Used Boring Machines for sale (65,968)

Condition: like new (used), Year of construction: 2010, functionality: fully functional, travel distance X-axis: 9,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 1,000 mm, CME TRAVELING COLUMN MILLING / BORING MACHINE CME TECHNICAL FEATURES - VISIBLE IN OPERATION Dsdpfx Aou R Rk Hsgmouw Brand: CME Model: MB 9000 Year: 2007 CNC: Siemens Sinumerik 840D X-axis: 9000 mm Y-axis (Vertical): 4000 mm Z-axis: 1000 mm W-axis (Ø 150 mm): 700 mm 2 rotary translation tables (linear travel: 2000 mm) 2500 x 2500 mm (25 TN) capacity Heidenhain optical scales on all axes Direct spindle 90-position tool change ZF range change Internal coolant Chip extractors

Condition: excellent (used), Rapid radial drilling machine / Radial drilling machine / Drilling machine (used) Manufacturer: Mikrosa Year of manufacture: 2001 Type: SRB 35 Drilling capacity: - Steel: 35 mm - Cast iron: 40 mm Thread cutting: - Steel: M20 - Cast iron: M24 Spindle taper: MK 4 Spindle speed: 20 – 2800 rpm, infinitely variable Automatic feed: infinitely variable Spindle stroke: 140 mm Arm reach: 1000 mm Table size: 1050 x 400 mm Column diameter: 200 mm Installation height: 600 mm Connected load: 7.8 kW Space requirement: approx. width 1250 mm, depth 2100 mm, max. height 2700 mm Duedpfxoy Skrzo Agmsw Weight: approx. 2000 kg Hydraulic clamping Thread cutting device Depth stop Lateral clamping surface Drill chuck 2 gearbox stages The machine is in very well-maintained condition, runs very smoothly, and is ready for immediate operation. Forklift available, free loading on truck. Affordable shipping possible. Location of the machine: 48477 Hörstel

Condition: used, functionality: unexamined, Year of construction: 2010, We offer this used MTS Lovat Mid shield with erector as Pushmodul, 3m tunnel boring machine, year 2010. Manufacturer: MTS Lovat Model: Mid shield with erector as Pushmodul 3m Year of manufacture: 2010 Condition: used Machine type: tunnel boring machine If you have any questions or need more information, please feel free to send us a message or give us a call. Dedpfx Agsy Nm Rbemjuw

Condition: used, spindle diameter 110 mm x-travel 2000 mm y-travel 1500 mm z-travel 1450 mm table surface area 1400 x 1600 mm taper ISO 50 spindle speed: 2 - 2500 Control TOSNUC 7-3 Dujdpfeyuqhyex Agmsw total power requirement 22 kW

Condition: used, spindle diameter 125 mm spindle travel 1000 mm column movement horizontal 7000 mm headstock - vertical 2500 mm/min cross travel column 450 mm taper ISO ISO 50 P.D.B. total power requirement 25 kW Dodpfx Aoyuql Eogmouw

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, Drilling machine with automatic angle adjustment Dedpfoy Iaizex Agmeuw

Condition: ready for operation (used), Year of construction: 1994, functionality: fully functional, A used CNC jig boring machine SIP 640 FANUC control Duedpfoy R Nnlex Agmjw Includes 80 tool holders Disassembly and loading are the responsibility of the buyer.

Condition: excellent (used), Year of construction: 2013, 4mm Dia. - 16mm Dia Range of Drilling; Up to 3,000mm Length of Component; Double Axis; Overall Length Approx 11 Metres x 900mm Wide, Dedpfjy Ey E Rex Agmeuw (2) Sections - Headstock Bed Length Approx 5 Metres, Drilling Length Bed Approx 6 Metres; (1) 500mm Dia 4-Jaw Chuck, 120mm Bore with Troyke DL-20-B, 4th Axis, 500mm Dia. Precision Rotary Table; Pendant Control; Stand Alone Electrical Cabinet (Dimensions Approx 3,000mm x 500mm x 1,900mm High); Technidrill Coolant Filtration System consisting of LNS 'Turbo HB' Swarf Conveyor, FSI 'CBFP 11' Filter System & Oil Tank with High Pressure Delivery Pumps; Stand Alone Dimplex Koolant Koolers Chiller Unit with Controls (Dimensions Approx 700mm x 1,300mm x 1,850mm High, 2012);

