Used Deckel Fp 4 A for sale (700)

Condition: used, Year of construction: 1987, - Lid Contour 3 CNC control - Sliding vertical milling head with extendable spindle - counter bearing for long milling arbors - Hydraulic tool clamp - Automatic speed gearbox - Automatic clamping in X/Y/Z axes - Automatic central lubrication - coolant device - direct path measurement - Collision protection clutch in Z/Y axes - year of construction 1987 Technical data Working range: - X-axis (longitudinal): 485 mm - Y-axis (transverse): 385 mm - Z-axis (vertical): 380 mm - Vertical quill stroke: 80 mm - Vertical milling head can be moved on headstock: 150 mm Main drive: - Motor: pole-changing three-phase AC brake motor and manual gearbox with clockwise/anticlockwise rotation - Power: 3.7 / 4.4 kW - 18 working spindle speeds: 50 - 2500 rpm - Step change: 1.25 Dsdpfxju Awlzo Aa Nocg - Tool holder: SK40 (M16) - Tool clamp: hydraulic Feed drive: - X-axis: 1 DC motor - Y- and Z-axis: 1 DC motor - All axes: ball screws - Feed speed programmable: 10 - 1000 mm/min - Rapid traverse X-/Y-/Z-axis: 2000 mm/min Universal table: - Number of T-slots: 7 - T-slot width: 14/H7 mm - T-slot spacing: 63 mm - Center bore Ø/depth: 63H6 / 8 - Distance from table center to screw-on surface: 260 mm - Max. Passage height (vertical milling spindle/table surface): 490 mm - Permissible load: 300 kg - Weight: 230 kg - Rotation range in horizontal position (axis C): 360 ° - Tilt range (axis A): +450 / -150 ° - Pivoting range (axis B): ± 450 ° - Measuring range with direct digital display: Resolution 360000 x 0.001 ° - Reduction ratios: 60:1 / 120:1 / 240:1 Installation: - Space requirement with safety area: approx. 2.3 x 2.5 m - Operating voltage: 400 V / 50 Hz - Total connected load: 7.5 kW / 9.5 kVA - Machine weight: approx. 1830 kg - Floor load: 3000 kg/m²

Condition: excellent (used), Year of construction: 2002, Control: 3-axis active path control, Heidenhain TNC 123 Spindle speed: 40 - 2000 rpm, geometrically stepped direct drive with 16 gear stages for maximum torque / milling performance Djdpfxeyg I Nfs Aa Nscg Feed rate: 5 to 500 mm/min, infinitely variable Rapid traverse: 1.2 m/min Quill: Extendable vertical quill, 60 mm, SK40 M16 draw thread Axes X/Y/Z: 300/160/340 mm Swivel table: 600 x 210 mm, max. load 200 kg

Condition: used, x-travel 560 mm y-travel 500 mm z-travel 450 mm Dodjyutuvjpfx Aa Necg table surface area 900x520 mm turning speeds 4000 U/min tool taper SK 40 Control Heidenhain type TNC 355 elec. weight of the machine ca. 2,7 t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 2001, DECKEL MAHO DMU 80T MACHINING CENTRE, 4 AXES CNC HEID. 430 X 880 Y 630 Z 630 Automatic 90° x 90° head Spindle 12,000 rpm / 7,400 spindle hours ATC with 32 tool positions SK 40 Dsdpfxjyt Sh Se Aa Nocg Very good condition

Condition: ready for operation (used), Year of construction: 2006, machine/vehicle number: 29110004034, functionality: fully functional, operating hours: 9,442 h, travel distance X-axis: 1,040 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, number of slots in tool magazine: 30, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Dcedpfx Aowa Tmwoa Nog Control: Siemens 810D Powerline Table surface: 1,250 x 600 mm X-axis travel: 1,040 mm Y-axis travel: 600 mm Z-axis travel: 500 mm Spindle & tool holder Tool holder: SK 40 Spindle speeds: 1 - 12,000 rpm Spindle drive: 13 kW / 19 kW (100% / 40% ED) Tool changer: 30 positions MACHINE DETAILS Spindle hours: 9,442 h On-time: 32,189 h EQUIPMENT - Linear drive in the X-axis for more precise movements - Bed flushing to clean the work area - Spiral chip conveyor for efficient chip disposal - Direct position measuring system for precise Position determination - Temperature compensation of the Z-axis via temperature sensor with active cooling unit - Blown air from outside via two pipes for chip removal

