Used Mazak Quick Turn 20 for sale (334)

Condition: excellent (used), Year of construction: 2007, turning length: 535 mm, spindle bore: 65 mm, travel distance X-axis: 225 mm, travel distance Z-axis: 535 mm, spindle motor power: 26,000 W, total height: 1,900 mm, total length: 2,900 mm, total width: 2,300 mm, overall weight: 4,380 kg, CNC Lathe MAZAK - QTN 200-II MACH-ID 9481 Make: MAZAK Type: QTN 200-II Control: Mazatrol Matrix Nexus Gedpfx Aeyyxh Tsf Asbl Year: 2007 Max. turning Ø:610mm X-Axis: 225mm Z-Axis: 535mm Spindle bore: 65mm Speedrange: 5000Rpm Spindle power: 26kW ATC / revolver:12 Chip conveyor: Yes Tool eye: Yes Hours: 5049H Length: 2900mm Width: 2300mm Height: 1900mm Weight: 4380kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 1,120 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, controller manufacturer: Mazak, controller model: Mazatrol M640, workpiece length (max.): 2,820 mm, workpiece width (max.): 655 mm, workpiece height (max.): 640 mm, workpiece weight (max.): 800 kg, table width: 510 mm, table length: 1,460 mm, overall weight: 6,100 kg, number of slots in tool magazine: 30, tool length: 350 mm, tool diameter: 110 mm, tool weight: 18,000 g, Equipment: documentation/manual, rotational speed infinitely variable, Mazak VTC 200B in very good condition for sale. The machine is fully operational and can be inspected under power at any time. TECHNICAL SPECIFICATIONS: Work Table: Table size 510 x 1,460 mm Max. table load: 800 kg Travel distances: X-axis 1,120 mm, Y-axis 510 mm, Z-axis 510 mm Rapid traverse speed: X/Y/Z-axis 30 m/min Feed rate: 1 - 8,000 mm/min Distance spindle nose to table: 180~690 mm Working spindle: Speed range 40 - 10,000 rpm Tool holder: CAT 40 Main drive power: 15 kW Max. torque: 98 Nm Gbsdpfsy Rarnex Af Ajl Tool magazine: Number of tool stations 30 Max. tool diameter: 80 mm (110 mm with adjacent station empty) Max. tool length: 350 mm Max. tool weight: 8 kg Machine data (standard configuration): Total connected load: 22.7 kVA Machine weight, approx. 6,000 kg Machine dimensions (L x W x H), approx. 3.00 x 2.90 x 2.80 m

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 1,660 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, workpiece length (max.): 4,000 mm, workpiece width (max.): 655 mm, workpiece height (max.): 640 mm, workpiece weight (max.): 1,000 kg, spindle speed (max.): 12,000 rpm, coolant supply: 16 bar, input voltage: 400 V, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, For sale here is a Mazak VTC 200C II including a Kitagawa rotary table (4th axis). The machine is in very good condition and immediately ready for operation. Inspection under power is possible at any time. Transport and installation can be offered upon request. Technical Data: Control: MAZATROL 640M Machine width: 2819 mm Machine height: 2870 mm Machine weight: 9100 kg Table length: 2000 mm Table width: 510 mm X-axis travel: 1660 mm Y-axis travel: 510 mm Z-axis travel: 510 mm Equipment: - Number of tools: 30 - Spindle power: 15 kW - Spindle speed: 12,000 RPM - Through-spindle coolant 16 bar - External coolant Gbodpfx Ajy Ndzdjf Aol - Renishaw measuring probe OMP60 - Kitagawa 4th axis - Automatic warm-up function The main spindle was replaced or renewed in 2025.

Condition: good (used), Year of construction: 1992, functionality: unexamined, turning length: 500 mm, turning diameter: 300 mm, For sale: Godjy Huvyjpfx Af Aebl 1 used CNC lathe Manufacturer: Yamazaki Mazak Corp. Model: Quickturn 10N-U Year of manufacture: 5/1992 Specifications: Spindle speed: 36 – 3,600 rpm Octagonal turret Fully automatic tailstock Max. workpiece length: 507 mm Turning diameter: 300 mm The machine can be viewed at our warehouse in 09599 Freiberg.

