Used Horizontal band saws - half-automatic - cutting range 0-300mm for sale (114)

Condition: new, capacity 90 degrees: round 350 mm capacity 90 degrees: square 330 mm 450x320 saw band length 4250x34x1,1 mm band speed 40 + 80 m/min table height 845 mm saw band width 34 mm total power requirement 2,2 kW weight of the machine ca. 0,985 t dimensions of the machine ca. 1,4 x 2,0 x 2,2 m Double miter band saw, hydraulic semi-automatic, DGS 350/450 HA-I · miter left + right 60° without machine conversion · 34 mm saw blade width · Large material support turntable, ball bearings · To position the saw blade guides using a very wide linear guide · Strong, robust transmission · Large chipboards · Infeed and outfeed roller Removable chip tray (disinfection) · Free-standing control panel, safe and ergonomic · Storage space for tapes, consumables · Cutting pressure regulator Feed regulator · Fully hydraulic vise Preload super fast (front loading) · Material height sensor (automatic cut start detection) Semi-automatic function: 1. Clamp material 2. Saw starts 3. Rapid lowering to the start of the material or the same for series cutting cut 4. Saw band off 5. Raise the frame to just above the material 6. Open the vise Optimum, material-independent cutting result through fine adjustment of the saw frame by means of: *Pressure Control Valve (Cutting Pressure Force) Celir Tisfgyicogerb *Feed Control Valve (Speed) *Switch with pictogram, easy and clear to use

Condition: good (used), Year of construction: 2004, saw band length: 2,530 mm, saw band width: 20 mm, For details see description and pictures; incl. mobile base frame and roller table Cjlirsqqh N As Tigorb incl. 3 pieces of completely new saw blades - dimensions 2540 x 20 x 0.9 mm

Condition: new, cutting diameter 250 mm saw band length 2950x27x0,9 mm table height mm band speed 36/72 m/min total power requirement 1,8 kW weight of the machine ca. 440 kg dimensions of the machine ca. m Colefg E H Njir Tigjrb Basic equipment: Vice with quick adjustment and adjustable guide bars Hydraulic band tensioning device with tensioning pressure display Base frame with removable coolant tray Chip clearing brush Precision stops set for cuts of: 0°, 45° and 60° left and 45° right Turntable for double miter cuts Electric coolant device 48 V (A micro spray device can be installed)

Condition: new, capacity 90 degrees: round 250 mm capacity 90 degrees: square 210 mm 290 x 210 mm saw band length 2.965 x 27 x 0,9 mm mm table height 940 mm band speed 25 - 90 m/min total power requirement 1,1/1,3 kW weight of the machine ca. 0,35 t dimensions of the machine ca. 1,3 x 0,8 x 1,5 m Crelirjfgyh Se Tigsb SPECIAL PRICE!!! Double miter metal band saw hydraulic semi-automatic with: - Hydraulic vice - Material height button - Cut monitoring by ammeter - Cutting pressure feed regulator - Belt speed 25 - 90 m/min - Miter cuts up to 60° left and 45° right - Patented, ball-bearing turntable for easy miter adjustment - Adjustable quick-release vise - Quick release lever - Automatic cooling

Condition: new, 900 mm 900 mm 900x900 mm saw band length 9300 x 67 x 1,1 mm table height 790 mm band speed 14 - 60 m/min total power requirement 11 kW weight of the machine ca. 8,45 t dimensions 4,485 x 1,68 x 3,15 m The semi-automatic, hydraulic saws from the X-tech line offer the best Saw technology and best performance when cutting special steels • The electro-welded machine frame and the steel saw frame meet requirements all cutting needs and eliminate vibration and noise. • The chip conveyor is hydraulically driven and the speed is adjustable • All movements of the machine (saw frame, vice, feed, Saw band guides) are carried out thanks to modern linear guides with high static and dynamic load performance, which also has very low sliding friction to guarantee. • Another characteristic feature is the roles for the Positioning of the material by a hydraulic motor are driven. They move at right angles to the material, and thus allowing optimal clamping of the material. • Thanks to the height control of the saw band position, the operator can place Cjlofg E Hpsir Tigorb the band in place near the top edge of the material. After the cut is finished, the tape automatically raised back to the previous position. Alternatively you can also “Remain” can be selected in the lower position. During the The software compares the cutting load with the cutting cycle Default. This means that the sawing system can be stopped in the event of irregularities become. • The saw band is cleaned by two adjustable steel brushes. The drive takes place hydraulically. • The hydraulic unit including filter and pressure gauge guarantees one particularly quiet operation at constant pressure. • Finely ground carbide inserts that clamp the saw blade, complete with lateral, hardened and adjustable guide rollers. The adjustable one The tape guide automatically moves as close as possible to the material. • The saw band is tensioned via a hydraulic cylinder, which is carried out by the Machine software is controlled. The voltage is set according to a given Time automatically delimbed when the machine is idle or after a cycle has been carried out. • Automatic version with CNC control in the X-TECH 900 / 1200 models a feed length of 500 mm for the series for high production rates. • The material is carried by a table with seven rollers. These will driven by a hydraulic orbital motor through which the material can be placed precisely even under maximum load. • All guided movements are carried out by four recirculating ball guides with one high capacity for static and dynamic loading; strong reduced feed friction. Tempered and ground prismatic Guides. Price on request.

