Used Mori Seiki Cnc for sale (197)

Condition: ready for operation (used), Year of construction: 2010, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 630 mm, table load: 400 kg, spindle speed (max.): 14,000 rpm, number of slots in tool magazine: 60, number of axes: 4, This 4-axis MORI SEIKI NH 4000 DCG was manufactured in 2010. It features an X-axis travel of 560 mm, Y-axis travel of 560 mm, and Z-axis travel of 630 mm. The machine has a spindle speed of 14,000 rpm and a tool magazine capacity of 60 positions. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI NH 4000 DCG horizontal machining centre we have for sale. Contact us for further details. Kjdpfx Aey Uw I Isfdonb • B-axis: Continuous Additional equipment • Pallet cubes: 250 × 250 × 600 mm and 400 × 150 × 600 mm • Various tooling • D'Andrea boring head attachment • Full machine manuals • SEI filtration/extraction unit • KUBE mist collector system Technical Specification Taper Size BT 40

Year of construction: 2000, condition: as good as new (ex-display), The following spare parts are available from a MORI SEIKI VL250, year of manufacture 2000: Kedpfscbinnox Afdjnb 1. Turret (not complete) Ball screw with nut, X and Z axis X and Z axis guide parts are from a new machine Motor, X-axis See photos.

Condition: used, Year of construction: 2010, turning diameter max. 320 mm turning length 810 mm control MSX 701 Number of revolutions max. 6.000 U/min power capacity - main spindel 22 / 18 kW max. usable bar diameter 52 mm C-Axis 0,001 ° spindle nose JIS A2-5 collet chuck 140 mm Number of revolutions max. 6.000 U/min power capacity - Sub spindle 22 / 18 kW max. usable bar diameter 52 mm C-Axis 0,001 ° spindle nose JIS A2-5 collet chuck 140 mm number of toolpositions 16 pos. Number of driven toolspositions 16 pos. Spindle speed - driven tools max. 6.000 min -1 power capacity - driven tools 7,5 / 5,5 kW Y - Axis 110 mm number of toolpositions 16 pos. Number of driven toolspositions 16 pos. Kedpfx Ajv E R E Aofdjnb Spindle speed - driven tools max. 6.000 min -1 power capacity - driven tools 7,5 / 5,5 kW x-travel 1/2: 210 mm y-travel 110 mm z-travel 1/2: 810 mm b-axis 900 mm total power requirement 86 kVA weight of the machine ca. 8,1 t dimensions of the machine ca. 8,0 x 3,5 x 2,8 m CNC - Turning- and MillingCenter MORI SEIKI - NZ 1500 T2Y - Main- and Subspindle - 2 turrets, up and below - Y-Axis - 2x 16 driven tool positions

Condition: used, Year of construction: 2013, x-travel 600 mm y-travel 530 mm z-travel 510 mm Control M 730 BM MAPPS IV max. spindle speed 10.000 min/-1 power capacity - main spindel 15 / 11 kW Knedpex R Enbjfx Afdsb tool taper SK 40 transmission ratio 1 spindle diameter in front bearing 80 mm table surface area 900 x 600 mm max. table load 800 kg T-slots 6x 18 x 100 mm distance spindle /table 150 - 660 mm number of toolpositions 30 pos. tool taper SK 40 max. tool diameter 80 mm max. tool-dia with free toolbox 150 mm max. tool length 300 mm max. tool weight 8,0 kg change-time tool to tool ca. 1,3 sec change-time chip to chip ca. 3,45 sec rapid traverse ( X / Y / Z ) 30 m/min feed speeds 1 - 30.000 mm/min Tipp feed 0 - 5.000 : 20 mm/min total power requirement 30 kVA weight of the machine ca. 6,0 t dimensions of the machine ca. 4,5 x 3,5 x 2,7 m CNC - Machining Center Vertical MORI SEIKI - NVX 5060 II / 40

