Used Thread Grinding for sale (6,309)

Condition: good (used), Year of construction: 2004, DGT Plus control system (Siemens basis) Kdjdpfovg Sifjx Abcoi Sanding length 2400 mm Sanding width 1290 mm Sanding height 700 mm Magnetic table 2000 x 1100 mm Max. Table load capacity 5000 kg Grinding wheel width 150 mm Sanding spindle speed 960 rpm Machine weight approx. 30 tons

Condition: new, functionality: fully functional, power: 55 kW (74.78 HP), Year of construction: 2026, Ball Mill for Powder and Mining Plant: Structure, Function, and Technical Details A ball mill is a key grinding machine widely used in mining, metallurgy, cement, chemical, and powder-making industries. It is designed to grind various ores and other materials into fine powder through impact and attrition between steel balls and the material inside a rotating cylindrical shell. In mining plants, ball mills are essential for ore beneficiation, preparing materials for flotation, magnetic separation, or leaching processes. In powder production, they ensure uniform particle size and high surface area for further processing. Working Principle The ball mill operates on a simple yet effective principle: as the cylindrical shell rotates around its horizontal axis, the grinding media (steel or ceramic balls) are lifted along the inner wall by centrifugal force and friction. When they reach a certain height, they fall freely, striking and grinding the material below. This repeated motion causes both impact and abrasion, reducing the material to the desired fineness. The grinding process can be performed in dry or wet conditions depending on the application. Structural Composition A standard ball mill consists of several main components: Feeding part: Equipped with a feeder or screw conveyor to ensure uniform material input. Discharging part: Can be grate type or overflow type, depending on the discharge method. Rotating part: The cylindrical shell made of steel plates, lined with wear-resistant liners. Transmission system: Includes motor, reducer, small transmission gear, and electrical control. Grinding media: Steel balls or ceramic balls of different diameters for efficient grinding. The internal liner design and ball size distribution are optimized to achieve maximum grinding efficiency and minimal energy consumption. Technical Details Typical Specifications: Feeding size: ≤25 mm Discharge size: 0.074–0.4 mm Kodeq Nf U Eopfx Abcedi Capacity: 0.65–615 t/h (depending on model and material hardness) Cylinder speed: 18–38 r/min Power: 18.5–4500 kW Liner material: High manganese steel, rubber, or alloy steel Grinding media load: 30–45% of cylinder volume Operating Modes: Dry grinding: Suitable for materials that must remain moisture-free, such as cement clinker, limestone, and quartz. Wet grinding: Common in ore beneficiation, where water or slurry improves grinding efficiency and particle uniformity. Application in Mining Plants In mining operations, ball mills are used after crushing to further reduce ore size and liberate valuable minerals. They are integrated into grinding circuits with classifiers, hydrocyclones, and flotation systems. The ground material is classified by size, and oversized particles are returned to the mill for regrinding. This closed-circuit system ensures consistent product fineness and efficient energy use. Common Applications: Gold, copper, iron, and zinc ore grinding Cement clinker and slag processing Silicate and ceramic powder production Coal and mineral powder preparation Conclusion A ball mill is an indispensable piece of equipment in both powder production and mining beneficiation plants. Its ability to grind materials into fine, uniform particles makes it vital for downstream processes such as flotation, sintering, and chemical reactions.

