Bästlein Gebrauchtmaschinenhandel GmbH

Condition: excellent (used), Functionality: fully functional, Year of construction: 2019, Storage Compartments. Quantity: 32 (8 per level) Dimensions (Trapezoidal): 720 (335) x 470 mm Maximum loading height: 8 x 350, 280, 275, 140 mm Load capacity per compartment: 125 kg Control unit: Power Panel PP520 Machine dimensions: 2700 x 2200 x 2700 mm Machine weight approx.: 4,500 kg Standard Equipment 32 storage compartments for up to 160 linear meters of bending tools The compact design allows bending tools or accessories to be stored dust-free and protected on four levels. Each level accommodates eight compartments, each of which can safely store up to 5 linear meters of tool per compartment, thanks to special tool holders. The maximum storage capacity is therefore 160 linear meters of bending tools within a 5.9 m² footprint. The ToolShuttle can be combined with all standard bending machines. Drive with maintenance-free servo motors The ToolShuttle is powered by energy-efficient servo motors with planetary gears and gear ring (rotational movement) and spindle drive (vertical movement). The combined control of rotational and vertical movement enables fast access times to all storage compartments. Easy and intuitive touch operation Selection of the compartments is managed via the integrated control unit. The compartment allocation can be individually configured and programmed. Central input/output station Loading and unloading of compartments is carried out at a central station, eliminating the need for time-consuming tool searches. Operator safety is ensured by an automatically opening window. Ergonomic storage compartments Thanks to special tool holders, the tools are stored in setup position. Ball bearings allow compartments to be moved easily and without effort, even with a maximum load of 125 kg each. (Includes lower tool holders (wood) for 16 compartments. Upper tool holders can be custom manufactured by the customer using the supplied DXF/GEO files. Different tool holders may be required depending on tool type.) Lower tool holders (wood, 16 pieces) Ergonomic storage compartments including lower tool holders (wood) for 16 compartments. Upper tool holders can be custom manufactured by the customer using the supplied DXF/GEO files. Different tool holders may be required depending on tool type. Transfer carriage The transfer carriage enables direct supply of up to two machines from the ToolShuttle. This eliminates all logistical effort; tools can be conveniently set up directly at the tool clamp. Carrying tools to the machine or using tool trolleys is a thing of the past. Two compartments can be supplied to the machine in a single operation. USB interface - The machine control system is equipped with a standard USB port. Optional Equipment Initial equipment tool holders for upper tools Ielhewz Ezpscdw Deaw Special foam tool holders ensure gentle storage of the upper tools. The initial set includes four different holder types for a total of sixteen compartments. Depending on the type, between 1.8 and 2.9 meters of upper tools can be stored per compartment. Set contains: 4 x type 1, 3 x type 2, 3 x type 3, 2 x type 4, 2 x type 5, and 2 x type 6.

Condition: new, Functionality: fully functional, Year of construction: 2025, pressing force: 180 t, Pressure: 180 t Bending length: 3100 mm Frame width: 3100 mm Control: Cybelec CybTouch 15 Stroke: 250 mm Installation height: 470 mm Rapid approach (down): 180 mm/s Ielhcdswz Et Sjw Djaw Bending speed: 0-10 mm/s Rapid return (up): 165 mm/s Total power requirement: 15 kW Machine weight approx.: 14,000 kg Dimensions: 4255 x 2390 x 3030 mm Standard equipment: - CNC control Cybelec CybTouch 15 Windows - 4 + 1 axes: Y1, Y2, X, R, C - Mechanical crowning system: B-CM - Backgauge system mod. GHP-2 - Servo-driven main motor - Safety system: DSP AP+MCS Additional equipment: - 2 x front support tables - 2 x stop fingers - Hydraulic upper tool clamping Wila Style - Hydraulic die clamping Wila Style - CE standard norm

