,000 × 2,300 × 2,400 mm Machine weight: 7,600 kg EQUIPMENT IRCO SIMAG loader magazine Chip conveyor Powered tools C-axis Y-axis

Condition: refurbished (used), Year of construction: 2003, functionality: fully functional, turning diameter over cross slide: 510 mm, turning length: 752 mm, turning diameter: 390 mm, spindle speed (max.): 4,000 rpm, rapid traverse X-axis: 18,000 m/min, rapid traverse Y-axis: 24,000 m/min, rapid traverse Z-axis: 24,000 m/min, feed rate X-axis: 18,000 m/min, feed rate Z-axis: 24,000 m/min, CNC Lathe MORI SEIKI ZL-2035MC – Technical Data Sheet The MORI SEIKI ZL-2035MC is a high-precision CNC lathe, ideal for advanced multi-axis turning operations, featuring dual spindles and live tool turrets. Manufactured in December 2002, it is engineered to deliver productivity and accuracy in complex machining processes. General Specifications Brand: MORI SEIKI Model: ZL-2035MC Category: CNC Lathe Year of construction: 12/2002 CNC Control: MORI SEIKI MSG-501 Machine weight: 5,900 kg Machine Dimensions: Length: 4,350 mm Width: 2,400 mm Height: 2,200 mm Machining Capacities Max swing over bed: Ø 680 mm Max swing over carriage: Ø 510 mm Hfjdpjxd Td Uefx Aftel Distance between centers: 752 mm Max turning diameter: Spindle No. 1: Ø 390 mm Spindle No. 2: Ø 294 mm Max turning length: 520 mm Bar capacity: Ø 65 mm (Ø 51 mm on No. 2) Axis Travels X Axis: No. 1: 235 mm No. 2: 175 mm Z Axis: No. 1: 520 mm No. 2: 490 mm B Axis: 505 mm Main Spindle Speed: 40 – 4,000 rpm Spindle nose: JIS A2-6 Chuck diameter: Ø 210 mm Minimum programmable C axis angle: 0.001° Spindle motor power (continuous/30 min): 11 / 7.5 kW Sub-Spindle Speed: 40 – 4,000 rpm Spindle nose: JIS A2-5 Chuck diameter: Ø 160 mm Minimum programmable C axis angle: 0.001° Spindle motor power (continuous/30 min): 7.5 / 5.5 kW Tool Turrets Turret No. 1 Number of stations: 12 Driven stations: Yes Driven tool speed: 4,000 rpm Turning/boring tool dimensions: 25x25 mm / Ø 32 mm Turret No. 2 Number of stations: 8 Driven stations: Yes Driven tool speed: 3,000 rpm Turning/boring tool dimensions: 25x25 mm / Ø 32 mm Rapid Feeds X axis rapid traverse: 18,000 mm/min Z axis rapid traverse: 24,000 mm/min B axis rapid traverse: 24,000 mm/min Manual feed for X / Z / B axes: 0 – 1,260 mm/min Included Accessories 5 live tool holders and various fixed toolholders Chip conveyor Transformer Part unloading arm Coolant tank with pumps Manuals, electrical diagrams, and CE Declaration

Condition: ready for operation (used), A Mori Seiki CNC lathe is available. Swing diameter over bed/slide: 450mm/300mm, max. turning diameter: 160mm, turning length: 525mm, travel X/Z: 135mm/560mm, bar capacity: 42mm, spindle bore: 52mm, spindle nose: JIS A2-5, spindle speed: 5000rpm, power: 7.5kW, torque: 172Nm, tool stations: 12, tailstock taper: MK4, quill diameter: 75mm, quill stroke: 80mm, rapid traverse: 12m/min. Machine dimensions X/Y/Z: approx. 2500mm/1500mm/1700mm, weight: approx. 3250kg, control: Fanuc Series 15-T. Documentation available. An on-site inspection is possible. Hjdpezipf Sjfx Aftofl