Condition: new, Year of construction: 2026, power: 7.5 kW (10.20 HP), Batch ball mills find applications in various industries where the processing of materials in discrete batches is required. The versatility of batch ball mills makes them suitable for a range of applications. Here are some common batch ball mill applications: 1. Ceramics Industry: - *Glaze Preparation:* Batch ball mills are extensively used in the ceramics industry for preparing glazes. Raw materials such as feldspar, quartz, and clay are ground with ceramic balls to achieve the desired particle size for glaze formulation. 2. Chemical Industry: - *Material Grinding:* Batch ball mills are used for grinding and blending various chemical materials. This includes the production of pigments, dyes, and other specialty chemicals where precise particle size control is crucial. 3. Pharmaceuticals: - *Drug Formulation:* In pharmaceutical manufacturing, batch ball mills are used for grinding and blending powders to create drug formulations. The controlled environment provided by these mills is essential for maintaining the integrity of pharmaceutical compounds. 4. Food Industry: - *Ingredient Mixing:* Batch ball mills may find application in the food industry for mixing and grinding ingredients. This can include the production of food additives, flavorings, and other powdered or granular products. 5. Mining and Minerals Processing: - *Ore Grinding:* Batch ball mills are used in mining and minerals processing for grinding minerals and ores. The controlled grinding helps in obtaining the desired particle size for subsequent processes, such as mineral separation or extraction. Kdedpfx Aeq I N H Njbcoi 6. Paints and Coatings: - *Pigment Dispersion:* In the paints and coatings industry, batch ball mills are employed for dispersing pigments into paint formulations. Achieving a uniform particle size is crucial for the quality and appearance of the final coating. 7. Building Materials: - *Raw Material Grinding:* Batch ball mills are used in the preparation of raw materials for the production of building materials, such as cement and concrete. Grinding of materials like limestone and clay helps in obtaining the desired fineness for subsequent processes. 8. Electronic Materials: - *Ceramic Powder Processing:* In the electronics industry, batch ball mills can be employed for processing ceramic powders used in the production of electronic components and insulating materials. 9. Research and Development: - *Material Testing:* Batch ball mills are often used in research and development laboratories for testing and optimizing material formulations. They provide a controlled environment for small-scale processing and experimentation. 10. Customized Applications: - *Specialized Processes:* Batch ball mills can be adapted for various specialized processes in different industries where precise grinding and mixing are required. Custom modifications can be made based on specific application requirements. When using a batch ball mill, it's important to consider factors such as the type of material being processed, desired particle size, and the specific requirements of the end product. Additionally, following the manufacturer's guidelines and maintaining proper operating conditions are essential for efficient and effective milling processes. Technical details We have different options for different requirements, please contact our team for more info.

Condition: new, Year of construction: 2026, power: 300 kW (407.89 HP), Ball Mill for Mining & Fine Powder Making: A ball mill is a fundamental grinding device widely used in mining, metallurgy, cement, and chemical industries. It is designed to grind ores and other materials into fine powder through impact and attrition between steel balls and the material inside a rotating cylindrical shell. In mining plants, ball mills are essential for ore beneficiation, while in powder-making industries, they ensure uniform particle size and high surface area for further processing. Working Principle The ball mill operates on the principle of impact and friction. As the cylindrical shell rotates around its horizontal axis, the grinding media—usually steel or ceramic balls—are lifted along the inner wall by centrifugal force and friction. When they reach a certain height, they fall freely, striking and grinding the material below. This repeated motion breaks down the material into fine particles. The process can be carried out in dry or wet conditions depending on the application. Structural Composition A standard ball mill consists of several main components: Feeding part: Ensures uniform material input through a feeder or screw conveyor. Discharging part: Can be grate type or overflow type, depending on the discharge method. Rotating part: The cylindrical shell made of steel plates, lined with wear-resistant liners. Transmission system: Includes motor, reducer, small transmission gear, and electrical control. Grinding media: Steel or ceramic balls of various diameters for efficient grinding. The internal liner design and ball size distribution are optimized to achieve maximum grinding efficiency and minimal energy consumption. Technical Details/Typical Specifications: Feeding size: ≤25 mm Discharge size: 0.074–0.4 mm Capacity: 0.65–615 t/h (depending on model and material hardness) Cylinder speed: 18–38 r/min Power: 18.5–4500 kW Liner material: High manganese steel, rubber, or alloy steel Grinding media load: 30–45% of cylinder volume Operating Modes: Dry grinding: Used for materials that must remain moisture-free, such as cement clinker, limestone, and quartz. Wet grinding: Common in ore beneficiation, where water or slurry improves grinding efficiency and particle uniformity. Kodpfx Aoq Ngafebcedi Application in Mining and Powder Production In mining operations, ball mills are used after crushing to further reduce ore size and liberate valuable minerals. They are integrated into grinding circuits with classifiers, hydrocyclones, and flotation systems. The ground material is classified by size, and oversized particles are returned to the mill for regrinding. This closed-circuit system ensures consistent product fineness and efficient energy use. In fine powder production, ball mills are used to produce materials such as silicate, ceramic powder, refractory materials, and chemical raw materials. The uniform particle size achieved by ball milling enhances product quality and performance in downstream applications. Conclusion A ball mill is an indispensable piece of equipment for both mining and fine powder making. Its ability to grind materials into fine, uniform particles makes it vital for ore beneficiation and industrial powder production. With flexible configurations, high efficiency, and reliable operation, modern ball mills provide a cost-effective and energy-efficient solution for large-scale grinding, ensuring consistent quality and productivity across diverse applications.

