Used Planer-type milling M/C - double column for sale (124)

Condition: defective spare-parts repository (used), Year of construction: 1998, Functionality: limited functionality, machine/vehicle number: 42162877, Manufacturer: ALD Germany Year of manufacture: 1997 Usage size (Width*height*depth): 600*600*900 mm Height of the stand from the floor: 1200mm Maximum load of the furnace : 600kg Maximum temperature of the furnace: 1300oC Protection gas: Nitrogen Maximum gas pressure when cooling: 10bar Convection fan capacity: 5KW Bwjb Hahjwc H Dzotcjl Power supply voltage: 3 phase, 400V/50Hz Total furnace power: 160KVA Total heat power: 120KW Min vacuum pressure: 5*106^-2 mbar Vacuum pump flow: 1000m3/h Boost pump flow: 180m3/h Normal cooling water flow: 15m3/h Fast cooling water flow: 60m3/h

Condition: good (used), Year of construction: 1979, Functionality: fully functional, More detailed technical specifications are written in the attached document. Fixed table length: 36000 mm Fixed table width: 6000 mm Distance between columns with covers / without covers: 6900/7100 mm Bob Hounkxdoahtcowl Gantry travel: 30000 mm Cross rail travel: 3100 mm Machine dimensions (L, W, H): 43000 x 12000 x 10000 mm

Condition: good (used), Year of construction: 2019, operating hours: 3,550 h, Functionality: fully functional, machine/vehicle number: 0345, travel distance X-axis: 3,200 mm, travel distance Y-axis: 2,600 mm, travel distance Z-axis: 1,000 mm, total length: 9,000 mm, table length: 3,000 mm, table width: 2,400 mm, total width: 8,000 mm, spindle speed (max.): 4,500 rpm, total height: 5,500 mm, rapid traverse X-axis: 7 m/min, rapid traverse Y-axis: 7 m/min, rapid traverse Z-axis: 7 m/min, table load: 11,000 kg, controller manufacturer: HEIDENHAIN, controller model: iTNC 640, Technical Specifications: - Operating voltage: 380 V - Frequency: 60 Hz - Connected load: 65 kVA - Control: HEIDENHAIN iTNC 640 Travel paths: - X-axis: 3,200 mm - Y-axis: 2,600 mm - Z-axis: 1,000 mm - Distance from spindle nose to table: 150–1,150 mm - Distance between table and gantry: 2,800 mm Table: - Dimensions: 3,000 x 2,400 mm - T-slots: 28 x 13 x 180 mm - Load capacity: 11,000 kg Spindle & feed rate: - Max. spindle speed: 4,500 rpm - Tool holder: BT 50 - X/Y-axis feed rate: 15 m/min Bsb Hahev Uh R Uotcewl - Z-axis feed rate: 12 m/min - Rapid traverse in all axes: 7,000 mm/min - Positioning accuracy: ±0.005 mm over 300 mm Features: - 60-station tool changer → the tool holders are included in the scope of delivery - 4th axis from DETRON - Coolant system - Chip conveyor

Condition: used, Year of construction: 2000, x-travel 3.700 mm y-travel 3.050 mm z-travel 1.000 mm Control HEIDENHAIN TNC-430 PA distance between columns 2.300 mm 1.175 mm rapid travel x/y/z 25.000 mm/min feeds 15.000 mm/min tool taper ISO-50 - DIN 69871 table weight 20.000 Kg spindle drive 37 kW milling head -swivable +/- 45 ° milling head AB Achse 360.000 pos. Tools changer 30 fach/tools Chip coveyor Ink. Internal cooling system 20 bar table-size 4.000 x 1.800 mm Bsbswg Hrge Hahtcowl weight of the machine ca. 42 t

