Anuba inserting machine

MASTERWOOD TEKNOMAT 2000-P

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Hedpfxsvwbp As Alweu

Condition: used, Year of construction: 2022, Machine is in perfect condition in small woodoworking shop. Hodpoy S U Duefx Alweu

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Grooving parquet machine ZEFIRO - automatic producing of the grooves on the plywood back side of parquet boards. Hodpfxsx Rrqve Alwsu Useful length 2400 mm. Entry belt conveyor included.

Condition: excellent (used), functionality: fully functional, POINT TO POINT BORING machine with CN model MASTERWOOD SPEEDY 207 second hand machine for custom furniture manufacturing, kitchen furniture, bathroom furniture, and various processes Boring head with 5 independent vertical chucks and 1 double horizontal chuck Saw for longitudinal cuts Machine table with 1390 x 750 mm boring capacity and two side jump up stops handled by the control unit to execute with only one program and one intermediate hold panels up to 2800 x 750 mm size Possibility of boring 2800 mm panels Hsdpfjwd Irvjx Alwju Pneumatic tool displacement mm 60 Max panel thickness mm 50 Spindles rotation rpm 4500 Saw rotation rpm 6000 Vacuum pump motor Hp 1,5 Vacuum cup diameter mm 80 Front stop complete with 4 locking cylinders for drilling narrow workpieces and strips Multitasking control complete with interactive graphic programming, 9" video, boring programs, optimizing working cycle, graphic, parametric, diagnostic modes Overall dimensions - Machine : mm 2500 x 1800 x 1800 h - Weight kg 850 Overall dimensions - Electric board : mm 800 x 520 x 1200 - Weight Kg 120

Condition: excellent (used), LOADER (BRIDGE-FRAME) WITH DOUBLE PICK-UP STATION Vacuum system (with its pump) N. 4 Vertical supporting columns of the top supporting beam N. 1 Horizontal top supporting beam (where the carriage slide on) N. 1 Motorized sliding carriage with horizontal metal arms N. 2 Horizontal metal arms with vacuum cups, adjustables Hodpjd Rg Dpsfx Alwou N. 2 Out-side rollers ways (on gound) to in-feed pile of panels to the Loader N. 1 Out-side motorized rollers table (which in-feed the panels to the Unloader), with also cross motorized conveyor belts (at 90°), dimensions mm 7232 (ca.) Separate electric and command panel Electronic Programmer OMRON Perimetral safety metal grids Working capacity (cycles/min) 16 - 20 (ca.) Min/Max panels thickness mm 10 - 50 (ca.) Min dimensions of the panels mm 250 x 320 (ca.) Max dimensions of the panels mm 1200 x 3200 (ca.) Total installed motor power Kw 23.3

Condition: used, Year of construction: 2016, total length: 6,400 mm, total width: 1,500 mm, total height: 1,700 mm, Weight: 1.450 kg - Year: 2016 - Documentation available: No - CE certificate present: No - Max. cutting length [mm]: 3200 - Min. saw blade diameter [mm]: 300 Hedpfxsyvh Rvo Alwju - Max. saw blade diameter [mm]: 350 - Arbor saw blade diameter [mm]: 30 - Dust extraction nozzle diameter [mm]: 120 - Spindle speed: Automatic - └ Max. spindle speed [rpm]: 4000 - Voltage [V]: 400 - Current consumption [A]: 18.5 - Fuse [A]: 25 - Transport dimensions: 6400mm x 1500mm x 1700mm (l x w x h) - Transport weight [kg]: 1450kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, machine/vehicle number: 008205, X axis working area: 4250 mm Y axis working area: 1320 mm Hsdpfjx A Th Rox Alweu Working Table: Pod and Rail Main Electrospindle power: 11 KW Number of controlled axes: 4 axes Total number of drilling spindles: 31 Total number of tool changer positions: 22

Condition: like new (used), Year of construction: 2005, I sell the vertical band saw mill Primultini SGD, Year 2005, line almost with zero working hours. Canali carriage mechanic + pneumatic. Compressor with air tank included. Sharpening workshop included. Condition like new. Available immediately. Hedpfx Alozkb R Newou

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Dimter / Weinig OptiCut 450 Quantum Optimizing Cross-Cut Saw Manufacturer: Dimter / Weinig Model: OptiCut 450 Quantum Year of manufacture: 2006 Machine description: Hodpfjyu Uriox Alwsu For sale: Dimter / Weinig OptiCut 450 Quantum optimizing cross-cut saw, year 2006, designed for high-speed and precise cross-cutting of timber with yield optimization. The Quantum version is one of the top models in the OptiCut 450 series and was developed for industrial use with extremely high output, precise positioning and reliable material transport. The machine is suitable for fixed-length cutting, defect cutting and production optimization. The OptiCut 450 series was designed for integration with scanners, sorting systems and automatic handling equipment. Typical Quantum features include VarioSpeed infeed, HighGrip feed rollers, an independent length measuring system and a servo-controlled intelligent waste gate. Technical data: - capacity: up to approx. 540 cuts/min - feed speed: approx. 300 – 415 m/min - maximum workpiece length: approx. 6.3 m - saw blade diameter: 450 mm - maximum cutting width: 235 mm - maximum cutting height: 100 mm - working height: 900 mm - motor: 7.5 kW - air consumption: approx. 1200 NL/min - cutting accuracy in the OptiCut 450 series: approx.± 0.8 mm Features / advantages: - extremely high cutting performance - high positioning accuracy - VarioSpeed system reducing gaps between boards - HighGrip rollers for secure material transport - servo-controlled waste gate - suitable for integration with scanners and sorting lines - proven Weinig / Dimter technology for continuous industrial production Condition: very good Note: Technical details may vary depending on the exact machine configuration, control version, handling equipment and installed options.

Condition: as good as new (ex-display), Year of construction: 2026, max. workpiece length 4400 mm profile spindle 1 Stück main drive 19,2 kW Control Beckhoff CNC machining center MASTERWOOD 4 WIN ----- Specially designed for a rational and flexible wooden window u. door production HIGHLIGHTS: - Different tool magazines for optimal tool loading - Simultaneous loading of 4 workpieces - Patented clamping system for optimal processing of the workpieces - CNC controlled work table with automatic positioning of beams and Hedpfx Alsyyqm Uowsu Stretcher - Automatic re-clamping for changing between external and internal profiling - INTEGRATED window construction software, i.e. the machine does not have to (but can of course) can be controlled from the office with external industry software. - strong motor with 19.2 kW HSK-63 E Please note that this stock machine is with us in Oberkochen and is already equipped with many useful options. Tools available at short notice on request! Request an offer and see for yourself unbeatable value for money! VIDEO of the machine on request! Below you will find the technical Description of the machine as a PDF document. We would be happy to sell your used machine to a pay a reasonable price! Suitable stationary or mobile suction on request! (see e.g. #5674 NESTRO NE 300) Suitable compressor on request! (#5997 Kaeser Aircenter SM 15) (technical information according to the manufacturer - without guarantee!)
