Used Twin Spindle Cnc Lathe for sale (21,371)

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 Nedpfx Aew Ah R Nsa Iewn - Max. bar diameter : 22 [mm] - Spindle speed : 10,000 [rpm] - Spindle power : 8.7/15 [kW] - Torque : 10/18 [Nm] - Number of counter-spindles : 2 - Spindle speed : 10,000 [rpm] - Number of slides : 10 - Travels : X x Z = 62 x 85 [mm] - Number of counter-operation slides : 2 - Travel : X = 62 [mm] - Dimensions : 3330 x 1830 x 2860 [mm] - Weight : 5700 [kg] - Connected power : 75 [kVA] - Production hours : 20,000 [h] EQUIPMENT - CN Siemens 840D SL - 2 NCU - TRANSMIT / TRACYL function - ARTIS - 2 additional electronic shaft preparations - 2 SCARA counter-spindles - 2 parts catchers with conveyor belt - Bar scrap recuperator - Index bar guide - Bar feeder predisposition - Fire protection system

Condition: ready for operation (used), Year of construction: 2022, functionality: fully functional, 2 used CNC lathes with Y-axis and two spindles Machines including loader and accessories (tool holders, jaws, etc.) Nsdpfx Aaow N R Nyj Iswn For technical data, see the PDF file

Condition: used, Cnc multispindle lathe INDEX MS32P Nodpfxswyfn Ho Aa Ijwn

Condition: new, Year of construction: 2025, turning diameter over cross slide: 250 mm, turning length: 730 mm, turning diameter: 500 mm, spindle speed (max.): 1,800 rpm, CNC lathe machine CK 6150 with flat bed We offer a new CNC lathe machine model CK6150. We use this machine in our production and you can see it in operation before ordering. The CK 6150 lathe has a flat bed and hardening guides, which ensures a long period of operation of the equipment. The machine is equipped with a CNC system, the GSK CNC system is installed as standard. Optionally, the machine can be equipped with a Fanuc or Siemens CNC system. The machine can have a tool holder for 4-6 or 8 tools, depending on the customer's wishes. It is possible to install a hydraulic chuck on the machine, which will greatly simplify the process of installing parts on it and a hydraulic tailstock. The CK 6150 lathe can be equipped with additional supporting frame for more accurate manufacturing of long parts. Technical specifications: Model CK 6150 x 1000 Maximum workpiece diameter over bed 500 mm Nwedpfxjxdmgve Aa Ien Maximum workpiece diameter over support 250 mm Maximum workpiece length 1000 mm Maximum turning length 730 mm Spindle bore diameter 82 mm Spindle speed 150-1800 rpm Engine power 7.5 kW Mechanical chuck (hydraulic optional) Chuck size 250 mm. 4-position tool holder (6 or 8 optional) Maximum tool size for tool holder 25x25 mm Machine weight 2700 kg Machine dimensions 2650×1700×1820 mm We can also supply lathes CK 6140, CK 6150 and CK 6160 with other dimensions of the working part: CK 6140 dimensions of the working part 550/750 mm CK 6150 dimensions of the working part 1000/1500/2000 mm CK 6160 dimensions of the working part 1000/1500/2000 mm CK 6152E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6185E dimensions of the working part 1000/1500/2000/3000/4000 mm CK 61100E dimensions of the working part 1000/1500/2000/3000 mm CK 61125E dimensions of the working part 1000/1500/2000/3000 mm

Condition: good (used), Year of construction: 2012, functionality: fully functional, Schiess CNC vertical lathe with C axis, year 1992, retrofitted in 2012 CNC: NUM 1060 FLEXIUM 2 tables, table diameter 2000mm – max turning diameter 2500mm – max table speed 201 rpm – table power 56 KW Load capacity (table included): 16,000kg Movable crossrail with 12 positions, 50mm pitch Available space under spindle nose: min. 795mm, max. 1345mm RAM Z stroke: 1000mm C axis with 360,000 positions – milling spindle max speed 1600 rpm – milling spindle power 22KW – 2 gear ranges Tool magazine: 20 turning tool positions, 35 milling tool positions 1 milling head WIDAFLEX UTS80 1 milling head ISO 50 Renishaw MP60 touch probe (for parts) Nwodpoxpqm Rjfx Aa Isn Tool presetter – Transmit function: G20 / G21 – No rigid tapping Chip conveyor Front door: partial opening M0 / full opening

