Used Okuma Lt 2000 for sale (202)

Condition: excellent (used), Year of construction: 2014, turning length: 700 mm, travel distance X-axis: 205 mm, travel distance Z-axis: 700 mm, spindle motor power: 22,000 W, total height: 2,800 mm, total length: 6,000 mm, total width: 3,900 mm, overall weight: 9,800 kg, Complete machining with twin spindel, upper and lower turrets Kitagawa 3 chuck left and right Tool holders with driven tools axial and radial Large jaws cabinet with inserts OGL Gantry loader with ca 10 Kg load capacity Chip conveyor Paper Filtration Pressure Tank Max. turning Ø: 400mm X-Axis: 205mm Z-Axis: 700mm Spindle bore: 62mm Speedrange: 6000Rpm Spindle power: 22kW Subspindle speeds: 6000Rpm Subspindle bore: 62mm Subspindle power: 15kW ATC / revolver: 16 Speed live tools: 6000Rpm Positions lower revolver:16 Pgedpfx Ajyn Em Rskhsr Speed live tools: 6000Rpm Power live tools: 7kW Chip conveyor: yes Tool eye: yes Length: 6000mm Width: 3900mm Height: 2800mm Weight: 9800kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 2012, functionality: fully functional, 1 OKUMA CNC Lathe Model LT2000EX-2M1Y with OSPP200LA CNC Controller Including CE mark 1 set 〈European Standard Specification〉 1-1 Spindle motor VAC 11/7.5 kw (5 min./cont. ) 2 set 1-2 Spindle speed 50 - 6,000 min-1 2 set 1-3 Spindle dia. 62/100 mm, 140 Flat nose 2 set Pgjdpfxoy Rnbde Akhjr 1-4 C-axis control, 360 degree at 0.001 degree increment 2 set 1-5 Y-axis 95mm (+50 to -45) for upper turret 1 set 1-6 Upper V16 (turning & milling) + Lower V16 (turning & milling) Radial turret (No tool holder included) 1 set 1-7 Rotary tool drive motor, PREX 5.5/3.7kw (2 min/count) 2 set 1-8 Rotary spindle speed 45-6,000 min-1 2 set 1-9 Coolant supply system, 0.8kw x 3 sets pump motor 1 set 1-10 Work light, fluorescent lamp 1 set 1-11 Totally enclosed guard 1 set 1-12 Door interlock 1 set 1-13 Chip pan, side chip disposal type 1 set 1-14 Foundation washers and leveling jack screws 1 set 1-15 Machine lifting hooks 1 set 1-16 Chuck auto open / close with confirmation 2 set 1-17 Chuck air blower 2 set 1-18 Lubrication monitor B-1 1 set 1-19 CE mark and EMC 1 set 1-20 Application for IEC standard 1 set 1-21 Double chuck operation pedal 2 set 1-22 Synchronized tapping (for LT2000EX-M) for Milling rotary tool 1 set 1-23 OSP-P200LA CNC Controller with 15" colour display, touch panel 1 set 1-24 OSP-P200LA 3D-M-E kit specifications 1 set *Multitasking machines Coordinate conversion (1 set) *Multitasking machines Profile generation (1 set) *Program storage Standard: 2GB (1 set) *Operation buffer Standard: 2MB (1 set) *Real 3D simulation (1 set) *Cycle time over check (1 set) *Load monitor (spindle, feed axis) (1 set) *NC operation monitor (incl. counter and monitoring function) (1 set) *Cycle time reduction function (1 set) *Variable spindle speed control (1 set) 1-25 Pitch error compensation X + Ys + Z 1 set 1-26 Inch / metric switchable function 1 set 1-27 Workpiece jump out detection 1 set 1-28 Status indicator lamp (2-layer lamp) instead of status indicator in 3D-E kit 1 set 1-29 Electrical power source application to suite local power source at each countries (CE transformer) 1 set 1-30 Chuck open/close during spindle rotation (LT-Standard) 1 set 1-set of tools - see last photo