Condition: new, fuel type: electric, Year of construction: 2026, machine/vehicle number: 2700x4500, Equipment: low noise, Main Technical parameters of the ball mill Drum diameter: 2400mm Drum length: 4500mm Motor power: 320KW Max input size: 25mm Capacity:35-60 t/h Weight: 72Tons Ball loading: 30Tons Besides this model, we also have the other models like 2700x4500, 3200x4500, 1830x13000mm, and so on, and we can also offer customerization service, we can also provide complete grinding solution for various industries like cement, quartz, ore beneficiation plant, and so on, welcome to contact us for more info. A ball mill is a common grinding machine used to grind and blend materials for use in mineral processing, including ore mining and the production of silica (silicon dioxide). When it comes to ore mining and silica grinding, the characteristics of the ore and the final product requirements will play a crucial role in selecting the appropriate ball mill. Here are some considerations for using a ball mill in ore mining and silica grinding: 1. Ore Characteristics: - Hardness: The hardness of the ore determines the type of ball mill that is most suitable. Harder ores may require a more robust and wear-resistant ball mill. - Particle Size Distribution: The initial particle size of the ore affects the grinding process. Different ores may require different approaches to achieve the desired particle size. 2. Silica Grinding: - Silica Content: If the primary goal is to grind silica, it's important to consider the initial silica content and the desired final particle size. Silica grinding often requires special attention to prevent excessive wear on the milling equipment. 3. Ball Mill Type: - Overflow vs. Grate Discharge: The type of discharge from the ball mill can impact the final product and the grinding efficiency. Overflow mills are generally used for most grinding applications, while grate discharge mills are more suitable for certain types of ores. 4. Mill Size and Capacity: - Mill Diameter and Length: The size of the ball mill should be selected based on the amount of material to be ground and the desired throughput. - Capacity: Ensure that the chosen ball mill has the capacity to handle the required volume of material efficiently. 5. Grinding Media: - Material and Size: The choice of grinding media (balls or cylpebs) and their size depends on the hardness of the ore and the desired final particle size. Different grinding media materials can impact the purity of silica during grinding. 6. Liners and Lifting Aids: - Liners: Consider the type of liners used in the ball mill to protect the shell and optimize the grinding process. - Lifting Aids: Some mills use lifting aids to enhance the grinding action and promote better mixing of the material. 7. Control and Monitoring Systems: Kedpfx Asq Igiiobcjdi - Automation: Utilize control systems to automate the milling process and ensure optimal performance. - Monitoring: Regularly monitor the milling process to adjust parameters as needed for consistent and efficient operation. 8. Safety Measures: - Safety Systems: Implement safety features to protect personnel and equipment during operation. Always follow the manufacturer's recommendations and guidelines for operation and maintenance to ensure safe and efficient use of the ball mill in ore mining and silica grinding applications.