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 2920x980x1450 mm Weight 1500 kg Dsdpfx Aevz Hx Dogmeuw Total power requirement 12 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 570x490x1720 mm Dedpfx Agsv A Hm Dsmouw Weight 90 kg Total power requirement 1 kw

Condition: used, core drilling diameter max. 50-600 mm bore depth 6000 mm table load 6 t turning speeds 50-600 U/min clamping diameter max. 650 mm Boring (pushing) from ID = 50 to 320 Skyving and roller Burnishing from ID = 50 to 300 Honing from ID = 50 to 320 Extraction system The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop Dusdpfx Aoy R Ef Tsgmew If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, spindle diameter 102 mm x-travel 1600 mm y-travel 1250 mm z-travel 1600 mm spindle taper ISO 50 bore spindle stroke 710 mm main drive motor 11 kW turning speeds 1600 U/min Feed 4000 mm/min Duodpfxjyqvmae Agmew Control Heidenhain type TNC 135 T-slot - width 22 mm T-slot - distance 140 mm table surface area 1250x1400 mm Table load 2500 kg total power requirement 23 kW weight of the machine ca. 9,3 t Rotating table 360° The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), ELECTRONIC (CNC control) machine, Numerical Control Type NC 500 - Software Tooling System N. 2 Through-feed motorized conveyoring belts - Feeding speed (m/min) 35 - 75 ca. Max. working width (mm) 3200. Min. working width (mm) 215 N. 2 Horizontal units/supports N° 2 Drilling heads for each horizontal unit (11 Spindles for each horizontal drilling head) Duodpfjyyw S Rox Agmow N. 5 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 x HP 1,8 N. 2 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 x HP 1,8 N. 4 Vertical top pressure clamps - N. 2 Motorized endless screws to evacuate wastes/chips Quota (axes) digital display. Total installed power (Kw) 62,7 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the vertical movement (Hv) of the 2 horizontal units The CNC controls the movement (X axe) of all the vertical units The CNC controls the movement (Y1 and Y2 axes) of the boring heads The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the pressure clamps The CNC controls the movement (X axe) of the conveyor belts The CNC controls programming of the working cycles

Condition: excellent (used), Numerical Control Type NC 400 Deluxe Through-feed motorized conveyoring belts (No.) 2 No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 1 Splindles for each horizontal drilling head (N°) 20 Max. working width (mm) 3200 Min. working width (mm) 205 (ca.) Duedpoyyw Sdefx Agmew No. 5 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 2 Top vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 Vertical top pressure clamps (N°) 4 Transport belts to evacute chips (wastes) (N°) 2 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the conveyor belts Total installed power (Kw)

Condition: refurbished (used), Numerical Control Type Power Control Professional Software woodWOP / TopDrill BST No. 2 Through-feed motorized conveyoring belts (4 x Kw ?) No. 2 Horizontal units/supports (with Digital quota/axes display) No. 1 Drilling head for each horizontal unit (1 x Kw 1,5) No. 21 Splindles for each horizontal drilling head Max. working width (mm) 2500 Min. working width (mm) 250 No. 4 Bottom vertical units/supports (with Digital quota/axes display) No. 2 Drilling heads/blocks for each bottom vertical unit (2 x Kw 1,5) Dedpedz Uk Tefx Agmjuw Miscellanous Spindles for each drilling head of the bottom vertical supports No. 2 Top vertical units/supports (with Digital quota/axes display) No. 2 Drilling heads/blocks for each top vertical unit (2 x Kw 1,5) Miscellanous Spindles for each drilling head of the top vertical supports No. 4 Vertical top pressure clamps Motorized carpet to evacuate chips and wastes Total installed power (Kw) 36

Condition: excellent (used), Electronic programmer NC 400 Through-feed motorized conveyoring belts (No.) 2 Horizontal units/supports (No.) 2 Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 Max. working width (mm) 3200 - Min. working width (mm) 205 (ca.) Bottom vertical units/supports (No.) 6 Drilling heads/blocks for each bottom vertical unit (N°) 2 Dsdpfxelwqrts Agmjuw Vertical top pressure clamps (N°) 4 Motorized endless screws to evacuate wastes/chips (N°) 2 Digital quota (axes) display Total installed power (Kw) 27.7 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops The CNC controls the movement (Z axe) of all the vertical units