Condition: ready for operation (used), CNC Milling Machine, Deckel FP4NC, Used machine Manufacturer: Deckel Model: FP4NC Serial number: 31549 Travel range (per axis): X-axis: 560 mm Y-axis: 500 mm Z-axis: 450 mm Table specifications: Length: 900 mm Width: 530 mm Dcsdewrdu Aopfx Aa Njg Max load capacity: 450 kg Feed rates: X-axis: 3600 mm/min Y-axis: 3600 mm/min Z-axis: 3600 mm/min Spindle specifications: Spindle taper: ISO 40 / BT / MK Spindle power: 7.5 kW Max speed: 5000 RPM

Condition: like new (used), functionality: fully functional, Universal milling machine Deckel FP3 with new 3-axis FPS active digital display Heidenhain General overhaul by FPS 2015 Mint condition Technical data: >> Year of construction 1980 Machine no. 2201-5045 >> Rigid angle table >> Speed: 25 - 2500 rpm >> Infinitely variable feed in 3 axes >> rapid traverse in 3 axes >> Drive power .:2,0 / 4,0 KW Djdpfxsu Dm E Ho Aa Necg >> Spindle brake >> Travel X/Y/Z: 500/300/400 mm >> Vertical milling head can be moved 200 mm on headstock >> Vertical quill and horizontal quill - SK40 extendable >> Tightening system M16 >> Weight approx. 1500 kg Accessories and equipment: >> 3 axes active digital display Heidenhain (latest version) >> Coolant device >> Central lubrication To the machine : On offer is a Deckel FP3 universal milling machine in mint condition. The FP3 was overhauled by FPS in 2015 and has only been used a little since then. The machine has little crank play and all spindles can be moved easily. On this newer FP3 model, the feed is infinitely variable in three axes, and the machine also has a rapid traverse for each axis. A major advantage is the active 3-axis digital display. With this Heidenhain line control you can enter dimensions which the machine automatically approaches. An oil change has been carried out. Mechanically and electrically tested. The digital display from Heidenhain makes work easier and even more precise. Take the opportunity to inspect and try out this machine on site under power. The machine is available immediately.

Condition: used, Flat belt pulley, toothed pulley, multi-belt pulley Djdpfeffh Nzox Aa Njcg -Spare part comes: from a machining center cover type FP3A -Diameter: 80 mm -Recording: 28 mm -Dimensions: 80/80/H61 mm -Weight: 1.2 kg

Condition: good (used), Electric motor, three-phase motor, brake motor -Manufacturer: Siemens, electric motor type 1LC3113-4BB23 Z from milling machine Deckel FP4L -Power: 4.0 kW Dcodpfx Aaoul H Dwe Njg -Speed: 1435 rpm -Design: B14 -Protection class: IP 44 -Brake: multi-disc brake type EK5dB24 -Dimensions: 575/270/H225mm -Weight: 64 kg

Condition: used, Control panel, operating unit, control board, operating panel, operating unit, keyboard, CNC control -Manufacturer: Deckel, control unit from milling machine Deckel FP4L -Transport dimensions: 1200/800/H220 mm Dsdpfx Aaoul H Eze Nocg -Weight: 33 kg

Condition: good (used), Universal milling head, milling chuck, milling extension, angle milling head -Manufacturer: Deckel, milling head from milling machine FP4L -Mounting: SK40 -Milling head: swiveling -Tool clamp: electric motor -Individual components: see photos -Transport dimensions: 1690/360/H745 mm -Weight: 548 kg Djdpfx Ajulp Aisa Necg

