Used Ctx for sale (126)

Condition: used, Year of construction: 2010, turning diameter max. 410 mm turning length 1.235 mm control IT / Turn Plus Heidenhain greates pass round over bed 700 mm turning speed range - main spindle max. 4.000 min/-1 power capacity - main spindel 35 / 45 kW max. Torque 770 Nm spindle head 220 h5 spindle diameter in front bearing 160 mm max. usable bar diameter 95 / 104 mm C-Axis 0,001 ° number of toolpositions 12 pos. Number of driven toolspositions 12 pos. Spindle speed - driven tool stations max. 4.000 min -1 power capacity driven tool-stations 12 kW max. Torque 36 Nm tool taper VDI 40 DIN 69880 turret change time 30°: 0,4 sec. Cgedsvzhiwjpfx Abpjn Y - Axis 120 (+/- 60) mm x-axis 300 mm z-axis 1.300 mm y-axis +/- 60 mm tailstock 1.200 mm taper of center MK 5 clamping capacity 1.400 daN rapid traverse ( X / Y / Z ) 30 / 22,5 / 30 m/min total power requirement 60 kVA weight of the machine ca. 7,7 t dimensions of the machine ca. 6,0 x 3,5 x 2,5 m CNC - Turning- and Millingcenter GILDEMEISTER - CTX beta 1250 V4 - Tailstock - Y-axis - Tool drive - Direct measuring system - Bar machining package - Connection for bar feed / bar loading magazine

Condition: used, Year of construction: 2006, Technical data: Working area: Max. swing diameter: 680 mm Swing diameter over X-guideways: 565 mm Chuck diameter: 250 / 315 mm Cross travel (X): 315 mm Longitudinal travel (Y): 1350 mm Headstock: Spindle diameter in front bearing: 150 mm Spindle bore: 107 mm Main drive: Main three-phase drive power: 36 / 45 kW Torque (100% duty cycle / 40% duty cycle): 600 / 750 Nm Speed range (100% duty cycle): 20 - 3200 rpm Speed range (40% duty cycle): 20 - 4000 rpm Tool turret: Number of tool stations: 12 Shank diameter: 50 mm Indexing time for 30°: 0.16 sec Tailstock: Tailstock quill travel: 1200 mm Quill stroke: 120 mm Quill diameter: 120 mm Quill taper: MT 5 Coolant system: Cjdjwym Inspfx Abpegn Capacity: approx. 220 l Pump output: 1.7 kW Delivery rate at 6 bar: 20 l/min Connected load: approx. 65 kVA Dimensions (LxWxH), approx.: 5560 x 2115 x 2050 mm Weight without chip conveyor, approx.: 9500 kg Equipment/features: - CNC control SIEMENS SINUMERIK 840D powerline with Shop Turn - Single-row turret with 12 fixed tool stations - Hinged belt chip conveyor

Condition: repair required (used), Year of construction: 2011, operating hours: 8,545 h, functionality: not functional, turning length: 310 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 190 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 370 mm, mount diameter: 30 mm, Condition: Non-functional. The machine has an unknown malfunction in the turret, making referencing and axis movement impossible. The machine requires repair! TECHNICAL DETAILS Turning length: 310 mm Swing diameter over bed: 500 mm Swing diameter over cross slide: 290 mm Distance between centers: 500 mm Cgsdpfx Abjw T Srdopen X-axis travel: 190 mm Z-axis travel: Z1: 335 / Z3: 370 mm Y-axis travel: 80 mm Control: Heidenhain CNC Pilot 4290 Spindle speed: 6,000 rpm Spindle bore: 73 mm Bar capacity: 50 mm Main spindle torque: 95 Nm at 100% and 127 Nm at 40% Tool turret - number of stations: 12 Tool holder: VDI 30 mm Rapid traverse X + Z axes: 30 m/min MACHINE DETAILS Total power requirement: 20 kVA Chip conveyor dimensions (LxWxH): 3.2 x 0.45 x 1.5 m Operating hours (on-time): 36,443 h Spindle hours: 8,545 h Interface: yes EQUIPMENT - 160 mm 3-jaw chuck with matching flange - 2 sets of spare jaws - 12-station turret with driven tooling - Sauter disc turret (C-axis = 300 rpm) - Chip conveyor 450 K-1/250; year of manufacture 2000 - Manual chuck fitted – no hydraulic chuck - Electrical cabinet with Rittal cooling