Condition: good (used), Year of construction: 2002, Universal CNC lathe BOEHRINGER NG 200 Manufacturer: BOEHRINGER Type: NG200 CNC double Control unit: Siemens 840D Year of construction: 10/2001 Turning diameter: 290 mm Turning length: 850 mm Control: SIEMENS 840 D Turning diameter over bed: 600 mm Turret 1 Turret 2 Counter spindle Counter spindle stock Tailstock C-axis Driven tools Automatic machine doors - newly retrofitted Z-axis resolution: 40nm (2nm interpolated) Travel path in Z: 740mm Rapid traverse speed in Z: 25 m/min Centering tip SK 30 X-axis resolution: 125nm (8nm interpolated) Travel path in Z: 220mm Rapid traverse speed in Z: 25 m/min Distance between main and counter spindle: 1034mm Drive power: 30-72 kW Torque: 662 Nm Max. speed range: 4500 rpm Spindle head: size 6/8 DIN 55026 Spindle diameter in front bearing: 120 mm Chuck diameter: 200-315mm Spindle bore: 103 mm Tailstock quill holder MK: MK 4 Machine weight approx. [weight]: 11 t Space required approx. [needed space]: 6.0x2.3x2.5 m Complete documentation is available. Inspection under power can be arranged at short notice. We are happy to answer any further questions you may have. Price, ex warehouse here plus VAT. Condition: good - ready for demonstration Delivery: ex warehouse - as seen Payment: net - after receipt of invoice Subject to prior sale, errors excepted. Nwsdpfxevr Eqge Aa Ion We ask for your order. Other machines and systems available from stock - please enquire. We look forward to hearing from you.

Condition: ready for operation (used), Year of construction: 2005, operating hours: 9,400 h, functionality: fully functional, machine/vehicle number: 8662, turning length: 380 mm, turning diameter: 400 mm, spindle bore: 55 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 100 rpm, travel distance X-axis: 160 mm, travel distance Y-axis: 440 mm, travel distance Z-axis: 380 mm, spindle motor power: 11 W, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 12 m/min, rapid traverse Z-axis: 20 m/min, total height: 1,900 mm, total length: 3,500 mm, total width: 1,650 mm, type of input current: three-phase, overall weight: 3,300 kg, bar passage: 45 mm, spindle nose: ASA 5", coolant pump power: 75 W, tailstock quill diameter: 85 mm, number of tool stations in tool turret 1: 12, Equipment: documentation/manual, Biglia B301 CNC Lathe – Refurbished Used in Excellent Condition Year 2005, used and overhauled, perfect for precision machining of small and medium components. Compact, reliable, and robust machine equipped with a bi-directional 12-position turret, automatic tailstock, and belt chip conveyor. Ideal for mechanical workshops and companies seeking a top-quality, ready-to-use CNC lathe. Main technical specifications: - Model: Biglia B301 - Year: 2005 Capacity: - Max swing diameter: 400 mm - Bar capacity: 45 mm - Machinable diameter (secondary operation): 220 mm Nsdpevw Agvofx Aa Iown - Max turning length: 380 mm Spindle: - Spindle nose: ASA 5” - Spindle bore: 55 mm - Chuck: 3-jaw Autoblok 210 BH - Spindle speed: 100 – 5000 rpm - Spindle motor power: 11 – 15 kW Travel: - X-axis travel: 160 mm - Z-axis travel: 380 mm - B-axis travel: 440 mm Rapid traverse: - Rapid on X/Z axes: 20 m/min - Rapid on B axis: 12 m/min Turret and tailstock: - Turret: bi-directional, 12 positions - Automatic tailstock: yes - Quill diameter: 85 mm - Taper: MT4 Weight and dimensions: - Machine weight: 3,300 kg - Dimensions: 3500 × 1650 × 1900 mm (h) Included accessories: - Belt chip conveyor - 12 static toolholders - Part catcher (pneumatic hand) Condition and availability: - Used, refurbished, tested, and in perfect working order - Ready for delivery - Can be inspected by appointment at our facility Ideal for: precision engineering, small-lot and serial production, and applications on steel, brass, aluminum, and engineering plastics.

