Used Hydraulic Presses For Trimming for sale (28,397)

Condition: new, Year of construction: 2019, machine/vehicle number: DF0369, pressing force: 220 t, pressure:220 t passage width:1500 mm stroke:400 mm weight of the machine ca.:5,2 t dimensions:ca. 4000 x 1950 x 2900 mm return capacity:20 t total power requirement:30 kW Max Working height:500 mm :10 mm :10 mm/sec. Bljdpfx Asfxyivoproh Return Speed:25 mm/sec speed rapid traverse:10 mm/sec pestle plate:2000 x 400 mm table plate:2000 x 600 mm table height over floor:900 mm :500 l Oil cooling (electric):1,5 kW (max) measuring system:TURCK oder Balluff :S7 1500 oder PILZ PSS 4000 Monitor SIEMENS:oder OMRON

Year of construction: 2020, condition: reconditioned (used), pressing force: 400 t, machine/vehicle number: DF0317, pressure:400 t passage width:600 mm stroke:400 mm Weight of machine approx.:14 t dimensions:2380 x 1680 x 3580 mm Engine Output:36 kW Max Working height:750 mm Approaching Speed max. :10 mm/sec Bodpfx Aod E Irhsprolh Pressure Speed:10 mm/sec column diameter:230 mm Return Capacity:40 t speed rapid traverse:25 mm/sec Travel:500 mm Oil Tank Capacity:600 l Oil Cooling:1,5 kW :6 m Monitor:WEG 12 Zoll :6800 ? :4200 ? Speed increase to 80 mm/sec.:19000 ? every additional meter conveyor belt:850 ? Faster Version with approach and working speed at 60mm/sec ist available on request. Price (excl. options): 117.500,--

Condition: new, Year of construction: 2018, machine/vehicle number: DF0116 - Rev.00, pressing force: 110 t, pressure:110 t passage width:1300 mm stroke:1500 mm Weight of machine approx.:12 t Bljdpfx Aedxvfleproh dimensions:ca. 2300 x 2090 x 4200 mm return capacity:11 t Max Working height:1500 mm pestle plate:1730 x 1100 mm table plate:1730 x 1100 mm table height over floor:700 mm column diameter:140 mm Thickness of ram plate:100 mm thickness of clamping plate:100 mm Noise Level (Max.):67 dB Color machine body:7035 RAL Color moving parts:2009 RAL Colour other components:7021 RAL Colour of balcony and casing:1021 RAL motor capacity:18 kW Approaching Speed max. :300 mm/sec pressure speed:15 mm/sec Oil Tank Capacity:150 l Siemens Control System:S7 1200

Year of construction: 2020, condition: like new (used), pressing force: 150 t, pressure:150 t stroke:500 mm Weight of machine approx.:ca. 8,5 t Bodpfx Asdxvfijprolh dimensions:1200x1800x3100 mm Engine Output:10 kW Max Working height:1000 mm Approaching Speed max. :9,9 mm/sec Pressure Speed:100t = 9,9 bis 0 mm/sec Table height above ground level (approx.):1000 mm :Schmiernippel column diameter:230 verchromt mm Return Speed:25 mm/sec :500 l demand for oil:ca 400 l Maintenance Balcony:5800 ? :3900 ? :2800 ? :4800 ? :29000 ? :8200 ? Faster Version with approach and working speed at 60mm/sec ist available on request. Price (excl. options): 117.500,--

Condition: new, machine/vehicle number: DF0279, pressing force: 1,000 t, pressure:1000 t passage width:1500 mm stroke:800 mm total power requirement:91 kW weight of the machine ca.:68 t dimensions:3850 x 2900 x 6000 mm return capacity:100 t Table dimensions:1500 x 2250 mm :1500 x 2250 mm table height over floor:1300 mm pre-running speed:200 mm/sec return speed:200 mm/sec Pressure Speed:10 mm/sec :1200 l Bjdpfx Aefxyiysprslh Oil cooling (electric):1,5 kW (max) Max Working height:1000 mm :200 mm/sec Monitor:12 Zoll