Condition: not inspected (used), Year of construction: 2009, operating hours: 24,854 h, functionality: unexamined, machine/vehicle number: 00410002771, turning diameter over cross slide: 380 mm, turning diameter: 410 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 300 mm, travel distance Z-axis: 850 mm, Equipment: documentation/manual, No minimum price – guaranteed sale to the highest bidder! Placing a bid obligates you to collect the machine within the period from 28.07.2025 to 31.07.2025. Including a comprehensive tool package TECHNICAL DETAILS Swing diameter over bed: 700 mm Max. swing diameter over cross slide: 380 mm Max. turning diameter: 410 mm Centre distance: 975 mm Turning length: 800 mm X-axis travel: 300 mm Z1-axis travel: 850 mm Z3-axis travel: 800 mm Max. spindle speed: 4,000 rpm Main spindle: ISM 102 C-axis torque: 600/770 Nm Cedpfewvhunsx Abpogn Spindle flange height from floor: 1,040 mm Spindle flange diameter: 220h5 mm Chuck diameter: 315 mm Bar diameter: 102 mm Spindle bore diameter: 118 mm Front bearing diameter: 160 mm C-axis angular resolution: 0.001° Turret with driven tools Tool holders: VDI 40 Number of tools: 12 pcs. Tailstock: travel 800 mm, Morse taper 5 MT MACHINE DETAILS Serial number: 00410002771 Operating hours: 71,843 h Spindle hours: 24,854 h Dimensions: 5,000 x 2,800 x 2,000 mm Weight: 7,500 kg EQUIPMENT - With technical documentation

Condition: like new (used), Year of construction: 2015, operating hours: 14,717 h, functionality: fully functional, turning length: 800 mm, turning diameter: 500 mm, spindle speed (max.): 12,000 rpm, travel distance X-axis: 480 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 845 mm, rotational speed (max.): 5,000 rpm, type of input current: three-phase, workpiece weight (max.): 7 kg, total height: 2,247 mm, total length: 2,890 mm, total width: 5,193 mm, overall weight: 7,800 kg, CNC controller: Siemens 840D sl with CELOS ERGOline Capacity X-axis travel mm: 480 (–10) Y-axis travel mm: ±100 Z-axis travel mm: 845 B-axis travel mm: ±110° (0,001º) C-axis: 360º (0,001º) Turning length mm: 800 Max. turning diameter mm: ø: 500 Distance between spindle centers mm: 1.020 Turn-mill spindle Speed spindle rpm: 12.000 Drive power kW: 22 / 19 Tool magazine Magazine places: 24 Tool holder: HSK-A63 Tool length max. mm: 300 Tool diameter max. mm: 125 Tool weight max kg: 7 Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 25 / 34 (100 / 40%) Spindle bore mm: 67 Maximun torque Nm: 380 / 280 Counter spindle Speed spindle rpm: 6.000 Drive power spindle kW: 20 / 27 (100 % / 40%) Spindle bore mm: 52 Maximun torque Nm: 170 Counter spindle travel mm: 800 Coolant system Cgodpfxjxdlyno Abpon Tank capacity liter: 600 L High-pressure bar: 8 / 20 Equipment Chip conveyor Blowing air through spindle center selectable via M-function Signal lamp Tool measuring arm Workarea light Coolant gun Internal coolant supply Interface for Bar feeder Paper band filter Working time hours Under power: 36.049 Cutting Time: 14.171 Basic machine dimensions / weight Length mm: 2.890 Width mm: 5.193 Height mm: 2.247 Weight kg: 7.800

Condition: used, Year of construction: 2011, Lathes Travel distance X: 270 mm Travel distance Y :120 mm Travel distance Z: 1200 mm turning length: 1135 mm max. turning diameter: 700 mm max. circulation diameter: 340 mm max. turning moment: 680 NM range of revolutions till: 4000 rpm Control: DMG powered tools Powered tools: 50 Scrapper chip conveyor Short bar loader magazine IRCO ILS-RBK 100/16 Various main spindle reduction sleeves NC-controlled workpiece removal device Conveyor belt for transporting the workpieces out of the machine Coolant system 8/20 bar with immersion cooler Coolant spray gun Chip conveyor Oil mist extraction system Control cabinet cooling unit (up to 40 °C) Csdpfxjwwv Ifj Abpegn 4-color signal light, connection for bar loader magazine Main spindle as integrated spindle motor ISM 102 Counter spindle as integrated spindle motor ISM 76 Easy-Tool Monitor Approx. 40 various quick-change collets size 100 (entire stock) Pneumatic changeover device Ø 100 mm Approx. 50 various tool holders, static and driven (entire stock) Installation elements Documentation

