Used Rack Milling Machine for sale (95,969)

Condition: good (used), Year of construction: 2012, Ref. -No.: 10290 Manufacturer: KOLB KLUEPPELBERG Type: Cubimat YC 2000 Year of construction: 2012 Type of control: CNC Control: Siemens Sinumerik 840 D Storage location: Halberstadt Fodpfx Asxdaxljabepn Country of origin: Deutschland Machine number: 016453-20.1 X-Travel: 7000 mm Y-Travel: 4000 mm Z-Travel: 4000 mm W-Travel: 2.000 mm Speed work spindle: 4.000 RPM Max. Torque: 2.100 Nm Max. Workpiece Weight: 20 t Table-Size (Lxw): 2.800 x 2.000 mm Table load max.: 18.000 kg Tool Taper: SK 50 Tool places: 360 Distance Between Columns: 3.200 x 4.000 mm Further information: - 4 milling heads available - 1 universal head - Pick Up Head Station The machine can be viewed under power by arrangement.

Condition: good (used), travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,600 mm, Manufacturer: SORALUCE Type: TL-25 Control: HeidenHain TNC 430 Year of manufacture: 1998 Aiptek ATC 30 positions Automatic head 2.5 x 2.5 Gr Central lubrication Machine housing with front doors Large tool package Specifications Metric US Standard X-axis 2500 mm Y-axis 1000 mm Z-axis 1600 mm Table length 2860 mm Table width 1000 mm Table load 7500 Spindle power 25 kW Spindle speed 0 - 3000 rpm Tool holder 50 ISO/Bt/Mk X-axis feed 10000 mm/min. Y-axis feed 10000 mm/min. Z-axis feed 10000 mm/min. Milling head auto index 2.5 x 2.5° Working hours 12500 H Dimensions (estimate) Length Fedpov Idaljfx Aabopn 6000 mm Width 3500 mm Height 3500 mm Weight 15000 kg Please note: The information on this page is correct to the best of our knowledge and belief and, where possible, has been obtained from the manufacturer. The information is given in good faith but its accuracy cannot be guaranteed. Accordingly, it will not constitute a representation and terms of contract. We recommend that you check all important details.

Condition: used, Year of construction: 2006, x-travel 1.760 / 2x 6 mm y-travel 600 mm z-travel 800 mm Fpodevzckcepfx Aaben Control iTNC 5 Heidenhain turning speed range - main spindle min/-1 swivellable indexing 1 ° tool taper SK 40 DIN 69 871 A table surface area 2.380 x 600 mm table surface area R: 1.000 x 600 mm table surface area L: 1.350 x 600 mm number of T-slots 7 T-slot - width 14H9 mm number of toolpositions 22 pos. tool taper SK 40 max. tool diameter 85 mm max. tool-dia with free toolbox 135 mm max. tool length 400 mm max. tool weight (L=400mm) 5,5 kg max. workpiece weight (L=200mm) 8,0 kg total power requirement 55 KVA weight of the machine ca. 14 t dimensions of the machine ca. 6,8 x 4,0 x 3,2 m Travelling column machining centre AXA - VHC 2-1760-S / E

