Listing
Turkey
5,223 km
40/15 TON COLUMN-TYPE HYDRAULIC DEEP DRAWING PRESS
CRONOSSTECHCHKSP 40/15
Call
Condition: new, Year of construction: 2025, pressing force: 40 t, table width: 700 mm, table length: 700 mm, clearance between the columns: 700 mm, retraction force: 15 t, stroke length: 400 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH 40/15 TON FOUR-COLUMN HYDRAULIC DRAWING PRESS
General Description
The CRONOSSTECH 40/15 ton four-column hydraulic drawing press is a compact and robust press solution designed for precision metal forming, deep drawing, and metal spinning applications. Thanks to its four-column frame construction, parallelism and perpendicularity tolerances remain stable throughout the pressing cycle.
The press frame, manufactured from St52 grade steel, undergoes stress relief via vibration treatment. The ram and punch systems can be controlled independently, with stroke and pressure adjustments performed precisely through the touchscreen panel.
Equipped with REXROTH or PARKER hydraulic components, IE3 class motor, and automatic lubrication system, this machine ensures long-lasting, safe, and efficient operation. The user-friendly PLC-controlled design minimizes operator errors.
This model is an ideal solution for small to medium-scale spinning, deep drawing, die trial, and precision pressing applications.
Key Advantages
- Rigid four-column press frame design
- Independent stroke and tonnage control for ram and pot
- Adjustable system via touchscreen panel
- High accuracy and repeatability
- Low maintenance requirements and long service life
Areas of Application
- Metal spinning applications
- Deep drawing processes
- Die testing and prototyping
- Metalworking and auxiliary production lines
⚙️ STANDARD AND TECHNICAL SPECIFICATIONS
TYPE: Four-column
FRAME MATERIAL: St52 – ERDEMIR
COLUMN SHAFT DIAMETER: Ø 90 – 4 pcs. Induction-hardened and chrome-plated shafts
SLIDE BEARING: Bronze Zr14
CAPACITY (RAM): 40 Tons
CAPACITY (POT): 15 Tons
DISTANCE BETWEEN COLUMNS: 700 × 700 mm
PARALLELISM TOLERANCE: 120 micron/m
PERPENDICULARITY TOLERANCE: 60 micron/m
STROKE (RAM): 400 mm
STROKE (POT): 100 mm
MIN. DAYLIGHT: 100 mm
MAX. DAYLIGHT: 500 mm
WELDING STRESS RELIEF: Vibration stress relief
WELDING PROCEDURE: WPQR and WPS certified by TÜRK-AK, EN ISO 15614-1:2017 (EN ISO 14731)
MAX. WORKING PRESSURE: 250 Bar
Lsdsx N Uk Nspfx Abcohd
TOTAL MOTOR POWER: 5.5 kW – IE3
MAIN PUMP: 22 cm³ – REXROTH or PARKER
MOVING TABLE FAST DESCENT SPEED: 150 mm/sec
MOVING TABLE DRAWING SPEED: 12 mm/sec
MOVING TABLE RETURN SPEED: 170 mm/sec
POT TABLE FORWARD SPEED: 30 mm/sec
MAIN CYLINDER BORE DIAMETER: Ø 145 mm – Ck45
POT CYLINDER BORE DIAMETER: Ø 90 mm – Ck45
AUXILIARY ACCELERATION CYLINDERS: 2 units
APPROXIMATE PRESS HEIGHT: 3100 mm
APPROXIMATE PRESS WIDTH: 1050 mm
APPROXIMATE PRESS DEPTH: 1050 mm
DISTANCE FROM BASE TO LOWER TABLE: 1000 mm
PRE-FILL VALVE: NG 100
HYDRAULIC UNIT: REXROTH or PARKER
COOLING SYSTEM: EMMEGI – CIESSE – PARKER
OFF-LINE FILTRATION: REXROTH or PARKER
LUBRICATION TYPE: Automatic (adjustable from the panel)
RAM / POT STROKE AND TONNAGE ADJUSTMENT: Adjustable from the panel
SYSTEM & PRESS STATUS INFORMATION: Viewable from the panel
DIE MEMORY: Adjustable from the panel
LINEAR MEASURING SCALE: NOVATECHNIK or TURCK
PLC APPLICATION: DELTA
TOUCHSCREEN PANEL: DELTA 7”
SWITCHGEAR COMPONENTS: SIEMENS – SCHNEIDER
APPROXIMATE WEIGHT: 4.5 Tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H-type 2500/800 ton hydraulic deep drawing press
CRONOSSTECHCHSP 2500/800
Call
Condition: new, Year of construction: 2025, pressing force: 2,500 t, table width: 1,800 mm, table length: 2,600 mm, retraction force: 800 t, stroke length: 1,000 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 2500/800
H-Type Hydraulic Deep Drawing (Forming) Press – 8-Gibbed
General Description
The CRONOSSTECH CHSP series H-type hydraulic forming presses are engineered for heavy-duty deep drawing applications that require extremely high tonnage, large bed dimensions, and precise blankholder force. The 8-gibbed H-frame structure ensures high rigidity throughout the pressing process, maintaining parallelism and perpendicularity tolerances over the entire stroke.
The CHSP 2500/800 model provides maximum stability, controlled material flow, and repeatable production performance for large and deep drawing dies, with a 2500-ton main ram and 800-ton blankholder capacity. Its vibration-stress-relieved welded steel frame is designed for durability and reliability in heavy industrial conditions.
⚙️ Standard Equipment
• Welded steel construction, 8-gibbed H-frame press body
• Vibration stress-relieved frame
• Bronze Zr14 gibbed slideways
• WPQR- and WPS-approved welding applications with TÜRK-AK accreditation
(EN ISO 15614-1:2017 / EN ISO 14731)
• PLC-controlled hydraulic system
• 7” touchscreen panel (DELTA)
• Adjustable stroke control for ram and blankholder
• Adjustable tonnage (pressure) control for ram and blankholder
• Automatic lubrication system
• Electronic filter contamination warning
• Hydraulic oil temperature and system status monitoring on-screen
• Off-line filtration and industrial cooling system
• SIEMENS – SCHNEIDER switchgear components
• Heavy-duty industrial safety systems
Lhsdpfjx N Uk Asx Abcsd
📐 Technical Specifications – CHSP 2500/800
Type: Welded steel construction, 8-gibbed H-frame press
Frame Material: St52 – ERDEMİR
Slideway Bearings: Bronze Zr14
Capacity (Ram / Blankholder): 2500 / 800 Ton
Moving / Fixed Table: 1800 × 2600 mm
Parallelism / Perpendicularity: 120 / 60 micron/meter
Stroke (Ram / Blankholder): 1000 / 350 mm
Daylight Opening (Min / Max): 200 / 1200 mm
Max. Working Pressure: 250 Bar
Total Motor Power: 180 kW – IE3
Main Pump: 140 cm³ – REXROTH or PARKER
Main Cylinder: Ø565 mm – Ck45 (4 units)
Blankholder Cylinder: Ø450 mm – Ck45 (2 units)
Pre-fill Valve: NG 200
PLC / Panel: DELTA / DELTA 7”
Approximate Weight: 132 Tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H Type 2000/600 directional hydraulic deep drawing press
CRONOSSTECHCHSP 2000/600
Call
Condition: new, Year of construction: 2025, pressing force: 2,000 t, table width: 1,500 mm, table length: 2,500 mm, retraction force: 600 t, stroke length: 1,000 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 2000/600
H-Type Hydraulic Deep Drawing (Stamping) Press – 8-Gib Design
General Description
The CRONOSSTECH CHSP Series H-type hydraulic deep drawing presses are engineered for heavy-duty deep drawing applications that require extremely high tonnage, large table dimensions, and controlled blank holder force. Thanks to its 8-gib H-frame construction, ram and table movements are carried out under high rigidity throughout the pressing cycle, maintaining strict parallelism and perpendicularity tolerances even across long strokes.
