Used Structural Steel Machinery Ltd

Condition: good (used), Year of construction: 2012, Vernet Behringer HD-X 918 / HBP 410/923 CNC Sawing / Drilling Line – Year 2012. Nslhsvzhlxjcdwvewd 3 Spindle. Automatic tool changer. Gripper Feed measuring system. Infeed and outfeed Cross Transfers.

Year of construction: 2007, Condition: good (used), PEDDINGHAUS FDB1500. YEAR OF MANUFACTURE 2007. 1500mm CAPACITY X 6000mm. PLASMA / OXY FUEL / DRILLING. HYPERTHERM HPR 260 SOURCE. Specification attached. Peddinghaus FDB 1500 plate processing machine for drilling and flame cutting. NC control Siemens Sinumerik 810. Machining dimensions: machining width from 80 to 1500 mm, sheet thickness from 6 - 50 mm, material length as a base up to 6000 mm, (the length is very easy to extend because of the roller measuring system), the infeed roller table and outfeed roller table are included respectively. Drill diameter: min. ø 8, up to max. ø 40 mm suitable for HSS coolant channel drill (cooling by the drill spindle), Njlsvzg U Ejhcdwvjwd The FDB 1500 is equipped with an oxyfuel flame cutting unit. An exhaust system is integrated below the torch box. A filter unit is available.

Condition: good (used), Year of construction: 2005, 500mm x 25mm Capacity. Nwolhovzg Uxjcdwvsd Punching / Shearing / Marking capacity. Mitre shearing.

Condition: good (used), Year of construction: 2000, Drilling machine: KD1215 Vertical (Y-Axis): 1 Unit Horizontal (Z & W-Axis): 2 Unit 3-Axis Drilling with Automatic Tool Changer (5 Tool Change positions per axis) Drilling Diameter: 5/16" to 1-9/16" (8 - 40 mm) Sawing machine Model: HDM 1431. Disc saw. Hydraulic horizontal clamping device. Mitre cutting device to adjust the angle from 45° to the left to 35° to the right. Material sensor. Hydraulically elevating feed roller. Specifications: Cutting disc diameter: 1,430mm Cutting width: 9.5mm Total power: 25KW Working height: 640mm Cutting capacities: 90º cut Angle steel: 250mm Steel in U: 400mm. Wide flanged beam: 1008x302mm. Nslhcdovrqvhjwvswd Special beams: 1000x450mm

Condition: good (used), Year of construction: 2017, V304 plate processing machine (including 1 gantry beam(s) of 6.500mm and side trucks) ◼ This V304 plate processing machine is capable of processing plates up to 3.050mm x 18.000mm for bevel plasma cutting and marking (needle marker, if attached) and 4.100 x 18.000 mm for oxy-fuel cutting and marking (needle marker, if attached) ◼ X-rail (21.000mm on both sides of the machine, including double linear guides, helical rack and pinion system and rubber covering band) ◼ Plasma cutting and extraction table (4.300mm x 18.720mm, 2 channel(s), 1 pcs, suitable for ≥ 350A cutting) ◼ Position 1: Plasma cutting unit Kjellberg SmartFocus400 (1 pcs, automatic gas console, complete with cutting parameter database) ◼ Plasma 3D bevel unit (1 pcs, including 5 NC-axis, Voortman height control, intelligent torch positioning system and 3D collision sensor, for x- ,y- , k- and v-weld preparations) ◼ Driven suspension (1 pcs, servo motor driven, including laser pointer) ◼ Dross inhibitor (1 pcs, including 1,2L reservoir) ◼ Arc Glare protection (1 pcs) ◼ Position 2: Plasma cutting unit Kjellberg SmartFocus400 (1 pcs, automatic gas console, complete with cutting parameter database) ◼ Plasma 3D bevel unit (1 pcs, including 5 NC-axis, Voortman height control, intelligent torch positioning system and 3D collision sensor, for x- ,y- , k- and v-weld preparations) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Dross inhibitor (1 pcs, including 1,2L reservoir) ◼ Arc Glare protection (1 pcs) Njlhcjvpalaodwvewd ◼ Position 3: Oxy-fuel cutting torch 4.0 (1 pcs, automatic gas console, ignition and piercing, complete with cutting parameter database) ◼ Voortman height control (1 pcs, capacitive height control) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Position 4: Oxy-fuel cutting torch 4.0 (1 pcs, automatic gas console, ignition and piercing, complete with cutting parameter database) ◼ Voortman height control (1 pcs, capacitive height control) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Position 5: Oxy-fuel cutting torch 4.0 (1 pcs, automatic gas console, ignition and piercing, complete with cutting parameter database) ◼ Voortman height control (1 pcs, capacitive height control) ◼ Dragged suspension (1 pcs, with automatic addressing) ◼ Cables high instead of low ◼ Donaldson fume extraction unit DFO 4-48 - 200L (incl. frequency controller) ◼ Air conditioning for switch panel (up to an ambient air temperature of 55°C) ◼ Hardware and software (includes VACAM ‘Machine Edition’, VACAM ‘Office Edition’, VACAD editor software module, VANEST nesting software, Layout marking software module, online support) ◼ Post processor for SigmaNEST (SigmaNEST is provided by the customer) ◼ Safety devices (safety bumpers, emergency stop cord)

