Used Mazak Quick Turn 20 for sale (368)

Condition: used, For sale is a fully functional CNC lathe that is currently still in production. The machine is being sold because it will be replaced by new equipment. Location: near Bremen Ledpfx Aaow D T Txebjah Loading: Free loaded (loading by the seller) Video: available, gladly shared via WhatsApp Details & Equipment: The machine is in operational condition and can be inspected during ongoing production Year of manufacture: 2000 Fusion 640 control Equipped with live tooling Turret fully fitted with tool holders Including: 1x live tool for internal machining 1x live tool for 90° machining Chip conveyor will also be included with delivery at a later date Machine documentation available Sub-spindle defective. If interested or if you have any questions, please feel free to contact me.

Condition: repair required (used), functionality: not functional, cnc lathe Lodpfsumlwxsx Aabsah

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 168121, Equipment: documentation/manual, rotational speed infinitely variable, Max. turning Ø 130 mm X-Axis 300 mm Lsdpfx Aaswhrnijboah Z-Axis 240 mm Spindle bore 32 mm Speedrange 7000 rpm

Condition: repair required (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 65123, For sale is a Mazak QT 10N with Knoll chip conveyor. Ledpfx Aown D Nfjaboah Machine and chip conveyor are functional and, considering their age, in good condition. The price is fixed and non-negotiable.

Condition: good (used), Year of construction: 2016, operating hours: 13,701 h, functionality: fully functional, machine/vehicle number: 276209, turning diameter: 255 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 225 mm, travel distance Z-axis: 1,125 mm, swing diameter over bed slide: 660 mm, TECHNICAL DETAILS Chuck size: 10 inch Maximum swing circle: max. 660 mm Standard turning diameter: max. 255 mm Maximum turning diameter: max. 360 mm Largest bar passage: max. Ø 80 mm Distance between spindle nose and turret edge: 59.5 - 1,179.5 mm Maximum weight (bar work): max. 500 kg Maximum weight (chuck work): max. 450 kg Spindle Speed: 35 - 4,000 rpm Shape of spindle nose: JIS A2-8 Ledpfsu Tdi Esx Aabsah Spindle bore: Ø 91 mm Acceleration time: 2.3 s Motor power (30-minute power/continuous power): 26/22 kW Maximum torque (15%ED): 465 Nm Tailstock Quill type: MT No 4 Movement stroke (tailstock body): max. 1,075 mm Minimum and maximum thrust: min. 1,000 N, max. 5,000 N Tools and turrets Number of tools: 12 pieces Outer chisel tool sizes: max. Ø 25 mm Internal turning tool sizes: max. Ø 40 mm Tool sizes router bits: max. Ø 20 mm Tool sizes end mills: max. Ø 20 mm Tool sizes for milling taps: max. M20 (3/4 UNI) × 2.5 mm Turret Switching time (next/opposite position): 0.23/0.62 s Milling spindle motor power (40%ED/continuous power): 5.5/3.7 kW Milling spindle speed: max. 6,000 rpm Maximum torque of the milling spindle (40%ED): max. 47 Nm Feed axes Rapid traverse X/Z: max. 30/33 m/min Time constant X/Z: 65/80 ms Travel range X: max. 225 [220 + 5] mm Travel range Z: max. 1,125 [1,120 + 5] mm MACHINE DETAILS Spindle center height: 1,020 mm Overall length: 3,385 mm Overall width: 1,720 mm Total height: 1,820 mm Space requirement: 5.82 m² Mass of the machine: 6,050 kg Mass of the machine (with steady rest): 6,250 kg Connected load: 44.5 kVA Voltage: 400 V Coolant tank volume: 270/315 l Machine package: 3.87 x 2.16 x 2.01 m, 6.62 t Chip conveyor package: 3.54 x 0.87 x 1.35 m, 325 t

Condition: excellent (used), Year of construction: 2001, turning length: 1,500 mm, turning diameter: 750 mm, spindle motor power: 30 W, spindle speed (max.): 3,300 rpm, Used Mazak Quick Turn Nexus 350M with rotating tools 3 axes max rpm 3300 max turning diameter 750MM Ljdpfx Aewi Iwceabsah X/Z axis 260/ 1605 MM incl. extra tools the machine can be seen in operation

Condition: excellent (used), Year of construction: 1989, I am selling a CNC lathe Mazak QuickTurn 20N. Lathe in bdb condition. Equipment: MAZATROL T-2, control MAZATROL CAM-T-2. Lajdpeu U R E Aofx Aabeh

Condition: ready for operation (used), Year of construction: 1999, Mazak Super Quickturn 200M (1999) C Axis and Milling 8" Chuck Cylinder Mazak tool length measuring system Full set of manuals Parts Catcher Tailstock Mazatrol & EIA programming Swarf Conveyor Bar feeder preparation No bar feeder included Lasdpfxow Rl Uge Aabjh This item is physically in stock and can be seen in full working order, at our showroom. Delivery and installation can be arranged at extra costs.

