Machsell Ltd

Condition: used, Year of construction: 1999, HARRISON ALPHA 550 S - GAP BED CNC LATHE MAKE HARRISON, MADE IN ENGLAND MODEL ALPHA 550 S YEAR 1999 CONTROL FANUC SPINDLE SPEED 15-1,800 RPM SWING OVER THE BED 660.0 mm SWING OVER THE SADDLE 370.0mm SWING IN THE GAP 830.0mm DISTANCE BETWEEN CENTRES 2000.0mm Drh0Of SPINDLE BORE 90.0 mm MAIN MOTOR 11 kw (15HP) TURRET 8 STATIONS ROTARY DUPOMATIC DIMENSIONS 3600 mm x 1500 mm MACHINE WEIGHT 3080 KGS PLUS UPGRADED CONTROL WITH FULL KEYBOARD 3 JAW CHUCK SAFETY CHUCK GUARD DUPLOMATIC ROTARY TURRET GAP BED MACHINE MANUALS TOOL HOLDERS

Condition: used, MAZAK A12 MEGA TURN CNC ELEVATING RAIL VERTICAL BORER MAKE MAZAK, MADE IN JAPAN MODEL A12 MEGA TURN YEAR LATE 1980 s CONTROL FANUC 6 TB TABLE DIA 1250.0 mm MAX SWING 1450.0 mm MAX CUTTING HEIGHT 1150.0 mm TABLE SPEED 1 - 350 RPM Drhqq9 ATC 16 STATIONS PLUS 4 TABLE JAWS TOOL HOLDERS SWARF CONVEYOR COOLANT SYSTEM GUARDING

Condition: used, Year of construction: 1997, MORI SEIKI SL-35 TURN MILL CENTRE MAKE MORI SEIKI, MADE IN JAPAN Drhqep MODEL SL-35 YEAR 1997 CONTROL FANUC MSC 516 CHUCK DIA 400.0 mm MAX. TURNING DIA 400.0 mm MAX. TURNING LENGT 780.0 mm SWING OVER BED 600.0 mm OVER CROSS SLIDE 425.0 mm MAX. SPINDLE SPEED 9-2500 rpm TURRET 12 STATIONS TAILSTOCK YES SPINDLE BORE 82.0 mm SPINDLE NOSE A8 RAPID TRAVERSE RATE X: 12,000mm/min & / Z: 15,000mm/min PLUS SWARF CONVEYOR TOOL SETTING PROBE GOOD RANGE OF TOOLING MACHINE MANUALS CLEAN

Condition: used, Year of construction: 2003, NAKAMURA TOME SUPER NTJ CNC LATHE Capzs7P7T3 MAKE NAKAMURA TOME, MADE IN JAPAN MODEL SUPER NTJ YEAR 2003 CONTROL FANUC 18 iT B CHUCK SIZE 210.0 mm MAX TURNING DIA. 200.0 mm BETWEEN CENTRES 780.0 mm DRAW TUBE DIA. 80.0 mm TRAVELS: X AXIS: 750.0 mm Z AXIS: 130.0 mm TURRET 2 x 12 STATIONS SPINDLE SPEED Up to 5,000 rpm SPINDLE BORE 65.00 mm SPINDLE NOSE A2-6 PLUS CNC SHORT MAGAZINE BARFEED TURRET TOOLING SWARF CONVEYOR MANUALS

