Used Ctp Computer To Plate for sale (23,380)

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2012, machine/vehicle number: 09233-K06P27, working width: 3,100 mm, stroke rate (max.): 10 1/min, sheet thickness (max.): 16 mm, distance between stands: 3,400 mm, working height: 900 mm, TECHNICAL DETAILS Sheet width: 3,100 mm Sheet thickness: 16 mm Frame gap: 3,400 mm Shearing angle: 2.5° Working height: 900 mm Backgauge: 1,000 mm Hold-downs: 14 units Strokes per minute: 10 MACHINE DETAILS Control: CYBELEC CybTouch 6 Total power requirement: 30 kW Dimensions & Weight Space required: approx. 4,150 x 2,360 x 2,450 mm Machine weight: approx. 16,400 kg Oil capacity: 500 l EQUIPMENT Electric backgauge 1,000 mm Electric cutting gap adjustment Electric cutting angle adjustment Bcedpfx Afoygw Epsheu Cutting length limitation Light barrier at rear of machine Finger guard at front Ball rollers in support table 1x side stop 2x front support arms Foot switch

Condition: used, Year of construction: 2001, - Year of manufacture: 2001 Specifications - Cutting length: 3100 mm - Capacity: 16 mm Bsdjxa Acljpfx Afhscu - Stroke: 170 mm - Strokes per minute: 10 - Oil tank: 410 l - Motor power: 37 kW - Operating voltage: 400 V - Rated current: 72 A - Main fuse rated current: 100 A - Dimensions (W x H x D): 3750 x 2400 x 3425 mm - Weight: 13800 kg

Condition: used, functionality: fully functional, Year of construction: 1998, control type: manual, degree of automation: manual, actuation type: hydraulic, number of rollers: 3, roller (top) diameter: 380 mm, side roll diameter: 340 mm, roller length: 3,100 mm, working width: 3,000 mm, working height: 900 mm, sheet thickness (max.): 30 mm, sheet thickness steel (max.): 30 mm, overall weight: 15,000 kg, total length: 5,500 mm, total width: 1,500 mm, total height: 1,600 mm, power: 22 kW (29.91 HP), input voltage: 380 V, input frequency: 50 Hz, number of digital displays: 3, Equipment: centralized greasing system, documentation/manual, emergency stop, hardened rollers, swiveling upper roller, Plate roll FW model HAV 3100X16-30 variable geometry 3-roll plate bending machine capacity 3000 x 30 mm Year of make 1998 Used machine in working condition Top roll 380 mm Side rolls 340 mm Rolls surface length 3100 mm Capacity bending Plate width 3000 mm Plate thickness 30 mm Prebend 16 mm minimum rolling diameter starting from ID 450 mm and above -configuration Bedpoydiq Sefx Afhscu -machine fully hydraulic operated -variable geometry of the 3 rolls with pinch prebend -hardened surface of the 3 rolls Rerolling system for calibration of welded plates Front open drop-end to unload the closed shell -Side arm hydraulic swing-down to align the plate in the rolls -hydraulic driven rotation of the upper roll with braking system Control console centralized electric with digital position readout Electric motor power 22Kw installed on hydraulic unit Voltage 3 phase 380/50 Safety and emergency stop installed Manuals operation and service original the machine Machine weight 15ton overall dimension cm 550 x 150 x H160 cm