Condition: good (used), Year of construction: 2004, functionality: fully functional, Technical details turning diameter 210 mm turning length 700 mm control Okuma OSP-E 100 L total power requirement 35,7 kVA weight of the machine ca. 7,1 t dimensions of the machine ca. 2660 x 2000 x 2330* mm Additional information CNC turning and milling center with C-axis and Y-axis, 2 turrets, and subspindle. The machine is being sold partially overhauled. CNC control: Okuma OSP-E 100 L Maximum turning diameter: 210 mm Swing over bed: 400 mm Distance between spindle noses: 960 mm Main spindle: Spindle bore: 53 mm Speed range: 50 to 6000 rpm Motor power: 11/7.5 kW Subspindle: Spindle nose: JIS A2-6 Speed range: 38 to 5000 rpm Motor power: 11/7.5 kW Z-axis: Travel: 700 / 700 mm (ZA + ZB) Rapid traverse: 40000 mm/min W-axis: Travel: 940 mm Rapid traverse: 40000 mm/min X-axis: Travel: 167 / 192 mm (XA + XB) Rapid traverse: 30000 mm/min Y-axis: Travel: 92 mm (+50/-42 mm) Rapid traverse: 15000 mm/min C-axis: Indexing: 360 x 0.001 deg. Rapid traverse: 400 rpm Disc turret: 2 x 12 stations Tool holder mount: VDI 30 mm Power of driven tools: 4 kW Total connected load: 35.7 kVA Machine weight: 7100 kg Machine dimensions: 2660 x 2000 x 2330 mm* Plus swarf conveyor and bar loader Psdpfx Akszru Ukshegr Accessories FMB Turbo 5-42/6200/A bar loader, year of manufacture 2005 Chip conveyor Coolant system Collet chuck for main and subspindle Both turrets equipped with tool holders Machine documentation.

Condition: like new (used), Year of construction: 2024, functionality: fully functional, maximum turning diameter: 2000 mm maximum turning length: 1400 mm control: Okuma OSP - P300 SA maximum workpiece weight: 10,000 kg maximum workpiece dimensions: 2000 mm x 1400 mm chuck diameter: 2000 mm C-axis positionable to 0.001° tool spindle traversable in X/Y/Z and indexable in B B-axis swivels 150° Y-axis travel: 1600 mm (+/- 800 mm) coolant supply through tool spindle automatic dual pallet changer tool stations: 60, HSK 100 Pgedpjywg Aaofx Akhor The complete equipment of the machine can be found in the .pdf file.

Condition: used, Year of construction: 2015, functionality: fully functional, Model: OKUMA MULTUS U3000 2SW 1500 (CNC turning and milling center) Control: OKUMA OSP-P300S Turning length: approx. 1,500 mm Max. turning diameter: up to 650 mm Tool system / interface: HSK-A63 Main spindle: Drive power: 22 kW Torque: 427 Nm Max. speed: 5,000 rpm (2 gear stages) Spindle nose: Short taper size 6 Spindle front bearing: Ø 120 mm Spindle bore: Ø 80 mm 3. Counter spindle (Okuma motor spindle) Travel: Traversable on the W-axis Drive power: 22 kW Torque: 427 Nm Max. speed: 5,000 rpm Spindle nose: Short taper size 6 Spindle front bearing: Ø 100 mm Spindle bore: Ø 62 mm Tool spindle / Milling spindle (Okuma motor spindle) Drive power: 22 kW Torque: 120 Nm Max. speed: 12,000 rpm Tool holder: HSK-A63 Pgedpfx Aezu I U Askhsr Axes & Travel Ranges C-axis: 360° (Indexing / Positioning in 0.001° increments) Y-axis: Stroke +125 mm / -125 mm (Total stroke 250 mm) B-axis: 240° (Indexing / Positioning in 0.001° increments) Tool magazine & Turret Tool Magazine (ATC): 120 positions Lower turret: 12 stations with direct mounting system "radial" Turret guides: ZB-axis with cylindrical roller linear guide XB-axis with slide guide Coolant supply / Internal coolant supply (ICS): max. 20 bar (including bag filter) External cooling for tool spindle: max. 8 bar Accessories: Short loader LNS Quick Load Seri O III