Condition: used, Rotary encoder, tachometer, encoder -Spare part comes: from a machining center cover type FP3A -Number: 1x speedometer available -Price: per piece -Dimensions: 83/122/H95 mm Dsdoffh N Aepfx Aa Njcg -Weight: 1.1 kg

Year of construction: 1980, condition: ready for operation (used), Max. rotational speed: 2500/min, feed rate: 5-500mm/min. Dcedpfxsfdzzyj Aa Neg

Condition: reconditioned (used), Year of construction: 1984, functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 150 mm, travel distance Z-axis: 340 mm, quill stroke: 80 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 40 rpm, table length: 210 mm, table width: 600 mm, total height: 1,750 mm, total length: 1,400 mm, total width: 1,600 mm, rotational speed (max.): 2,000 rpm, rotational speed (min.): 40 rpm, overall weight: 850 kg, table load: 200 kg, warranty duration: 3 months, The machine underwent a factory or partial overhaul by us in 2026 and is in top condition. As part of the partial overhaul, a new brake motor was installed. Control System 3-axis – active – digital display HEIDENHAIN TNC 113 Spindle Speed 40–2000 rpm, geometrically stepped direct drive with 18 speed levels for maximum torque and milling performance Feed Rate 5 to 500 mm/min, infinitely adjustable Rapid Traverse 1.2 m/min Quill Extendable quill, vertical 80 mm SK40 with M16 drawbar thread, optionally with DECKEL saw thread S20 x 2 Extendable quill, horizontal approx. 100 mm Axes X/Y/Z 300/150/340 mm Table Fixed angle table 600x210 mm Maximum table load: 200 kg Features • Vertical and horizontal spindle • Milling head manually swivelable +/- 90° Dcsdpsyi Amwsfx Aa Nsg • Z-axis bellows Options • Chip tray • Machine lamp • Universal table • Rotary table • Slotting head • Dividing head • Steady rest • etc.

Condition: reconditioned (used), Year of construction: 1988, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 50 rpm, quill stroke: 60 mm, total height: 1,935 mm, total length: 2,000 mm, total width: 200 mm, rotational speed (max.): 2,500 rpm, rotational speed (min.): 50 rpm, type of input current: three-phase, overall weight: 1,445 kg, table length: 460 mm, workpiece weight (max.): 400 kg, table load: 400 kg, table width: 800 mm, year of last overhaul: 2013, warranty duration: 6 months, The machine was completely and professionally overhauled by us in 2013. We were able to repurchase the machine from a customer who had used it very little, and we fully serviced and inspected it. Control 3-axis - Active - Digital display HEIDENHAIN TNC 113 Speed 50 - 2500 rpm, geometrically stepped direct drive with 18 speed stages for maximum torque / milling performance Feed 6.3 to 630 mm/min, steplessly adjustable Rapid Traverse 1.3 m/min Quill Extendable quill, vertical 60 mm, SK40 with M16 drawbar thread, optionally: with DECKEL - saw thread S20 x 2 Extendable quill, horizontal approx. 100 mm Axes X/Y/Z 500/400/400 mm Table Rigid angle table 800x460 mm Equipment • Vertical and horizontal spindle • Milling head manually swivels +/- 90° • Central lubrication Options • Z-axis bellows • Chip tray • Machine lamp Djdpeyitxqefx Aa Nscg • Universal table • Rotary table • Slotting head • Dividing attachment • Counter-holder • etc.

