Used Machine Center for sale (87,948)

Condition: new, Year of construction: 2025, functionality: fully functional, CNC machining center NESTING with fully automatic loading and unloading As with all Nesting machines: various sizes, line drilling, Becker vacuum pumps, CadCam Nesting software, CNC controller, remote control, servodrive, etc. The best machine is the one that fits your company. Specify which configuration you require. We guarantee reliability (see the photos) Casdoxx Uc Uepfx Addea Prices starting from €85,000 – New machines You can call or WhatsApp us for more information and/or to make an appointment. WhatsApp: We handle transport, customs clearance, and delivery to your location. Machine instruction – extra warranty – 7/24 support

Condition: new, functionality: fully functional, travel distance X-axis: 510 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 300 mm, 📝 Description & Additional Technical Parameters Product Description: The VTX-5 is part of the Tongtai VTX Series of compact CNC vertical tapping / milling centers. It is designed to combine high speed, rigidity, and precision in a relatively small footprint. It uses a direct-drive spindle to improve tapping accuracy and reduce maintenance compared to belt-driven designs. Roller guideways (linear rails) are used to ensure smooth, rigid motion. Tool changing is relatively fast, and the structure is optimized for stability and precision under moderate loads. Technical Parameters: Table size: 600x400mm Strokes on X/Y/Z: 510/400/300mm Maxim loading capacity on the table: 250kgs Rapid traverse on X/Y/Z: 60/60/60 m/min Machine size (Width x Depth x Height): 1.700x2.600x2.700mm Codpfxexni Iqo Addoaa Machine weight: 2.850kgs Siemens controller model 828D with Shopmill and 10,4inch LCD Spindle speed 12.000 rpm direct driven Spindle motor 5,8kW Tool shank BBT-30 4th axis rotary table diameter 170mm and tailstock CTS ( coolant through spindle) 20bar Chip Conveyor chain type

Condition: new, Year of construction: 2025, total height: 2,100 mm, total length: 8,500 mm, total width: 1,400 mm, overall weight: 1,850 kg, working height: 900 mm, The machine is engineered to handle the connection nuts of solar panel frames, executing drilling, tapping, and cutting operations concurrently within a singular unit. Thanks to the simultaneous processing of four profiles, it allows for the production of one nut every 1.5 seconds. Please contact us for detailed informations. Caedpfx Ajvvkvpeddja

Condition: excellent (used), Year of construction: 2016, XYZ 1550VS Gap Bed Centre Lathe EX Training College Machine 3 Jaw Chuck 2-axis Digital Readout Toolpost & Chuck Guard Footbrake (Modern Triumph 2000 size machine Manufactured & Installed 2016 Machine Capacity: Swing Over Bed 390mm Swing in Gap 610mm Swing Over Cross Slide 150mm Distance Between Centres 1250mm Cross Slide Travel 230mm Codpoxn Sf Ssfx Addjaa Spindle: Spindle Speeds 20 – 2500rpm Spindle Power 5.75kW Spindle Bore 54mm Spindle Nose D1-6 For sale with Jet Machinery Ltd Jet Machinery Stock No: #79010 Machine Serial Number: 7715 Cost: £9,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: new, Year of construction: 2023, functionality: fully functional, 5-axis travelling column machining centre - SAMAG SFZ3500- with swivel head and internal rotary table (Ø:1000mm, interference Ø:1300mm) X:3500mm Y:1000mm Z:1000mm Spindle: SK50 max. 12,000rpm 54kW Tool changer: 60 Control: Heidenhain TNC7 Coolant system with paper belt filter Cajdpfxettv Haj Addea Internal coolant supply: 40bar (max. 80bar) Internal air supply through the spindle 3D touch probes Collision monitoring (DCM) Kinematics Opt The machine is available at short notice and can be inspected and tested at the factory.