The CHSP 2000/600 model offers high precision and repeatability in large-volume die, deep drawing, and stamping operations with its 2000-ton main ram and 600-ton blank holder capacity. Its stress-relieved, steel-welded frame structure is designed for longevity and reliability under heavy industrial conditions.
⚙️ Standard Features
Ledpfx Abex N Ukvscohd
• Steel-welded construction, 8-gib H-frame press body
• Stress-relieved frame through vibration methods
• Zr14 bronze gib bushings
• WPQR and WPS certified welding by TÜRK-AK accredited standards (EN ISO 15614-1:2017 / EN ISO 14731)
• PLC-controlled hydraulic system
• 7” DELTA touchscreen panel
• Adjustable ram and blank holder stroke controls
• Adjustable tonnage (pressure) control for ram and blank holder
• Automatic lubrication system
• Electronic hydraulic filter contamination warning
• On-screen monitoring of hydraulic oil temperature and system status
• Offline filtration and industrial cooling system
• SIEMENS – SCHNEIDER electrical components
• Industrial safety systems for operator protection
📐 Technical Specifications – CHSP 2000/600
Type: Steel-welded, 8-gib H-frame press body
Frame Material: St52 – ERDEMİR
Gib Bushings: Zr14 bronze
Capacity (Ram / Blank Holder): 2000 / 600 tons
Moving / Fixed Table: 1500 × 2500 mm
Parallelism / Perpendicularity: 120 / 60 microns/m
Stroke (Ram / Blank Holder): 1000 / 350 mm
Daylight (Min / Max): 200 / 1200 mm
Max. Working Pressure: 250 bar
Total Motor Power: 180 kW – IE3
Main Pump: 140 cm³ – REXROTH or PARKER
Main Cylinder: Ø720 mm – Ck45 (2 pcs)
Blank Holder Cylinder: Ø390 mm – Ck45 (2 pcs)
Pre-Fill Valve: NG 200
PLC / Panel: DELTA / DELTA 7”
Approximate Weight: 105 tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.

Get information now
+44 20 806 810 84
+44 20 806 810 84
List now
*per listing / month
Listing
Turkey
5,223 km
H type 1500/500 ton hydraulic deep drawing press
CRONOSSTECHCHSP 1500/500
Call
Condition: new, Year of construction: 2025, pressing force: 1,500 t, table width: 1,500 mm, table length: 2,400 mm, retraction force: 500 t, stroke length: 1,000 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 1500/500
H-Type Hydraulic Deep Drawing (Forming) Press – 8-Guided
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses are engineered for maximum frame rigidity, precise parallelism, and long-lasting operation in high-tonnage deep drawing applications requiring large bolster dimensions. Thanks to the 8-guide H-frame body, the ram and table movements remain controlled and stable throughout the pressing process.
The CHSP 1500/500 model, with 1500-ton main ram and 500-ton blank holder capacity, is developed for large-dimension dies, deep drawing, and precise forming operations. The vibration stress-relieved welded steel frame delivers high durability and reliability under heavy-duty industrial conditions.
⚙️ Standard Equipment
• Welded steel construction, 8-guide H-frame design
• Vibration stress-relieved frame structure
• Bronze Zr14 slide bearings
• WPQR and WPS certified welding procedures with TÜRK-AK accreditation (EN ISO 15614-1:2017 / EN ISO 14731)
• PLC-controlled hydraulic system
• Touchscreen panel (DELTA 7”)
• Adjustable ram and blank holder stroke control
• Adjustable ram and blank holder tonnage (pressure) control
• Automatic lubrication system
• Electronic contamination warning for the filter
• Monitoring of hydraulic oil temperature and system status via display
• Off-line filtering and industrial cooling system
• SIEMENS – SCHNEIDER electrical components
• Industrial safety systems for operator protection
📐 Technical Specifications – CHSP 1500/500
Type: Welded steel construction, 8-guide H-frame design
Frame Material: St52 – ERDEMİR
Guide Bearings: Bronze Zr14
Capacity (Ram / Blank Holder): 1500 / 500 tons
Lhsdpfxjx N Ukio Abced
Moving / Fixed Table: 1500 × 2400 mm
Parallelism / Perpendicularity: 120 / 60 micron/meter
Stroke (Ram / Blank Holder): 1000 / 350 mm
Daylight Opening (Min / Max): 200 / 1200 mm
Max. Operating Pressure: 250 bar
Total Motor Power: 90 kW – IE3
Main Pump: 101 cm³ – REXROTH or PARKER
Main Cylinder: Ø620 mm – Ck45 (2 units)
Blank Holder Cylinder: Ø360 mm – Ck45 (2 units)
Pre-Fill Valve: NG 200
PLC / Panel: DELTA / DELTA 7”
Approximate Weight: 87 tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H-type 1200/400 ton hydraulic deep drawing press
CRONOSSTECHCHSP 1200/400
Call
Condition: new, Year of construction: 2025, pressing force: 1,200 t, table width: 1,500 mm, table length: 2,000 mm, retraction force: 400 t, stroke length: 1,000 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 1200/400
H-Type Hydraulic Deep Drawing (Stamping) Press – 8 Guideways
General Description
The CRONOSSTECH CHSP series H-type hydraulic stamping and deep drawing presses are designed to deliver maximum rigidity, precision, and process control in sheet metal forming applications requiring high tonnage.
The 8-guideway H-frame structure ensures stable maintenance of parallelism and perpendicularity tolerances even with large table dimensions.
The CHSP 1200/400 model, featuring a 1200-ton main ram and a 400-ton blank holder capacity, is tailored for heavy industry applications requiring deep drawing, stamping, and controlled material flow. Its vibration-stress-relieved steel construction frame guarantees long-lasting and reliable performance.
⚙️ Standard Equipment
• Steel construction, 8 guideway H-frame press body
• Vibration stress-relieved frame structure
• Bronze Zr14 gib guides
• WPQR and WPS certified welding by TURKAK-accredited institutions
(EN ISO 15614-1:2017 / EN ISO 14731)
• PLC-controlled hydraulic system
• 7'' DELTA touchscreen panel
• Adjustable ram and blank holder stroke control
• Adjustable ram and blank holder tonnage (pressure) control
• Automatic lubrication system
• Electronically controlled filter contamination warning
• Monitoring of hydraulic unit oil temperature and system status on screen
• Offline filtration and industrial cooling system
• SIEMENS – SCHNEIDER industrial switchgear
• Industrial safety features for operator protection
📐 Technical Specifications – CHSP 1200/400
Type: Steel construction, 8 guideway H-frame body type
Frame Material: St52 – ERDEMIR
Gib Guide Material: Bronze Zr14
Capacity (Ram): 1200 Tons
Capacity (Blank Holder): 400 Tons
Ledpfx Asx N Uirsbcehd
Moving / Fixed Table: 1500 × 2000 mm
Parallelism / Perpendicularity: 120 / 60 micron/meter
Stroke (Ram / Blank Holder): 1000 / 350 mm
Clearance (Min / Max): 100 / 1100 mm
Max. Working Pressure: 250 Bar
Total Motor Power: 75 kW – IE3
Main Pump: 70 cm³ – REXROTH or PARKER
Main Cylinder: Ø560 mm – Ck45 (2 units)
Blank Holder Cylinder: Ø450 mm – Ck45
Pre-fill Valve: NG 200
PLC / Panel: DELTA / DELTA 7”
Approximate Weight: 75 Tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H-Type 1000/350 Ton Hydraulic Deep Drawing Press
CRONOSSTECHCHSP 1000/350
Call
Condition: new, Year of construction: 2025, pressing force: 1,000 t, table width: 1,500 mm, table length: 2,000 mm, retraction force: 350 t, stroke length: 1,000 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 1000/350
H-Type Hydraulic Deep Drawing (Spinning) Press – 8-Guided Slides
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses are engineered with a double-acting (ram + blank holder) system architecture for high-tonnage sheet metal forming, deep drawing, and spinning applications. Thanks to its 8-guide H-frame structure, high rigidity is ensured during pressing operations, and parallelism and perpendicularity tolerances are consistently maintained even with large bed dimensions.