Condition: used, Year of construction: 2004, turning diameter: 660 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 35 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,045 mm, total height: 2,600 mm, total length: 3,820 mm, total width: 2,060 mm, overall weight: 10,400 kg, CNC Turning Milling centre with Second Spindle CNC Control Mazatrol PC Fusion CNC 640 MT PRO Turning diameter 550/660 mm Turning length 1016 mm Spindle bore diameter 65 mm Spindle speed 35-5000 R/min X-axis movement 580 mm Y-axis movement 160 mm Z-axis movement 1045 mm B-axis travel 225 ° mm Godpfx Afoy Nytpj Ajbl C-axis indexing 360° Spindle nose A2-6 Tool Taper Capto C6 Number of tools in magazine 40 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: good (used), Year of construction: 2015, functionality: fully functional, Description: The machine is in good technical condition; testing is possible upon prior arrangement. It is an ideal machine for complete machining in a single setup (turning + milling). Equipment and specifications: - Main spindle + subspindle (complete machining from both sides) - Milling spindle with B-axis - Mazatrol SmoothG control - Tool magazine with 36 stations Capto C6 / PSC63 - Internal coolant supply - Large amount of accessories (jaws, clamps, holders, etc.) Gedpfxey Rgcms Af Aobl - Includes functional postprocessor for SolidCAM - Significant time and cost savings when implementing the machine into production

Condition: used, Year of construction: 2009, functionality: fully functional, machine/vehicle number: 213294, workpiece length (max.): 1,000 mm, The Mazak INTEGREX 200-IV T CNC lathe is an advanced 5-axis turning and milling center that combines turning and milling functions in one device, used in the aerospace, automotive and tool manufacturing industries. Gjdpfxsv R Uv Aj Af Aobl The machine is in very good condition; it worked 5 days a week for 8 hours. In recent years, it has been used sporadically. Liquidation of a service plant.

Condition: used, Year of construction: 2018, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 820 mm, travel distance Z-axis: 720 mm, controller model: Mazatrol SmoothG, table width: 820 mm, table length: 3,500 mm, overall weight: 16,500 kg, spindle speed (max.): 12,000 rpm, operating hours of spindle: 3,679 h, spindle motor power: 22,000 W, number of slots in tool magazine: 48, input voltage: 400 V, type of input current: AC, Equipment: chip conveyor, CNC Vertical Machining Center MAZAK VTC-820/30 (Year of manufacture 2018 / Commissioned 2019) The MAZAK VTC-820/30 is a high-performance CNC vertical machining center designed for precise and efficient machining of large workpieces. With generous travel distances of 3,000 mm on the X-axis, 820 mm on the Y-axis, and 720 mm on the Z-axis, this machine is especially suitable for long and complex components in mechanical engineering, mold making, and general metalworking. The robust worktable, measuring approximately 3,500 × 820 mm, allows for the accommodation of large-dimensioned workpieces. The powerful main spindle, with speeds up to 12,000 rpm and a drive power of around 22 kW, ensures high metal removal rates and accuracy. The CAT 40 (ISO 40) spindle taper provides broad tool compatibility. The machine is equipped with a state-of-the-art MAZATROL SmoothG control system, offering intuitive operation, fast programming, and high process reliability. The 48-position tool changer enables flexible and efficient production processes, even for complex manufacturing tasks. To ensure optimal production conditions, the machining center features through-spindle coolant supply, a chip conveyor, and a lubricant preparation system. With a machine weight of approximately 16,500 kg, the VTC-820/30 offers outstanding stability and vibration damping, which has a positive effect on surface quality and dimensional accuracy. Overall, this is a modern and versatile vertical machining center that delivers high precision, performance, and reliability for industrial manufacturing applications. With us, you are in the best hands – professional, reliable, and passionate about machinery! Gbjdpfx Ajyipy Rof Ajl PS CNC Service Germany GmbH & Co. KG All information without guarantee.

