Used Surface grinding horiz. 400-699mm grind. length for sale (203)

Condition: good (used), Year of construction: 1986, Functionality: fully functional, grinding length: 600 mm, grinding width: 400 mm, grinding height: 580 mm, For sale is a surface grinding machine of the brand Aba and type FP-60/40 The machine is in good condition and fully functional. Technical specifications: Year of manufacture: 1986 Sanding area: max. (length x width) mm 600x400 Table surface sanded: mm 600x300 Clamping surface: max. mm 1020x300 Distance grinding spindle center table surface: max. mm 750 X-axis (longitudinal movement): Hydraulic longitudinal movement max. mm 720 Longitudinal feed speed m/min 3-30 Z-axis (transverse movement): Transverse movement electro-mechanical max. mm 360 Intermittent cross feed: mm/pulse 3-30 Cross feed: m/min 1.5 Y-axis (vertical movement): Vertical movement: max. mm 580 Vertical rapid traverse: m/min 0.250 Vertical feed automatic adjustment from/to: mm 0.001-0.999 Diameter: mm 400 Width: mm 50 (max. 60) Bore: mm 127 Grinding motor/power (standard) at 50 Hz: kW 11 Grinding motor/speed at 50 Hz: 1/min 1450 Grinding motor/speed-controlled power at 3000 17min: kW 11 Power consumption of the machine: KVA approx. 14 Weight of the machine: kg 3500 On request, transportation and loading can be arranged at extra cost. can be organized throughout Europe. Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Celqsuy S S De Dbk Asgt Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For further information or contact options, please visit our website

Condition: used, Vertical grinding machine, surface grinding machine DORMAC / DORIA type Perseo Cup grinding machine No. 786 Year of manufacture 1987 Sanding area 500 x 250 mm Magnet 400 x 150 mm Grinding height grinding wheel - magnet approx. 190 mm Grinding height grinding wheel - clamping surface table approx. 235 mm Grinding wheel diameter 175 mm Table longitudinal movement approx. 600 mm Grinding wheel speed approx. 2800 rpm Motor power approx. 2.2 kW Mains connection 380 Volt, 50 Hz - Manual depth adjustment via handwheel, travel per handwheel rotation, Z-axis 2.5 mm = 0.01 mm per graduation mark - handwheel on the right of the spindle housing, fine adjustment via knurled wheel on the handwheel Celsvkgvhoq Dbk Aogt - Manual transverse adjustment via handwheel, travel per handwheel revolution, Y-axis 2 mm = 0.01 mm per graduation mark - Hydraulic longitudinal table movement - mechanical magnet WAGNER, type 0112N-15/40-4 400 x 150 mm, height 45 mm - Wet grinding unit with settling filter opposite - 2 grinding wheels Ø 175 mm - 1 grinding wheel holder - 1 balancing device for the grinding wheels Space requirement L x W x H 1500 x 1100 x 1800 mm Weight 570 kg good condition

Condition: like new (used), Year of construction: 1989, CHEVALEV surface grinding machine Cjlq Dbsvv Hlajk Aegt with grinding dust extraction Hydralikaregat

Condition: good (used), Year of construction: 1991, Technical data - Table surface: 800 x 450 [mm] - Grinding surface: 800 x 500 [mm] Cgjlqsvx E Rtj Dbk Aet - Max. distance between table surface and spindle: 650 [mm] - Max. weight on the table: 400 [mm] - Spindle speed: 1400/1700 [tr/min] - Dimensions of the grinding wheels: 350 x 127 x 50 [mm] - Dimensions of the machine: 3350 x 2100 x 1750 [mm] - Weight: 2900 [kg]

Condition: used, grinding length 600 mm grinding width 200 mm workpiece height 250 mm Cjlq Dsu N I Nkjbk Aegt grinding wheel diameter 200 mm grinding wheel width 20 mm total power requirement kW weight of the machine ca. 1000 kg dimensions of the machine ca. 2000 x 1200 x 1650 m

Condition: good (used), grinding length: 500 mm, grinding width: 200 mm, grinding wheel diameter: 225 mm, distance table to spindle center: 350 mm, type of input current: three-phase, spindle speed (max.): 4,000 rpm, spindle speed (min.): 1,000 rpm, overall weight: 1,800 kg, power: 4.7 kW (6.39 HP), space requirement length: 2,570 mm, Equipment: documentation/manual, rotational speed infinitely variable, Vial grinding machine JUNG infinitely variable cutting speed up to 35m/min. with suction, and with coolant device Cslq Dbkjrblx Re Aegt