Condition: new, Year of construction: 2025, Ref. -No.: 10464 Manufacturer: IGREK Type: 3500 XXL Year of construction: 2025 Type of control: CNC Control: Siemens 840 D / Heidenhain iTNC 640 Storage location: Istanbul Country of origin: Türkiye X-Travel: 10500 mm Y-Travel: 3500 mm Z-Travel: 1400 mm A-Axis: +/- 115 ° B-Axis: 360 ° Max. Torque: 235 Nm Rapid Traverse X/Y/Z: 30 m / min Drive power spindle: 54 kW Table load max.: 4000 kg Tool Taper: HSK-A100 Spindle Speeds: 12500 RPM Machine length: 16000 mm Bweb Howfy Dgjahtcsl Machine width: 7400 mm Machine Height: 8500 mm Weight: 195 t Further information: GREK 3500 XXL – Customized precision for large-scale projects The IGREK 3500 XXL is a CNC 5-axis portal milling machine of the latest generation, developed for the high-precision machining of large components. Built in 2024, it is ready for immediate use and equipped with the latest technology to meet the most demanding requirements in heavy industry and mechanical engineering. Key features: Gigantic machining areas: With travel distances of 10,500 mm (X), 3,500 mm (Y) and 1,400 mm (Z), the machine offers extraordinary flexibility for machining large parts. 5-axis simultaneous machining: The A-axis with +/- 115° and the B-axis with 360° guarantee maximum precision and versatility when machining complex workpieces. Powerful spindle: Equipped with a speed of up to 12,500 rpm, a maximum torque of 235 Nm and a drive power of 54 kW – ideal for high-performance machining. Robust and durable: Weighing 195 tons and with a table load of up to 4,000 kg, the machine is designed for heavy-duty machining. Innovative tool holding fixture: The HSK-A100 tool holding fixture enables quick tool changes and increases efficiency. Speed and efficiency: Rapid feed rates of 30 m/min on all axes ensure maximum productivity. Technical data at a glance: Traverse paths: X 10,500 mm / Y 3,500 mm / Z 1,400 mm Spindle power: 54 kW Spindle speed: 12,500 rpm Table load: up to 4,000 kg Machine dimensions (LxWxH): 16,000 x 7,400 x 8,500 mm Weight: 195 tons Additional benefits: The machine is supplied with the advanced Siemens 840D or Heidenhain iTNC 640 control system and offers worldwide warranty and service support from the manufacturer. Choose the IGREK 3500 XXL for precision and efficiency in the machining of large parts. Contact us now for a non-binding offer!

Condition: excellent (used), Year of construction: 2017, Functionality: fully functional, Technical details x-travel 3500 mm y-travel 2200 mm z-travel 1200 mm Control Heidenhain iTNC 530 total power requirement 45 kW weight of the machine ca. 48 t Additional information Bweb Hahjwgamqstcjl The milling spindle was renewed / overhauled in November 2024. Operating hours 15918 Travels: X/Y/Z 3500/2200/1200 mm Table clamping area 3000 x 2000 mm Rapid traverse X/Y/Z 30 m/min. Max. spindle speed 20000 rpm Tool holder HSK A 63 Power 30 kW Torque 80 Nm Equipment: Heidenhain iTNC 530 CNC control Universal milling head with B axis -110°/+110° and C axis -200°/+200° 32-ATC tool changer Coolant through spindle 24 BAR THREE-DIMENSIONAL PROBE HEIDENHAIN TS 460

Condition: excellent (used), Year of construction: 2008, Control: Heidenhain iTNC530 with handwheel Working ranges X-axis: approx. 3,000 mm Y-axis: approx. 6,000 mm Z-axis: approx. 1,250 mm The milling head can be adjusted using the control (A-axis)! No machine table! Milling spindle (new!) Type: HSD ES951 Adapter: HSK63F Cooling: Air Clamping: Pneumatic Maximum speed: 24,000 rpm Power: 10 kW Torque: 8.7 (S1) and 10.5 (S6) Suitable materials: Wood, plastic, aluminum Linear axis drives Feed rate X, Y, Z axes: up to 20 m/min Axis acceleration X, Y, Z axes: up to 1.5 m/s2 Connection data Connected load: approx. 25 kW Back-up fuse: 42 A Dimensions, weight Machine space requirements: approx. 5,500 x 9,000 x 4,500 mm Total weight: 96,000 kg Machine condition Fully functional, no longer in use Under power since dismantled and stored. Bsb Hahtowffyyocswl Available immediately!