Condition: used, Year of construction: 2003, max. Spindle speed 5000 U/min. travel -x axis 160 mm travel -z axis 450 mm numbers of turret head positions 12 tool taper VDI 30 Control Heidenhain iT Plus Dimensions (L x W x H) 4,5 x 2,5 x 2,5 m weight of the machine 3700 kg CNC Turning- and Milling Center | DMG GILDEMEISTER - CTX 310 Additional equipment: - C-Axis The machine is in good condition. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: CTX310 | CTX-310 Cgjdpfxsv Ehawo Abpen

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, CNC Turning and Milling Center - DMG GILDEMEISTER - CTX gamma 1250 TC YOM: 2009, until 2011 showroom machine, from 2012 operating The machine can be inspected by appointment in the factory under power. Condition: Good (high accuracy), ready for immediate use. Spindle hours (August 1st, 2025): 9.580 h The heart of the machine is the integrated traveling column with turning milling spindle and interpolating B-axis. Machine basic data: * Part hollow clamping device (hydraulic) * C-axis * Cross slide above with turning/milling spindle as motor spindle, with hydraulic clamping in turning, tool holder: Capto C6 * Y-axis: +/- 200 mm * B-axis: +/- 120° * Disc-type tool magazine * Absolute, direct measuring systems in X-, Y-, Z1-axis * USB-interface, Ethernet interface TECHNICAL SPECIFICATIONS: * Control: Heidenhain CNC Pilot 4290, 3-D path control Cgodpfx Abjw Hg Nlopon TURN PLUS Working area: * Swing diameter over bed: 630 mm * Turning diameter: 630 mm * Spindle distance: 1.510 mm * Bar diameter max.: 65 mm Main drive I: * Drive power (100% / 40% ED): 24 / 34 kW * Speed range from - up to: - 5.000 rpm * Speed of the C-axis: - 5.000 rpm Turning/milling spindle: * Tool holder: Capto C6 * Spindle speed: - 12.000 rpm * Drive power (100% / 40% ED): 13.2 / 22 kW * Torque (100% / 40% ED): 60 / 100 Nm Tool magazine: * Number of tools: 36 * Dimensions of the machine approx. (Width/Depth/Height): 6.860 x 4.220 x 2.530 mm * Total weight of the machine approx.: 18,5 tons EQUIPMENT: * Well equipped … * No steady rest available * Documentation complete available. Detailed technical data sheet and information on equipment available on request. There is no guarantee for correctness and completeness of the technical details and and accessories.

Condition: good (used), Year of construction: 2011, CNC Milling and Turning Center Machine Type: DMG CTX beta 1250 TC Control: Siemens 840 D solutionsline + ShopTurn Year of Manufacture: 2011 Available from: February 2026 TECHNICAL SPECIFICATIONS: Maximum turning length: 1,250 mm Turning diameter: 390 mm Bar capacity: 75 mm Main Spindle Speed range: 0 - 5,000 rpm Drive power: 34 / 25 kW C-axis: 0.001° 3-jaw chuck: Röhm KFD-HS 250-91 mm Counter spindle: ISM 52 Csdpfxoxvaqro Abpogn Speed range: 6,000 rpm Drive power: 27 / 20 kW C-axis: 0.001° 3-jaw chuck: Röhm KFD-HS 200-66 mm CNC spindle swiveling for milling and turning operations B-axis: +/- 110° Speed range: 15 - 12,000 rpm Drive power: 22 kW Torque: 100 Nm Tool holder: HSK 63 Tool stations: 24 Y-axis: 100 +/- mm Machine weight: 8,000 kg Footprint (LxWxH): 5.67 x 2.72 x 2.1 m Features: Chip conveyor High-pressure pumps: 8/20/80 Paper band filter Coolant tank: 980 l Oil mist extraction Tool breakage control: Renishaw