Condition: as good as new (ex-display), Number: AAL 130426 Length: 1,000 mm Storage diameter: 170 mm Cone intake: 46 to 64 mm diameter 70 mm length Nwjdpfx Aed Nlagsa Ien Speed: 8,000 U/min Condition: Unused Use: For large Chevalier grinding machine FSG 2460 CNC

Condition: used, Year of construction: 2005, functionality: fully functional, power: 45 kW (61.18 HP), input frequency: 50 Hz, The second-hand Twin Aces BRAVE-F1 model was manufactured in 2005 and is in perfect working condition. Its technical specifications are as follows: Nsdpfx Aaov Hdlfs Iewn Serial No: B05046 Installed Power: 45 kW Voltage: 380V AC ±%10 Frequency: 50/60 Hz

Condition: as good as new (ex-display), Year of construction: 2024, operating hours: 10 h, functionality: fully functional, machine/vehicle number: 8046723D038, spindle motor power: 11,000 W, turning diameter over cross slide: 380 mm, spindle speed (max.): 3,000 rpm, overall weight: 2,000 kg, type of input current: three-phase, total width: 1,800 mm, total length: 2,500 mm, total height: 1,800 mm, torque: 373 Nm, Equipment: documentation/manual, CNC LATHE STYLE 350 [850 dbc] - main spindle motor power 11kW - main spindle bore Ø54 mm, 3,000 rpm - manual universal with 3 jaws D200mm - VDI30 turret with 8 positions - Coolant gun, including high-pressure pump - Work area lighting (LED) - Cooling system - Automatic lubrication - Ball screw protection - Full fairing with sliding doors - Speed potentiometer - Coolant control button - Handwheel Nwsdpfsvvwblox Aa Ijn - Remote support on machine – allows remote diagnostics

Condition: new, Discover the ultimate power and precision of our vertical lathe series. With its robust construction and proven technology, it delivers groundbreaking results for your machining projects. Experience the limitless possibilities of our CNC variant and take your production to the next level. TECHNICAL MAIN DATA (CNC MODEL): - Max. swing diameter: 1500/1800/2750/4000/5000 mm - Max. turning diameter: 1250/1600/2500/4000/5000 mm - Max. workpiece height: 1000/1600/2000/2000/2000 mm - Spindle motor power: 30/37/55/75 kW - Table diameter: 1000/1250/2250/3600/3600/4500 mm - Max. table speed: 500/400/120/63/63/50 rpm ACCESSORIES: Fanuc or Siemens control, ZF gearbox, chip conveyor, lubrication system, hydraulic system, machine guard, air gun, tricolor lamp, work light, chip cart, foot pedal, standard tool holder. SPECIAL ACCESSORIES: C-axis, tool magazine, linear scale, tool presetter, workpiece probe, electrical cabinet air conditioner, special tool holder, and more. For further details, please refer to the attached PDF file. TECHNICAL MAIN DATA (CONVENTIONAL MACHINE): - Faceplate diameter: 1000|1400|1800|2000|2300 mm - Swing diameter: 1200|1600|2000|2300|2600 mm - Turning height: 1000|1250|1400|1600|1500 mm - Table speed: 6.3-200|5-160|3.2-100|5-160|2.5-80 m/min - Gear stages: 16 - Max. workpiece weight: 3.2|5|8|8|8 t - Main motor power: 22|30|37|37 kW - Approx. machine weight: 9|14|18|23|21 t ACCESSORIES: Tool holder: 5-fold; Faceplate: with 4 jaw clamps; Servo motors: for axis adjustment, and more. For further details, please refer to the attached PDF file. Conventional vertical lathe with solid and proven technology, power, and precision for the machining of heavy workpieces. - Optimal loading - easily accessible with crane and forklift - Vertical support with 5-fold tool holder and side support (optional) with separate feed for internal and external machining - Heavy-duty column construction with wide, hardened guides - Hydraulic clamping of the crossbeam - Stable guide construction provides excellent stability and accuracy to the vertical arm - The spindle runs in a highly precise double-row roller bearing and is adjustable - The drive is through a reduction gear for high torque and a speed range of 2.5 - 80 min- Warranty: 12 months on the machine Now get a 15% energy subsidy from BAFA when replacing an old machine! Also benefit from the favorable leasing and hire purchase conditions of our leasing partners. Ask us about it. Of course, you also receive free delivery, assembly/commissioning, and ready-to-use handover as well as control training from us. The special net price displayed refers to the smallest model of the conventional series. The images show the CNC variants as well as a conventional version. Nwodpjd I I Iljfx Aa Isn