Condition: reconditioned (used), Year of construction: 1997, Surface grinding machine Make ELB-Schliff Model Perfekt 4 SPS-NK Year of construction: 1997 - partially overhauled, newly painted, RAL 7035 light gray / RAL 7012 basalt gray RAL 5012 blue-grey Machine no. 48.021 with warranty: Accessories: Coloqaz Icsq Dbk Ajgt - Electro-magnetic clamping plate 400 x 250 mm pole pitch 5 mm with holding force control - automatic vertical infeed with infeed program with digital display for vertical and transverse movement - automatic central lubrication - Wet sanding unit with automatic paper belt filter for filter paper with 460 mm width x 200 m with filter density 0.016-0.025 mm - stainless steel rear panel - Electric straight line dresser with dimensional compensation with dressing diamond - Table stroke counter with the option of after a preset number of strokes to automatically dress the grinding wheel - adjusting elements - Operating instructions Used as seen The machine corresponds technically the status of the year of manufacture at that time.

Condition: used, Surface grinding machine BLOHM type HFS 6 make no.: 10493 year of construction 1973 Electro magnetic clamping plate 600 x 300 mm grinding length 600 mm grinding width 400 mm table longitudinal movement max. 650 mm transversal movement 350 mm distance spindle center - table surface max. 600 mm distance spindle center - magnetic plate max. 517 mm Clamping surface table 1020 x 300 mm grinding wheel diameter 300 mm grinding wheel width 50 mm grinding wheel bore 76 mm table longitudinal feed 2-30 m/min infinitely variable table cross feed 2-65 mm stepless electric cross feed 3 m/min vertical feed 0,001 - 0,020 mm per infeed pulse vertical feed 0,250 m/min grinding wheel speed 1400 / 2800 rpm. Motor power hydraulic pump 2,2 kW Motor power grinding spindle 5 / 6 kW Mains connection 380 Volt, 50 Hz. Total power 11 kW - automatic depth adjustment - hydraulic longitudinal table movement - grinding wheel dresser on the headstock - electromagnetic plate height 83 mm Cjlq Dbksd Hbafo Aegt - coolant system adjacent, with magnetic filter in filter housing - grinding spindle circulating lubrication - adjacent control cabinet (800 x 500 mm) - swiveling control panel - operating instructions and spare parts manual space requirement L x W x H 3000 x 2200 x 2100 mm weight surface grinding machine 3000 kg weight switch cabinet 200 kg good condition

Condition: excellent (used), Year of construction: 2017, Functionality: fully functional, machine/vehicle number: 66586, grinding length: 650 mm, grinding width: 323 mm, grinding height: 450 mm, table length: 600 mm, table load: 420 kg, table width: 400 mm, TECHNICAL DETAILS X-axis: 600 mm Z-axis: 450 mm Y-axis: 323 mm Magnetic clamping plate Type: Electro-permanent magnetic clamping plate Size: 600 x 400 mm Table load: 420 kg Area of application: High-precision machining Features: Electronic demagnetization and holding force coding Pole pitch: 18 mm (transverse parallel pole) Air hole set: 2 x 3 holes, central locking device Dressing system Type: Hydraulic straight dresser Automatic: Automatic dressing with compensation of the dressing amount, grinding wheel wear, intermediate dressing and grinding head reset MACHINE DETAILS Installation dimensions: 4,350 x 3,700 x 2,300 mm Machine dimensions: 3,425 x 2,263 mm Weight: 3,200 kg Connection power: 9.5 kVA EQUIPMENT - Microcomputer control group for magnetic clamping plate - Electro-permanent magnetic clamping plate (600 x 400 mm) with demagnetization and holding force coding Cgslq Dbkevw Su Aj Aot - Belt filter machine SBF 30 Complete with 150 l tank, pump, supply lines, fittings and 1 roll of filter fleece - Replacement disk flange (Ø 127 mm). - Automatic dressing with hydraulic dresser