Condition: good (used), Year of construction: 2012, ■ BCS Thermo 2000 Plate cutting machine (operating range 2.000 x 6.000 mm) ■ Gantry beam (length 3.500mm) ■ Machine track (8m on both sides of the machine) ■ Plasma cutting and extraction table (2.000 x 6.000 mm, 1 pcs) ■ Plasma cutting unit Hypertherm HPR260XD (1 pcs) o IHT M4000 PCS automatic height control o Driven suspension (motor driven, including laser pointer) ■ Oxy-fuel cutting unit (1 pcs) o IHT M4000 CAP automatic height control o Driven suspension (motor driven) ■ Fume extraction unit Filtercube 4H ■ Hardware and software (including VACAM ‘Machine Edition’) ■ Safety devices (emergency stop cord) Nwslhcovpagqjdwvod Plasma cutting unit HPR260XD Material Mild steel Max. thickness 64 mm Max. pierce capacity 38 mm Dross-free cutting max. 32 mm Marking Yes, with same consumables Plasma gas mild steel Cutting O2 (99,9% pure clean, dry, oil-free) Marking Argon gas Shield gas mild steel O2 / Air (99,9% pure clean, dry, oil-free) Automatic gas console Yes Cutting speed 6 mm Approx. 4.035 mm / min 130A 12 mm Approx. 3.060 mm / min 200A 25 mm Approx. 1.660 mm / min 260A 38 mm Approx. 890 mm / min 260A 50 mm Approx. 590 mm / min 260A 64 mm Approx. 195 mm / min 260A * Grounding max. 6 m of machine: AC power, PE and service grounds must be connected to all equipment according to local and national codes. Oxy-fuel cutting unit Type GCE Fit+ Ignition Automatically Max. thickness 200 mm Gas Propane Optional gas Acetylene Cutting gas O2

Condition: good (used), Year of construction: 2016, Transfer roller conveyor (length 6m, width 2.500mm, roll diameter 159mm, roll distance 800mm, line load 750kg/m, spread load 1.500kg/m) ◼ Infeed roller conveyor (length 6m, width 2.050mm, roll diameter 159mm, roll distance 800mm, capacity 1.250kg/m) ◼ Hydraulic pushers for 6m infeed roller conveyor (3 pcs, integrated in the infeed roller conveyor) ◼ V320-2000 plate processing system (base frame with vertical drilling unit, automatic tool changer, swarf brush, oxy-fuel cutting unit, automatic discharge table and product conveyor belt) ◼ Feeder trucks (servo driven, master truck with 3 hydraulic clamps, support truck with 2 hydraulic clamps) ◼ Lifting device for feeder truck (including motor drive for infeed conveyor) ◼ Plasma cutting unit HPR260XD (including automatic height control system IHT M4000 PCS) ◼ Fume extraction unit Donaldson DFPRO6 Nolhcdwsvpaf Tjvswd ◼ Layout marking tool (1 pcs) ◼ Air conditioning for switch panel (up to an ambient air temperature of 55°C) ◼ Outfeed roller conveyor (length 3m, width 2.050mm, roll diameter 159mm, roll distance 300mm, capacity 1.250kg/m) ◼ Hardware and software (includes VACAM ‘Machine Edition’, VACAM ‘Office Edition’, VACAD editor software module, VANEST nesting software, Layout marking software module, online support)

