Condition: used, Year of construction: 2013, Technical details: spindle diameter: 160 mm x-travel: 6000 mm y-travel: 5000 mm z-axis: 1500 mm dimension of the ram: 470 x 500 mm w-axis: 900 mm spindle taper ISO: 50 spindle turning speed range: 1 -3000 U/min spindle motor: 71 kW feed speeds: 1 - 5000 mm/min rapid speed: 25 m/min total power requirement: 187,6 kW dimensions of the machine ca.: 14,1 x 13,4 x ü.F.7,8 m Machine in mint condition ! with CNC control HEIDENHAIN iTNC 530 autom. toolchanger 80 - pockets CNC Rotary Table 4000 x 4000 mm max. table load 75 to. longitudinal movement V-axis 1500 mm autom. head changer with universal Milling Head universal high speed milling head 5-axis 18000 rpm RENISHAW measuring probe belt filtering unit and through spindle coolant chip conveyor * Cqhr2Joos8

Condition: refurbished (used), Year of construction: 1996, WOTAN Rapid 5 - CNC panel boring machine - support sleeve (RAM) Year of construction :1996/2006 Spindle : 160mm ( Ø ) X-stroke : 19.000 mm Y-stroke : 3.000 mm W-stroke : 900 mm ( spindle ) Z-stroke : 900 mm ( support sleeve / RAM ) Dimensions : 360 x 360 mm (support sleeve / RAM) Spindle speed : 3.2 - 1250 rpm Rapid traverse speed : 5/10 m/min Rb33Tup Spindle motor : 90 kw Total power : 180 kW Weight of the machine : +/- 160 T Control : Heidenhain iTNC530 (2006) Machining heads : 3 pieces 1st angular translation head : 2500 Nm 2nd universal milling head : 1600 Nm 3. horizontal milling head : 2500 Nm Rotary table : 2500 x 2000 mm - 40 T Base plate (9 pieces) : 5.000mmx1.200mm (15.000mmx3.600mm) Chip conveyor

Condition: used, Year of construction: 2005, X AXIS TRAVEL: 10000 MM Y AXIS TRAVEL: 4000 MM Z AXIS TRAVEL (RAM): 1000 MM W AXIS TRAVEL (SPINDLE): 800 MM TOTAL Z + W AXIS TRAVEL: 1800 MM SPINDLE DIAMETER 160 MM SPINDLE MOTOR POWER 40 KW SPINDLE RPM: 3000 RPM SPINDLE TAPER ISO 50 DIN 69871/1A NR 02 SPEED RANGE RAM DIMENSIONS: 460 X 520 MM Uojozdsbkj RAPID FEEDING 20000 MM/MIN ROTARY TRANSLATION TABLE MODEL MG 50 OF 2500 x 3500 mm , load 50 ton , 360000 position 0,001° stroke 2000 mm HEIDENHAIN iTNC 530 CNC TOOL CHANGER 40 PLACES MANUAL UNIVERSAL HEAD ANCHOR PLATE 6000 X 2000 X 300 MM EXTERNAL REFRIGERATION TOTAL INSTALLED POWER 110 KVA YEAR : 2005

Condition: good (used), Year of construction: 1979, Functionality: fully functional, machine/vehicle number: 332046, travel distance X-axis: 8,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 2,200 mm, spindle speed (max.): 850 rpm, spindle speed (min.): 6 rpm, feed rate X-axis: 8 m/min, feed rate Y-axis: 6 m/min, feed rate Z-axis: 1 m/min, total width: 10,000 mm, total length: 14,000 mm, total height: 4,500 mm, spindle diameter: 160 mm, table load: 40,000 kg, table length: 3,000 mm, table width: 3,000 mm, workpiece weight (max.): 40,000 kg, overall weight: 71,000 kg, drill spindle length: 1,200 mm, year of last overhaul: 2002, power: 60 kW (81.58 HP), table movement X-axis: 3,000 mm, The machine is dismantled on stock, it is fully functionable. Unawab0Vep

Condition: repair required (used), Year of construction: 1999, Make: Union Germany Type: P 150 Year: 1999 (original CNC) Control: Heidenhain TNC 426 Spindle Dia: 150 mm Travel X = 15000 mm Travel Y = 3500 mm Travel Z (column front back) = 800 mm Travel W = 750 mm Spindle power: 37/51 KW Spindle speed: 5 - 3000 rpm Spindle torque: 2515 NM Spindle Taper: ISO 50 Cutting Feeds: 15 m/min Rapid Feeds: 15 m/min Machine comes with floor plates: 2 pcs. 4000 x 1750 mm x 400 mm 4 pcs. 3500 x 1750 x 400 mm E2Pl3Ba Machine can be supplied optional with a manual rotary table Union Ti 1800 size: 2000 x 1800 mm x 12500 Kg cap. Please note: The machine is not working currently because the X-axis drive gearbox needs replacement of bearings and sealings.

Condition: used, travel distance X-axis: 7,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 900 mm, spindle speed (max.): 1,200 rpm, feed rate X-axis: 900 m/min, Ø quill: mm. 140 B2Qtifa3Cq Spindle taper : ISO 50 travel X : mm. 7000 travel Y: mm. 4000 Cross travel Z RAM: mm. 900 Quill travel W: mm. 900 Rotary table: mm. 1800x1800 load admitted on table: Ton. 10 Table rotation: °.pos. Table long.travel (AxisV): mm. 1500 Spindle speed : RPM. 1200 Spindle motor: Kw. 70 CNC ECS 2101 N°2 milling square heads N.2 Floor plate 6000x2000