Condition: used, Year of construction: 2008, operating hours: 11,800 h, turning length: 705 mm, turning diameter: 356 mm, spindle bore: 91 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 260 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 795 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 10,000 m/min, rapid traverse Z-axis: 30,000 m/min, bar diameter: 80 mm, Turning diameter: 356 mm Turning length: 705 mm Control: MSX-850 Swing diameter over bed: 923 mm Swing diameter over cross slide: 755 mm Travel path - X: 260 mm Travel path - Z: 795 mm Travel path - Y: 100 mm Spindle speed: 4,000 rpm Bar diameter: 80 mm Spindle bore: 91 mm C-axis: 0.001° Rapid traverse X/Y/Z: 30,000/10,000/30,000 mm/min Machine weight approx.: 6,100 kg Accessories/Equipment: Clamping unit Kitagawa BB210A821 + Kitagawa SS1881K21 Iaelhcewykppodw Dew * Power chuck for main spindle, consisting of: - Hydraulic 3-jaw through-power chuck, type: Kitagawa BB210A821, Ø 254 mm, through-hole 81 mm, max. speed 4,500 rpm, including mounting components and a set of soft jaws - Draw tube for max. bar diameter of 80 mm - Hydraulic hollow chuck cylinder, type Kitagawa SS1881K21, through-hole 81 mm - Anti-rotation device and clamping stroke monitoring Double foot switch with protective cover for main spindle - Foot switch for actuating the chuck on the main spindle, version with two pedals instead of the standard single pedal Integrated quill bearing (MT 3) Coolant system with increased pressure 5 bar Hinged belt chip conveyor, right discharge side - Hinged belt chip conveyor with rollers, version for right-hand machine side, approx. 1,000 mm discharge height, including control adaptation Integrated parts catcher for main spindle I/F for bar feeder - Preparation for connection of a bar feeder or a bar loading magazine Total counter Workpiece counter - Signal light (red, white, green)

Condition: used, Year of construction: 2017, travel distance X-axis: 1,020 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 610 mm, controller manufacturer: HEIDENHAIN, controller model: TNC 640, table width: 600 mm, table length: 1,200 mm, rotational speed (max.): 12,000 rpm, overall weight: 7,100 kg, X travel 1020 mm Y travel 610 mm Z travel 610 mm Iaslhcdwswx H Tuo Dew Spindle speed 12,000 rpm Table size 1200 x 600 mm Control TNC 640 Taper ISO 40 Machine weight approx. 7,090 kg Dimensions 2800 x 2760 x 2860 mm

Condition: used, Functionality: fully functional, Year of construction: 2006, operating hours: 10,920 h, control type: CNC control, controller manufacturer: TRUMPF, controller model: TASC 6000, bending force (max.): 50 t, working width: 1,275 mm, bending length: 1,275 mm, stroke distance: 215 mm, throat depth: 420 mm, distance between stands: 1,040 mm, installation height: 385 mm, overall weight: 4,900 kg, Standard equipment: - Robust machine frame in all-steel welded construction - High bending strength press beam - Electrohydraulic upper drive via proportional valves - Modern block hydraulic system Iajlhcdewwrt Rsw Dew - CNC backgauge with rack and pinion drive for X and R axes - Safe adjustment of backgauge fingers from the front - Upper tool clamping system "New Standard Clamping II", manual - Lower tool holder for EV dies, hydraulic clamping, programmable displacement (2 positions) - Control unit TRUMPF TASC 6000 - Safety device consisting of side and rear safety doors - Control cabinet with climate control - Network-capable Optional equipment: - 2 additional clamp-on backgauge fingers - Hydraulic upper tool clamping - Bendguard - Rear roll-up safety cover - Support console - Preparation for ACB