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, Ref. No.: LT-2418 Manufacturer: Okuma Model: Multus U3000 1SW-1500 Control: Okuma OSP-P300S-H Year of manufacture: 2014 Commissioning: 2.015 Language Keyboards / Software: International / English Country of origin: Japan Technical Characteristics: Capacity: Turning on bed: Ø 650 mm Distance between points: 1.500 mm Maximum turning diameter: Ø 650 mm Pgedpfx Aou U E Avskhsr Maximum turning length: 1.500 mm Bar pitch (main spindle): Ø 70 mm Bar passage (opposite spindle): Ø 70 mm Main spindle: Spindle diameter: Ø 140 mm Spindle nose (type): JIS A2-8 Spindle inside diameter: Ø 80 mm Speed ranges: 2 ranges, infinitely variable Spindle speed: 50 - 4.200 rpm Motor: 22/15 kW (30 min/cont) Opposing spindle: Spindle diameter: Ø 140 mm Spindle nose (type): JIS A2-8 Spindle inside diameter: Ø 80 mm Speed range: 2 ranges, infinitely variable Spindle speed: 50 - 4.200 rpm Motor: 22/15 kW (30 min/cont) X-axis: Stroke: 645 mm Rapid traverse: 50.000 mm/min Z axis: Stroke: 1,600 mm Rapid traverse: 50.000 mm/min Y-axis: Stroke: 250 [± 125] mm Rapid traverse: 40,000 mm/min W-axis: Stroke: 1,594 mm Rapid traverse: 30.000 mm/min B axis: Controlled angle: -30° to +210° (increment 0.001°) Rapid traverse: 30 rev/min C axis: Controlled angle: 360° (0.0001° increment) Rapid traverse: 200 rpm Turret: Type: H1 Number of tools: 1 (L or M tool) Tool dimensions: Turning outside: 25 x 25 mm Turning inside: Ø 40 mm Milling head: Spindle speed: 50 - 12.000 rpm Speed ranges: 2 speed ranges, infinitely variable Motor: 25/19 kW (3 min/cont) Tool changer (ATC): Cone Toolholder: HSK-A63 Number of tools: 40 Max. diameter of adjacent tools: ø 90 mm Maximum diameter of non-adjacent tools: ø 130 mm Maximum tool length: 400 mm Maximum weight of each tool: 10 Kgf Dimensions and weights: Height of the machine: 2.905 mm Occupied floor area: 4,480 x 2,995 mm (4,480 x 2,995 mm) Machine weight: 16,200 kg

Condition: used, Year of construction: 2001, turning diameter: 210 mm, spindle bore: 53 mm, travel distance X-axis: 195 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 700 mm, rotational speed (max.): 6,000 rpm, overall weight: 6,500 kg, distance table center to spindle nose: 960 mm, OKUMA OSP-U100L control unit, with TOP AUTOMAZIONI XF370 bar feed system. Workholding and tooling are not included. Podpfx Aozw Nu Nokhegr MUST BE PICKED UP BY SEPTEMBER 2026.

Condition: used, Year of construction: 2004, functionality: fully functional, Max turning diam 720mm, max lenght 2,000mm, 12-2,800Rpm, Spindle bore 110mm, XA 660mm, XB 230mm, ZA 2.215mm, Y 250mm, ZB 2,100, B-axis 0.001dg, BT 50 Big Plus, 40-5,000Rpm, Lower turret VDI V12, Tail Stock MT5. Helix and Hobbing function, OSP E100L, Portal loder, weight 28.000kg. Delivery September 2026. Pgodpfozimqxsx Akhor

Condition: good (used), Year of construction: 2005, functionality: fully functional, turning length: 700 mm, turning diameter: 210 mm, spindle speed (max.): 5,000 rpm, overall weight: 7,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Max.: 210 mm Bench turning diameter: 400 mm Max. machinable length: 700 mm X/Z travel: 192/700 mm Stroke against spindle (W-axis): 730 mm Pgedpfx Akszhwnrohsr C-axis: 0.001° Rapid traverse X/Z: 30/32 m/min Main spindle speed: 5000 rpm Motor: 11/7.5 kW 2 turrets: 12 stations Machine dimensions: 2700 x 2000 x 1980 mm Machine weight: 7000 kg Equipment: 2 turrets, 12 stations, VDI 30 Measuring tool IRCO SiMag

Condition: like new (used), Year of construction: 2022, operating hours: 1,325 h, functionality: fully functional, Control unit: OKUMA OSP P300LA-e Pgodeziqp Sepfx Akhsr Swing over bed: D450 mm Swing over cross slide: D350 mm Max. turning diameter: 230 mm Max. turning length: 500 mm X-axis travel: 165 mm Z-axis travel: 470 mm Max. spindle speed: 5,000 RPM Drive capacity: 15 / 11 kW (20 min. / continuous) Spindle bore: D62 mm Turret: 12-station Max. tool size: 25x25 mm Tailstock quill taper: MT5 Weight approx.: 3800 kg Dimensions (LxWxH): 2600 x 1830 x 1700 mm Accessories and Equipment - Coolant system - Chip conveyor - 3-jaw chuck D250 mm - Built-in tool presetter arm - Foot pedals - Machine leveling feet - Manuals The machine has very low operating hours and is in like-new condition. Under power in our showroom.