Condition: good (used), Year of construction: 1999, operating hours: 1,887 h, functionality: fully functional, machine/vehicle number: 142031, spindle speed (max.): 5,000 rpm, Mazak Super Quickturn 200 (1999). Serial Number: 142031. Date: 1999. Weight: 5000kg/11,000lbs. Mazak tooleye measuring system. Tailstock. Swarf Conveyor. Parts Catcher. 12 Station Turret. Mazatrol PC-Fusion- CNC 640T control panel. Main Spindle Max 5000RPM. Collet Chucks and Collets. Hydrafeed barfeeder NOT included. Lajdpfx Aaetz A Dfjbjh This item is physically in stock and can be seen in full working order, at our showroom. Delivery and installation can be arranged at extra costs.

Condition: ready for operation (used), Year of construction: 2023, operating hours: 300 h, Main Drive Laodpfx Ajwttvxjabsh Number of axis 5 Media Chip conveyor Yes Additional Equipment 36 tool change Includes tailstock function This 5-axis Mazak INTEGREX j-200S was manufactured in 2023. Ideal for complex machining tasks, it offers precision and versatility in a compact design. Consider the opportunity to buy this Mazak INTEGREX j-200S. Contact us for more information. Application Types Other Machine Tools

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, turning diameter: 320 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 240 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 495 mm, bar diameter (max.): 51 mm, TECHNICAL DETAILS Machining diameter: 320 mm Turning diameter over slide: 320 mm Machining length (chuck workpiece): 180 mm Bar capacity: 51 mm Travels and feeds Lsdpfowi Na Sox Aaboah X-axis travel: 240 mm Y-axis travel: 100 mm Z-axis travel: 495 mm X-axis rapid traverse: 30 m/min Y-axis rapid traverse: 10 m/min Z-axis rapid traverse: 33 m/min Spindles Number of headstocks: 2 Main spindle speed: 5,000 rpm Main spindle motor power (30 min / 100%): 22 / 15 kW C-axis resolution: 0.001° Spindle bore: 61 mm Counter spindle speed: 5,000 rpm Counter spindle motor power (30 min / 100%): 22 / 15 kW C-axis resolution: 0.001° Tool turret Number of tool positions: 2 x 16 Tool shank height: 25 mm Boring bar shank diameter: 40 mm Turret: with driven tools Driven tools Speed: 4,500 rpm Drive power: 3.7 kW MACHINE DETAILS Spindle chuck: Kitagawa B-208 (210 mm) Control: Mazatrol 640T Machine weight: 8,400 kg EQUIPMENT - 2 x 16-station tool turrets - CNC option package EIA / ISO programming - Air purge device on the chuck - Flex GL 150F gantry loader with pallet conveyor - Tool-Eye - Partition wall - High-pressure cooling 70 bar - Chip conveyor Mayfran ConSep 2000 II