Condition: new, Year of construction: 2026, General refurbished, as good as new machine, modernized to the legally prescribed safety standard "state of the art" according to the safety regulations of the employers' liability insurance associations. Switch cabinet electronics Installation of a new CE - control cabinet according to the current legal regulations of the professional associations BGVA 3 / DIN-EN 60204-1 new machine standard. Optionally complete machine in CE execution. A CE declaration of conformity is issued for the machine. With this FPS Werkzeugmaschinen GmbH acts as manufacturer. The machine fulfills the requirements of the BETRIEBS-SICHERHEITSVERORDNUNG- Betr.SichV. The year of manufacture corresponds to the date of delivery of the machine. EN ISO 12100, EN ISO 13857, DIN EN 13128:2009-09, EN ISO 13850, EN ISO 13849, EN 60204-1 Control system 3-axis - FPS active - digital display Speed 50 - 2500 rpm geometrically stepped direct gear with 18 speed steps for maximum torque / milling performance Feed rate 6,3 to 630 mm/min, infinitely variable rapid traverse 1,3 m/min Quill Extendable quill, vertical 60 mm SK40 with M16 tightening thread optional: with DECKEL - saw thread S20 x 2 Extendable quill, horizontal approx. 100mm Axes X/Y/Z 500/400/400 mm Table Rigid angular table 800x460mm Equipment - Vertical and horizontal spindle - Milling head manually tiltable +/- 90 °. Options - Z-axis bellows - chip tray - machine light - central lubrication Dsdpfoh R S Tcox Aa Necg - universal table - rotary table - Shaper head - dividing head - counterholder - etc.

Year of construction: 1987, condition: ready for operation (used), Offered is a Deckel FP4NC vertical milling machine with Heidenhain TNC 355 control. Year 1987, including tool cabinet as well as various tools. Travel distances: X/Y/Z: 560mm/500mm/410mm, dimensions X/Y/Z: approx. 1800mm/1600mm/2000mm, weight: approx. 2400kg. Viewing is possible by appointment. Dcsdjxyk Upepfx Aa Nog

Condition: ready for operation (used), Deckel Maho 5100027000 Touch Panel for Deckel Maho CNC 432 control, serial number as per photo, used, normal signs of use, 100% functional, scope of delivery as per photos Djdpfsi D Upgex Aa Njcg

Condition: ready for operation (used), Year of construction: 2002, operating hours: 38,040 h, functionality: fully functional, travel distance X-axis: 1,040 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, rotational speed (max.): 12,000 rpm, number of slots in tool magazine: 30, TECHNICAL DETAILS CNC Control: Heidenhain iTNC530 X-axis: 1,040 mm Y-axis: 600 mm Z-axis: 500 mm Linear drive: On the X-axis Worktable Dimensions: 1,250 mm x 600 mm Max. workpiece weight: 800 kg Spindle Spindle operating hours: 38,040 h Spindle speed: 12,000 rpm Tool System Taper type: SK-40 Tool magazine capacity: 30 Tool diameter: 100 mm Max. tool diameter with empty neighboring pockets: 140 mm Max. tool length: 300 mm Max. tool weight: 7 kg MACHINE DETAILS Djdjxal Rxjpfx Aa Nscg Length: 3,750 mm Width: 2,340 mm Height: 3,164 mm Weight: 8,900 kg EQUIPMENT - Direct measurement system - Blum tool laser measurement for tool length and diameter - Chip conveyor - Bed flushing - Electronic handwheel

Condition: ready for operation (used), Year of construction: 2002, operating hours: 23,838 h, functionality: fully functional, travel distance X-axis: 640 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, workpiece weight (max.): 600 kg, rotational speed (max.): 12,000 rpm, TECHNICAL DETAILS X-axis travel: 640 mm Y-axis travel: 600 mm Z-axis travel: 500 mm Control: Heidenhain iTNC 530 External length: 850 mm External width: 630 mm Max. table load: 600 kg Dcsdpfxjwtq Rgs Aa Nsg Spindle speed range: 12,000 rpm Tool holder: SK 40 MACHINE DETAILS Operating hours: 107,000 h Spindle hours: 23,838 h