Condition: used, pressing force: 30 t, machine/vehicle number: DF0139, pressure:30 t passage width:1000x1000 mm stroke:800 mm total power requirement:3 kW weight of the machine ca.:5 t dimensions of the machine ca.:3360x1300x1360 mm return capacity:3 t column diameter:75 mm traversing speed:bis 200 mm/sec. :0-10 mm/s :200 mm/sec table height over floor:900 mm Bljdsfxykhjpfx Aprsh distance table - lower edge of ram:1000 mm :126 mm diameter of piston:71 mm

Condition: used, Year of construction: 2001, machine/vehicle number: H01-3129, pressing force: 200 t, pressure:200 t passage width:1300x1300 mm stroke:1000 mm total power requirement:37 / 5,5 kW weight of the machine ca.:29500 kg dimensions of the machine ca.:2600x3000x5200 mm speeds::450 mm / freier Fall speeds::20 mm/sek tracking travel:130 / 60 ms oil pressure :283 bar capacity of oil tank:2200 L Bodsfhcc Nopfx Aprolh

Condition: new, Year of construction: 2019, machine/vehicle number: DF0329, pressing force: 350 t, pressure:350 t passage width:3000 mm stroke:900 mm total power requirement:75 kW weight of the machine ca.:60 t dimensions:2660 x 5400 x 5700 mm return capacity:35 t Table dimensions:3610 x 1600 mm :3610 x 1600 mm table height over floor:900 mm Blodpjfxygzofx Apreh pre-running speed:230 mm/sec return speed:170 mm/sec :2000 l max. working heidht:1700 mm pressure speed:21 mm/sec speed rapid traverse:200 mm/sec Oil cooling (electric):3 kW (max) :S7 1500 Monitor:WEG 12 Zoll

Condition: new, machine/vehicle number: DF0238 - Rev.00, pressing force: 20 t, pressure:20 t passage width:400 mm stroke:300 mm Weight of machine approx.:3 t dimensions:2200 x 650 x 2540 mm power capacity:ca. 4,5 kW table plate:400 x 400 mm pestle plate:400 x 400 mm Bjdpfxefxyhbj Aprelh daylight:300 mm table height over floor:950 mm :2 - 20 t :S7 1500

Condition: new, Year of construction: 2017, pressing force: 150 t, machine/vehicle number: DF0149, pressure:2x 75 / 150 t passage width:2050 x 965 mm stroke:800 mm total power requirement:Hauptmotor 22 kW weight of the machine ca.:6,5 t dimensions of the machine ca.:1500 x 1025 m :150 mm :150 mm :72 mm :2 kW :870 x 350 x 150 mm :1500 x 600 x 150 mm :1500 x 1025 x 75 mm :1500 x 1025 x 150 mm :120 mm :80 mm :350 l demand for oil:320 l :350 mm max. open height:1600 mm :15-0 mm/sec :100 mm/sec :2050 x 965 mm :6 mm :0,5 mm Bjdpfxod Aftpj Aprjlh

Condition: used, Year of construction: 2017, pressing force: 500 t, pressure:500 t passage width:1300x800 mm stroke:600 mm weight of the machine ca.:18 t dimensions of the machine ca.:2400 x 2400 x 5500 m draw back pressure:50 t Controll:Zweihandbedienung cylinder:1 Stück motor:50 kw Oil Cooling:elektrisch Bljdpfxod E Irms Aprjh column diameter:200 mm work height max.:700 mm Table dimensions:1900 x 800 mm table height over floor:1000 mm pestle plate:1300 x 800 mm pre-running speed:150 mm/sec work speed:5-10 mm/sec. return speed:150 mm/sec :1500 l quantity of oil:1400 l

Condition: new, Year of construction: 2018, machine/vehicle number: DF0199 - Rev.00, pressing force: 160 t, pressure:160 t passage width:1200 mm stroke:600 mm Weight of machine approx.:7 t dimensions:ca. 2400 x 1400 x 3400 mm return capacity:16 t Max Working height:800 mm Return Speed:25 mm/sec pestle plate:1670 x 800 mm table plate:1670 x 800 mm table height over floor:800 mm Oil cooling (electric):1,5 kW (max) Engine Output:18 kW speed of forward flow:10 mm/sec Bjdpfodxvfhox Aprslh pressure speed:10 mm/sec Travel:600 mm Oil Tank Capacity:300 l