Condition: reconditioned (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 25,000 m/min, feed rate Y-axis: 25,000 m/min, feed rate Z-axis: 25,000 m/min, spindle speed (max.): 3,000 rpm, spindle speed (min.): 20 rpm, table width: 850 mm, table length: 3,700 mm, overall weight: 18,500 kg, RepairFIT by Dornhöfer The Difference. Including installation & commissioning! Year of manufacture: 2007 Travel / Stroke Capacities: Longitudinal (X): 3,500 mm Vertical (Y): 1,250 mm Cross (Z): 1,000 mm Table dimensions: Length: 3,700 mm Width: 850 mm T-slots: 5 x 22 H12 Reference slot: 1 x 22 H8 T-slot spacing: 140 mm Paintwork: RAL 5011 (steel blue) RAL 7035 (light grey) Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Main drive: Drive power: 100% duty cycle 24 kW Spindle speed range: Spindle speed: 20-3,000 rpm Torque: 479 Nm Max. feed rate: X, Y, and Z axes 25,000 mm/min Mean acceleration: 2 m/s² Weight: approx. 18,500 kg HEIDENHAIN iTNC 530 HSCI Swiveling control pendant including Heidenhain iTNC 530 control (1 processor / 4 axes) with software options 1 and 2. Automatic Milling Head, Diagonal H4 Automatic indexing Soraluce “Diagonal” milling head, Type H4 / 2 planes with 2.5° x 2.5° indexing, 479 Nm, tool clamping force 18,000 N. Automatic tool changer: Automatic tool changer (random carousel) with 20 magazine positions: The automatic tool change is carried out in the vertical position of the tool spindle. Maximum tool diameter: 125 mm Maximum tool length: 250 mm Maximum tool weight: 15 kg Number of magazine positions: 20 Chip conveyor package: Three chip conveyors, two longitudinal screw conveyors and one cross hinge belt conveyor with integrated coolant tank, discharge height: 1,000 mm Coolant System 2: Coolant/lubricant system 2 with discharge via shower ring and internal coolant supply according to DIN 69871 Form AD, tank capacity 500 l + 150 l lift tank with pump, delivery rate 50 l/min, delivery pressure 5/8 bar. Increased delivery pressure of high-pressure pump from 15 bar. Fpsdpfx Aajxgn Efobon RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line are sourced by us following a strict selection process and undergo a thorough inspection (deep-dive check). After intensive cleaning, all identified visible defects and faults are professionally repaired by our expert service team.

Condition: used, Year of construction: 2013, operating hours: 3,064 h, Applicable material: Asphalt Serial number: 10188210xxxx Please contact ATS Norway for more information Please provide reference number upon request: 20327 Specifications: - 2013 model - 3064 hours - Deutz engine - Hydraulic lift and lower - Milling width of 60 cm - Lower and raise function on the roof - Ready for delivery Description: We have a 2013 Bomag BM600/15 Asphalt milling machine for sale. Fpsdpfxswi Rc Us Aabsn Everything works as it should according to the owner. Services have been carried out at our own workshop. The milling width is 60 cm. Errors and defects may occur. Ready for delivery Hours: 3064 Own weight: 6800 Model: BM600/15

Condition: used, Year of construction: 2017, x-travel 500 mm y-travel 450 mm z-travel 400 mm Fjdpfx Aewm Rthoabjpn Control DMG MORI

Condition: good (used), Year of construction: 2009, Ref. -No.: 10521 Manufacturer: LAGUN Type: CM 6 Year of construction: 2009 Type of control: CNC Control: HEIDENHAIN iTNC 530 Fjdpfjxc Tttex Aabopn Storage location: Halberstadt Country of origin: Spain X-Travel: 6000 mm Y-Travel: 1200 mm Z-Travel: 2000 mm C-Axis: 0,001 ° Rapid Traverse X/Y/Z: 30 m / min Table surface area (LxW): 7500 x 1100 mm Tool changer: 60 Drive power spindle: 60 kW Table load max.: 5.000 kg Tool Taper: SK 50 Spindle Speeds: 6.000 RPM Further information: Automatic universal swivel head 1° x 1° incl. accessories, tools, holders 4th axis preparation (rotary table) Positioning accuracy: ± 0.030 mm Repeat accuracy: ± 0.010 mm Machine is in production and can be inspected under power at any time.

Condition: used, Year of construction: 2001, x-travel 2000 mm y-travel 920 mm z-travel 900 mm table surface area 2200 x 750 mm table load 3 t number of T-slots 6 T - slots - width 18 mm T - slots distance 120 mm spindle taper ISO 50 DIN 69871-B spindle speed max. 3000 U/min transmission ratio 1 speeds infinitely variable range 1 60 - 3000 U/min Fodpfxjg E Utxj Aabopn weight of the machine ca. 21,6 t feeds longditudinal/cross/vertical 0 - 5000 mm/min rapid traverse 15000 mm/min total power requirement 38 kw weight of the machine ca. 11 t Pull studs DIN69872-B | IKZ Hours: Control on: 43036 h Machine on: 41311 h Program run 13894 h The machine is already dismantled