Condition: ready for operation (used), Year of construction: 2011, operating hours: 15,359 h, functionality: fully functional, turning diameter: 320 mm, spindle bore: 61 mm, rotational speed (max.): 5,000 rpm, feed length X-axis: 240 mm, feed length Y-axis: 100 mm, feed length Z-axis: 495 mm, workpiece weight (max.): 300 kg, distance between centers: 1,190 mm, No reserve price - guaranteed sale at the highest bid! TECHNICAL DETAILS Maximum swing diameter: 320 mm Chuck diameter: 203 mm Distance between spindles: 1,190 mm Standard machining diameter: 260 mm Maximum machining diameter: 320 mm Maximum workpiece length: 180 - 530 mm Maximum workpiece weight (chuck incl.): 300 kg Control: MATRIX 2 Spindle Spindle nose: JIS A2-6" Spindle bore: Ø 61 mm Spindle speed: 35 - 5,000 rpm Acceleration/deceleration time: 2.5 s / 2.5 s Spindle motor power (continuous/half-hour power): 15/22 kW Maximum spindle torque: 467 Nm (25% ED) Turret Number of tools: 12 x 2 Tool size (external turning): 25 mm Tool size (internal turning): Ø 40 mm Tool sizes (drilling/milling) Max. drilling diameter: Ø 20 mm Max. tap size: M12 Max. milling cutter diameter: Ø 20 mm Axes Ljdpfxjvt Tfuj Aabeah X-axis travel: 240 mm Rapid traverse: 30,500 mm/min Z1/Z2-axis travel: 440 / 495 mm Rapid traverse: 33,000 mm/min Y-axis travel: ±50 mm Rapid traverse: 10,000 mm/min Cooling Coolant tank capacity: 220 l MACHINE DETAILS Power requirements (continuous/half-hourly): 75.9/ 55.8 kVA Connected load: 85 kVA Overall length: 3,570 mm Total width: 1,995 mm Total height: 2,095 mm Machine weight: 8,400 kg Operating hours: 41,895 h Cutting spindle 1: 15,275 h Cutting spindle 2: 15,359 h

Condition: like new (used), Year of construction: 2023, operating hours: 300 h, functionality: fully functional, turning length: 1,000 mm, Mint machine with tool holder TOP Lsdpfou Ez Npox Aaboah

Condition: ready for operation (used), Year of construction: 2001, General Data Machine weight 7500 kg Control Unit Brand MAZATROL Model Fusion 640MT Main Drive Number of spindles 2 Spindle speed range 5000 Number of axis 5 Movement X-Axis Movement 530 mm Y-Axis Movement 140 mm Z-Axis Movement 1065 mm Tools Type of tool holder KM-63 Media Chip conveyor Yes This 5-axis Mazak INTEGREX 200 SY was manufactured in 2001. A robust turn-mill centre featuring dual spindles and a MAZATROL FUSION 640MT control unit, it offers a spindle speed of 5000 1/MIN and movements of X-530 mm, Y-140 mm, Z-1065 mm. Consider the opportunity to buy this Mazak INTEGREX 200 SY turn-mill centre. Contact us for more information about this machine. Lodpfewyqfwjx Aabeah Application Types Turning

Condition: excellent (used), Year of construction: 2004, MAZAK INTEGREX 200-III ST 5 Axis Turning Centers Lathe, s/n 174623, w/ MAZATROL 640MT Pro Control, 40” Center Distance, 2.5” Bar Capacity, 26” Swing, 26” Turning Diameter, Travels: X-22.83”, Y-6.3”, Z-41.14”, B Axis Head Tilt: 225°, C Axis Index: 0.001°, 5,000 RPM Spindle Speed (Main/Sub), Live Tooling, 12,000 RPM Live Tooling Spindle Speed, 40-ATC, KM63 Taper, Sub Spindle, Oil Matic Oil Temp Regulator, Chip Conveyor Lasdpfx Aaeu A Dglobeh

Condition: good (used), Year of construction: 1989, functionality: fully functional, machine/vehicle number: 84365-U, Well-maintained CNC lathe from screw manufacturing plant Turning length (max.): 510 mm Swing diameter (max.): 254 mm Turning diameter over bed: 440 mm Turning diameter over slide: 250 mm Distance between centers: 680 mm CNC control: Mazatrol CAM T-2 X axis: 180 mm Z axis: 510 mm Maximum workpiece weight: kg Spindle bore: 51 mm Number of turrets: 1 Number of tools: 8 Laodpfx Aaew Tt Ndoboh Powered tool stations: Spindle speeds: 4500 rpm Spindle motor power: 15 kW Tailstock: No Bar feeder: No ----- Length x Width x Height: 254.0 × 2172.0 × 1790.0 mm Weight:

Year of construction: 2000, condition: ready for operation (used), General Data Measurements width 2105 mm Measurements depth 3485 mm Machine weight 7500 kg Control Unit Brand MAZATROL Main Drive Spindle speed range 3500–5000 Spindle bore 61 mm Number of axis 4 Movement X-Axis Movement 530 mm X-Axis Feed Force 0–6000 mm/min X-Axis Rapid Traverse 30 m/min Lsdpoxpyw Ejfx Aaboah Y-Axis Movement ±70 mm Y-Axis Feed Force 0–6000 mm/min Y-Axis Rapid Traverse 15 m/min Z-Axis Movement 1065 mm Z-Axis Feed Force 0–6000 mm/min Z-Axis Rapid Traverse 33 m/min Tail Stock Pinol diameter 80 mm Pinol way 870 mm Pinol tool taper MK4 Tools Number of station 20 Max weight 7 kg Max tool diameter 90 mm Max tool length 250 mm This 4-axis Mazak INTEGREX 200 Y was manufactured in 2000. It features a maximum turning diameter of 540 mm, a swing diameter of 540 mm, and a bar diameter capacity of 51 mm. The machine supports a workpiece weight up to 150 kg and offers a spindle speed range up to 5,000 rpm. It includes a Mazak KM 63 quick change tool system with 20 slots. If you are looking to get high-quality turning capabilities, consider the Mazak INTEGREX 200 Y machine we have for sale. Contact us for more information. Application Types Turning

Condition: excellent (used), With sub-spindle Laedpfx Aoxpugbeabsh With C-axis, with Y-axis MAZAK Mazatrol Nexus control Turning length -538 mm Swing Diameter -675 mm Turning diametre 380 mm Spindle speeds 35- 5'000 + 35- 6'000 rpm Tool changer with 16 driven positions Bar loader Tool presetter device Piece catcher attachment Misc. accessories MARCELS MASCHINEN CH

Condition: used, Year of construction: 2017, spindle speed (max.): 45,000 rpm, travel distance X-axis: 207 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 1,225 mm, controller manufacturer: MAZAK, controller model: SMOOTH G, number of spindles: 2, CONTROLS .. CNC controls MAZAK SMOOTH G BASIC FUNCTIONS .. number of spindles: 2 .. number of turrets: 2 .. live positions: yes MAIN SPINDLE .. spindle revolutions (max): 45000 /min .. drive power: 22 kW .. spindle bore diameter: 65 mm .. spindle positioning: 0.0001 ° .. c-axis: yes COUNTER SPINDLE Lodpfxoxm Rr Ue Aabsah .. spindle revolutions (max): 5000 /min .. drive power: 22 kW .. spindle positioning: 0.0001 ° .. c-axis: yes X/Z SLIDE .. Z-axis travel: 1225 mm .. X-axis travel: 207 mm .. Y-axis travel: 100 mm .. distance spindle tool holder (max): 344 mm .. number of tool positions (total): 12 .. number of live positions: 12 .. - rotation speeds (max): 6000 /min X/Z SLIDE .. Z-axis travel: 1280 mm .. X-axis travel: 141 mm .. Y-axis travel: 70 mm .. rotating range B-axis up to: 0.0001 ° .. distance spindle tool holder (max): 210 mm .. number of tool positions (total): 12 .. number of live positions: 12 .. - rotation speeds (max): 6000 /min Accessories - 1 set of tool holders - 1 pc. 3-jaw chuck Kitagawa BB08 for main spindle - 1 pc. collet chuck Hainbuch 52mm, axfix - 1 piece bar loader, Hydrafeed Multifeed MX-1B

Condition: excellent (used), Year of construction: 2000, functionality: fully functional, Z 1,065mm, Y 140mm, X 530mm, ATC 40 pos, HSK63, Mazatrol PC Fusion 640. weight 7.000kg Ledpfx Aaexnwp Aobjah

Condition: used, Year of construction: 2004, turning diameter: 660 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 35 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,045 mm, total height: 2,600 mm, total length: 3,820 mm, total width: 2,060 mm, overall weight: 10,400 kg, CNC Turning Milling centre with Second Spindle CNC Control Mazatrol PC Fusion CNC 640 MT PRO Turning diameter 550/660 mm Lajdpfsxd Ay Ejx Aabeh Turning length 1016 mm Spindle bore diameter 65 mm Spindle speed 35-5000 R/min X-axis movement 580 mm Y-axis movement 160 mm Z-axis movement 1045 mm B-axis travel 225 ° mm C-axis indexing 360° Spindle nose A2-6 Tool Taper Capto C6 Number of tools in magazine 40 If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: good (used), Year of construction: 2013, CNC MATRIX 2 , Maximum diameter 658 mm, travel X 615 mm, travel Z 1585 mm, travel Y 250 mm, bar passage 102 mm bore 112, spindle speed 35 to 2200 rpm, milling spindle 35 to 12000 rpm, 5 simultaneous axes, mm, 36 tool magazine Capto C6, RENISHAW preparation, steady rest support, chip conveyor. Lsdpfxjuqktte Aabeah