Condition: new, Year of construction: 2026, functionality: fully functional, Ball Mill with Air Classifier: The Ultimate Powder Processing Equipment In the world of industrial powder production, precision, efficiency, and flexibility are paramount. Whether producing ultra-fine powders for high-tech applications or coarser materials for everyday products, the combination of a Ball Mill with Air Classifier offers unparalleled performance. This dynamic duo provides a comprehensive solution for industries ranging from chemicals and ceramics to paints, plastics, and pharmaceuticals. This article introduces the ball mill with an air classifier, explores its applications, and highlights the key advantages of this essential powder equipment. General Introduction to Ball Mill with Air Classifier ball mill with air classifier is an advanced grinding and classification system designed for efficient, high-quality powder production. The system consists of two main components: 1. Ball Mill: A cylindrical grinding device filled with grinding media (such as steel balls) that operates by rotating around its axis. The raw material is reduced to smaller particle sizes through impact and friction within the mill. 2. Air Classifier: A sophisticated device that separates particles based on size using airflow. Fine particles are carried away, while coarser particles are returned to the ball mill for further grinding. The combination of these two components creates a closed-loop system that ensures consistent particle size distribution, high efficiency, and minimal waste. Applications of Ball Mill with Air Classifier The ball mill with air classifier is a versatile solution used in a wide range of industries to process various materials. Key applications include: 1. Mineral Processing The system is widely used in the production of minerals such as calcium carbonate, quartz, feldspar, and talc. These finely ground minerals are essential for industries like ceramics, paints, plastics, and rubber. 2. Cement and Construction Materials Cement and other construction materials require precise particle size control for optimal performance. The ball mill with air classifier ensures uniformity and enhances the quality of construction materials. 3. Chemicals and Pharmaceuticals Kdodpfx Aevlwkxebcji Fine powders play a critical role in the chemical and pharmaceutical industries. From active pharmaceutical ingredients (APIs) to industrial chemicals, this system delivers the consistent quality required for these applications. 4. Paints, Coatings, and Pigments The production of paints and coatings demands ultra-fine powders to achieve smooth finishes and vibrant colors. The ball mill with air classifier produces high-quality powders for superior results. #### 5. Food and Agriculture Food-grade powders such as additives, preservatives, and agricultural products like fertilizers can be efficiently processed using this system, meeting stringent regulatory requirements. Industries That Benefit from Ball Mill with Air Classifier Several industries rely on the capabilities of this system to produce fine powders with specific characteristics: - Ceramics: Produces high-purity powders for tiles, insulators, and advanced ceramics. - Rubber and Plastics: Creates fillers and additives for improved durability and performance. - Pharmaceuticals: Ensures consistent particle size for APIs and excipients. -Construction: Delivers materials for concrete, plaster, and other applications.

Condition: ready for operation (used), functionality: fully functional, center height: 125 mm, center width: 600 mm, grinding wheel diameter: 400 mm, grinding wheel width: 50 mm, grinding wheel bore: 127 mm, No reserve price - guaranteed sale to the highest bidder! The motor and frequency converter for the workpiece headstock have been replaced! In addition, the control cabinet and wiring diagram have been renewed! TECHNICAL DETAILS Centre height: 125 mm (175 mm with risers) Centre distance: 600 mm Grinding wheel diameter: 400 mm Grinding wheel width: 50 mm Grinding wheel bore: 127 mm Swivel adjustment: 270° Workpiece headstock speed: 20 to 400 rpm Spindle taper: 5 MT Tailstock taper: 3 MT Table swivel adjustment: 10° Table speed: up to 6.0 m/min MACHINE DETAILS Kdjdpfx Abeyu Rd Iscei External grinding wheel motor: 4.0 kW Workpiece spindle motor: 2.2 kW Dimensions & Weight Dimensions (L x W x H): 2,580 x 1,680 x 1,670 mm Machine weight approx.: 2,700 kg EQUIPMENT New control cabinet and new wiring diagram New motor and frequency converter for the workpiece headstock 2-axis digital display Coolant tank Geometry according to Kellenberger protocol Extensive accessories