Condition: good (used), Year of construction: 2007, DRILLING MACHINE Operating range V630/1000M Min. / max. height 10 – 450 mm Min. / max. width 60 – 1.050 mm Max. positioning weight 9.000 kg Number of drilling units 3x Automatic tool changer 3x (3x 5 positions) Height measuring Included Width measuring Included Machine weight 12.000 kg Roller feed measuring system Max. speed 42 m/min Min. infeed length 1.500 mm Nwslhcdwevpafyjvsd Drilling unit VD40 Feed and positioning servo-motors with servo-invertors Spindle rpm Stepless 100 – 2.500 rpm (servo-motors) Lubrication Internal by mist of air / oil Holder SK 40 Drill diameter oil-tube-drills 8 – 40 mm Drill diameter carbide drills 13 – 32 mm Thread tapping M8 – M24 Centre point marking possibility Yes, 3 sides SAWING MACHINE Sawing machine VB1050 Capacity (h x w) 0° 500 x 1.130 mm Capacity (h x w) +/- 15° 500 x 1.060 mm Capacity (h x w) +/- 30° 500 x 925 mm Capacity (h x w) +/- 45° 500 x 725 mm Capacity (h x w) +/- 60° 500 x 470 mm Saw band speed stepless 40 – 120 m / min Saw drive motor 7,5 kW Saw band dimensions 9.550 x 54 x 1,6 mm Hydraulic band tension 48.000 N Machine weight +/- 8.500 kg

Condition: good (used), Year of construction: 2012, Vernet Behringer HD-X 918 / HBP 410/923 CNC Sawing / Drilling Line – Year 2012. Nwjlhovn Uv Recdwvsd 3 Spindle. Automatic tool changer. 24 metres infeed. 18 metres outfeed. Gripper Feed measuring system. Infeed and outfeed Cross Transfers.

Condition: excellent (used), Year of construction: 2012, DRILLING MACHINE: Power consumption, kW 9 Maximum thickness of the processed wall 40 mm Minimum thickness of the processed wall 6 mm Diameter of holes 6 - 40 mm Tool rotation speed 0 – 2100 rpm Tool change automatic Feed gripper movement speed 1 – 720 mm/min Horizontal clamping force 1 x 2.5 tons Njlhcdwevkp Dhjvowd Vertical clamping force 4 x 1.5 tons Dimensions of workpieces to be processed: Maximum 1200 x 600 mm Minimum 80 x 6 mm SAWING MACHINE CPI 105DI

Condition: good (used), Year of construction: 2017, 630mm x 350mm capacity. 18.5kw Drilling drive motors. Carbide Drilling and Milling options. Automatic tool changer. 4 axis scribing. Nwjljvkp Aqehcdwvjd Roller feed. Small parts conveyor.

Condition: good (used), Year of construction: 1999, CNC PUNCH / DRILL / SHEARING LINE for angle and plates. TECHNICAL DATA. PUNCH INSTALLATION. MATERIAL SPECIFICATION material sample steel 52 plate size (MM) X (MM) max 300 x 25 Njlhcdwsvkphgjvewd material sample steel 37 plate dimension (MM) X (MM) min 60 x 6 max 400 x 20 angle line dimension min 50 x 50 x 5 max 150 x 150 x 5 Punch information TYPE P2- XXX-XX number 2 TYPE P3-XXX-XX number 3 TYPE P5-XXX-XX number 5 punching capacity tonnage 110 punching diameter (mm) x thickness (mm) max 32 x 20 Shear UNIT Shear tonnage 180 Capacity max 400 x 20 Stamping UNIT Total number of characters number 40 Maximum number of characters per operation 12 CONNECTION VALUES Voltage 3 phase + Neutral + Earth V 3 X 400 Fuse A 63 slow Power KW 25 Frequency HZ 50 Permitted m-axis tolerance mains voltage % +/- 10 Field rotation Right Air pressure bar 6-8 Air capacity m2 / hour 250

Condition: good (used), Year of construction: 2003, Minimum capacity 35mm x 35mm x 3mm Nwolhcdwevkpfrsvod Maximum capacity 150mm x 150mm x 15mm Maximum punch diameter 30mm Minimum punch diameter 6mm 36 character punching / marking unit. 12 metres length capacity.

Year of construction: 2007, Condition: good (used), GIETART 1500 4 Turbines. DCE Unit. Nwslhcdjvbgnxjwved Sound proof enclosure. Infeed Outfeed Rollers Outfeed Crosstransfers.