Condition: good (used), Year of construction: 2011, CNC Turning and Milling Center Machine type: DMG CTX Beta 800 V3 Control: Siemens 840D Year of manufacture: 2011 TECHNICAL DATA: Max. turning length: 800 mm Turning diameter: 380 mm Max. turning diameter over bed: 700 mm Spindle bore: 67 mm Cjdpfxsxvap Ij Abpegn C-axis Main spindle: ISM 76 Spindle speed range: 0 - 5,000 rpm Drive power: 25 kW Number of turrets: 1 Tool positions: 12 Driven tools: 6 Tailstock Equipment features: Chip conveyor

Condition: excellent (used), Year of construction: 1997, Hello. I have for sale a CNC GILDEMEISTER CTX400E V3 driven tool lathe. TECHNICAL AND VISUAL CONDITION: Very Good. Type: CNC lathe Manufacturer: GILDEMEISTER Model: CTX400E V3 Control: Heidenhain 1190 Country of manufacture: Germany Year of manufacture: 1997 Machine parameters: Cgsdsmv Ei Hopfx Abpen - head: 12 - tools for VDI-40 toolholders (6 driven sockets) - max rpm 5000 /min. - C axis - driven tools - hydraulic tailstock - receiver of finished part - max. turning diameter X axis = 290mm - max. turning length Z axis = 600mm - cooling system - three-jaw hydraulic chuck 250mm - spindle bore Fi-66mm - pass-through spindle - chip conveyor - full programming manual - Mechanical and Electrical Documentation - machine weight: 5.5 tons - the price includes loading on a truck Machine after full inspection. 100% operational. Connected and ready to work. Stal-Com company for 17 years we are engaged in sales, service and training on CNC machines from DMG group. We specialize in all models of Gildemeister lathes and Deckel Maho Machining Centers. All machines undergo a meticulous technical inspection. In addition to customers from Poland, our machines are also bought by customers from all over Europe and parts of Asia. Each machine can be checked during production as we also do machining. After purchasing a machine from our company, we provide training for the crew as well as we can set up the production of details at the customer's site. We cooperate with many companies on a permanent basis to which we provide further machine tools.

Condition: excellent (used), Year of construction: 1995, Hello. I am offering a GILDEMEISTER CTX400 CNC LATHE for sale. TECHNICAL & VISUAL CONDITION: Very Good Type: CNC Lathe Manufacturer: GILDEMEISTER Model: CTX400 Control: Heidenhain 1190 Country of manufacture: Germany Year of manufacture: 1995 Machine Specifications: - Turret: 12 tool positions for VDI-30 holders - Max. spindle speed: 5,000 rpm - Hydraulic tailstock - Finished part catcher - Max. turning diameter X-axis: 290 mm - Max. turning length Z-axis: 600 mm - Coolant system - 3-jaw hydraulic chuck, 200 mm - Spindle bore: Ø66 mm - Through spindle - Chip conveyor - Complete programming manual - Mechanical and electrical documentation - Machine weight: 5.5 tons - Loading onto truck included in price The machine has undergone a full inspection. 100% operational. Connected and ready for work. Cgodpfxsw Trvvs Abpjn For 17 years, Stal-Com company has been engaged in the sales, service, and training for CNC machines from the DMG group. We specialize in all models of Gildemeister lathes and Deckel Maho machining centers. All our machines undergo thorough technical inspections. In addition to customers from Poland, our machines are purchased by clients all over Europe and parts of Asia. Every machine can be inspected under power during production, as we also provide contract machining services. After purchasing a machine from us, we provide operator training and can also assist in setting up part production at the customer’s site. We maintain long-term cooperation with many companies, supplying them with additional machine tools.