Condition: new, Year of construction: 2023, functionality: unexamined, machine/vehicle number: 6356, travel distance X-axis: 8,000 mm, travel distance Y-axis: 3,200 mm, travel distance Z-axis: 1,600 mm, MACHINE CONFIGURATION GENERAL SPECIFICATIONS TRAVERSES - Longitudinal traverse     8.000 mm - Vertical traverse     3.200 mm - Cross traverse     1.600 mm C0 Axes configuration in the machine: Longitudinal traverse X Vertical traverse Y Cross traverse Z Milling head zero position (0,0) Spindle parallel to Z REMARK: In case that the customer wants to modify this standard, option C0B must be selected before machine is launched into production. MACHINE ACCURACY Positioning A (according to ISO 230-2) ▪Longitudinal traverse 8.000 mm 0,023 mm ▪Vertical traverse 3.200 mm 0,013 mm ▪Cross traverse 1.600 mm 0,010 mm Repeatability R (according to ISO 230-2) ▪Longitudinal traverse 8.000 mm 0,018 mm ▪Vertical traverse 3.200 mm 0,010 mm ▪Cross traverse 1.600 mm 0,008 mm MEASURING SYSTEM LE_H Absolute linear scales: Manufacturer Heidenhain Axes X / Y / Z Sealing Compressed air Precision ±0,005 mm AUTOMATIC SLIDE FEEDS ▪Number of feeds as per ISO R-229 Stepless adjustable ▪Rapid Feed: Longitudinal axis 35.000 mm/min Vertical axis 35.000 mm/min Cross axis 35.000 mm/min ▪Acceleration rate (instantaneous, not maximum): Longitudinal axis 1 m/s² Vertical axis 1,5 m/s² Cross axis 2 m/s² NC17 Digital drive axis servomotors Heidenhain ▪Feed servomotors torque (M0):  Longitudinal axis (double pinion) 2 x 26,1 Nm Vertical axis 47,6 Nm Cross axis 47,6 Nm ▪Working feed force (X-Y-Z axes) 20.000 N MACHINE MEASUREMENTS ▪Approx. length (L) 13.790 mm ▪Approx. height (H) 6.640 mm ▪Approx. width (W) 3.850 mm ▪Ram section and clearance diameter 480 x 500 mm / Ø 695 mm MAIN SPINDLE AD43 Spindle motor: H Manufacturer Heidenhain Power (S1-100% / S6-60%) 43 / 49 kW T900 Maximum torque available (S1-100% / S6-60%) 900 / 1.045 Nm Type Direct Drive Location Inside RAM Cooling system Coolant HEADS H94E MACHINE PREPARATION FOR FUTURE INSTALLATION OF AUTOMATIC HEAD CHANGING SYSTEM ▪Mechanical preparation for code H94D (with adapter flanges). ▪Head is fixed or changed in the machine manually (not automatically) with bolts. ▪To be acquired for full automatic head changing system: Additional heads (with its own adapter flanges). Pick-up station for heads. ▪Modifications on the ram for full automatic head changing system: Substitution of the adapter flange. Bolts in the ram will be substituted by hydraulic clamping cylinders (PLC activated). Electrovalves and hydraulic installation. H41 ORTHOGONAL INDEXING HEAD ▪Indexing positioning (Hirth coupling): Vertical joint (±360º) 1º Horizontal joint (±135º) 1º Indexing accuracy ±1” Joint clamping / unclamping Hydraulic Permissible tangential moment 13.250 Nm Each joint equips its own encoder to control rotation. ▪Tool spindle: Lubrication Refrigerated oil Fpjdpfx Aaexcnk Tebjn Bearings Angular contact Automatic tool clamping / unclamping Mechanical / hydraulic Sealing (nose) Air pressured labyrinth ▪Power transmission: Gear ratio 1:1 Lubrication Cooled oil Gears Klingelnberg teeth spiral bevel gears ▪Air blowing for taper cleaning purposes while automatic tool changing.

