Condition: like new (used), Year of construction: 2010, Haas Multigrind CB multi axis CNC grinder, 12 station, Siemens Sinumerik 840D control, load / unload, LTA industrial air cleaning unit, (2010) B8D9P23Dv0 Full machine specification can be seen on the photographs or can be seen sent via email.

Condition: like new (used), Year of construction: 2012, 12 station, Siemens Sinumerik 840D control, load / unload, VAS air cleaning unit, (2012) B8D7Uiq8Vg Full machine specification can be seen on the photographs or can be seen sent via email.

Condition: like new (used), Year of construction: 2022, General Specifications: • Swing Over Bed: 550 mm (21.65 inches) • Max. Cutting Diameter: 300 mm (11.81 inches) • Max. Cutting Length: 300 mm (11.81 inches) • Chuck Size: 6 inches • Machine Weight: Approximately 3,200 kg Axis Travels: • X-Axis Travel: 170 mm (6.69 inches) • Z-Axis Travel: 335 mm (13.19 inches) • Rapid Traverse Rates: 36 m/min (X and Z axes) Spindle: Drdbw9 • Spindle Speed: Up to 6,000 RPM • Spindle Motor Power: 11/7.5 kW • Spindle Nose: A2-5 • Spindle Bore Diameter: 56 mm (2.20 inches) • Bar Capacity: 45 mm (1.77 inches) Turret: • Number of Tool Positions: 12 stations • Turret Type: BMT-55P • Indexing Time (1 face): 0.15 seconds Additional Features: • Slant Bed Design: 45-degree slant bed for enhanced rigidity and chip disposal • High-Rigidity Linear Guideways: Ensures precision and durability • Compact Footprint: Optimized for space-saving without compromising performance

Condition: excellent (used), Mantech 40Ton x 2000mm Pressbrake Year 2020 Nominal Force – 400KN Workable length 2000mm Vertical column distance 1800mm Throat depth 200mm Stroke 100mm Max open height 340mm Stroke adjustment 80kg Motor power 4Kw Net weight 3300kg Dimensions 2550 ( Length )x 1500 (width) x 2200mm (height) With Tooling & Manuals Br2Eqd0O2W

Condition: excellent (used), FOR SALE - Jones & Shipman Ultramat 650 Easy Year 2006 Angle approach Grinder Ultramat Easy Grind GE Fanuc Powermate motion control Number of axes controlled 2 Maximum length between centres 650mm Centre Height 190mm - Raised Maximum workpiece weight between centres 100kg Wheelslide (X axis) Total infeed 260mm Maximum traverse speed 6m/min Maximum programmable diametrical infeed rate per min 100mm Minimum programmable increment dia 0.001mm Electronic Handwheel increments 0.001, 0.01, 0.1mm Tableslide (Z Axis) Maximum stroke length - 750mm Maximum traverse speed 12m/min Minimmum programmable increment 0.001mm Electronic handwheel increments 0.001, 0.01, 0.1mm Table swivel clockwise 16° / anticlockwise 18° Wheelheads Swivelling (Universal) Grinding wheel 350mm Dia Maximum Left Hand - width 50mm Bore- 127mm Wheel speed 33m/s Motor power 4kW Grinding wheel Diameter Max 300mm Right hand width 25mm Bore 127mm Wheel speed 33m/s Motor power 4KW Workheads Dead centre fixed base (standard) Speed range, continuously variable, rpm 0-660 Spindle taper 5MT Drbzrv Output torque, (continous rating) 27Nm Motor power 1.1kW Tailstocks Plain tailstock (standard) Poppet diameter 50mm Poppet taper 3MT Centre travel 30mm Poppet pressure, adjustable 60-410N Approx weight 5300kgs

Condition: good (used), Great Condition X Travel - 650mm Y Travel - 230mm Z Travel - 350mm Table Length - 550mm Table Width - 200mm Dimensions - L2405mm x W1800mm x H1800mm Weight approx 2500kgs 3 Phase Bndi2Tgg7C

Condition: good (used), Year of construction: 2012, Excellent Machine Under power & still working Bm9087T8Yg Year 2012