Condition: good (used), Year of construction: 2016, CNC 5-axis portal milling machine (gantry) Jobs JomaX 265 W Year of construction 2016 Bjb Haherif I Hjtcowl Siemens 840D SL CNC control Panel field size 25,000 x 5,000 mm (10 panel fields) Panel field load per panel field max. 10,000 kg Rapid traverse X,Y,Z/W 28,000/8,000 mm/min. C/A axis 30°/s Distance spindle nose ~ table max. 3,900 mm Distance between uprights 6,000 mm Travel distances X 28,000 mm Y 6,500 mm Z 1,500 mm 2-axis NC swivel milling head. C 400 (+/- 200°). A 220° +/- 110° Spindle holder HSK-A100 Spindle drive power 42/53 kW Spindle torque max. 1,337/1,687 Nm Spindle speeds up to 3,000 rpm. 1-axis angular milling head 90° BUSS With C-axis +/-200° Spindle holder HSK-A100 Spindle drive power 30/37 kW Spindle torque max. 955/1,178 Nm Spindle speeds up to 2,800 rpm Vertical milling head BUSS Spindle holder HSK-A100 Spindle drive power 45/56 kW Spindle torque max.1,433/1,783 Nm Spindle speeds up to 4,000 rpm. Head magazine with 3 positions Tool magazine with 60 positions Workpiece measurement with M&H Multi 20 measuring probe. Tool measuring system for diameter and length as well as tool breakage monitoring. High-pressure coolant through the tool 50 bar. 2 chip conveyors Estimated total machine weight 450 - 500 tons Offer number V(F)-6865

Condition: good (used), Year of construction: 1999, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 1,150 mm, total length: 6,000 mm, total width: 6,000 mm, spindle speed (min.): 100 rpm, spindle speed (max.): 1,600 rpm, total height: 5,200 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 10 m/min, Manufacturer/ Make: FOOKE Model/ Type: Endura Type 8 Year of manufacture/ YOM: 1999 Control: Siemens 840 D Powerline Tool holder/ Tool holder: HSK-A63 Max. speed/ max. rpm: 16,000 Bob Hajwhcutjhtcjwl X-Way/ X-Way: 3000 mm Y-Way/ Y-Way: 2500 mm Z-Way/ Z-Way: 1150 mm A-Axis/ A-Axis: +/- : 100 mm C-Axis/ C-Axis: +/- : 181.5 mm Table size/ Table size: 3000 mm x 2500 mm Option/ option: Blowing air outside Kinematics/ kinematics: Clevis

Condition: used, Year of construction: 1996, Table size 4000 x 1250 mm X/Y/Z - 3500/2500/1000 mm Spindle speeds 5000 rpm Spindle taper SK 50 Tool changer w/60 stations Control: Bwjbev Iz Rbo Hahtcol Heidenhain TNC 426 Weight 24300 kg Equipped with:

Condition: new, Year of construction: 2025, Ref. -No.: 10463 Manufacturer: IGREK Type: FR 3500 XL Year of construction: 2025 Type of control: CNC Control: Siemens 840 D / Heidenhain iTNC 640 Storage location: Istanbul Country of origin: Türkiye X-Travel: 6500 mm Y-Travel: 3500 mm Z-Travel: 1400 mm A-Axis: +/- 115 ° C-Axis: 360 ° Turning Speeds: 12500 RPM Max. Torque: 235 Nm Rapid Traverse X/Y/Z: 30 m / min Table-Size (Lxw): 2290 - 6490 x 3580mm mm Drive power spindle: 54 kW Table load max.: 4000 kg Tool Taper: HSK-A100 Machine length: 11500 mm Machine width: 7400 mm Machine Height: 6600 mm Weight: 120 t Further information: IGREK FR 3500 XL – Precision and performance at the highest level The IGREK FR 3500 XL is a CNC-controlled 5-axis portal milling machine of the latest generation (year of manufacture 2024). It was specially developed for the demanding machining of large workpieces and impresses with its versatility and precision. With a modern control system from Siemens 840D or Heidenhain iTNC 640 and a robust construction, the machine offers optimal conditions for manufacturing in a wide range of industries. Key features: Large machining areas: With travel distances of 6,500 mm (X), 3,500 mm (Y) and 1,400 mm (Z), the machine is ideal for machining large components. 5-axis simultaneous machining: The A-axis with a swivel range of +/- 115° and the C-axis with a rotation of 360° enable highly precise machining of complex geometries. Powerful spindle: The spindle reaches speeds of up to 12,500 rpm and a maximum torque of 235 Nm – perfect for demanding milling work. High stability: The machine weight of 120 tons and the table load of up to 4,000 kg ensure low-vibration machining even with heavy workpieces. Flexible tool holding fixture: The HSK-A100 tool holding fixture enables quick tool changes and optimal process times. Rapid feed rate: High productivity is achieved with 30 m/min in the X, Y and Z directions. Technical data at a glance: Table size: 2,290 – 6,490 x 3,580 mm Spindle power: 54 kW Bjb Hahswfy Dastcewl Max. torque: 235 Nm Tool holder: HSK-A100 Machine dimensions (LxWxH): 11,500 x 7,400 x 6,600 mm Max. table load: 4,000 kg The IGREK FR 3500 XL sets new standards in the machining of large parts. It is available immediately and offers comprehensive warranties and services directly from the manufacturer, internationally and across the board. Use the latest technology for your production – contact us for further details!

