Eccentric Press - Single Column

WEINGARTEN NR 80

Condition: new, TC 165 x 750V Illustration shows MIOTAL® TC 180 x 1000 Center distance: 750 mm Center height: 165 mm Swing diameter over bed: Ø 330 mm Bed width: 190 mm Cross slide travel: 160 mm Top slide travel: 90 mm Spindle connection: DIN 55029 (Camlock) D 1 - 4 Spindle bore: Ø 40 mm Max. Chuck diameter: Ø 200 mm Spindle speed, infinitely variable: 30 - 2000 1/min Mechanical feed stages: 3 Motor power: 2.2 kW Longitudinal feeds Z: (40) 0.044 - 1.96 mm/rev Face feeds X: (40) 0.022 - 0.98 mm/rev Metric thread: (32) 0.4 - 7.0 mm Thread inch: (32) 4 - 56 Gg/inch Thread module: (32) 0.4 - 7.0 Diametral thread: (32) 7.5 - 112 Quill diameter tailstock: Ø 40 mm Inner taper of quill tailstock: MK 3 Quill stroke: 100 mm Lateral adjustment: ± 10 mm Weight, approx.: 650 kg Features: - Acceptance protocol according to DIN - Precise, hardened and ground guides - Robust headstock with recirculating oil lubrication, precision bearing-mounted spindle, hardened and ground gears for long-lasting quality - Electromagnetic spindle brake (TC), frequency converter with electric braking device (V models) Gedpfx Aboir Igwjheip - Torsion-resistant machine beds made of MEEHANITE quality casting, stress-free annealed and multi-ribbed for extremely smooth running - Electrical equipment from SIEMENS/SCHNEIDER - Overload protection for feed gearbox - Pulse button for main spindle - CE / IEC as well as German documentation and German service Basic equipment (standard accessories): - Machine stand with splash guard rear panel - 3-jaw lathe chuck - 4-fold steel holder - Foot pedal with mech. brake device - Coolant device - Chuck guard and spindle cover in accordance with European safety standards CE - 1 Fixed center point for main spindle - 1 Fixed center point MK3 - 1 Test report - Safety devices and electrical equipment according to CE - Reducing sleeve for main spindle Operating tool Available options for this lathe: - 3-axis digital readout - Quick-change holder system Multifix also available as a gearbox version

Condition: refurbished (used), Pressure: 150t Length of Stroke: 140mm Table size: 510x530mm Gisdpfxogd H Tpo Abhep

Year of construction: 1972, condition: used, machine/vehicle number: 51512/72, pression: 75 t throat: 300 mm table size: 620 x 800 mm clearance hole in the die: 225 x 325 mm table adjustment: 175 mm tappet area: 180 x 475 mm tappet adjustment: 80 mm stroke adjustment: 16 - 140 mm number of strokes: 90 /min engine: 380 V, 3 kW space needed: 1700 x 1200 x 2500 mm Giodpfxjb Tdqus Abhop weight: 3,3 t

Condition: used, Year of construction: 2021, functionality: fully functional, machine/vehicle number: TET351P5-offAD-Bypass - 2200373733, cooling capacity: 66 kW (89.73 HP), type of input current: three-phase, type of cooling: water, overall weight: 1,082 kg, ambient temperature (max.): 46 °C, ambient temperature (min.): -5 °C, input voltage: 400 V, pressure: 6 bar, temperature: 7 °C, volume flow: 11.2 m³/h, pump pressure: 4.68 bar, total width: 866 mm, total length: 2,250 mm, total height: 2,054 mm, warranty duration: 3 months, input frequency: 50 Hz, Equipment: type plate available, Process chiller / air-cooled water chiller, Type: TAEevo Tech 351 P5-offAD-Bypass MTA S.p.A. Chiller, water chiller; cooler TAEevo Tech 351 P5-offAD-Bypass are air-cooled compact water chillers suitable for outdoor installation down to -5°C. Includes crankcase heater, electronic expansion valves, phase monitoring, 350-liter buffer tank, and integrated P5 high-pressure pump. Special features: Gedpfjwlt Rajx Abheip - Open fill system / attached tank - Bypass with manual valve between water inlet and outlet Chilled water outlet temperatures adjustable from -10°C to +30°C. Cooling capacity: 66 kW Chilled water temperature outlet/inlet (°C): 7 / 12 Flow rate (m³/h): 11.2 Available pump pressure (bar): 4.68 Ambient temperature (°C): 32 Refrigerant: R 410A Electrical data: Voltage (V): 400, Frequency (Hz): 50, Phases: 3 Max. power consumption (kW): 39 Max. current (A): 68 Start-up current circuit (A): 213 Protection class: IP54 Dimensions: Length (mm): 2250, Width (mm): 866, Height (mm): 2054 Weight (kg): 1082 Connection: Rp 2" Serial no.: 2200373733 Year of manufacture: 2021 Condition: Visual 2, Technical OK used (Subject to technical changes and prior sale!) Location: MTA Deutschland GmbH, 88131 Lindau Used machines may have visual imperfections due to their usage. (Subject to technical changes and prior sale!)

