LüneHanse Vertriebs GmbH

Condition: good (used), Year of construction: 1987, Functionality: fully functional, total width: 2,100 mm, total length: 2,600 mm, total height: 2,100 mm, heating capacity: 0.48 kW (0.65 HP), overall weight: 5,000 kg, Clamping unit - Heating capacity of the heating plate 0.48 kW per 1 heating rod Ljlhccqjwc Rf Asnjrk 0.9 kW per 8 heating rods - Pressure capacity 1,000 kN - Locking cylinder approx. 260 mm

Condition: excellent (used), Year of construction: 2006, The vulcanizing press from manufacturer PAN STONE, model S-V-65-2RT-PCD, was used by a renowned German company specializing in sealing technology and electromobility. This company is known for its high quality and innovation in seal production. The machine was part of a production line responsible for manufacturing high-performance seals used in various industries. It was always professionally maintained and repaired, which explains its excellent condition. This press offers you the opportunity to invest in proven technology that was utilized by a leading company in Germany. Dimensin ⇒ 2650 x 2100 x 2100 mm Clamping Force ⇒ 635 KN Working pressure ⇒ 206 bar Piston diameter ⇒ Ø200 mm Stroke ⇒ 140 mm Daylight ⇒ 150/180 mm Heating plant dimension ⇒ 250 x 300 mm Max. mass of heating plant ⇒ 70 kg Oil reservoir ⇒ 100 l Rated power ⇒ 19.66 kW Heater capacity ⇒ 9.6 kW Lelhccqswc Rfvonjrk Vacuum motor power ⇒ 2,6 kW Between light curtain and mould area ⇒ 270 mm Stroke of vacuum cover ⇒ 140 mm

Condition: good (used), Year of construction: 1997, Clamping Unit: Clamping force ⇒ 7,000 kN Operating pressure ⇒ 250 bar Specific pressing pressure ⇒ 610 N/cm² Number of daylight openings ⇒ 2 Installation height with 75 mm heating plate & 20 mm insulation plate ⇒ approx. 2x 190 mm Piston stroke ⇒ approx. 400 mm Piston diameter ⇒ 543 mm Estimated weight ⇒ approx. 16 tonnes Clamping force, rapid traverse ⇒ approx. 2 x 85 kN Retraction force ⇒ approx. 2 x 47 kN Operating pressure ⇒ 300 bar Piston diameter ⇒ 60/40 mm Lrjlhccewc Rfpeqnek Stroke: 400 mm Hydraulic System: Pressure setting ⇒ 40 - 300 bar Flow rate regulation ⇒ 0 - 99 % Flow rate l/min (HD) ⇒ 45 against 300 bar Drive power ⇒ 22 kW Tank dimensions (LxWxH) ⇒ 1000 x 770 x 535 mm Closing Speed: Rapid traverse ⇒ approx. 40 - 50 mm/s Slow closing ⇒ approx. 0 - 20 mm/s Pressing speed ⇒ approx. 0 - 3 mm/s Slow opening: approx. 0 - 20 mm/s Opening, rapid traverse: approx. 0 - 60 mm/s

Condition: used, Year of construction: 2017, Functionality: fully functional, input voltage: 400 V, volume flow: 6,300 m³/h, type of cooling: air, total length: 3,900 mm, total width: 1,050 mm, Air volume 6300 m³/h Air velocity 1.94 m/s Insulation 50 mm Filter M5 and F7 Fan Lslhccswc Rfieqnjrk Heater Cooler

Condition: excellent (used), RENISHAW Measuring System Package: ACR1 ⇒ Automatic changeover system for up to 8 probe modules. ACC2-2 ⇒ Communication between the CMM controller and the ACR1 changeover system. IS1-2 ⇒ Fully automated system for using multiple sensor types connected in parallel. PI7-2 ⇒ Signal processing from the TP7M strain gauge probe and standard touch probes. PI 200 ⇒ Interface for TP200 and standard touch probes. TP200 (x2) ⇒ Probe module with strain gauge technology for high accuracy. TP7M (x4) ⇒ 25 mm diameter strain gauge probe with auto-mount. Lrslhccewc Rfcsqnok + MITUTOYO ⇒ Calibration ball Ø 19.9819 mm ceramic, with M8 thread

Condition: good (used), Year of construction: 2006, Functionality: fully functional, controller manufacturer: SIEMENS, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Control: SIEMENS 840D Solution Line HV milling head can be used in horizontal and vertical positions X-axis: 1,350 mm Y-axis: 770 mm Z-axis: 1,330 mm NC rotary table: B-axis input and display resolution: 0.001° Clamping area: 800 x 800 mm Max. load: 2,000 kg Interference diameter: 1,600 mm Work spindle: Speed range: 20...6,000 rpm Lslowc Rd Eehccqnork Tool holder: HSK 100 Drive power at 60% duty cycle: 30 kW Torque at 60% duty cycle: 1,080 Nm Automatic tool changer stations: 240 Coolant system with fleece gravity filter and 80 bar pressure output RENISHAW measuring probe OMP60 Oil and emulsion mist extraction KNOLL chip conveyor Tool breakage detection