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 2,000 mm, warranty duration: 12 months, Workpiece Clamping Diameter : ø 3 – 140 mm (Optional: ø 210 mm) Workpiece Diameter : ø 3 – 310 mm Workpiece Length : 50 – 2.000 mm Centre Hole Diameter : ø 1 – 60 mm (Optional ø 100 mm) Workpiece Weight : max. 170 kg (Optional 1,000 kg) Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Grinding Process : Manual Sectors: : Precision Grinding, Aviation, Automotive, Machinery etc. Kdedpfxexrnche Abcsi Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex M-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex M-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Contact us for more details.

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, Workpiece Clamping Diameter : ø 3 – 140 mm (Optional: ø 210 mm) Workpiece Diameter : ø 3 – 310 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 60 mm (Optional ø 100 mm) Workpiece Weight : max. 170 kg (Optional 1,000 kg) Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Grinding Process : Semi-Automatic, CNC Control Panel : Beckhoff CNC Movements : Z-Axis Indurstry 4.0 Compatibility : Available Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Sectors : Precision Grinding, Aviation, Automotive, Machinery etc. Kdjdpfx Asgb Ec Hebcoi Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Easy to Use CNC Control Panel: Benefit from very simple operation and grinding program recording with the Beckhoff control panel and Z-axis servo movement. Industry 4.0: Fully compatible with Industry 4.0 applications, thanks to the Beckhoff control panel. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex SA-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex SA-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Z-Axis movement is provided by servo motor in CNC form. The part is loaded-unloaded and clamped manually. Settings are made from CNC control panel and grinding is started by pressing the start button. No other manual setting or control is made during grinding. Contact us for more details.

Condition: reconditioned (used), functionality: fully functional, The machine is retrofitted and modernized in 2025. The modernisation consists of adding the automatic infeed and auto cycle functions. The HMI and operating panel is offered in English, German and French. Dimensions Grinding Wheel (OD x ID x width) Ø 350 x Ø 127 x 100 mm Grinding wheel width 100 mm Ø min / max to rectify 1.5 / 50 mm Ksdpfx Ajvtl Rpebcsdi No. infinite grinding wheel speeds Min / max speed of regulating wheel (r.p.m.) 10/250 rpm Infeed : Auto Auto cycle : Yes Dressing : Manual Dimensions Regulating Wheel (OD x ID x width) Ø 230 x Ø 76.2 x 100 mm Regulating wheel width 100 mm Maximum length to be rectified in plongeé 200 mm Length 1800 mm Width 1300 mm High 1600 mm Weight 2000 Kg Accessories: New Coolant tank with paper filtration system

Condition: new, grinding band dimension 150 x 2000 mm band speed 33 m/sec weight of the machine ca. 105 kg engine output 4 kW turning speeds 2800 U/min Kdodpfjyv N Agox Abcji Accessories / equipment: - Vibration-free running smoothness - Adjustable working height - S1 motors with 100% duty cycle - Surface and contact grinding possible - Removable protective cover for surface grinding - Connection piece for double suction - Built according to the CE standard

Condition: new, grinding band dimension 75 x 2000 mm band speed 33 m/sec weight of the machine ca. 90 kg engine output 4 kW turning speeds 2800 U/min Accessories / equipment: - Vibration-free running smoothness Kodpfx Aeyv Nyfebcsdi - Adjustable working height - S1 motors with 100% duty cycle - Surface and contact grinding possible - Removable protective cover for surface grinding - Connection piece for double suction - Built according to the CE standard

Condition: new, width of the strips 2000 mm band length 75 mm band speed 16,5/33 m/s turning speeds 1400/2800 U/min weight of the machine ca. 75 kg Kedsyv Nw Dopfx Abcodi Volume: 83 dB

