Used Multi Spindle Drilling Machine for sale (69,374)

Condition: good (used), Multi-spindle head, multi-spindle drilling head, drilling gear -Manufacturer: Romai, multi-spindle head 2 spindles -Type SMSK 2/23 -Drilling tool holder: MK3 Prsdewyuu Njpfx Airsc -min. distance drill bit: mm -Dimensions: Ø 220 x 455 mm -Weight: 27 kg

Condition: good (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: M130.67989, (Please tell us your offer price) Sale only within Europe, incl. Turkey Price without packaging; delivery condition: FCA (machine location) ===== Technical data see handout. Pedpfxozfwqnj Airorc All warranty rights are excluded. For the correctness of the technical data and year of construction, for the completeness of accessories and tool equipment, and for compliance with all safety and environmental protection requirements specified in the accident prevention regulations. No sale to private individuals. Sales only within Europe, incl. Turkey Price without packaging; Delivery condition: FCA (machine location) ===== Technical data please see handout in attachment. German text leading language. Without any guaranty and warranty, including completeness of tools & accessories as well as environmental and safety regulations. No private sales.

Year of construction: 1994, condition: excellent (used), 29 spindles maximum width of the element 168mm left / right spindles Pjdsiclfbepfx Airerc 32mm spindle spacing electric adjustment of the angle of the aggregate 4 pneumatic clamps pneumatic extension of the drilling head power supply 380V

Condition: good (used), Offered here is a multi-spindle drilling machine from Knoevenagel. Specifications: Table size: 58 x 43 cm (with a scale from 0-50 cm) The table is height-adjustable and can be tilted. VGC 18809 420 V, 4.0 A 15 spindles Prjdped Sdurofx Airjc Please refer to the images for all further information and details regarding the condition.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, AC motors for spindle speed and feed Chip conveyor No. 2 polygon milling/thread milling devices No. 1 broaching unit No. 1 threading unit No. 1 pick-up with retraction slide No. 1 deburring unit Psdpjxyghfsfx Airerc No. 1 rack milling device No. 2 wedge recesses No. 2 marking devices No. 1 carriage on 6th radial CNC axis (Siemens), with X and Z No. 2 sensors for length control of short, non-threaded or first of bar piece, with automatic discharge into bin at 4th and 8th station Giovanni Cucchi integrated bar feeder No. 1 bar elevator Tool holders

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: 173180025, empty load weight: 975 kg, working height: 50 mm, working width: 3,000 mm, working length: 3,000 mm, Equipment: CE marking, TECHNICAL DETAILS Working area, X-axis: 3,000 mm Working area, Y-axis: 3,000 mm Working area, Z-axis: 50 mm Horizontal drilling spindles: 4 MACHINE DETAILS Power of main motor: 3 kW Voltage: 400 V Current consumption: 3 A Dimensions & Weight Dimensions (L x W x H): 1,750 x 1,800 x 1,800 mm Net weight: 975 kg Podpfx Asy Tu Uieirerc Transport packages: 1 EQUIPMENT CE marking Horizontal drilling machine Vertical drilling machine Saw unit included

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, rotational speed (min.): 3,150 rpm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! The machine is sold complete with collets, holders, and additional accessories! For more Schütte multi-spindle machines from the same location, see below! TECHNICAL DETAILS Maximum turning length: 80 mm Maximum drilling depth: 80 mm Largest material passage: 32 mm Maximum bar feed: 125 mm Spindle speed (turning): 200–3,150 rpm Spindle speed (right-hand threading): 11.2–1,575 rpm Thread cutting unit: Right-hand thread via undercut MACHINE DETAILS Coolant capacity: 600 l Pump output: 170 l/min Dimensions & Weight Footprint: 7.3 x 2.5 m Prsdpfjz Ag A Iox Airjc Height: 2 m Weight: 8,300 kg Voltage: 380 V Frequency: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulating oil pump: 0.25 kW EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Holders Additional accessories