Condition: new, pressing force: 20 t, machine/vehicle number: DF0233, pressure:20 t stroke:600 mm table surface area:2000 x 600 mm dimensions:ca. 3500 x 1200 x 2800 mm total power requirement:3 kW pre-running speed:9,9 mm/sec Bjdpfefxyi Sjx Aprjlh return speed:25 mm/sec Pressure power:180 bar :100 l weight of the machine ca.:3 t :5 Zoll

Condition: new, Year of construction: 2018, machine/vehicle number: DF0280, pressing force: 160 t, pressure:160 t passage width:1000 mm stroke:800 mm total power requirement:22 kW weight of the machine ca.:13 t dimensions:2300 x 2850 x 4000 mm return capacity:16 t Table dimensions:1430 x 1000 mm :1430 x 1000 mm table height over floor:850 mm pre-running speed:200 mm/sec return speed:200 mm/sec Pressure Speed:15 mm/sec :400 l Oil cooling (electric):1,5 kW (max) Blsdpfjd Ap Udsx Apreh Max Working height:1000 mm :200 mm/sec Monitor:10 Zoll

Condition: as good as new (ex-display), Year of construction: 2018, machine/vehicle number: DF0151 - Rev.00, pressing force: 110 t, pressure:110 t passage width:800 mm stroke:500 mm Approx. weight (w/o operational materials):5 t Measurements L x W x H:ca. 1950 x 1510 x 3145 mm Return Capacity:11 t Engine Output:20 kW Cylinder diameter:200 mm Max Working height:700 mm Bljdpfxodxrqws Aproh Approaching Speed max. :195 mm/sec Pressure Speed:1 - 15 mm/sec. Return Speed:5 - 140 mm/sec Travel:500 mm Ram plate:800 x 600 mm Thickness of ram plaet:6 Zoll Table size:800 x 700 mm Table height above ground level (approx.):900 mm Oil Tank Capacity:400 l Program Memory:200 prgms Monitor Siemens:10 Zoll Siemens Control System:S7 1200 Lightcurtains by Schmersal:700 mm Speed controlled via proportional valve for speeds between 5 to 195 mm/sec on approach, 1 to 15 mm/sec during pressure phase and 5 to 140 mm/sec during return. HMI - pressure regulation for capacity of hydraulic cylinder from 20 to 110 tons Siemens remote access for maintenance purposes Motor with energy efficiency level IE3 according to CE

Condition: new, Year of construction: 2019, machine/vehicle number: DF0362, pressing force: 250 t, pressure:250 t passage width:1800 mm stroke:600 mm total power requirement:22 kW weight of the machine ca.:24 t dimensions:ca. 3390 x 3400 x 3800 mm column diameter:160 mm return capacity:25 t max. working heidht:800 mm Table dimensions:1800 x 1600 mm :2350 x 1600 mm table height over floor:900 mm hydraulic table shift:25 mm/sec table load:5 t pre-running speed:10 mm/sec pressure speed:10 Return Speed:25 mm/sec speed rapid traverse:10 mm/sec :600 l Bjdpofxyinefx Aprolh Oil cooling (electric):1,5 kW (max) :46er / 10 my Monitor SIEMENS:10 Zoll

Condition: new, pressing force: 100 t, pressure:100 t passage width:700 mm stroke:450 mm weight of the machine ca.:6 t dimensions:ca. 3000 x 1210 x 3100 mm return capacity:10 t :22 kW Max Working height:850 mm :1 - 100 mm speed of return flow:1 - 100 mm/sec :1 - 10 mm/sec. pestle plate:1090 x 600 mm table plate:1090 x 600 mm positioning accuracy:0,1 mm table height over floor:800 mm :300 l Oil cooling (electric):1,5 kW (max) ejector:d=100 mm ejector stroke:210 mm pressure of ejector:100 t no. of ejector pins:1 Stück Bodpfx Ajfxyhqsprelh Monitor WEG:15 Zoll :2.000,-- ? :2.400,-- ? :3.000,-- ? :2.400,-- ? :5.800,-- ?