Condition: excellent (used), Year of construction: 2021, CNC Gantry (Portal) flexible machine (Through-feed panel in horizontal position) Numerical Control Open powerTouch, Software WoodWOP (Ready for TAPIO) In-feeding working table (panel support) + Out-feeding working table (panel support) Panels (workpieces) feeding by No. 3 motorized conveyor belts Minimum workpieces dimensions (X - Y - Z) mm 250 x 100 x 12 Maximum workpieces dimensions (X - Y - Z) mm 2500 x 1050 x 60 Lateral Guide for sensitive Workpieces edges No. 3 Vertical Pressure Clamps Motorized carpet to evacuate chips and wastes. Built-in electric and command cabinet Total installed power: Kw 47 approx OPTIONAL: WIRELESS BAR CODE SCANNER N° 2 WORKING GROUPS (TOP) - (SERVO-MOTOR for X-Y-Z axis ): N° 4 Drilling heads V15 (4 x Kw 2.3) with No. 15 vertical spindles each (total top spindles No. 60) N° 3 WORKING GROUPS (BOTTOM) - (SERVO-MOTOR for X-Y-Z axis : N° 3 Drilling heads V32 (3 x Kw 2.3) with No. 32 vertical spindles each (total bottom spindles No 96) N° 3 Drilling heads V35 (3 x Kw 2.3) with No. 35 vertical spindles each (total bottom spindles No 105) Dujdpfx Aox Aqi Esgmsw N° 6+6 (total 12) horizontal drilling spindles in Y-axe N° 2 WORKING GROUPS (HORIZONTAL) N° 2 Drilling heads H21 (2 x Kw 2,3) with horizontal spindles N° 21 Horizontal drilling spindles (Right Side) + N° 21 Horizontal drilling spindles (Left Side)

Condition: excellent (used), Numerical Control Type Power Control Software TOPDRILL BST 500 Dodpfxjivawpo Agmeuw No. 2 Through-feed motorized conveyoring belts No. 2 Horizontal units/supports (with Digital quota/axes display) No. 1 Drilling head for each horizontal unit (1 x Kw 1,5) No. 21 Splindles for each horizontal drilling head Max. working width (mm) 2500 Min. working width (mm) 250 No. 4 Bottom vertical units/supports (with Digital quota/axes display) No. 2 Drilling heads/blocks for each bottom vertical unit (2 x Kw 1,5) N. 11 Spindles for each drilling head of the bottom vertical supports No. 4 Vertical top pressure clamps Motorized carpet to evacuate chips and wastes Total installed power (Kw) 20

Condition: excellent (used), Numerical Control Type NC 400 Dodjidqd Tspfx Agmsuw Through-feed motorized conveyoring belts (No.) 2 No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 Max. working width (mm) 3200 Min. working width (mm) 205 (ca.) No. 5 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 2 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Vertical top pressure clamps (N°) 4 Transport belt to evacute chips (wastes) Digital quota (axes) display Total installed power (Kw) 59,1 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the conveyor belts

Condition: excellent (used), Numerical Control Type NC 400 Through-feed motorized conveyoring belts (No.) 2 No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 Max. working width (mm) 3200 Min. working width (mm) 205 (ca.) No. 6 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 3 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Vertical top pressure clamps (N°) 5 Transport belt to evacute chips (wastes) Digital quota (axes) display Total installed power (Kw) 59,1 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the conveyor belts Dedpfx Agjidqf Rjmsuw

Condition: excellent (used), ELECTRONIC (CNC control) machine, Numerical Control Type NC 500 - Software Tooling System N. 2 Through-feed motorized conveyoring belts - Feeding speed (m/min) 35 - 75 ca. N. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 x HP 1,8 Duodpfx Ajhvi Dusgmjw Max. working width (mm) 3200 - Min. working width (mm) 215 N. 7 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 x HP 1,8 N. 3 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 x HP 1,8 N. 5 Vertical top pressure clamps - N. 2 Motorized endless screws to evacuate wastes/chips The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the vertical movement (Hv) of the 2 horizontal units The CNC controls the movement (X axe) of all the vertical units The CNC controls the movement (Y1 and Y2 axes) of the boring heads The CNC controls the movement (Y axe) of the stops The CNC controls the movement (X axe) of the pressure clamps The CNC controls the movement (X axe) of the conveyor belts The CNC controls programming of the working cycles