Condition: new, functionality: fully functional, turning diameter over cross slide: 654 mm, turning length: 1,514 mm, turning diameter: 418 mm, travel distance X-axis: 290 mm, travel distance Z-axis: 1,600 mm, spindle motor power: 18,500 W, rapid traverse X-axis: 18 m/min, rapid traverse Z-axis: 18 m/min, rotational speed (max.): 2,500 rpm, total height: 2,072 mm, total length: 5,575 mm, total width: 2,072 mm, overall weight: 9,000 kg, bar passage: 77 mm, spindle nose: ASA A2-8, LATHE FOCUS MOD. FBL 300 LMC WITH INCLINED BED TECHNICAL SPECIFICATIONS: CNC: FANUC 0i-TF Plus + Manual Guide I, 10.4'' color graphic display, remote handwheel Maximum turning length: 1,514 mm Distance between centers: 1,708 mm Maximum swing over bed: 654 mm Maximum turning diameter: 418 mm Bar capacity: 77 mm Spindle mount: ASA A2-8 Maximum spindle speed: 2,500 rpm Spindle motor: 15 – 18.5 kW X-axis travel: 290 mm Z-axis travel: 1,600 mm Rapid traverse X-Z: 18 m/min Tailstock travel: 1,510 mm Quill travel: 130 mm Quill diameter: 90 mm Quill taper: MT 5 Overall dimensions: 5,575 x 1,980 x 2,072 mm Weight: 9,000 kg COMPLETE WITH THE FOLLOWING STANDARD ACCESSORIES: - Hydraulic chuck Ø10'' Kitagawa, set of soft and hard jaws - Hydraulic chuck foot pedal - Serial, Ethernet, and USB ports - Belt-type chip conveyor with chip collection trolley - Rotating tailstock - Three-color alarm and cycle end warning lamp Nsdew A Rnkepfx Aa Iewn - Integrated work light - Levelling feet - Tool box with service keys - Programmable tailstock - Mobile coolant tank - Centralized lubrication system - Oil skimmer - Hydraulic spindle pedal - Set of tools and service keys - SAUTER turret, 12 positions - Tool holder BMT 65 - Driven tool motor 3.7/5.5 kW - Max driven tool speed: 4,000 rpm - No. 9 tool holders (4+4+1) - Power transformer - Operating and maintenance manuals, electrical diagrams, CNC manuals - CE Declaration INCLUDED ACCESSORIES: - Cooling system with Grundfos pump, 9.5 bar - Automatic tool presetting (Renishaw) - Hydraulic steady rest base with carriage-mounted positioning - Tailstock with carriage coupling via M function - Air blast through the spindle - No. 1 straight driven tool holder for BMT 65 - No. 1 angled driven tool holder for BMT 65 BRAND NEW MACHINE, CE COMPLIANT