Condition: reconditioned (used), functionality: fully functional, GILDEMEISTER GS20 LATHE VARIANT 25 MM ELECTRICALLY AND MECHANICALLY REFURBISHED -REFURBISHED PNEUMATIC SECONDARY CHUCK -NEW AIR TREATMENT UNIT AND SOLENOID VALVES -RADIAL AND AXIAL SLIDES IN POS. 1-2-4-5 -WORKPIECE PICK-UP AT POS. 6 MECHANICAL OVERHAUL: 1. TURNTABLE OVERHAUL Psdpfx Aisw Sxptsrorc 2. SLIDE OVERHAUL 3. FRONT AND LEVER OVERHAUL 4. SPINDLE OVERHAUL 5. COLLET OPENING/CLOSING SYSTEM OVERHAUL 6. THREAD CUTTING UNIT OVERHAUL ELECTRICAL OVERHAUL: 1. NEW SIEMENS S71200 PLC AND SIEMENS KTP700 PANEL 2. CAM ENCODERS 3. RELAY REPLACEMENT

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, spindle speed (max.): 3,750 rpm, bar diameter (max.): 26 mm, overall weight: 6,800 kg, No reserve price – guaranteed sale to the highest bidder! The machine is sold complete with collets, toolholders, and additional accessories! For further Schütte multi-spindle machines for sale from the same location, see below! TECHNICAL DETAILS Bar diameter round: 26 mm Bar diameter square: 19 mm Bar diameter hexagonal: 22 mm Bar diameter octagonal: 24 mm Spindle circle diameter: 270 mm Prsdpfx Aoz Agy Heirjc Standard bar feed: 125 mm Special bar feed: 290 mm Longitudinal slide travel, standard total: 80 mm Longitudinal slide travel, standard working length: 63 mm Longitudinal slide travel, special total: 125 mm Longitudinal slide travel, special working length: 98 mm Cross slide travel, upper slide total: 40 mm Cross slide travel, upper slide working length: 25 mm Cross slide travel, middle slide total: 40 mm Cross slide travel, middle slide working length: 25 mm Cross slide travel, lower slide total: 50 mm Cross slide travel, lower slide working length: 31 mm Number of spindle speeds: 49 Spindle speed range I: 530–3,750 rpm Spindle speed range II: 236–1,700 rpm Workpiece revolutions per working cycle, standard: 60–425 Workpiece revolutions per working cycle, short: 33.5–236 Workpiece revolutions per working cycle, extended: 95–670 Number of main times per spindle speed: 35 MACHINE DETAILS Rated drive motor power: 18.5 kW Drive motor speed: 1,500 rpm Dimensions & Weight Dimensions with control cabinet (L x W): 3,500 x 1,450 mm Length with bar guide: 6,470 mm Machine weight: 6,800 kg Space requirement for packed machine: 14 m³

Condition: good (used), functionality: fully functional, 2 Index MS 25 E machines in very good condition and fully functional – also available individually – for sale. Pjdpozicxlsfx Airjrc Inspection while the machines are powered on is possible.

Condition: used, Multi-speed machine with flexible shaft, BIAX Type MB 4-2 Machine No. 9/50/55, Year of manufacture approx. 1970 Length of flexible shaft: 2 meters Speed: 900 - 9000 rpm, infinitely adjustable Motor speed: 3000 rpm Motor power: 1.2 kW = 1.5 hp Power connection: 380 Volts, 50 Hz - Handheld straight grinder with collet Ø 6 mm - Swiveling and rotating base - Transport trolley with 2 drawers Overall dimensions: 850 x 550 x 1100 Weight: approx. 80 kg Good condition Universally suitable for milling, grinding, and polishing operations. Pjdpfofim Tiox Airorc