Condition: excellent (used), Year of construction: 2007, VICTOR V TURN II-26 CNC LATHE MAKE VICTOR, MADE IN TAIWAN MODEL V TURN II-26 YEAR 2007 CONTROL FANUC 0i-TC CHUCK SIZE 250.0 mm SWING OVER THE BED 670.0 mm SWING OVER CARRIAGE 486.0 mm MAX TURNING DIA. 370.0 mm BETWEEN CENTRES 1080.0 mm TRAVELS: X AXIS: 185+50 (180+15) mm Z AXIS: 980.0 mm B AXIS: - 425 mm 915 mm TURRET 12 STATIONS MAX SPINDLE SPEED 3500 rpm SPINDLE BORE 86.0 mm SPINDLE NOSE A2-8 SPINDLE MOTOR 15/18.5 kW BEARING DIA. 130.0 mm B0A08Tlwvw MAX BORING BAR 40.0 mm (VDI-40) FEEDRATE RAPID TRAVERSE X: 20,000 mm/min Z: 24,000 mm/min B: 12,000 mm/min FEED RATE CUTTING X/Z=0~1260 mm/min TAILSTOCK QUILL DIA. 85.0 mm TAILSTOCK QUILL BORE TAPER MT#5 TAILSTOCK QUILL STROKE 120.0 mm PLUS TOOL SETTING PROBE WORK STEADY SWARF CONVEYOR FULL SET OF MANUALS

Condition: used, MANZONI CR 130 TON C FRAME MECHANICAL PRESS MAKE MANZONI, MADE IN ITALY MODEL CR 130 TONNAGE 130 TONS BED SIZE BOTTOM BOLSTER 1200.0 x 600.0 mm TOP BOLSTER 800.0 x 450.0 mm STROKE LENGTH 140.0 mm SPEED 60 SPM PLUS GEARED PRESS STEEL CONSTRUCTION Dqrlwf PENDANT CONTROL

Condition: excellent (used), Year of construction: 2001, turning diameter: 380 mm, DAEWOO - DOOSAN PUMA 400 LB CNC LATHE MAKE DAEWOO - DOOSAN, MADE IN KOREA MODEL PUMA 400 LB YEAR 2001 CONTROL FANUC 18 iT CHUCK SIZE 450.0 mm SWING OVER THE BED 700.0 mm SWING OVER SADDLE 480.0 mm MAX TURNING DIA. 380.0 mm BETWEEN CENTRES 2100.0 mm DRAW TUBE DIA. 117.5 mm TRAVELS: X AXIS: 362.0 mm Z AXIS: 2155.0 mm TURRET 10 STATIONS SPINDLE SPEED 20 - 2,000 rpm SPINDLE BORE 132.00 mm SPINDLE NOSE A2 - 11 BEARING DIA. 180.0 mm TURRET TOOL HEIGHT 25.0 mm Csaj70Mmuk TURRET BAR DIA. 50.0 mm TURRET INDEXING TIME 0.25 sec FEEDRATE RAPID TRAVERSE X: 16,000 mm/min Z: 18,000 mm/min FEEDRATE CUTTING FEED X , Z: 0,001 ~ 500.000 TAILSTOCK QUILL DIA. 120.0 mm TAILSTOCK QUILL BORE TAPER MT#6 TAILSTOCK QUILL TRAVEL 120.0 mm PLUS HYDRAULIC STEADY TOOL SETTING ARM SWARF CONVEYOR TURRET TOOLING FULL SET OF MANUALS

Condition: used, Year of construction: 2004, MORI SEIKI MT 2000 SZ TURN MILL CENTRE MAKE MORI SEIKI MODEL MT 2000 YEAR 2004 CONTROL MSG 501 SWING OVER CROSS SLIDE 599.5 mm SWING 749.0 mm CHUCK SIZE 250.0 mm DISTANCE BETWEEN CENTRE 1280.0 mm MAX. CUTTING DIAMETER 548.6 mm MAX. CUTTING LENGTH 1018.0 mm BAR CAPACITY 63.5 mm C AXIS 0.001 DEGREE SPINDLE RANGE 4500 rpm SPINDLE MOTOR 20 hp SPINDLE NOSE A2-6 SUB SPINDLE BAR CAPACITY 43.18 mm SUB SPINDLE MOTOR 10 hp SUB SPINDLE SPEED 6000 RPM TOOL CHANGE CAPACITY 60 STATION TURRET 12 STATIONS TRAVEL B AXIS +/- 120 DEGREE Bei07Sm Y AXIS +/- 78.7 MM PLUS CNC BARFEED PART CONVAYOR TOOL SETTING PROBE Y AXIS HIGH PRESSURE SWARF CONVAYOR FULL SET OF MANUALS GOOD RANGE TOOLING