Condition: excellent (used), Year of construction: 2013, Travels X-axis: 650 mm Y-axis: 560 mm Z-axis: 560 mm Rapid traverse: 32 m/min 2 work tables each: (setup side / machining side) Pallet dimensions: 500 x 500 mm Possible table position: 360,000 degrees Max. workpiece weight: 400 kg MILLING SPINDLE Spindle mount: SK-40 DIN 69871 Direct drive: 8,000 rpm with gear box Drive power: 10 / 16 kW Tool changer Tool changer type: Double gripper Csdpsv Sdcnsfx Addsaa Number of tools: 40 Max. tool diameter: ø 115 mm Max. tool length: 300 mm Internal coolant system Spindle cooler Chip conveyor Connection data and dimensions Air connection: 6 bar Total connected load: 25 kVA Rated voltage: 380V 50/60 Hz Minimum machine weight: 6,700 kg Machine dimensions (LxWxH): 3,500 x 2,500 x 2,650 mm Very compact machine! Video available.

Condition: new, Year of construction: 2025, functionality: fully functional, travel distance X-axis: 3,050 mm, travel distance Y-axis: 1,220 mm, travel distance Z-axis: 100 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 25 m/min, number of spindles: 16, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Numerical Pegasus-Cad software Working area in X - 3050mm Working area in Y - 1220mm 2 working zones Lifting feed table, stackable Caodpfx Adoxx T R Dedea Automatic loading system, Schmalz type Label printing system with automatic application on the loading table ATC 3-axis vertical electrospindle, 13.2 kW, with automatic tool changer, ISO 30 Automatic tool change system with 16 positions - positioned at the rear of the machine Automatic tool change system, carousel for fast changeovers Automatic unloading system with motorized conveyor belt Automatic worktable cleaning system Protection and safety system with light curtain and fencing Automatic lubrication system 250 m3/h - 5.5 kW vacuum pump Contact by phone: 0031634707163 Transport, installation, and user training negotiable Danmar Machines BV Almelo

Condition: new, functionality: fully functional, feed length X-axis: 510 mm, feed length Y-axis: 510 mm, feed length Z-axis: 510 mm, feed rate X-axis: 60 m/min, feed rate Y-axis: 60 m/min, feed rate Z-axis: 60 m/min, 📄 Product Description The Tongtai SH-4000P is a high-speed, high-rigidity horizontal machining center designed for efficient machining of aluminum and light metal workpieces. It features a compact structure, three-point support bed, high rapid traverse speed, and optional APC (Automatic Pallet Changer). The built-in spindle provides high speed and precision, ideal for automotive and general manufacturing industries. ⚙️ Technical Parameters Caodpfx Aexnizdjddja Strokes on X/Y/Z: 510/510/510mm B axis rotary table: 0,001º indexing table Rapid traverse on X/Y/Z: 60/60/60 m/min Pallet size: 2 x (400x400mm) Maximum load on the table (pallet): 2 x 400kgs Maximum workpiece dimension (diameter x height): Ø 550 x H 800mm Spindle speed: 15.000 rpm Built in spindle motor: 18.5/26/37 kW Machine size (Width x Depth x Height): 1.750x5.060x2.720mm Machine weight: 8.700kgs Fanuc controller model 0i-MF with Manual guide i and 10,4''LCD monitor Tool shank: BBT-40 ATC with 60 tools CTS ( coolant through spindle): 70bar Chip Conveyor integrated type with trolley Oil Skimmer

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, Universal Machine Center 5 axis simultaneous Caedpfxjwvra Io Addea DMG DMC 105V Linear Year 2007 Travel : X1050 Y 800 Z 560mm NC Rotary Table Ø1,000mm Heidenhain iTNC530 Control Spindle 18,000rpm ATC 30 HSK-63A NC B axis Control Milling Head – 120o / +30o Roto clear window Tool Measuring system – Blum Measuring probe Cooling by air blast through spindle by M code Spindle through coolant Chip conveyor ____Cheapest 1m 5axis_____