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: 25.12.15, Fresan FP 100P - C Frame Eccentric Press - 100 Tons (1000kN) TECHNICAL DATA: * Power: 100 tons (1000kN) * Strokes Per minute: 60 (variable) * Ram-Table Distance: 445 mm * Stroke Adjustment: 0 - 132 mm * Ram Adjustment: 95 mm (motorized) * Table Dimensions: 700 x 1000 mm STANDARD SPECIFICATIONS: * Conformity to CE safety regulations * Welded steel frame * Crankshaft made of AISI 4140 (42CrMo4) alloy steel. Highly durable and ductile. CNC ground for minimum surface friction. * SnBz-12 quality bronze bearings * Pneumatic clutch-brake combination * Fully closed gearbox with helical gears working in oil * Double body press safety valve * Safety PLC & light curtains & safety switches (Pilz) * Ram with 6 slides & waste oil collector * 7-inch HMI touchscreen operator panel * Speed control with AC inverter * Motorized ram adjustment * Mechanical fuse for overload protection (Hydraulic fuse can be installed on standard a machine after purchase) * Pneumatic counterbalance cylinders (ISO, 4 pcs) * Automatic central lubrication & used oil collectors (Thin oil / slideways oil) Gsdpsnxh T Rjfx Abhsip OPTIONAL EQUIPMENT: * Additional work table * Part ejector mechanisms(upper and/or lower ejectors) * Material feeding, loading & unloading systems (Decoilers, straighteners, pneumatic & servo feeders...) * Special design / customized machine

Year of construction: 2024, condition: new, Make: DURMA Type: MS 2504 year of manufacture: 2022 cutting length: 2550 mm sheet thickness: 4 mm Control: EZM9910 Operating hours: 0 Cutting angle: 1°30 Strokes per min.: 42 motor power: 7,5 kW Gjdpfed R Er Dex Abheip backgauge range: 750 mm table width: 450 mm table height: 800 mm dimensions L/W/H: 3200x2300x1350 mm Weight: 3780 kg Standard equipment control unit EZM9910 backgauge range 750 mm programmable via control unit Jvcmke Plastic inserts for hold-down 1 side stop and 2 sheet support arms Finger guard Portable foot switch with emergency stop Spring loaded stop in T-slot of the support arms Ball screw Ikh7877 Table plates with ball rollers Upper knife with 2 cutting edges Lower knife with 4 cutting edges CE marking Extended equipment Adjustable angular fence 0-180 The machine can be inspected and demonstrated at any time by appointment in our demonstration center in Staufenberg. Further machines are ready for demonstration at our facility in Staufenberg. We will be happy to provide you with further information on request.

Condition: ready for operation (used), Year of construction: 2001, operating hours: 19,853 h, functionality: fully functional, machine/vehicle number: 11170000963, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 5-axis simultaneous Speed 18000 Tool changer 60 pieces / SK 40 DIN69871 Gsdjwqp Huopfx Abhoip Tools included in the price ICS / air blast Heidenhain 426/430

Condition: new, shaft diameter: 80 mm, - Ring bending machine - Shaft diameter 80 mm - The two lower rollers are moved hydraulically - Three rollers are driven - Two digital displays - Brake motor - Can be used horizontally/vertically - Mobile control panel - Emergency stop Gedpeucqqujfx Abhsip - Documentation - 400 V

Condition: used, Year of construction: 1990, Technical details: tube diameter: 42 mm wall strength: 25 mm round bar steel: max. Ø 20 mm square material: Rohr 25 x 25 mm bending radius max.: innen max: Ø 20 und außen max: Ø 170 mm bending speed: keine Angaben °/s tube pipe draw up length: 3000 mm control: Software RC 7000 weight of the machine ca.: 2,8 t dimensions electric cabinet: 800 x 700 x 2000 mm dimension machine xH: 5,1 x 0,7 x 2,0 m Application: Machining of deformable tubes, rectangular tubes and round bars and square tubes. Description of the software RC7000, programming manual rectangular tube 42 x 20 x 2,5mm bending direction to the left Operation via control panel with monitor Accessories: -div. bending tools for tube Ø 25mm -12 div. collets Gedpfx Aou Ibvusbhsip -div. auxiliary and clamping devices *

Condition: new, Year of construction: 2023, pipe drilling machine, inclined drilling machine, automatic drilling machine TDM100, manual, with one drilling head IMMEDIATELY AVAILABLE FROM STOCK + TO BE INSPECTED UNDER POWER - minimum quantity lubrication - manual material clamping - manual feed - max. tube length 3.000mm (option 6.000mm) - positioning accuracy +/- 0,2mm - 10 stops (can be extended as required) - manual insertion and removal of material - drill head swivels +/- 50 - manual 360 degree tube swiveling device - power drilling unit 1 x 2,2 kW - motor speed 295 - 2950 rpm - display speed on touch panel - illumination drilling unit - integrated tool cabinet - round tube up to 114mm - square up to 100 x 100mm - flat material up to 100 x 15mm - T-profile up to 100 x 100 x 12mm Godpfxelgvkio Abhsip - L-profile up to 100 x 100 x 8mm - Double post up to 100 x 15mm - Flow drilling up to M12 - Drilling up to Ø 50mm