Condition: new, width of the strips 150 mm band length 2000 mm band speed 16,5/33 m/sec total power requirement 2,6/3,37 kW turning speeds 1400/2800 U/min weight of the machine ca. 95 kg Equipment / Accessories: - Removable dust catcher - Fine adjustment of the band adjustment Kdjdpfx Abeyv Nb Nocji - Sanding belt - Eye protection - Motor protection switch - Operation manual - Sanding table - working height adjustment - surface grinding pad

Condition: new, neu ca. 2 Wochen ab Auftragse Italien 17940 € 344.45 € Dm. 200x78x78 mm 2800 1/min 300 mm 300x150x55 mm 350x150 mm 500x160 mm 3.6 kW 1020 mm 820 mm 2170 mm 440 kg This Grinding machine with fixed table derives from the model R.V. 500 but it differs from it as it is equippedwith a long column supported by four bearings and is opportunely stiffened by a sturdy column support. This Surface grinding machine, due to its stiffness and geometrical stability, is highly suitable for grinding with precision pieces of notable height: single or mass-produced die-shop components, moulds, punches, gears and others. Moreover, the nuts of the vertical translation screw and the dowels to realign the wheel motor to the axis,equipping this model of Grinding machine with fixed table, allow preserving perfect work conditions over the years, too. CAST IRON BED to maintain the geometric stability of the grinding machine in time, too. CAST IRON COLUMN, protected by bellows and supported by four adjustable precision bearings, broadly sized for this type of grinding machine with fixed table. Three-phase MOTOR air-cooled by double jacket, to prevent the overheating of the grinding machine motorduring continuous machining and to keep the temperature of the motor shaft and of bearings constant. Hardened, ground and dynamically balanced SHAFT, supported by precision ball bearings, widely sized for this type of grinding machine with fixed table and self-adjusting by means of springs for the backlash preload, to absorb thermal expansions. VERTICAL TRANSLATION SCREW supported by opposite and adjustable ball bearings, Kdjdpfx Abeyv Iqvocsi with apt motion for maintaining, in this model of grinding machine with fixed table, the wheel work field free from hindrances and for avoiding dust depositions. Metal BELLOWS for a better protection of the vertical translation screw of the grinding machine. Opposite bronze NUTS, for the recovery of the eventual wear in time of the vertical translation screw of the grinding machine with fixed table. REGISTRATION DOWELS to re-align the wheel motor of the grinding machine to the axis, obtaining parallel surfaces also in time. HANDWHEEL of the grinding machine, supported by three bearings and engaged on the screw by means of a pair of helical gears, equipped with graduated drum, supported by a trust bearing, for a stock removal of mm 0.01 - 0.02 - 0.03 for each single pass; the rapid feed per handwheel turn is mm 2. KNOB WITH JACK, for the programmable micrometric feed of mm 0.01 - 0.02 - 0.03 - 0.04 per pulse, which allows a simple use by avoiding the constant increment control. SLOT to permit the maximum use in height of the work field of the grinding machine wheel and to clamp non-magnetic parts and accessories such as: magnetic chuck, self-centering chuck and squares. Low-voltage CONTROLS, protection, indicator light and all requisites to comply with safety and conformity regulations provided for this type of grinding machine with fixed table. HANDLES, SHAPES AND SIZES of the grinding machine with fixed table designed to meet the current ergonomic recommendations for work. WITH FOLLOWING ACCESSORIES: Magnetic chuck 300 x 150 mm Wheel flange and cup wheel Semiautomatic dresser with diamond Coolant system Operating manual in German or Italian

Condition: good (used), Tos BU 16 Cylindrical external / internal grinding machine Max. Grinding diameter: 160 mm Sanding length: 250 mm Center height: 125 mm Kodpfx Abeiau I Ijcjdi Clamping area between spikes: 250 mm Spindle speed: 2420/3290 rpm 2,5 kW Weight: 1,3 t Dimensions: 1900 x 1100 x 1500 mm Cooling system