Condition: used, CNC Vertical Machining Center HURCO Type BMC 25/M Serial No: ZB9-001-052 Year of manufacture: approx. 1995 Travel distances X: 610 mm, Y: 410 mm, Z: 560 mm Table size (clamping surface) 845 x 400 mm Table size (with coolant groove) 1050 x 500 mm Spindle taper SK 40 Distance spindle nose - table 155 - 710 mm Table load capacity max. 500 kg Overhang 420 mm Spindle speed max. 10,000 rpm Cajdpfx Adow Nklhodoa Feed rate 3 to 5080 mm/min Rapid traverse 10 m/min Spindle drive approx. 5.5 kW Power supply 400 Volt, 50 Hz - CNC path control Ultimax 3 with two TFT monitors - Electronic handwheel - Indirect measuring system with rotary encoders on the ballscrew - Tool changer with 20 tool stations - Full enclosure with sliding door - Swiveling control panel - Yaskawa (Japan) spindle drives - Pneumatic-mechanical tool clamp - Without coolant system – pump included – coolant tray missing Machine width 2400 mm Space requirement for transport L x W x H = 3000 x 2400 x 2650 mm Weight 4200 kg Good condition

Condition: as good as new (ex-display), Year of construction: 2024, Axolox 3021 CNC wood router - display machine available immediately - in 19mm Forescolor, consisting of a router table (X-axis), gantry (Y-axis), Z-axis unit made of compact board, and a base frame, with adjustable machine feet. Router bed as a sacrificial board made of 19mm MDF. Table openings pre-prepared lengthwise and crosswise. Mechanical set consisting of profile guides including profile guide carriages, recirculating ball screws, and precision racks. All elements assembled, pre-lubricated, including a test run, and immediately ready for operation. The control set consists of control cables, energy chains, planetary gears, stepper motors, high-performance power amplifiers, power supply, and toroidal transformer, fully pre-assembled in the control cabinet, as well as sensors for each axis. Switching relays for automatic control of the existing extraction system. Brush seals for dust protection, as well as CE-compliant safety devices with a mobile extraction system and a laser scanner mounted on one side for monitoring the work area, with a 275° and 5.5 m field range (positioning the machine in a corner of the room). A handheld control unit is equipped with all the necessary functions for operating the machine, including an emergency stop button and a deadman's switch. A tool length sensor is used to determine the tool length and change the active zero offset. A 2.2 kW high-frequency spindle includes a union nut, frequency converter, line filter, brake resistor, and collet set. A built-in monitor includes a mini PC with Windows 10 and Beamicon2 control software, as well as a mouse and keyboard, pre-installed in an ergonomic desk. A Rhino 7.0 CAD license and an Estlcam V11 CAM license, as well as all necessary documentation, will be sent by email prior to delivery. - Milling bed designed as a vacuum table consisting of six adjustable sub-elements. Cross table made of PE with an MDF cover plate. Vacuum pump from Becker with an output of 160 m³/h, with an oil-driven rotor. A 16 amp, 400 V AC plug is required for the vacuum pump's power connection. The customer must provide 3 mm HDF raw on both sides for the entire vacuum table (3000 x 2100 mm) as a sacrificial plate. (Recommended use: machining coated chipboard) - Tool set: 10 pieces 2 x 5 mm TAC double-flute cutters Caodpfxjwdny Tj Addea 8 x 4 mm solid carbide single-flute cutters - Maintenance package: Including a 150 ml grease gun, a 400 g cartridge of high-performance grease, a 500 ml can of silicone spray grease, and a grease nipple - Clamping device as an attachment for the existing high-frequency spindle. Suitable for slightly curved and particularly thin materials. Location: From stock, 54634 Bitburg - Available immediately - Subject to prior sale