Condition: used, Functionality: fully functional, Year of construction: 2007, operating hours: 4,755 h, control type: CNC control, controller manufacturer: TRUMPF, controller model: TASC 600, bending force (max.): 230 t, working width: 3,230 mm, stroke distance: 445 mm, distance between stands: 2,690 mm, installation height: 615 mm, overall weight: 16,400 kg, Standard equipment: - Robust machine frame as an all-steel welded construction - High bending strength pressing beam - Spherical mounting of the pressing beam with inclined positioning - Electrohydraulic top drive with 4-cylinder technology - Proportional valve technology and selectable double pump - Modern modular hydraulics with control valves mounted on the cylinder - Electronic pressure scale - Measuring system with centrally mounted glass scales and temperature compensation - Manually integrated wedge crowning in the table - Upper tool clamping system "New Standard Clamping", manual, hardened, self-centering, for vertical tool change - Lower tool clamping with hydraulic clamping, hardened - Programmable lower tool shifting (pneumatic, 2 positions) - 2-axis backgauge system with rack-and-pinion drive for X and R axes - 2 backgauge fingers with safe adjustment from the front - Machine control TRUMPF TASC 6000 - Control panel with LCD keypad, foot switch, emergency stop and emergency off - Safety equipment: integrated side doors and automatic rear rolling cover - Control cabinet cooling (air-to-air heat exchanger) - Oil cooler - Network capable Iolowwih Eshcdw Deaw Special equipment: - 5-axis backgauge system - Hydraulic upper tool clamping - CNC-controlled crowning - CNC lower tool shifting - BendGuard - Foot switch - Support console - Bending aid first arm - Table extension - Table widening - Short parking position (190 mm) - Preparation for ACB

Condition: good (used), Functionality: fully functional, Year of construction: 2001, Pressing force 175 t Iaolhcdjwvkz Dew Djw Bending length 4050 mm Distance between uprights 3550 mm Oil capacity 300 l Control system CYBELEC DNC 1200 PS Total power requirement 15 kW

Condition: new, Year of construction: 2025, Functionality: fully functional, Table length: 2000 mm Table width: 1000 mm Table height: 200 mm Bore diameter: 28 mm Bore pattern on surface: 100 x 100 mm Iaolhcdjwvkiusw Dew Material thickness: approx. 24.5 - 27 mm Side panel height: 200 mm Working height: 850 mm Weight: 850 kg Product description: Siegmund Retro offer incl. accessories: Welding table as 25 years ago, additionally with plasma nitriding and current table legs - High-quality steel S355J2+N + plasma nitriding - Boreholes in side panel in diagonal grid - Corners, edges, and holes chamfered at 45° - Construction reinforced with ribs - Incl. basic feet (working height 850 mm) Accessories: - 6 x Professional clamp, nitrided - 12 x Quick release bolts, double blackened, without slot - 8 x Universal stop 225 L, nitrided - 2 x Stop and clamping angle 175 L, nitrided - 2 x Stop and clamping angle 500 G, nitrided - 1 x accessory set - Eccentric stop Ø 60 with M10 thread, nitrided - Allen key size 6 - Brush Ø 30 with protective cap - CleanBasic 1 litre in spray bottle - Anti-spatter agent 1 litre in spray bottle - Torch holder, blackened

Condition: new, Year of construction: 2025, Functionality: fully functional, Table length: 2400 mm Table width: 1200 mm Table height: 200 mm Bore diameter: 28 mm Bore grid top: 100 x 100 mm Material thickness: approx. 24.5 - 27 mm Side panel height: 200 mm Working height: 850 mm Iajlswvkh Dehcdw Dow Product description: Siegmund retro special offer incl. accessories: Welding table as built 25 years ago, additionally upgraded with plasma nitriding and current-generation table legs. - High-grade steel S355J2+N + plasma nitriding - Side panel bores in diagonal grid - Corners, edges and bores chamfered at 45° - Rib-reinforced construction - Includes base set of legs, height 650 mm Accessories: - 6 x Professional screw clamps, nitrided - 2 x stop and clamping brackets 175 L, nitrided - 10 x quick-release bolts without groove, double blackened - 8 x universal stops 225 L, nitrided - 2 x stop and clamping brackets 500 G, nitrided - 1 x accessory set

Year of construction: 2025, Condition: new, Functionality: fully functional, borehole diameter: 28 mm, Table length 3000 mm Table width 1500 mm Table height 200 mm Drilling diameter 28 mm Ielswvkgtshcdw Deaw Material thickness approx. 24.5 - 27 mm Side panel height 200 mm Weight approx. 1,553 kg >>> ANNIVERSARY OFFER