Year of construction: 2005, condition: ready for operation (used), - USED - CNC EXTERNAL GRINDING MACHINE CENTRE HEIGHT: 171 mm DISTANCE BETWEEN CENTRES: 430 mm MAX GRINDING LENGTH: 400 mm MAX ADMITTED LOAD: 150 Kg X-AXIS TRAVEL: 170 mm Z-AXIS TRAVEL: 600 mm RAPID FEEDS: 12 m/min SPINDLE: 830 rpm; 24 Nm Kjdpfjyvlxdox Abcedi GRINDING WHEEL SIZE: 508 x 80 x 203,2 mm MOTOR POWER: 7,5 kW CONTROL UNIT: FAGOR 8055 TCO WEIGHT: 4500 Kg ACCESSORIES: PAPER FILTER ; FUME EXHAUSTER ; MAGNETIC FILTER ; GRINDING WHEEL BALANCER NOTE: 0-9° SWIVELLING TABLE; SWIVELLING CHUCK; INVERTER FOR KEEPING THE PERIPHERAL EXTERNAL GRINDING WHEEL SPEED STEADY; PIECE LOCKING DEVICE WITH PNEUMATIC SYSTEM; HYDRAULIC OPENING TAILSTOCK AND DEVICE FOR SEARCHING THE CYLINDRICITY

Condition: used, Technical details: grinding length: 1000 mm grinding width: 500 mm workpiece height: 500 mm table surface area: 1000 x 450 mm magnetic plate size: 1005 x 500 x 84 mm table speed: k.A. m/min table adjustment: längs: 1100 mm table adjustment: quer: 500 mm grinding spindle speed: 1420 - 2840 U/min grinding head vertical adjustable: 700 mm dimensions of grinding wheel: Ø 280 x 50 mm weight of the machine ca.: 2,7 t dimension machine xH: 3,1 x 2,0 x 2,4 m dimension coolant device LxWxH: 3,0 x 1,1 x 0,85 m dimensions of hydaulic: 750 x 600 x 850 mm dimension control panel: 0,65 x 0,85 x 1,3 m Kjdpfx Ajvc Aw Esbcedi Equipment: Dressing device Holder for dial gauge Coolant filter system Hydraulic unit Manual control unit *

Condition: good (used), Year of construction: 2007, Kuehlmittelanlage 2.500l, Haftkraftregelung, halbautom. Wuchtsystem Schleiflaenge 3150 mm Schleifbreite 800 mm Werkstueckhoehe 650 mm Tischflaeche 3.150 x 600 mm Magnetspannplatte 3.000 x 600 mm Kdedpfx Abodgk H Ajcoi Spindeldrehanzahl 1/min Schleifscheibenabmessung 450 x 100 x 127 mm Spindelleistung kW Gesamtleistungsbedarf 22 kW Maschinengewicht ca. t Raumbedarf ca. 11 x 3 x 2,4 m

Condition: good (used), - All rubber rollers new or as good as new - Belt length 3000 mm Kodpfx Aeulvipjbcedi - Year of manufacture - Price On request

Condition: used, throat 215 mm thread M2 - M10 thread depth max. 60 mm spindle MK 2 bore depth 90 mm 150 bis 450 mm 220 x 285 mm column diameter 75 mm mm Total height 950 mm Kedpfx Asyv N Ddebcodi motor speeds: 700 / 1400 1/min weight of the machine ca. 95 kg

Condition: new, grinding band dimension 150 x 2000 mm band speed 33 m/sek. total power requirement 3 kW Kdsdeyv Nw Rspfx Abcji weight of the machine ca. 95 kg turning speeds 2800 U/min Standard equipment: - Removable dust catcher - Fine adjustment of the band adjustment - Sanding belt - Eye protection - Motor protection switch - Operation manual - Sanding table - working height adjustment - surface grinding pad