Condition: excellent (used), Year of construction: 2004, Functionality: fully functional, Year of Manufacture ⇒ 2004 Control ⇒ FANUC 16 Ois-MB X-Axis ⇒ 600 mm Y-Axis ⇒ 410 mm Z-Axis ⇒ 460 mm C-Axis ⇒ 360° max. Spindle Speed ⇒ 12,000 U/min Lslhswc Rdxoccqnork Including approx. 180 tool holders

Condition: good (used), Year of construction: 2014, Functionality: fully functional, Model ⇒ TNL 18-7 Control ⇒ Traub TX 8i-s Workpiece length (max.) ⇒ approx. 200 mm Workpiece diameter (max.) ⇒ 20 mm Main Spindle: Speed ⇒ 12,000 rpm Power ⇒ 5.5 kW Spindle passage ⇒ 18 mm Measurement system resolution Z ⇒ 0.001 mm Lslhccewc Rdroqnork Counter Spindle with Tool Turret: Speed ⇒ 12,000 rpm Power ⇒ 3.4 kW Workpiece Ø (max.) ⇒ 21 mm Workpiece clamping depth (max.) ⇒ 180 mm Clamping pressure (max.) ⇒ 30 bar Upper Tool Turret: ⇒ 8 stations Tool holder ⇒ Traub Ø 45 Traverse path X/Y/Z-axis ⇒ 120//-25/+40//250 mm Rapid traverse X/Y/Z-axis ⇒ 20/20/40 m/min Resolution X/Y/Z-axis ⇒ 0.0005/0.0005/0.001 mm Lower Tool Turret: ⇒ 7 stations + counter spindle Tool holder ⇒ Traub Ø 45 Traverse path X/Y/Z-axis ⇒ 120//-20/+40//250 mm Rapid traverse X/Y/Z-axis ⇒ 20/20/40 m/min Resolution X/Y/Z-axis ⇒ 0.0005/0.0005/0.001 mm

Condition: good (used), turning diameter over bed slide: 600 mm, turning length: 3,000 mm, overall weight: 3,850 kg, Turning diameter over support: 370 mm Max. working travel of the bottom slide: approx. 350 mm Lrelhjwc Rc Usccqnek Max. working path of the top slide: approx. 125 mm Speed range: 18-900 rpm Main spindle with camlock spindle head size 8 Machine dimensions approx. (LxWxH): 5,500 x 1,400 x 1,500 mm

Condition: good (used), Year of construction: 1972, Functionality: fully functional, travel distance X-axis: 290 mm, travel distance Y-axis: 170 mm, travel distance Z-axis: 310 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, table width: 195 mm, table length: 640 mm, overall weight: 1,200 kg, Dimensions: 1066 x 1048 x 1330 mm Lrslhowc Rcheccqnek Milling spindle adjustable in 16 steps Internal taper of the spindle: ISO 40

Condition: good (used), Year of construction: 1972, Functionality: fully functional, travel distance X-axis: 290 mm, travel distance Y-axis: 170 mm, travel distance Z-axis: 310 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, table width: 195 mm, table length: 640 mm, overall weight: 1,200 kg, Dimensions: 1066 x 1048 x 1330 mm Milling spindle adjustable in 16 steps Internal taper of the spindle: ISO 40 Lrelhowc Rb Deccqnek Vertical Milling Head Spindle turning speed range: 50 - 2500 U/min

Condition: excellent (used), machine/vehicle number: 77WSX22305E5A-135, BENZ - MONO WSX 05 - 90° Angle Head Mounting ⇒ HSK-A100 Collet ⇒ ER25-A (clamping range: 0.5–16 mm) Max. torque ⇒ 30 Nm Max. speed ⇒ 8,000 rpm Gear ratio ⇒ 1:1 Lrelhowc Rbqjccqnjk Angle head ⇒ 360° adjustable Weight ⇒ approx. 8 kg The angle head was used with a MAG HÜLLER HILLE - NBH6+, but can also be adapted or adapted for other machines.

Condition: good (used), Year of construction: 2001, Heavy-duty pliers in good used condition, current new price: €55,000 Maximum clamping range: 400 mm Min. clamping range: 50 mm Lolhccqowc Rbdsnerk Steady width: 170 mm Steady height: 730 mm

Condition: used, Year of construction: 2013, Functionality: fully functional, Rubber solution mixing system Length 1800 mm Width 1000 mm Height 1710 mm Inline mixer with thermo-siphon system Type 450LS Lolhccqowc Ra Tsnerk Compact agitator Type ARW-2081 (EX)