Year of construction: 2022, Condition: as good as new (ex-display), The cast-iron machine frame features superior rigidity and torsional strength, precision guideways and excellent machining quality All guideways are lubricated reliably via a central lubrication system The workspace is protected by an easily accessible enclosure A powerful coolant pump is combined with a vacuum exhaust unit to clear grinding dust and aerosol during machining operations All required parameters for precise grinding spindle feeds are entered and edited via the Siemens touchscreen The high-quality preloaded ball screw and a powerful servo-motor ensure high precision and repeatability of positioning on the Y-axis The machine features an electronic hand-wheel for configuration tasks and manual movement of the grinding spindle If set to Auto mode, the user-defined roughing and finishing parameters, number of spark-out strokes, and return to zero are automatically processed Grinding spindle Large grinding spindle, dynamically balanced, completely sealed with permanent lubrication Preloaded precision-bearings ensure maximum grinding performance and high reliability over many production hours Programming The high-quality preloaded ball screw and a powerful servo-motor ensure high precision and repeatability of positioning on the Y -axis The machine features an electronic hand-wheel for configuration tasks and manual movement of the grinding spindle If set to Auto mode, the user-defined roughing and finishing parameters, number of spark-out strokes, and return to zero are automatically processed Hydraulics Extremely quiet operation and minimal heat build-up for optimum work results under continuous operating conditions Hydraulically operated linear table movement, infinitely variable, high consistency, and soft reversal of direction External hydraulic unit with oil cooler unit ensures perfect temperature stability Magnetic clamping plate A large magnetic setup plate is included and ensures torsion-free clamping, long tool life and high reliability The control unit is integrated into the electric system to simplify operation, allowing quick clamping and degaussing for maximum production efficiency Workpiece weight (max.) 270 kg Cgslof Hmr Aeq Dbk Ast Spindle nose-to-table surface distance 580 mm Table dimensions 635x305 mm Dimensions magnetic clamping plate 600x300 mm Scale ring division Y-axis 0,005 mm Scale ring division Z-axis 0,02 mm Autom. transverse feed Z-axis 0,1 - 8 mm Speed 1.450 1/min Autom. vertical feed 0,005 - 0,05 mm TravelsTravel X-axis 765 mm Travel Y-axis 340 mm FeedHydr. feed X-axis 7 - 23 m/min Rapid feed Y-axis 480 mm/min Rapid feed Z-axis 990 mm/min Drive capacity Motor rating main drive 4 kW Measures and weights Grinding wheel dimensions 350x40x127 mm Overall dimensions (length x width x height) 2,9x2,2x1,9 m Weight 2.800 kg

Condition: used, Grinding length 600 mm Grinding width 350 mm Magnet size 600 x 200 mm Workpiece height 450 mm Table speed 1 - 30 m/min Feed automatic 1 - 60 (transverse) mm/stroke Cjlq Devk T Scsbk Aegt Rapid traverse (transverse) 1.2 mm/min Machine weight approx. 2,450 kg

Condition: new, Precision surface grinding machine with automatic longitudinal and transverse feed. All castings, such as machine stand, table, etc., are made of MEEHANITE® quality cast iron and are therefore ideally suited for rough everyday work. Ideal for tool and mold making. Table size: 250 x 500 mm Installation height (max. distance spindle/table): 500 mm Max. Table load: 250 kg Motor power main spindle: 1,5 kW Connection: 400 V Dimensions (LxWxH), approx.: 2250 x 1400 x 1800 mm Weight, approx.: 1350 kg* * only machine without auxiliary units Features: - All castings, such as machine column, table, etc., made of MEEHANITE® quality castings. - All guideways hardened and ground - Automatic cross and longitudinal feed - NC-controlled automatic vertical infeed - Ergonomically arranged control panel - Automatic central lubrication - Separate hydraulic power pack - Grinding wheel - Grinding wheel flange - Manual dressing device - Balancing mandrel - Balancing scale - Dressing diamond - Demagnetizing device - Machine light - leveling elements - Operating tool - Operating instructions - CE Available options: - Elektromagent clamping plate (fine-pole) - Automatic demagnetization control for electromagent clamping plate - 2-axis digital display, accuracy 0.001 mm, X 450 / Y 500 mm - Coolant system with magnetic separator / magnetic separator - Partial enclosure with limit switch protected sliding doors - Full enclosure with limit switch protected sliding doors - Additional grinding wheel flange - Grinding wheel and flange for mild steel Cgjlq Dbop Dt T Nek Aet - Grinding wheel and flange for HRC55 - Ball screw for cross feed - Further options on request Pictures may show the machine with special accessories and with application examples.