Condition: good (used), Year of construction: 1990, Lumsden 92ML Rotary Surface Grinder 48" Magnetic Chuck Year 1990 - Latest ones made Segmental wheel diameter - 711mm / 28" Segments per set - 12 Table diameter and grinding capacity - 1219mm / 48" Dq72Cz Max height of wheel to table - 572mm / 22.5" Min height of wheel to table - 114mm / 4.5" Max height of wheel to magnetic table - 457mm / 18" Spindle speed 550rpm Table speeds - 18 & 6 rpm Automatic feed 10 rates - 0.1 - 1.0mm/min (0.004 - 0.040 ins/min) Power elevation - 635mm/min (25ins/min) Spindle motor - 50-75hp at 960rpm Table motor - 6 /.5hp at 1440/480rpm Feed motor - 0.25hp at 1440rpm Elevation motor - 1hp at 720rpm Coolant pump motor - 1hp at 1440rpm Overall height of machine - 3048mm Floor space 4394 x 3353mm Weight approx 12,200kgs / 12ton

Condition: like new (used), Year of construction: 2016, Ajax AJUM 350 Horizontal Milling Machine Excellent condition - Like new! With Arbor & support arms Dqwosl DRO Pendant control Year 2016 Manuals

Condition: excellent (used), Year of construction: 1997, Europa Centurion CU5 Ram Type Milling Machine (Like Huron) Excellent condition - we welcome any inspections! Year 1997 Specification - Table size 1635 x 460mm No of T Slots 5 Width of T slots 18mm Distance between slots 80mm Longitudinal travel 1300mm Vertical travel (knee) 440mm Cross Travel (ram) 650mm Min Spindle nose to table surface 40mm Spindle Taper 50INT No of spindle speeds 27 Spindle speed range 30-2050rpm Qalsqgrro Longitudinal powerfeed 10 - 1000mm/min Cross powerfeeds 10- 1000mm/min Vertical powerfeeds 5 - 500mm/min Longitudinal rapid feed 2800mm/min Cross rapid feed 2800mm/min Vertical rapid feed 1400mm/min Spindle motor 7.5kW Max Table load 1800kgs Dimensions - L 2010mm x W 2621mm x H1950mm

Condition: good (used), Year of construction: 2006, General Data Measurements width 2610 Measurements depth 3270 Measurements height 2240 Machine weight 2600 Control Unit Brand FANUC Model System 16-WB Main Drive Max taper angle ± 30 degrees/80 mm (option ± 45 degrees/40 mm) Number of axis 5 Movement X-Axis Movement 520 mm Y-Axis Movement 370 mm Z-Axis Movement 300 mm (275 mm in water bath) U-Axis Movement ± 60 mm W-Axis Movement ± 60 mm Workpiece Workpiece X 790 mm Workpiece Y 730 mm Workpiece Z 275 mm Workpiece weight 650 kg (with coaxial spindle), 450 kg (with water bath) Table Outer length 750 mm Bsg8Qfdp8A8 Outer width 590 mm Additional Equipment Bedra wire unwinding device BAS 45/100E (to the left of the machine), capable of handling wire spools weighing up to 45 kg This 5-axis FANUC Robocut Alpha 1C erosion machine was manufactured in 1997. It features a coordinate travel of 520 x 370 mm on the X and Y axes, and a Z-axis adjustment of 300 mm. The machine can handle a maximum workpiece weight of 650 kg and offers a rapid traverse of 900 mm/min. Ideal for precision erosion tasks, the FANUC Robocut Alpha 1C machine we have for sale. Contact us for further details regarding this erosion machine.

Condition: excellent (used), Year of construction: 2006, Ercolina CML TB-76 Pipe Bender Hx3Jwzl Excellent condition Year 2006 Foot Pedal Weight 193kg Power supply - 415v/3 phase

Condition: excellent (used), Year of construction: 2014, Perfect PFG-50 150AHR Surface Grinder Year 2014 Fully working condition. We welcome any inspections to view this machine demonstrating. Grinding surface of table - 500 x 1500mm Max distance centre of spindle to table - 600mm Total max safety load weight - 1200kgs Table guideway - V & Flat way Bsczd7Cb9Yy Wheel dimension - 405 x 50 x 127mm Spindle motor - 10HP Machine net weight - 7200kgs Floor space - 4800 x 2300 x 2040mm

Condition: excellent (used), Jones & Shipman 624 Dominator CNC Surface Grinder Under power and working. Can be shown demonstrating at our premises in Burscough Fanuc Series 210i-M CNC Control Br309Spwdpg Table Length 600mm x 200mm width Wheel diameter 250mm Wheel width 25mm Max wheel speed 3200rpm Spindle power 5.6kw