Condition: like new (used), Year of construction: 2007, Retrofitted: 2024 Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 4500 x 2000 mm Number of T slots: 11 T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mm Y axis traverse: 3000 mm Z axis traverse: 1000 mm Vertical capacity (VC): -10 / 990 mm Distance between columns: 2435 mm Milling head Auto-indexing differential head (UAD - 0,1º) Tool clamping system: Hydraulic Taper nose: ISO50 Speed range: 6000 rpm Spindle power: 30 kW Feedrates Feedrate: 5000 mm/min Rapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 10000 Kg Machine weight approximate: 45300 Kg Machine dimensions approximate: 10975 x 4768 x 5095 mm Beb Hahjugbn Ejtcowl Accesories Guarding Automatic tool changer: ATC30 Coolant: External & internal high pressure through spindle Electronic handwheel: HR-410 Sales conditions Guarantee: 6 months mechanical spare parts Sale price (Ex Work): On request View all technical features

Condition: excellent (used), Year of construction: 2002, operating hours: 1,46,161 h, Functionality: fully functional, operating hours of spindle: 4,486 h, First commissioned: 2002 Control: Fidia C20 with HPX control panel X-axis: approx. 3,000 mm Y-axis: approx. 2,360 mm Z-axis: approx. 1,500 mm A-axis: ± 105° C-axis: ± 300° Clamping table Clamping area: approx. 5,000 x 2,000 x 400 mm T-slot spacing: 18H12 / 250 mm Table load: 15,000 kg/m² 2-axis milling head AC3 (2003) Spindle power: 28 kW Spindle speed: max. 18,000 rpm Torque: 90 Nm Tool holder: HSK 63A Tool clamping: hydraulic Minimum quantity lubrication: External Linear axis drives X-, Y-axis feed rate: up to 20 m/min Z-axis feed rate: up to 20 m/min X-, Y-, Z-axis acceleration: up to 1.5 m/s2 Connection data Connected load: 40 kW Back-up fuse: approx. 80 A Dimensions, weights Space requirement (machine with peripherals): approx. 7,300 x 5,600 x 5,600 mm Total weight: approx. 16,500 kg Color Housing, gantry, control cabinet: light gray Milling head and applications: turquoise Additional equipment Bsb Haowdv N Ajhtcewl - 18-position chain tool changer - 3-sided housing, without extraction ducts Optional for an additional charge: - Wired measuring probe Machine condition Fully functional, in very good condition. Available from 01.05.25 and still powered until the end of June 2025.