Condition: used, Year of construction: 1998, turning length: 1,500 mm, turning diameter: 400 mm, spindle speed (min.): 3,000 rpm, travel distance X-axis: 280 mm, travel distance Z-axis: 1,536 mm, MAZAK QUICK TURN 40 CNC LATHE MAKE MAZAK, MADE IN JAPAN MODEL QUICK TURN 40 YEAR 1998 CONTROL MAZATROL T PLUS CHUCK SIZE 400.0 mm MAX SWING OVER BED 650.0 mm MAX SWING OVER CARRIAGE 400.0 mm MACHINING LENGTH 1500.0 mm TURNING DIA 400.0 mm TRAVEL X AXIS: 280.0 mm Z AXIS: 1536.0 mm SPINDLE SPEED 3,000 RPM SPINDLE MOTOR 29.9 kW SPINDLE NOSE A2-8 TURRET TOOL CAPACITY 12 TOOLS STATIONS MACHINE DIMENSIONS MACHINE WEIGHT 5715 kgs PLUS TOOL SETTING ARM SWARF CONVEYOR D7V2Lrc TRANSFORMER

Condition: ready for operation (used), Year of construction: 2001, JOHNFORD VTC 880 TWIN PALLET CNC VERTICAL LATHE MAKE JOHNFORD, MADE IN TAIWAN MODEL VTC 880 + APC + ATC YEAR 2001 CONTROL FANUC 18 T MAX SWING DIA 1,000 mm MAX CUTTING DIA 900.0 mm STANDARD CUTTING DIA 800.0 mm MAX CUTTING HEIGHT 800.0 mm TRAVERSES X AXIS 50.0 mm to 810.0 mm Z AXIS 880.0 mm D7Vwk3O SPINDLE SPEEDS 10 to 800 RPM SPINDLE BEARING DIA 330.0 mm SPINDLE NOSE A2 - 11 SPINDLE MOTOR 18.5 / 22 kW TURRET TYPE AUTOMATIC TOOL CHANGER NO OF TYPES 2 X 12 ATC TOOLS SHANK SIZE BT 50 AND CAPTO PLUS FULL C AXIS MILLING TAPPING X, Z, C, A AND B AXES HIGH PRESSURE COOLANT PAPER COOLANT FILTRATION SWARF CONVEYOR FULLY OPERATIONAL FULL SET OF MANUALS GOOD RANGE OF TOOLING

Condition: good (used), JONES & SHIPMAN 1011P SURFACE GRINDER with Electro Magnetic chuck MAKE JONES & SHIPMAN, MADE IN ENGLAND MODEL 1011P ELECTRO MAGNETIC CHUCK TABLE SIZE 680.0 mm x 280.0 mm MAGNETIC TABLE SIZE 600.0 mm x 200.0 mm CAPACITY LONG TABLE TRAVERSE 730.0 mm TRANSVERSE CROSS TABLE 280.0 mm MAX GRINDING WHEEL DIA 260.00 mm MAX GRINDING LENGTH 680.0 mm MAX GRINDING WIDTH 300.0 mm Dpqo0T MAX WORKPIECE HEIGHT 300.0 mm WHEEL SPEEDS 2,050 RPM PLUS HUMPREYS ELECTROMAGNET CHUCK POWER RISE AND FALL DUST EXTRACTOR DIGITAL READ OUT MODERN CLEAN BO SERIES

Condition: good (used), AMADA PROMECAM ITP2 5020 CNC PRESS BRAKE MAKE AMADA PROMECAM, MADE IN FRANCE MODEL ITP2 5020 CONTROL CNC EMA TONNAGE 50 TONS LENGTH 2000.0 mm Chccmutbrw NO OF AXES 3 AXIS CNC SAFETY GUARDS SICK LIGHT GUARD TOOLING YES PLUS FULL SET OF CLAMPS UPSTROKING PRESS BRAKE QUANTITY OF TOOLING