Condition: new, capacity 90 degrees: round 250 mm capacity 90 degrees: square 210 mm 290 x 210 mm saw band length 2.965 x 27 x 0,9 mm mm table height 940 mm band speed 35 / 70 m/min total power requirement 1,1/1,3 kW weight of the machine ca. 0,35 t dimensions of the machine ca. 1,3 x 0,8 x 1,5 m SPECIAL PRICE!!! Double miter metal band saw hydraulic semi-automatic with: - Hydraulic vice - Material height button - Cut monitoring by ammeter - Cutting pressure feed regulator - Belt speed 34 / 74 m/min Celir Tod Iip Rjigorb - Miter cuts up to 60° left and 45° right - Patented, ball-bearing turntable for easy miter adjustment - Adjustable quick-release vise - Quick release lever - Automatic cooling Share of freight costs 120 EUR

Condition: new, cutting diameter 250 mm saw band length 2950 x 27 x 0,9 mm table height ca. 800 mm band speed 36/72 m/min total power requirement 1,5/1,8 kW weight of the machine ca. 0,37 t dimensions of the machine ca. m MEP sawing machine: Saw band bow, vice unit and base made of durable cast iron Precision grade marking on the cast iron structure Electrical system (with fully identifiable electrical wiring and Low voltage system 24 V) Switch handle IP 55 for manual cycles (if available) Rotating scraper brush for the saw band Clamping unit with vice for quick approach Accurate stops with adjustment for miter cuts at 0°, 45°, 60° left Bi-metal saw band 2950 x 27 x 0.9 mm Keys, instructions for use and instructions for ordering spare parts in the User language SHARK 281 with manual operation and SHARK 281 CCS with manual operation and Colirjfg E H Ie Tigerb cutting with automatic head feed by its own weight. CCS (Cut Control System) with (A switch for manual and automatic Cutting – B) Cutting speed regulation – C) Hydraulic brake with tank – D) End stop for stopping the belt) also optional for already produced machines available. Vice with quick adjustment Hydraulic converter for belt tension display Electric coolant pump for cooling and lubricating the saw band and manageable coolant tray above the base frame In the versions with a pneumatic vice (MA), the opening takes place and Closing the vise with a manual valve (with pedal control as option available)

Condition: new, cutting diameter 185 mm saw band length 2.085 x 20 x 0,90 mm table height 915 mm band speed 35/70 m/min capacity 90 degrees: round 185 mm capacity 90 degrees: square 150 mm capacity 90 degrees: flat 220 x 150 mm connected load frequency 400 V total power requirement 0,8 kW weight of the machine ca. 195 kg dimensions of the machine ca. 550 x 1.280 x 1.740 mm mm Metal band saw with stepless electronic speed control and automatic lowering. • Selector switch for hydraulically controlled or manual band arm lowering • Saw arm can be swiveled up to 60 ° to the right • Quick-action vice • Belt guide with 8 ball bearings • Hydraulic saw band tension with tension pressure display and band break Celirehpktrs Tigorb shutdown •Incl. Coolant system •Incl. Machine cabinet