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, drilling depth: 80 mm, No reserve price – guaranteed sale to the highest bidder! The machine is sold with collets, holders, and additional accessories! Prsdpfxez Ag Ans Airjc For more Schütte multi-spindle machines available at the same location, see below! TECHNICAL DETAILS Max. turning length: 80 mm Max. drilling depth: 80 mm Maximum bar diameter round: 32 mm Maximum bar diameter square: 22 mm Maximum bar diameter hexagonal: 27 mm Maximum bar diameter octagonal: 29 mm Spindle circle diameter: 300 mm Standard bar feed: 125 mm Special bar feed: 290 mm Normal longitudinal slide total travel: 100 mm Normal longitudinal slide working travel: 80 mm Special longitudinal slide total travel: 145 mm Special longitudinal slide working travel: 115 mm Cross slide upper slide total travel: 50 mm Cross slide upper slide working travel: 33 mm Cross slide middle slide total travel: 50 mm Cross slide middle slide working travel: 30 mm Cross slide lower slide total travel: 60 mm Cross slide lower slide working travel: 37.5 mm Maximum material passage: 32 mm Maximum material feed: 125 mm MACHINE DETAILS Voltage: 400 V Frequency: 50 Hz Coolant capacity: 700 l Pump: E-submersible pump Pump capacity: 180 l/min EQUIPMENT Rapid drilling device Gripper device Reaming device Independent auxiliary longitudinal control Motorized cross slide adjustment Collets Holders Additional accessories

Condition: good (used), Year of construction: 1984, Multi-spindle head, multi-spindle drill head, drilling gear -Joint multi-spindle head Predpodym D Tofx Airsc -Max. x drill -7x drill built-in collet: mm -min. Distance drill: mm -Weight: 11.3 kg Articulated multi-spindle heads are: variable tools for various machining operations such as drilling, thread cutting, countersinking, reaming, milling, turning, with which several holes can be machined at once.

Condition: good (used), Year of construction: 1984, Multi-spindle head, multi-spindle drilling head, drilling gearbox -Multi-spindle drill head with: drive -Drive geared motor SEW Eurodrive type: RF40DT80K4B -Power: 0.55 kW -Speed: 165 rpm -max. x: drill bit -4x built-in drill bits Collet: mm Podpfsdz A Tpox Airsrc -Drilling pattern can be adjusted -Dimensions: 1115/150/H300 mm -Weight: 55 kg

Year of construction: 2007, condition: good (used), ■ V600 Drilling machine (moveable drilling cabinet, executed with 1 horizontal drilling unit and automatic tool changer) ■ Drilling table with power rail length 15 metres, effective length 12 metres ■ Hardware and software (includes VACON 110 machine control) ■ Safety devices (safety bumpers) Predpfxeq Hgg Us Airsc ■ Year of construction 2007

Condition: good (used), Year of construction: 1984, Multi-spindle head, multi-spindle drilling head, drilling gearbox -Multi-spindle drill head with: drive -Drive geared motor SEW Eurodrive type: RF40DT80K4B -Power: 0.55 kW -Speed: 165 rpm -max. x: drill bit -4x built-in drill bits Collet: mm Pedpfx Aiodz A Trsrerc -Drilling pattern can be adjusted -Dimensions: 1115/150/H300 mm -Weight: 55 kg

Condition: ready for operation (used), Year of construction: 2013, machine/vehicle number: 72.122, functionality: fully functional, number of axes: 3, overall weight: 1,500 kg, spindle speed (max.): 24,000 rpm, No minimum price – guaranteed sale to the highest bidder! Prsdo Af Hgpopfx Airsc TECHNICAL DETAILS Number of controlled axes: 3 Working area X: 2,500 mm Working area Y: 900 mm Working area Z: 70 mm Milling spindle Number of milling spindles: 1 Tool holder: ISO 30 Spindle speed: 12,000–24,000 rpm Spindle speed control: Stepless Number of horizontal drilling spindles: 6 Number of vertical drilling spindles: 10 MACHINE DETAILS Voltage: 400 V Current consumption: 22 A Fuse rating: 32 A Main motor power: 4 kW Connected load: 12 kW Dimensions & Weight Dimensions (L x W x H): 2,000 x 2,600 x 2,700 mm Weight: 1,500 kg Number of transport packages: 1 EQUIPMENT Horizontal drilling unit Vertical drilling unit Sawing unit Manual operation

Condition: used, 2-spindle vertical drilling machine Prsdpfoyg Ix Tox Airjc

Condition: used, machine/vehicle number: 19170, 4-Spindle Paper Drilling Machine Ideal 504 Online-Video-Inspection by Skype-Video Podpsh Axygsfx Airorc We would be very pleased with your visit - more machines on Stock Available Immediately - Can be inspect On Stock Emskirchen / Nürnberg - Can be test

Condition: used, Year of construction: 2018, functionality: fully functional, number of spindles: 35, SECOND-HAND MULTISPINDLE DRILL WITH 35 SPINDLES MAGGI BORING SYSTEM 35 YEAR 2018 Prsdjx Rcqgspfx Airec - Center distance 32 mm.