Condition: used, Year of construction: 2023, MAZAK - QTE-200MY SG - 2023 - 825 working hours only - maximum turning diameter: 695 mm - standard machining diameter: 235 mm - chuck size: 8" - maximum machining length: 535.0 mm - maximum machining diameter: 340 mm - maximum bar diameter: 65 mm - Ø65 mm with chuck BR08A615 - Ø52 mm with chuck B208A615 - maximum chuck load: 200 kg - maximum workpiece weight (shaft machining): 500 kg Gbsdpfxoy Hf Els Af Asl - distance from spindle nose to tailstock: 81 – 686 mm Main Spindle - maximum speed: 5000 rpm - minimum speed: 35 rpm - spindle nose: JIS A2-6 - acceleration / deceleration time: 2.64 s - motor power (25% duty): 15.0 kW - motor power (continuous): 11.0 kW - maximum torque: 167 Nm Turret (Tool Head) - number of stations: 12 - external turning tool size: 25 mm - internal turning tool size: 40 mm - drill tool size: 20 mm - Mmilling tool size: 20 mm - threading tool size: M20 - indexing time (one step): 0.23 s - indexing time (full rotation): 0.63 s - driven tool power (continuous): 3.7 kW - driven tool power (40% duty): 5.5 kW - max. driven tool speed: 4500 rpm - min. driven tool speed: 20 rpm - max. driven tool torque: 47 Nm Tailstock - taper: MT No.5 - stroke: 565 mm - maximum thrust force: 5000 N Axis Movements - rapid traverse X: 30 m/min - rapid traverse Y: 10 m/min - rapid traverse Z: 30 m/min - C-axis speed: 555 rpm - travel X: 215 mm - travel Y: 100 mm - travel Z: 605 mm Additional - coolant tank capacity: 225 L - coolant pump: MTA70H-250 A-W-A-B (GRUNDFOS) - number of pumps: 1 - pump power: 0.25 kW - machine power consumption (40%): 27.8 kVA - continuous power consumption: 22.0 kVA - air pressure: 0.5 MPa - air consumption: 370 L/min Machine Dimensions - spindle center height: 1020 mm - length: 2785 mm - width: 1690 mm  - height: 1725 mm - weight: 4650 kg

Condition: ready for operation (used), Year of construction: 2000, operating hours: 10,974 h, travel distance X-axis: 1,120 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller manufacturer: MAZATROL, controller model: Fusion 640 M, table width: 510 mm, table length: 1,460 mm, table load: 800 kg, overall weight: 6,100 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 7,500 W, tool weight: 8,000 g, number of axes: 3, This 3-axis Mazak VTC-200B was manufactured in 2000 and features a rapid traverse of 36 m/min and both internal and external cooling systems. In 2019, it received a new spindle motor and spindle, along with recirculating ball screws in the X and Y axes. Consider the opportunity to buy this Mazak VTV-200B vertical machining centre. Contact us for more information. - Distance Table Surface to Spindle Nose: 180-690 mm- Spindle Taper: SK 40 CAT- Max Tool Diameter: 80 mm (110 mm with free adjacent pockets)- Max Tool Length: 350 mm- Accessories/Features: EIA/ISO programming, Automatic tool length measurement system, Synchronous tapping, 3 free M functions, 1 complete set of manuals- Working Hours (Servo X-Axis): 76,203 hours- Working Hours (Spindle): 75,952 hours Additional equipment • chip conveyor is included Machine Benefits Qualitative Machine Benefits • 2019: new spindle motor and spindle, recirculating ball screws in x and y axes • 2024: new recirculating ball screw in x axis due to a material defect. Technical Machine Benefits • Rapid traverse: 30 m/min • Workpiece: Automatic Tool Changer (ATC), Capacity: 24 positions • Tools: coolant pump: 5-bar • Tools: internal and external cooling Extra Information Machine still under power Gbjdpfoyaaw Uex Af Ajl Technical Specification Through-spindle Coolant Yes

Year of construction: 2007, condition: ready for operation (used), - USED - 8-AXIS CNC LATHE WITH MILLING HEAD, DOWN TURRET HEAD AND COUNTER SPINDLE MAX ROTATING DIAMETER: 660 mm MAX TURNING LENGTH: 1495 mm MAX TURNING DIAMETER: 660 mm BAR CAPACITY: 65 - 65 mm SPINDLE: 35-5000 rpm; 22 kW; 254 mm COUNTER SPINDLE: 35-5000 rpm; 18,5 kW; 254 mm HEAD: CAPTO C6 ; -30°+195° ; 15-12000 rpm; 18,5 kW Gbodpfeyy Thzox Af Aol X-AXIS TRAVEL: 580 mm X2-AXIS TRAVEL: 150 mm Y-AXIS TRAVEL: 160 mm Z-AXIS TRAVEL: 1545 mm Z2-AXIS TRAVEL: 1490 mm B-AXIS TRAVEL: 1550 mm RAPID FEEDS X-Y-Z: 38 - 26 - 38 m/min TURRET HEAD: 9 POS TOOL MAGAZINE: CHAIN-TYPE ; 80 POS HIGH PRESSURE COOLANT: 18 Bar CONTROL UNIT: MAZATROL MATRIX WEIGHT: 11800 Kg OVERALL DIMENSIONS: 5090 x 3270 x 2830 mm ACCESSORIES: SWARF CONVEYOR ; PAPER FILTER ; TOOL SETTER