Condition: good (used), turning length: 500 mm, turning diameter: 300 mm, spindle bore: 62 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 210 mm, travel distance Z-axis: 520 mm, Mori Seiki SL-15 CNC Turning Center Machine Type: CNC Turning Center (2-Axis) Serial Number: 1899 Control System: Mori Seiki MSC-516 Hfjdpfsx Hp Ikox Aftel Maximum Turning Diameter: approx. 300 mm Maximum Turning Length: approx. 500 mm Swing Over Bed: approx. 510 mm Axis Travels X-Axis Travel: approx. 210 mm Z-Axis Travel: approx. 520 mm Spindle Nose: A2-6 Spindle Bore: approx. 62 mm Maximum Spindle Speed: approx. 4,000 rpm Spindle Motor Power: approx. 11 / 15 kW Tool Turret: 12-Station Tool Size: 25 × 25 mm Equipment & Features Hydraulic Tailstock Tool Presetter 6.5" 3-Jaw Power Chuck Coolant System Machine Weight: approx. 4,000 kg Machine Dimensions (L × W × H): approx. 2,700 × 1,600 × 1,700 mm

Condition: good (used), Year of construction: 2006, functionality: fully functional, Technical details turning diameter 660/275 mm turning length 1498 mm control Fanuc/Mori Seiki MSX 701 total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm Additional information 9-axis CNC turning and milling centre * Fanuc MSX-701 CNC control * Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. * 40-position tool magazine * 10-position turret at bottom, all positions driven * 2 x 3-jaw quick-change chuck KNCS-N 315/91 * KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system * Chip conveyor * Drain system for main spindle chuck (controlled via M function) * Drain system for tool cutting edge (controlled via M function) * Coolant gun incl. accessories * Oil mist extraction * Direct measuring system X1, X2, Y-axis * Bar loader interface * Double foot switch for both spindles * Islands and pocket programming for MAPPS * High-speed fixed cycle for MAPPS * Programm memory extension to 8 MB * Programm restart * 3-stage signal lamp * 512 MB memory card (CF card) Swing diameter over cross slide (tool spindle 1): 750 mm Swing diameter over cross slide (turret 2): 400 mm Max. turning diameter (tool spindle 1): 660 mm Max. turning diameter (turret 2): 275 mm Max. machined workpiece length: 1498 mm Max. bar material: 90 mm Travels: X1 axis (tool spindle): 750 mm Y axis (tool spindle): 420 (+/- 210) mm Z1 axis (tool spindle): 1635 + 100 mm for tool change B axis (tool spindle): +/- 120 deg., full B-axis 1 deg. indexed and 0.0001 deg. braked X2 axis (turret): 195 mm Z2 axis (turret): 1525 mm SZ axis (subspindle): 1610 mm Rapid traverse: (X1,Z1) 50 m/min. / (Y,X2,Z2,SZ) 30 m/min. Main and subspindle: Spindle speeds infinitely variable (spindle 1 + 2): 30-3000 rpm. C axis (spindle 1 + 2): 0.001 deg. Main spindle motor: 22/18.5 kW Subspindle motor: 22/18.5 kW Torque (spindle 1 + 2): 1000 Nm Hfedpfx Ajzr Hgxeftsl Disc turret: Number of tool positions: 10 Speed of driven tools: 6000 rpm. Drive power: 5.5/3.7 kW Milling spindle head: Tool holder: HSK A63 Max. speed: 12,000 rpm Drive power: 18.5/11 kW Torque: 120/44 Nm Tool changer: 40-stations Tool diameter 70/140 mm Tool length 400 mm Tool weight 8/10 kg Total power requirement 90 kVA Main dimensions Length x width x height 5301 x 2997 x 2788 mm Machine weight 26.6 t Accessories: Measuring arm (picture) tool measurement in machine Tool holder + box, reduction sleeves, driven tools Clamping jaws package Collets package