Condition: good (used), Butler 5m CNC Elga Mill Model DR12VA with Rail CNC Control Heidenhain 320 TNC - current model Brvk2Hq0Pmy Table 5000mm x 1200mm ( Plus one bed extension piece ) Longitudinal Travel 3300mm Vertical Travel 1675mm Spindle Taper 50 ISO Spindle speeds 2 - 2000rpm

Condition: good (used), 60" Table Complete with coolant tank and sizing Specification - Segmental wheel diameter - 864mm / 34" Segments per set - 16 Table diameter and grinding capacity - 1524mm / 60" Magnetic Table diameter - 1524mm / 60" Max. height of wheel to table - 272mm / 22.5" Min. height of wheel to table - 114mm / 4.5" Spindle speed - 450rpm Table speeds - 16 &5.5rpm Automatic feed 10 rates - 0.1-1.0mm/min (0.004-0.040ins/min) Power elevation - 635mm/min (25ins/min) Spindle motor - 60-100h.p at 960rpm Table motor - 6/2.5h.p at 1440/480rpm Feed motor - 1/4h.p at 1440rpm Elevation motor - 1hp at 720rpm Coolant pump motor - 1hp at 1440rpm Overall height of machine - 3073mm/ 10.1" Floor space - 4394mm/14.5" x 3607mm / 11.10" Cw7Cpktv Approx weight - 16700kgs

Condition: excellent (used), Year of construction: 2015, travel distance X-axis: 1,270 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 508 mm, controller manufacturer: Hurco, table width: 1,321 mm, table length: 508 mm, table load: 1,800 kg, spindle speed (min.): 10,000 rpm, Optional extra of twin screen Um0Cs7Ylnr 4th axis unit

Condition: good (used), Year of construction: 2003, Trumpf Trumatic L3020 Co2 Laser Fully working condition - removed from working factory Working Range X axis - 3000mm Y axis - 1500mm Z axis - 115mm Overshoot range X axis - -16- +88 Y axis - 19 - +61 Z axis - - 2 - +16 Max Travel range X axis - 3104mm Y axis 1580mm Z axis - 117m Control - Trumpf CNC Control based on siemens sinumerik 840D Electrical Connections with TLF 3200 - 73 kVa Fuses (at 400v) - 125A Speed - Max. positioning speed, Parallel to axis - 60m/min Simultaneous - 85m/min Bujsnkhjr3 Accuracy - smallest programmable increment. Positioning accuracy - +0.1mm Repeatability - +0.03mm Max laser power in cw mode with TLF3200 - 3200W Max material thickness - 20mm

Condition: excellent (used), Year of construction: 1998, Hardinge HXL-S CNC Lathe Dog2Ap Fagor Control Year 1998 Manuals Great Condition - Fully Working with no faults. We welcome any inspections

Condition: good (used), Cardinal Broach Model TM7 Bp3Iypjc

Condition: good (used), Model 200/4 Bqigv39T80 FIXED ANGLE TO 90º Main Technical Data Blades length 200 mm Maximum thickness R=42 Kg/mm² Maximum thickness R=60 Kg/mm² Strokes/min. at 250 mm of cutting lentgh 52 Three phase motor 3 HP Tank oil capacity 35 l Working table 750 x 530 mm Dimensions (L x W x H) 750 x 600 x 1.020 mm Approximate weight 480 kg - Blade clearance adjustment automatic for thickness from 0,5 to 4 mm - Automatic operation by means pedal or by impulse - Mechanical adjustment of vertical travel

Year of construction: 2013, Condition: excellent (used), A pair of You Ji YV250 Vertical Borers Ofwdyqbtp Max Swing Dia - 500mm Max Turning Dia - 350mm Max Turning Height - 250mm Spindle speed 50-2500rpm Spindle bearing diameter 100mm Spindle Nose A2-8 Turret Type - 6 Station Number of Tools - 6 X axis travel -50,+300 Z axis travel 450mm X axis rapid traverse 12m/min Z axis rapid traverse 24m/min Spindle motor P22 11/15 kw X axis servo motor 1.6kw Z axis servo motor 3kw Hydraulic motor 2.2kw Coolant motor 0.5+1kw 10" / 250mm 3 Jaw Auto strong close centre Chuck Boring bar brush Drilling sleeve MT2 and MT3 Chip conveyor and coolant tank Fanuc Series Oi-TD control Dimensions - L 2920mm W 1480mm H 2460mm Weight 4500kg Power capacity 30kva

Year of construction: 1988, Condition: used, Eubama S5 Rotary Transfer Machine Serial Number 5531 Year 1988 Da8Vlari0 Pristine Condition Not been used for 15 years