Condition: used, Year of construction: 2008, turning diameter max. 320 mm turning length 810 mm control MSX 701 MAPPS III standard turning dia. 200 mm Main spindle: Number of revolutions max. 6.000 min/-1 power capacity - main spindel 22 / 18,5 kW Bar feed max. 52 mm Kjdetqmqwepfx Afdonb spindle bore 61 mm C-Axis 0,001 ° Subspindel: Number of revolutions max. 6.000 min/-1 power capacity - Sub spindle 22 / 18,5 kW Bar feed max. 52 mm spindle bore 61 mm C-Axis 0,001 ° Turret 1 + 3: number of toolpositions je 16 pos. Number of driven toolspositions je 16 pos. Spindle speed - driven tools max. 6.000 min -1 power capacity - driven tools 7,5 / 5,5 kW Y - Axis 110 (+65 / -45) mm Turret 2: number of toolpositions 16 pos. Number of driven toolspositions 16 pos. Spindle speed - driven tools max. 6.000 min -1 power capacity - driven tools 7,5 / 5,5 kW Y - Axis 110 (+45 / -65) mm axis stroke: x-travel 1-3: 210 mm y-travel 1-3: 110 mm z-travel 1+3: 300 / 2: 810 mm total power requirement 90 kVA weight of the machine ca. 9,3 t dimensions of the machine ca. 4,5 x 3,0 x 2,5 m CNC - Turning- and MillingCenter MORI SEIKI - NZ 1500 T3Y3 - Main- and Subspindle - 3 turrets, 2x upper / 1x below - 3x Y-Axis - 3x 16-pos. tool-drive - incl. 28x collets - incl. Hainbuch changing device

Condition: used, Year of construction: 2002, turning diameter 390 mm turning length 507 mm control MSG 805 MAPPS max. turning diameter 390 mm greates pass round over bed 680 mm Swing dia. over traverse guideway 510 mm centre distance 618 mm Knjdpfovzhiqjx Afdob turning speed range - main spindle 45 - 4.500 min/-1 power capacity - main spindel 11 / 7,5 kW spindle bearing diameter 110 mm spindle bore 73 mm max. bar capacity 51 mm spindle nose JIS A2-6 chucking diameter 210 mm C-Axis 0,001 ° x-axis 235 (195+40) mm z-axis 520 mm number of toolpositions 12 pos. Number of driven toolspositions 12 pos. Spindle speed - driven tool stations max. 3.000 min -1 power capacity driven tool-stations 5,9 / 4,5 kW Shank height for square tool 25 mm Drill shank diameter max. 50 mm turret change time 0,2 sec. tailstock adjustment 490 mm dia. of quill 85 mm taper of center MT 4 quill stroke 120 mm rapid traverse X: 18 / Z: 24 m/min Tipp feed 0 - 1.260 mm/min total power requirement 30,1 kW weight of the machine ca. 4,5 t dimensions of the machine ca. 5,0 x 2,5 x 2,5 m CNC - Turning- and Millingcenter MORI SEIKI - SL 204 MC

Condition: used, Year of construction: 2007, x-travel 560 mm y-travel 560 mm z-travel 630 mm Control MSX 701 III MAPPS Max. rpm 14.000 min/-1 power capacity - main spindel 18,5 / 11 kW max. Torque 120 Nm tool taper MAS BT 40 distance spindle center to table 80 - 640 mm distance Spindlenose and center of table 100 - 730 mm numbers of pallets 2 size of pallet 400 x 400 mm max. workpiece weight 400 kg max. workpiecediameter 630 mm max. workpiece height 900 mm change time of pallets 6,0 sec Kedpfxswbi Ado Afdonb b - axis 0,001 ° number of toolpositions 60 pos. tool taper MAS BT 40 max. tool diameter 70 / (140) mm max. tool length 400 mm max. tool weight 8,0 kg rapid traverse ( X / Y / Z ) 50 m/min feed speeds 0 - 50.000 mm/min Tipp feed 0 - 1.260 mm/min total power requirement 35 kVA weight of the machine ca. 9,8 t dimensions of the machine ca. 5,5 x 3,5 x 2,8 m CNC - Machiningcenter Horizontal MORI SEIKI - NH 4000 DCG - pallet-changer - Control options Program restart, cylindrical and spiral interpolation High-speed milling cycles, island and pocket milling cycles