Condition: new, Year of construction: 2025, functionality: fully functional, Simply Center Punch – The Center Marking Aid! A revolution in precision: We present the “Simply Center Punch” The world's only center marking device – an exclusive innovation from Northern Germany. The Problem No more inaccurate center marking of round parts - Are you familiar with the challenges of precisely center punching shafts or rods ranging from 15 mm up to 400 mm? - Inaccurate positioning. - Poor lighting conditions - No glasses for older users - Time-consuming manual alignment - Inefficient and error-prone processes - The market does not offer a universal and reliable solution for varying diameters. Casdpfx Aexb Ucajddsa Our Solution: Simply Center Punch – A World First! Simply Center Punch: Precision made simple. - Globally unique: A center punch device / center marking aid developed and utility model protected by us, setting new industry standards. - 100% in-house development: From the first concept to the finished product – all from a single source. - Manufactured in-house: We guarantee quality "Made in Germany." - Versatile use: For diameters from 15 mm to 400 mm. - Center marking at the push of a button: Simply position, turn the handle, and mark the center. Your Advantages at a Glance Your benefits. - Maximum precision: Centers drill holes and markings with accuracy up to 0.3 mm. - Saves time and money: Speeds up your workflow and reduces rework. - Effortless handling: Intuitive operation requiring no prior experience. – Weight just 780 g. - Universally applicable: One tool for nearly all diameters in mechanical engineering, metalworking, etc. - Robust and durable: Made from high-quality materials for professional, continuous use.

Condition: good (used), Centre bore 2- 50 mm Diameter of workpiece 8 - 125 mm Lenght of workpiece 50 - 1000 mm Grinding wheel speeds 13'000 - 45'000 rpm Misc.accessories Caedpfx Adjrivluodoa MARCELS MASCHINEN AG

Condition: not inspected (used), functionality: fully functional, spindle bore: 65 mm, turning diameter: 500 mm, power: 10 kW (13.60 HP), manufacturer: Tool Factory Budapest type: EU500/1500 turning length: 1500mm turning diameter: "over bed": 500 mm above cross slide: 315 mm Caodpfeqwlmqjx Addoa revolution: 18 degrees. speed range: 25-1250 rpm main spindle hole: 65mm spindle bore: 63mm tip holder insert sleeve cone: 72 metric lathe tip taper: morse 5. main engine power: 10kw mains voltage 3 phases 380V 50Hz machine length: 3400mm total width of the machine: 1210mm height: 1265 mm machine weight: 3550 kg

Condition: used, Year of construction: 1964, Technical details: shaft diameter: max. 120 mm work piece - max.: 800 mm height of profile: Tiefe: max. 90 mm grinding spindle speed: nicht bekannt U/min Table dimensions: Ø 150 mm voltage: 380 V total power requirement: 1,1 kW weight of the machine ca.: 0,675 t dimension machine xH: 0,75 x 0,70 x 2,0 m Casdpfx Adju Ngr Dodea Application: vertical internal cylindrical grinding of shafts face, and center grinding with shaft grinder. Spindle head technical details: -equipment shank grinder Ø 13mm 60°; clamping element Ø 6mm shank clamping head. -travel=vertical 950mm by handwheel and transversal 80mm by crank handle -abrasive device with diamond, adjustment crosswise= 80mm. Table other specifications: -with fixed tip holder 60°. -speed 63 / 125 rpm. -adjustment vertical 600mm, in height 1.100mm, operation manual. centering block: -prismatic guide accessories: -fixed tip L=180mm -fixed tip L=300mm -div. shank grinder -div. clamping and auxiliary tools *

Condition: used, CNC Vertical Machining Center HURCO Type BMC 30/M Serial No: B3M92202056AB : 9650234 Year of construction 1996 CNC path control Ultimax 3 Travel X: 760 mm, Y: 460 mm, Z: 610 mm Table size (clamping surface) 1010 x 400 mm Table size (with water groove) 1120 x 500 mm Spindle holder SK 40 Distance spindle nose - table 150 - 760 mm Projection 450 mm Spindle speed 80 to 8000 rpm infinitely variable Codetrhq Hepfx Addoaa Feed rate 3 to 16,000 mm/min. Rapid traverse 24 m/min. Spindle drive 7.5 kW at 30 min / 5.5 kW at 100% Mains connection 400 Volt, 50 Hz - CNC path control Ultimax 3 (with hardware update e.g. TFT monitors) - Electronic handwheel - Indirect measuring system with rotary encoders on the ball screw spindle - Tool changer with 24 tool positions - Fully protected cabin with sliding door - Rotating control panel - spindle drives Yaskawa (Japan) - pneum. mechanical tool clamp - Coolant unit adjacent, pushed under from behind - trough rinsing Machine width 2400 mm Space required for transportation L x W x H 3400 x 2400 x 2550 mm Weight approx. 4800 kg good condition