Year of construction: 2021, operating hours: 7,990 h, condition: used, machine/vehicle number: 318657, Power: 42.55 kVA, weight: 5,600 kg, 16-position tool changer, driven tools, Y-axis, chip conveyor, 1 tool cabinet with 7 drawers, with accessories, 1 pallet with tools, 1 lot of clamping jaws, !!!Collection: 08+09 June 2026!!! Gbodjyztf Aspfx Af Asl

Condition: good (used), Description: The machine is in good technical condition, with the possibility of testing by prior arrangement. Maximum turning diameter: 660 mm Maximum swung diameter: 660 mm Main spindle: - Speed range: 35–5,000 rpm - Main drive power: 22/15 kW - Maximum torque: 349 Nm - Spindle bore: 76 mm - Chuck diameter: 210 mm - Indexing (C axis): 0.0001° Sub spindle: - Speed range: 35–5,000 rpm - Power (10 min/continuous): 18.5/15 kW - Maximum torque: 326 Nm - Chuck diameter: 210 mm - Indexing (C axis): 0.0001° Coolant tank capacity: 300 l Machine power supply: 66 kVA Operating voltage: 400 V / 50 Hz Air pressure: 5 bar, 500 l/min Control system: MAZATROL Fusion 640 MT Flush cooling: - Pump capacity: 20 l/min - Pump pressure: 5 bar Accessories: - Technical documentation - Chip conveyor with coolant - Tool magazine for 20 tools - B axis (positioned at 0.001° increments) - C and Y axes - Sub spindle angular position indexing - Synchronization of main and sub spindle - Tool presetting system (Tool Eye) - Front door locking - 20-position tool magazine - Complete cooling system - Interface for IC memory card Godpfx Aey Amqzef Asbl

Condition: used, Year of construction: 1998, turning diameter / mm turning length / mm control / Technical Specifications Working Area Max. swing diameter: 540 mm Max. turning diameter: 540 mm Max. turning diameter over ways: 520 mm Max. turning length: 1029 mm Godpfoyyqthsx Af Ajbl Main Spindle Speed range: 35–5,000 rpm Main drive power: 22 kW Max. torque: 349 Nm Spindle nose: A2 – 6 inches Spindle bore: 61 mm Spindle positioning C-axis: 0°–360°/0.001° Tool turret Tool turret type: Single-spindle turret Driven tools Speed range: 15–6,000 rpm Drive power: 7.5 Kw Max. torque: 103 Nm Tool magazine Number of tool positions: 40 Max. tool weight: 7 kg Machine weight: approx. 5700 kg A wide range of accessories included – see photos A backup from 3 September 2012 is available

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 157626, Manufacturer: Mazak Model: Integrex 200-2SY Controller: Mazatrol PC Fusion CNC 640 Robot NOT included Max. Machining diameter: 540 mm Max. Machining length: 1018 mm Spindlebore: 51 mm Spindlepower: 22 kW 5000 rpm Travel: X = 530 mm Gedpfx Afjvlxf De Ajbl Z = 1065 mm Machine weight: 7800 kg. Machine dimensions: L=5200 x W=2500 x H=2750 mm

Condition: used, Year of construction: 2010, Mazak VTC820/30 3-Axis Machining Centre. S/No. 200131 (2010) with Mazatrol Matrix Control, X/Y/Z Travels 3000/800/720mm, Table 3500mm x 820mm, Spindle Speed 18,000rpm, Spindle Taper BT40, B Axis Swivel Head +/- 110, Removable Centre Partition. Country of Origin: United Kingdom Gedpfx Aoy Ib Ryjf Aobl Please Note: There are no loading facilities on site, dismantling and loading will be at the cost of the purchaser. Location: These lots are located in Birmingham & Wolverhampton, UK. Please Note: There are no loading facilities on site, dismantling and loading will be at the cost of the purchaser.