Condition: used, Year of construction: 2011, turning diameter max. 320 mm turning length max. 810 mm control MSX-701 IV greates pass round over bed 800 mm Swing dia. over traverse guideway 800 mm distance between spindles 1.130 mm Number of revolutions max. 5.000 rpm power capacity - main spindel 25 / 22 kW max. Torque 358 Nm spindle diameter in front bearing 120 mm spindle bore 73 mm max. usable bar diameter 65 mm C-Axis 0,001 ° spindle nose JIS A2-6 collet chuck 160 mm Number of revolutions max. 5.000 rpm power capacity - Sub spindle 25 / 22 kW max. Torque 358 Nm spindle diameter in front bearing 120 mm spindle bore 73 mm max. usable bar diameter 65 mm C-Axis 0,001 ° spindle nose JIS A2-6 collet chuck 160 mm number of toolpositions 16 pos. Number of driven toolspositions 16 pos. Spindle speed - driven tools max. 6.000 min -1 power capacity - driven tools 7,5 / 5,5 kW Y - Axis 110 mm Shank diameter 20 x 20 mm Drill shank diameter 32 mm turret change time 0,18 sec. number of toolpositions 16 pos. Number of driven toolspositions 16 pos. Spindle speed - driven tools max. 6.000 min -1 power capacity - driven tools 7,5 / 5,5 kW Shank diameter 20 x 20 mm Drill shank diameter 32 mm turret change time 0,18 sec. x-travel 1/2: 210 mm y-travel 110 mm z-travel 1/2: 810 mm Traverses Subspindle B: 870 mm rapid traverse ( X / Y / Z ) 1: 30 / 20 / 50 m/min rapid traverse ( X / Y / Z ) 2: 30 / - / 50 m/min Tipp feed 0 - 5.000 mm/min Knodpfx Afsv E R E Nsdsb total power requirement 94 kVA weight of the machine ca. 8,3 t dimensions of the machine ca. 10,0 x 3,0 x 2,5 m CNC - Turning- and MillingCenter MORI SEIKI - NZ 2000 T2Y - Main- and Subspindle - 2 turrets, up and below - Y-Axis - 2x 16 driven tool positions

Condition: used, Year of construction: 1998, x-travel 1.020 mm y-travel 510 mm z-travel 510 mm control MSC 501 Fanuc table surface area (APC) 1.200 x 480 mm Ksdpfx Afsy Apcysdenb max. table load (APC) 550 kg turning speed range - milling 10.000 U/min power capacity - milling spindle 22 / 18,5 kW tool taper BT 40 number of toolpositions 30 pos. tool taper BT 40 max. tool diameter 80 mm max. tool-dia with free toolbox 125 mm max. tool length 300 mm max. tool weight 8 kg rapid traverse 32 m/min feed 1 ~ 16.000 mm/min Tipp feed 0 ~ 1.260 mm/min spindle bearing diameter 85 mm total power requirement 59,5 kVA weight of the machine ca. 6,9 t dimensions of the machine ca. 3,9 x 2,7 x 2,9 m CNC - Machining Center - Vertical MORI SEIKI - SV 500 B/40 - Clamping devices are NOT included in the scope of delivery

Condition: used, Year of construction: 2006, x-travel 600 mm y-travel 400 mm z-travel 400 mm control MSX 501 Mori Seiki table surface area 700 x 450 mm max. table load 350 kg number of T-slots 4 T-slot - width 18 mm T-slot - distance 100 mm Number of revolutions 12.000 U/min power capacity - main spindel 18,5 / 15 / 11 kW tool taper BT 40 max. Torque 110,5 Nm diameter of forward milling spindle bearing 70 rapid travel x/y/z 20.000 mm/min feed speeds 1 - 20.000 mm/min Tipp feed 15 Steps / 0 - 1.260 mm/min Number of Toolpositions in magazine 40 Pos. Max. mould width 80 mm max. tool-dia with free toolbox 125 mm max. tool length 250 mm max. tool weight 8 kg Knodpjv Az Ucjfx Afdjb change-time chip to chip 2,8 sec change-time tool to tool 1,0 sec total power requirement 34 kVA weight of the machine ca. 7,2 t dimensions of the machine ca. 2,8 x 3,0 x 2,9 m Machining Center Vertical MORI SEIKI - NV 4000 DCG - ca. 14.000 Operating-Hours