Condition: excellent (used), Year of construction: 2003, CNC Gantry Type Milling - Routing Machine (for Aluminium Skin drilling / Milling Operations) MTorres MGP-51350-TT Manufactured 2003 Siemens Sinumerik 840D CNC control Bob Hahtsm Shb Hjcowl Machine working traverses: X 13000 mm - Gantry longitudinal travel Y 4500 mm - Milling support cross travel Z 1000 mm - Milling ram vertical travel Positioning speeds / rapid traverse rates 15000 mm/min. 2-Axis rotary swivelling milling head A & C Axes simultaneous Positioning speeds / rapid traverse rates 10 rpm Spindle drive motor rating 20 KW Spindle speeds to maximum 30000 rpm (electro spindle) 20 station tool changer Tool diameter max. 80 mm Tool length max. 125 mm Tool weight max. 10 kg 16 units TorresTool pogo stick clamping system for parts - NC controlled 5-Axis Gantry Routing & Drilling Machine. Designed for high speed milling and drilling of aircraft structural components. Applications include net trimming and drilling of compound contoured fuselage panels, wing skins, composite structures, frames, stringers, honey comb components, etc. By integrating the TORRESTOOL® with the TORRESMILL® 5-Axes High Speed Milling Machine, the system provides the highest grade of flexibility and reduces change over time from one work piece configuration to another to less than 2 minutes. All support rods with vacuum cups move simultaneously in cnc controlled axes and are automatically locked in their final positions. Proposal Number V(F)-6790

Condition: good (used), Year of construction: 1973, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 860 mm, Oerlikon milling machine, rarely used, only used for punching tool repairs. Very precise. Bsb Hswgk Ixsahtcswl With CNC control. Can be used for workpiece weights up to 3000kg.

Condition: like new (used), Year of construction: 2020, Functionality: fully functional, Accessories included: 02 40110 Automatic loading (1 x) 03 20110 Packaging, transport, and installation (1 x) 04 50060 PHSF60 three-jaw precision manual chuck (1 x) 05 50500 Barcode scanner (1 x) 06 30120 qs-STAT measurement data export (1 x) Bjb Hjwgw Swjahtcewl 07 30300 24-month warranty extension

Condition: good (used), Year of construction: 2012, Ref. -No.: 10290 Manufacturer: KOLB KLUEPPELBERG Type: Cubimat YC 2000 Bwob Haowfyxwjhtcsl Year of construction: 2012 Type of control: CNC Control: Siemens Sinumerik 840 D Storage location: Halberstadt Country of origin: Deutschland Machine number: 016453-20.1 X-Travel: 7000 mm Y-Travel: 4000 mm Z-Travel: 4000 mm W-Travel: 2.000 mm Speed work spindle: 4.000 RPM Max. Torque: 2.100 Nm Max. Workpiece Weight: 20 t Table-Size (Lxw): 2.800 x 2.000 mm Tool Taper: SK 50 Distance Between Columns: 3.200 x 4.000 mm Further information: 4 Milling Heads available.

Condition: refurbished (used), Year of construction: 1999, travel distance X-axis: 11,450 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,250 mm, Technical description Value Unit Travel distance X-axis: 11,450 mm Y-axis: 3,500 mm Z-axis: 1,250 mm Cross-section of the Z-axis slider: 360 x 360 mm Portal aperture: 3,000 mm Height under vertical spindle: 1,400 mm Working clamping width: 2,500 mm Milling unit: Type FA 305 C Power: 30 kW Max. torque: 1,070 Nm Max. speed: 4,000 rpm Cross section of the pusher: 360 x 360 mm Vertical head with spindle Power: 30 kW Max. speed: 4,000 rpm Max. torque: 1,070 Nm Rapid traverse in X, Z: 25,000 mm/min Rapid traverse in Y: 20,000 mm/min Work feed infinitely variable in X, Y and Z: 10,000 mm/min Compressive force of each axis: 25,000 N Tool holder: SK 50 Horizontal angle head with 144 x 2.5° pitch, with SK50 spindle Available power: 30 kW Max. speed: 4,000 rpm Max. torque: 1,070 Nm Positioning increment: 2.5 degrees Longitudinal pallet system 1 pallet shuttle with 2 storage stations 1 manual pallet transfer system between machine and shuttle 2 workpiece holder pallets: 5,000 x 2,500 mm Tool changer Chain magazine: 80 positions Distance between the positions on the chain: 130 mm Diameter of consecutive tools: 125 mm Tool diameter max.: 200 mm Bwob Hahtotix S Nscol Maximum tool length: 400 mm Tool weight max.: 25 kg Tool change time, tool to tool: 8 sec Tool change time, chip to chip: 38 sec Equipment: Cooling devices: - Cooling via orientable nozzles - IKZ / cooling through the center of the spindle, 3,000 l tank, capacity: 30 l/min, pressure: 7 bar at the mold 2 chip conveyors: 1 Portal cladding Measuring probe, make: RENISHAW, type: MP14 Electronic handwheel Remote diagnosis Tool management and wear management Documentation in 2 copies: German / French CE marking Very well maintained, continuously serviced condition!

