Used Worm Grinding Machine for sale (84,285)

Year of construction: 2007, condition: ready for operation (used), travel distance X-axis: 350 mm, travel distance Z-axis: 1,750 mm, overall weight: 9,600 kg, number of axes: 4, General Data Machine weight 9600 kg Main Drive Number of axis 4 Movement X-Axis Movement 350 mm Z-Axis Movement 1750 mm This 4-axis Tacchella Proflex 3 cylindrical grinding machine was manufactured in 2007. It features a grinding length of 1200 mm, a max grinding diameter of 350 mm, and a total load capacity of 47 kW. The machine is equipped with a Siemens Sinumerik 840D control system, ensuring precise and efficient operations. If you are looking to get high-quality grinding capabilities, consider the Tacchella Proflex 3 machine we have for sale. Contact us for more information. Itjdpfxex H U Atj Aanor Application Types Grinding

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder -Manufacturer: Schwabe, double grinding wheel type EK4/4 -Grinding wheel: max. Ø 400 mm / Actual Ø 360 mm -Speed: 1400 rpm -Operating voltage: 380/660 volts -Motor power: 3 kW -Dimensions: 1320/930/H1450 mm -Weight: approx. 500 kg Iodpfx Aolmrkhjanotr

Condition: good (used), Code: 0427 Brand: ILMETECH Model: I 12 - 065 Automatic knife grinding machine for planer knives, knife blades and rectilinear tools - CE Standard Technical data: Suitable for grinding of HSS steel as well as carbide tools used in the woodworking, paper, leather, plastics, metal and food sectors Max working length mm 650 Tilting grinding motor unit Grinding wheel motor power kW 1,15 Grinding wheel external diameter mm 125 Iedpfx Aeu H Apyoanstr Grinding wheel feed per stroke mm 0-0,05 Two-speed carriage feed mt/min 6/12 Coolant pump capacity lt/min 0-30 Overall dimensions mm 1450 x 550 x 1300 h Weight kg 186

Condition: excellent (used), Year of construction: 1980, Grinding length: 600 mm Grinding width: 200 mm Clamping area of table: 600 x 200 mm Maximum distance between table and grinding spindle center: 500 mm Grinding wheel dimensions: 250 x 25 x 51 mm Itodsx Ir I Aepfx Aanjr Table longitudinal feed hydraulically steplessly adjustable: 1 - 24 m/min Table cross feed per handwheel revolution: 4 mm Grinding spindle speed steplessly adjustable via DC drive: 800 - 4200 rpm DC drive: 1.5 - 5.0 kW Net weight with control cabinet approx.: 2000 kg Space requirement approx.: 3100 x 1700 x 1900 mm

Condition: ready for operation (used), Tool grinder, tool sharpener, drill sharpener, Schanbacher S3-50 Manufacturer: Schanbacher Type: S3-50 Year: 2012 Dimensions: 460 × 600 × 1260 mm Drill diameter: 3–50 mm; Point angle: 90°–140° Ijdpfx Ajx Dbltjanjtr Includes: Protective cover, dust extraction system

Condition: used, grinding length 12000 mm grinding width 2800 mm Itjdowa Dxwepfx Aanor workpiece height 2510 mm control Siemens 840 D workpiece weight 24000 kg column daylight 2820 mm table surface area 11990 x 2500 mm table feed 1 - 40 m/min cross rail - adjustment 2510 mm total power requirement 110 kW dimensions of the machine ca. 32,5 x 9 x 6,73 m weight of the machine ca. 151 t Equipment/Accessories: - 1 universal grinding support, 22 kW swivel range of grinding spindle +/- 110° grinding wheel dimensions Ø 700 x 130 mm vertical adjustment 1000 mm with puller - 1 peripheral grinding support, 30 kW grinding wheel dimension Ø 600 x 150 mm vertical adjustment 230 mm with puller - Coolant and filter unit - Various grinding wheels and flanges - Technical documentation