Condition: good (used), Year of construction: 2000, Parts shown by hand not come. Tool cabinet and cutting tools not come. Only tool holders will come. Gbjdpfxjx Atyaj Af Ajl

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 510 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 460 mm, controller model: Mazatrol Fusion 640M, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 510 mm Travel Y-axis: 510 mm Travel Z-axis: 460 mm Swivel range A-axis: +30° / -120° Rotation range C-axis: +/- 360° Feed rate range (X-/ Y-/ Z-axis): 1 - 50,000 mm/min Rapid traverse (X-/ Y-/ Z-axis): 50 m/min Indexing A and C: 0.001° Swivel time 90° A/C: 1.9 / 1.5 s Gbodpfx Afsyxmq Tj Aol Main spindle Max. spindle speed: 12,000 rpm Spindle drive power: 22/15 kW Tool holder: ISO 40 Spindle diameter: 80 mm Acceleration time to max. speed: 1.7 s Worktable Clamping surface: 500 x 400 mm Number of T-slots: 5 T-slot width: 18 mm T-slot spacing: 80 mm Distance from spindle to table: 190 - 650 mm Max. workpiece size: 500 x 500 x 405 mm Max. table load: 300 kg Tool changer Max. number of tool positions: 40 Max. tool diameter: 80 mm Max. tool diameter with adjacent spaces free: 125 mm Max. tool length: 300 mm Max. tool weight: 8 kg Tool change time: 4.5 s MACHINE DETAILS Control: Mazatrol Fusion 640M Total power requirement: 51 kVA Dimensions & Weight Space requirement: 3.4 x 3.7 x 2.8 m Machine weight: 7.5 t EQUIPMENT Hydraulic unit Coolant system Chip tray Tool measurement Documentation

Condition: ready for operation (used), Year of construction: 2021, spindle speed (max.): 4,000 rpm, travel distance X-axis: 450 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 960 mm, number of axes: 5, This 5-axis Mazak INTEGREX J-200 S was manufactured in 2021. It features a maximum machining diameter of 500 mm, X-axis travel of 450 mm, Y-axis travel of 200 mm, and Z-axis travel of 960 mm. The machine is equipped with a 36-tool magazine and a maximum spindle speed of 4,000 rpm. If you are looking to get high-quality mill-turn capabilities, consider the Mazak INTEGREX J-200 S machine we have for sale. Contact us for further details. • Control: Smooth G • Distance between spindles: 1000 + 440 mm • Max machining diameter: 500 mm Gbodpfxsyxc N Ej Af Ajl • Spindle attachment: A2-6 • Max bar capacity: 65 mm • Spindle bore: 76 mm • Tool magazine: 36 Capto Additional equipment • Chip conveyor: Mayfran belt type