Condition: good (used), Machine available for delivery within 15 days. Vertical 5-axis machining center MIKRON WF 41C. CNC Heidenhain 426. 16-tool magazine. Table length: 500 mm. Table width: 1000 mm. Max spindle speed: 4000 rpm. Spindle motor power: 4000 kW. In operating condition. Fpodpfx Aexl Htfjabon

Condition: good (used), USED DEVLIEG 43H-72 SPIRAMATIC JIG MILL Equipped With: Spindle Diameter - 4" Spindle Nose Taper - No. 50 NMTB Spindle Travel - 20" Table Size - 35" x 72" Horizontal Travel - 72" Retraction of Table - 16" Vertical Travel of Head - 52" Spindle Speeds (16) - 21 to 1000 RPM Fodpfjimd H Nex Aabjpn Spindle Feeds (8) - .002" to .024" Milling Feedrates X & Y (16) - 0.5 to 36 IPM Rapid traverse in all directions Approx Floor Space - 205" x 146" x 126" Weight, Approx – 14.515 kg Dimensions: FB X RL - 11'8" X 16' with sliding gaurds X Height: 10'10" all the tools/microbores from the pictures will be delivered together with the machine and are included in the final price. Price Euro 14.700 Euro + VAT, negotiable, FCA: Oradea/Romania Irrtum, Anderungen und Zwischenverkauf vorbehalten / Subject to errors, changes and prior sale / Ne rezervăm dreptul la greșeli, modificări și vânzare We speak English. /Wir sprechen Deutsch./ Beszélünk magyarul. /Nous parlons français/Vorbim romana

Condition: good (used), Year of construction: 2008, Traverses X Y Z: 3000 x 1300 x 2000mm, Table 2000 x 1600mm, table load 13,000 kgs, B axis 360 degrees, Fpjdpfx Asvz A Rieabon Heidenhain iTNC530, ISO SK50 spindle taper, 5,000rpm Spindle Speed, 60 station toolchanger, coolant, Interlocked guards.

Condition: new, Year of construction: 2025, Ref. -No.: 10464 Manufacturer: IGREK Type: 3500 XXL Year of construction: 2025 Type of control: CNC Control: Siemens 840 D / Heidenhain iTNC 640 Storage location: Istanbul Country of origin: Türkiye X-Travel: 10500 mm Y-Travel: 3500 mm Z-Travel: 1400 mm A-Axis: +/- 115 ° B-Axis: 360 ° Max. Torque: 235 Nm Rapid Traverse X/Y/Z: 30 m / min Drive power spindle: 54 kW Table load max.: 4000 kg Tool Taper: HSK-A100 Spindle Speeds: 12500 RPM Machine length: 16000 mm Machine width: 7400 mm Machine Height: 8500 mm Weight: 195 t Further information: GREK 3500 XXL – Customized precision for large-scale projects The IGREK 3500 XXL is a CNC 5-axis portal milling machine of the latest generation, developed for the high-precision machining of large components. Built in 2024, it is ready for immediate use and equipped with the latest technology to meet the most demanding requirements in heavy industry and mechanical engineering. Key features: Gigantic machining areas: With travel distances of 10,500 mm (X), 3,500 mm (Y) and 1,400 mm (Z), the machine offers extraordinary flexibility for machining large parts. 5-axis simultaneous machining: The A-axis with +/- 115° and the B-axis with 360° guarantee maximum precision and versatility when machining complex workpieces. Powerful spindle: Equipped with a speed of up to 12,500 rpm, a maximum torque of 235 Nm and a drive power of 54 kW – ideal for high-performance machining. Robust and durable: Weighing 195 tons and with a table load of up to 4,000 kg, the machine is designed for heavy-duty machining. Innovative tool holding fixture: The HSK-A100 tool holding fixture enables quick tool changes and increases efficiency. Speed and efficiency: Rapid feed rates of 30 m/min on all axes ensure maximum productivity. Technical data at a glance: Traverse paths: X 10,500 mm / Y 3,500 mm / Z 1,400 mm Spindle power: 54 kW Spindle speed: 12,500 rpm Table load: up to 4,000 kg Machine dimensions (LxWxH): 16,000 x 7,400 x 8,500 mm Weight: 195 tons Additional benefits: The machine is supplied with the advanced Siemens 840D or Heidenhain iTNC 640 control system and offers worldwide warranty and service support from the manufacturer. Fodpfx Aaexc Tr Ajbspn Choose the IGREK 3500 XXL for precision and efficiency in the machining of large parts. Contact us now for a non-binding offer!