Condition: good (used), Year of construction: 2006, Used lathe by OKUMA - Model: LT 200-M TwinStar Pgodpfxev S Su Ss Akhor - Year of manufacture: 2006

Condition: good (used), Year of construction: 2007, Used OKUMA lathe - Model: LT200-M TwinStar Podsv S Svvjpfx Akhegr - Year: 2007 - including chip conveyor - coolant tank - immediately available

Condition: ready for operation (used), Year of construction: 2013, spindle speed (max.): 6,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 550 mm, spindle motor power: 11,000 W, controller manufacturer: OKUMA, number of axes: 5, This 5-axis Okuma LB2000EX II was manufactured in 2013. It features a maximum turning diameter of 360 mm and a turning length of 500 mm. The machine includes a robust turret with 12 stations and a main spindle speed of 6,000 rpm. If you are looking to get high-quality turning capabilities, consider the Okuma LB2000EX II horizontal turning machine we have for sale. Contact us for further details. • Maximum turning diameter: 360 mm • Maximum turning length: 500 mm Pgedpfx Ajzcphuokher • Maximum bar capacity: 62 mm • W-axis travel: 500 mm • C-axis indexing: 0.001° • Main spindle nose: ASA 6" • Sub-spindle maximum speed: 6,000 rpm • Sub-spindle motor power: 11 / 7.5 kW • Turret stations: 12 • Driven tool speed range: 45–6,000 rpm • Driven tool motor power: 5.5 / 3.7 kW • Turning tool size: 20 × 20 mm • Boring bar capacity: Ø32 mm Additional equipment • Bar feeder: TOP XF365 (YOM 10/2013, installed 2014) • Hinge-type chip conveyor • Manual tool setter (presetting) • Parts catcher Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: ready for operation (used), Year of construction: 2021, spindle speed (max.): 5,000 rpm, travel distance X-axis: 270 mm, travel distance Y-axis: 120 mm, spindle motor power: 22,000 W, total height: 2,330 mm, overall weight: 10,000 kg, product length (max.): 3,530 mm, number of axes: 5, This 5-axis Okuma LT 300 MY was manufactured in 2021, featuring a max turning diameter of 350 mm and a bar capacity of 65 mm. It supports spindle speeds up to 5,000 RPM and includes a motorized 12-position turret. Ideal for complex turning operations, the machine also offers rapid traverse rates and a substantial distance between centers of 1,200 mm. Consider the opportunity to buy this Okuma LT 300 MY horizontal turning machine. Contact us for more information. • Distance between centers: 1,200 mm • Max turning diameter: 350 mm • Rotating diameter over guards: 550 mm • Spindle / counter-spindle: ASA 8 • Bar capacity: 65 mm Pgedpfex Imriox Akhjr • Tailstock / counter-spindle travel (W axis): 940 mm • X axis travel: 270 / 230 mm • Y axis travel: ±60 mm • Z axis travel (ZA / ZB): 930 / 920 mm • Rapid traverse (X / Z / W): 30 / 40 / 40 m/min • Rapid traverse Y axis: 26 m/min • Turret: 12 positions, motorized, VDI 40 • Turret indexing time: 0.25 s • Live tooling speed / power: 100–4,500 rpm, 7.0 / 3.3 kW

Condition: good (used), Year of construction: 2006, functionality: fully functional, turning length: 900 mm, turning diameter: 450 mm, Used Okuma Multus B300-W multi-function CNC lathe including newer Kuka robot 70 kg (1–2 years old), without handling set-up. Podpfxjyux S Ho Akhjgr

Condition: good (used), Year of construction: 2007, functionality: fully functional, turning length: 1,500 mm, turning diameter: 710 mm, Used Okuma Multus B400W Max. turning diameter Ø 710 mm Turning length 1500 mm Kuka robot 140 kg without handling attachment 2 spindles, 7 axes, loading conveyor - loading station - unloading station - 950 mm swing 12+15" chuck 70 bar high-pressure pump Pjdsyrf T Sepfx Akhogr

Condition: good (used), Year of construction: 2000, Well-maintained, used CNC lathe from Okuma. Type: LT10-M Capacity: ø 210 x 130 mm Pedpfezhal Hsx Akhegr Spindle bore: ø 53 mm Okuma OSP-U100L control system Further specifications can be found in the data sheet.