Year of construction: 2021, condition: new, pressing force: 50 t, Here are the technical data of the offered machine: If the press does not exactly meet your requirement profile, please click to request an individual offer exactly according to your needs: Contact us for an individual offer HIDROBRASIL manufactures presses exactly according to your requirements at surprisingly low prices! Technical data + information: hydraulic 50 T heating press for laboratories It is a lower piston press with an open height of 400 mm ram travel 300 mm heating platen capacity up to 250 degrees heating plate size 200x200mm weight about 1500 kg height 1950 mm hydraulics built in the press body Hydraulic tank with 100 l monitored vertical door for the press chamber pressure, position - and speed adjustable via SIEMENS S 7 1200 SIEMENS touch screen monitor with 9 inch Safety technology from SICK (C-press, hydraulic press, hydraulic press, laboratory press, laboratory) Are you looking for a custom-fit machine? Contact us for an individual offer. Bljdogrkigspfx Apreh Our hydraulic presses are manufactured according to German machinery directives, as well as European machinery directives (Directive 2006/42/EC), EC standards and EU safety regulations. Furthermore our presses exceed the Canadian and European safety requirements, because they correspond in all points to the national Brazilian safety guideline NR 12, which is based on these. Our great strength is the special machine construction and the press automation. We sell customized hydraulic presses, press brakes and impact shears at surprisingly low prices. For the hydraulics of the presses we mainly use components of leading European manufacturers.

Condition: as good as new (ex-display), Year of construction: 2022, pressing force: 400 t, Press design double column press Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Pressing force max. 4000 kN Free ripping force max. 400 kN Pressure build-up time Closed die steel to steel Max. 4 sec. Dimensions 3,800 mm long and 4,475 mm wide Max. Opening width 800 mm Stroke 800 mm Table height above floor 1100 mm Height above floor (headroom) approx. 4300 mm Hall height min. 5500 mm parallel deviation at 20°C +/- 0,1 mm Deflection Bsdpoph Uk Nefx Aprolh Determined at max. clamping force with 70% occupancy < = 0.2 mm/m Weight Total weight of press without operating materials and table plate approx. 28 t Press table Table size 1500x1500 mm Speeds Fast closing with 100 mm sec. Pressing speed 8 - 3 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders/driving cylinders 1 pc. Operating pressure max. 300 bar Pressing pressure build-up time 4 sec. Pressure accuracy during pressing stroke +/- 3 bar Main pump BOSCHREXROTH axial piston pump approx. 145 L/min Oil volume approx. HLP 46 MW 1000 liters Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Auxiliary pump BOSCHREXROTH, gear pump 10 L/min Pressure stabilization for up to 300 sec. Electrical system Main supply 400 V AC Control voltage 24 V DC Frequency 50 Hz Connection hydraulics main motor 40 kW Sliding table press with 400 T capacity, Closing speed up to 100 mm/ ( adjustable via touch screen ) Opening speed up to 100 mm/sec ( adjustable via touch screen ) Starting press speed 10 mm/sec ( adjustable via touch screen ) table top size 1500x1500mm ram size approx. 1600x1500mm Oil temperature monitoring 55 degree warning, 60 degree shutdown Automatic lubrication ( adjustable via touch screen ) Free positioning of the ram ( adjustable via touch screen ) SICK/PILZ light barriers 14 mm, front, up to 1800 mm height Hydraulic and mechanical ram protection Circuit oil cooling ( adjustable via touch screen ) Ejector in table, 20 T press force, 350mm travel Ejector moves outwards with the table Table plate milled flat, with DIN 22 T grooves Pressure adjustment from 60 T to 400 T ( adjustable via touch screen ) Travel limitation either by pressure or position Set-up mode, single stroke and cycle sequence ( adjustable via touch screen ) Swiveling control panel on the cabinet Two-hand operation, with opening button, manual/single stroke/cycle switchover button Installation, commissioning, instruction against separate charge The control is supplied by SIEMENS. ( S 7 1200 ) Also the touch screen monitor with 9 inch. The remote maintenance unit SECOMEA -Ethernet is included in the delivery. The side of the press has two 1000 mm high and 800 mm wide windows with double doors. (sliding table press, hydraulic press, hydraulic press, double column press)

