Used surface grinding horiz. 400-699mm grind. length for sale (219)

Condition: ready for operation (used), Year of construction: 1980, functionality: fully functional, machine/vehicle number: 207306 - 6813, grinding length: 600 mm, grinding width: 300 mm, grinding wheel diameter: 300 mm, spindle speed (max.): 3,000 rpm, grinding spindle motor power: 8 W, No minimum price - guaranteed sale to the highest bidder! Ijdpfx Aowm H I Ismyjat TECHNICAL DETAILS Grinding length: 600 mm Grinding width: 300 mm Spindle and Drive Spindle speed: 0 – 3,000 rpm Grinding spindle motor: 7.5 kW Total power requirement: 7.5 kW Grinding Wheel Grinding wheel diameter: 300 mm Grinding wheel dimensions: 76 x 20 mm EQUIPMENT - Magnetic table - Surface grinding machine

Condition: used, Technical details: Magnetic plate: 900 x 450 mm Heidenhain measuring system Automatic feed Isdpfxoyhwhwe Amyoat Cross movement electrically and manually via handwheel Vertical movement electrically and manually via handwheel Longitudinal movement hydraulically and manually via handwheel Grinding spindle with plain bearings

Condition: good (used), Grinding range 400 x 200 x 410 mm Grinding wheel size 225 x 25 x 50.8 mm Magnetic plate 350 x 150 mm Iedpfjwufkqsx Amyeat MARCELS MASCHINEN CH

Condition: used, grinding length:650 mm grinding width:450 mm workpiece height:425 (ohne Magnetplatte) mm max. workpiece weight:600 kg weight of the machine ca.:3,8 t total power requirement:15 kW machine dimensions approx. WxHxD:3,0 x 2,4 x 2,3 m Used/reconditioned surface grinding machine, make GER, type RSA-650. Automatic infeed in all 3 axes. Machine geometrically overhauled, repainted (RAL6011, green), all functions tested, accuracy checked. OVERHAUL SCOPE: Machine completely disassembled, all components thoroughly cleaned and tested for complete functionality. Main spindle newly mounted, concentricity 3 µ. All guideways newly scraped in new machine geometry. Wear parts replaced, defective components repaired or replaced. Reassembly, complete functional test and internal acceptance. Machine repainted. Machine in perfect condition, ready for production. MEASURED GEOMETRIC ACCURACIES: Actual geometric accuracy after overhaul, measurement with dial gauge. Geometry of machine axes X and Z X = longitudinal axis 650 mm Z = transverse axis 450 mm Measurement magnet traversed with dial gauge. X axis = Max. Deviation 0,008 mm Z axis = Max. Deviation 0,005 mm INCL. THE FOLLOWING ACCESSORIES: -Electro-magnetic clamping plate, with fine longitudinal pole pitch. dimensions 600 x 400mm -demagnetizing device -Complete coolant device with paper band filter - Digital display of the vertical axis (Y-axis), make Sony Iodpfx Aofkg H Tjmyjat -Technical documentation in English language -1 pieces grinding wheel holders -1 piece grinding wheel dresser, mounted above the grinding wheel with manual infeed and automatic (hydraulically operated) transverse movement - 1 set of setting elements You can find more information in the attachment. Payment: 100% before loading the machine Warranty: 6 months on the geometry and the new parts demonstrably installed. No general legal warranty.