Condition: excellent (used), Year of construction: 2003, operating hours: 9,100 h, I have for sale a CNC LATHE DMG GILDEMEISTER CTX 310 V3 driven tools. TECHNICAL AND VISUAL CONDITION: Very Good Type: CNC Lathe Manufacturer: GILDEMEISTER Model: CTX 310 V3 Control: Heidenhain Data Pilot 4290 Country of manufacture: Germany Year of manufacture 2003 - Number of machine operating hours 9144 hours Machine parameters: - head: 12 - tools for VDI-30 holders + TurnPlus attachment - max. rpm 5000 /min. - C axis - driven tools - hydraulic tailstock - Through spindle - max. turning diameter X axis: 190 mm - max. turning length Z axis: 455 mm - cooling system - hydraulic chuck Three-jaw SMW AutoBlock Cgodpfx Abjvxxhfepsn - spindle bore Fi-50mm - chip conveyor - full programming instructions - Mechanical and Electrical Documentation - Machine weight: 3.8t. - loading included in the price Machine after a full inspection. 100% efficient. Connected and ready to work. WE ALSO TAKE CARE OF ALL PROCEDURES RELATED TO LEASING!!! Stal-Com has been selling, servicing and training CNC machines from the DMG group for 17 years. We specialize in all models of Gildemeister lathes and Deckel Maho Machining Centers. All machines undergo a meticulous technical inspection. Our machines are purchased by customers from all over Europe and part of Asia, in addition to customers from Poland. Each machine can be checked during production because we also do machining. After purchasing a machine in our company, we conduct training for the crew and we can also set up the production of parts at the customer's. We cooperate with many companies on the basis of permanent cooperation to which we supply subsequent machine tools

Condition: good (used), Year of construction: 2006, Machine is in good working condition Cgjdpfx Abjvax N Eopjn

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, turning length: 1,250 mm, turning diameter over cross slide: 500 mm, turning diameter: 390 mm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 450 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 1,300 mm, bar passage: 65 mm, total height: 2,700 mm, total length: 7,000 mm, total width: 3,000 mm, overall weight: 12,000 kg, Equipment: documentation/manual, Manufacturer: DMGMORI Type: CTXbeta1250TC Year of manufacture: 2008 (retrofit in 2022) Control: Siemens 840D Solutionline Number of axes: 5 axes Equipment: - automatic tool changer - swivel head as B-axis - belt filter system with internal cooling and chip conveyor - differential pressure clamping main/counter spindle - workpiece collection device - preparation for bar loader (optionally available) Technical data: Max. turning diameter 500 mm X-axis 450 mm Y-axis 100 mm Z-axis 1300 mm B axis 220 ° Spindle bore 65 mm Speed 5000 rpm Spindle power 34 kW Counter spindle speed 6000 rpm Counter spindle passage 52 mm Counter spindle power 20 kW Tool changer 24 B-axis mount HSK 63 B-axis spindle speed 12000 rpm B-axis power 22 kW Installation dimensions approx. L 7000 / W 2300 / H 2300 mm Weight approx. 8,000 kg Chip conveyor: Yes Coolant device: Yes Internal coolant supply: Yes Options: · Full cabin · NC swivel head as B-axis · Coolant device and chip conveyor · Documentation · Geometrically within the new machine tolerances Condition: - Machine fully functional - Geometry within the manufacturer's tolerance for new machines - All wear parts replaced Cgodpoubyv Refx Abpen Retrofit 2022: - Linear guides Z1 and Z2/3 replaced - Linear guide Y-axis replaced - Main and counter spindle overhauled - Milling spindle overhauled - B-axis (bearings and clamping) renewed - sliding plates overhauled - hoses and cables overhauled, drag chains revised - cabin doors repainted, viewing windows renewed - maintenance carried out according to manufacturer's specifications