Condition: new, Year of construction: 2021, pressing force: 17 t, Here are the technical data of the offered machine: If the press does not exactly match your requirement profile, please click to request an individual offer exactly according to your needs: Contact us for an individual offer HIDROBRASIL manufactures presses exactly according to your requirements at surprisingly low prices! Technical data + information: Hydraulic 17 T single column press Single column press with 17 T capacity, suitable for continuous shift operation, with these basic data: a) Traversing speed 10 mm/sec. downwards, b) opening speed up to 25 mm/sec c) starting pressing speed 10 mm/sec. d) table size 400x400 mm e) ram size 200x200 mm, with T grooves and central cylinder clamping f) Overall size approx. 1150x800x1750 mm g) oil temperature display on oil tank h) pressure adjustment from 5 T to 17 T ( adjustable by knob ) i) Hand lever operation with two speeds j) Machine body powder-coated, or double-painted k) Control cabinet supply line from above with 3000 mm cable and 16 Ampere plug l) assembly, commissioning, instruction against separate calculation Bjdogrki Sspfx Aprolh Press design Single column press Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Press force max. ( at 250 bar ) 170 kN Free ripping force max. 10 kN Pressure build-up time Closed die Steel to steel Max. 2 sec. Dimensions Max. Opening width 250 mm Stroke and min. opening 100 mm Table height above floor 850 mm Height above floor (headroom) approx. 2200 mm Hall height min. 2.500 mm parallel deviation at 20°C +/- 0,1 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.3 mm/m Weight Total weight of press without operating materials approx. 1 to Speeds Fast closing with 10 mmSec. Press speed 10 - 0 mmSec Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders 1 pcs. Operating pressure max. 250 bar Pressing pressure build-up time . 2 sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump Gear pump approx. 6 L/min Oil volume approx. HLP 46 MW 100 liters Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Electrical system Main supply 400 V AC Control voltage hydraulic pumps 24 24 V DC V DC Frequency 50 Hz Hydraulic connection Main motor 2.2 kW Total connection Approx. 3 kW Design The press is designed as an oil-hydraulic single-column press. The hydraulic system and the tank are located on the top and inside of the press, respectively. Hydraulic unit The hydraulic system is mounted on the top of the press. Safety devices For the scope of delivery described, the press complies with the valid safety regulations according to UVV, as well as with the standards and directives valid for the EU, in each case in the latest version. Electrical system / control system The control cabinet with control, power and safety components is located on the right side of the press. The press is operated by a hand lever control.

Condition: used, Year of construction: 2016, machine/vehicle number: 4303, pressing force: 500 t, pressure:500 t passage width:2100 x 1500 mm stroke:1000 mm total power requirement:62 kW weight of the machine ca.:39 t dimensions:5100 x 2800 x 4040 mm return capacity:40 t Main cylinder:2 Stück column diameter:Hauptzylinder 360 mm Blsdpfsdyynvex Aproh Table dimensions:2100 x 1500 with T-Nute mm Ram size:2100 x 1500 mm table height over floor:850 mm pre-running speed:300 mm/sec return speed:300 (bei 20T Stößelgewicht) mm/sec Pressure Speed:200T = 28 mm/sec Oil Tank Capacity:ca. 1000 l Auxiliary cylinder:2 Stück column diameter:Hilfszylinder 120 mm Total size Table Tops:ca. 2750 x 1600 mm Total size of plunger plates:ca. 2750 x 1600 mm Pressure Speed:300T = 20 mm/sec Pressure Speed:500T = 6 mm/sec Retract force of the plunger:40 t Tension of the control chain:24 V voltage:400 V Frequency:50 Hz Axial piston pump (REXROTH/Bosch A4VSO125):290 lt/min Daylight Opening:1500 mm Hydraulic block:REXROTH pressure control:über PLC (Mindestdruck 50T) Cylinder:4 x ?90 x 70 mm stroke length max.:300 über PLC einstellbar mm Outejection speed forward:95 mm/sec. Outejection speed return:240 mm/sec. Capacity:4 x 15T bei 250 bar t Pressure setting:über Monitor von 50-500T t Pressure constant posture:0-900 sec Hydraulics tank:2000 l Siemens Control System:S7 300 Storage capacity:200 Programme Electronics from German manufacturers:SIEMENS/MÖLLER Tax desk:auf Schwenkarm Light sensors sick:1500 auf der Vorderseite mm