Year of construction: 2014, condition: ready for operation (used), Control Unit Brand MAZATROL Model Matrix 2 Main Drive Number of spindles 2 Spindle speed range 4000 Spindle motor power 15 / 22 kW Number of axis 8 Movement X-Axis Movement 240 mm Y-Axis Movement 50 mm Z-Axis Movement 495 mm Lajdpfxowttzue Aabjh Turret Number of turrets 1 Tool taper VDI / Capto Tools Number of index 12 + 12 Additional Equipment Equipped with GL 100 Gantry Loader with Tray System Supplied with tooling set as per listing photos This 8-axis Mazak Multiplex 6200 Y was manufactured in 2014, featuring dual spindles and turrets, each with a 254 mm chuck diameter and 4000 rpm speed. It includes a Mazatrol Matrix 2 control unit and a GL 100 Gantry Loader. Ideal for complex turning operations, it offers a bar capacity of 51 mm and a maximum turning diameter of 320 mm. If you are looking to get high-quality turning capabilities consider the Mazak Multiplex 6200 Y machine we have for sale. Contact us for more information. Application Types Turning

Condition: used, Year of construction: 2012, turning length: 500 mm, turning diameter: 530 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 450 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 550 mm, bar passage: 65 mm, bar diameter (max.): 65 mm, controller manufacturer: MAZATROL, controller model: MATRIX, number of spindles: 1, CONTROLS .. CNC controls MAZATROL MATRIX BASIC FUNCTIONS .. number of spindles: 1 WORKING RANGE TURNING .. turning diameter (max): 530 mm .. bar diameter (max): 65 mm .. worpiece length max.: 500 mm MAIN SPINDLE .. spindle revolutions (max): 5000 /min .. c-axis: yes X/Z SLIDE .. Z-axis travel: 550 mm .. X-axis travel: 450 mm .. Y-axis travel: 2000 mm .. rotating range B-axis up to: 190 ° .. - rotation speeds (max): 12000 /min TOOL MAGAZINE .. number of positions: 72 Lasdpfx Aaoxm Rrnsbeh .. tool diameter max.: 90 mm .. - with free neighbour positions: 125 mm .. tool length max.: 210 mm ATTACHMENTS (TURNING) .. tailstock: yes .. bar magazine: yes .. - bar length (max): 1200 mm .. - bar diameter (max): 65 mm .. workpiece unloading system: yes .. thread cutting attachment: yes .. chip conveyor: yes .. coolant unit: yes .. band filtration unit: yes .. coolant through turret: yes .. through spindle coolant attachment: yes .. aspiration unit: yes .. hydraulic system: yes .. European CE standards: yes

Year of construction: 2023, operating hours: 154 h, condition: ready for operation (used), General Data Measurements width 1690 mm Measurements depth 2785 mm Measurements height 1725 mm Machine weight 4650 kg Control Unit Brand MAZATROL Model SMOOTH Ez Main Drive Number of axis 3 Movement X-Axis Movement 215 mm X-Axis Rapid Traverse 30 m/min Y-Axis Movement 100 mm Y-Axis Rapid Traverse 10 m/min Z-Axis Movement 605 mm Z-Axis Rapid Traverse 30 m/min Media Air pressure 0.5 to 1.0 MPa Additional Equipment Transformer for Europe (CE) Roller guide with spherical roller bearings SD memory card I/F + USB memory I/F 1 Set of control keys Foundation kit (steel plates) CE Marking (With noise filter) C-axis Positioning 0.0001° Increment 12-Position Turret Y-Axis Control Interface bar feeder This 3-axis Mazak QTE-200MY SG was manufactured in 2023. It features a maximum swing diameter of 695 mm, a standard cutting diameter of 235 mm, and a maximum turning diameter of 340 mm. The main spindle operates at speeds up to 5,000 min-1, with a motor power of 15.0 kW. It includes a 12-position turret and rapid traverse rates on the X, Y, Z and C axes are 30, 10, and 30 m/min respectively. Contact us for more information about this machine. Application Types Lsdpfx Aasxirlbobeah Turning
