PROFEX Dca

Condition: reconditioned (used), Year of construction: 2001, • X / Y / Z / W 3000 / 2000 / 1250 / 560 • Max. spindle speed 3000 rev.min • Automatic Tool changer 60 pos • Milling head • Through spindle coolant • Chip conveyor • Operators platform • Rotary table and X axis housing • Safety fence around machine • Machine documentation • On request we are able to offer new CNC system Heidenhain TNC640 and other upgrades Spindle diameter 130 mm Length of the working table 1600 mm Width of the working table 1800 mm Maximum table load (evenly distributed) 8000 kg Power of the spindle drive 37 kW Maximum rotary speed of the spindle 3000 1/min Travel length X-axis (mechanical feed) 3000 mm Travel length Y-axis (mechanical feed) 2000 mm Travel length Z-axis (mechanical feed) 1250 mm Klslhcewlzhasdwzet Maximum travel length of the working spindle 560 mm Maximum feed rate in X-axis 166.7 mm/s Maximum feed rate in Y-axis 166.7 mm/s Maximum feed rate in Z-axis 10 mm/s Machine height 4550 mm Machine length 6350 mm Machine width 7750 mm Machine weight 39 t

Condition: excellent (used), COLGAR 413 CNC Siemens Sinumerik 840C, max. spindle speed: 2,950 rpm • X axis: 10,000 mm • Y axis: 3,000 mm • Z axis: 1,250 mm (Ram travel) • V axis: 1,300 mm (Working spindle) • Two rotary tables, each with a load capacity of 20 t • Automatic tool changer with 60 tool stations One table can travel 1,400 mm along the V axis Tool changer Control Spindle diameter: 130 Torque: 1,900 Nm Taper: ISO 50 Spindle motor: 42 kW Feed rates • Feed (X / Y / W / Z): 5,000 mm per min • Rapid traverse (X / Y / Z): 10,000 mm per min • Rapid traverse (W): 8,000 mm per min • Axial feed force: 2,000 kg Klslor Hdqxjhcdwzjt Complete manuals, including hydraulic and electrical schematics, are available

Condition: as good as new (ex-display), Year of construction: 2025, TOS Varnsdorf WH 10 CNC Heidenhain TNC620 - Remanufactured Work spindle diameter 100 mm Clamping taper ISO 50 Tool shank 69871 DIN Clamping adapter - screw TOS 4100793 Main motor power (S1/S6-40%) 22/34 kW Max. spindle speed 2500 rev/min Max. torque of the spindle (S1/S6-40%) 2173/3250 Nm Table transverse travel X 1250 mm Headstock vertical travel Y 1100 mm Klolhcdwjpdrzzjzet Table longitudinal travel Z 1000 mm Spindle stroke W 630 mm Table clamping surface 1000 x 1100 mm Workpiece weight max. 3,000 kg Feed range 4 – 6000 mm/min Total power consumption 50 kVA Machine weight 13 000 kg Features mechanical side - hardened guide surfaces on all axes - Biplast-V lining for the guide ways counter surfaces - Geometric accuracy according to the accuracy protocol TOS Varnsdorf WH 10 - Sliding working spindle with diameter of 100 mm, spindle bearings - FAG, SKF - hydraulic tool clamping set 22kN - Ott-Jakob - Headstock with cooling circuit - reTOS Varnsdorf - Ball screws on the X, Y, Z and W axes - KSK Kurim - Rim and pinion for precise rotary table positioning - reTOS Varnsdorf - Hydraulic system (unit, pumps, hoses, fittings) - Baseco - Rotary table reinforcement controlled by CNC system - Central lubrication system controlled by CNC system - Tribotec - Telescopic covers (X and Z axes) Features electrical side - CNC control system iTNC 620 Heidenhain Gen3 - Servo-motors Siemens 1FKZ 100…(5 pcs.) - Spindle motor 1PH8135... - 22kW - Converter Heidenhain UM114D - Linear scales Heidenhain for X, Y and Z axes - Encoder Heidenhain ROD 480 for rotary table - Encoder Heidenhain TTR ERM for spindle - Oriental stop - Control cabinet from Ritall with cooling unit - Wiring and modern electrical components - End-limit switches Balluff - Rotational control panel - Workplace lighting Other - Electrical inspection report, technical documentation - Certificate of geometric accuracy WH 10 Tos Varnsdorf - spindle ball-bar test protocol, linear scales accuracy protocol - cooling of work space placed on spindle forehead (tank, pump, hoses) - working spindle support with brass bushings SP200 Tos Varnsdorf - Heidenhain Options nr. 8, 19 and 20 - Heidenhain HR510 handwheel - Heidenhain Linear scales upgrade to LC115 series for X, Y and Z axis