Condition: used, Year of construction: 2012, workpiece . workpiece diameter 15 -70 mm swing diameter max. 150 mm Itsdsx H Andjpfx Aanor clamping length max. 500 mm Swing over bezel area 70 mm dimension 150 x 300 mm max. turning speeds 250 min/-1 longitudinal adjustment manuell über Kettenrad Fixed tip MK 4 (Junker D75 mm) clamping capacity ü. Hydraulik einstellbar travel -z axis max. 1000 mm feed z - Achse (CNC gesteuert) dimension D 205 x 450 mm flange diameter D 190 mm standards association D 127 mm drive 30 kW speed control mit Frequenz- Umformer max. turning speeds 4400 min/-1 type Borazon (CBN) o. Diamant mm diameter 450 mm bore D 127 mm peripheral speed max. 90 m/sec type GR-3520-NR mm diameter range D 20 - D 35 mm dimension D 80 x 250 mm flange D 100 standards association D 75 drive 1,8 kW max. turning speeds 24000 min/-1 weight of the machine ca. 7,0 t In our opinion, the machine is in good condition and can be inspected under power by appointment. There are 2 identical machines available. Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well as Subject to prior sale!

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder -Motor power: 1.35 kW -Speed: 1500 rpm Itjdpfx Aaob A Id Hsnjr -Grinding discs: Ø 300 x 40 mm -Operating voltage: 380 volts

Condition: used, MONNIER + ZAHNER MZ 130 is a Worm gear cutting machine designed for high precision, excellent accuracy and reliable performance. Capacities: workpiece diameter 2–55 mm; module max. 1.5/2.0 mm; workpiece length max. 300 mm; max. cutting length 230 mm; cutter diameter 16–40 / 53–100 mm; max. cutter travel 60 mm; swivel head +/-45°; axes X70 Y30 Z250 mm. Key specs: milling spindle speed max. 8000 t/min; workpiece spindle speed 950 t/min; collet attachment 25 W; voltage 50 Hz 3x400 V; machine weight ≈3500 kg; overall L2200 x W1800 x H1850 mm. Delivers tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical sectors. Itedpfox Iudgox Aaner

Year of construction: 2015, condition: ready for operation (used), Main Drive Itodpox D Swaefx Aanjr Number of axis 2 This PALMARY GU32x60S cylindrical grinding machine was manufactured in 2015. It features a swivel over table of Ø320 mm and a distance between centers of 600 mm, allowing for a max external grinding diameter of Ø300 mm. With a grinding wheel speed of 45 M/s and a spindle speed up to 300 r.p.m., this machine is ideal for precision work. If you are looking to get high-quality grinding capabilities, consider the PALMARY GU32x60S machine we have for sale. Contact us for more information. Application Types Grinding

Condition: used, Year of construction: 2001, Technical details: grinding diameter max.: 3-220 mm regulating wheel width: 400 mm max. width of grinding wheel: 400 mm grinding motor: 55 kW Isdpfx Aajttxg Ienetr peripheral speed: max. 45 m/sec regulating wheel dimensions: 350 x 400 x 203 mm dimensions of grinding wheel: CBN 500 x 400 x 304 mm grinding wheel size: KORUND 600 x 400 x 304 mm total power requirement: 75 kVA weight of the machine ca.: 13 t. dimensions of the machine ca.: 4,47 x 2,77 x 2,49 m. Centerless Grindign Machine JUNKER JUPITER 500 CNC SIEMENS in good condition. Including: · 2 robots Kuka KR 16 Year 2007 · CNC loading and unloading device Promot EPL60NC Year 2007 The machine was lately used for grinding of guide bushes (through grinding). Plunge is possible. JUPITER's Centerless grinding, also available with CBN. Junker this circular grinding method with CBN grinding wheels, which opens up significant productivity benefits from the long service life of the grinding wheel, especially at high volumes. In addition, the simultaneous removal takes on the entire Schleswig-Holstein, which provides both in mass production and in small batches for significantly reduced processing times. The grinding process with JUPITER When centerless grinding, there are two grinding processes: the through grinding and plunge. Both methods are possible with the JUPITER. Applications through grinding: Pin and Bushings Body, rings, smaller rings, piston parts (eg compressors), waves with constant diameter piston rods (eg shock), Small piston for hydraulic and fuel injection, precision wires and rods, piston pins. Applications Plunge: Rotor shafts, transmission parts, bearing surfaces of camshafts, tube and pipe fittings for composite camshafts, universal joints, parts for needle injection, valve stems, barrel rolls. *