Condition: excellent (used), Year of construction: 1990, overall weight: 17,500 kg, total height: 500 mm, total length: 6,000 mm, total width: 3,000 mm, plate width: 3,000 mm, Floorplate Length:6000mm Floorplate Width:3000mm Length: 6000mm Bcedoygwa Tjpfx Afheu Width: 3000mm Height: 500mm Weight: 17500kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2011, control type: NC control, number of rollers: 4, roller (bottom) diameter: 270 mm, roller (top) diameter: 290 mm, side roll diameter: 250 mm, roller length: 3,100 mm, working width: 8 mm, sheet thickness (max.): 8 mm, overall weight: 8,200 kg, total length: 6,200 mm, total width: 1,800 mm, total height: 3,900 mm, power: 8 kW (10.88 HP), Rolling width: 3100mm Rolling thickness 3x toproll Ø:10mm Rolling thickness 5x toproll Ø:14mm Rolling thickness prebending: 8mm Top Roll Ø: 290mm Bottom Roll Ø: 270mm Side roll Ø: 250mm Number of rolls: 4 Rolling speed: 1 - 5 Top support: yes Power: 8kW Length: 6200mm Bedpsygvwdsfx Afhscu Width: 1800mm Height: 3900mm Weight: 8200kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: new, neu ca. 12 Wochen ab Auftrags Türkei 39400 € 628.39 € 32900 € 2050 mm 10 mm 10 mm 8 mm 10 mm 8 mm 8 mm 6 mm 200 mm 200 mm 180 mm 6 m/min 3850 mm 1350 mm 1290 mm 3750 kg motorized roller drive upper and lower roller driven hydraulic side roll feed 3 digital displays Bcjdsyb S Aropfx Afhju hydraulic folding bearings hardened rollers conical bending device user manual in GERMAN or ENGLISH OPTIONAL EQUIPMENT: overhead crane side supports NC control variable speed

Condition: new, neu ca. 12 Wochen ab Auftrags Türkei 34900 € 555.81 € 29100 € 2050 mm 8 mm 8 mm 6 mm 8 mm 6 mm 6 mm 4 mm 180 mm 180 mm 150 mm 5 m/min 3850 mm 1350 mm 1290 mm 3300 kg motorized roller drive upper and lower roller driven hydraulic side roll feed 3 digital displays Bcsdpfsyb S Afsx Afhsu hydraulic folding bearings hardened rollers conical bending device user manual in GERMAN or ENGLISH OPTIONAL EQUIPMENT: overhead crane side supports NC control variable speed

Condition: new, neu ca. 12 Wochen ab Auftrags Türkei 20000 € 318.72 € 16600 € 1270 mm 5 mm 5 mm 4 mm Bodpfx Afsyb Sz Ujhecu 5 mm 4 mm 4 mm 3 mm 130 mm 130 mm 130 mm 5 m/min 3020 mm 1150 mm 1110 mm 2150 kg motorized roller drive upper and lower roller driven hydraulic side roll feed 3 digital displays hydraulic folding bearings hardened rollers conical bending device user manual in GERMAN or ENGLISH OPTIONAL EQUIPMENT: overhead crane side supports NC control variable speed

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 55900 € 1056.51 € 3100 mm 9 mm 8 mm 7 mm 7 mm 5 mm 245 mm 245 mm 180 mm 1,5 / 6 m/min 7.5 kW 5350 mm 1600 mm Bsdeyb Sz Ispfx Afhjcu 1470 mm 6850 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Digital read-out for lower and side rolls position Hardened rolls Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules OPTIONAL EQUIPMENT: Infinitely adustable speed of rolls Hydraulic side support Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone length can be max. 30 % oremust be more than 60 % of roll length Hardened rolls are recommended

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 46300 € 884.33 € 2050 mm 11 mm 11 mm 9 mm 9 mm 7 mm 220 mm 220 mm 160 mm 1,5 / 6 m/min 5.5 kW 4400 mm 1150 mm 1250 mm 4080 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Digital read-out for lower and side rolls position Hardened rolls Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules OPTIONAL EQUIPMENT: Infinitely adustable speed of rolls Hydraulic side support Bjdpsyb Szujfx Afhjcu Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone length can be max. 30 % oremust be more than 60 % of roll length Hardened rolls are recommended