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, Dear Sir or Madam the details of the Okuma Multus B400 with main and counter spindle tool magazine HSK 63 with 80 places 1500mm turning length main spindle passage 100mm CNC turning/milling center with CNC control OKUMA OSP P200L Enlarged main spindle Ø110mm Ø150/110mm, spindle nose size 11 Speed range 38-2800 1/min. Counter spindle as W-axis incl. hollow clamping device with Ø70mm bore in the draw tube helical interpolation also for thread milling Tool height correction in Y-axis for turning tools Extension kit "M "OSP P200L (Kit One-Touch IGF-M-D) Software multifunction tool for the use of special tools 80-station tool changer instead of 20 stations C-axis synchronization software for simultaneous control of both C-axes Increased speed 10,000 rpm for driven tools 20/14 kW, max. 85 Nm Interlit ISF 540/6670 slat-band chip conveyor with integrated coolant tank Interlit SPB4 gravity belt filter with 900 L clean tank Supply pump TH 90/690 FSI frequency-controlled pump for gravity belt filter SPB 4 Manual rinsing gun for attachment to additional coolant tank SPB4 SMW VNK 250/110 Power clamping cylinder for hollow sp. m. Bore Ø 110.5 mm Chuck Rota THW Plus 315-104 A11 Cylinder SMW VNK 250/110 2-stage clamping pressure for power clamping device Call by program Door automation Multus B 400 Open/close via M command two doors, both open simultaneously Chuck Rota THW Plu 315-104 A8 Cylinder SMW VNK 225/95 mounted. Year of construction: 2011 Commissioning: June 2011 Podpfotdg Evjx Akhegr Warranty: A warranty for the used machine is excluded altogether. However, HAF Präzisionstechnik assures that defects, including hidden defects, are not known. Unknown defects can therefore not be excluded. Machine is under power and in very good condition. Viewing is possible by arrangement. We are also happy to process your acceptance parts in advance.

Condition: excellent (used), OKUMA control system Turning diameter: 650 mm Turning length: 1450 mm For technical specifications, see the photo. Podsyxrggspfx Akhegr The price of the machine includes the accessories shown in the photo.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, turning length: 900 mm, turning diameter over cross slide: 630 mm, turning diameter: 450 mm, spindle motor power: 22,000 W, spindle speed (min.): 38 rpm, spindle speed (max.): 3,800 rpm, spindle bore: 80 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 945 mm, mount diameter: 130 mm, rapid traverse X-axis: 40,000 m/min, rapid traverse Y-axis: 26,000 m/min, rapid traverse Z-axis: 40,000 m/min, total height: 2,600 mm, total length: 3,750 mm, total width: 2,050 mm, spindle nose: JIS A2-6, travel distance W-axis: 1,000 mm, Equipment: documentation/manual, Turn-mill center OKUMA Multus B300-W Pgodpfsw Eip Sox Akhjr TECHNICAL CHARACTERISTICS : CNC control : OSP-P200L Distance between centers : 900 [mm] Max. cutting diameter : 630 [mm] Height of centers over cariage: 630 [mm] Max. swing over bed: 630 [mm] Stroke X axis: 580 [mm] Stroke Y axis: -80 / +80 [mm] Stroke Z axis: 935 [mm] Stroke W axis: 1000 [mm] B axis indexing precision: 0.001 [°] Milling head max. speed: 10000 [rpm] Milling head spindle attachment: HSK-A63 Max. milling spindle power :16 [kW] Tool magazine capacity: 60 Max. tool length :300 [mm] Max. tool diameter: 130 [mm] Max. weight of single tool: 8 [Kg] Rapid traverse rate X axis: 40000 [mm/min] Rapid traverse rate Z axis: 40000 [mm/min] Rapid traverse rate Y axis: 26000 [mm/min] Rapid traverse rate W axis: 20000 [mm/min] Spindle nose: JIS A2-6 Min. spindle speed :38 [rpm] Max. spindle speed: 5000 [rpm] Increment C-axis :0.001 [°] Spindle power: 22 [kW] Counter spindle nose: JIS A2-6 Min. counter spindle spindle speed: 38 [rpm] Max. counter spindle speed: 5000 [rpm] Counter spindle power :15 [kW] Total power required :39.3 [kVA] Rated current :56.7 [A] Supply voltage :400 [V] Machine dimensions: 4340 x 2050 x 2600 ADDITIONAL INFORMATION : x1 One-Touch IGF software option (CD-ROM also for PC programming) x1 remote electronic handwheel x1 2-colour status light x1 chip conveyor x1 coolant tank