Condition: used, Year of construction: 1996, operating hours: 80,000 h, Functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 30 m/min, feed rate Y-axis: 30 m/min, feed rate Z-axis: 30 m/min, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, Control: Heidenhain TNC 430 with handwheel Working areas X-axis: 3,000 mm Y-axis: 2,500 mm Bwsb Haowbhldshtcsl Z-axis: 1,000 mm A-axis: +/- 90° C-axis: 360° Clamping table Length x width: 4,100 x 2,100 mm 2-axis swivel head Axes with hydraulic clamping Motor spindle power: 20 kW (40% duty cycle) Spindle speed: max. 9,000 - 15,000 rpm Torque: max. 127 Nm (40% duty cycle) Tool holder: HSK 63A Linear axis drives X/Y/Z axis feed rate: up to 30 m/min Electrical connection values Voltage: 400 V Frequency: 50 Hz Fuse: 63 A Power requirement: 40 kW Dimensions & Weight Machine space requirements: approx. 7,000 x 4,000 x 4,500 mm Total weight: approx. 40 tons Color: light gray Additional equipment - 24-station tool changer - Chip conveyor with integrated coolant system - Tool measurement

Condition: like new (used), Year of construction: 1996, Retrofitted: 2025 Numerical control: NUEVO/NEW HEIDENHAIN TNC-320 Technical features Dimensions Dimensiones mesa: 6.000 x 2.000 mm Número de ranuras T: 13 Medidas ranuras T: 22 mm Traverses of axis Recorrido longitudinal X: 6.000 mm Recorrido transversal Y: 3.800 mm Recorrido vertical Z: 1.000 mm Capacidad vertical (VC): 500 / 1.500 mm (salida directa) Distancia entre columnas: 3.100 mm Milling head Cabezal universal (UM40 – Cuerpo B: manual / Cuerpo C: 3º auto-indexado) y Salida directa Bwsb Hahtewfunyscol Amarre herramienta: Hidráulico Cono: ISO50 (DIN-69871)  /  Tirante: DIN-96872 Gama de velocidades: 3.000 rpm Potencia mandrino: 30 kW Feedrates Avances rápidos (X / Y,Z): 7.200 / 12.000 mm/min Weight and dimensions Peso aproximado máquina: 50.000 Kg Peso máximo sobre mesa: 15.000 kg Dimensiones aproximadas máquina: 14.740 x 5.330 x 5.050 mm Accesories Carenado: 2 puertas correderas con nuevo vallado perimetral de seguridad Cambio de cabezales: automático con bisagra/soporte lateral en columna Evacuador de virutas: 2 longitudinales por paletas Volante electrónico: Nuevo HR-510 Taladrina: Externa e interna alta presión a través del mandrino (interna sólo con la salida directa) Sales conditions Garantía: Repuestos mecánicos 6 meses Precio y condiciones de venta: Consultar View all technical features