Condition: used, Year of construction: 2014, x-travel 1300 mm y-travel 500 mm z-travel 570 mm spindle taper SK40 spindle turning speed - stepless 60 - 6000 U/min rapid traverse x/y/z 7,5 m/min Number of tools 16 St. table surface area 1500 x 400 mm workpiece weight 700 kg total power requirement 12 kW weight of the machine ca. 4100 kg dimensions of the machine ca. 3800 x 3800 x 2800 mm - SIEMENS control SINUMERIK 828D - automatic tool clamping - Cooling device - automatic central lubrication - Chip tray Fedpett Tdmjfx Aabepn - Full enclosure - Operation manual

Condition: used, For sale: the tool milling machine shown in the photos, manufactured by the German company Deckel, model FP3A. The machine offers manual, semi-automatic, and automatic operation modes. Controlled via G-codes. Control type: CNC 2102 Deckel. Fpsdpexluu Rjfx Aabjn

Condition: used, Year of construction: 2004, x-travel 3.600 mm y-travel 920 mm z-travel 820 mm Control 840D pl ShopMill Siemens turning speed range - main spindle 20 - 18.000 min/-1 power capacity - main spindel 35 / 25 kW max. Torque 130 Nm tool taper HSK-A63 swivellable B: +/- 100 ° table surface area 4.200 x 900 mm max. table load 4.200 kg T-slots 9x 18H7 x 100 number of toolpositions 130 ( 120 +10 ) pos. tool taper HSK-A63 max. tool diameter 50 mm max. tool weight 6,0 kg max. tool length 200 mm rapid traverse ( X / Y / Z ) 100 / 50 / 50 m/min feed speeds max. 20.000 mm/min Fpsdpfx Aaountmqebjn total power requirement 92 kVA weight of the machine ca. 17,0 t dimensions of the machine ca. 11,0 x 5,5 x 3,0 m CNC - Travel Column Milling Machine DECKEL MAHO - DMF 360 linear - 5 Axis ( NC-Swivel-Milling-Head & LEHMANN - EA 430.2A ) - moveable tailstock - separated WorkingTable - internal Coolant-System - 120-pos. Tool-Magazine incl. cleaning-unit - 10 additional pos. for oversized tools - Machine equipped with increased accuracy

Condition: excellent (used), Year of construction: 2002, The KSF-2E is the world’s leading specialized CNC milling machine for fully automated production and complete machining of high-quality cross joints and grids in the serial manufacturing of glazing bars for windows and doors. Thanks to its dedicated aggregates, the machine produces cross joints from wood, aluminium, MDF, or PVC with outstanding quality and precisely processes all components of the glazing bar grids. OPERATIONS: Fjdpfxexl Dnas Aabspn • Cross joints in various designs and sizes • End processing of glazing bars • Cutting frame profiles to size The machine is additionally equipped with a transverse feed/magazine for components.

Condition: used, functionality: unexamined, For sale are 3 milling heads with integrated quill by Scheller. €350 per milling head The heads were previously installed on FE 1-10 Scheller milling machines. A reference photo is included in the images. (PLEASE NOTE: MACHINE IS NO LONGER AVAILABLE. THIS LISTING IS FOR THE HEADS ONLY) Delivery throughout Europe is possible on request and at additional cost. Prices are excluding VAT. Viewings available by appointment. Please contact us—our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Are you looking for a high-quality yet affordable metalworking machine for your production facility? Or want to sell your own? Fpjdeuabmbjpfx Aabjn For further information or contact options, please visit our website.