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 132542, turning diameter over cross slide: 470 mm, turning length: 300 mm, turning diameter: 580 mm, spindle bore: 62 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 380 mm, spindle motor power: 11,000 W, rapid traverse X-axis: 25 m/min, rapid traverse Z-axis: 30 m/min, total height: 1,839 mm, total length: 1,865 mm, total width: 1,734 mm, overall weight: 3,200 kg, Equipment: documentation/manual, OKUMA LB2000EX-MC x 300mm OSP P200L CNC-Controller Number of axis - 3 Swing over bed - 580mm Swing over cross slide - 470mm Max dia. turning - 360 mm Max turning length - 300 mm X axis travel - 260 mm Z axis stroke - 390 mm Rapid X-axis 25,000 mm/min Z axis rapid 30,000 mm/min Spindle nose - Flat Main spindle speed - 6000 rpm Main spindle power - 11 kW Main spindle diameter - 100 mm Kitagawa 6 inch chuck Driven tools - 6000rpm Driven tools - 5,5kW Turret type VDI 12 Stations Square tool section - 20mm Boring bar section - 32mm Tailstock Quill diameter - 70mm NC tailstock stroke - 415mm Pedexrnr Nepfx Akhogr Konus - MK 4 Chip conveyor type high Wight - 3200kg One Touch dialog with colour High presure coolent

Condition: good (used), Year of construction: 2008, - Max. turning diameter over bed: 700 mm - Turning length: 1,500 mm Main spindle: - Speed range: 2,800 rpm - Enlarged main spindle: Ø 150 mm, bore: 110 mm - Drive power: 30 kW, 900 Nm - Spindle nose: Size 11 Total power requirement: 59.5 kVA Approx. machine weight: 14.5 t Space requirement approx.: 6.4 x 3.0 x 2.6 m Pgodpfx Akjxmirgehjr EQUIPMENT: - 3-jaw chuck, SMW KNCS-N 400 K11 - Tailstock - Programmable CNC steady rest slide (cross slide NOT retractable) - SMW-AUTOBLOK SLU-3, self-centering steady rest, clamping range Ø 12 - 152 mm - Full clamping cylinder for partial hollow clamping, draw tube bore max. Ø 100 mm - In-process measuring system Renishaw for X-/Z-/C-axis - Programmable CNC tailstock on W-axis - Drilling/milling spindle and C-axis 0.001° - Tool changer: 80 positions Tool system: HSK-A63 - Y-axis travel +115/-115 = 230 mm - B-axis 225°, positioning in 0.001° increments - ICS / internal coolant supply for driven tools - Synchronized thread cutting with driven tools - Software for use of multifunctional tools, e.g. special tool with radially arranged indexable inserts, which can be positioned in the drilling/milling spindle at 60°, 90°, 120° and 180° positions - Software for gear hobbing for straight and helical gearing with speed synchronization of main and milling spindles - Electrostatic extraction unit - Chip conveyor - Documentation - CE marking

Condition: good (used), Year of construction: 2005, operating hours: 16,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, controller manufacturer: Okuma, controller model: OSP E100M, table width: 500 mm, table length: 500 mm, spindle speed (max.): 15,000 rpm, operating hours of spindle: 12,000 h, coolant supply: 70 bar, spindle nose: BT 40, number of spindles: 1, number of slots in tool magazine: 60, Equipment: chip conveyor, Horizontal machining center Okuma MB 500H with a 2-position pallet changer Podpfx Aszv Iabekhegr Year of manufacture: 2005 Control system: Okuma OSP E100M Technical data: Spindle speed: 10 - 15,000 rpm Drive power: 26 kW Tool holder: BT 40 Number of magazine positions: 60 Internal coolant pressure: 70 bar Travel distances: X-axis: 800 mm Y-axis: 800 mm Z-axis: 800 mm 4th axis: Index 1° Number of pallets: 2 Pallet size: 500x500 mm Accessories: - Coolant system, type ConSep 2000, by Mayfran - Chip conveyor, type ConSep, by Mayfran - Tool breakage monitoring in the magazine - Workpiece coolant shower