Condition: new, Year of construction: 2026, grinding length: 560 mm, grinding width: 240 mm, total height: 2,150 mm, total length: 2,250 mm, total width: 1,720 mm, workpiece weight (max.): 180 kg, feed rate X-axis: 25 m/min, grinding wheel diameter: 220 mm, distance table to spindle center: 450 mm, table length: 508 mm, type of input current: three-phase, table width: 200 mm, grinding wheel width: 20 mm, overall weight: 1,800 kg, rotational speed (max.): 2,850 rpm, power: 5 kW (6.80 HP), input voltage: 400 V, Equipment: documentation/manual, Siemens PLC control Touchscreen Electronic handwheel Digitally controlled automatic vertical feed with servomotor SINO 2-axis digital readout Electromagnetic clamping plate Cooling system LED lighting Grinding wheel Flange Central oil lubrication Table size ----- 200 x 508 mm T-slot width / quantity ----- 14 / 1 mm Electromagnetic clamping plate ----- 200 x 460 mm Max. longitudinal travel of table ----- 560 mm Ijdpfx Ameykvkxjyeat Max. cross travel of table ----- 240 mm Table speed, hydraulic ----- 5~25 m/min Max. distance spindle - table ----- 450 mm Max. permissible workpiece weight ----- 180 kg Grinding wheel ----- 220 × 20 × 31.75 mm Cross travel Automatic feed, cross ----- 0.2~8 mm / stroke Rapid traverse, cross ----- 990 mm/min Feed per handwheel revolution, cross ----- 4 mm/rev Handwheel graduation ----- 0.02 mm Vertical travel Automatic feed, vertical ----- 0.005 / 0.01 / 0.02 / 0.03 / 0.04 / 0.05 mm Rapid traverse, vertical ----- 480 mm/min Feed per handwheel revolution, vertical ----- 1 mm/rev Handwheel graduation ----- 0.005 mm Main motor ----- 2.2 kW Hydraulic pump motor ----- 0.75 kW Vertical feed motor ----- 0.5 kW Weight ----- 1800 kg Machine dimensions ----- 2250 x 1720 mm

Condition: used, Year of construction: 1953, grinding wheel dia. x width ca. 200 x 25 mm magnetic clamping plate ca. 450 x 170 mm cross feed of the table 200 mm revolutions of grinding spindle 3000 U/min grinding wheel hole diameter 51 mm weight ca. 1300 kg 0,001 - 0,013 mm grinding length 600 mm Iajdpfx Amexu Nw Esyet Surface grinding machine Includes extractor 1 additional grinding wheel holder Machine was in occasional use until recently

Year of construction: 1987, condition: used, grinding length max. 630 mm grinding width max. 200 mm workpiece height . mm x-axis max. 250 mm y-axis max. 710 mm distance spindle center to table max. 500 mm table surface area 0,25 mm Isdegbgawepfx Amyoat table load max. 1,1 t table speed -stepless- 2 - 18 m/min cross feed autom. . dust exhaust 0,25 kW coolant pump 0,09 kW total power requirement ca. 4,5 kW weight of the machine ca. 1,3 t dimensions of the machine ca. 2400 x 1600 x 1900 mm Adjustments Y axis: 1 scale value = 0.005 mm Z axis: 1 scale value = 0.002 mm Manual adjustment (within the range of 250 mm of the Y axis): 80 mm Speeds: automatic cross feed Adjustment path in Y direction: - intermittent 0.2 - 20 mm per stroke; - continuous: 0 - 4 m/min Grinding wheel Ø max. 200 mm Grinding wheel bore: 51 mm Grinding wheel width: 20 mm Diamond dressing unit Digitaldisplay for 2 advertisement vertical infeed

Condition: used, Year of construction: 1996, grinding length 600 mm grinding width 250 mm workpiece height ca. 385 mm table surface area 600 x 200 mm table speed -stepless- 2 - 35 m/min table load capacity max. 250 kg grinding wheel size ø 225 x 25 mm grinding wheel hole diameter 50,8 mm Iasdpfx Ajt Tqrnemyot vertical feed autom. 0,001 - 0,099 mm rapid traverse vertical 600 mm/min cross feed of table continual 10 - 1000 mm/min rapid traverse cross 1000 mm/min total power requirement 6 kVA dimensions of machine L x W x H 2,65 x 1,70 x 2,28 m Accessories: DRO on Y-and Z-axis, magnetic plate 600 x 200 mm, grinding wheel with flange, wheel trueing attachment, wet grinding attachment with paper band filter

Condition: good (used), Year of construction: 1988, functionality: fully functional, Surface grinding machine Geibel&Hotz Type FS 40 Primus SA Condition: good Iajdpfx Aeyh Hutjmyet Fully functional

Condition: good (used), Year of construction: 1963, Grinding area: 600 x 400 mm Iaodow Rqy Iopfx Amyst Magnetic table Coolant tank various grinding wheels

Condition: good (used), Magnetic table 455 x 170 mm digital display water tank Honing device Wet sanding device Isdpfotu Il Tjx Amyoat

Condition: excellent (used), Grinding length 600 mm Grinding width 320 mm Max. workpiece height 500 mm Iaodpfx Asw Hy Twomyet Longitudinal table travel 750 mm Cross table travel 340 mm Grinding wheel diameter 350 mm Grinding wheel width 40 mm Spindle speed 1500 rpm Vertical rapid traverse 400 mm/min Power 3.7 kW Automatic feed Magnetic chuck Coolant system Weight 2500 kg