The CHSP 1000/350 model, featuring a 1000-ton main ram and 350-ton blank holder capacity, is specifically designed for deep drawing processes requiring controlled material flow—ideal for applications in automotive, white goods, defense, and heavy industries. The welded steel construction, stress-relieved by vibration, guarantees long-term, reliable operation.
⚙️ Standard Equipment
• Welded steel construction, 8-guide H-frame press body
• Vibration stress-relieved frame structure
• Bronze Zr14 slide bearings
• WPQR and WPS certified welding, TÜRK-AK accredited (EN ISO 15614-1:2017 / EN ISO 14731)
• PLC-controlled hydraulic system
• 7” DELTA touchscreen control panel
• Adjustable ram and blank holder (pot) stroke control
• Adjustable ram and blank holder (pot) tonnage (pressure) control
• Automatic lubrication system
• Electronically monitored filter contamination warning
• On-screen monitoring of hydraulic unit oil temperature and system status
• Off-line filtration and cooling system
• SIEMENS – SCHNEIDER electrical components
• Safety systems for operator protection
📐 Technical Specifications – CHSP 1000/350
Type: Welded steel construction, 8-guide H-frame press body
Frame Material: St52 – ERDEMİR
Slide Bearing: Bronze Zr14
Capacity (Ram): 1000 tons
Capacity (Blank Holder): 350 tons
Moving/Fixed Table: 1500 × 2000 mm
Parallelism / Perpendicularity: 120 / 60 micron/meter
Stroke (Ram / Blank Holder): 1000 / 350 mm
Daylight Opening (Min / Max): 100 / 1100 mm
Lhodpfx Asx N Uilobced
Max. Operating Pressure: 250 Bar
Total Motor Power: 75 kW – IE3
Main Pump: 70 cm³ – REXROTH or PARKER
Main Cylinder: Ø500 mm – Ck45 (2 units)
Blank Holder Cylinder: Ø370 mm – Ck45
Pre-Fill Valve: NG 200
PLC / Panel: DELTA / DELTA 7”
Approximate Weight: 65 tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H-type 800/270 ton hydraulic deep drawing press
CRONOSSTECHCHSP 800/270
Call
Condition: new, Year of construction: 2025, pressing force: 800 t, table width: 1,500 mm, table length: 2,000 mm, retraction force: 270 t, stroke length: 1,000 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 800/270
H-Type Hydraulic Deep Drawing (Sinking) Press – 8-Guided
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses are designed based on the double-acting principle (ram + blank holder) for high-tonnage sheet metal forming, deep drawing, and sinking applications.
The 8-guided H-frame structure offers high rigidity, stable parallelism, and extended die life even with large table dimensions during the pressing process.
The CHSP 800/270 model, with its 800-ton main ram and 270-ton blank holder capacity, is specifically engineered for processes requiring controlled material flow in automotive, white goods, defense industry, and heavy sheet metal forming applications. The vibration stress-relieved steel frame ensures long-lasting and reliable operation.
⚙️ Standard Equipment
• Steel construction, 8-guided H-type press frame
• Vibration stress-relieved body structure
• Bronze Zr14 slide bearings
• WPQR and WPS certified welding (accredited by TÜRK-AK)
(EN ISO 15614-1:2017 / EN ISO 14731)
• PLC controlled hydraulic system
• Touch panel display (DELTA 7”)
• Adjustable ram and blank holder stroke control
• Adjustable ram and blank holder tonnage (pressure) control
• Automatic lubrication system
• Electronically monitored filter contamination alert
Lodpfx Abjx N Uh Uscohd
• Real-time monitoring of hydraulic unit oil temperature and system status via screen
• Off-line filtration and cooling system
• SIEMENS – SCHNEIDER electrical components
• Operator safety systems for maximum protection
📐 Technical Specifications – CHSP 800/270
Type: Steel construction, 8-guided H-type press frame
Frame Material: St52 – ERDEMİR
Slide Bearings: Bronze Zr14
Capacity (Ram): 800 Tons
Capacity (Blank Holder): 270 Tons
Moving Table Size: 1500 × 2000 mm
Fixed Table Size: 1500 × 2000 mm
Parallelism Tolerance: 120 micron/meter
Perpendicularity Tolerance: 60 micron/meter
Stroke (Ram): 1000 mm
Stroke (Blank Holder): 350 mm
Min. / Max. Daylight: 100 / 1100 mm
Max. Working Pressure: 250 Bar
Total Motor Power: 75 kW – IE3
Main Pump: 70 cm³ – REXROTH or PARKER
Main Cylinder: Ø390 mm – Ck45 (2 units)
Blank Holder Cylinder: Ø370 mm – Ck45
Pre-fill Valve: NG 200
PLC: DELTA
Touch Panel: DELTA 7”
Approximate Weight: 54 Tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H-type 600/200 ton hydraulic deep drawing press
CRONOSSTECHCHSP 600/200
Call
Condition: new, Year of construction: 2025, pressing force: 600 t, table width: 1,200 mm, table length: 1,500 mm, retraction force: 200 t, stroke length: 1,000 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 600/200
H-Type Hydraulic Deep Drawing (Spinning) Press – 8 Guideways
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses are engineered with a double-acting operating principle to ensure controlled material flow in sheet metal forming, deep drawing, and spinning applications. The 8-guideway H-frame structure provides maximum rigidity during pressing; parallelism and perpendicularity tolerances are stably maintained throughout the extended stroke length.
Model CHSP 600/200, featuring a 600-ton main ram and a 200-ton blankholder (cushion) capacity, is designed to ensure full control over the die and component during high-tonnage deep drawing and spinning operations. The frame structure is stress-relieved by vibration for durable and reliable performance.
⚙️ Standard Equipment
- Welded steel construction, 8-guideway H-frame press body
- Vibration stress-relieved frame structure
- Bronze Zr14 slide bearings
Lhsdpjx N Uhzjfx Abcsd
- WPQR and WPS certified welding by TÜRK-AK-accredited procedures (EN ISO 15614-1:2017 / EN ISO 14731)
- Design and manufacturing to CE standards
- PLC-controlled hydraulic system
- Touch panel display (DELTA 7”)
- Adjustable ram and cushion stroke control
- Adjustable ram and cushion tonnage (pressure) control
- Automatic lubrication system
- Electronically monitored filter clogging warning
- On-screen display of hydraulic unit oil temperature and system status
- Cooling system
- Off-line filtration
- Safety systems for operator protection
- SIEMENS – SCHNEIDER electrical components
📐 Technical Specifications — CHSP 600/200
- Type: Welded steel, 8-guideway H-frame press body
- Frame Material: St52 – ERDEMİR grade
- Slide Bearings: Bronze Zr14
- Capacity (Ram): 600 tons
- Capacity (Cushion): 200 tons
- Movable Table Size: 1200 × 1500 mm
- Fixed Table Size: 1200 × 1500 mm
- Parallelism Tolerance: 120 micron/meter
- Perpendicularity Tolerance: 60 micron/meter
- Ram Stroke: 1000 mm
- Cushion Stroke: 350 mm
- Min. Daylight: 100 mm
- Max. Daylight: 1100 mm
- Weld Stress Relief: By vibration
- Welding: WPQR and WPS certified by TÜRK-AK (EN ISO 15614-1:2017), supervised by certified “welding coordination engineers” (EN ISO 14731)
- Max. Working Pressure: 250 bar
- Total Motor Power: 55 kW – IE3
- Main Pump: 70 cm³ – REXROTH or PARKER
- Movable Table Fast Down Speed: 150 mm/s
- Movable Table Drawing Speed: 12 mm/s
- Movable Table Return Speed: 170 mm/s
- Cushion Advance Speed: 30 mm/s
- Main Cylinder Bore: Ø550 mm – Ck45
- Cushion Cylinder Bore: Ø320 mm – Ck45
- Auxiliary Acceleration Cylinders: 2 units
- Approx. Press Height: 5900 mm
- Approx. Press Width: 3250 mm
- Approx. Press Depth: 2300 mm
- Lower Table Height from Floor: 1400 mm
- Pre-fill Valve: NG 150
- Hydraulic Power Unit: REXROTH or PARKER
- Cooling System: EMMEGI – CIESSE – PARKER
- Off-line Filtration: REXROTH or PARKER
- Linear Scale: NOVATECHNIK or TURCK
- PLC System: DELTA
- Touch Panel Screen: DELTA 7”
- Electrical Components: SIEMENS – SCHNEIDER
- Approx. Weight: 35 tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H Type 500/175 ton hydraulic deep drawing press
CRONOSSTECHCHSP 500/175
Call
Condition: new, Year of construction: 2025, pressing force: 500 t, table width: 1,200 mm, table length: 1,500 mm, retraction force: 175 t, stroke length: 1,000 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 500/175
H-Type Hydraulic Deep Drawing (Forming) Press – 8-Guided
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses are developed with a double-acting working principle to ensure controlled material flow in sheet metal forming, deep drawing, and forming applications. The 8-guide H-frame construction provides maximum rigidity during the pressing process; parallelism and perpendicularity tolerances are stably maintained throughout the long stroke.