Condition: good (used), AMADA PROMECAM APX 50.20 CNC 7 AXIS PRESS BRAKE MAKE AMADA MODEL PROMCAM APX 50.20 YEAR 1995 CONTROL OPERATEUR 2 CAPACITY 50 TONS BENDING LENGTH 2050.0 mm OPEN HEIGHT 370.0 mm Chbo0Zn32E STROKE LENGTH 100.0 mm THROAT DEPTH 400.0 mm MOTOR POWER 9 KW TBC WEIGHT 6400 KG PLUS 7 AXIS- Y, R1,R2,X1,X2,Z1,Z2 COLOURED GRAPHIC SCREEN FULL SET OF TOOL CLAMPS SICK OPERATOR SAFETY LIGHT GUARDS

Condition: good (used), Year of construction: 2008, HWACHEON HI- TECH 200B CNC LATHE MAKE HWACHEON, MADE IN SOUTH KOREA MODEL HI TECH 200B YEAR 2008 CONTROL FANUC O i-TB SWING OVER BED 500.0 mm SWING OVER SADDLE 390.0 mm MAX MACHINING DIA 350.0 mm MAX WORK LENGTH 400.0 mm TRAVERSES (XZ) X AXIS: 195.0 mm Z AXIS: 430.0 mm CHUCK DIA 250.0 mm MAX. SPINDLE SPEED 3,500 RPM SPINDLE NOSE A2-8 SPINDLE BAR CAPACITY 76 mm TURRET 12 STATIONS MACHINE WEIGHT 4,500 kgs PLUS RENISHAW PROBE Cfcbprcqcg PARTS CATCHER TAILSTOCK SWARF CONVEYOR MACHINE MANUALS MACHINE IN GOOD WORKING ORDER

Condition: used, Year of construction: 2000, travel distance X-axis: 600 mm, travel distance Y-axis: 430 mm, travel distance Z-axis: 460 mm, MORI SEIKI SV-400 WITH 4TH AND 5TH AXIS VERTICAL MACHINING CENTRE MAKE MORI SEIKI, MADE IN JAPAN MODEL SV-400 YEAR 2000 CONTROL MORI FANUC MSC 501 TABLE SIZE 900.0 x 500.0 mm TRAVERSES (XYZ) X: 600.0 mm Y: 430.0 mm Z: 460.0 mm SPINDLE SPEED Up to 12,000 rpm Vw3Esyz SPINDLE TAPER BT 40 ATC 30 STATIONS RAPID TRAVERSE XYZ: 32,000 mm/min FEEDRATE 1-16000mm/min PLUS NIKKEN 4th and 5th AXIS UNIT RENISHAW PROBBING TWIN SWARF CONVEYOR COOLANT SYSTEM

Condition: used, Year of construction: 1998, MORI SEIKI SL-200 SMC, 4- AXIS TURN MILL CENTRE MAKE MORI SEIKI, MADE IN JAPAN MODEL SL-200 SMC YEAR 1998 CONTROL FANUC MSD- 518 (18-T) MAX. TURNING DIA. 390mm MAX. TURNING LENGT 507mm SWING OVER BED 680mm OVER CROSS SLIDE 510mm BAR WORK CAPACITY 51.0mm MAX. SPINDLE SPEED 0--4000rpm TURRET 12 stations, ALL DRIVEN stations TAILSTOCK YES SPINDLE BORE 65mm POWER TOOL SPEED (C-AXIS) 67- 3000rpm SPINDLE NOSE A8 (TBC) RAPID TRAVERSE RATE X: 18,000mm/min & / Z: 24,000mm/min ELECTRICAL POWER SUPPLY 37.9kVA MACHINE FLOOR SPACE 2650.0 X 1900.0 mm MASS OF MACHINE 4500 KGS PLUS 4- AXIS MACHINE SUB SPINDLE RENISHAW TOOL SETTING PROBE Boflqaeznq0 SWARF CONVEYOR GOOD RANGE OF TOOLING MACHINE MANUALS SWARF BIN MIST EXTRACTOR VERY CLEAN