Condition: excellent (used), Year of construction: 2013, operating hours: 30,000 h, functionality: fully functional, Control: Siemens 840 D Country of origin: EU – Poland Voltage: 400V Dimensions: 3082x2260x1775 mm (with chip pan), 4228x2260x1775 mm (with chip conveyor) Net machine weight: 3400 kg TECHNICAL DATA CTX 310 ecoline V1/V3 New Design Working range - Max. swing over bed: 330 mm - Max. swing over cross slide (X-axis): 260 mm - Max. turning diameter: Ø 200 mm - Chuck diameter: Ø 210 mm - X-axis travel: 182.5 mm - Z-axis travel: 455 mm - Centre height: 190 mm - Distance between centres: 581 mm Feed drives - Rapid traverse speed X/Z: 30 m/min - Control: Siemens Sinumerik 840D Slim Line - C-axis with Siemens control - Speed: 0 – 100 rpm - Torque: 112 Nm - Accuracy: < 0.04° Spindle - Spindle nose: 140 h5 mm - Front bearing inner diameter: 100 mm - Spindle bore: Ø 74.3 mm - Max. bar capacity: 51 mm - Main drive with Siemens control - Drive power (40% / 100% DC): 16.5 / 11 kW - Torque (40% / 100% DC): 166.5 / 112 Nm - Max. spindle speed: 5000 rpm Turret - Number of tool stations: 12 - Tool holder: DIN69880 (VDI 3425) - Shank diameter: 30 mm - Tool change (with indexing lock): 0.95 s - Tool change (without indexing lock): 0.4 s - Turret with Siemens control - Number of driven tools: 12 - Drive power (40% DC) at 4000 rpm: 8.4 kW - Torque (40%): 20 Nm - Max. speed: 4500 rpm Tailstock - Automatic stroke: 396 mm - Quill type: flange-mounted - Max. quill axial force: 400 daN Hydraulic unit - Tank capacity: 50 l - Max. pressure: 50 bar Cooling system - Tank capacity: 175 l - Capacity with conveyor: 200 l - Pump power: 0.85 kW - Pump output at 5 bar: 30 l/min Electrical connection - Max. power: 21 kVA - Voltage: 400V - Frequency: 50–60 Hz - Fuses: 33 A Pneumatics Codpsxdiarjfx Abpjgn - Compressed air connection: 6 bar

Condition: used, Year of construction: 2015, 3 axis cnc lathe DMG MORI CTX BETA 2000 Year of production 2015 Siemens 840D control C axis driven tools Tool head 16 positions Sauter VDI40 Max. workpiece diameter 600mm Max. workpiece length 2,000 mm Spindle clearance: Ø104mm Cgodpsulw Igjfx Abpjn Hydraulic support Measuring probe

Condition: ready for operation (used), Swing diameter over bed/face slide: 570mm/420mm, turning diameter: 420mm, turning length: 635mm, traverse path X/Z: 220mm/635mm, speed: 5000rpm, spindle bore: 79mm, max. bar diameter: 65mm. Tool positions: 12, driven tools: 6, tool holder: VDI 30, rapid traverse X/Z: 24m/30m/min. Machine dimensions X/Y/Z: approx. 3500mm/2500mm/2000mm, weight: approx. 4500kg. On-site inspection is possible. Cgsdpfx Abjv Uqcgopsn

Year of construction: 2009, condition: ready for operation (used), Turning diameter: 200mm, passage diameter: 330mm, passage diameter over cross slide: 260mm, travel X/Z: 160mm/460mm, feed X/Z: 24m/min, speed: 5000rpm, spindle clearance: 51mm, spindle power: 16.5kW/11kW, torque: 1665.5Nm/112Nm, tailstock: 400mm, tool positions: 12. Machine dimensions X/Y/Z: approx. 4200mm/1700mm/2300mm, weight: approx. 3500kg, control: Siemens Sinumerik 810D. Including chip conveyor. Documentation available. On-site inspection is possible. Cgsdpfxsv Dkb Is Abpjn

Year of construction: 1998, condition: ready for operation (used), Base machine CTX 200E with driven tools, C-axis and 1x back working. Includes DATAPILOT software package TurnPlus, cooling unit for control cabinet, hinge belt chip conveyor, discharge height: 1100mm including coolant tank, tool holder set for universal disc turret with tool holders for external machining, boring bar holders, tools with cylindrical shank holders, sealing plugs, reducing sleeves. Bar gripper, axial complete, workpiece pick-up device, tool spindles 3x axial for drilling/milling/tapping, 1x radial for drilling/milling/tapping, 1x for saw blades, collet chuck complete for main spindle, collet chuck complete for counter spindle, 17x DIN collets 173E round Ø 3-40mm, 2x DIN collets 173E, hex SW 7 and 12mm, 2x DIN collets 173E, square SW 8mm. Bar loading magazine IEMCA BOSS 542/32, guide channel set LW 13, additionally for IEMCA BOSS 542, 13x guide jaws for bar loading magazine IEMCA BOSS 542/32, Ø 8-41mm. With complete documentation. The machine has been idle for one year as the turret head is missing, no further defects known, operating hours unknown, without maintenance records. With bar loader and numerous tools. Cjdpfx Asw Tl Ifjbpjgn