Condition: as good as new (ex-display), Year of construction: 2018, operating hours: 200 h, functionality: fully functional, machine/vehicle number: 1421160-BV40058101, turning length: 300 mm, turning diameter: 240 mm, spindle bore: 61 mm, spindle speed (max.): 3,500 rpm, travel distance X-axis: 190 mm, travel distance Z-axis: 400 mm, spindle motor power: 11 W, rapid traverse X-axis: 18 m/min, rapid traverse Z-axis: 24 m/min, total height: 1,880 mm, total length: 2,860 mm, total width: 1,700 mm, overall weight: 3,400 kg, bar passage: 42 mm, Takamaz XL-150M CNC Lathe – showroom-used machine, virtually zero operating hours, never processed any material. The machine is in excellent condition, year 2018, practically new. Equipped with Fanuc CNC, driven tools, and numerous accessories. Main specifications: Year of manufacture: 2018 Serial number: 1421160-BV40058101 CNC: FANUC Series Oi – TD Maximum swing diameter: 280 mm Maximum turning diameter: 240 mm Maximum turning length: 300 mm Bar capacity: 42 mm Spindle bore: 61 mm Spindle: 3-jaw chuck SMW AUTOBLOK Ø 210 mm Spindle nose: ASA A2-8 Spindle nose height: 1050 mm Bearing inner diameter: 100 mm Spindle speed: up to 3500 rpm Axes: X-axis travel: 190 mm Z-axis travel: 400 mm Rapid traverse: X 18 m/min – Z 24 m/min Nwsdpfx Aovw Ahysa Ion Turret and tool holders: 12-position turret Internal/external tool holder 25x25 mm Boring bar holder Ø 32 mm Indexing time: 0.1 sec Driven tools up to 4000 rpm Motors and power: Spindle motor: AC 11/7.5 kW X-axis servomotor: 1.2 kW Z-axis servomotor: 1.8 kW Maximum absorbed power: 24 kW Dimensions and weight: Overall dimensions with chip pan: 2860 x 1700 x 1880 mm Net weight: 3400 kg Standard accessories: Right-side hinged belt chip conveyor 1 axial driven tool holder 1 radial driven tool holder 6 static tool holders (2 boring bar holders + 4 tool holders) Documentation included: Lathe operation manual Programming manual CE Declaration of Conformity As-new condition – machine available immediately.

Condition: new, Year of construction: 2023, functionality: fully functional, type of input current: three-phase, overall weight: 1,030 kg, rotational speed (max.): 2,500 rpm, turning diameter over cross slide: 320 mm, bar passage: 56 mm, spindle motor power: 3,700 W, mount diameter: 16 mm, spindle bore: 56 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 150 rpm, turning length: 750 mm, Equipment: rotational speed infinitely variable, Technical Specifications Center Distance 750 mm Center Height 160 mm Swing Diameter Over Bed 320 mm Swing Diameter Over Cross Slide 150 mm Bed Width 215 mm Spindle Bore 56 mm Spindle Mount A2-5 Speed Range, Continuously Variable 150 - 2500 rpm Nodswh Aiwspfx Aa Iown Travel X-Axis / Z-Axis 160 mm / 750 mm Rapid Traverse X-Axis / Z-Axis 4 / 7 m/min Number of Tool Positions 6 pcs. Tool Shank Dimensions 16 x 16 mm Positioning Accuracy ± 0.01 mm Quill Diameter 45 mm Quill Travel 100 mm Quill Mount MT 4 Motor Power 3.7 kW Machine dimensions (W x D x H) 1910 x 1150 x 1840 mm Weight approx. 1030 kg

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 07400000151, Axis:XYZCB (8-axis) Ø250 x 300mm Bar Feeder:Ø65 Tool:VDI30 / Tooth profile Control:SIEMENS 840D POWERLINE Dimensions: 2430x5600x2430mm Nwsdpfxjttm N No Aa Ion