Condition: used, Year of construction: 2003, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 330 mm, FANUC ROBODRILL T21i DL CNC DRILL-TAP MACHINE MAKE FANUC, MADE IN JAPAN MODEL ROBODRILL T21i DL CONTROL FANUC 16I-MB YEAR 2003 TABLE SIZE 850.0 x 410.0 mm TRAVERSES X Y Z 700.0 x 400.0 x 330.0 mm SPINDLE SPEED 10 – 20,000 RPM Ixhs2Sq8J ATC 21 STATIONS SPINDLE TRAPER ISO 30 RAPID TRAVERSE 54m/min DISTANCE BETWEEN SPINDLE NOSE TO TABLE 150.0 mm – 480.0 mm CUTTING FEEDRATE 1 – 30,000mm/min TOOL CHANGE TIME 1.6 sec MAX TOOL DIA 80.0 mm MAX TOOL LENGTH 200.0 mm MAX TOLL WEIGHT 2 kgs POWER RATING 5.5 Kw PLUS SWARF TRAY COOLANT SYSTEM SET OF TOOLING SET OF MANUALS

Condition: used, JONES & SHIPMAN 1436 SURFACE GRINDER MAKE JONES & SHIPMAN MODEL 1436 TABLE SIZE 279.0 mm x 914.0 mm CAPACITY LONG TABLE TRAVERSE 965.0 mm TRANSVERSE TABLE 286.0 mm TRAVERSE VERTICAL 305.0 mm TABLE SIZE 279.0 mm x 914.0 mm CROSS FEED 0,0025 mm AUTOMATIC RANGE CRESS FEED 0,381 to 25.0 mm HYDRAULIC TABLE 3 to 27 m/min WHEEL SPEEDS 3300 RPM MOTOR 5.5 hp STANDARD GRINDING WHEEL 254.0 mm x 51.0 mm x 76.0 mm MACHINE DIMENSIONS 3,607 mm x 2,235 mm x 2,083 mm PLUS AUTOMATIC DOWN FEED MACHINE CLOSED LOOP WALKER MAGENTIC CHUCK POWER RISE AND FALL PHILIPS FILTRATION SYSTEM Cyyt7Tmr

Condition: used, WEBSTER AND BENNETT EV54” ELEVATING RAIL VERTICAL TURRET LATHE MAKE WEBSTER BENNETT, MADE IN ENGLAND MODEL EV 54” YEAR TABLE SIZE 1372.0 mm SWING 1524.0 mm HEIGHT UNDER CROSS SLIDE 1143.0 mm CROSS SLIDE RISE & FALL 610.0 mm TURRET RISE & FALL 914.0 mm TURRET TRAVERSE 914.0 mm SPEED RANGE 6.3 – 140 RPM FEED RATE 0.05 mm – 2.5mm PER REV Czwnndsd PLUS RAM TYPE MACHINE CAPTO TOOLING 2 AXIS READOUT PENDANT CONTROL ELEVATING RAIL

Condition: ready for operation (used), Year of construction: 2009, BROTHER TC-32 BN QT TWIN PALLET WITH 4TH AXIS VERTICAL MACHINING CENTRE MAKE BROTHER, MADE IN JAPAN MODEL TC-32 BN QT YEAR 2009 CONTROL BROTHER CNC-B00 TABLE SIZE 600.0 mm x 425.0 mm MAX TURNING DIA 1,200.0 mm TRAVERSES (XYZ) X AXIS: 550.0 mm Y AXIS: 400.0 mm Z AXIS: 415.0 mm SPINDLE SPEED 12 - 12,000 RPM SPINDLE TAPER BT 30 SPINDLE MOTOR 11/6 kW ATC 26 STATIONS PLUS Bhautvbvwg3 NIKKEN 4TH AXIS TABLE TWIN PALLET SWARF CONVEYOR SET OF MANUALS