Condition: excellent (used), Year of construction: 2005, machine/vehicle number: 181174, operating hours: 5,600 h, 5 axis simultaneously and 5 axis free form - CAP Tool system! Accumulated time: Power on: 2026:04'40" Auto open: 1323:07'43" Auto cut: 669:16'50" Total cut: 5606:49'54" Total time: 2028:04'40" Bought new from Mazak factory. Excellent and working condition. Comes with different machining tools. You're welcome to test and see the machine. Year of manufacture: 10-2005 - Max. Schwingdurchmesser …………….…… Ø660 mm - Max.Bearbeitungsdurchmesser ( oberer / unterer revolver ) ………..Ø660 mm / Ø270 mm - Max. Bearbeitungslange ……………....…1016 mm - X – Achsen Verfahrweg ( oberer revolver ) ……………...………….580 mm - X2 – Achsen Verfahrweg ( unterer revolver ) …………….150 mm - Z – Achsen Verfahrweg ( oberer revolver ) …………….....…..1045 mm - Z2 – Achsen Verfahrweg ( unterer revolver ) …………….….990 mm - B – Achsen Verfahrweg ………….…………….….225° - C – Achsen Verfahrweg ………….…………….360° - Spannfuttergrose ……………... 8 “ - Hauptspindeldrehzahl ……………..….5000 o / min - Hauptspindelbohrung ……………...……………. Ø51 mm - Min. Hauptspindelindexierung ……………..………… 0.0001 ° - Spannfuttergrose 2. spindel ……………..………….. 8 “ - Drehzahl der 2. spindel …………….…5000 o / min - Verfahrweg des 2. spindelstocks ( W – Achsen ) ……………..…….. 1050 mm - Eilganggeschwindigkeit des 2. spindelstocks ( W – Achsen ) …….. 30000 mm / min - Min. Indexierung der 2. spindel …………… 0.001 ° - Revolvertyp ( oberer )…………… mit ATC - Werkzeugschafthohe ( oberer )……………..….. 25 mm - Bohrstangenschaftdurchmesser ……………..….. Ø40 mm - Revolvertyp ( unterer )…………….…… trommelrevolver mit 9 stationen - Werkzeuganzahl …………….….. 9 Werkzeuge - Werkzeugschafthohe ( unterer )…………….…….. 25 mm - Bohrstangenschaftdurchmesser …………….... Ø32 mm - Revolverschaltzeit ( unterer )……………. 0.14 s / 1 schaltschritt - Frasspindeldrehzahl …………….. 12000 o / min - Bearbeitungskapazitat der frasspindel ……………. Frasen : Ø100 mm , schaftfrasen : Ø32 mm , Bohren : Ø30 mm , Gewindebohren : M27 -: X – Achsen ( oberer ) …………… 38000 mm / min : X 2– Achsen ( unterer ) ………….…… 38000 mm / min - : Y – Achsen …………… 26000 mm / min -: Z – Achsen ( oberer ) …………….… 38000 mm / min -: Z2 – Achsen ( unterer ) ……………..… 38000 mm / min - Eilganggeschwindigkeit : C – Achsen …………….… 400 o / min - Tippvorschubgeschwindigkeit : X – Achsen ( oberer ) ……….…… 2000 mm / min - Tippvorschubgeschwindigkeit : X2 – Achsen ( unterer ) ………..… 2000 mm / min - Tippvorschubgeschwindigkeit : Y – Achsen ( oberer ) ………….… 2000 mm / min - Tippvorschubgeschwindigkeit : Z – Achsen ( oberer ) …………..… 2000 mm / min - Tippvorschubgeschwindigkeit : Z2 – Achsen ( oberer ) …………… 2000 mm / min Godpfx Afod H Eryj Aebl - Tippvorschubgeschwindigkeit : C – Achsen …………….… 2000 ° / min - Werkzeugschaft / Werkzeugaufnahmekapazitat …………….. CAPTO C6 No 20 Werkzeuge - Max. Werkzeugdurchmesser …………….. Ø90 mm (Ø125 mm bei freien Nebenplatzen ) 300 mm / 10 kg - Werkzeugwechselzeit ( werkzeug-zu-werkzeug ) …………….. 1.3 s - Hauptspindelmotor ( 30 min -/Dauerbetrieb ) ……………..AC 22 kW / AC 15 kW - Motor der 2. spindel ( 30 min -/Dauerbetrieb ) ……………....AC 18.5 kW / AC 15 kW - Frasspindelmotor ( 20 % ED ) ……………. AC 15 kW - Kuhlmittelpumpenmotor ……………1.2 kW - Leistungsaufnahme (Dauerbetrieb ) …………….….. 66.0 kVA - Druckluftanschluss ……………..…..5 bar , 500 l / min - Kuhlmittel frassungsvermogen des Tanks ……………..….. 300 l - Maschinenhohe ……………..……..2597 mm - Aufstel