Condition: good (used), Year of construction: 1998, Manufacturer: Henninger Type: ZS-201 Year of manufacture: 1998 Self centerring device Double column slide ways Dressing Unit Tailstock by rack & pinion Eccentric adjustment 0 - 20 mm Large Cone-Stone tooling package Specifications Metric US Standard Minimum workpiece Ø 20 Ø Min. Maximum workpiece Ø 450 Ø Max. Max. product length 1200 mm Speed 18300 Rpm Max. grinding angle 45 - 120 ° Codpfx Ajvt Tuijddoaa Max. workpiece weight 190 Dimensions (estimate) Length 1250 mm Width 1250 mm Height 1900 mm Weight 365 kg Please note: The information on this page has been compiled to the best of our knowledge and belief by us and, where possible, by the manufacturer. The information is provided in good faith but accuracy cannot be guaranteed. Accordingly, it will not constitute a representation and terms of contract. We recommend that you review all important details.

Year of construction: 2012, condition: excellent (used), YASDA YBM Vi40 CNC jig boring machine / machining center machine in perfect condition incl. accessories (see photos) For the complete photo gallery: See attached PDF file (from page 4) TECHNICAL DATA Travels X-axis: 900 mm Csdpfxepqx H To Addjaa Y axis: 500 mm Z axis: 450 mm Distance from the table surface to the spindle tip: 100 to 550 °. Rotary table diameter: 400 mm Pallet loading capacity: 200 kg Table surface configuration: 44-M12 thread C axis: 360 ° Table tilt axis movement range (B axis): +- 110 ° Distance between center of tilt axis and rotary table: 0 mm Rotary axis (C axis): 100 rpm Max. rotation of the inclination axis: 20 rpm Motor for rotary axis: 4,2 kW Motor for inclination axis: 4,5 kW Spindle type: SA40-24`000-18,5 Spindle speed range: 100 - 24`000 rpm Spindle speed range programming: Programming by direct input of a 5-digit S-command Number of spindle speed ranges: 1 Type of spindle conical bore: HSK-63A Inner diameter of spindle bearing: 65 mm diameter Rapid traverse Speed: X,Y,Z axis: 20`000 rpm Feed rate: X,Y,Z axis: Max. 5000 rpm C-axis: 100 rpm B axis: 20 rpm Smallest input increment: 0.0001 mm/deg Automatic tool changer: 60 tools Selection method: Any selection Tool shank type: HSK-63 A Max. tool diameter Tool diameter: 100 mm Max. tool diameter Tool diameter at full setting: 70 mm Max. Tool length: 250 mm Max. Tool weight: 7 kg Tool balance weight: within G2.5 Machine dimensions: 3220 x 3885 x 3515 mm Machine weight: 15`000 kg No responsibility is taken for the accuracy, completeness and timeliness of the information.

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, Workpiece Clamping Diameter : ø 3 – 140 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 100 mm Workpiece Weight : max. 170 kg Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Grinding Process : Semi-Automatic, CNC Control Panel : Beckhoff CNC Movements : Z-Axis Indurstry 4.0 Compatibility : Available Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Sectors : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Easy to Use CNC Control Panel: Benefit from very simple operation and grinding program recording with the Beckhoff control panel and Z-axis servo movement. Industry 4.0: Fully compatible with Industry 4.0 applications, thanks to the Beckhoff control panel. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. Codpfx Aogb Ec Hsddeaa The Zentroflex SA-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex SA-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Z-Axis movement is provided by servo motor in CNC form. The part is loaded-unloaded and clamped manually. Settings are made from CNC control panel and grinding is started by pressing the start button. No other manual setting or control is made during grinding. Contact us for more details.