Condition: excellent (used), Functionality: fully functional, grinding length: 650 mm, grinding width: 400 mm, grinding height: 400 mm, table length: 850 mm, table width: 360 mm, grinding wheel width: 350 mm, No reserve price - guaranteed sale at the highest bid! TECHNICAL DETAILS Table dimensions: 850 x 360 mm Grinding area: 650 x 400 mm Grinding height: 400 mm Magnet size: 600 x 400 mm Grinding wheel dimensions: 350 x 40 x 52.7 mm Travel paths Travel paths x / y / z: 840 / 500 / 410 mm MACHINE DETAILS Dimensions: 4,000 x 3,000 x 2,500 mm Weight: 3 t Connected load: 15 kW Cjlqevuqzpe Dbk Aogt

Condition: as good as new (ex-display), I am offering for purchase surface grinding machine FS 2045 made by Ziersch & Baltrusch renovated and modernized in our company. The grinder has a swivel electromagnetic table with dimensions of 150x450mm. Completely new electrical installation (new electrical cabinet, servo drives) and new control system with panel. Machine geometry guaranteed. The grinder is ready for installation and operation. Available immediately. Celq Dbopah E Sek Asgt I am at your disposal if you have any further questions.

Condition: used, Surface grinding machine, precision surface grinding machine BRAND (Switzerland) type FS 735 Machine No.: 322 82 Year of construction 1982 Electric magnetic chuck 700 x 300 mm Sanding length 700 mm Sanding width 300 mm Transverse movement max. 340 mm Table longitudinal movement max. 750 mm Distance spindle center - magnet max. 400 mm Grinding wheel diameter 300 mm Grinding wheel width 50 mm Grinding wheel width 60 mm with recess on one side of the grinding wheel Grinding wheel bore 127 mm Table longitudinal feed 0 - 30 m/min infinitely variable Table cross feed pulse 1 to 10 mm Cross feed 340 mm in 6 sec Cgelqsn Saf Nj Dbk Ast Vertical infeed 0.001 - 0.055 mm Vertical infeed 150 mm/min. Grinding wheel speed 2500 rpm. Grinding wheel speed 39 Vm/sec. Motor power grinding spindle max. 5.7 kW Motor power hydraulics 1.5 kW Mains connection 400 Volt, 50 Hz, approx. 7 kVA - Digital display for cross and depth adjustment - Infinitely variable grinding wheel speed - Automatic depth adjustment - Automatic table cross adjustment, hydraulic and mechanical handwheel for table cross adjustment - Hydraulic clamping for cross adjustment - Hydraulic longitudinal table movement - Hydraulic dressing device - BRAILLON electromagnetic plate, type BJP 700 x 300 mm, overall height 100 mm, infinitely adjustable magnet strength - Central oil lubrication - BEDA belt filter system with coolant tank and pump opposite L x W x H = 1600 x 650 x 1100 mm - adjacent hydraulic unit with electrical cabinet L x W x H = 1800 x 750 x 1700 mm - Machine equipped with one grinding wheel Ø 295 mm, width 50 mm - 2 additional grinding wheel holders with grinding wheels (inner diameter 127 mm) - 1 grinding wheel remover Space required for surface grinding machine L x W x H 2200 x 1800 x 2350 mm Weight of surface sanding machine approx. 3100 kg Weight of hydraulic unit 500 kg Weight of belt filter system 200 kg Space requirement on pallet 2700 x 2200 x 2500 mm Complete weight with pallet approx. 4000 kg Good condition

Condition: excellent (used), Jones & Shipman 624 Dominator CNC Surface Grinder Under power and working. Can be shown demonstrating at our premises in Burscough Fanuc Series 210i-M CNC Control Table Length 600mm x 200mm width Colqsu D H Uhe Dbk Ajgt Wheel diameter 250mm Wheel width 25mm Max wheel speed 3200rpm Spindle power 5.6kw

Condition: ready for operation (used), Year of construction: 1982, Sanding length 500 mm Sanding width 350 mm Sanding height 375 mm Sanding spindle drive 3.7 kW Table speed 2-28 m/min Celqsu Ag Ais Dbk Aogt Automatic cross feed 1-60 mm/stroke Automatic vertical feed 0.002 - 0.06 mm/min Grinding wheel dimensions 300 x 76.2 x 50 mm Machine weight approx. 2,800 kg