Condition: ready for operation (used), Year of construction: 1998, machine/vehicle number: 632, spindle speed (min.): 12,000 rpm, magazine for 40 tools BT40 toolholders Kodjvun H Nspfx Afdenb MSC-501 control system 2 pallets

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 669, travel distance X-axis: 560 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, controller model: MSC 502, rotational speed (max.): 12,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X-axis: 560 mm Travel Y-axis: 510 mm Travel Z-axis: 510 mm Distance spindle center to table: 50 – 650 mm Distance spindle nose to table center: 100 – 610 mm Main Spindle Max. speed: 12,000 rpm Drive power: 22 / 18.5 kW Tool holder: MAS BT-40 Spindle bearing diameter: 70 mm Pallet Changer Number of pallets: 2 Pallet size: 400 x 400 mm Max. workpiece diameter: 580 mm Max. workpiece height: 650 mm Knsdpfsy R U Ecox Afdjb B-Axis Switching time 90°: 2.5 sec Pallet changeover time: 6.0 sec Tool Changer Number of tool positions: 60 Max. tool diameter: 80 mm Max. tool diameter with adjacent magazine slots free: 125 mm Max. tool length: 300 mm Max. tool weight: 8 kg Tool-to-tool change time: 1.5 sec Chip-to-chip change time: 3.7 sec Rapid traverse (X/Y/Z): 32 m/min Feed rate: 1 – 24,000 mm/min Jog feed rate: 0 – 1,260 mm/min MACHINE DETAILS CNC control: MSC 502 Total power requirement: 63 kVA Dimensions & Weight Footprint approx.: 5.5 x 4.5 x 2.7 m Machine weight approx.: 9.0 t EQUIPMENT Documentation Chip conveyor Cooling device High-pressure coolant system Internal coolant supply Tool magazine: 60 positions Pallet changer Pallets: 2 Signal lamp B-axis Hydraulic unit Spindle oil cooler Note: Shaft for loading must be provided by the buyer.

Condition: ready for operation (used), Year of construction: 1989, functionality: fully functional, machine/vehicle number: 1764, controller manufacturer: Fanuc, No minimum price – guaranteed sale to the highest bidder! MACHINE DETAILS Ksdpfsy Sluqox Afdsnb Control: Fanuc EQUIPMENT Accessories as shown in the pictures

Condition: excellent (used), Year of construction: 2006, x-travel 750 mm y-travel 210 mm z-travel 1150 + 100 mm control Fanuc MSX-701III Maximum turning diameter 660 mm Max. turning length 1498 mm Diameter over cross slide max. 400 mm Kjdpfx Afsy Spuujdsnb number of spindle speeds 3000 U/min tool piece magazine with 40 Plätzen turret 10 Fach total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm

Condition: used, Year of construction: 1996, functionality: limited functionality, travel distance X-axis: 630 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 650 mm, controller model: Fanuc MSX-516, rotational speed (max.): 12,000 rpm, The P8 power supply, valued at €1,500, was only replaced in August 2024! The spindle was repaired in 2017 and has mostly only been used for single-layer operation since then! TECHNICAL DETAILS Travel range X-axis: 630 mm Travel range Y-axis: 600 mm Travel range Z-axis: 650 mm Feed length X-axis: 630 mm Feed length Y-axis: 600 mm Feed length Z-axis: 650 mm Table width: 500 mm Table length: 500 mm Number of pallets: 2 Maximum speed: 12,000 rpm Number of tool magazine slots: 60 (BT40) MACHINE DETAILS Control: Fanuc MSX-516 Phases: 3 Frequency: 50 Hz Voltage: AC 200 V Full load current: 181 A Note: The rapid traverse rate of the X-axis is reduced by 20% to extend the service life of the telescopic guides. The sealing ring during pallet changes is likely defective. The seller temporarily resolved this by inserting a ball valve in between when the pallets needed to be changed. EQUIPMENT Documentation/Manual Chip conveyor Knodpezcuyiofx Afdjb