The CHSP 500/175 model features a 500-ton main ram and a 175-ton cushion ram (pot), designed to deliver complete control over the die and workpiece for high-tonnage deep drawing and forming operations. The machine frame is stress-relieved by vibration to ensure a durable and reliable operation.
⚙️ Standard Equipment
- Steel construction, 8-guide H-frame press body
- Stress-relieved frame by vibration
- Bronze Zr14 slide bushings
- WPQR and WPS certified welding applications, accredited by TÜRK-AK
(EN ISO 15614-1:2017 / EN ISO 14731)
- Design and manufacturing compliant with CE standards
- PLC-controlled hydraulic system
- 7” DELTA touchscreen panel
- Adjustable ram and cushion stroke control
- Adjustable ram and cushion tonnage (pressure) control
- Automatic lubrication system
- Electronic filter contamination alert
- Monitoring of hydraulic unit oil temperature and system status on the display
- Cooling system
- Off-line filtration
- Integrated operator safety systems
- SIEMENS – SCHNEIDER electrical components
📐 Technical Specifications – CHSP 500/175
- Type: Steel construction, 8-guide H-frame press body
- Frame Material: St52 – ERDEMIR
- Guide Bushing: Bronze Zr14
- Capacity (Ram): 500 Ton
- Capacity (Cushion): 175 Ton
- Moving Table Size: 1200 × 1500 mm
- Fixed Table Size: 1200 × 1500 mm
- Parallelism Tolerance: 120 micron/m
- Perpendicularity Tolerance: 60 micron/m
- Stroke (Ram): 1000 mm
- Stroke (Cushion): 350 mm
- Min. Daylight: 100 mm
- Max. Daylight: 1100 mm
- Stress Relief: Vibration stress relief
- Welding: WPQR and WPS certified by TÜRK-AK
EN ISO 15614-1/2017
(Welding procedures monitored by “welding coordination engineers” certified under EN ISO 14731)
- Max. Operating Pressure: 250 Bar
- Total Motor Power: 45 kW – IE3
- Main Pump: 70 cm³ – REXROTH or PARKER
- Moving Table Fast Approach Speed: 150 mm/s
- Moving Table Forming Speed: 12 mm/s
- Moving Table Return Speed: 170 mm/s
- Cushion Table Forward Speed: 30 mm/s
- Main Cylinder Bore: Ø500 mm – Ck45
- Cushion Cylinder Bore: Ø300 mm – Ck45
- Auxiliary Acceleration Cylinders: 2 units
Ledpfxox N Uhue Abcohd
- Approx. Height: 5800 mm
- Approx. Width: 3250 mm
- Approx. Depth: 2200 mm
- Lower Table Height from Floor: 1400 mm
- Pre-fill Valve: NG 150
- Hydraulic Unit: REXROTH or PARKER
- Cooling System: EMMEGI – CIESSE – PARKER
- Off-line Filtration: REXROTH or PARKER
- Linear Scale: NOVATECHNIK or TURCK
- PLC: DELTA
- Touchscreen: DELTA 7”
- Electrical Components: SIEMENS – SCHNEIDER
- Approx. Weight: 26 Ton
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H-TYPE 400/150 TON HYDRAULIC DEEP DRAW PRESS
CRONOSSTECHCHSP 400/150
Call
Condition: new, Year of construction: 2025, pressing force: 400 t, table width: 1,200 mm, table length: 1,500 mm, retraction force: 150 t, stroke length: 1,000 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 400/150
H-Type Hydraulic Deep Drawing (Forming) Press – 8 Guideways
General Description
The CRONOSSTECH CHSP series H-Type hydraulic deep drawing presses are developed with a double-acting working principle to ensure controlled material flow in sheet metal forming, deep drawing, and forming applications. The H-frame structure with 8 guideways provides maximum rigidity during the pressing cycle, and maintains parallelism and perpendicularity tolerances consistently over long strokes.
The CHSP 400/150 model, with a 400-ton main ram and 150-ton blank holder ram (pot), is designed for deep drawing and forming applications that require high tonnage. The frame is stress-relieved by vibration to ensure long-term durability and reliable operation.
⚙️ Standard Equipment
- Steel construction, H-frame body with 8 guideways
- Stress-relieved frame via vibration
- Bronze Zr14 guide slippers
- WPQR and WPS approved welding by TÜRK-AK accredited certification
(EN ISO 15614-1:2017 / EN ISO 14731)
- Design and manufacturing conform to CE standards
- PLC-controlled hydraulic system
- 7” DELTA touchscreen panel
- Adjustable ram and blank holder (pot) stroke control
- Adjustable ram and pot tonnage (pressure) control
- Automatic lubrication system
- Electronic filtration contamination warning
- Monitoring of hydraulic unit oil temperature and system status on display
- Cooling system
- Off-line filtration
- Safety systems for operator protection
- SIEMENS – SCHNEIDER switchgear components
📐 Technical Specifications – CHSP 400/150
Type: Steel construction, H-frame body with 8 guideways
Frame Material: St52 – ERDEMIR
Guideway Liners: Bronze Zr14
Capacity (Ram): 400 Tons
Capacity (Pot): 150 Tons
Moving Table Dimensions: 1200 × 1500 mm
Fixed Table Dimensions: 1200 × 1500 mm
Parallelism Tolerance: 120 microns/m
Perpendicularity Tolerance: 60 microns/m
Stroke (Ram): 1000 mm
Stroke (Pot): 350 mm
Min. Open Height: 100 mm
Max. Open Height: 1100 mm
Stress Relieving: Vibration method
Welding Application: WPQR & WPS approved by TÜRK-AK accreditation
EN ISO 15614-1:2017
(Welding applications are supervised by certified "welding coordination engineers" per EN ISO 14731)
Max. Working Pressure: 250 Bar
Total Motor Power: 37 kW – IE3
Main Pump: 45 cm³ – REXROTH or PARKER
Rapid Descent Speed (Movable Table): 150 mm/s
Forming Speed (Movable Table): 12 mm/s
Return Speed (Movable Table): 170 mm/s
Forward Speed (Pot Table): 30 mm/s
Main Cylinder Internal Diameter: Ø450 mm – Ck45
Pot Cylinder Internal Diameter: Ø280 mm – Ck45
Auxiliary Acceleration Cylinders: 2 units
Approx. Press Height: 5600 mm
Approx. Press Width: 3250 mm
Approx. Press Depth: 2200 mm
Lower Table Height from Floor: 1400 mm
Pre-fill Valve: NG 150
Hydraulic Unit: REXROTH or PARKER
Cooling System: EMMEGI – CIESSE – PARKER
Off-line Filtration: REXROTH or PARKER
Linear Position Transducer: NOVATECHNIK or TURCK
PLC System: DELTA
Touch Screen Panel: DELTA 7”
Switchgear: SIEMENS – SCHNEIDER
Approx. Weight: 24 Tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Lhjdpfx Ajx N Uhhebcsd
Listing
Turkey
5,223 km
H-type 300/100 ton hydraulic deep drawing press
CRONOSSTECHCHSP 300/100
Call
Condition: new, Year of construction: 2025, pressing force: 300 t, table width: 1,200 mm, table length: 1,500 mm, retraction force: 100 t, stroke length: 800 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, RONOSSTECH CHSP 300/100
H-Type Hydraulic Deep Drawing (Spinning) Press – 8 Guideways
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses have been developed with a double-acting working principle to ensure controlled material flow during sheet metal forming, deep drawing, and spinning applications. The H-frame structure with 8 guideways provides maximum rigidity during pressing; parallelism and perpendicularity tolerances are stably maintained throughout the long stroke.