Condition: excellent (used), functionality: fully functional, 29 spindles left/right spindles spindles span 32mm horizontal or vertical drilling setting of depth of drilling pneumtatic movement of drilling head Prsdpfxszz N S Ao Airsc

Condition: ready for operation (used), Year of construction: 1991, functionality: fully functional, bar diameter (max.): 32 mm, turning length: 80 mm, rotational speed (max.): 3,150 rpm, drilling depth: 80 mm, No minimum price – guaranteed sale to the highest bidder! The machine is sold with collets, tool holders, and additional accessories! For more Schütte multi-spindle machines from the same location, see below! TECHNICAL DETAILS Maximum bar capacity: 32 mm Maximum bar feed: 125 mm Maximum turning length: 80 mm Maximum drilling depth: 80 mm Spindle speed for turning: 200–3,150 rpm Spindle speed for right-hand thread cutting: 11.2–1,575 rpm MACHINE DETAILS Coolant capacity: 600 l Pump output: 170 l/min Dimensions & Weight Required space: 7.3 x 2.5 m Height: 2 m Weight: 8,300 kg Voltage: 380 V Frequency: 50 Hz Main drive: 20.5 kW Immersion pump: 1.5 kW Feed drive: 1.5 kW Hydraulic pump: 1.5 kW Circulating oil pump: 0.25 kW EQUIPMENT 6 cross slides 6 longitudinal slides 6 cams for cross slides 6 cams for longitudinal slides Operating tools Collets Prodpfx Aisz Agz Dorsc Tool holders Additional accessories

Condition: excellent (used), Year of construction: 1999, Drilling capacity (steel): 18mm Drilling capacity (cast): 23mm Thread cutting (steel): M14mm Spindle holder: MK 2 Spindle stroke: 100mm Extension: 250mm Column diameter: 90mm Pjdpekytxzefx Airorc Power: 0.55 kW Spindle speed: 125 – 2400 RPM / 225 – 4300 RPM

Condition: good (used), for spindle taper: MK 3 Drilling Ø: 10 mm Thread cutting: M 5 / M 8 min./max. Spindle distance: 35/120 mm Case diameter: 170 mm Case length: 218 mm weight: Prodped R Atcefx Airsc

Condition: not inspected (used), Year of construction: 1996, functionality: unexamined, machine/vehicle number: 43, turning diameter over cross slide: 32 mm, number of spindles: 6, spindle speed (max.): 3,150 rpm, bar diameter (max.): 32 mm, overall weight: 8,000 kg, TECHNICAL DETAILS Swing diameter over cross slide: 32 mm Max. spindle speed: 3,150 rpm Number of spindles: 6 Round bar capacity: 32 mm Square bar capacity: 22 mm Psdpsyybcaefx Airerc Hexagonal bar capacity: 27 mm Max. bar feed: 125 mm Max. travel long slide: 100 mm Maximum number of parts: 35 Machining speed: from 1.12 s to 125 s Spindle speeds: from 200 rpm to 3,150 rpm Number (steps): 49 Machining time: from 0.63 s to 200 s MACHINE DETAILS Voltage: 50 Hz, 3x 380 V Power: 18.5 kW Dimensions & Weight Dimensions (L x W x H): 3,850 x 1,390 x 2,200 mm Weight: approx. 8,000 kg EQUIPMENT Knoll AE 1114 high-pressure system Filtration system 5-bar and 40-bar pumps individually adjustable for processing stages Plate heat exchanger Lifting pump for chip conveyor