Condition: new, Year of construction: 2024, neu 2024 9729 Bsdsyb Szhepfx Afhecu prompt, Zwischenverkauf v Türkei 28450 € 488.96 € 1 25600 € 1550 mm 7 mm 7 mm 4.5 mm 4.5 mm 3.5 mm 150 mm 150 mm 130 mm 1,5 / 6 m/min 4 kW 3750 mm 960 mm 1100 mm 2500 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Digital read-out for lower and side rolls position Hardened rolls Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules OPTIONAL EQUIPMENT: (time of deliver with options approx. 10 weeks) Infinitely adustable speed of rolls Hydraulic side support Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone length can be max. 30 % oremust be more than 60 % of roll length Hardened rolls are recommended

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 31600 € 603.56 € 2050 mm 6 mm 6 mm 4 mm 4 mm 3 mm 150 mm 150 mm 130 mm 1,5 / 6 m/min 4 kW 4250 mm 960 mm 1100 mm 2800 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Bcedpfx Afoyb Szbjhsu Digital read-out for lower and side rolls position Hardened rolls Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules OPTIONAL EQUIPMENT: Infinitely adustable speed of rolls Hydraulic side support Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone length can be max. 30 % oremust be more than 60 % of roll length Hardened rolls are recommended

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 57000 € 1077.3 € 2550 mm 13 mm 13 mm 10 mm 10 mm 8 mm 260 mm 260 mm 200 mm 1,5 / 6 m/min 7.5 kW 4800 mm 1600 mm 1550 mm 6800 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Digital read-out for lower and side rolls position Hardened rolls Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules OPTIONAL EQUIPMENT: Infinitely adustable speed of rolls Hydraulic side support Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone length can be max. 30 % oremust be more than 60 % of roll length Hardened rolls are recommended Bcjdpfx Afsyb Sy Rohou

Condition: new, neu ca. 12 Wochen ab Auftrags Türkei 26300 € 502.33 € 2050 mm 4 mm 4 mm 3 mm 3 mm 2 mm 130 mm 130 mm 130 mm 5 m/min 2,2 + 1,1 kW 3800 mm 1150 mm 1110 mm 2450 kg motorized roller drive upper and lower roller driven Bsdpfxoyb Sy Ds Afhscu hydraulic side roll feed 3 digital displays hydraulic folding bearings hardened rollers conical bending device user manual in GERMAN or ENGLISH OPTIONAL EQUIPMENT: overhead crane side supports NC control variable speed

Condition: new, neu Bcedpfxeyb Sywo Afhsu ca. 10 Wochen ab Auftrags Türkei 48100 € 918.71 € 2550 mm 9 mm 9 mm 7 mm 7 mm 5 mm 220 mm 220 mm 160 mm 1,5 / 6 m/min 5.5 kW 4900 mm 1150 mm 1250 mm 4600 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Digital read-out for lower and side rolls position Hardened rolls Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules OPTIONAL EQUIPMENT: Infinitely adustable speed of rolls Hydraulic side support Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone length can be max. 30 % oremust be more than 60 % of roll length Hardened rolls are recommended

Condition: new, neu ca. 12 Wochen ab Auftrags Türkei 25200 € Bcedpfxjyb Syqe Afheu 481.32 € 1050 mm 2.5 mm 2.5 mm 2 mm 90 mm 4,5 m/min 2.2 kW 2250 mm 1000 mm 1500 mm 900 kg FOR ROUND AND ELEPTIC SHAPES FOR MASS PRODUCTION (CYCLE UP TO ONLY 20 SEC POSSIBLE) 4 rolls NC control with touchscreen Top roll driven by hydromotor and plantary gearbox Hydraulic drop end Mobile control panel Hardened rolls Operating manual in English or German OPTION: Feeding table price on request

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 52700 € 996.03 € 2550 mm 10 mm 10 mm 8 mm 8 mm 6 mm 245 mm 245 mm 180 mm 1,5 / 6 m/min 7.5 kW 4800 mm 1600 mm 1470 mm 6170 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Digital read-out for lower and side rolls position Hardened rolls Bcsdpfx Aoyb Syksfhou Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules OPTIONAL EQUIPMENT: Infinitely adustable speed of rolls Hydraulic side support Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone length can be max. 30 % oremust be more than 60 % of roll length Hardened rolls are recommended