Condition: new, capacity 90 degrees: round 250 mm capacity 90 degrees: square 210 mm 290 x 210 mm saw band length 2.965 x 27 x 0,9 mm mm table height 940 mm band speed 25 - 90 m/min total power requirement 1,1 / 1,3 kW weight of the machine ca. 0,35 t dimensions of the machine ca. 1,3 x 0,8 x 1,5 m ATTENTION SPECIAL PRICE!!! (20347) Double miter metal band saw with: - Belt speed 25 - 90 m/min - Miter cuts up to 60° left and 45° right - Ball-bearing rotary table for quick miter adjustment Crelijfgyh Rjr Tigeb - Quick-action clamping stick can be moved - Quick release lever - Automatic cooling

Condition: new, cutting diameter 220 mm saw band length 2455 mm table height 850 mm cutting width 230 mm cutting speed 25 - 80 m/min Cslod Iip Tjir Tigsrb dimensions of saw-band 2455 x 27 x 0,9 mm 90 mm 90 mm 90 x 100 mm 150 Impact energy 150 Air consume per blow 150 x 210 220 mm stroke back stop 210 mm cross-slide 230 x 185 total power requirement 1,2 kW weight of the machine ca. 0,24 t dimensions of the machine ca. 1,2 x 0,6 x 1,7 m SPECIAL PRICE!!! -Miter cuts up to 60° left - Cutting speed 25 - 80m/min. - Vice with quick release device -Carbide saw band guide -Tape tension control -Electr. automatic cooling Auto-Cut-System = 3 step system -Automatic saw frame lowering via the hydraulic cylinder -Infinitely adjustable feed -with limit switch - rapid lowering of the saw frame from the rest position to the workpiece, then switch to normal saw feed -Manual mode

Condition: new, cutting diameter 240 mm dimensions of saw-band 2730 x 27 x 0,9 mm table height 920 mm cutting speed 35 + 70 m/min 240 mm stroke back stop 230 mm cross-slide 270x230 210 Impact energy 200 Air consume per blow 200x210 130 mm 130 mm 130x160 mm total power requirement 1,2 kW Cslir Tijd Iip Ssgerb weight of the machine ca. 0,26 t dimensions of the machine ca. 0,9 x 1,6 x 1,74 m • miter left 60° • Quick-release vise with quick-release device a. • Quick release lever for easy handling • Frame and gear made from one piece, very quiet cut and very low vibration • Electrical monitoring of band tension and band breakage, saw band cover. • Carbide saw band guide • Large machine bed • Machine base (disassembled) with automatic cooling The AutoCut system consists of: Hydraulic cylinder, feed control, spring assembly, limit switch Automatic saw frame lowering via the hydraulic Cylinder, continuously adjustable feed, with limit switch at the end of the cut. Rapid lowering of the saw frame from the rest position to the workpiece, then toggle to normal saw feed (e.g. for scribing). Manual operation: The hydraulic cylinder works as a brake cylinder (e.g. for notching). Through the brake cylinder the saw can be positioned in any position during the return stroke.

Condition: new, cutting diameter 300 mm capacity 90 degrees: flat 330 x 260 mm capacity 90 degrees: square 260 x 260 mm capacity 45 degrees: flat 270 x 200 mm capacity 45 degrees: round 260 mm capacity 45 degrees: square 250 x 250 mm capacity 60 degrees: flat 170 x 170 mm capacity 60 degrees: square 170 x 170 mm capacity 60 degrees: round 180 mm turning speed range: 40 / 80 m/min dimensions of saw-band 3320 x 27 x 0,9 mm engine output 1,5 / 1,8 kW weight 670 kg Electro-hydraulic semi-automatic band saw SHARK 332 SXI EVO with semi-automatic-dynamic, manual function, has a MEP-28 control for miter cuts from 45° right to 60° left. Some features: New centralized switch console on an articulated arm. Low voltage control panel: Polyester membrane keyboard with thermoformed highlighted Push buttons and actuation control signal. Cslir Tiofg E H Usgjrb Display to show: * Diagnostics (messages in the user language) * Alarms (description of alarm causes) * State of inputs and outputs * Counting cuts * Time taken for the cut made * Current consumption of the saw blade motor * Saw blade tension * Blade speed * Numerical display of head position. Switch handle IP55 of manual 24V cycle. Complete program of all special cutting cycles. Identification of other possible special cutting cycles for special ones Applications New, latest generation hydraulic control unit, extremely powerful and with low energy consumption. Turntable (on roller bearings of 420 mm with preloaded thrust bearings assembled). Double belt speed (40/80 m/min.) with control Intended to accommodate an electronic inverter for the Continuous regulation of the belt speed from 20 to 90 m/min. Stroke of the saw bow can be programmed directly from the control panel Adaptation to the cutting material. Clamping device can be moved laterally to the left and right Quick release vice. Manually operated strap tension control with display on the screen electronic converter. Base designed to completely contain the coolant, even with maximum angle cuts. The coolant pan (provided with an electric pump for lubrication and Cooling of the saw band) and the chip drawer (can be replaced by a Chip conveyor to be replaced - see special accessories) are in the base frame built-in. Preparation for installing the minimum blade lubrication kit (Optional, in addition to the conventional standard lubrication with emulsion oil. Chip clearing brush. The machine is intended for pallet truck transport. Adjustable length stop for cuts of the same length Material support arm with roller for attaching the loading platform Bimetal saw band for solid and profile material. Tools and instructions for use in the respective user language.