Condition: excellent (used), Year of construction: 2010, operating hours: 2,800 h, HIGH SPEED 5-Axis Gantry Milling Machine with Linear Drive Motors 2-Axis NC Milling Head and high speed spindles Forest Liné Minumac 2400 New in 2010 Siemens Sinumerik 840D control Table size (floor plate) 3000 x 6500 mm Table load max. 5000 kg/m² Distance between the columns 4500 mm Working travels (Linear Drive Motors) X 6800 mm X1/X2 2250/2250 (for separate working areas) Y 3500 mm Z 2000 mm 2-Axis NC Universal Milling Head Head Rotary axis C-Axis +/- 360° Head Swiveling Axis (Tilting) B-Axis +/-110° (220°) 2 x Interchangeable spindles Spindle 1: 20 KW. 18000 rpm. 120 Nm. HSK-A63 Spindle 2: 40 KW. 24000 rpm. 56 Nm. HSK-A63 Tool magazine and automatic tool changers ATC 2 x Tool magazines: 1 for each working area 20 station (2 x 20) tool magazine positions Tool taper HSK-A63 Tool diameter 80 mm Tool length 250 mm Tool weight max. 5 kg Linear drives X,Y,Z Rapids X,Y to 60000 mm/min. Rapids Z to 40000 mm/min. B/C 10 rpm 2 x Chip conveyors Bwjb Hahjwa R Sdstcel This High Gantry 5-Axis Milling machine is ideal for the machining of soft materials like Aluminium and aluminium alloys, resin, plastics etc. For machining steel a suitable HF-Spindle can be purchased from spindle manufacturers or from the machine manufacturer. High Gantry Milling Machine/Top Gantry Milling Machine. Simultaneous 5-Axis Machining with 2-Axis NC Universal Milling Head. Machining in one working area OR in 2 separate working areas, for simultaneous working and loading/offloading of work and pendulum machining. High Speed with linear motor drives. High precision. Heidenhain linear scales X,Y,Z Axes. Heidenhain encoders B,C Axes. 2 x interchangeable high speed spindles. The spindle changing is semi-automatic. Only the 4 holding bolts need to be handled manually. 2 x 20 station tool magazines and automatic tool changers. ATC 1 if for the full machining stroke. ATC 2 is for use in the second working area if separate working area function is in use. Tool measurement, length and diameter and tool breakage control with BLUM Laser measurement system. 1 in each working area. Parts probing with Renishaw RPM 60 probe. Monitoring of the working area with a colour camera with motor zoom objective. Full guarding. Telescope roof in front of and behind the crossrail, sealing off the working area. The roof is opened to load workpieces by crane. 2 x Chip conveyors 6800 mm usable length (X-Axis). 1 x Lift up conveyor at the end of the X-Axis. Said to be in excellent condition. Power ON hours - 2800 ONLY ! Spindle run hours - 1800 ONLY ! Proposal Number V(F)-7038 Note: The side columns are steel filled with concrete. These will not be used again. When moved the concrete columns need to be poured when making the foundation. The drawings are available. Advice and assistance can be provided by the manufacturer.

Condition: used, x-travel 6500/13150 mm y-travel 4000 mm z-travel 1250 mm w-travel 2250 mm control Sinumerik 840 D table surface area 5500/12150 x 3000 mm distance between columns 3500 mm max. distance between table and spindle-nose 3000 mm max. workpiece weight 70000 / 105000 kg ram head dimension 480 x 510 mm spindle turning speed - stepless 6,3 - 4000 U/min milling spindle motor 63 kW max. torque on the spindle 3300 Nm tool taper DIN 39871 AD ISO 50 feed speeds X/Y/Z= 24000 mm/min total power requirement 120 kVA weight of the machine ca. 245 t dimensions of the machine ca. 29 x 7,7 x 8,1 m The Machine is in almost new condition - in 2020, it was completely retrofit and modernized for 1.6 million Euro! Bwjb Hjwa Dx Rjahtcol Equipment/accessories: - automatic tool magazine for 153 tools - automatic milling head magazine for 6 milling heads - machining modules/ milling heads: 1. machining module -straight - straight long - 2. machining module -standard angle - 4000 rpm, 144 x 2.5°, ISO 50 3. machining module -narrow angle extended -40 kW, 4000 rpm, 1800 Nm, 144 x 2.5°, ISO 50 4. machining module -universal index - 40 kW, 4000 rpm, 2100 Nm, - C-axis 144 x 2.5° , B-axis +/- 44 x 2.5°, ISO 50 - coolant unit - chip conveyor - technical documentation