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 49900 € 953.09 € 2050 mm 13 mm 13 mm 10 mm 10 mm 8 mm 245 mm 245 mm 180 mm 1,5 / 6 m/min 7.5 kW 4300 mm 1600 mm 1470 mm 5450 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Digital read-out for lower and side rolls position Hardened rolls Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules Bjdpjyb Sydjfx Afhecu OPTIONAL EQUIPMENT: Infinitely adustable speed of rolls Hydraulic side support Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone length can be max. 30 % oremust be more than 60 % of roll length Hardened rolls are recommended

Condition: used, empty load weight: 7,850 kg, maximum load weight: 22,150 kg, overall weight: 30,000 kg, axle configuration: 3 axles, first registration: 04/2021, loading space length: 9,000 mm, loading space width: 2,550 mm, suspension: air, tire size: 245/70R17,5 ---/140J, color: other, gearing type: other, front tire size: 245/70R17,5 ---/140J, rear tire size: 245/70R17,5 ---/140J, driver cabin: other, emission class: none, Equipment: ABS, compressed air brake, Loading area length approx. 9,000 mm, loading height approx. 900 mm, , -- Misprints, errors and omissions excepted, sample pictures --, More data under: !, More Details: ! Bcedpfxoyfni No Afhsu

Condition: new, pressure: 150motor: 15daylight: 500stroke lenght (max.): 400table diamension: 900 x 600tappet area: 900 x 600table height: 850messurements (LxWxH): ca. 1300 + (300 Schaltschrank) x 2000 x 3200weight approx.: 8000oil filling: 400Hydraulic C-Frame PressType: C-Frame, hydraulicCapacity: Pressing force: 150 tons at 240 bar Return force: 30 tons at 150 bar Control ModesMode 1: Setup mode without light sensor Mode 2: Automatic single stroke with light sensor Hydraulic SystemMain cylinder: Ø 270 mm Auxiliary cylinders: 2 pcs Ø 70 x 40 mm Guiding columns: 4 pcs Ø 50 mm Main motor: 15 kW / 22 HP (IE3) Pump: 45 cc, 65 l/min – REXROTH Tank capacity: 500 liters Oil volume: 400 liters Auxiliary motor: 2.2 kW / 3 HP Auxiliary pump: included Oil tank air cooler: included Adjustable Speeds (via PLC)Advance stroke: 120 mm/s Return stroke: 140 mm/s Pressing phase: 13 – 5 mm/s Mechanical DataDaylight (open height): 500 mm (distance between ram and table) Stroke length: 400 mm Table depth: 650 mm Throat depth: 350 mm Table height: 850 mm (floor to top of table) Bcodpfjwzzzfjx Afheu Plate DimensionsTable plate: 900 x 600 x 120 mm (with T-slots – customizable) Ram plate: 900 x 600 x 300 mm (with T-slots & spring welding) Hydraulic AccessoriesHydraulic block & valves by REXROTH Pre-fill valve Hydraulic and mechanical ram locking at TDC Pressure & speed adjustable via PLC Side safety doors (slidable towards rear) Control & ElectronicsMain control cabinet PLC: Siemens S7–1200 Safety PLC: SICK Swiveling control panel with soft starter Mobile two-hand control Light sensors: SICK (700 mm + 130 mm) Stroke measurement: 500 mm linear scale HMI: 9 Siemens display (storage for up to 500 tools) Remote maintenance module: Secomea Dual LED work area lighting 8 free I/O ports on PLC (for external systems like robot or coil feeder) General SpecificationsPower supply: 400 V / 50 Hz Standards: Complies with EN 693 machine directive Control safety: Dual-channel secured Valves: Hydraulic proportional valves Documentation: Operating manual, parts list & maintenance plan (in German) Warranty: 12 months (optional 24 months) Paint color: Main frame RAL 7035 – light grey Dimensions & WeightOverall dimensions (W x D x H): approx. 1300 mm + 300 mm control cabinet x 2000 mm x 3200 mm Weight: approx. 8,000 kg