Condition: good (used), Year of construction: 1985, Ref. -No.: 10595 Manufacturer: GILDEMEISTER MAX MüLLER Type: MD 6S Year of construction: 1985 Type of control: CNC Control: EPL 4 Storage location: Halberstadt Country of origin: Germany Tool holder type: 2 x VDI 50 Centre Distance: 1765 mm Spindle passage: 101 mm Swing diameter over bed: 720 mm Swing diameter over cross slide: 490 mm Lathe chuck diameter, max.: 400 mm Power Capacity: 50 kW Weight Of The Machine Ca.: 16 t Turning Speed Range: 10 - 2800 rpm Quill holder: MK 5 Further information: - Equipment - Powered tools - Tailstock - Automatic quill stroke - Chip conveyor - Automatic sliding safety doors - Hydraulic steady rest Fjdsxc Tuwspfx Aabopn - 2 turrets

Condition: used, Year of construction: 2002, x-travel 2600 mm y-travel 1000 mm z-travel 1000 mm table-size 3.600 x 900 mm max. workpiece weight 8.000 kg no. of flutes 6 groove width 22 mm flute distance 125 spindle taper ISO 50 DIN 69871 number of spindle speeds 4.000 (2 Steps 0 - 1.000, U/min feed speeds 10 - 5.000 mm/min rapid speed 10.000 / 10.000 / 10.000 mm/min dimensions of the machine ca. 9,82 x 5,1 x 3,16 m weight of the machine ca. 21,5 t Control Fsdegvqqlepfx Aabepn Engine: Spindle drive motor: 29 kW Feed drive motor Y-axis: 20 Nm, X- and Z-axis: 27 Nm Hydraulic motor: 2.2 kW Coolant pump motor: 0.50 kW Lubrication pump motor: 0.09 kW - Tool changer

Condition: good (used), Year of construction: 1996, feed length X-axis: 700 mm, feed length Y-axis: 550 mm, feed length Z-axis: 500 mm, travel distance X-axis: 700 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 500 mm, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 10,000 m/min, feed rate Z-axis: 10,000 m/min, spindle speed (max.): 4,500 rpm, spindle speed (min.): 25 rpm, rapid traverse X-axis: 10,000 m/min, rapid traverse Y-axis: 10,000 m/min, rapid traverse Z-axis: 10,000 m/min, mount diameter: 40 mm, table length: 1,000 mm, table width: 500 mm, overall weight: 3,500 kg, X-axis / longitudinal 700 mm Y-axis / transverse 550 mm Z-axis / vertical 500 mm Table dimensions 1000 x 500 mm Spindle speed range stepless in 3 gear steps 25 - 4200 rpm Tool holder SK 40 Feed range X-Y-Z 1 - 10000 mm/min Rapid traverse X-Y-Z 10000 mm/min Weight approx. 3500 kg Control: Heidenhain TNC 407 - TNC 415 Fedpexg Rxbjfx Aabjpn

Condition: ready for operation (used), Year of construction: 2003, operating hours: 54,000 h, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 500 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 20,000 rpm, table width: 850 mm, table load: 4,000 kg, table length: 2,100 mm, total height: 330 mm, total width: 2,570 mm, total length: 5,200 mm, type of input current: three-phase, overall weight: 12,000 kg, distance table to spindle center: 45 mm, quill travel distance: 500 mm, spindle motor power: 15,000 W, MANUFACTURER: PARPAS • YEAR OF MANUFACTURE: 2003 • MODEL: PHS 920P • OPERATING HOURS: 54,178 • CONTROL UNIT BRAND: HEIDENHAIN iTNC 530 TECHNICAL DETAILS GENERAL DATA • WIDTH: 2570 mm • LENGTH: 5200 mm • HEIGHT: 3300 mm • WEIGHT: 12,000 kg CONTROL SYSTEM • BRAND: HEIDENHAIN • MODEL: 530 DRIVE • SPINDLE SPEED: 20,000 rpm (HSK A50) • SPINDLE POWER: 15 kW • NUMBER OF AXES: 5 TRAVELS • X-AXIS TRAVEL: 2000 mm • Y-AXIS TRAVEL: 1200 mm • Z-AXIS TRAVEL: 500 mm Fpsdpfx Asxg Rd Roabsn • A-AXIS ROTATION: +/- 65° • C-AXIS ROTATION: +/- 100° • MAX. RAPID TRAVERSE: 30 m/min TABLE • LENGTH: 2100 mm • WIDTH: 850 mm • T-SLOTS: 7 • DISTANCE BETWEEN T-SLOTS: 120 mm • MIN. DISTANCE SPINDLE TO TABLE: 45 mm • MAX. DISTANCE SPINDLE TO TABLE: 545 mm • MAX. TABLE LOAD: 4000 kg TOOLING • MAX. TOOL WEIGHT: 3 kg • MAX. TOOL DIAMETER: 50 mm • MAX. TOOL LENGTH: 150 mm • TOOL HOLDER TYPE: HSK A50 ADDITIONAL FEATURES • Spindle chiller • Air dryer for spindle lubrication • 20-position tool magazine with Heidenhain tool probe • Highly rigid construction • 5-axis simultaneous machining • Air and oil-cooled spindle • Z-axis compensation • Approx. 95 shrink-fit tool holders plus other accessories