Condition: new, cutting diameter 300 mm saw band length 3320 x 27 x 0,9 mm table height mm band speed 40/80 m/min total power requirement 1,5/1,8 kW weight of the machine ca. 670 kg dimensions of the machine ca. m How it works in the CCS version: After the material has been advanced and Once the vices have closed, the cutting process begins. The lowering is done by its own weight and is controlled by a spring balanced and a hydraulic brake cylinder regulates when the cut is carried out, the saw arm is moved by hand to the necessary position for the feed of the material is pushed up. Electrical panel (marked cable connection, indicator light for Ready for operation, safety main switch provided with padlock, Switch or speed switch, emergency stop, thermal magnetic protection, Low voltage system 24 volts) Electronic tape tension converter with on-screen display. Manual vice with quick lock Base frame with coolant tray and chip drawer, which has a Motorized chip conveyor (accessory) can be replaced. Cslir Tisfg E H Togsrb Electric coolant pump for cooling and lubricating the saw blade. Chip clearing brush Adjustable precision stops to make cuts of the same length. Machine is intended for pallet truck transport. Bimetal saw band for solid and profile material Tools and instructions for use

Condition: new, cutting diameter 250 mm capacity 90 degrees: flat 280 x 220 mm capacity 90 degrees: square 220 x 220 mm vice 285 mm turning speed range: 36/72 m/min dimensions of saw-band 2950x27x0,9 mm total power requirement 1,5 / 1,8 kW weight of the machine ca. 485 kg dimensions of the machine ca. 1700 x 1000 x 1800 mm Electro-hydraulic semi-automatic band saw SHARK 282 SXI EVO with semi-automatic-dynamic, manual function, has a MEP-28 control for miter cuts from 45° right to 60° left. Semi-automatic function: At the start of the cycle: - Vice closes and motor starts – Saw head lowers for the cut – Motor switches off – Saw head rises – Vise opens. Semi-automatic dynamic system (manual lowering of the saw band bow up to to the desired position and cycle start via the manual button.) Some features: New centralized control console on an articulated arm to allow the operator can be easily switched from any working position. Low voltage control panel: Polyester membrane keyboard with thermoformed highlighted Push buttons and actuation control signal. Display to show: * Diagnostics (messages in the user language) * Alarms (description of alarm causes) * State of inputs and outputs * Counting cuts * Time taken for the cut made * Current consumption of the saw blade motor * Saw blade tension * Blade speed * Numerical display of head position. Switch handle IP55 of manual 24V cycle. Complete program of all special cutting cycles. Identification of other possible special cutting cycles for special ones Applications New, latest generation hydraulic control unit, extremely powerful and with low energy consumption. Large work surface with turntable on roller bearings, measuring 265 mm preloaded thrust bearing, mounted. Double belt speed (36/72 m/min.) with control Intended to accommodate an electronic inverter for the Continuous regulation of the belt speed from 20 to 90 m/min. Stroke of the saw bow can be programmed directly from the control panel Adaptation to the cutting material. Clamping device can be moved laterally to the left and right Quick release vice. Manually operated strap tension control with display on the screen electronic converter. Base frame with pull-out coolant tray. Celir Tisfg E H Ssgsrb Electric coolant pump for cooling and lubricating the saw band. Preparation for installing the minimum blade lubrication kit (Optional), in addition to the conventional standard lubrication Emulsion oil. Chip clearing brush. The machine is intended for pallet truck transport. Length stop for cuts of the same length Material support arm with roller for attaching the loading platform Bimetal saw band for solid and profile material. Tools and instructions for use in the respective user language.