Condition: as good as new (ex-display), Year of construction: 2014, functionality: fully functional, Available from stock Max. Grinding width: 225 mm (incl. wheel) Max. Grinding length: 450 mm Max. Distance table to spindle center: 450 mm Max. Longitudinal movement of the table (hydr.): 500 mm Max. Max. longitudinal movement of the table (man.): 530 mm Automatic vertical infeed: 0.002 - 0.004 mm Automatic transversal infeed: 0.4 - 6 mm Max. Clamping surface of the table: 450 x 200 mm Max. Clamping surface of magnetic clamping plate: 450 x 200 mm Grinding wheel D x B x d: 203 x 12.7 x 31.75 mm Rapid traverse: 330 mm/min Grinding spindle speed: 2850 rpm grinding spindle drive: 1.5 kW hydraulic motor: 0.75 kW weight: 1300 kg dimensions W x D x H: 2100 x 1650 x 1900 mm Balancing mandrel Manual extractor with diamond Automatic vertical feed Ijdpoirwnvefx Amyoat Electro-magnetic clamping plate Control panel on swivel arm Grinding wheel spindle on 4 high precision angular contact ball bearings Hardened guideways in all 3 axes with needle bearings Grinding wheel Grinding wheel flange Grinding wheel balancing scale Coolant system with aut. paper filter and magnetic separator Operating instructions in ENGLISH Machine and equipment according to CE regulations

Condition: used, Year of construction: 1982, grinding length 0600 mm grinding width 200 mm workpiece height 250 mm Iaedou Rt Diepfx Amyst magnetic plate size 600 x 200 mm total power requirement 4,5 kW weight of the machine ca. 2,5 t dimensions of the machine ca. 2000 x 1200 x 1650 mm With magnetic plate 600 x 200 mm and automatic dressing arrangement.

Condition: excellent (used), Jones & Shipman 624 Dominator CNC Surface Grinder Under power and working. Can be shown demonstrating at our premises in Burscough Fanuc Series 210i-M CNC Control Iodpfxju D H Uhe Amyoat Table Length 600mm x 200mm width Wheel diameter 250mm Wheel width 25mm Max wheel speed 3200rpm Spindle power 5.6kw

Condition: refurbished (used), grinding length: 600 mm, grinding width: 200 mm, grinding length 600 mm Iaedexal Hyepfx Amyet grinding width 200 mm electromagnetic chuck 450×175 mm X-travel 660 mm Z-travel 225 mm grinding wheel size 250x25x51 mm Control Jung TouchScreen weight approx. 3000 kg

Condition: good (used), Year of construction: 1979, functionality: fully functional, machine/vehicle number: 1054, grinding length: 400 mm, grinding width: 150 mm, Table length: 400mm Table width: 150mm Maximum cutting length: 400mm Maximum grinding width: 150mm Maximum workpiece weight: 75kg Distance spindle to table: 400mm Table speed 1-24 m./min. Sharpening stone diameter: 25mm Spindle speed: 900 – 4500 rpm. Year of construction: 1979 Isdpfxer Eq U Se Amyeat

Condition: good (used), Year of construction: 1991, Technical data - Table surface: 800 x 450 [mm] - Grinding surface: 800 x 500 [mm] - Max. distance between table surface and spindle: 650 [mm] - Max. weight on the table: 400 [mm] Iaodpfevx E Rtjx Amyet - Spindle speed: 1400/1700 [tr/min] - Dimensions of the grinding wheels: 350 x 127 x 50 [mm] - Dimensions of the machine: 3350 x 2100 x 1750 [mm] - Weight: 2900 [kg]

Condition: good (used), - Table surface: 457 x 152 mm - Maximum distance between grinding wheel and table surface: 400 mm - Grinding spindle power: 2.2 kW - Grinding wheel dimensions: 200 x 25 mm diameter - Grinding wheel rotation speed: 1000-4000 rpm Iodpewlhtvefx Amyoat - Table travel speed: 1-25 m/min - Minimum programmable increment: 0.001 mm - Dimensions: 1800 x 1200 x 1950 mm