The CHSP 300/100 model, featuring a 300-ton main ram and a 100-ton bottom cushion ram (pot), is specially designed for deep drawing and spinning operations requiring high tonnage. The frame construction is stress-relieved using vibration methods for long life and reliable performance.
⚙️ Standard Equipment
- Steel construction, H-frame with 8 guideways
- Vibration stress-relieved frame
- Bronze Zr14 slide bearings
- WPQR and WPS certified welding applications accredited by TURK-AK (EN ISO 15614-1:2017 / EN ISO 14731)
- Design and manufacture in compliance with CE standards
- PLC-controlled hydraulic system
- Touchscreen panel (DELTA 7”)
- Adjustable stroke control for both ram and cushion (pot)
- Adjustable tonnage (pressure) control for ram and cushion (pot)
- Automatic lubrication system
- Electronic filter contamination alert
- Display of hydraulic unit oil temperature and system status on screen
- Cooling system
- Off-line filtration
- Safety systems for operator protection
- SIEMENS – SCHNEIDER switching components
📐 Technical Specifications – CHSP 300/100
- Type: Steel construction, H-frame with 8 guideways
- Body Material: St52 – ERDEMİR
- Slideway Bearings: Bronze Zr14
Lhodpsx N Uhbefx Abced
- Capacity (Ram): 300 Ton
- Capacity (Cushion): 100 Ton
- Movable Table Size: 1200 × 1500 mm
- Fixed Table Size: 1200 × 1500 mm
- Parallelism Tolerance: 120 micron/m
- Perpendicularity Tolerance: 60 micron/m
- Stroke (Ram): 800 mm
- Stroke (Cushion): 300 mm
- Min. Clearance: 100 mm
- Max. Clearance: 900 mm
- Stress Relief: Vibration stress relief
- Welding Application: WPQR and WPS certified by TURK-AK
EN ISO 15614-1:2017
(Welding applications are supervised by "welding coordination engineers" certified as per EN ISO 14731)
- Max. Working Pressure: 250 Bar
- Total Motor Power: 37 kW – IE3
- Main Pump: 45 cm³ – REXROTH or PARKER
- Movable Table Fast Down Speed: 150 mm/s
- Movable Table Spinning Speed: 12 mm/s
- Movable Table Return Speed: 170 mm/s
- Cushion Table Forward Speed: 30 mm/s
- Main Cylinder Bore: Ø390 mm – Ck45
- Cushion Cylinder Bore: Ø230 mm – Ck45
- Auxiliary Acceleration Cylinders: 2 units
- Approx. Height: 4400 mm
- Approx. Width: 3250 mm
- Approx. Depth: 2200 mm
- Bottom Table Height from Floor: 1350 mm
- Pre-fill Valve: NG 150
- Hydraulic Unit: REXROTH or PARKER
- Cooling System: EMMEGI – CIESSE – PARKER
- Off-line Filtration: REXROTH or PARKER
- Linear Distance Scale: NOVATECHNIK or TURCK
- PLC Application: DELTA
- Touchscreen Panel: DELTA 7”
- Switching Components: SIEMENS – SCHNEIDER
- Approximate Weight: 21 Ton
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H-Type 250/80 Ton Hydraulic Deep Drawing Press
CRONOSSTECHCHSP 250/80
Call
Condition: new, Year of construction: 2025, pressing force: 250 t, table width: 1,200 mm, table length: 1,500 mm, retraction force: 80 t, stroke length: 800 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 250/80
H-Type Hydraulic Deep Drawing (Spinning) Press – 8-Guided Slides
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses are engineered with a double-acting working principle to ensure controlled material flow in sheet metal forming, deep drawing, and spinning applications. The 8-slide H-frame structure provides maximum rigidity during the pressing process, while parallelism and perpendicularity tolerances are consistently maintained throughout the stroke.
The CHSP 250/80 model, featuring a 250-ton main ram and an 80-ton lower cushion (pot) capacity, is designed for medium to high tonnage deep drawing and spinning operations. The frame construction is stress-relieved by vibration to guarantee long-lasting, reliable performance.
⚙️ Standard Equipment
- Steel construction, 8-slide H-frame press design
- Vibration-stress-relieved frame structure
- Bronze Zr14 slide bearings
- WPQR and WPS certified welding by TÜRK-AK accredited procedures
(EN ISO 15614-1:2017 / EN ISO 14731)
- Design and manufacturing in compliance with CE standards
- PLC-controlled hydraulic system
- 7” DELTA touchscreen panel
- Adjustable stroke control for ram and cushion (pot)
- Adjustable ram and cushion tonnage (pressure) control
- Automatic lubrication system
- Electronic filter contamination indicator
- On-screen monitoring of hydraulic unit oil temperature and system status
- Cooling system
- Off-line filtration
- Safety systems for operator protection
- SIEMENS – SCHNEIDER switchgear
📐 Technical Specifications – CHSP 250/80
Type: Steel construction, 8-slide H-frame press
Frame Material: St52 – ERDEMIR
Slide Bearings: Bronze Zr14
Capacity (Ram): 250 Ton
Capacity (Cushion): 80 Ton
Moving Table Size: 1200 × 1500 mm
Fixed Table Size: 1200 × 1500 mm
Parallelism Tolerance: 120 micron/meter
Perpendicularity Tolerance: 60 micron/meter
Ram Stroke: 800 mm
Cushion Stroke: 300 mm
Min. Daylight: 100 mm
Lodpfx Abjx N Uaqscohd
Max. Daylight: 900 mm
Stress Relief: Vibration stress relief
Welding Certification: WPQR and WPS by TÜRK-AK accreditation
EN ISO 15614-1/2017
(Welding procedures are overseen by certified “welding coordination engineers” per EN ISO 14731)
Max. Working Pressure: 250 Bar
Total Motor Power: 37 kW – IE3
Main Pump: 45 cm³ – REXROTH or PARKER
Moving Table Fast Down Speed: 150 mm/s
Moving Table Drawing Speed: 12 mm/s
Moving Table Return Speed: 170 mm/s
Cushion Forward Speed: 30 mm/s
Main Cylinder Bore: Ø360 mm – Ck45
Cushion Cylinder Bore: Ø200 mm – Ck45
Auxiliary Acceleration Cylinders: 2 pcs
Approx. Press Height: 4200 mm
Approx. Press Width: 3250 mm
Approx. Press Depth: 2200 mm
Lower Table Height from Floor: 1350 mm
Pre-fill Valve: NG 125
Hydraulic Power Unit: REXROTH or PARKER
Cooling System: EMMEGI – CIESSE – PARKER
Off-line Filtration: REXROTH or PARKER
Linear Distance Measurement: NOVATECHNIK or TURCK
PLC System: DELTA
Touchscreen Panel: DELTA 7”
Switchgear: SIEMENS – SCHNEIDER
Approx. Weight: 18 Ton
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H TYPE 200/70 TON HYDRAULIC DEEP DRAWING PRESS
CRONOSSTECHCHSP 200/70
Call
Condition: new, Year of construction: 2025, pressing force: 200 t, table width: 1,000 mm, table length: 1,200 mm, retraction force: 70 t, stroke length: 800 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 200/70
H-Type Hydraulic Deep Drawing (Flanging) Press – 8 Slideways
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses are designed with a double-acting working principle to ensure controlled material flow in sheet metal forming, deep drawing, and flanging applications. The 8-slideway H-frame construction provides maximum rigidity during pressing operations, maintaining parallelism and perpendicularity tolerances consistently throughout the stroke.