Condition: used, grinding length 4000 mm grinding width 1450 mm workpiece height 1250 mm control Siemens 840 D workpiece weight 11000 kg column daylight 1460 mm Iedpowa Dx Dofx Aanjtr table surface area 4000 x 1250 mm table feed 1 - 45 m/min cross rail - adjustment 1250 mm total power requirement 40 kW dimensions of the machine ca. 12,3 x 6 x 4,8 m Equipment/Accessories: - 1 universal grinding support, 7.5 kW Swivel range grinding spindle +/- 110° grinding disc dimensions Ø 500 x 60 mm Vertical adjustment 350 mm with puller - 1 peripheral grinding support, 22.5 kW Grinding wheel dimension Ø 600 x 100 mm Vertical adjustment 150 mm with puller - with 6 magnetic plates arranged on the table - seperate clamping table - various grinding wheels and flanges - Technical documentation

Condition: excellent (used), functionality: fully functional, center height: 180 mm, grinding length: 500 mm, grinding wheel diameter: 410 mm, grinding wheel width: 40 mm, spindle speed (max.): 1,500 rpm, INTERNAL/EXTERNAL GRINDING MACHINE RIBON CENTER HEIGHT: 180 mm Isdpfx Aox H Ip Teanstr CENTER DISTANCE: 500 mm MAX. GRINDABLE DIAMETER: 360 mm

Condition: good (used), Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder -Motor power: 3 kW -Grinding discs: Ø 400 mm -Operating voltage: 380 volts -Weight: 200 kg Itedpjb A If Tsfx Aanjr

Condition: good (used), Year of construction: 2000, Ref. -No.: 10609 Manufacturer: GLEASON - PFAUTER Type: P 2400 G Year of construction: 2000 Type of control: CNC Control: Siemens 840 D Storage location: Halberstadt Country of origin: Germany Machine length: 1100 mm Machine width: 6585 mm Iedpfx Aasx Hn Ehjnotr Machine Height: 5200 mm Max. Workpiece Diameter: 2640 mm Weight Of The Machine Ca.: 23 t Grinding Wheel Diameter: 400 mm Spindle Speeds (Infinitely Variable): 600 bis 6000 mm Grinding Wheel Width: 80 mm X-Axis: 1200 mm Y-Axis: 300 mm Z-Axis: 1000 mm Z2 - axis: 150 mm Sandable profile depth: 80 mm Workpiece table: 0 bis 5 1 / min Feed rate X-axis: 3000 mm Feed rate Y-axis: 5000 mm Z-axis feed rate: 6000 mm Further information: - Fully automatic centering device - Oil mist separation - Gear tooth measurement - “Profile grinding” software package - Error diagnosis - IFK2 internal milling head - Milling mandrel with spacer discs - Chip conveyor - Oil mist extraction - Technical documentation

Year of construction: 2020, condition: ready for operation (used), Additional Equipment ELBARON grinding mist extraction system / Robot pallets / Collets for all common diameters up to 20 mm / Spare spindle / Sanding wheel packs and associated sanding wheels (Approx. 25 pieces) This 5-axis TGT V2 Maxima was manufactured in 2020 and is in mint condition. It features an ELBARON grinding mist extraction system and includes collets for diameters up to 20 mm. Extras include robot pallets, spare spindle, and sanding wheel packs. Consider the opportunity to buy this TGT V2 Maxima. Contact us for more information. Iodpsx D Hi Rsfx Aanotr Application Types Grinding

Condition: used, Year of construction: 2015, thread dia. 20 - 80 mm grinding length 3500 mm thread pitch . mm threading lenght min./max. 50/3500 mm centre height 400 mm workpiece length - max. 4000 mm control Siemens 840-Dsl Itedpfx Asw Ed S Ueanor feed speed u-axis 0 - 2500 mm/min feed speed w-axis 0 - 2500 mm/min feed speed b-axis 100 1/min total power requirement 45 kW weight of the machine ca. 24 t dimensions of the machine ca. 10,7 x 4,6 x 2,9 m Thread Grinding Machine / Profile Grinding Machine, suitable for: - the thread grinding of single and multi-start ball screws with gothic profiles and special profiles - Ø 20 to 80 mm with a grinding wheel Ø of 350 to 500 mm - length between the centers up to max. 4000 mm Equipment / Accessories: - grinding spindle: - capacity 14 kW - with a grinding wheel diameter range of 350-500 mm, cutting speeds between 20 and 75 m/s can be set. - grinding wheels: - diameter new 500 mm - diameter worn 350 mm - bore diameter 203.2 mm - shaped diamond roll: - diameter 121.3 mm - radius 0.5 mm - driver flange for workpiece diameter 15-70 mm - driver: - for 10-32 mm drive diameter on the workpiece - for 31-60 mm drive diameter on the workpiece - for 60-105 mm drive diameter on the workpiece