Year of construction: 1998, Condition: good (used), AMADA PROMECAM ITS2 2512 CNC PRESS BRAKE Dmbsnh MAKE AMADA PROMECAM, MADE IN FRANCE MODEL ITS2 2512 YEAR 1998 CONTROL OPERATEUR 2 TONNAGE 25 TONS LENGTH 1250.0 mm NO OF AXES 4 AXIS CNC GUARDING SICK OPERATOR LIGHT GUARD TOOLING FULL SET OF CLAMPS PLUS UPSTROKING HYDRAULIC PRESS BRAKE FOOT CONTROL PENDANT FULL SET OF MANUALS FULL SET OF CLAMPS SET OF TOP AND BOTTOM TOOLING

Year of construction: 2007, Condition: good (used), OKK VP 400 5 AXIS VERTICAL MACHINING CENTRE MAKE OKK MODEL VP 400 YEAR 2007 CONTROL FANUC 310IS A5 TABLE SIZE DIA. 350.0 mm TABLE LOAD 200 KGS TRAVERSES (XYZAC) X: 600.0 mm Ckhiefeky8 Y: 410.0 mm Z: 460.0 mm A: -120 to +30 degrees C: 360 degrees SPINDLE SPEED 100 – 12,000 RPM SPINDLE TAPER 7/24 # 40 SPINDLE NOSE TO TABLE 150 – 610.0 mm SPINDLE MOTOR 22/18.5 kW RAPID TRAVERSE RATE: (X, Y, Z) 48/48/36 m/min ATC 30 stations SPINDLE TAPER BT 40 MAX. TOOL LENGTH 300.0 mm MAX. TOOL WEIGHT 7 KG TOOL CHANGE TIME 1.2 SEC PLUS BIG PLUS BT 40 SPINDLE 2 SPEED TOOL CHANGER CERAMIC SPINDLE BEARINGS SIMALTENOUS 5 AXIS THROUGH SPINDLE COOLANT RENISHAW MP10 PROBE RENISHAW MEASUREMENT TWIN AUGER CONVEYORS SPINDLE CHILLER

Year of construction: 1998, Condition: good (used), CHEVALIER FSG 1640 AD SURFACE GRINDING MACHINE MAKE CHEVALIER, MADE IN TAIWAN MODEL FSG-1640 AD YEAR 1998 TABLE SIZE 1000 x 400 mm GRINDING WHEEL SIZE 445 mm TRAVERSES 400 x 1000 mm MAX HEIGHT FROM TABLE TO SPINDLE CENTRE 445.0 mm TOTAL POWER REQUIRMENT 7.4 kW PLUS Cg9Bttxqqf AUTOMATIC DOWN FEED WHEEL-MOUNTED WHEEL DRESSER SYSTEM HYDRAULIC MOVEMENT COOLANT SYSTEM 400.0 x 1000.0 mm ELECTRO MAGNETIC CHUCK MACHINE MANUALS

Year of construction: 1997, Condition: good (used), MAZAK VTC 30C VERTICAL MACHINING CENTRE Mu3Rts MAKE MAZAK, MADE IN JAPAN MODEL VTC 30C YEAR 1997 CONTROL MAZATROL M PLUS TABLE SIZE 2.000 X 670 mm TRAVERSES (XYZ) 1.660 mm x 760 mm x 760 mm RAPID TRAVERSE (X, Y, Z AXIS) 24.000 mm/min SPINDLE SPEED 7,000 RPM SPINDLE POWER 18.5 kW SPINDLE TAPER ISO - 40 ATC 24 STATIONS MACHINE WEIGHT 8,000 KGS PLUS SWARF CONVEYOR MANUALS