Condition: used, Year of construction: 2008, SECOND-HAND 5-AXIS CNC WORKING CENTER BACCI MOD. TWIN - Strokes: x = 3400 Nodpfx Ajwrcn Isa Iown y = 1500 z = 850 b = endless c = 400° - Type 4 head 7.5 kw - 0-24.000 rpm - N. 2 tgv woriking tables - OSAI control - Enclosed cabin on 4 sides + roof - No. 2 Becker vacuum pumps 100 m³/h - Serial no. 477 - CE rules - Year 2008

Condition: used, Year of construction: 1999, Lathe with 4 tools only for 3-cylinder crank shaft Njdpfx Aaew Dufis Iswn *

Condition: used, Year of construction: 2000, SECOND-HAND 5 AXIS CNC WORKING CENTER BACCI MOD. TWIN - CE - Axis strokes: X 3400 mm Y 1800 mm Z 1250 mm B unlimited C 400° - Head Type 4 (7.5 kw cad.) - Max rotation speed 24,000 rpm - N. 2 variable geometry tables TGV - Vacuum pomp - Yaskawa drivers - Osai control Nwodpfxewrc Tde Aa Ion - Cabin on 4 sides + roof - Year 2000 - CE rules

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 1325.0458-14, controller manufacturer: Siemens, input frequency: 50 Hz, input current: 190 A, TECHNICAL DETAILS Electrical Operating voltage: 400 V Phases: 3 AC Frequency: 50 Hz Fusing: 250 A Rated current: 190 A EQUIPMENT Lathe with 4 tools, suitable only for 3-cylinder crankshaft Nedpfowx Hktox Aa Iown

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, turning length: 900 mm, turning diameter: 300 mm, spindle bore: 86 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 270 mm, controller model: FANUC 31i-B, TECHNICAL DETAILS Swing diameter over bed: 780 mm Swing diameter over slide: 700 mm Maximum turning diameter: 300 mm Maximum turning length: 900 mm Nsdsxltbcopfx Aa Iown Bar capacity: 76 mm Spindle Chuck size (main/sub-spindle): Ø254 mm Spindle bore (main/sub-spindle): Ø86 mm Spindle speed: 4,000 rpm Spindle motor (max./continuous): 26 / 15 kW Spindle drive: integrated motor Spindle flange: A2–8 C-axis indexing: 0.001° Travel axes X1/X2 axis: 270 / 190 mm Z1/Z2 axis: 920 mm Y axis: ±120 mm Rapid traverses Rapid traverse speed X/Y/Z axes: 24 / 24 / 24 m/min Rapid traverse speed ZB axis: 12 m/min Guideway system: Box Guide Turret Tool stations: 2 × 12 External tool size: Ø25 mm Internal tool size: Ø40 mm Indexing time: 0.2 s/step Turret system: Wedge type Driven tools Motor power (max./continuous): 5.5 / 2.2 kW Tool speed: 4,000 rpm Collet size: Ø20 ER32 Tool type: BMT65 MACHINE DETAILS Control: FANUC 31i-B Tank and supply system Coolant tank: 230 l Lubrication tank: 8 l Electrical data Power consumption: 69 kVA Line voltage: 220 / 400 V Dimensions & weight Dimensions (L × W x H): 3,670 × 2,170 x 2,601 mm Weight: 11,000 kg EQUIPMENT LNS bar feeder

Condition: ready for operation (used), Year of construction: 1984, functionality: fully functional, turning length: 600 mm, turning diameter: 400 mm, spindle bore: 73 mm, controller model: ELTRO MPULS, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Nedpfsxn I Sbjx Aa Iown Turning diameter: 400 mm Turning length: 600 mm Swing diameter: 600 mm Spindle bore: 73 mm MACHINE DETAILS Control model: ELTRO MPULS