Condition: good (used), Year of construction: 1975, Double bench grinder, double grinding machine, pedestal grinder, pedestal grinder Itjdpfx Aeb A I T Ijaner -Motor power: 1.1 kW -Speed: 1745 rpm -Grinding discs: max. Ø 315 mm -Operating voltage: 380 volts -Weight: 230 kg

Condition: used, Year of construction: 2008, tip circle diameter 650/800 mm workpiece length - max. 1100 mm max. module 20 (25) mm min. module 0,5 mm control Siemens Sinumerik 840 D Itedpfx Aow Rrbyjaner total connected load 62 kVA helical angle -45 / + 120 ° weight of the machine ca. 10 t

Condition: used, Year of construction: 2006, grinding diameter - cylindrical max. 650 mm grinding diameter - internal max. 600 mm control Siemens Sinumerik 840 D internal grinding depth max. 600 mm External grinding length max. 600 mm workpiece length - max. 380 mm turning speed range - stepless 1-795 U/min Workpiece spindle unit (U/B1/L adjustment): -Travel (U axis) 300 mm -Swivel angle (B1 axis) -1°/+12° -Speed range (infinitely variable) 1-795 rpm -Setup speed (tapping) 10 rpm -Spindle head size A 8 according to DIN 55026 -Through bore 58.5 mm -Workpiece diameter max. 830 mm -Workpiece length max. 600 mm -Load capacity at spindle head max. 6100 N Itodpfxew Rf Tvs Aanor Internal grinding device (Z1/X1/B2): -Travel (Z1 axis) 800 mm -Travel (X1 axis) 150 mm -Swivel angle (B2 axis) 270° -Drive power of internal grinding spindles (infinitely variable) 7.5 kW -Grinding block mounting bore (diameter) 100 mm -Grinding block mounting length (diameter) 100 mm -Grinding diameter max. 600 mm -Grinding depth max. 860 mm -Manual longitudinal adjustment of internal grinding axis on table 530 mm External and surface grinding device (Z2/X2): -Travel (Z2 axis) 800 mm -Travel (X2 axis) 470 mm -Drive power of external grinding spindles 5.5 kW -Mounting bore grinding block Ø 120 mm -Grinding diameter max. 650 mm -Grinding length max. 600 mm -Grinding wheel diameter max. 500 mm Equipment/accessories: -Various grinding spindles -Various flanges/grinding wheel holders -Various clamping jaws -Coolant system -Oil mist filter -Cooler -Technical documentation

Condition: used, Year of construction: 1983, grinding length 8400 mm grinding width 1450 mm workpiece height 1250 mm surface area 8000 x 1250 mm table height over floor 920 mm distance between columns 1470 mm workpiece weight max. 59700 kg weight of the machine ca. 59,7 t dimensions of the machine ca. 22 x 5 x 5 m Adjustment ranges: -Crossbeam, vertical 1250 mm -Grinding support, horizontal 3100 mm Isdpovr Hgvefx Aanstr Adjustment speeds: -Machine table (X-axis) infinitely variable 1-45 m/min Table creep speed 5 m/min -Grinding support, horizontal (Y-axis) Rapid traverse 3000 mm/min Feed, step 0.001-0.099 mm Feed rate, continuous 100-3000 mm/min Creep speed 18+1 mm/min Tip infeed 0.001-0.019 mm -Crossbeam (W-axis) Rapid traverse 410 mm/min Table drive: -Oil transmission, Type Iv4 -Cylinder-Ø 185 mm -Piston rod Ø 130 mm -Drive motor 22 kW