Condition: new, Precision surface grinding machine with automatic longitudinal and transverse feed. All castings, such as machine stand, table, etc., are made of MEEHANITE® quality cast iron and are therefore ideally suited for rough everyday work. Ideal for tool and mold making. Table size: 200 x 450 mm Installation height (Max. distance spindle/table): 450 mm Max. Table load: 150 kg Motor power main spindle: 1,5 kW Connection: 400 V Dimensions (LxWxH), approx.: 2080 x 1200 x 1700 mm Weight, approx.: 950 kg* * only machine without auxiliary units Features: - All castings, such as machine column, table, etc., made of MEEHANITE® quality castings. - All guideways hardened and ground - Automatic cross and longitudinal feed - NC-controlled automatic vertical infeed - Ergonomically arranged control panel - Automatic central lubrication - Separate hydraulic power pack - Grinding wheel - Grinding wheel flange - Manual dressing device - Balancing mandrel - Balancing scale - Dressing diamond - Demagnetizing device - Machine light - leveling elements - Operating tool - Operating instructions - CE Cgjlq Dbjp Dt Ttek Ast Available options: - Elektromagent clamping plate (fine-pole) - Automatic demagnetization control for electromagent clamping plate - 2-axis digital display, accuracy 0.001 mm, X 450 / Y 500 mm - Coolant system with magnetic separator / magnetic separator - Partial enclosure with limit switch protected sliding doors - Full enclosure with limit switch protected sliding doors - Additional grinding wheel flange - Grinding wheel and flange for mild steel - Grinding wheel and flange for HRC55 - Ball screw for cross feed - Further options on request Note: Picture shows FSM 2550 AH of identical design. Pictures may show the machine with special accessories and with application examples.

Condition: used, Surface grinder MÄGERLE F7 Celqjvxlp Ao Dbk Asgt

Condition: good (used), grinding length: 400 mm, grinding width: 150 mm, Table length 400 mm Table width 150 mm Grinding length 400 mm Grinding width 150 mm Execution: hydraulic Cslqsvga Suj Dbk Asgt Max. distance from table to spindle-centreline 350 mm Table speeds: stepless from .00 m/min up to 0.0 m/min Automatic vertical feed: from 0.00 0 mm up to 0.013 mm Diameter of grinding wheel 00 mm Width of the grinding wheel 16 mm Grinding wheel speeds: from 800 rpm Voltage 50 Hz 3x 380 Volt Grinding spindle motor .30 HP Machine's weight about 900 kg Overall dimensions machine: Length 1300 mm Width 1 00 mm Height 1500 mm

Condition: used, Surface Grinding Machine, Precision Surface Grinding Machine BRAND (Switzerland) Type Mini 500 machine no.: 505/86 year of construction 1986 Electro magnetic clamping plate 450 x 200 mm grinding length 500 mm grinding width 240 mm cross movement 220 mm table longitudinal movement 550 mm distance spindle center - magnet max. 350 mm grinding wheel diameter 225 mm grinding wheel width max. 25 mm grinding wheel bore 50,8 mm table longitudinal feed 0,5-24 m/min infinitely variable table cross feed pulse 0,05-30 mm cross feed 10 - 1000 mm/min. vertical infeed 0,001 - 0,05 mm vertical dividing feed 600 mm/min. Grinding wheel speed 2820 rpm. Grinding wheel speed 33 Vm/sec. motor power grinding spindle 2,2 kW Motor power hydraulics 1,1 kW mains connection 400 Volt, 50 Hz, 9,5 kVA - automatic depth infeed, vertical infeed - mechanical handwheels for axis movements - hydraulic longitudinal table movement - electromagnetic plate WAGNER 450 x 200 mm, height 73 mm Celq Dbkjd Nrqfo Aegt - central lubrication - belt filter system with coolant tank and pump adjacent L x W x H = 1300 x 500 x 650 mm - 2 pieces additional grinding wheel holders for grinding wheels with 50,8 mm inner diameter - 1 piece balancing shaft and 1 piece grinding wheel puller - hydraulic power pack L x W x H = 700 x 300 x 750 mm space requirement L x W x H 2000 x 1400 x 2250 mm weight approx. 1600 kg good condition