Condition: used, TURNING CENTER "MORI SEIKI" MOD. ZL 200SMC With twin powered turret and sub-spindle CNC MSC-501 Turning length: 452 mm Max. turning diameter: 388 mm Max. diameter over bed: 510 mm Distance between centers: 751 mm Spindle mount: A2-6 Spindle speed: 4,000 rpm Spindle motor power: 11 kW Number of tools: 12 Knodpfxsxwxwte Afdob

Condition: used, Year of construction: 1988, turning diameter ca. 570 mm turning length ca. 530-610 mm control FANUC ohne Gewähr x-travel ca 160-200 mm Kedpsyiu Tpjfx Afdenb y-travel ca. 560 mm weight of the machine ca. 4,5 - 5 t ca 10 oder 12 spindle bore 52-76 mm weight of the machine ca. 4 t

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 71, turning length: 360 mm, turning diameter: 440 mm, spindle speed (max.): 5,000 rpm, bar passage: 45 mm, controller model: Fanuc 18iTA, TECHNICAL DETAILS Turning diameter: 440 mm Turning length: 360 mm Spindle speed: 50 - 5,000 rpm on both spindles Bar capacity: 45 mm Knsdpjy E Hpiofx Afdsb Spindle nose: ASA A2-5 C-axis: 0.001 on both spindles MACHINE DETAILS Control: Fanuc 18iTA Upper turret: 12 driven stations Lower turret: 12 driven stations Main spindle: 11 / 7.5 kW Sub spindle: 7.5 / 5.5 kW EQUIPMENT Chip conveyor Parts catcher Bar loader interface Bar loader: LNS Mini-Sprint S2 42/3M

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, workpiece weight (max.): 300 kg, spindle speed (max.): 12,000 rpm, The machine spindle was recently replaced. The corresponding report can be provided upon request. TECHNICAL DETAILS Travel X-axis: 730 mm Travel Y-axis: 510 mm Travel Z-axis: 510 mm Rapid traverse X-axis: 50 m/min Rapid traverse Y-axis: 50 m/min Rapid traverse Z-axis: 40 m/min Table width: 500 mm Table height: 870 mm Table length: 500 mm Table load capacity: 300 kg Rotary table diameter: 500 mm Rotational speed (max.): 1,200 rpm Kedey N N Suepfx Afdjnb Spindle speed (max.): 12,000 rpm Spindle interface: HSK-A63 Workpiece height (max.): 450 mm Workpiece weight (max.): 300 kg Tool length: 300 mm Tool diameter: 125 mm Tool weight: 8,000 g Number of tool magazine slots: 180 MACHINE DETAILS Control unit: Siemens 840 D Total weight: 14,800 kg Incoming voltage: 400 V EQUIPMENT Mori Seiki tool application manual KNOLL FKA/500 band filter system + 3 filter rolls Filtermist FX5000 emulsion extraction unit Renishaw OMP60 3D probe Chip conveyor Spindle chiller Documentation + circuit diagrams

Condition: good (used), Year of construction: 1999, 4-axis CNC lathe with sub spindle and 2 turrets Control: Fanuc 18iTA Upper turret: 12 driven stations Lower turret: 12 driven stations C-axis: 0.001° on both spindles Main spindle: 11 / 7.5 kW Sub spindle: 7.5 / 5.5 kW Spindle speed: 50 - 5,000 rpm on both spindles Bar capacity: 45 mm Spindle nose: ASA A2-5 Knjdpfxoy Enhmo Afdjb Turning diameter: 440 mm Turning length: 360 mm Chip conveyor Parts catcher Bar feeder interface Bar feeder: LNS Mini-Sprint S2 42/3M

Condition: good (used), Year of construction: 2003, functionality: fully functional, For sale used Mori Seiki VL-25A1 in excellent condition. Year: 2003 Knedpfx Ajuf Tb Ujfdeb Mori Siki Mori Siki Mori Siki Mori Siki, 2003. Delivery parity: EXW Székesfehérvár. We can assist in disassembling and assembling the machine on request.