Condition: good (used), functionality: fully functional, travel distance X-axis: 1,000 mm, For sale is a milling machine of the Niigata brand and type U-1000 The machine is fully functional and ready for immediate use Technical data Work table 360x1500 mm with 4 T-slots Longitudinal travel X 1000 mm Transverse travel Y 500 mm Mounting: SK 50 Vertical travel Z 430 mm Rapid traverse 2 m / min. Spindle holder SK 50 Spindle speeds 500 - 2000 rpm. Max. Table load 800 kg Vices and magnetic plate not included in the offer, can be offered additionally. On request, loading and transport (Europe-wide) can be organized for an additional charge. Prices plus VAT Viewing possible by appointment. Contact us, our team will be happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MUCH MORE. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? Cjdpfxer Izbrj Addoaa For further information or contact options, please visit our website

Condition: excellent (used), workpiece diameter 60 mm grinding depth 30 mm clamping length 1000 mm total power requirement kW Casdpfx Asunt Egoddea weight of the machine ca. 0,6 t dimensions of the machine ca. 0,5 x 0,5 x 2,1 m

Condition: good (used), Year of construction: 1976, operating hours: 9,999 h, functionality: fully functional, machine/vehicle number: 46244066, Technical Data for Technica AG / TECHNICA Type 5100 (also ZSM 5100 / AG 5100) Center / Center Hole / Universal Grinding Machine Technical Data – TECHNICA / ZSM 5100 Max. workpiece diameter approx. 125 mm Min. workpiece diameter approx. 8 mm Max. workpiece length / center distance approx. 1,100 mm Models up to 2,000 mm Minimum workpiece length 50 mm Maximum workpiece weight approx. 120 kg Certain versions up to 250 kg Cedpjxda Dujfx Addjaa Center hole diameter approx. 2-50 mm Taper angle of center hole approx. 60° Grinding wheel speeds depending on wheel diameter approx.: Ø 15 mm: 45,000 rpm Ø 27 mm: 22,500 rpm Ø 48 mm: 13,000 rpm Machine weight approx. 460 kg

Year of construction: 1981, condition: used, machine/vehicle number: 3328781, Stop adjustment in x-axis up to approx.: 1150 mm Casdebnpcwspfx Addsa Stop adjustment in y-axis up to: 150 mm for material thickness theoretically up to: 190 mm electrical connection: 380 V space requirement: 2050 x 850 x 1200 mm Weight: 138 kg

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, warranty duration: 12 months, Workpiece Clamping Diameter : ø 3 – 140 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 100 mm Workpiece Weight : max. 170 kg Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement Caedswv Nq Ropfx Addoa +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Semi-Auto Grinding Cone Dressing : Included Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Grinding Process : Manual Sectors: : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Cost Efficiency & High Productivity: Benefit from lower production costs and high productivity due to a short grinding process and reduced production times for subsequent processes (cylindrical grinding). Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex M-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors. Additionally, the Zentroflex M-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. Contact us for more details.

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, warranty duration: 12 months, Workpiece Clamping Diameter : ø 3 – 140 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 100 mm Workpiece Weight : max. 170 kg Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Grinding Process : Robotic, Complete-CNC Control Panel : Beckhoff CNC Movements : Z1-Axis, Z2-Axis, Workpiece clamping Feeding : Stäubli robot arm for loading, unloading and aligning Automatic Grinding Cone Dressing : Included Automatic Compensation After Dressing: Included Indurstry 4.0 Compatibility : Available Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Sectors: : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Non-Stop Production: Achieve continuous production with robotic arm feeding, automatic dressing, and automatic compensation features, eliminating the need for constant operator oversight. Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Easy to Use Complete-CNC Control Panel: Utilize a full CNC control panel that allows you to control all axes of the machine, manage robotic feeding, and perform automatic dressing with the Beckhoff control panel. Easily save all grinding programs and monitor machine working times, efficiency, and errors. Industry 4.0: Fully compatible with Industry 4.0 applications, thanks to the Beckhoff control panel. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex A-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors for mass-production. Additionally, the Zentroflex A-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. With 6-Axis robot arm and servo motors on all axes of the machine, Zentroflex A-series center hole grinding machines operate completely autonomously. All loading and unloading operations are performed by the robot arm. All axis movements of the machine are also performed autonomously with servo motors. Cone dressing and compensation are also performed automatically. All movements and measurements of the machine are performed from the CNC control panel. Caedpfx Adeu Nmi Nodja Contact us for more details.