Condition: good (used), Functionality: fully functional, Year of construction: 2003, Pressure: 225 t Bending length: 2050 mm Distance between uprights: 1550 mm Control: CYBELEC DNC 1200 PS Eco Stroke: 550 mm Table height: 700 mm Throat depth: 405 mm Distance table/ram: 320-870 mm Frame throat depth: 405 mm Machine weight approx.: 14,000 kg Accessories/Equipment: - Controlled axes: Y1 - Y2 - X - R - Z1 and Z2 manually adjustable Iaelowvi Uvshcdw Djw - Lasersafe angle measurement - Pneumatically adjustable support table - Pneumatic upper and lower tool clamping - Two-hand foot pedal operation - Manual crowning

Condition: excellent (used), Functionality: fully functional, Year of construction: 2024, working width: 1,020 mm, bending length: 1,020 mm, operating speed: 5 mm/s, overall weight: 2,100 kg, total length: 2,200 mm, total width: 1,000 mm, total height: 2,300 mm, power: 7.5 kW (10.20 HP), pressing force: 100 t, Equipment: lower tooling, upper tooling, Pressure: 100 t Bending length: 1020 mm Stroke: 300 mm Working speed: 5 mm/sec Iajlhcdwowuqrmj Dow Table size: 500x1020 mm Total power requirement: 7.5 kW Machine weight approx.: 2,100 kg Space requirement approx.: 2200x1000x2300 mm

Condition: good (used), Year of construction: 1998, Pressing force: 220 kN Maximum sheet thickness: 6.4 mm Travel path - X: 2000 mm Travel path - Y: 1250 mm Positioning speed X-axis: 90 m/min Positioning speed Y-axis: 60 m/min Positioning speed simulation: 108 m/min Ielhcdswub S Rsw Dsaw Positioning speed rotary axis: 360 °/sec Punching diameter: 76.2 mm Workpiece weight: 150 kg Smallest programmable travel increment: 0.01 mm or 0.01° Tool stations: 15 pcs Tool change time: 1.5 - 6.5 sec Machine weight approx.: 11,050 kg Dimensions: 6400 x 5800 x 2100 mm Operating hours: 30,430 h

Condition: good (used), Functionality: fully functional, Year of construction: 2002, Sheet width: 4000 mm Sheet thickness: 2.5 mm Frame gap: 4060 mm Stroke: 300 mm Total power requirement: 3 kW Iolhcowub N Nedw Djaw Machine weight approx.: 5,500 kg

Condition: good (used), Year of construction: 2021, Belt dimensions 8000x150 mm Workpiece width - max. 150 mm Workpiece length - max. 8000 mm Grinding speed 4.5 - 27 m/sec Iolhcdwewqfbno Dsaw Sanding shoe dimensions 270 x 150 mm Table load max. 100 kg Table height adjustment 540 mm Total power requirement 3 kW Machine weight approx. 530 kg Dimensions 4500 x 1300 x 1450 mm Accessories: - Extraction - Work table dimensions: 3000x800 mm - Dimensions: 4500x1300x1450 mm - Weight: 530 kg Accessories: - Extraction - Work table dimensions: 3000x800 mm - Dimensions: 4500x1300x1450 mm - Weight: 530 kg

Condition: good (used), Functionality: fully functional, Year of construction: 1999, with control conversion to CYBELEC Visitouch 19 Pressure 125 t Bending length 4050 mm Frame width 3550 mm Throat depth 300 mm Iaolhjwqfaqocdw Dsw Installation height 560 mm Stroke 240 mm Back gauge - adjustable 5-1000 mm Control CYBELEC Visitouch 19 Dimensions L-W-H 5200x2200x3000 mm Total power requirement 18.5 kW Machine weight approx. 14,500 kg Equipment: - front bending aid - back gauge with 8 stop fingers - AKAS laser safety device in front of the machine - V-die block - segmented - upper tool - die shifting - two-hand operation - manual crowning - pneumatic upper and lower tool clamping

Condition: used, Year of construction: 1999, Press force 230 t Bending length 3060 mm Distance between uprights 2690 mm Stroke 365 mm Control DELEM DA 66 T Distance between posts 2690 mm Dimensions 3660 x 2310 x 3100 mm Machine weight approx. 17,700 kg Equipment: - 2-hand foot switch Iaolhcdwswn Efuo Dew - Side safety doors - Safety door behind the machine - Control renewed in Delem DA 66 T