Condition: new, band speed 33 m/s Kjdpfxsyv Nvge Abcjdi grinding band dimension 75 x 2000 mm total power requirement 3 kW weight of the machine ca. 75 kg turning speeds 2800 U/min Standard equipment: - Knife set for flat steel - Complete knife set for angle steel shears - Complete normal punching equipment - Quick release device for punches up to 31 mm - Support table for punching device, rectangular notching and flat steel shears - Bending stamp with matrices V 40 and V 70 - Electric contact stop (1.000 mm)

Condition: used, Year of construction: 2016, Used machine Cross sanding machine Year of construction 2016 Product advantages Underneath perfectly lacquered, stained or oiled wood surfaces there is always a perfectly sanded surface! Felder sanding machines are characterized by solid construction, state-of-the-art machine technology and maximum productivity. The most important highlights at a glance: ? Sanding width 1350mm ? Sanding width 3-170mm ? Combined superfinishing unit ? Touch-screen control for work processes ? The Felder operating concept guarantees maximum process and work safety Kdsdpfew I Uv Ujx Abcoi Your advantages at a glance: Time saving ? Motorized adjustment of the contact roller in the 1/100 mm range from the control panel ? Innovative unit arrangement for pre-sanding / fine sanding of veneered workpieces ? Brushing devices at the machine outlet ? Lacquer sanding against additional equipment ? comfort ? Fixed feed table height (machine head adjusts) ? Touch screen control with clear image display and program memory ? Machine data acquisition for sanding belt wear and much more. ? Tool-free handling when changing the sanding belt ? Large fold-down table extensions for the heaviest workpieces ? flexibility ? Units for calibration, fine sanding and lacquer sanding ? Variable feed speed up to 20 m/min by means of inverter Innovation ? Electronically segmented sanding pad with silicone technology for minimum air consumption ? Combined superfinishing unit incl. chevron sliding belt to compensate for oscillation marks ? quality ? Solid machine construction ? Durable machine components Basic equipment Control unit finish 1350 classic Control unit with 7" color touch screen 100 program memory locations Maintenance intervals Plain text error messages Ammeter for load monitoring Feed table fixed infeed height - fixed table, 900mm, electric height control of the units incl. fine adjustment from the control panel, V-speed infinitely variable from 2.8-20m/min. Adjustable via inverter from the control panel Manual protection and workpiece over-thickness protection Workpiece detection sensor with 25 sensors 55 mm segment width Endlessly manufactured belt conveyor with honeycomb structure Automatic feed carpet centering Cross sanding unit finish 1350C high gloss Segmented, electronic-pneumatic sanding pad ESC, segment width 25 mm, incl. quick-change system Chevron sliding belt between sanding pad Sanding belt for homogeneous sanding without oscillation marks Variable pressure control on the operating side Electro-pneumatic sanding belt oscillation Electronic sanding belt run-off protection 1 motor with 7.5 kW (10 hp) Star-delta start-up Cleaning fan with time control Cutting speed 12 m/sec Sanding belt 140 x 4560 mm Combined superfinishing unit 1350C: Rubberized, grooved contact roller with 85-90° Shore hardness and 142 mm diameter Electromot. Position-controlled grit compensation segment, electro-pneumatic sanding pad ESC, segment width 25 mm, incl. quick-change system Variable pressure control on the operating side Chevron sliding belt between sanding pad and sanding belt belt for homogeneous sanding without oscillation marks Mechanically pre-tensioned rubber pressure rollers Electro-pneumatic sanding belt oscillation Electronic sanding belt run-off protection

Condition: good (used), Year of construction: 1972, Slideway grinding machine WMW SFBZ 2200/6000 Manufactured by WMW Germany in 1972 Kdodpfxew U A Rms Abcoi Main technical data: Table size: 2240x6000 mm Max. grinding width: 2200 mm Max. grinding length: 6000 mm Max. grinding height: 2000 mm Max. workpiece weight: 15,000 kg Machine weight: 130 tons For more information, please contact us.