Condition: new, Year of construction: 2022, pressing force: 15 t, Single column press with 15 T capacity suitable for continuous shift operation a) travel speed 10 mm/sec. downwards, b) opening speed up to 25 mm/sec c) starting pressing speed 10 mm/sec d) table size 400x400 mm Bodpfoitylgjx Aprolh e) ram size 200x200 mm, with T grooves and central cylinder clamping f) Overall size approx. 1150x800x1750 mm g) oil temperature display on oil tank h) pressure adjustment from 5 T to 17 T ( adjustable by rotary control ) i) Hand lever operation with two speeds j) Machine body powder-coated, or double-painted k) Control cabinet supply line from above with 3000 mm cable and 16 Ampere plug l) assembly, commissioning, instruction against separate calculation Press design Single column press Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Press force max. ( at 250 bar ) 150 kN Free ripping force max. 10 kN Pressure build-up time Closed die Steel to steel Max. 2 sec. Max. Opening width 400 mm Stroke and min. opening 350 mm Table height above floor 850 mm Height above floor (headroom) approx. 1900 mm Hall height min. 2.500 mm Parallel deviation at 20°C +/- 0.1 mm Determined at max. clamping force with 70% occupancy < = 0.3 mm/m Weight Total weight of the press without operating materials approx. 1.1 to Fast closing with 10 mm sec. Press speed 10 - 0 mm sec. Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Number of pressing cylinders 1 pc. Operating pressure max. 290 bar Pressing pressure build-up time . 2 sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump Gear pump approx. 9 L/min Oil volume approx. HLP 46 MW 80 liters Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Electrical system 400 V AC Main supply Control voltage 24 V DC Hydraulic pumps 24 V DC Frequency 50 Hz Hydraulic connection Main motor 3 kW Total connection Approx. 5 kW Equipment control cabinet Protection class IP 54 Reserve space Approx. 20 Cooling no Interior lighting no Operating mode switch Lockable yes

Condition: as good as new (ex-display), Year of construction: 2021, pressing force: 20 t, Hydraulic 20 T single-column production press for the manufacture of lightweight concrete parts. Here are the technical data of the offered machine: If the press does not exactly meet your requirements, please click here to request an individual offer exactly according to your wishes: Contact us for an individual offer HIDROBRASIL manufactures presses exactly according to your wishes at surprisingly favourable prices! Technical data + information: a) Closing speed up to 10 mm/sec b) Opening speed up to 20 mm/sec c) Maximum open height 300 mm d) Pressing speed 4 - 10 mm/sec. ( adjustable via rotary control ) e) Die size 600x800 mm f) Ram size 950x600 mm g) Manual lubrication (via grease nipple) h) Pressure setting from 5 T to 20 ( adjustable via rotary control ) i) Travel 300 mm j) Installation, commissioning, instruction at extra charge Technical Data Press type C Press, hydraulic Thermal neutral 80 - 120 °C Number of operating sides 1 side Forces Pressing force max. 200 kN Free ripping force max. 10 kN Pressure build-up time Closed die Steel on steel Max. 3 sec. Dimensions Max. Opening width 350/50 mm Stroke 300 mm Table height above floor, approx. 900 mm Height above floor (headroom) approx. 1900 mm Hall height min. 2,500 mm Parallel deviation at 20°C +/- 0.4 mm Deflection Determined at max. clamping force with 2/3 occupancy < = 0.6 mm/m Weight Total weight of the press without operating materials approx. 2.2 to Speeds Fast closing with 10 mm sec. Press speed 10-5 mm sec. Bjdpsia Nc Tsfx Aprolh Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to max. 78 db(A) DIN 45635-T16-KL3 Hydraulics Number of press cylinders 1 pc. Plus 1 ejector, 110 mm stroke, max. operating pressure 255 bar Pressing pressure build-up time 03. apr sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH/ASC approx. 6 L/min Oil volume approx. HLP 46 D 100 litres Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Electrical system Main supply 400 V AC Control voltage 24 V Frequency 50 Hz Hydraulic connection Main motor 3 kW Total connection Approx. 4 kW (C-press, hydraulic press, hydraulic press, concrete press) Are you looking for a customised machine? Contact us for an individual offer. Our hydraulic presses are manufactured in accordance with German machinery directives, as well as European machinery directives (Directive 2006/42/EC), the EC standards and EU safety regulations. Furthermore, our presses exceed the Canadian and European safety requirements, as they comply in all points with the national Brazilian safety directive NR 12, which is based on these. Our great strength is the construction of special machines and press automation. We sell customised hydraulic presses, press brakes and impact shears at surprisingly favourable prices. For the hydraulics of the presses, we mainly use components from leading European manufacturers.