Condition: used, maximum load weight: 30,200 kg, overall weight: 38,000 kg, axle configuration: 2 axles, first registration: 11/2020, next inspection (TÜV): 10/2026, total width: 2,550 mm, total height: 3,900 mm, Year of construction: 2020, Equipment: ABS, 2-axle DOLL LOGO 21 with 8 bolsters First registered November 2020, from a single owner Mileage only 58,700 km Both axles with forced steering and remote control Hydraulic adjustment of the 3 rear bolsters, operated from the crane platform 2x 12 tonnes BPW axles with drum brakes WABCO Trailer EBS Length 10,715 mm Extendable from -1,800 to +4,500 mm Loading height 1,640 mm Unladen weight 7,800 kg Tires: 8x 315/80 R 22.5, tread depth 70 to 80% 8-bolt design for transporting: 4x 2-meter logs 4x 3-meter logs 3x 4-meter logs 2x 5-meter logs 2x 6-meter logs and long timber up to 21 meters 8x DOLL MAMMUT steel bolsters 16x DOLL rectangular stanchions, load capacity up to 9,000 kg per pair Full-LED lighting 4x LED work lights Central lubrication system Very good condition Bodpfx Ajydgxmefhscu RENT is the new BUY, also available for RENT IMMEDIATELY-----

Condition: used, empty load weight: 7,400 kg, maximum load weight: 22,600 kg, overall weight: 30,000 kg, axle configuration: 3 axles, first registration: 07/2023, loading space length: 9,000 mm, suspension: air, tire size: 245/70R17,5 ---/140J, color: other, gearing type: other, front tire size: 245/70R17,5 ---/140J, rear tire size: 245/70R17,5 ---/140J, driver cabin: other, emission class: none, Equipment: ABS, compressed air brake, , -- Misprints, errors and omissions excepted, sample pictures --, More details under: !, More Details: ! Bedpfxeydkure Afhjcu

Condition: new, Year of construction: 2026, Extremely powerful industrial magnet for iron separation Special price: €990 net (shipping €14.90 net) Bsdpfx Afetqfhxehjcu *Construction lengths can be found in image 2 The active side is equipped with a stainless steel end plate (material 1.4301). Threaded holes are provided on the rear side for mounting; *handle available on request The block magnet systems can be used at temperatures of up to max. +100°C operating temperature. The magnet surface should be cleaned regularly from captured iron parts. Pickup distances for all types, for example: For a steel nut M5: approx. 60 mm For an M5 x 30 screw: approx. 100 mm Mounting example 1: Mounted above a conveyor belt, 'iron parts jump onto the holding surface of the magnet.' Mounting example 2: Mounted within a pipeline system with direct contact to the material flow. For maximum separation safety, a cascade setup of multiple block magnets in series is possible. Assembly and safety instructions: When handling, already upon unpacking and later during installation, ensure that there are no loose iron parts, such as tools or screws, nearby. The magnetic force is so strong that painful injuries may occur if fingers get caught between iron parts and the active surface. There should be no steel parts under the active surface within a minimum distance of 400 mm.

Condition: used, First registration: 23/05/1980, vehicle identification number: 10628, permitted gross weight: 40,000 kg; NOTE: The low loader’s registration documents are missing. A statutory declaration of loss by the owner, required for the application of new documents at the relevant road traffic authority, is available and will be handed over to the highest bidder or buyer of the low loader! Bcjdpfxoyf R Eae Afheu

Condition: good (used), Year of construction: 2004, overall weight: 6,000 kg, total height: 245 mm, total length: 5,990 mm, total width: 1,250 mm, Floorplate Length: 6000mm Floorplate Width: 1250mm Height: 245mm No. Of T-slots: 5 Distance from T to T-slot / Jump:250mm T -slot size: 28mm Length: 5990mm Width: 1250mm Height: 245mm Weight: 6000kg Bcjdpfxoxdltus Afhju Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