Lhsdpfox N T U Tjx Abced
The CHSP 200/70 model, featuring a 200-ton main ram and a 70-ton lower blank holder (pot) capacity, is engineered for medium-to-high tonnage deep drawing and flanging processes. The frame structure undergoes vibratory stress relief for long-lasting and reliable performance.
⚙️ Standard Equipment
- Steel construction, H-frame press body with 8 slideways
- Vibratory stress-relieved frame
- Bronze Zr14 slideway bearings
- Welding processes verified by TÜRK-AK accredited WPQR and WPS certificates
(EN ISO 15614-1:2017 / EN ISO 14731 compliant)
- Design and manufacturing in accordance with CE standards
- PLC-controlled hydraulic system
- 7” DELTA touchscreen panel
- Adjustable ram and pot stroke control
- Adjustable ram and pot tonnage (pressure) control
- Automatic lubrication system
- Electronically monitored filter contamination warning
- On-screen monitoring of hydraulic unit oil temperature and system status
- Cooling system
- Off-line filtration
- Safety interlock systems for operator protection
- SIEMENS – SCHNEIDER switchgear components
📐 Technical Specifications – CHSP 200/70
Type: Steel construction, H-frame with 8 slideways
Frame Material: St52 – ERDEMIR
Slideway Bearings: Bronze Zr14
Capacity (Ram): 200 tons
Capacity (Pot): 70 tons
Movable Table Dimensions: 1000 × 1200 mm
Fixed Table Dimensions: 1000 × 1200 mm
Parallelism Tolerance: 120 microns/meter
Perpendicularity Tolerance: 60 microns/meter
Ram Stroke: 800 mm
Pot Stroke: 300 mm
Min. Daylight: 100 mm
Max. Daylight: 900 mm
Weld Stress Relief: Vibratory stress relief
Welding Application: WPQR and WPS certified by TÜRK-AK according to EN ISO 15614-1:2017
(Supervised by certified "welding coordination engineers" as per EN ISO 14731)
Max. Working Pressure: 250 Bar
Total Motor Power: 22 kW – IE3
Main Pump: 32 cm³ – REXROTH or PARKER
Movable Table Rapid Down Speed: 150 mm/s
Movable Table Drawing Speed: 12 mm/s
Movable Table Return Speed: 170 mm/s
Pot Table Forward Speed: 30 mm/s
Main Cylinder Bore: Ø320 mm – Ck45
Pot Cylinder Bore: Ø190 mm – Ck45
Auxiliary Acceleration Cylinders: 2 Units
Approx. Height of Press: 3800 mm
Approx. Width of Press: 2950 mm
Approx. Depth of Press: 2200 mm
Distance from Floor to Lower Table: 1350 mm
Pre-fill Valve: NG 125
Hydraulic Unit: REXROTH or PARKER
Cooling System: EMMEGI – CIESSE – PARKER
Off-line Filtration: REXROTH or PARKER
Linear Position Scale: NOVATECHNIK or TURCK
PLC: DELTA
Touchscreen Panel: DELTA 7”
Switchgear: SIEMENS – SCHNEIDER
Approximate Weight: 13.5 tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H-type 150/50 ton hydraulic deep drawing press
CRONOSSTECHCHSP 150/50
Call
Condition: new, Year of construction: 2025, pressing force: 150 t, table width: 1,000 mm, table length: 1,200 mm, retraction force: 50 t, stroke length: 600 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 150/50
H-Type Hydraulic Deep Drawing (Forming) Press – 8 Guideways
Lsdpfxox N T U Ho Abcehd
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses are developed with a double-action working principle to provide controlled material flow for sheet forming, deep drawing, and stamping applications. The 8-guideway H-frame design ensures maximum rigidity during pressing; parallelism and perpendicularity tolerances are consistently maintained throughout the stroke.
The CHSP 150/50 model, featuring a 150-ton main ram and 50-ton blankholder (cushion) capacity, is designed for precise and repeatable deep drawing processes. The frame construction is stress-relieved by vibration to ensure long-term durability and reliable operation.
⚙️ Standard Equipment
- Steel construction, H-frame press body with 8 guideways
- Stress-relieved frame via vibration
- Bronze Zr14 slide bearings
- WPQR and WPS certified welding by TÜRK-AK accreditation (EN ISO 15614-1:2017 / EN ISO 14731)
- Design and manufacturing compliant with CE standards
- PLC-controlled hydraulic system
- Touch panel screen (DELTA 7”)
- Adjustable ram and cushion stroke control
- Adjustable ram and cushion tonnage (pressure) control
- Automatic lubrication system
- Electronic filter contamination alert
- Hydraulic oil temperature and system status monitoring on screen
- Cooling system
- Off-line filtration
- Safety systems for operator protection
- SIEMENS – SCHNEIDER switchgear components
📐 Technical Specifications – CHSP 150/50
Type: Steel construction, H-frame press body with 8 guideways
Frame Material: St52 – ERDEMIR
Slide Bearings: Bronze Zr14
Capacity (Ram): 150 Ton
Capacity (Cushion): 50 Ton
Moving Table Dimensions: 1000 × 1200 mm
Fixed Table Dimensions: 1000 × 1200 mm
Parallelism Tolerance: 120 micron/m
Perpendicularity Tolerance: 60 micron/m
Stroke (Ram): 600 mm
Stroke (Cushion): 200 mm
Min. Daylight: 100 mm
Max. Daylight: 700 mm
Stress Relief: Vibratory stress relief
Welding Application: WPQR and WPS certification accredited by TÜRK-AK
EN ISO 15614-1/2017
(Welding applications supervised by "welding coordination engineers" certified according to EN ISO 14731)
Max. Working Pressure: 250 Bar
Total Motor Power: 18.5 kW – IE3
Main Pump: 32 cm³ – REXROTH or PARKER
Moving Table Rapid Down Speed: 150 mm/sec
Moving Table Drawing Speed: 12 mm/sec
Moving Table Return Speed: 170 mm/sec
Cushion Advance Speed: 30 mm/sec
Main Cylinder Inner Diameter: Ø280 mm – Ck45
Cushion Cylinder Inner Diameter: Ø160 mm – Ck45
Auxiliary Acceleration Cylinders: 2 units
Approx. Press Height: 3650 mm
Approx. Press Width: 2950 mm
Approx. Press Depth: 2000 mm
Lower Table Height from Floor: 1250 mm
Pre-fill Valve: NG 100
Hydraulic Power Unit: REXROTH or PARKER
Cooling System: EMMEGI – CIESSE – PARKER
Off-line Filtration: REXROTH or PARKER
Linear Position Transducer: NOVATECHNIK or TURCK
PLC System: DELTA
Touch Panel Screen: DELTA 7”
Switchgear: SIEMENS – SCHNEIDER
Approximate Weight: 11 Ton
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Turkey
5,223 km
H Type 100/40 Ton Hydraulic Deep Drawing Press
CRONOSSTECHCHSP 100/40
Call
Condition: new, Year of construction: 2025, pressing force: 100 t, table width: 1,000 mm, table length: 1,200 mm, retraction force: 40 t, stroke length: 600 mm, operating pressure: 250 bar, Equipment: documentation/manual, safety light barrier, CRONOSSTECH CHSP 100/40
H-Type Hydraulic Deep Drawing (Flanging) Press – 8-Guided Slides
General Description
The CRONOSSTECH CHSP series H-type hydraulic deep drawing presses are engineered with a double-acting working principle to ensure controlled material flow during sheet metal forming, deep drawing, and flanging operations. The 8-side guided H-frame structure guarantees maximum rigidity throughout the pressing cycle, maintaining stable parallelism and perpendicularity tolerances over the entire stroke.