Condition: good (used), Year of construction: 2008, functionality: fully functional, Okuma Multus B300-W 6-axis turning and milling center - Okuma OSP P200L - Year 2008 - Cutting time: 10,500 h - H1 milling spindle: 6,000 rpm - Main spindle: 3,800 rpm, Rota NC 315-86 - Counter spindle: 5,000 rpm - ATC 60 system HSKA-63 (60 tools) Pgedpfeyg Rf Nex Akhor - Geometry: very good - Marpos tool sensor

Condition: excellent (used), functionality: fully functional, Commissioning: as Okuma stock machine 09.2017 Control OSP P300S Machine Equipment ▪ Enlarged main spindle KK size 11 Front bearing Ø 160 mm Speed range 3,000 rpm Bore Ø 112 mm Motor with 32 kW output Torque 955 Nm ▪ Hollow clamping cylinder Ø 127 mm SMW VNK 320-127 with bore Ø 127 mm ▪ Pressure reducing valve Adjustable range 8-70 bar ▪ Tailstock ▪ Turning length approx. 1500 mm ▪ H1 turret (1 station) ▪ Y-axis ▪ B-axis 0.001° ▪ 40-station tool magazine ▪ Additionally: lower turret with 12 stations ▪ Tool spindle 12,000 rpm ▪ Hinged belt chip conveyor: high-performance chip conveyor with low-maintenance self-cleaning function ▪ Drum sump filter TMF300 with clean tank 980 l Pjdpfx Ajyviigjkhjgr ▪ Supply pump TC160/740, 8 bar ▪ Supply pump RSP 20/32-070-1-1-0, 70 bar ▪ Self-centering steady rest on the lower turret (not possible in combination with driven tools for the lower turret) ▪ Automatic door ▪ Robot interface type E for connecting other loading and unloading systems to single-spindle machines ▪ 3D machine model for simulation in a CAM system Technical Details ▪ Main drive (Okuma motor spindle): 22 kW / 700 Nm / 50–4,200 rpm Spindle nose KK size 8 Front spindle bearing Ø 140 mm Spindle bore Ø 91 mm Speed range: 2-stage Range switching at full speed ▪ Lower turret: 12 stations In ZB-axis with cylindrical roller guide In XB-axis with slide guide ▪ Real-time collision avoidance system CAS ▪ 19" color LCD TFT (1280x1024) with 3D color graphics as touchscreen/panel with vertical display and tiltable keyboard (adjustable angle) ▪ Second operating system Windows 7 for operation and data communication, open and freely usable for Windows 7 compatible applications ▪ Programmable tailstock on W-axis with hydraulic quill ▪ Tool magazine 40 stations ▪ C-axis 360° Positioning in 0.001° steps ▪ Y-axis with travel +150/-150 = 300 mm ▪ B-axis 240° Positioning in 0.001° steps ▪ Tool spindle (Okuma motor spindle): 22 kW / 120 Nm / 12,000 rpm ▪ Internal coolant supply for rotating tools, pump with max. pressure 20 bar Including bag filter, external cooling tool spindle, pump with max. pressure 3 bar ▪ Tool system HSK-A63 ▪ Tool monitoring system for tool life and breakage ▪ Tool measurement system (with standard chuck) for safe setup ▪ Machine management MacMan with integrated BDE (operating data acquisition) ▪ Parts program memory 2 GB ▪ Max. length individual part program 2 MB ▪ 2 USB 2.0 ports ▪ Ethernet interface with browser and DNC-T1 for program transfer ▪ Harmonic speed oscillation via periodic speed change ▪ Tool height correction in Y-axis for turning tools ▪ Circular thread milling X/Z/Y/B (helical interpolation) Including eccentric milling X/Y/C ▪ Hi-Cut Pro high-speed control for rotating tools ▪ 10 workpiece zero points (coordinate system selection) ▪ Coordinate conversion (shift, rotate) ▪ Electronic spindle orientation + / - 0.1°