Condition: excellent (used), Year of construction: 1987, functionality: fully functional, Universal Milling Machine Deckel FP4M with 3-Axis Heidenhain Digital Readout, Special Paint Finish in Light Grey, CE Compliant!!! Technical Specifications: - Year of manufacture: 1987 Machine no.: 2203-2790 - Rigid angle table (freshly planed) - Spindle speed: 50–2500 rpm - Feed rate: 8–630 mm/min - Drive power: 3.7 / 4.4 kW - Spindle brake - Rapid traverse: 1300 mm/min - Travel X/Y/Z: 500/400/400 mm - Vertical milling head on column adjustable by 150 mm - Vertical and horizontal quill – SK40 - Vertical quill extendable by 90 mm - Drawbar thread: M16 - Weight approx. 1500 kg Dcodpsxctyajfx Aa Nsg Accessories & Features: - 3-axis Heidenhain digital readout - Coolant system - Chip tray - Central lubrication system About the machine: For sale is a Deckel FP4M universal milling machine, CE compliant and in very good condition. The machine has been partially overhauled, displays minimal backlash on the handwheels, and all lead screws move smoothly and evenly. Even at maximum speeds, the milling machine runs quietly. Rapid traverse is available on all axes; all bellows are new. The rigid angle table has been freshly planed. This is a reliable and user-friendly machine. An oil change has been performed. Mechanically and electrically tested. The Heidenhain digital readout makes operation easier and even more precise. Take advantage of the opportunity to inspect and test the machine under power on site.

Condition: like new (used), Year of construction: 1987, functionality: fully functional, Equipment: documentation/manual, Universal milling machine Deckel FP1 with 3-axis active digital display TNC 113 Heidenhain and infinitely variable feed Mint CONDITION Technical data: >> Year of manufacture 1987 Machine no. 2102-3536 >> Rigid angle table >> Speed: 40 - 2000 rpm >> Infinitely variable feed in 3 axes Dodpeu R D I Sofx Aa Nocg >> Rapid traverse in 3 axes >> Drive power .:1,5 / 1,9 KW >> Spindle brake >> Travel X/Y/Z: 300/160/340 mm >> Vertical milling head can be moved 100 mm on headstock >> Vertical quill and horizontal quill - SK40 >> Tightening system S20x2 >> Weight approx. 800 kg Accessories and equipment: >> 3-axis digital readout Heidenhain TNC113 >> Electric central lubrication >> Machine lamp >> Coolant device >> Operating instructions, spare parts plan About the machine : Ccbroxg Universal milling machine Deckel FP1 built in 1987 in mint original condition. The machine has very little crank play and all spindles can be moved easily. The milling machine runs very smoothly even at maximum speeds. On this newer FP1 model, the feed is infinitely variable in three axes, and the machine also has rapid traverse in these axes. A great advantage is the active 3-axis digital display. With this Heidenhain line control you can enter dimensions which the machine automatically approaches. The FP1 was in a training company where it was only used occasionally. An oil change was carried out. Mechanically and electrically tested. The Heidenhain digital display makes work easier and even more accurate. Take the opportunity to inspect and try out this little gem under power on site.

Condition: excellent (used), functionality: fully functional, Equipment: documentation/manual, F736 Universal milling machine Deckel FP1 with 3-axis active digital readout TNC 111 Heidenhain 2008 Retrofit at FA Huttelmaier Very good CONDITION Technical data: >> Year of construction 1985 Machine no. 2102-2891 >> Rigid angle table >> Speed: 40 - 2000 rpm >> Infinitely variable feed in 3 axes >> Rapid traverse in 3 axes >> Drive power .:1,5 / 1,9 KW >> Spindle brake >> Travel X/Y/Z: 300/160/340 mm >> Vertical milling head can be moved 100 mm on headstock >> Vertical quill and horizontal quill - SK40 >> Tightening system S20x2 >> Weight approx. 800 kg Accessories and equipment: Dedpfx Aju Nvwvoa Nocg >> 3-axis digital readout Heidenhain TNC111 >> Coolant device >> Operating instructions, spare parts plan To the machine : Universal milling machine Deckel FP1 built in 1985 in very good condition. The FP1 was overhauled by Huttelmaier in 2008. The machine has very little crank play and all spindles can be moved easily. The milling machine runs very smoothly even at maximum speeds. On this newer FP1 model, the feed rate is infinitely variable in three axes, and the machine also has rapid traverse in these axes. A great advantage is the active 3-axis digital display. With this Heidenhain line control you can enter dimensions which the machine automatically approaches. The FP1 was in a training company where it was only used occasionally. An oil change was carried out. Mechanically and electrically tested. The Heidenhain digital display makes work easier and even more accurate. Take the opportunity to inspect and try out this little gem under power on site.