The CHSP 100/40 model features a 100-ton main ram and a 40-ton cushion ram (blankholder), specifically designed for precision deep drawing and flanging operations. The frame construction is stress-relieved by vibration to ensure long service life and reliable operation.
⚙️ Standard Equipment
- Steel construction, H-frame body with 8 sliding guides
- Vibration stress-relieved frame structure
- Bronze Zr14 slide bearings
- WPQR and WPS certified welding procedures accredited by TÜRK-AK (EN ISO 15614-1:2017 / EN ISO 14731)
- Design and manufacturing in compliance with CE standards
- PLC-controlled hydraulic system
- 7” DELTA touchscreen panel
- Adjustable ram and cushion stroke control
- Adjustable ram and cushion tonnage (pressure) control
- Automatic lubrication system
- Electronically monitored filter contamination warning
- On-screen monitoring of hydraulic oil temperature and system status
- Cooling system
Ledpfsx N T Uyox Abcehd
- Off-line filtration
- Safety systems for operator protection
- SIEMENS – SCHNEIDER switchgear components
📐 Technical Specifications – CHSP 100/40
- Type: Steel construction, H-frame body with 8 sliding guides
- Frame Material: St52 – ERDEMİR grade
- Slide Bearing: Bronze Zr14
- Capacity (Ram): 100 Tons
- Capacity (Cushion/Blankholder): 40 Tons
- Moving Table Size: 1000 × 1200 mm
- Fixed Table Size: 1000 × 1200 mm
- Parallelism Tolerance: 120 micron/meter
- Perpendicularity Tolerance: 60 micron/meter
- Stroke (Ram): 600 mm
- Stroke (Cushion): 200 mm
- Min. Daylight: 100 mm
- Max. Daylight: 700 mm
- Weld Stress Relief: Vibration stress-relieving
- Welding: WPQR and WPS approved by TÜRK-AK, EN ISO 15614-1:2017 (certified welding coordination engineers supervise per EN ISO 14731)
- Max. Operating Pressure: 250 Bar
- Total Motor Power: 11 kW – IE3
- Main Pump: 22 cm³ – REXROTH or PARKER
- Moving Table Rapid Down Speed: 150 mm/sec
- Moving Table Flanging Speed: 12 mm/sec
- Moving Table Return Speed: 170 mm/sec
- Cushion Table Forward Speed: 30 mm/sec
- Main Cylinder Bore: Ø230 mm – Ck45
- Cushion Cylinder Bore: Ø140 mm – Ck45
- Auxiliary Acceleration Cylinders: 2 units
- Approximate Height: 3400 mm
- Approximate Width: 2950 mm
- Approximate Depth: 2000 mm
- Distance from Floor to Lower Table: 1250 mm
- Pre-fill Valve: NG 100
- Hydraulic Unit: REXROTH or PARKER
- Cooling System: EMMEGI – CIESSE – PARKER
- Off-line Filtration: REXROTH or PARKER
- Linear Position Transducer: NOVATECHNIK or TURCK
- PLC Application: DELTA
- Touch Panel: DELTA 7”
- Switchgear: SIEMENS – SCHNEIDER
- Approximate Weight: 9 Tons
Production Note
This machine is manufactured by CRONOSSTECH in Turkey.
Listing
Germany
6,760 km
Clamp Jaw Elevator
Gronemeyer
Call
Condition: ready for operation (used), A vertical upward clamping jaw elevator and a vertical downward clamping jaw elevator in stainless steel design are available. This is a conveyor system for overcoming height differences in production lines. Bottles, jars, cans and also cartons etc. can be conveyed upwards and downwards. (1) Upward elevator, output: 14,000 cans/h (empty containers open), speed: 25m/min, format diameter: 100mm, format height: 50-80mm (400g), total length with infeed and outfeed section: 2500mm, frame width: 1050mm, infeed height: 900mm, outfeed height: 2600mm, height difference: 1700mm, drives: frequency-controllable, motor power: 1.1kW. (2) Downward elevator, output: 14,000 cans/h (empty cans open), speed: 25m/min, format diameter: 100mm, format height: 80mm (400g), total length with infeed and outfeed section: 2500mm, frame width: 1050mm, infeed height: 900mm, outfeed height: 2600mm, height difference: 1700mm, drives: frequency-controllable, motor power: 1.1kW. On-site inspection is possible, were completely overhauled in the past.
Ledpfxeu Av Egs Abcjhd
Listing
Germany
6,760 km
Vacuum Deep-Drawing Machine
GeissDU 1600x1000x620 T7
Call
Year of construction: 1996, condition: ready for operation (used), A large-format vacuum thermoforming machine Geiss is available. Heating capacity: 180kW, forming area X/Y: 1600mm/1000mm, drawing depth: 620mm, quick-clamping system: 640mm, window plate adjustment: 250mm-750mm, drilling grid: 50mm, closing force: 50kN. Documentation available. An on-site inspection is possible. Expected to be available from February 2026.
Lhedpexwyvkofx Abced
Listing
Germany
6,760 km
Vacuum Deep-Drawing Machine
GeissT8 DU
Call
Year of construction: 2008, condition: ready for operation (used), A Geiss large-format vacuum thermoforming machine is available. Panel cutting min.: 1100mm/1300mm, max. panel cutting: 2100mm/1800mm, max. forming depth: 620mm. Additional panel format 1: min.: 850mm/750mm, max.: 1850mm/1250mm. Additional panel format 2: min.: 1050mm/800mm, max.: 2050mm/1300mm. Including a separate loading machine with pneumatic panel separating equipment, an automatic aligner for panel cuts in longitudinal and transverse direction, a pneumatic pusher for removing the molded parts from the loading unit, fully automatic central lubrication of the loading machine, several interchangeable pallets for window panel sets, a storage rack for window panels as well as a vacuum control with four independently adjustable flow stages and an air preparation system. Documentation available. On-site inspection is possible.
Lhodpfx Abowih Arscod
Listing
Germany
6,760 km
Vacuum Deep-Drawing Machine
SealedAirCryovac VS 26
Call
Year of construction: 2021, condition: ready for operation (used), A semi-automatic vacuum skin packaging machine (tray sealer) Sealed Air for Darfresh skin packaging is available. Packaging capacity: 15/min, cycle performance: 1.5 cycles/min, film width: 562mm, max. product dimensions X/Y/Z: 670mm/470mm/50mm, tray length range: 135mm-700mm, tray width range: 120mm-520mm, tray height range: 5mm-50mm. Machine dimensions X/Y/Z: approx. 1050mm/1650mm/1250mm, weight: approx. 500kg. Documentation available. An on-site inspection is possible.
Ljdpfxsxaphbs Abcehd
Listing
Germany
6,760 km
Deep Drawing Thermoforming Machine
CFS Palazzolo S.p.A.CFS Compact M 285 3.10
Call
Year of construction: 2002, condition: ready for operation (used), Offered is a thermoform vacuum packaging machine / deep-drawing packaging machine from CFS. Air: 8bar / 500Nl/min, water: 2bar / 75l/min, weight approx. 2800kg. Inspection by arrangement possible.