Condition: used, Year of construction: 1969, grinding length 500 mm grinding width 200 mm workpiece height 250 mm total power requirement 5,5 kW weight of the machine ca. 2500 kg dimensions of the machine ca. m J U N G Horizontal High Precision Surface- and Profile Grinding Machine Model HF 50 RD, Year 1969, partially reconditioned in 2021 Serial-no. 4082 _____ Grinding length max. 500 mm Grinding width max. 200 mm Table size 600 x 200 mm Grinding height under grinding wheel approx. 250 mm Table cross travel approx.. 230 mm Table slide cross stroke 0,2 - 8 mm/table stroke Table longitudinal travel max.. 550 mm Table speed longitudinal 1 – 20 m/min. Measurement of grinding wheel 225 x 25 x 51 mm Grinding wheel speed infinitely adjustable 1.000 - 4.500 rpm Vertical feed 0.001 - 0.01 mm/stroke Grinding spindle drive infinitely variable load 0,4 – 1,5 kW Cgjlq Djt Hwziobk Aot Total electrical load 5,5 kW - 380 V – 50 cycles Weight approx. 2.500 kg Accessories/Special Features: • Due to the infinitely variable speed range of the grinding wheel this design is especially suited for grinding of high alloyed steels and carbide, hardmetal, etc. • Set up switches for plunge-in or normal pendular-grinding with automatic infeed • Automatic infeed of grinding slide during surface- and/or profile grinding, (plunge-in cut)with automatic stop of infeed by contact-Gauge. • motorized rapid feed of grinding head up/down • Manual straight grinding wheel-dressing device mounted above the grinding wheel • Manual Table mounted, swivable magnetic chuck make BRAILLON size 400 x 200 mm • separate converter cabinet for infinitely variable speed regulation and with respective display of cutting speed in m/sec. • Wet grinding facility including coolant tank and bandfilter cleaning device, separate standing, • Including 3 separate flanges, some grinding wheels, service tools, etc. Condition : good – can be inspected here under power, partially reconditioned by a JUNG Specialist (table pistons, lubrication, infeed system, Dresser, covers, etc.) Delivery : ex stock – as inspected Payment : net– after completion of contract

Year of construction: 2021, Condition: refurbished (used), grinding length max. 600 mm Clamping surface of the table 600 x 200 mm Magnet size max. 500 (max. 600) x 200 mm Maximum distance between table surface and grinding spindle centre 495 mm Grinding wheel dimensions (Dxwxd) 250x25x51 mm Grinding spindle drive 5,5kW (three-phase current) with autom. adjustment of the peripheral speed Cgslq Dbjgg Etaok Ajt and electronic braking of the grinding spindle Manual head dresser for cylindrical dressing with dressing dimension compensation Digital path measuring system in Y- and Z-axis Automatic central lubrication We would be pleased to submit you an individual offer for a factory overhauled machine. Ilg+Sulzberger GmbH Werkzeugmaschinen Stuttgart cooperates with Blohm Jung Gmbh Göppingen as sales partner for the region of Baden-Württemberg.

Condition: new, Precision surface grinding machine MIOTAL FSM 3060 AH Table size: 300 x 600 mm Installation height: 500 mm Max. Table load: 300 kg Motor power: 4.6 kW Connection: 400 V Dimensions: 2300 x 1790 x 2200 mm Weight, approx.: 2000 kg Equipment and scope of delivery: - All cast parts, e.g. machine stand, table etc. made of MEEHANITE® quality casting - Automatic cross and longitudinal feed - Permanent lubrication - Automatic cross lifting device - Splash guard on the rear - Grinding wheel - Grinding wheel flange - Honing device - Balancing mandrel - Balancing scale - Dressing diamond - Machine light - Leveling elements - Operating tool - Operating instructions - CE Special equipment of our storage machine: - Electric magnetic clamping plate 300 x 600 mm (fine pole) - 2-axis digital readout, accuracy 0.001 mm, X 450 / Y 500 mm - Automatic vertical infeed AD 5 (NC-controlled) for model AH - mode of operation: Automatic rapid traverse vertical and automatic fine feed vertical - Automatic demagnetization control for magnetic clamping plate - Coolant system with magnetic separator - Manual dressing device - Parts enclosure - Ergonomically arranged control panel - Additional grinding wheel flange - Ball screw for cross feed - Grinding wheel and flange for mild steel - Grinding wheel and flange for HRC55 Alternative equipment features / other machine configurations on request. Cgolq Dbsd Sfd Eok Aet

Condition: good (used), Year of construction: 1990, Year of construction 1990 Control type CNC Sanding length 600 mm Cjlji Hn U Ujq Dbk Asgt Sanding width 200 mm Workpiece height 375 mm Table load 100 kg Grinding wheel dimensions 250x25x51 mm Run at 1-24 m/min Speed 4200 rpm Drive motor 5 kW Total power requirement 7.5 kW Machine weight approx. 3.2 t Space requirement approx. 3.7 x 2.1 x 2.1 m