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, Equipment: documentation/manual, F729 Universal milling machine Deckel FP1 with 3-axis active digital readout TNC 113 Heidenhain and stepless feed very good CONDITION Technical data: >> year of construction 1992 machine no. 2102-6289 >> Rigid angle table (newly planed) >> Speed: 40 - 2000 rpm >> Infinitely variable feed in 3 axes >> Rapid traverse in 3 axes >> Drive power: 1.5 / 1.9 KW >> Spindle brake >> Travel X/Y/Z: 300/160/340 mm Dcedpfx Aju T D Nrea Njg >> Vertical milling head can be moved 100 mm on headstock >> Vertical quill and horizontal quill - SK40 >> Tightening system S20x2 >> Weight approx. 800 kg Accessories and equipment: >> 3-axis digital readout Heidenhain TNC113 Bmbwuweo9T3 >> Coolant device >> Operating instructions, spare parts plan To the machine : We offer a Deckel FP1 universal milling machine built in 1992 in very good condition. The machine has very little crank play and all spindles can be moved easily. The milling machine runs very smoothly even at maximum speeds. On this newer FP1 model, the feed is infinitely variable in three axes, and the machine also has rapid traverse in these axes. A great advantage is the active 3-axis digital display. With this Heidenhain line control you can enter dimensions which the machine automatically approaches. The FP1 was in a training company where it was only used occasionally. An oil change was carried out. Mechanically and electrically tested. The Heidenhain digital display makes work easier and even more accurate. Take the opportunity to inspect and try out this machine under power on site.

Condition: excellent (used), functionality: fully functional, Universal Milling Machine Deckel FP1 with 3-Axis Active Digital Readout TNC 113 Heidenhain and Infinitely Variable Feed, Light Grey, Excellent Condition Technical Data: >> Year of manufacture: approx. 1990, Machine no. 2102-5231 >> Fixed angle table >> Spindle speed: 40 - 2000 rpm >> Infinitely variable feed on all 3 axes >> Rapid traverse in 3 axes >> Drive power: 1.5 / 1.9 kW >> Spindle brake Dcodpsxu E R Isfx Aa Njg >> Travel X/Y/Z: 300/160/340 mm >> Vertical milling head adjustable by 100 mm on spindle carrier >> Vertical and horizontal quill - SK40 >> Drawbar system M16 >> Weight: approx. 800 kg Accessories and Equipment: >> 3-axis digital readout Heidenhain TNC113 >> Central electric lubrication >> Coolant system >> Operating manual, spare parts diagram About the Machine: Offered is a Universal Milling Machine Deckel FP1 in very good condition in light grey. The machine has minimal backlash and all spindles move smoothly. Even at maximum spindle speeds, the milling machine runs very quietly. In this newer FP1 model, the feed is infinitely variable in all three axes; in addition, rapid traverse is available in these axes. A significant advantage is the active 3-axis digital readout. With this Heidenhain positioning control, you can input dimensions that the machine will automatically move to. The FP1 was previously used in a training workshop, where it was only operated occasionally. The oil has been changed. Mechanically and electrically inspected. The Heidenhain digital readout makes working easier and even more precise. Take advantage of the opportunity to view and test this exceptional machine under power on site. The machine is available immediately.