Condition: excellent (used), Year of construction: 2016, Functionality: fully functional, travel distance X-axis: 1,500 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,150 mm, feed rate X-axis: 80 m/min, feed rate Y-axis: 80 m/min, feed rate Z-axis: 80 m/min, spindle speed (max.): 24,000 rpm, torque: 28 Nm, distance table center to spindle nose: 250 mm, Equipment: rotational speed infinitely variable, X-axis: approx. 1,500 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,150 mm A-axis: ± 120° C-axis: ± 245° First commissioned: 2016 New milling head: 2018 Overhaul: 2021 (details upon request!) Control: Heidenhain iTNC 530 including HR 550 handwheel Clamping table Clamping surface: 3,000 x 1,500 x 30 mm, steel construction M8 threaded holes in 50x50 mm grid Zero-point clamping system, 15 H7 locating holes in 50x50 mm grid for amf clamping system, clamping bolt size 10 and M8 locking screw HS 678 milling head Max. spindle power: 22 kW Max. torque: Approx. 28 Nm Max. spindle speed: 20,000 rpm Tool holder: HSK 63A Tool clamping: hydraulic Linear axis drives Feed rate X, Y, Z-axis: up to 80 m/min Acceleration X, Y, Z-axis: up to 5 m/s² Connection data Connected load: 40 kW Back-up fuse: 63 A Dimensions, weights Machine space requirements: approx. 7,000 x 3,500 x 4,600 mm Total weight: approx. 15,000 kg Color: Bwebewbgnqs Hahtcsl white, anthracite, neon yellow Additional equipment - Work area cover - Minimum quantity lubrication - Heidenhain KinematicsOpt - 39-station tool changer Optional for an additional charge: - Heidenhain TS 460 measuring probe - Blum Control NT 3A Laser Tool Measurement Machine Condition Fully functional, in good condition, and can be inspected under power.

Condition: excellent (used), Year of construction: 2013, First commissioned: 2013 Control: Heidenhain iTNC 530 including HR 520 handwheel Machine hours Machine under power: approx. 40,700 h Spindle hours: approx. 17,100 h Spindle hours of current milling spindle: approx. 150 h X-axis: approx. 2,500 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,250 mm A-axis: ± 110° Bwob Hahtswa T Hkecjl C-axis: ± 300° Working table Clamping area: approx. 2,500 x 3,250 x 400 mm 2-axis milling head VH30 Spindle power: 60 kW Spindle speed: max. 22,000 rpm Torque: 95 Nm Tool holder: HSK 63A Tool clamping: hydraulic Coolant supply: external and internal Linear axis drives X/Y/Z axis feed rate: up to 60 m/min X/Y/Z axis acceleration: up to 5 m/s² The machine is currently set to the following default values because there was insufficient power available on site! X/Y axis feed rate: up to 40 m/min Z axis feed rate: up to 30 m/min X/Y/Z axis acceleration: up to 2.5 m/s² Connection data Connected load: 190 kVa Back-up fuse: approx. 315 A The machine can be reset to its original values at any time if sufficient power is available. The following reduced connection values apply: Connected load: 130 kVA Back-up fuse: approx. 250 A Dimensions, weight Space requirement (machine with peripherals): approx. 10,000 x 8,000 x 5,650 mm Total weight: approx. 63,000 kg Color Enclosure, gantry, control cabinet: RAL 7035 light gray Milling head and applications: RAL 6038 fluorescent green Description: Additional equipment - Coolant supply with belt filter system - 50-station chain tool changer - Work area cover - Chip conveyor - Emulsion mist extraction system from LTA Optional for an additional charge: - Renishaw RMP60 wireless touch probe - BLUM Control NT Condition of the machine Fully functional, in very good condition. Already disassembled and stored.

Condition: excellent (used), Year of construction: 2012, First commissioned: 2012 Control: Heidenhain iTNC 530 including handwheel X-axis: approx. 7,500 mm Y-axis: approx. 3,500 mm Z-axis: approx. 2,500 mm A-axis: ± 110° Bwsb Hswa Tz Isahtcol C-axis: ± 275° Clamping table Clamping area: approx. 7,500 x 3,000 x 300 mm 2-axis milling head Spindle power: 39 kW Spindle speed: max. 24,000 rpm Torque: 32 Nm Tool holder: HSK 63A Tool clamping: hydraulic Linear axis drives Feed rate X-, Y-, and Z-axis: up to 65 m/min Connection data Connected load: 130 kW Dimensions, Weight Machine footprint with peripherals: approx. 15,500 x 8,500 x 7,550 mm Total weight: approx. 120,000 kg Color Housing, gantry, control cabinet: RAL 7035 light gray Milling head and appliqués: RAL color 5002 ultramarine blue Additional equipment - 140-station chain tool changer - Work area cover Optional for an additional charge: - Laser tool control system - Wireless workpiece measuring system Machine condition Fully functional, in very good condition. Can be inspected under power.