Condition: used, Year of construction: 2023, x-travel 3000 mm y-travel 820 mm z-travel 720 mm Control Mazatrol Smooth G spindle taper SK 40 spindle turning speed range 35 - 12.000 U/min spindle motor 15 kW distance spindle centre table top edge 140 - 860 mm table load 2500 Kg rapid travel x/y/z 50 m/min table width 3500 mm table length 820 mm table height over floor 870 mm T-slots 7 T-slot - width 18 mm T-slot - distance 100 mm tool change unit 48 tool changing time 4,7 sec wotkpiece diameter with 2 vacant positions 130 mm workpiece diameter at full load 80 mm max. tool weight 8 kg tool length - max. 350 mm air pressure - required 5 - 9 bar Air volume 260 l/min electrics - voltage/frequency 400 / 50 V/Hz coolant tank 500 l total power requirement 46,7 kW weight of the machine ca. 15,4 t dimensions of the machine ca. 5,3 x 3,6 x 3,3 m Standard machine including the following optional extras: - Provision for dual oil mist extraction - Air cooling via the rotating milling spindle - 48-tool magazine - Pulse handwheel - 3-colour LED signal light - Additional work area lighting - Air blow-off device on the milling spindle - High-pressure coolant supply through the spindle (15 bar) - Provision for MAZAK Monitoring - Chip conveyor with left-hand ejection (Crowther) - Manual grease gun - Grease cartridge - Mazak API - Drilling cycle with automatic chip breaking - Synchronous thread cutting - Rapid traverse with constant angle of inclination STANDARD ACCESSORIES Adaptation for the European market USB port (1 port) Mazak standard colour Work area lighting SAFETY FEATURES Operator door with interlock switch Work area cladding The splash guard enclosure encloses the work area from the side. Fully enclosed work area Protection against chips, coolant and access to the work area during automatic machining. Safety precautions in accordance with global standards COOLANT SUPPLY Coolant supply via spindle (pump pressure = 5 bar) Complete coolant system includes pumps, valves, pipework and nozzles for the efficient production of high-quality components. FACTORY AUTOMATION Automatic start/stop and warm-up function Automatic activation of a warm-up via digital timer MEASURING SYSTEM Tool length measurement and tool breakage detection Gbedpfx Aoyvvluef Ajl NUMERICAL CONTROL Horizontally adjustable NC control panel Relocation Detector Mazatrol SmoothG control 19" colour LCD screen (touch screen) Mazak Tornado tapping/drilling cycle (Mazatrol) EIA/ISO input function Tool path verification in the background 3D coordinate conversion Shape compensation for rotating axes Mazacc-2D software (contour correction) Mazacc-3D software package MAZACC-3D high-speed software package (NO456) is additionally required. Control system with high smoothing Interface for LAN SD memory card interface Smooth Standard Software for M/C - NO443 B) MAZACC-2D software (workpiece shape compensation) - NO444 D) MAZACC-3D high-speed software package - NO445 B) Shape compensation for rotating axes - NO497 D) High-precision control for finishing - Seamless corner point control - Variable acceleration control - Ultra-high-speed machining mode - NO498 Rapid traverse paths, rounding function Absolute positioning system - All dimensions, weights and performance specifications are subject to change - - Used machine without warranty - - Subject to prior sale -

Year of construction: 2000, condition: ready for operation (used), General Data Measurements width 2105 mm Measurements depth 3485 mm Machine weight 7500 kg Control Unit Brand MAZATROL Main Drive Spindle speed range 3500–5000 Spindle bore 61 mm Number of axis 4 Movement Gbsdpex D N Ipsfx Af Ael X-Axis Movement 530 mm X-Axis Feed Force 0–6000 mm/min X-Axis Rapid Traverse 30 m/min Y-Axis Movement ±70 mm Y-Axis Feed Force 0–6000 mm/min Y-Axis Rapid Traverse 15 m/min Z-Axis Movement 1065 mm Z-Axis Feed Force 0–6000 mm/min Z-Axis Rapid Traverse 33 m/min Tail Stock Pinol diameter 80 mm Pinol way 870 mm Pinol tool taper MK4 Tools Number of station 20 Max weight 7 kg Max tool diameter 90 mm Max tool length 250 mm This 4-axis Mazak INTEGREX 200 Y was manufactured in 2000. It features a maximum turning diameter of 540 mm, a swing diameter of 540 mm, and a bar diameter capacity of 51 mm. The machine supports a workpiece weight up to 150 kg and offers a spindle speed range up to 5,000 rpm. It includes a Mazak KM 63 quick change tool system with 20 slots. If you are looking to get high-quality turning capabilities, consider the Mazak INTEGREX 200 Y machine we have for sale. Contact us for more information. Application Types Turning

Condition: used, Year of construction: 2004, MAZAK VTC 200B II, year 2004 X axis: 1120 mm Y axis: 510 mm Z axis: 510 mm Spindle: max. 12,000 rpm SK40 Through-spindle coolant (IKZ) Table length: 1460 mm Table width: 510 mm Table load: 800 kg Tool changer: 30 positions Spindle power: 18.5 kW Gbsdeylnxkjpfx Af Aol Spindle speed: 12,000 rpm Tool changer: 30 positions IKZ: Yes Number of controlled axes: 3 Chip conveyor: Yes Cooling system: Yes