Condition: as good as new (ex-display), Year of construction: 2020, pressing force: 400 t, Hydraulic 400 to column press suitable for continuous shift operation, with these basic data: a) Closing speed 100 - 450 mm/sec. b) Opening speed 50 - 250 mm/sec ( adjustable via touch screen ) c) Pressing speed 5 - 60 mm/sec ( adjustable via touch screen ) d) Piston accumulator with approx. 4 nitrogen bottles e) Table size (clamping surface) 2700 x 1700mm ( seen from the front, between the columns ) f) Total table size 3400 x 1700mm g) 28 T-slots according to customer requirements h) Table, ram and press head are annealed stress-free. i) column diameter 250 mm j) slide size 3400 x 1700mm (clamping surface 2700 x 1700mm ) k) Total size of the machine approx. 3900 x 2200 ( at the bottom ) x 5700 mm height l) Oil temperature monitoring ( adjustable via touch screen ) m) Automatic lubrication ( adjustable via touch screen ) n) Free positioning of the ram ( adjustable via touch screen ) o) KEYENCE light barriers 14 mm on front and rear side p) Circuit oil cooling ( adjustable via touch screen ) q) Pressure holding valve 0 to 600 sec. ( adjustable via touch screen ) r) Table top size 3400 x 1700mm, plane milled s) Laterally monitored doors, 1200mm high, 1000mm wide t) RITTAL control cabinet, 2200 mm wide, up to 20 m from the press u) Pressure setting from 50 to 400 tons ( adjustable via touch screen ) v) Travel limitation optionally via pressure or position w) Programming mode, set-up mode, single stroke + continuous stroke (adjustable via rotary switch ) x) Swivelling control panel with 15 inch touch screen monitor y) Two-hand operation on both sides z) Prepared for automatic material feed ( SIEMENS S 7 1500 ) aa) Machine body primed and painted bb) assembly, commissioning, instruction against separate charge The hydraulics of the presses we offer are completely based on BOSCH-REXROTH/Parker/HAWE components. In the switch cabinet only components are used (SIEMENS) which are easily available in Germany. The safety technology comes completely from SICK except for the light barriers. The control system is supplied by SIEMENS. ( S 7 1500 ) as well as the touch screen monitor with 15 inch. The SIEMENS remote maintenance unit SECOME -Ethernet is included in the scope of delivery. SPECIAL FEATURE: the design chosen by us with two press cylinders and the piston accumulator make it possible to supply the full power with a main motor of 90 kW. Below under 1.3 the technical details Technical data Press design Press design Column press Thermally neutral 80 - 120 °C Number of operating sides 2 sides Forces Pressing force max. 4,000 kN Free ripping force max. 600 kN Pressure build-up time Closed tool steel to steel Max. 2 sec. Dimensions - intended minimum tool height 600 mm Max. Opening width 1600 mm Stroke and min. opening 1000/600 mm Table height above floor 820 mm Height above floor (headroom) approx. 5700 mm Hall height min. 7000 mm Parallel deviation at 20°C +/- 0,1 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.17 mm/m Blsdpfsg Iihwox Aprjh Weight Total weight of the press without operating materials approx. 52 To Speeds ( see attached cycle diagram ) Fast closing 100 - 450 mm/s Pressing speed At F max.

Condition: used, Year of construction: 2019, pressing force: 200 t, pressure:200 t stroke:800 mm total power requirement:25 kW draw back pressure:16 t :1 Stück Column-Diameter:150 mm dayligth:1200 mm Ram Height:1000 mm Blsdpfx Aped E Irljrsh Ram size:1300 x 2220 mm table surface area:1500 x 1300 mm :1300 x 2220 mm :820 mm table surface area:1500 x 1300 mm table height:800 mm table load:8 t pre-running speed:1 - 9,8 mm/sec return speed:2,5 - 25 mm mm/sec quantity of oil:300 l weight of the machine ca.:17 t Dimensions (L/W/H):2420 x 1300 x 4782 mm :0 - 200 T :1 - 10 mm :elektrisch