Condition: refurbished (used), functionality: fully functional, grinding length: 630 mm, grinding width: 230 mm, total height: 1,650 mm, total length: 1,535 mm, total width: 1,770 mm, grinding height: 360 mm, feed rate X-axis: 2 m/min, feed rate Z-axis: 20 m/min, grinding wheel diameter: 400 mm, table load: 180 kg, rotational speed (max.): 3,220 rpm, power: 1.5 kW (2.04 HP), disc diameter: 250 mm, Retrofit of Surface Grinding Machine TOS BSKF 20 NC with SCHNEIDER Control System - Machine is fully dismantled and retrofitted Standard Accessories: - 2-axis cycle control, manufactured by Schneider-Electric Functions: Infeed, Spark-Out, Dressing, and Compensation - Grinding wheel 250 x 20 x 76 mm - Grinding wheel flange - Electro-magnetic chuck 600 x 200 mm - Automatic feed on Y and Z axes - Diamond dresser holder (without diamond) - Coolant system with settling tank - Machine lamp - Centralized lubrication - Operating tools - Operating manual - CE declaration - Inspection report Included: Transport and packaging On-site relocation with crane/forklift Commissioning Iaedpfxjxf Ez Ue Amyjt Travel and accommodation expenses Accessories: - Partial enclosure - Single-point diamond, 0.75 ct - Balancing arbor with nut and wrench - Grinding wheel balancing stand - Set of levelling elements - Oil filling

Condition: used, Year of construction: 1977, functionality: fully functional, machine/vehicle number: 7570, 1 used: JUNG Surface and Profile Grinding Machine • Model: HF 50-R(D) • Machine No.: 7570 • Year of manufacture: approx. 1977, overhauled 06-1998 • Grinding area: 500 x 200 mm • Grinding wheel: max. 250 x 25 x 51 mm EQUIPMENT: Electro-magnetic chuck 450 x 180 mm 1 straight dresser mounted on the side of the spindle head 1 grinding wheel holder with wheel 1 universal paper band filter 1 frequency converter for speed control Leveling feet Iodpfxow R Tqps Amyeat

Condition: good (used), Manufacturer: JUNG Stock number: 3018 Year of manufacture: Machine number: 4985 Type: HF 50 RD Grinding length: 500 mm Grinding width: 200 mm Clamping area table: 700 x 200 mm Magnet: 450 x 175 mm Max. table–spindle distance: 350 mm Table longitudinal travel: 1 to 24 m/min steplessly adjustable Table cross travel: 0.2 to 8 mm steplessly adjustable, automatic Grinding head vertical adjustment: 0.001 to 0.01 mm automatically adjustable Iaodpfxsw Apm Se Amyet Spindle speed: 1,000 to 4,000 rpm Grinding wheels: 225 x 20 x 51 mm Connection: 4.7 kW Accessories/Equipment: Diaform device, Heidenhain display for one axis Condition: Good Weight: 1.55 t Dimensions: 1,700 x 1,600 x 2,000 mm

Condition: good (used), Year of construction: 1987, functionality: fully functional, Jung JF 520 MS 1987 magnet 175 x 450 mm max. grinding range 600 x 220 mm variable magnetic force variable speed creep feed grinding automatic feed for plunge and surface grinding diaform Iedpfx Aeydd S Demyjat 4x grinding flange with wheel documentation machine powered for inspection.

Condition: reconditioned (used), Year of construction: 2025, grinding length: 400 mm, grinding width: 200 mm, JUNG JF415 / JF420 rebuilt mechanicaly, geometricaly und electricaly rebuilt according JUNG acceptance protocoll for new machines - retrofit with new 12“-SIEMENS-Touch-OP control - new electrical cabinet with magnetic control for chuck - plain text error codes - electro mechanical vertikal feed - dresser compensation Iaodjc S Agvjpfx Amyet - automatic lubrication unit - all numeric values (verical feed) und on/off functions e.g. hydraulic and und coolant unit over touch panel - all analog functions e.g. rpm, magnetic force and feed of Z-axis fpr direct access of the worker over switches on the control panel - 12 month warranty delivery time approx. 12 weeks max. grinding range: 400 x 200 m

Condition: refurbished (used), Year of construction: 2025, grinding length: 600 mm, grinding width: 250 mm, grinding wheel diameter: 225 mm, JUNG HF50 mechanicaly, geometricaly und elektricaly rebuilt according JUNG acceptance protocoll for new machines 12 month warranty in stock max. grinding range: 600 x 250 mm Iedpsbwl Ubefx Amyjat