Condition: used, Year of construction: 2002, Pressure 250 t Bending length 3550 mm Frame width 3000 mm Ijlhcdwjwn Ebio Djaw Control Cybelec DNC 1200 Machine weight approx. 18,500 kg Space requirement approx. 4300x2750x3750 mm Accessories: - 2-hand foot switch - Lasersafe Fisseler - Hydraulic tool clamping top and bottom - Die shifting - Hydraulic crowning - Support arms - Control Cybelec DNC 1200 - 1 set of upper and lower tools - Controlled axes y1, y2, x, r, z1, z2, back gauge tilt - Safety guard

Condition: good (used), Year of construction: 1998, Machine weight approx. 3,500 kg Space requirement approx. 4700x1800x2000 mm Dry deburring system RÖSLER RT 250 EURO (Year of construction: 1998) Wet grinding system with lid RÖSLER R 320 EC (Year of construction: 1998) Process water recirculation system RÖSLER Z 500 HA-TURBO-FLOC (Year of construction: 1998) Centrifuge RÖSLER Z 800 (Year of construction: 2014) Ielhcdewn Ea Sow Doaw

Condition: good (used), Year of construction: 1989, Pressure 50 t Bending length 2050 mm Weight approx. 7,000 kg Accessories: Ielhcdswn Earow Dsaw -Foot pedal -Hydraulic upper tool clamping -2 manual movable backgauge fingers -Tools -Controlled axes: y1, y2, X, R -Controller Cybelec DNC 60

Condition: used, Year of construction: 2008, Pressure 130 t Bending length 3200 mm Folding column width 2690 mm Maximum stroke 445 mm Operating hours approx. 49,794 h Ielswgk Hnohcdw Deaw Total power requirement 24 kW Machine weight approx. 10,900 kg Equipment: – Trumpf Tasc 6000 control system – 2 support arms in front of the machine – Foot switch – Laser safe Operating hours: Machine on: approx. 49,794 h Hydraulics operating time: approx. 31,087 h Press beam operating time: approx. 4,655 h Crafter operating time: approx. 313 h

Condition: used, Year of construction: 2005, Pressure 230 t Bending length 4250 mm Column clearance 3680 mm Thrust 420 mm Ram stroke 445 mm TASC 6000 control system Machine weight approx. 19,200 kg Accessories/equipment: Islswgk E Dshcdw Doaw – 2 support arms – 1 bending aid – 2 stop fingers – Light barrier in front of the machine – Foot switch

Condition: used, Year of construction: 1988, Drilling capacity in steel St 60 28 mm Drilling capacity in cast iron GG 20 35 mm Drilling capacity in St 60 35 mm Spindle mount MT 3 Throat 290 mm Quill stroke 160 mm Table stroke 592 mm Column diameter 115 mm Clamping area 510 x 300 mm Iajlhcdwewgkyuj Djw Spindle speed 130-1750 rpm Machine weight approx. 400 kg

Condition: used, Year of construction: 2003, Cutting range at 90 degrees: round Ø 335 mm Iolhowgktujcdw Deaw Cutting range at 90 degrees: flat 500 x 335 mm Saw blade length 4400 x 34 x 1.1 mm Cutting speed 18-115 m/min Lowering speed 0 to 300 mm/min Working height 750 mm Machine weight approx. 1,550 kg Space requirement approx. 2230 x 2350 x 1900 mm Accessories/equipment: Bundle clamping range: – Width: 0 – 500 mm – Height: 15 – 335 mm Material feed: – Single: 0 – 600 mm – Multiple: 0 – 6000 mm Remnant length: Manual: approx. 70 mm Automatic: approx. 110 mm

Condition: used, Year of construction: 1996, Max. punching force: 55 tons Notching: 10 mm Hole diameter and thickness: 40x10 mm Flat steel: 300x15 or 200x20 mm 90° angle steel: 120x120x10 mm 45° angle steel: 70x70x7 mm Bar steel: 40 mm Square steel: 40 mm Strokes per minute with a 20 mm stroke: 37 /min Throat: 250 mm Iajlewgkq Tehcdw Dew Machine weight: approx. 1,800 kg