Lsdpfexx Ud Eex Abcshd
Listing
Grafenberg
6,833 km
Deep hole drilling
SFT tieflochbohren
Call
Condition: good (used), We offer contract deep-hole drilling work.
From a diameter of 0.5 to 400 mm and up to a drilling depth of 12,000 mm, everything is possible!
Lsdpfx Absrt T U Escjhd
Please contact us and we will be happy to prepare a quotation for you.
Please let us know the quantity, the material, the drilling diameter and the drilling depth.
Trust Seal
Dealers certified through Machineseeker

Listing
Siedlce
5,967 km
Self-centring 3-jaw chuck
CORMAKUchwyt samocentrujący do rur WP400
Call
Condition: new, Year of construction: 2026, The CORMAK WP400 self-centring 3-jaw pipe chuck is a high-quality accessory designed for use with welding positioners and welding rotators. It enables quick and stable clamping of cylindrical or hexagonal workpieces with diameters ranging from 120 to 380 mm. Thanks to its robust design and high clamping force, the chuck ensures reliability and precision essential for automatic and semi-automatic circumferential welding processes.
Main advantages of the WP400 chuck
Wide clamping range – allows clamping of workpieces with diameters from 120 to 380 mm, ensuring versatility for both series and single-piece production.
Self-centring 3-jaw mechanism – guarantees fast and accurate alignment of the workpiece along the rotator axis.
High clamping force – 350 kg – enables safe clamping of heavy components during dynamic rotation.
Compatible with welding positioners – perfectly matches welding rotators and other welding support equipment, allowing full utilisation of their capabilities.
Stable and durable design – engineered for long-term use in demanding industrial conditions.
Design and technology
The WP400 model features a precise, mechanically synchronised clamping system that ensures the workpiece is always perfectly centred on the rotational axis. The three independently moving jaws are made of hardened steel, resistant to wear and deformation. A large through-hole of ⌀170 mm allows for the passage of tubular workpieces, while the load capacity of 240 kg provides safe handling of heavy components.
Precision and performance
Lhodpsycqpyjfx Abcjd
The WP400 chuck minimises setup time, increasing overall workstation efficiency. The self-centring system eliminates positioning errors and improves the quality of circumferential welds. Its rigid construction ensures stability during automatic or semi-automatic welding cycles, even under high loads.
Applications
The WP400 chuck is designed for industrial facilities using welding positioners, welding rotators, and other devices supporting welding processes. It is ideal for clamping pipes, sleeves, flanges, and other components requiring rotational welding. With its high clamping force and load capacity, the WP400 is suitable for both light and heavy-duty production environments.
Technical parameters
Model WP-400
Max clamping force 350 kg
Max load capacity 240 kg
Through-hole diameter ⌀ 170 mm
Clamping range ⌀ 120–380 mm
Listing
Siedlce
5,967 km
Self-centring 3-jaw chuck
CORMAKUchwyt samocentrujący do rur WP300
Call
Condition: new, Year of construction: 2026, The WP300 self-centering three-jaw chuck is a specialist accessory designed for clamping pipes and workpieces with cylindrical or hexagonal cross-sections in welding positioners and welding rotators. Thanks to its precise self-centering clamping mechanism, it ensures secure and accurate positioning of the workpiece during rotation, which results in higher quality and repeatability of the welding process.
Key advantages of the WP300 chuck
Precise self-centering mechanism – enables quick and accurate centering of pipes and workpieces, eliminating the need for manual positioning.
High versatility – compatible with many welding rotators and positioners, including models PS310, PS320, and PS360.
Stable clamping – thanks to three independent jaws, the workpiece remains securely clamped even at high rotational speeds.
Robust construction – made of high-grade materials resistant to vibration, loads, and harsh welding environments.
Optimal working diameter – the ability to clamp pipes up to 270 mm in diameter allows for a wide range of applications.
Design and technology
The WP300 model features a compact and durable steel construction designed for intensive operation. The three-jaw mechanism operates synchronously, automatically positioning the workpiece on the axis of rotation. The large outer diameter (300 mm) and the through bore (100 mm) allow for handling a wide range of workpiece dimensions. The mounting holes are designed to ensure full compatibility with CORMAK welding positioners.
Precision and efficiency
The WP300 chuck provides high clamping repeatability, which translates into precise circumferential welds. It shortens workpiece preparation time and reduces setup errors, increasing production efficiency and improving operator safety. The solid construction ensures stable operation even under dynamic loads.
Applications
The WP300 chuck is intended for use in circumferential welding processes, particularly in manufacturing plants, metalworking workshops, and companies involved in steel structure prefabrication. It is used with welding rotators and welding positioners, enhancing their functionality and versatility.
Technical data
Max. pipe diameter: 270 mm
Outer diameter: 300 mm
Lhjdpfx Abjycqptocjd
Inner diameter (through bore): 100 mm
Mounting hole spacing: 105 mm
Bolt hole diameter: 9 mm
For welding positioners: PS310, PS320, PS360
Weight: 14 kg
Listing
Siedlce
5,967 km
Self-centring 3-jaw chuck
CORMAKUchwyt samocentrujący do rur WP200
Call
Condition: new, Year of construction: 2026, The WP200 self-centring 3-jaw chuck is a professional accessory designed for use with welding positioners and welding rotators such as models PS310 and PS320. Its precise clamping mechanism allows quick, stable, and concentric fastening of pipes and cylindrical or hexagonal parts, significantly improving the efficiency and safety of circumferential welding.
Main advantages of the WP200 chuck
Self-centring 3-jaw mechanism – ensures even and stable clamping of workpieces regardless of their shape.
Versatility – compatible with most welding rotators and welding positioners, including CORMAK PS310 and PS320.
Clamping precision – perfect alignment of workpieces translates into better weld quality and smooth rotation.
Durable construction – robust body made from high-strength materials resistant to heavy mechanical and thermal loads.
Compact size and easy installation – low weight and precisely positioned mounting holes ensure quick integration with welding equipment.
Design and technology
The WP200 chuck features three high-quality jaws designed to automatically centre the workpiece on the rotational axis. Its outer diameter of 200 mm and inner diameter of 80 mm allow clamping of workpieces up to 170 mm in diameter. The body is made of high-grade steel, providing excellent resistance to deformation during long-term use.
Precision and efficiency
The WP200 self-centring 3-jaw mechanism significantly reduces setup time for welding operations. The elimination of backlash and positioning errors directly improves the quality of circumferential welds. Stable clamping of workpieces also enhances operator safety during welding.
Lodpfx Abjycqnvjcehd
Applications
The WP200 chuck is designed for use with welding rotators, welding positioners, and welding manipulators in operations involving pipes, flanges, rings, and cylindrical components. It is ideal for welding workshops, manufacturing plants, and the steel construction industry.
Technical parameters
Max pipe diameter: 170 mm
Outer diameter: 200 mm
Inner diameter: 80 mm
Mounting hole spacing: 85 mm
Mounting hole diameter: 9 mm
For welding positioner: PS310, PS320
Weight: 10 kg
Listing
Korschenbroich
7,029 km
Deep drilling machine
TIEFBOHRTECHNIKT20-500
Call
Condition: used, Year of construction: 1974, 414312067
voltage 380 V
Lhodjx U A T Njpfx Abcsd
frequency 50 Hz
rated capacity 13 kVA
We make it easier for you to find: "deep jaws"
You will receive new offers immediately and free of charge via e-mail
You can easily terminate the search request at any time
Used Deep Jaws (4,327)
Search Machineseeker now with more than 2,00,000 used machines:Browse through the most popular machine descriptions:
This may be of interest to you

Get information now
+44 20 806 810 84
+44 20 806 810 84
List now
*per listing / month