Year of construction: 2004, condition: good (used), You can check under power, after scheduling an appointment. Kedpoidqwdsfx Afdjnb Dismantling, moving and transporting the machine is entirely the customer's responsibility. We can help with loading as needed. Parity: EXW Székesfehérvár

Condition: excellent (used), functionality: fully functional, Fixed tool holders Machine: MORI SEIKI SL2000 Turret manufacturer: SAUTER ---- Knsdpfx Afoynb E Njdjb 2x→ No. 444-119 Turning Tool Holder 25 mm steel holder Fixed turning tool holder Price: on request ----- 1x→ No. 444-201 Double Turning Tool Holder for main spindle and sub spindle with 1x clamping bar for 25 mm tool steels Fixed turning tool holder Price: on request ----- 1x→ No. 444-210 Boring Bar Holder Cylindrical mount ø 32 mm second mount ø 32 mm; 57 mm to the rear Price: on request ----- 1x→ No. 444-205 Turning Holder Mount 25 mm steel holder Price: on request

Condition: ready for operation (used), Year of construction: 2010, operating hours: 5,002 h, functionality: fully functional, machine/vehicle number: NT100JG0126, turning length: 424 mm, turning diameter: 370 mm, travel distance X-axis: 380 mm, bar passage: 52 mm, controller model: FANUC FS-31iA5 (MAPPS 4), TECHNICAL DETAILS Turning length: 424 mm Maximum turning diameter: 370 mm (270 mm with turret 2) Bar capacity: 52 mm Turn-mill spindle Full indexing specifications: Yes X-axis travel: 380 mm Y-axis travel: ±105 mm Z-axis travel: 460 + 155 mm (ATC) B-axis: ±120º Spindle speed: 12,000 rpm Drive power: 9/5.5 kW Tool magazine Magazine positions: 38 Tool holder: Capto C5 Maximum tool length: 250 mm (210 mm for tools under Ø70 mm) Maximum tool diameter: Ø70/Ø130 mm (with/without adjacent tools) Maximum tool weight: 5 kg Lower Turret X-axis travel: 155 mm Z-axis travel: 610 mm Number of tool stations: 10 Tool rotational speed: 6,000 min⁻¹ Driven tool power: 1.5/1.2 kW Main Spindle Spindle speed: 6,000 rpm Drive power: 11/7.5 kW Spindle bore: 73 mm Chuck type: Hollow chuck (8") Manufacturer: KITAGAWA Spindle nose: JIS A2-5 Maximum torque: 223 Nm Sub Spindle Spindle speed: 1,000 rpm BW axis: 4 fixed positions, 0º, -30º, -180º (-225º for overhang to conveyor, if equipped) MACHINE DETAILS Control: FANUC FS-31iA5 (MAPPS 4) Potential rated output: 39.24 kVA Knsdpfx Afey Edc Hsdob Dimensions & Weight Dimensions (L x W x H): 2,705 x 2,425 x 2,385 mm Weight: 8,800 kg Operating Hours Powered on: 54,061 hours Spindle 1 operating hours: 9,813 hours Spindle 2 operating hours: 5,002 hours EQUIPMENT Chip conveyor Signal lamp High-pressure pump Air blower outside the spindle Foot switch (double) for main and sub spindle

Condition: used, Year of construction: 1986, Technical details: x-travel: 800 mm y-travel: 460 mm z-travel: 510 mm total power requirement: 20 kW weight of the machine ca.: 8 t Vertical Processing Centre 20kW is the nominal value. The spindle only needs 7.5kW. It looks like 15kW will be enough. * Kodpfx Aewvblaofdenb