Condition: used, machine/vehicle number: 186137200089, used TOS tool milling machine model FNG 40 CNC Year of manufacture: 1988 with Heidenhain path control TNC 155 with fixed angular table 800x400mm Travel paths: X/Y/Z = 500/400/400mm Speed range: 10-3150 rpm Spindle: SK40 Chip guard, attachable Documentation for the machine and control is available. Fpsdpexf Inksfx Aaben The machine is located in 71334 Waiblingen-Beinstein and can be inspected by appointment.

Condition: good (used), Year of construction: 2003, Ref. -No.: 10454 Manufacturer: DOOSAN Type: DAEWOO PUMA 300 MSC Year of construction: 2003 Type of control: CNC Control: FANUC 18i-TB Storage location: Halberstadt Country of origin: South Korea Machine-No.: 0MS19XX Turning Speeds: 4500 RPM Bar passage: 62 mm Turning Length: 595 mm Turret places: 12 Pcs Further information: - 4 axes (X/Z/C/B) - counter spindle - driven tool station - finished part removal system - conveyor belt - chip conveyor Fodpfxjxc Trpj Aabopn - Powercool coolant system - LNS Quickload Servo 3 bar loader - tool holder - collet holder - collets Machines can be inspected under power by appointment.

Condition: good (used), Year of construction: 1981, Ref. -No.: 10447 Manufacturer: SKODA Type: WD 200 Year of construction: 1981 Retrofit: 2010 Type of control: CNC Control: SIEMENS SINUMERIK 840D Storage location: Halberstadt Country of origin: Germany X-Travel: 9000 mm Y-Travel: 4000 mm Z-Travel: 1450 mm W-Axis: 2000 mm Bed width: 2000 mm Bed height: 550 mm Spindle Diameter: 200 mm Quill Stroke: 1600 mm Rotary Table (Lxw): 4000 x 4000 mm Table Load: 80000 kg Clamping Area: 3000 x 3000 mm Turning Speeds: 257 - 2570 RPM Spindle taper: 120 Automatic feeds: 342 mm / rev Spindle Turning Speed - Stepless: 1,5 - 630 RPM Fodpfxsw Upfds Aabjpn Max. Torque On The Boring Spindle: 20000 Nm Rapid Traverse: 16000 m / min Drive Capacity - Spindle Motor: 9,8 - 35,5 kW Total Power Requirement: 75 kW Bore Depth: 2000 mm Vertical headstock movement on the column: 3150 mm transverse movement of the stand on the bed: 4000 mm Lowest position of the spindle axis above the bed: 1100 mm Spindle speed when moving the quill forward: 1,6 - 300 max. rpm Drill feeds (spindle, quill) continuously variable in the range: 1,6 - 1600 mm / min Milling feeds (headstock vertical, column horizontal) infinitely variable: 1,6 - 1600 mm / min Machine length: 11350 mm Machine width: 5450 mm Machine Height: 7350 mm Weight Of The Machine Ca.: 65 t Further information: Threading: 22 metric threads, pitch range 0.5 - 12mm 32 Whitworth threads, pitch range 28 - 1 (gears) Accessories: - console for tools - 1 set of operating tools - ejector and fastening wedges for spindle - lubricating press - 1 set of spare parts for electrical equipment - clamping base plate - setting stick with electrical equipment Machine can be inspected under power by appointment.