Condition: ready for operation (used), Year of construction: 2000, operating hours: 12,013 h, functionality: fully functional, turning length: 580 mm, turning diameter: 100 mm, spindle speed (max.): 8,000 rpm, bar diameter (max.): 36 mm, TECHNICAL DETAILS Nsdpfx Ajxqpfbja Iewn Bar diameter: 36 mm Chuck diameter: 100 mm Turning length: 580 mm Swing diameter over bed: 145 mm Turning diameter: 100 mm Spindle speed: 2 x 25 - 8,000 rpm Sub-spindle: yes Indexing: 2 x C-axis, 0.001° degree Turret Number of turrets: 2 x 12-position VDI 25 Powered tool stations: 2 x 12 Tool rotation speed: 31 - 6,300 rpm MACHINE DETAILS Control: Sinumerik 840 D Total power requirement: 50 kVA Machine weight: approx. 6 t Space required: approx. 4.8 x 2.2 x 2 m Operating hours: 21,521 h Spindle hours: 12,013 h EQUIPMENT - SIMAG bar feeder 42.1, year of manufacture 2000

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 09095, spindle speed (max.): 5,000 rpm, travel distance X-axis: 190 mm, travel distance Z-axis: 550 mm, turning diameter over bed slide: 470 mm, center width: 305 mm, TECHNICAL DETAILS Turning diameter over bed: 470 mm Turning diameter over carriage: 310 mm Nodpjxrbriefx Aa Iswn Distance between centers: 305 mm X-axis travel: 190 mm Z-axis travel: 550 mm Spindle bore: 70 mm Max. spindle speed: 5,000 rpm Tool magazine: 12 positions MACHINE DETAILS Control model: Fanuc 18i-T Power: 15.0 kW Dimensions & Weight Dimensions (L x W x H): 3,700 x 1,600 x 2,200 mm Weight: 5,000 kg EQUIPMENT Driven tools Chip conveyor Turret head Documentation CE marking

Condition: used, Year of construction: 2015, TAKISAWA TS4000YS year 2015 CNC control FANUC 32i-MODEL B Max. turning diameter 315 [mm] Max. swing over bed 600 [mm] Max. Turning length 735 [mm] Stroke X axis 267 [mm] Stroke Z axis 840 [mm] Stroke Y axis -50 [mm] / +70 [mm] Stroke A axis 780 [mm] Rapid traverse rate X axis 30000 [mm/min] Nsdpfx Aowq Sf Tsa Ijwn Rapid traverse rate Z axis 30000 [mm/min] Rapid traverse rate Y axis 10000 [mm/min] Rapid traverse rate A axis 30000 [mm/min] Spindle nose A2-8" Max. bar diameter 82 [mm] Spindle throughbore 94 [mm] Max. spindle speed 4200 [rpm] Spindle power 22 [kW] Counter spindle nose F140 Counter spindle throughbore 53 [mm] Max. counter spindle speed 6000 [rpm] Counter spindle power 11 [kW] Max. tool holder cross-section 25 [mm] Number of tool stations 15 Number of tool stations driven 15 Max. speed driven tools 6000 [rpm] Lubrication tank capacity 370 [l] Total power required 37 [kVA] Supply voltage 400 [V] Chip conveyor with machine 5 live tool holders Weight 6700 [Kg]

Condition: ready for operation (used), Year of construction: 1985, functionality: fully functional, turning diameter over cross slide: 490 mm, spindle speed (max.): 2,800 rpm, turning diameter over bed slide: 720 mm, center width: 1,765 mm, controller model: EPL 4, Equipment: chip conveyor, TECHNICAL DETAILS Distance between centres: 1,765 mm Spindle bore: 101 mm Swing diameter over bed: 720 mm Swing diameter over cross slide: 490 mm Max. chuck diameter: 400 mm Speed range: 10 - 2,800 rpm Quill taper: MK 5 Tool holder type: 2 x VDI 50 MACHINE DETAILS Control: EPL 4 Drive power: 50 kW Approx. machine weight: 16 t EQUIPMENT Nwjdpfx Aexn Iyloa Ien Driven tools Tailstock Automatic quill travel Chip conveyor Automatic sliding safety doors Hydraulic steady rest 2 turrets