Condition: good (used), Year of construction: 2015, 30° left Ø 520 550 x 520 45° left Ø 560 800 x 520 Nwslhsvbgipocdwvsd 90° Ø 620 1250 x 520 45° right Ø 560 800 x 520 30° right Ø 520 500 x 520 Motor 14,5 kW Saw blade 10000 x 67 x 1,6 mm Saw blade speed 15/150 m/min. Length of remaining piece without bundle clamp manual: 40 mm

Condition: good (used), Year of construction: 2015, CNC Layout Marking on 4 sides. Roller feed measurement. Independent bottom torch. Nwslova Hwkehcdwvod Siemens CNC Control.

Condition: good (used), Year of construction: 2018, 80 mm pipe diameter. 12 metres length cutting. Nsljva Htfehcdwvjwd

Condition: good (used), Year of construction: 2016, FICEP 1201 FRC Minimum Profile mm 80 x 42 Maximum Profile mm 1220 x 60 1 x OXY FUEL Cutting Head 1 x HYPERTHERM HPR 260XD Plasma Torch. Dust extraction system. Nelova Hfnehcdwvowd

Condition: good (used), Year of construction: 2009, Three Spindle. Automatic tool changer on 3 spindles. 25 metres In-Feed. 45 metres Out-Feed. Roller Feed. In-Feed Cross Transfers. Out-Feed Cross Transfers. Swarf Brush. Nslhcdweva El Hevowd 1000mm Section Capacity.

Condition: good (used), Year of construction: 2015, VOORTMAN V320C CNC PLATE PROCESSING MACHINE INFEED SYSTEM • Infeed roller conveyor (length 6m, width 2.050mm, roll diameter 159mm, roll distance 800mm, capacity 1.250kg/m, including liftable datum line) PLATE PROCESSING MACHINE 1 Nslhouibrijcdwvswd • V320-2000 Plate processing system (base frame with vertical drilling unit, automatic tool changer and automatic discharge table) • Feeder trucks (servo driven, master truck with 3 hydraulic clamps, support truck with 2 hydraulic clamps) • Swarf brush (automatic swarf removal after drilling operations) • Oxy-fuel cutting torch • Plasma cutting unit Hypertherm HPR260XD (1 pcs, automatic gas console, complete with cutting parameter database) • Donaldson fume extraction unit DFPRO6 • Product conveyor belt • Hardware and software (including VACAM ‘Machine Edition’, VACAM ‘Office Edition’) • Safety devices (light curtain, safety fencing, light curtain muting) • Working direction from right to left OUTFEED SYSTEM • Outfeed roller conveyor (length 1,5m, width 2.050mm, roll diameter 159mm, capacity 1.250kg/m.

Condition: good (used), Year of construction: 2007, 12 Metres Plate Length. 3 Metres Plate Width. Precision Plasmarc 400 Amp Source. Nwslhcdeuibk Eewvjd

Condition: good (used), Year of construction: 2008, Geka Alfa 500/150 MC CNC PLATE PUNCH & SHEAR LINE. YEAR 2007 6 METRES INFEED 500MM PLATE WIDTH 20MM THICK MAXIMUM CAPACITY 110T PUNCHING FORCE 3 STATION PUNCH Noljudzmcshcdwvewd MARKING SYSTEM

Condition: good (used), Year of construction: 2007, Tandem CNC Pressbrake 2 x DURMA ADS 60-400. 6 METRES X 400 TONNES. C/W DELEM DA69W CNC CONTROL. Nslhjucgf Uocdwvjwd

Year of construction: 2007, Condition: good (used), Material dimensions Length : max. 1.400 mm' Width : max. 1.000 mm Thickness : 3 - 60 mm Max. weight : 600 kg, heavier plate weights reduced speeds. * Longer lengths possible by automatic repositioning Dimensions Clamping Table VD 40 Drilling unit Drill diameter Thread tapping Spindle rpm Njljt Ipgmohcdwvowd Feed and positioning Lubrication Centring possibility Hydraulic clamping Automatic tool changer Power supply Not included Ambient temperature Working height

Year of construction: 2020, Condition: good (used), Voortman V630/1050T – VB750 CNC Sawing / Drilling Line- Year 2020. 3 Spindles. Automatic Tool Changer. 19 metres infeed. Nwjlhcotvzp Isdwvjd 15 Metres outfeed. Feeder Truck. Measuring Head. Scribing. Infeed Crosstransfers Outfeed Crosstransfers.