Condition: ready for operation (used), Year of construction: 2001, General Data Machine weight 7500 kg Control Unit Brand MAZATROL Model Fusion 640MT Main Drive Number of spindles 2 Gbsdpfex D Dphex Af Aol Spindle speed range 5000 Number of axis 5 Movement X-Axis Movement 530 mm Y-Axis Movement 140 mm Z-Axis Movement 1065 mm Tools Type of tool holder KM-63 Media Chip conveyor Yes This 5-axis Mazak INTEGREX 200 SY was manufactured in 2001. A robust turn-mill centre featuring dual spindles and a MAZATROL FUSION 640MT control unit, it offers a spindle speed of 5000 1/MIN and movements of X-530 mm, Y-140 mm, Z-1065 mm. Consider the opportunity to buy this Mazak INTEGREX 200 SY turn-mill centre. Contact us for more information about this machine. Application Types Turning

Condition: used, Year of construction: 2020, turning diameter 380 mm turning length 511 mm control Mazatrol SmoothG turning diameter over slide 276 mm max. swing diameter over bed 675 mm Standard machining diameter 276 mm bar material dia. 65 mm x-axis 234 mm rapid traverse X-axis 30 m/min z-axis 625 mm rapid traverse Z-axis 33 m/min turning speeds 35 - 5000 U/min spindle nose A2-6 spindle bore 76 mm Motor output (40%ED) 26 KW 22 KW Max. Torque 465 Nm turning speeds 6000 U/min Main drive power 11 KW Max. Torque 90 Nm Milling spindle speeds ( driven tools) 35-6000 1/min torque on milling spindle max: 47 Nm power capacity - milling spindle 5,5 (40% ED) kW Milling spindle power 3,7 kW Numbers of tools 12 (angetrieben) Tool cross section (outside) 25 qmm Boring bar- Ø 40 mm Drill- Ø 20 mm Mill- Ø 20 mm Tap- Ø M20x2,5 Switching time one turret station ca. 0,20 sec coolant tank 180 l connected load 46,2 kW weight of the machine ca. 5,9 t dimensions of the machine ca. 2,7 x 1,9 x 1,9 m incl. the following accessories: - Signal light (3-colour LED), rectangular - High-performance coolant system (1.1 kW) Flow rate max. 17.6 l/min, pressure (at pump) 5 bar. - Additional coolant nozzle main spindle - Preparation for oil mist extraction electrical/mechanical flange 98mm - Preparation for bar feed - Robot interface (Advance/Profibus) - Chip conveyor with low ejection height - Overload monitoring system - Drilling cycle with torque-dependent chip breaking Gbjdpfx Afjtugggo Asl - Preliminary use of a hollow clamping cylinder on counter spindle - Hollow clamping device incl. draw tube + cylinder - Clamping chuck Hainbuch Spanntop Nova Axfix mini size 52 - Chuck Hainbuch Spanntop Nova Axfix special mini size 52 - 2 x collets - Changing device for collet chuck STANDARD ACCESSORIES Automatic on/off and warm-up function Air blowing device on the chuck on the counter spindle Use of linear systems with guide carriage USB connection (1 connection) Set of manuals in electronic form on CD C-axis main spindle Input accuracy 0.0001° Spindle positioning counter spindle without C-axis Input accuracy 0.001° Tool turret with 12 stations VDI, Operator door with locking switch Double foot switch for both main and counter spindle Hydraulic pressure interlock Fully enclosed work area Work area lighting Safety precautions in accordance with global standards High-performance coolant system (520W) Flow rate max. 11.5 l/min. Complete coolant system Automatic opening/closing of the chuck jaws Automatic tool eye Absolute positioning system Preparation for chip conveyor (lateral) Synchronisation of main and counter spindle Synchronised tapping with milling spindle Relocation Detector Mazatrol SmoothG control 19" LCD colour screen (touch screen) User macro (600 variables) EIA/ISO input function Optional stop (optional stop) Tool path check in the background Thread cutting function (G33) Polar coordinate input (EIA) Drawing data direct input function Interface for LAN SD memory card I/F - Second-hand machine without warranty - All dimensions, weights and performance specifications are non-binding