Condition: used, Year of construction: 2007, max. workpiece diameter 800 mm Itsdpfx Aaew Rrckenor profile depth 100 mm control Siemens Sinumerik 840 D x-travel 650 mm y-travel 300 mm z-travel 1300 mm spindle turning speed - stepless 400 - 4000 U/min table turning speeds 0 - 10 U/min total power requirement 110 kVa dimensions of the machine ca. 9,48 x 6,13 x 5,00 m weight of the machine ca. 24,5 t Tool: - Largest grinding wheel diameter 450 mm - Largest grinding wheel width 160 mm Feed rates: - X-axis 1 to 3000 mm/min - Y-axis 1 to 5000 mm/min - Z-axis 1 to 6000 mm/min Equipment/accessories: - Counterholder - Grinding oil treatment system - Oil mist extraction - Measuring probe - Dresser - Technical documentation

Condition: used, Year of construction: 2001, grinding length 4200 mm Isdpjthumuefx Aanetr grinding width 1300 mm workpiece height 550 mm Control Siemens 840D passage width 1300 mm electro-magnetic table 4200 x 1300 mm grinding height 550 mm grinding motor 306 kW grinding motor turning speeds up to 370 U/min grinding motor feed, infinitely variable 0,5-35 m/min coolant flow rate 2000 l/min weight of the machine ca. 50 t dimensions of the machine ca. 11,21 x 5,25 x 3,85 m Equipment / Accessories: - segment head - diameter 1400 mm - for segment dimensions 120/106 x 41 x 250 mm - number of segments: 1 set = 26 pieces - grinding motor adjustment - in steps: 0,002 - 1 mm - continuous: up to 5 mm/min stepless

Condition: used, Year of construction: 2001, tip circle diameter 1000 mm root circle diameter 50 mm max. module 18 mm min. module 1 mm Itedpfx Aewp S Thjanjr max. wheel diameter 1000 mm gear width 630 mm Profile height max. 41 mm helical angle (left/right) max. 45 ° table diameter 720 mm max. table load 1500 kg grinding wheel diam. min/max. 180 / 400 mm grinding wheel width 60 (45/30) mm grinding spindle speed 0 - 3100 U/min total connected load 30 kVa

Condition: used, Year of construction: 2009, internal diameter max. 600 mm grinding depth max. 800 mm grinding length max. 600 mm control Siemens 840 D grinding diameter - internal max. 600 mm grinding diameter - cylindrical max. 800 mm workpiece length - max. 380 mm external grinding length max. 600 mm travel - x1 axis 150 mm travel - z1 axis 1100 mm travel - x2 axis 470 mm travel - z2 axis 800 mm workpiece spindle 8,5 kW turning speed range - stepless 1-795 U/min Equipment / Accessories: Workpiece spindle unit (U/B1/L adjustment): - Travel (U-axis): 300 mm - Swivel angle (B1 axis): -0,5°/+12° - Drive power of the workpiece spindle: 8.5 kW - Speed range (infinitely variable): 1-795 rpm - Set-up speed (jogging): 10 rpm - Spindle head size A 8 according to DIN 55026 Itsdswp S Tnepfx Aaner - Through-hole 58.5 mm - Workpiece diameter max. 830 mm - Workpiece length (overhung clamping) max. 800 mm - Workpiece length (clamped between centers) max. 800 mm - Load capacity at spindle head max. 6100 N Internal grinding device (Z1/X1/B2): - Travel (Z1 axis): 1100 mm - Travel (X1 axis): 150 mm - Swivel angle (B2 axis): 270° - Manual longitudinal adjustment of internal grinding axis on table: 780 mm - Drive power of the internal grinding spindles (infinitely variable) Belt-driven grinding spindles: 7.5 kW - Grinding block mounting hole (diameter): 100 mm / 125 mm - Mounting length of sanding block: 220 mm - Sanding diameter: max. 600 mm - Sanding depth: max. 800 mm External and surface sanding device (Z2/X2): - Travel (Z2 axis): 800 mm - Travel distance (X2 axis): 470 mm - Swivel angle (B2 axis): 270° - Drive power of the external grinding spindles: 7.5 kW - Grinding block mounting hole: Ø 140 mm - Sanding diameter: max. 800 mm - Sanding length max. 600 mm - Grinding wheel dimensions: max. Ø 450 x 50 x Ø 127 mm