Condition: excellent (used), Numerical Control Type NC 400 (with work cycle management software) Through-feed motorized conveyoring belts (No.) 2 Max. working width (mm) 3200 - Min. working width (mm) 205 (ca.) No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 No. 4 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 2 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Djdpfxsi D D Tfo Agmeuw Vertical top pressure clamps (N°) 2 Motorized endless screws to evacuate wastes/chips (N°) 2 Digital quota (axes) display Total installed power (Kw) 25 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops OPTION: Front feed hopper/loader (for narrow pieces: Min 60mm - Max 260mm)

Condition: excellent (used), Gantry (Portal) machine Movable panel (workpiece), movable working head (Horizontal position of the panel/workpiece) Numerical Control Power Control, Software WoodWOP Safety cabin (enclosure) of the working head and integral safety cabin (enclosure) of the machine In-feeding working table (panel support). Out-feeding working table (panel support) Panels (workpieces) feeding by No. 3 motorized belts - Feeding speed (m/min) max 130 ca. Minimum workpieces dimensions (X - Y - Z) mm 250 x 100 x 15 Maximum workpieces dimensions (X - Y - Z) mm 2500 x 1050 x 60 Motorized carpet to evacuate chips and wastes. Separate electric and command cabinet Total installed power: Kw 99 N° 2 WORKING GROUPS (TOP) - (SERVO-MOTOR X-Y-Z ): N° 4 Drilling heads (4 x Kw 2.3) with No. 10 vertical spindles each (total top spindles No. 40) N° 3 WORKING GROUPS (BOTTOM) - (SERVO-MOTOR X-Y-Z ) : N° 6 Drilling heads (6 x Kw 2.3) with No. 40 vertical spindles each (total bottom spindles No 240) N° 2 WORKING GROUPS (HORIZONTAL) N° 2 Drilling heads with horizontal spindles Dodpfx Agsgwbbqomeuw N° 21 Horizontal drilling spindles (Right Side) + N° 21 Horizontal drilling spindles (Left Side) N° 8 Dowel Inserting nozzle & glue injectors(Right side) + N° 8 Dowel Inserting nozzle (Left Side) N° 2 Storage tanks for automatic feeding of the dowels OPTIONAL: WIRELESS BAR CODE SCANNER

Condition: excellent (used), Numerical Control Type NC 400 (Software) Through-feed motorized conveyoring belts (No.) 2 Dusdpfx Agegk T Ttjmow No. 2 Horizontal units/supports Drilling heads for each horizontal unit (N°) 2 Splindles for each horizontal drilling head (N°) 11 Max. working width (mm) 3200 - Min. working width (mm) 205 (ca.) No. 6 Bottom vertical units/supports Drilling heads/blocks for each bottom vertical unit (N°) 2 No. 4 Top vertical units/supports Drilling heads/block for each top vertical unit (N°) 2 Vertical top pressure clamps (N°) 5 Motorized endless screws to evacuate wastes/chips (N°) 2 Digital quota (axes) display Total installed power (Kw) 48 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops

Condition: excellent (used), Electronic programmer RT 483 No. 2 Through- feed motorized conveyoring belts Feeding speed (55 m/min ca.) No. 2 Horizontal units/supports No. 1 Drilling heads for each horizontal unit/support (1 x HP 1,5) No. 20 Spindles for each horizontal drilling head Max. working width (mm) 3200 Min. working width (mm) 220 No. 7 Bottom vertical units/supports No. 2 Drilling heads/blocks for each bottom vertical unit (2 x HP 1,8) No. 4 Top vertical units/supports No. 2 Drilling heads/blocks for each bottom vertical unit (2 x HP 1,8) No. 4 Vertical top pressure clamps No. 2 Motorized endless screws to evacuate wastes/chips Quota (axes) digital display Dsdsfz Nanepfx Agmjuw Total power installed (Kw) 35,1 The CNC controls the movement (X axe) of the mobile horizontal unit The CNC controls the movement (Y axe) of the stops