Condition: used, Year of construction: 1986, Mori Seiki MV45/45 from 1986 with Fanuc 11M control, 820 × 555 × 550 mm travels, BT 45 spindle (4.500 rpm, 7,5 kW) and Kitagawa 4th axis for simultaneous 4-axis machining. Professional through-spindle coolant retrofit by Deuschle (15 bar, M50-switched, rotary union through pull stud) and two mechanical gear stages deliver 200 Nm torque; box guideways ensure rigidity. Includes approximately 75 BT 45 tool holders with through-coolant passage and 20 pull studs. CNC CONTROL Controller: Fanuc 11M AXES Number of controlled axes: 4 Number of simultaneous axes: 4 X-axis travel mm: 820 Y-axis travel mm: 555 Z-axis travel mm: 550 4th axis / rotary table: Kitagawa SPINDLE Max. spindle speed rpm: 4.500 Hjdpezy Svujfx Aftjfl Spindle power kW (S1/S6): 7,5 / 5,5 Spindle torque Nm: 200 Spindle taper / interface: BT 45 Gearbox stages / speed ranges rpm: 2 COOLING Coolant through spindle bar: 15 EQUIPMENT & OPTIONS • Box guideways (flat slideways) — very rigid, stable machine • 4-axis simultaneous: Kitagawa 4th-axis rotary unit, hydraulically clamped, fully integrated in the control • Spindle with 2 mechanical gear stages — high torque, 200 Nm in low gear • Through-spindle coolant (IKZ) retrofitted by Deuschle: rotary union through the pull stud, hydraulic clamping/release with pressure intensifier, own 15 bar pump switched via M50 • Chip conveyor at the front, discharging to the right • Approx. 75 BT 45 tool holders included, all with through-coolant passage, plus about 20 pull studs • 4th axis (rotary table)

Condition: used, Year of construction: 2008, turning diameter 600 mm turning length 1.045 mm control MSX - 711 III MAPPS III swing diameter over support 600 mm distance between spindles 1.255 mm max. bar capacity 65 mm turning speed range - main spindle max. 5.000 min/-1 power capacity - main spindel 25 / 22 kW no. of turning speeds 2 spindle nose JIS A2-6 spindle bore 73 mm internal diameter 120 mm C-Axis 0,0001 ° chucking diameter 200 mm Speed range Tool Spindle max. 12.000 min/-1 Power rating Tool Spindle 5,5 / 3,7 kW tool taper Capto C5 internal diameter 65 mm B - Axis 0,0001 ° swivellable +/- 120 ° x-axis 685 (610 + 75) mm y-axis +/- 125 mm z-axis 1 mm number of toolpositions 12 pos. Shank height for square tool 20 mm Drill shank diameter max. 32 mm tools in tool magazin 40 pos. max. tool diameter 70 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 4 kg change-time tool to tool 1,25 sec Rapid traverse X / Z: 50 m/min Rapid traverse Y: 30 m/min Hfjdpjz At T Hefx Aftjl Rapid traverse X2 / Z2: 30 m/min total power requirement 88 kVA weight of the machine ca. 16,5 t dimensions of the machine ca. 6,0 x 4,0 x 3,0 m High-Precision 5 Achsen CNC-Turning- and Millingcenter MORI SEIKI - NT 3200 DCG / 1000 SZ - 5 Axis - Swivable Milling-Head (B-Axis) - Subspindle - lower turret - approx. 11,300 power-on hours - approx. 9,200 spindle hours

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, CNC control MORI SEIKI MSG-805 MAPPS Maximum turning diameter: Ø 430 mm Maximum turning length: 519 mm X-axis travel: 230 mm Z-axis travel: 520 mm Main spindle speed: 50–6,000 rpm Main spindle power: 15 / 11 kW Main spindle bore diameter: Ø 56 mm Maximum bar diameter: Ø 45 mm Sub-spindle speed: 5,000 rpm Turret positions: 12 Powered tool speed: 3,000 rpm Hfjdpfxozz Agyo Aftel