Condition: ready for operation (used), operating hours: 31,819 h, turning diameter over cross slide: 290 mm, turning length: 600 mm, travel distance X-axis: 210 mm, travel distance Z-axis: 645 mm, rotational speed (max.): 5,000 rpm, - CNC lathe with EPL 2 control, equipped with round magnet. It was last used for fine contour turning of hardened components. (without chuck, tailstock and chip conveyor) Technical data Swing diameter over bed: 300 mm Swing diameter over face: 290 mm Travel path X: 210 mm Travel path Z: 645 mm Speed range: 25 - 5000 rpm Tool carrier: universal disk turret Codpfsqcu Uvex Abpegn Tool positions: 12 Tool holder: 30 mm (DIN 69 880)

Condition: good (used), Year of construction: 2002, functionality: fully functional, turning diameter over cross slide: 260 mm, turning diameter: 200 mm, spindle bore: 68 mm, overall weight: 3,200 kg, TECHNICAL DETAILS Turning diameter: 200 mm Cedpewbu E Dofx Abpsgn Turning diameter over cross slide: 260 mm Spindle bore: 68 mm Control: Siemens with ShopTurn MACHINE DETAILS Total weight: 3,200 kg EQUIPMENT - Driven tools (2 axial, 2 radial) - Schunk 201 chuck - Collet chuck including various collets - Various rotary plates

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, CNC Lathe Manufacturer: Gildemeister Cgsdpfexc Uq Tjx Abpon Model: CTX 420 linear V3 Year of Manufacture: 2003 Control Unit: Heidenhain Plus IT Swing diameter over bed: 680 mm Swing diameter over cross slide: 565 mm Cross travel: 260 mm Longitudinal travel: 635 mm Drive power (40/100%): 25/37 kW Speed range: 20 – 5000 rpm Weight approx.: 6500 kg Equipment: Driven tools: 12 stations Tool turret: 12-position Sauter turret VDI 30 Partly hollow clamping chuck Tailstock Automatic quill travel Quill taper: Mk 5 Chip conveyor Measuring arm Oil mist extraction unit Subject to prior sale and errors.

Condition: ready for operation (used), Year of construction: 2014, operating hours: 3,324 h, functionality: fully functional, turning diameter: 465 mm, travel distance X-axis: 300 mm, travel distance Z-axis: 1,050 mm, rotational speed (max.): 3,250 rpm, TECHNICAL DETAILS Max. swing diameter: 680 mm Max. swing diameter over cross slide: 465 mm Max. turning diameter: 465 mm X-axis travel: 300 mm Z-axis travel: 1,050 mm CNC control: SIEMENS SINUMERIK 840D Main Spindle Spindle head: 220h5 mm Bar capacity: 76/90 mm Spindle diameter at front bearing: 140 mm Chuck sizes: 250 mm Drive power (40/100% DC): 33/22 kW (AC) Max. torque (40/100% DC): 630/420 Nm Max. speed: 3,250 rpm Tool Turret Number of tool stations: 12 Driven tools: 6 Tool holder: VDI 40 Shank diameter: 40 mm Drive power (40% DC): 8.4 kW Max. torque: 20 Nm Max. speed driven tools: 4,000 rpm Tailstock Tailstock quill stroke: 850 mm Center taper: MK 4 Tailstock quill force: 1,200 daN Guides Ball screw X/Z axis (D x P): 40 x 10 mm MACHINE DETAILS Machine weight with chip conveyor: 8,100 kg Ergonomic control panel: SlimlinePanel Chip conveyor: hinged belt chip conveyor Coolant pressure: 5 bar High-performance coolant pump: 12 bar Csdpfx Aeww E Ibebpogn Connected load: 50 kVA Frequency: 50 Hz Operating hours: 14,828 h Spindle hours: 3,324 h EQUIPMENT - 12-position tool turret, VDI 40 mount - Hydraulic hollow clamping device - Sandvik tool kit - Chip conveyor - Self-centering, hydraulic steady rest SLU 3.1 - Mechanical oil mist separator type AFS 600 - Electric sliding door actuation - Tropical package for ambient temperatures up to 50°C

Condition: ready for operation (used), Year of construction: 2005, 1 unit of used CNC lathe with driven tools and Y-axis. Siemens control. Cedpowz Sgfefx Abpsgn
